TABLE OF CONTENTS

Product Record

Read and Save These Instructions

Record Your Model and Serial Numbers

Record below the model and serial numbers found on the laundry center serial plate located on the inside of the dryer door. Keep these numbers for future reference.

Model Number:______________________________

Serial Number:_______________________________

Purchase Date:_______________________________

This Use & Care Guide provides general operating instructions for your laundry center. It also contains information about features for several other models. Your laundry center may not have every feature included. Use the laundry center only as instructed in this Use & Care Guide.

Note: The instructions appearing in this Use & Care Guide are not meant to cover every possible condition and situation that may occur. Common sense and caution must be practiced when installing, operating and maintaining any appliance.

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

LAUNDRY CENTER SAFETY

Your safety and the safety of others is very important.

We have provided many important safety messages in the Use & Care Guide, Operating Instructions, Installation Instructions and on your appliance. Always read and obey all safety messages.

This is the safety alert symbol. This symbol alerts you to hazards that can kill or hurt you or others. All safety messages will be preceded by the safety alert symbol and the word "DANGER" or "WARNING". These words mean:

DANGER

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

explosion or to prevent property damage, personal injury or loss of life.

- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

- WHAT TO DO IF YOU SMELL GAS:

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.

• If you cannot reach your gas supplier, call the fire department.

Installation and service must be performed by a qualified installer, service agency or the gas supplier.

You will be killed or seriously injured if you don't follow instructions.

You can be killed or seriously injured if you don't follow instructions.

For your safety, the information in this manual must be followed to minimize the risk of fire or

rounding type

GAS

wall receptacle

Grounding type wall receptacle

LAUNDRY CENTERS:

Do not under

Do not under any

any circumstances

circumstances cut,

cut, remove,

remove, or bypass

or bypass

the grounding prong

from this plug

from this plug.

Power supply

CORRECTCORRECT

CORRECT

CORRECTCORRECT

cord with 3-prong

Use this way ONLYUse this way ONLY

Use this way ONLY

Use this way ONLYUse this way ONLY

rounding plu

Do not use or mix liquid chlorine bleach with other household chemicals such as toilet cleaners, rust removers, acid or products containing ammonia. These mixtures can produce dangerous fumes which can cause serious injury or death.

Power supply cord with 3-prong grounding plug

Avoid fire hazard or electrical shock. Do not use an adaptor plug or extension cord or remove grounding prong from electrical power cord. Failure to follow this warning can cause serious injury, fire or death.

IMPORTANT: If the supply cord is damaged, it should be replaced by the manufacturer or qualified service representative to avoid any kind of risk.

Important Safety Instructions

You can be killed or seriously injured if you don't follow these Important Safety

Read all instructions before using this laundry center.

Instructions:

• To reduce the risk of fire, electrical shock, or injury to persons when using this laundry center, comply with the basic warnings listed below.

• Failure to comply with these warnings could result in serious personal injuries.

Prevent Fire

• Do not wash or dry items that have been previously cleaned in, soaked in, or spotted with gasoline, cleaning solvents, kerosene, waxes, etc. Do not store these items on or near the dryer. These substances give off vapors that could ignite or explode.

• Do not place items exposed to cooking oils in your dryer. Items contaminated with cooking oils may contribute to a chemical reaction that could cause a load to catch fire.

• Do not put oily or greasy rags or clothing on top of the laundry center. These substances give off vapors that could ignite the materials.

• Do not add gasoline, cleaning solvents, or other flammable or explosive substances to the wash water. These substances give off vapors that could ignite or explode.

• Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using the washer, turn on all hot water faucets and let the water flow from each for several minutes. This will release any accumulated hydrogen gas. Hydrogen gas is flammable; do not smoke or use an open flame during this time.

• To prevent fire, do not use heat to dry items containing plastic, foam rubber or similarly textured rubber-like materials, or items containing feathers or down. Use Air Fluff (No Heat) only.

• Clean the dryer lint screen before or after each load. The interior of the dryer, lint screen housing and exhaust duct should be cleaned approximately every 18 months by qualified service personnel. An excessive amount of lint build-up in these areas could result in inefficient drying and possible fire. See Care and Cleaning.

• Do not operate the dryer if the lint screen is blocked, damaged or missing. Fire hazard, overheating and damage to fabrics can occur. If your dryer has a drying rack, always replace the lint screen when finished using the drying rack.

• Keep area around the exhaust opening and surrounding areas free from the accumulation of lint, dust and dirt.

Important Safety Instructions Con't

• Do not obstruct the flow of ventilating air. Do not stack or place laundry or throw rugs against the front or back of the laundry center.

• Do not spray any type of aerosol into, on or near laundry center at any time.

• Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of the fabric softener or product.

• Failure to comply with these warnings could result in fire, explosion, serious bodily injury and/or damage to the rubber or plastic parts of the laundry center.

Protect Children

• Do not allow children to play on or in the laundry center. Close supervision of children is necessary when the laundry center is used near children. As children grow, teach them the proper, safe use of all appliances.

• Destroy the carton, plastic bag and other packing materials after the laundry center is unpacked. Children might use them for play. Cartons covered with rugs, bedspreads or plastic sheets can become airtight chambers.

• Keep laundry products out of children's reach. To prevent personal injury, observe all warnings on product labels.

• Before the laundry center is removed from service or discarded, remove the washer lid and dryer door to prevent accidental entrapment.

• Failure to comply with these warnings could result in serious personal injuries.

Prevent Injury

• To prevent shock hazard and assure stability during operation, the laundry center must be installed and electrically grounded by a qualified service person in accordance with local codes. Installation instructions are packed in the laundry center for the installer's reference. Refer to INSTALLATION INSTRUCTIONS for detailed grounding procedures. If the laundry center is moved to a new location, have it checked and reinstalled by a qualified service person.

• To prevent personal injury or damage to the laundry center, the electrical power cord of a gas laundry center must be plugged into a properly grounded system. Never ground the laundry center to a gas pipe.

Do not use an extension cord or an adaptor plug.

• Follow package directions when using laundry products. Incorrect usage can produce poisonous gas-resulting in serious injury or death.

- Do not combine laundry products for use in 1 load unless specified on the label.

- Do not mix chlorine bleach with ammonia or acids such as vinegar.

• To prevent serious personal injury and damage to the laundry center:

- All repairs and servicing must be performed by an authorized servicer unless specifically

recommended in this Owner's Guide. Use only authorized factory parts.

- Do not tamper with controls.

- Do not install or store the laundry center where it will be exposed to the weather.

• ALWAYS disconnect the laundry center from the electrical supply before attempting any service or cleaning. Failure to do so can result in electrical shock or injury.

• Do not use any type spray cleanser when cleaning dryer interior. Hazardous fumes or electrical shock could occur.

• To prevent injury, do not reach into the washer while parts are moving. Before loading, unloading or adding items, push in the cycle selector knob and allow the tub to coast to a complete stop before reaching inside.

• To prevent injury, do not reach into the dryer if the drum is moving. Wait until the dryer has stopped

completely before reaching into the drum.

• A thermal limiter switch automatically turns off the dryer motor in the unlikely event of an overheated situation (electric dryers only). A service technician must replace the thermal limiter switch after correcting the fault.

• The washer is equipped with an electrical overload protector. The motor will stop if it becomes overheated The washer will automatically restart after a cool down period of up to 30 minutes, if the washer has not been manually turned off during this time.

• Failure to comply with these warnings could result in serious personal injuries.

Washing Procedures

Sort laundry into loads that can be

washed together.

Empty pockets.

• Follow the guidelines below for preparing the wash load.

• Read the Washer Operating Instructions for operating your specific

model.

• Always read and follow fabric care and laundry product labels.

To reduce the risk of fire, electrical shock, or injury to persons,

read Important Safety Instructions before operating this washer.

1. Sort laundry into loads that can be washed together.

Sort items by recommended water temperatures, wash time, and agitate/

spin speeds.

• Separate white, light, and colorfast items from dark and noncolorfast items.

• Separate items which shed lint from items which attract lint. Permanent press, synthetic, knit and corduroy items will pick up lint from towels, rugs and chenille bedspreads.

• Separate heavily soiled items from lightly soiled items.

• Separate lacy, sheer and loosely knit items from sturdy items.

2. Prepare items for washing.

• Empty pockets.

• Brush off lint and dirt. Shake out rugs and beach towels.

• Close zippers, fasten hooks, tie strings and sashes, and remove

nonwashable trims and ornaments.

• Remove pins, decorative buttons, belt buckles, and other objects which could be damaged. This also helps protect other items in the wash load.

• Mend rips and tears to prevent further damage during washing.

• Place delicate items such as bras, shoulder pads, hosiery, and belts in

a mesh bag to prevent tangling during the wash cycle.

• Turn knit items inside out to prevent pilling.

Place delicate items in a mesh bag.

Bleach Dispenser (some models)

3. Pretreat stains and heavy soil. See Stain Removal for details.

4. Add a measured amount of detergent to the wash tub before

adding the laundry load.

Follow detergent manufacturer's directions. The amount required depends

on type of detergent, load size and soil level, and water hardness.

5. If desired, add liquid bleach to Bleach Dispenser (some models).

• Before adding the wash load, add liquid bleach to bleach dispenser

located in left front corner under the lid:

• 3/4 cup (180 ml) for small loads

• 1 cup (240 ml) for large loads

• 1-1/4 cups (300 ml) for extra-large loads.

• Then add 1 cup (240 ml) water to flush the dispenser.

• Do not use powdered bleach in the bleach dispenser.

For models without a bleach dispenser, dilute the recommended

amount of liquid chlorine bleach in 1 quart (.95 L) water. Add it to wash water after a few minutes of agitation. Do not pour bleach directly on

wash load.
