Frigidaire 131781700 User Manual
2
For your safety, the information in this manual must be followed to minimize the risk of
fire or explosion or to prevent property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Clear the room, building or area of all occupants.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Important Safety Instructions
Read all instructions before using this laundry center.
Product Registration
Thank you for choosing this laundry
center. This owner's guide will explain
proper operation and care.
Record Your Model and Serial
Numbers
Record below the model and serial
numbers found on the laundry center
serial plate located on the inside of the
dryer door. Keep these numbers for
future reference.
Model Number __________________
when using this laundry center, comply with the basic warnings listed below.
Failure to comply with these warnings could result in serious personal injuries.
Prevent Fire
soaked in, or spotted with gasoline, cleaning solvents, kerosene, cooking oils,
waxes, etc. Do not store these items on or near the dryer. These substances give
off vapors that could ignite or explode.
center. These substances give off vapors that could ignite the materials.
To reduce the risk of fire, electrical shock, or injury to persons
Do not wash or dry items that have been previously cleaned in,
Do not put oily or greasy rags or clothing on top of the laundry
Serial Number ___________________
Date of Purchase ________________
Register Your Product
The self-addressed PRODUCT
REGISTRATION CARD should be
filled in completely, signed and
returned.
Versión en español
Si desea obtener una copia en español de
este Manual del Usuario, sírvase escribir
a la dirección que se incluye a continuación.
Solicite la P/N 131781800.
Spanish Owner's Guides
Frigidaire Company
P. O. Box 9061
Dublin, Ohio 43017-0961
©
1998 White Consolidated Industries, Inc.
All rights reserved.
Do not add gasoline, cleaning solvents, or other flammable or
explosive substances to the wash water. These substances give off vapors that
could ignite or explode.
Under certain conditions, hydrogen gas may be produced in a hot
water system that has not been used for 2 weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been used for such a period, before
using the washer, turn on all hot water faucets and let the water flow from each
for several minutes. This will release any accumulated hydrogen gas. Hydrogen gas
is flammable; do not smoke or use an open flame during this time.
To prevent fire, do not use heat to dry items containing plastic,
foam rubber or similarly textured rubber-like materials, or items containing
feathers or down. Use Air Fluff (No Heat) only.
Clean the dryer lint screen before or after each load. The interior
of the dryer, lint screen housing and exhaust duct should be cleaned approximately
every 18 months by qualified service personnel. An excessive amount of lint buildup in these areas could result in inefficient drying and possible fire. See Care and
Cleaning, pages 12-13.
Printed in U.S.A.
3
This Owner's Guide provides general
operating instructions for your laundry
center. It also contains information
about features for several other
models. Your laundry center may not
have every feature included.
Use the laundry center only as
instructed in this Owner's Guide.
Do not operate the dryer if the lint screen is blocked, damaged or
missing. Fire hazard, overheating and damage to fabrics can occur. If your dryer
has a drying rack, always replace the lint screen when finished using the drying
rack.
Keep area around the exhaust opening and surrounding areas
free from the accumulation of lint, dust and dirt.
Do not obstruct the flow of ventilating air. Do not stack or place
laundry or throw rugs against the front or back of the laundry center.
Avoid fire hazard or
electrical shock. Do not use an adaptor
plug or extension cord or remove
grounding prong from electrical power
cord. Failure to follow this warning can
cause serious injury, fire or death.
GAS LAUNDRY CENTERS:
Grounding type
wall receptacle
Do not under
any circumstances
cut, remove,
or bypass
the grounding prong
from this plug.
Power supply
cord with 3-prong
grounding plug
CORRECT
Use this way ONLY
Do not spray any type of aerosol into, on or near laundry center
at any time.
Do not use fabric softeners or products to eliminate static unless
recommended by the manufacturer of the fabric softener or product.
Failure to comply with these warnings could result in fire, explosion, serious
bodily injury and/or damage to the rubber or plastic parts of the laundry center.
Protect Children
Do not allow children to play on or in the laundry center. Close
supervision of children is necessary when the laundry center is used near children.
As children grow, teach them the proper, safe use of all appliances.
Destroy the carton, plastic bag and other packing materials after
the laundry center is unpacked. Children might use them for play. Cartons covered
with rugs, bedspreads or plastic sheets can become airtight chambers.
Keep laundry products out of children's reach. To prevent personal
injury, observe all warnings on product labels.
Note: The instructions appearing in
this Owner's Guide are not meant to
cover every possible condition and
situation that may occur. Common
sense and caution must be practiced
when installing, operating and
maintaining any appliance.
Before the laundry center is removed from service or discarded,
remove the washer lid and dryer door to prevent accidental entrapment.
Failure to comply with these warnings could result in serious personal injuries.
Prevent Injury
To prevent shock hazard and assure stability during operation, the
laundry center must be installed and electrically grounded by a qualified service
person in accordance with local codes. Installation instructions are packed in the
laundry center for the installer's reference. Refer to INSTALLATION INSTRUCTIONS
for detailed grounding procedures. If the laundry center is moved to a new location,
have it checked and reinstalled by a qualified service person.
To prevent personal injury or damage to the laundry center, the
electrical power cord of a gas laundry center must be plugged into a properly
grounded system. Never ground the laundry center to a gas pipe. Do not use
an extension cord or an adaptor plug.
4
Important Safety
Instructions (continued)
Follow package directions when using laundry products. Incorrect
usage can produce poisonous gas--resulting in serious injury or death.
• Do not combine laundry products for use in 1 load unless specified on the
label.
• Do not mix chlorine bleach with ammonia or acids such as vinegar.
Do not use or mix
liquid chlorine bleach with other
household chemicals such as toilet
cleaners, rust removers, acid or
products containing ammonia.
These mixtures can produce
dangerous fumes which can cause
serious injury or death.
To prevent serious personal injury and damage to the laundry
center:
• All repairs and servicing must be performed by an authorized servicer
unless specifically recommended in this Owner's Guide. Use only authorized
factory parts.
• Do not tamper with controls.
• Do not install or store the laundry center where it will be exposed to the
weather.
ALWAYS disconnect the laundry center from the electrical
supply before attempting any service or cleaning. Failure to do so can result in
electrical shock or injury.
Do not use any type spray cleanser when cleaning dryer interior.
Hazardous fumes or electrical shock could occur.
To prevent injury, do not reach into the washer while parts are
moving. Before loading, unloading or adding items, push in the cycle selector knob
and allow the tub to coast to a complete stop before reaching inside.
To prevent injury, do not reach into the dryer if the drum is moving.
Wait until the dryer has stopped completely before reaching into the drum.
A thermal limiter switch automatically turns off the dryer motor in the unlikely
event of an overheated situation (electric dryers only). A service technician must
replace the thermal limiter switch after correcting the fault.
The washer is equipped with an electrical overload protector. The motor will
stop if it becomes overheated. The washer will automatically restart after a cool
down period of up to 30 minutes, if the washer has not been manually turned off
during this time.
Failure to comply with these warnings could result in serious personal injuries.
SAVE THESE INSTRUCTIONS
5
Washing Procedures
Sort laundry into loads that can be
washed together.
Empty pockets.
• Follow the guidelines below for preparing the wash load.
• Read the Washer Operating Instructions, pages 17-18, for operating your
specific model.
• Always read and follow fabric care and laundry product labels.
To reduce the risk of fire, electrical shock, or injury to persons, read
Important Safety Instructions, pages 2-4, before operating this washer.
1. Sort laundry into loads that can be washed together.
Sort items by recommended water temperatures, wash time, and agitate/spin
speeds.
• Separate white, light, and colorfast items from dark and noncolorfast items.
• Separate items which shed lint from items which attract lint. Permanent
press, synthetic, knit and corduroy items will pick up lint from towels, rugs
and chenille bedspreads.
• Separate heavily soiled items from lightly soiled items.
• Separate lacy, sheer and loosely knit items from sturdy items.
2. Prepare items for washing.
• Empty pockets.
• Brush off lint and dirt. Shake out rugs and beach towels.
• Close zippers, fasten hooks, tie strings and sashes, and remove nonwashable
trims and ornaments.
• Remove pins, decorative buttons, belt buckles, and other objects which
could be damaged. This also helps protect other items in the wash load.
• Mend rips and tears to prevent further damage during washing.
• Place delicate items such as bras, shoulder pads, hosiery, and belts in a mesh
bag to prevent tangling during the wash cycle.
• Turn knit items inside out to prevent pilling.
Place delicate items in a mesh bag.
3. Pretreat stains and heavy soil.
See Stain Removal, pages 7-8, for details.
4. Add a measured amount of detergent to the wash tub before
adding the laundry load.
Follow detergent manufacturer's directions. The amount required depends on
type of detergent, load size and soil level, and water hardness.
5. If desired, add liquid bleach to Bleach Dispenser (some models).
• Before adding the wash load, add liquid bleach to bleach dispenser located
in left front corner under the lid:
• 3/4 cup (180 ml) for small loads
• 1 cup (240 ml) for large loads
• 1-1/4 cups (300 ml) for extra-large loads.
• Then add 1 cup (240 ml) water to flush the dispenser.
• Do not use powdered bleach in the bleach dispenser.
For models without a bleach dispenser, dilute the recommended amount of
liquid chlorine bleach in 1 quart (.95 L) water. Add it to wash water after
a few minutes of agitation. Do not pour bleach directly on wash load.
Bleach Dispenser (some models)
6
