Frigidaire 134031900C User Manual

TUMBLE ACTION WASHER

Use & Care Guide

MACHINE À LAVER PAR CULBUTAGE

Guide de L’utilisateur

LAVADORA CON TAMBOREACCIÓN

Manual de Uso & Mantenimiento

Contents

Warranty and Service (U.S.)...........................................................2

Important Safety Instructions....................................................3

Washing Procedures...............................................................4-6

Stain Removal..........................................................................6-7

Common Washing Problems.....................................................8

Care and Cleaning......................................................................9

Avoid Service Checklist............................................................10

Warranty and Service (Canada)..................................................11

Français............................................................................... 12-22

Consignes de sécurité importantes........................................12

Instructions de lavage........................................................13-15

Détachage............................................................................15-16

Problèmes de lessive courants.................................................17

Entretien et nettoyage.......................................................18-19

Guide de dépannage.........................................................19-20

Service (Canada).......................................................................21

Garantie (Canada)...................................................................22

Español................................................................................23-32

Instrucciones importantes para la segurid............................23

Prodedimientos para el lavado..........................................24-26

Eliminación de manchas....................................................26-27

Problemas comunes del lavado..............................................28

Cuidado y limpieza...................................................................29

Lista de comporbacion para evitar el servicio....................... 30

Garantía y Servicio (E.E.U.U.).....................................................31

Back Cover.................................................................................32

Product Registration
Thank you for choosing this washer. This

owner's guide will explain proper operation
and care.

Register Your Product
The self-addressed PRODUCT
REGISTRATION CARD should be filled in

completely, signed and returned.

Enregistrement du produit
Merci d’avoir choisi cette laveuse. Le présent

Guide de l’utilisateur décrit les normes
d’utilisation et d’entretien du produit.

Enregistrer le produit

La CARTE D’ENREGISTREMENT préalablement
adressée doit être remplie en entier, signée et
retournée.

Registro del Producto
Le agradecemos que haya seleccio-nado esta
lavadora. En este manual del usuario encontrará

las intrucciones apropiadas para su
funcionamiento y cuidado.

Registre su Producto

La TARJETA DE REGISTRO DEL PRODUCTO ya
dirigida debe ser llenada, firmada y enviada.

Read and Save These Instructions

Record Your Model and Serial Numbers

The model and serial numbers of your washer are found on the washer serial
plate located at the top, inside of the door opening. Record and retain these
numbers.

Lisez et conservez ces instructions

Le numéro de modèle et de série de votre machine à laver par culbutage se
trouve, sur la plaque signalétique située sur la partie supérieure de la contre­porte. Notez et conservez ces numéros.

Anote su Número de Modelo y de Serie

Anote a continuación el número de modelo y de serie que se encuentran en la placa
de serie situada en el interior de la puerta de la lavadora. Conserve estos números
para referencia futura.

Model Number:
Número de Modelo:
Numéro de modèle:

Serial Number:
Número de Serie:
Numéro de série:

Purchase Date:
Fecha de compra:
Date d’achat:

www.frigidaire.com

1

P/N 134031900C (0504)

FRIGIDAIREFRIGIDAIRE

FRIGIDAIRE

FRIGIDAIREFRIGIDAIRE

Tumble Action Washer Warranty

WW

ARRANTY LENGTH:ARRANTY LENGTH:

W

ARRANTY LENGTH:

WW

ARRANTY LENGTH:ARRANTY LENGTH:

FULL ONE-YEAR
WARRANTY

From Date of Purchase

LIMITED 2nd-5th YEAR
WARRANTY

From Date of Purchase

FRIGIDAIRE WILL P FRIGIDAIRE WILL P

FRIGIDAIRE WILL P

FRIGIDAIRE WILL P FRIGIDAIRE WILL P

AA

Y FOR:Y FOR:

A

Y FOR:

AA

Y FOR:Y FOR:

Labor and replacement parts which prove to be defective in materials or workmanship.

Any warranty service must be provided by Frigidaire or an authorized Frigidaire
service company.

Replacement part for the motor, driven pulley or motor controller
which prove to be defective.

Keep your sales receipt!

LIMITED 2nd-25th YEAR
WARRANTY

From Date of Purchase

FRIGIDAIRE WILL NOT PFRIGIDAIRE WILL NOT P

FRIGIDAIRE WILL NOT P

FRIGIDAIRE WILL NOT PFRIGIDAIRE WILL NOT P

1. Service calls where the problem is not the fault of the washer. Below are some, but not every example
of issues where you must pay the service call cost.

Service calls to:

• remove shipping devices or to level your washer

• correct leaks at water inlet hose connections

• correct improper placement of drain hose in your drain

2. Repairs for washer used in a commercial application or more than single-family household use.

3. Repairs for delivery damage to your washer or damage caused by misuse, fire, flood, acts of God, or use of parts or servicers not

4. Any labor costs during the limited warranties.

5. Travel costs of servicer to your home in the state of Alaska.

6. Pickup, delivery or installation of your washer.

7. Repairs on products with serial plates that have been altered, removed, or cannot be read.

8. Consequential or incidental damages such as property damage and incidental expenses resulting from any breach of this written or

Keep your sales receipt. The date on the receipt establishes the warranty period should service be required. This written warranty gives

you specific rights. You may also have other rights which vary from state to state. If you need service, first read “Avoid Service Checklist”
section of this booklet. If service is still needed, contact Frigidaire Home Products Consumer Service or an authorized Frigidaire servicer. For

information on where to obtain service, contact our Consumer Assistance Center at 1-800-944-9044.

• advise you on proper setting of controls or to instruct you how to use the washer

Service calls where the problem is due to:

• house wiring faults, improper electrical voltage, blown house fuse, tripped circuit breaker

• slow or backed-up drain, weak (spongy) floor, insects or rodents causing the problem

• frozen water lines in the washer or house

• washer installed outside, exposed to the elements

authorized by Frigidaire.

any implied warranty. Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation

or exclusion may not apply to you.

Replacement part for an inner wash basket that breaks due to a defect in materials or workman­ship. (Excludes Alaska)

AA

Y FOR:Y FOR:

A

Y FOR:

AA

Y FOR:Y FOR:

Product features or specifications as described or illustrated are subject to change without notice. This warranty made by White

Consolidated Industries, Inc. applies only in the 50 states of the U.S.A. and Puerto Rico.

Instructional Website

www.spinandtumble.com is an instructional
website with a slide show presentation. It
highlights features unique to this tumble
action washer and will help you operate your
washer correctly. This website is especially
helpful if your previous washer was a top

load model.

This Owner's Guide provides general operating
instructions for your washer. It also contains
information about features for several other
models. Your washer may not have every
feature included here.

Use the washer only as instructed in this Owner's
Guide and the Operating Instructions card
included with your washer.

Note: The instructions appearing in this Owner's Guide are not meant to cover every
possible condition and situation that may occur. Common sense and caution must be

practiced when installing, operating and maintaining any appliance.

As an ENERGY STAR Partner,

→

Frigidaire Home Products has
determined that this product meets
the ENERGY STAR guidelines for

→

energy efficiency.

2

Printed in U.S.A.

Read all instructions before using this washer.

To reduce the risk of fire, electrical shock, or injury to persons when using this

washer, comply with the basic warnings listed below.

Failure to comply with these warnings could result in serious personal injuries.

Prevent Fire

Do not wash items that have been previously cleaned in, soaked in, or spotted

with gasoline, cleaning solvents, kerosene, cooking oils, waxes, etc. Do not store these items on
or near the washer. These substances give off vapors or chemical reactions that could ignite or
explode.

Do not put oily or greasy rags or clothing on top of the washer. These substances

give off vapors that could ignite the materials.

3

Washing Procedures

Sort laundry into loads that can be

washed together.

• Follow the guidelines below for preparing the wash load.

• Read the Operating Instructions card for operating your specific model.

• Always read and follow fabric care and laundry product labels.

To reduce the risk of fire, electrical shock, or injury to persons, read

Important Safety Instructions, pages 3-4, before operating this washer.

1. Sort laundry into loads that can be washed together.

Sort items by recommended water temperatures and wash time.

• Separate white, light, and colorfast items from dark and noncolorfast items.

• Separate items which shed lint from items which attract lint. Permanent
press, synthetic, knit and corduroy items will pick up lint from towels, rugs
and chenille bedspreads.

• Separate heavily soiled items from lightly soiled items.

• Separate lacy, sheer and loosely knit items from sturdy items.

• Do not machine wash items containing fiberglass. Small particles of
fiberglass left in the drum may stick to fabrics in other loads and cause skin
irritation.

Empty pockets.

Place delicate items in a mesh bag.

2. Prepare items for washing.

• Empty pockets.

• Brush off lint and dirt. Shake out rugs and beach towels.

• Close zippers, fasten hooks, tie strings and sashes, and remove nonwashable
trims and ornaments.

• Remove pins, decorative buttons, belt buckles, and other objects which
could be damaged. This also helps protect other items in the wash load.

• Mend rips and tears to prevent further damage during washing.

• Place delicate items such as bras, shoulder pads, hosiery, and belts in a mesh
bag to prevent tangling during the wash cycle.

• Turn knit items inside out to prevent pilling.

3. Pretreat stains and heavy soil.

See Stain Removal, pages 7-8, for details.

4. Add laundry load to washer.

• Combine large and small items in a load. Load large items first. Large items
should not be more than half the total wash load.

• Washing single items such as a sweater, towel or jeans may cause an out­of-balance load. Add 1 or 2 similar items to help balance the load.

Add laundry load to washer.

• Single heavy items such as a bedspread can be washed separately.

• The washer can be fully loaded, but the items should not be tightly packed.
The door should close easily.

4
