Friedrich FPHW091, FPHW121, FPHW093, FPHW123, FPHSW09A1A User Manual

...

Ductless Split Systems

PRO Series

High efciency single and multizone ductless with Fast Pro™, Friedrich's contractor-friendly features for easy installation and faster service

PREMIER Series

Exceptional quality and our highest efciency line with Fast Pro™, Friedrich's contractor-friendly features for easy installation and faster service

SELECT Series

Excellent efciency and outstanding quality make Select a truly exceptional value line

THE EXPERTS IN ROOM AIR CONDITIONING

THE CONTRACTOR'S CHOICE FOR DUCTLESS.

Three exceptional lines of ductless with unique features for easy installation and fast service. All with the performance and value you expect from Friedrich.

Friedrich Precision Inverter® delivers exceptional energy efficiency and smooth performance

Precision Inverter technology varies the compressor, the outdoor and the indoor fan speeds, eliminating constant compressor start-ups/shut-downs that traditional systems require to maintain the set temperature. Soft start technology starts the compressor with minimal amperage at start up, saving energy versus compressors utilizing locked rotor amperage (LRA).

Each system can adjust capacity and cooling output to provide only the amount of cooling needed at a given time. The result is optimal comfort with low energy costs.

2 | FLOATING AIR® SERIES DUCTLESS

THE ADVANTAGES OF INVERTER DUCTLESS SYSTEMS

TRADITIONAL SYSTEM INVERTER SYSTEM

At initial start up, a xed capacity system slowly reaches the set temperature.

Complete shutdown once set temperature is achieved.

Temperature within the space rises until 2nd system start up.

System works at full capacity to again reach set temperature.

System cycles on and off continually to maintain the set temperature.

At initial start up, utilizes variable capacity to quickly reach the set temperature.

Reduces capacity as set temperature is achieved.

Variable capacity maintains set temperature keeping space comfortable with reduced energy consumption.

MULTIZONE SYSTEMS PROVIDE TOTAL FLEXIBILITY.

MIX AND MATCH SYSTEMS TO FIT MOST APPLICATIONS.

Zone cooling and heating provides unmatched customized comfort and energy savings

Occupants have the ability to set the temperature of each zone to their preferred comfort level*, or turn off units in unoccupied rooms without affecting other zones.

That’s the beauty and efficiency of a Friedrich Ductless Multizone System.

*Multizone units cannot heat and cool simultaneously.

A UNIQUE DESIGN THAT MAKES FRIEDRICH—

THE EASIEST DUCTLESS TO INSTALL, CLEAN & SERVICE

THE PROBLEM:

On typical ductless indoor units, accessing

the indoor coils is extremely difcult and

takes so much time that a thorough cleaning may be next to impossible.

Access to piping, wire terminal blocks, the fan and fan components is also a challenge.

THE SOLUTION:

Friedrich FastPro was designed with the HVAC technician in mind. In a few easy steps that can be performed in minutes, the entire blower wheel assembly can be removed for easier, faster cleaning and service. Also, you'll have easy access to the terminal blocks. FastPro will save you hours on the jobsite.

MODEL IDENTIFICATION GUIDE

Model Type: FR- Floating Air Premier FP- Floating Air Pro FS- Floating Air Select

Function: HS – Heat Pump Single HM – Heat Pump Multi HF – Heat Pump Flex Single and Multizone

Approximate Cooling BTU/HR

Voltage 1- 115 Volts 3- 230 Volts

FP HS W 09 A 1 A - A

Application: W- Wallmounted D- Ducted (Insider) C- Cassette R- Remote Condenser

Model Introductory Character: A- 2019 B- 2020 C- 2021 D- 2022

Marketing Suffix: Letter indicates modification to existing model

4 | FLOATING AIR® SERIES DUCTLESS

FastPro is available on Floating Air® Pro and Floating Air® Premier wall-mounted units

IN A FEW EASY STEPS

YOU CAN ACCESS THE BLOWER WHEEL ASSEMBLY AND SLIDE IT OUT FOR FULL ACCESS TO THE INDOOR COIL

Back out electrical panel screws Remove electrical access panels (2) Lock the access panel

Unplug the wire harness Remove screws then slide out the blower wheel assembly Complete access to the coils for easy cleaning

Unique features

for faster installation

and easier service

• Alignment arrows on the Friedrich wall bracket help you mark and drill the hole in the wall accurately, and with total confidence

• Easy-to-remove modular drain pan assembly

• Quick access to tangential blower and motor makes repairs easier

• Clear access to piping

• Easy access to the wire terminal

blocks

• Kickstand on the wall bracket provides ample space for your hands to work

• Auto leak detection

• Advanced corrosion protection

• Auto clean

• Washable, antimicrobial air filters

Pro Series | Ductless Split Systems

SINGLE ZONE • WALL-MOUNTED HEAT PUMPS

The contractor’s line with extensive features to make installation and service

faster and easier. Exceptional efficiency and dependable performance.

Features

• Precision Inverter® technology (variable speed compressor)

• Fast Pro™ blower wheel assembly for the fastest access for maintenance of any wall-mounted ductless split systems

• Soft start compressor

• BLDC motor

• High efficiency for low operating

cost

WIRELESS

REMOTE CONTROL

• DiamonBlue Advanced Corrosion Protection

• Auto Clean indoor coil

• Cooling/Heating/Fan/Auto mode

• LCD remote

• Surge Cool/Heat

• Tangential fan for optimum air flow

• Ultra quiet operation

• Sleep mode

• Auto restart

• Auto changeover

• 24-hour on/off timer

• ENERGY STAR

• Easy-to-read temperature display

qualified models

6 | FLOATING AIR® SERIES DUCTLESS

Operates in extreme conditions

• Low ambient operation down to 5°F (Cooling mode)

• Low ambient operation down to

-4°F (Heating mode)

• Low temperature compressor start-up protection

PRECISION

PARTS

WARRANTY

COMPRESSOR WARRANTY

PRO SERIES SPECIFICATIONS

PERFORMANCE RATINGS 115 volt models 230/208 volt models

SYSTEM MODEL NO.

INDOOR MODEL

OUTDOOR MODEL

SPECIFICATIONS

CAPACITY COOLING (RATED) Btu

CAPACITY COOLING MIN - MAX Btu

COOLING AMPS

HEATING AMPS

SENSIBLE HEAT RATIO

CAPACITY HEATING (RATED) @ 47°F Btu

CAPACITY HEATING MIN - MAX Btu

CAPACITY HEATING (RATED) @ 17°F Btu

COP

HSPF

SEER

EER

MOISTURE REMOVAL Pts/h

AIRFLOW (HIGH/MED/LOW/QUIET) CFM

SOUND RATING - INDOOR (HIGH/MED/LOW/QUIET) dB-A

SOUND RATING - OUTDOOR dB-A

OPERATING RANGE (HEATING) °F

OPERATING RANGE (COOLING) °F

EST. YEARLY OPERATING COST U.S. $

ELECTRICAL DATA

POWER SOURCE V/Hz/Phase

MIN. AMPACITY A

COOLING WATTS W

HEATING WATTS W

MAX. TD FUSE/ BREAKER A

POWER AND COMMUNICATION CABLE No. x AWG

REFRIGERATION SYSTEM

REFRIGERANT

COMPRESSOR TYPE

CONNECTIONS

LIQUID LINE O.D. in

SUCTION LINE O.D. in

REFRIGERANT CHARGE oz.

FACTORY PRECHARGE ft.

MIN. / MAX. LINE LENGTH ft

MAX. HEIGHT DIFFERENCE ft

DIMENSIONS & WEIGHT

INDOOR UNIT

W x H x D in

NET WEIGHT lbs

SHIPPING WEIGHT lbs

OUTDOOR UNIT

W x H x D in

NET WEIGHT lbs

SHIPPING WEIGHT lbs

TOTAL NET WEIGHT lbs

TOTAL SHIPPING WEIGHT lbs

FPHW091 FPHW121 FPHW093 FPHW123

FPHSW09A1A FPHSW12A1A FPHFW09A3A FPHFW12A3A

FPHSR09A1A FPHSR12A1A FPHSR09A3A FPHSR12A3A

9000 12000 9000 12000

3600-10000 4000-13500 3600-10000 4000-13500

6.3 8.3 2.9 4.3

7.0 9.7 3.1 5.0

76% 77% 76% 77%

9500 13000 9500 13000

3600-10500 4000-14000 3600-10500 4000-14000

5000 7500

3.56 3.46

5000

3.88

10.00 10.50 10.70 10.50

19.5 22.0 22.5 22.0

12.8 13.0 13.7 13.0

1.9 2.5 1.9 2.5

424/382/323/247 424/382/323/247 424/382/323/247 424/382/323/247

39/32/29/26 39/32/29/26 39/32/29/26 39/32/29/26

53 53 53 53

(-4° – 75°) (-4° – 75°) (-4° – 75°) (-4° – 75°)

(5° – 115°) (5° – 115°) (5° – 115°) (5° – 115°)

$61 $72 $53 $72

115V~,60Hz,1P 115V~,60Hz,1P 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P

13.5 16.5 10 10

700 950 655 960

780 1100 720 1110

20 25 15 15

4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG

R410a R410a R410a R410a

Rotary Rotary Rotary Rotary

Flare Flare Flare Flare

33.5 40.9 33.5 40.9

25 25 25 25

9.8-50 9.8-50 9.8-50 9.8-50

33 33 33 33

33 7/8 x 11 3/16 x 8 1/2 33 7/8 x 11 3/16 x 8 1/2

20 20 20 20

24.25 24.25 24.25 24.25

28 1/8 x 19 x 9 7/16 31 7/8 x 23 x 11 28 1/8 x 19 x 9 7/16 31 7/8 x 23 x 11

65 78 59.5 72.5

68 82.5 65 79

85 98 79.5 92.5

92.25 106.75 89.25 103.25

7500

3.42

Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit w ww.ftc.gov/energy.

Due to continuing research in new energy-saving technology, specications are subject to change without notice.

Pro Series | Ductless Split Systems

SINGLE ZONE • WALL-MOUNTED HEAT PUMPS

The contractor’s line with extensive features to make installation and service

faster and easier. Exceptional efficiency and dependable performance.

Features

• Precision Inverter® technology (variable speed compressor)

• Fast Pro™ blower wheel assembly for the fastest access for maintenance of any wall-mounted ductless split systems (feature not

FPHFW18A3A, FPHFW24A3A

FPHSW36A3A

on model

• Soft start compressor

• BLDC motor

• High efficiency for low

operating cost

• DiamonBlue Advanced Corrosion Protection

• Auto Clean indoor coil

• Cooling/Heating/Fan/Auto mode

• LCD remote

• Surge Cool/Heat

• Tangential fan for optimum air flow

• Ultra quiet operation

• Sleep mode

• Auto restart

• Auto changeover

• 24-hour on/off timer

• ENERGY STAR

• Easy-to-read temperature display

FPHSW36A3A)

qualified model

WIRELESS

REMOTE CONTROL

8 | FLOATING AIR® SERIES DUCTLESS

Operates in extreme conditions

• Low ambient operation down to 5°F (Cooling mode)

• Low ambient operation down to

-4°F (Heating mode)

• Low temperature compressor start-up protection

PRECISION

PARTS

WARRANTY

COMPRESSOR WARRANTY

PRO SERIES SPECIFICATIONS

PERFORMANCE RATINGS 230/208 volt models

SYSTEM MODEL NO.

INDOOR MODEL

OUTDOOR MODEL

SPECIFICATIONS

CAPACITY COOLING (RATED) Btu

CAPACITY COOLING MIN - MAX Btu

COOLING AMPS

HEATING AMPS

SENSIBLE HEAT RATIO

CAPACITY HEATING (RATED) @ 47°F Btu

CAPACITY HEATING MIN - MAX Btu

CAPACITY HEATING (RATED) @ 17°F Btu

COP

HSPF

SEER

EER

MOISTURE REMOVAL Pts/h

AIRFLOW (HIGH/MED/LOW/QUIET) CFM

SOUND RATING - INDOOR (HIGH/MED/LOW/QUIET) dB-A

SOUND RATING - OUTDOOR dB-A

OPERATING RANGE (HEATING) °F

OPERATING RANGE (COOLING) °F

EST. YEARLY OPERATING COST U.S. $

ELECTRICAL DATA

POWER SOURCE V/Hz/Phase

MIN. AMPACITY A

COOLING WATTS W

HEATING WATTS W

MAX. TD FUSE/ BREAKER A

POWER AND COMMUNICATION CABLE No.x AWG

REFRIGERATION SYSTEM

REFRIGERANT

COMPRESSOR TYPE

CONNECTIONS

LIQUID LINE O.D. in

SUCTION LINE O.D. in

REFRIGERANT CHARGE oz.

FACTORY PRECHARGE ft.

MIN. / MAX. LINE LENGTH ft

MAX. HEIGHT DIFFERENCE ft

DIMENSIONS & WEIGHT

INDOOR UNIT

W x H x D in

NET WEIGHT lbs

SHIPPING WEIGHT lbs

OUTDOOR UNIT

W x H x D in

NET WEIGHT lbs

SHIPPING WEIGHT lbs

TOTAL NET WEIGHT lbs

TOTAL SHIPPING WEIGHT lbs

FPHW183 FPHW243 FPHW363

FPHFW18A3A FPHFW24A3A FPHSW36A3A

FPHSR18A3A FPHSR24A3A FPHSR36A3A

18000 23500 36000

6500-19500 8000-26500 12000--38000

6.3 8.3 18.5

7.2 11.1 16

80% 76% 79%

19000 26000 36000

6500-20000 8000-26500 12000--38000

11600 14500 18700

3.40 3.05

11.6 10.5 8.8

23.3 21 16.4

13 12.5 8.6

3.2 5.1 6.8

618/565/482/382 735/665/559/441 1030/824/706/588

45/41/37/34 47/42/36/33 50/45/40/38

55 58 60

-4° – 75° -4° – 75° -4° – 75°

5° – 115° 5° – 115° 5° – 115°

$124 $169 $376

230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P

15 20 30

1385 1880 4186

1638 2500 3459

20 30 35

4 x 14AWG 4 x 14AWG 4 x 14AWG

R410a R410a R410a

Rotary Rotary Rotary

Flare Flare Flare

54.7 66.3 81.2

25 25 25

9.8-66 9.8-66 9.8-66

33 33 33

45 3/16 x 13 1/8 x 9 15/16 50 5/8 X 13 5/8 X 10 5/16

33 33 40

38.5 38.5 48

33 7/8 x 25 9/16 x 12 3/16 34 7/8 x 31 5/16 x 14 3/8 34 7/8 x 31 5/16 x 14 3/8

99 123.5 141

108 141 152

132 156.5 181

146.5 179.5 200

3.05

Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit w ww.ftc.gov/energy.

Due to continuing research in new energy-saving technology, specications are subject to change without notice.

Pro Series | Ductless Split Systems

SINGLE ZONE • CEILING CASSETTE HEAT PUMPS

The contractor’s line with extensive features to make installation and service

faster and easier. Exceptional efficiency and dependable performance.

MC24Y3J, MC36Y3J

Low prole indoor unit is recessed into the ceiling for a clean look and greater clearance.

NOTE: Grilles are sold separately.

• Precision Inverter® technology (variable speed compressor)

• Soft start compressor

• Natural air flow

• 4-Way cooling

• Surge Cool/Heat

• Cooling/Heating/Fan mode

• Dry mode

• Sleep mode

• Independent vane control

• 3 Fan speeds

• Evaporator frost control

• 24-hour on/off timer

• Auto restart

• Auto changeover

• Temperature display on remote

• Ultra-quiet turbo fan

• DiamonGold Advanced

Corrosion Protection

• Clean, modern look

• Flexible installation

• ENERGY STAR

• Precise air distribution

• Capable of branch duct to

adjacent closet or bathroom

™

qualified models

Operates in extreme conditions

• Built-in low ambient standard, down to 14°F (Cooling mode)

• Low ambient operation down to

-4°F (Heating mode)

WIRELESS

REMOTE CONTROL

10 | FLOATING AIR® SERIES DUCTLESS

MR24UY3J MR36UY3J

PRECISION

PARTS

WARRANTY

COMPRESSOR WARRANTY

PRO SERIES SPECIFICATIONS

PERFORMANCE RATINGS Single Zone Cassette - Heat Pumps

SYSTEM MODEL NO. C24YJ C36YJ INDOOR MODEL MC24Y3J MC36Y3J OUTDOOR MODEL MR24UY3J MR36UY3J

SPECIFICATIONS

CAPACITY COOLING (RATED) Btu 24,000 36,000 CAPACITY COOLING (MIN~MAX) Btu 9,700~26,700 14,000~42,000

CAPACITY HEATING CAPACITY HEATING @170 F (RATED) Btu 18,600 26,000 CAPACITY HEATING (MIN~MAX) Btu 10,900~30,000 14,500~45,000 COOLING AMPS 15.1 20.2 HEATING AMPS 16.0 24.0 COP . 2.84 2.78 SENSIBLE HEAT RATIO .77 .76 SEER 17.0 19.0 EER 12.6 13.5 HSPF 9.7 9.5 ENERGY STAR * Yes Yes MOISTURE REMOVAL Pts/h 5.1 7.7 AIRFLOW (LOW, MED, HIGH ) CFM 459 / 530 / 600 918 / 989 / 1,060 SOUND RATING - INDOOR H/M/L dB(A) 38/36/34 46/44/43 SOUND RATING - OUTDOOR dB(A) 62 67 OPERATING RANGE (COOLING) °FDB 14~118 14~118 OPERATING RANGE (HEATING) °FWB -4~64 -4~64 EST. YEARLY OPERATING COST $ 172 240

ELECTRICAL DATA

POWER SOURCE V 208/230/60/1 208/230/60/1 MINIMUM AMPACITY A 18.1 24.5 COOLING WATTS W 1910 2970 MAX. TD FUSE/BREAKER A 30 40 POWER AND COMMUNICATION CABLE

REFRIGERATION SYSTEM

REFRIGERANT R410A R410A COMPRESSOR TYPE Twin Rotary Twin Rotary CONNECTIONS Flare Flare LIQUID LINE O.D. in 3/8 3/8 SUCTION LINE O.D. in 5/8 5/8 FACTORY PRECHARGE ft 25 25 REFRIGERANT CHARGE oz 71 120 MIN./MAX. LINE LENGTH ft 25~164 25~246 MAX. HEIGHT DIFFERENCE ft 98 98

DIMENSIONS & WEIGHT

INDOOR UNIT W X H X D in 33-1/16 x 8-1/16 x 33-1/16 33-1/16 x 11-3/8 x 33-1/16 NET WEIGHT lbs 45 54 SHIPPING WEIGHT lbs 58 65 INDOOR UNIT GRILLE** W X H X D in 37-3/8 x 15/16 x 37-3/8 37-3/8 x 15/16 x 37-3/8 INDOOR UNIT GRILLE** NET WEIGHT lbs 11 11 OUTDOOR UNIT W X H X D in 37-7/16 x 32-7/8 x 13 37-13/32 x 54-3/8 x 13 NET WEIGHT lbs 132 203 SHIPPING WEIGHT lbs 146 227 TOTAL NET WEIGHT lbs 178 257 TOTAL SHIPPING WEIGHT lbs 203 293

470 F (RATED) Btu 27,000 40,000

No. x AWG

4 x 14AWG 4 x 14AWG

Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit w ww.ftc.gov/energy.

*System meets ENERGY STAR

published minimums. **Models require grille. Sold separately.

Due to continuing research in new energy-saving technology, specications are subject to change without notice.

Pro Series | Ductless Split Systems

SINGLE ZONE • THE INSIDER® CONCEALED DUCTED HEAT PUMPS

The contractor’s line with extensive features to make installation and service

faster and easier. Exceptional efficiency and dependable performance.

Features

• Precision Inverter® technology (variable speed compressor)

• Soft start compressor

• BLDC motor

• Cooling/Heating/Fan mode

• Dry mode

• 3 Fan speeds

• Auto restart

• Auto changeover

• DiamonGold Advanced Corrosion

Protection™

• Control lock function on controller

• External Static Pressure Range

(ESP)

- 24,000 (0.1 – 0.78) WC

- 36,000 (0.15 – 0.6) WC

Operates in extreme conditions

• Built-in low ambient standard, down to 5°F (Cooling mode)

• Low ambient operation down to

-4°F (Heating mode)

WIRED WALL

CONTROLLER

MR24UY3J MR36UY3J

PRECISION

PARTS

WARRANTY

COMPRESSOR WARRANTY

12 | FLOATING AIR® SERIES DUCTLESS

PRO SERIES SPECIFICATIONS

PERFORMANCE RATINGS Single Zone - The Insider™ Concealed Ducted Heat Pumps

SYSTEM MODEL NO. D24YJ D36YJ INDOOR MODEL MD24Y3J MD36Y3J OUTDOOR MODEL MR24UY3J MR36UY3J

SPECIFICATIONS

CAPACITY COOLING (RATED) Btu 24,000 36,000 CAPACITY COOLING (MIN~MAX) Btu 9,700~26,700 16,000~41,400

CAPACITY HEATING CAPACITY HEATING CAPACITY HEATING (MIN~MAX) Btu 10,900~30,000 17,500~48,000 COOLING AMPS 15.1 20.8 HEATING AMPS 15.1 21.4 SENSIBLE HEAT RATIO .68 .67 SEER 17.0 17.6 EER 12.0 12.1 COP . 2.84 2.78 HSPF 10.0 9.2 ENERGY STAR No No MOISTURE REMOVAL Pts/h 7.0 10.6 AIRFLOW (LOW, MED, HIGH ) CFM 530 / 618 / 688 706 / 953 / 1,130 SOUND RATING - INDOOR H/M/L dB(A) 38/36/35 39/38/37 SOUND RATING - OUTDOOR dB(A) 62 67 OPERATING RANGE (COOLING) °F 5~118 5~118 OPERATING RANGE (HEATING) °F -4~64 -4~64 EST. YEARLY OPERATING COST $ 180 268

ELECTRICAL DATA

POWER SOURCE 208/230/60/1 208/230/60/1 MINIMUM AMPACITY A 18.1 24.5 COOLING WATTS W 2000 2910 MAX. TD FUSE/BREAKER A 30 40 POWER AND COMMUNICATION CABLE

REFRIGERATION SYSTEM

DIMENSIONS & WEIGHT

INDOOR UNIT W X H X D in 46-9/16 x 11-3/4 x 17-3/4 48-1/2 x 15 x 23-1/4 NET WEIGHT lbs 73 125 SHIPPING WEIGHT lbs 95 139 OUTDOOR UNIT W X H X D in 37-7/16 x 32-7/8 x 13 37-7/16 x 54-3/8 x 13 NET WEIGHT lbs 132 203 SHIPPING WEIGHT lbs 146 227 TOTAL NET WEIGHT lbs 205 327 TOTAL SHIPPING WEIGHT lbs 240 366

470F (RATED) Btu 27,000 40,000

170F (RATED) Btu 17,600 24,600

No. x AWG

4 x 14AWG 4 x 14AWG

Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit w ww.ftc.gov/energy.

Due to continuing research in new energy-saving technology, specications are subject to change without notice.

Pro Series | Ductless Split Systems

MULTIZONE HEAT PUMP SYSTEMS

The contractor’s line with extensive features to make installation and service

faster and easier. Exceptional efficiency and dependable performance.

Features

• Precision Inverter® technology (variable speed compressor)

• Fast Pro™ blower wheel assembly for the fastest access for maintenance of any wall-mounted ductless split systems

• Soft start compressor

• BLDC motor

• High efficiency for low operating

cost

WIRELESS

REMOTE CONTROL

• DiamonBlue Advanced Corrosion Protection

• Auto Clean indoor coil

• Cooling/Heating/Fan/Auto mode

• Surge Cool/Heat

• Natural air flow

• Ultra quiet operation

• Sleep mode

• Auto restart

• Auto changeover

• 24-hour on/off timer

• ENERGY STAR

• Hidden display (only visible during

operation)

qualified model

FPHMR24A3A

14 | FLOATING AIR® SERIES DUCTLESS

FPHMR36A3A

Operates in extreme conditions

• Low ambient operation down to 5°F (Cooling mode)

• Low ambient operation down to

-4°F (Heating mode)

• Low temperature compressor start-up protection

PRECISION

PARTS

WARRANTY

COMPRESSOR WARRANTY

PRO SERIES SPECIFICATIONS

PERFORMANCE RATINGS Multizone Wall-Mounted - Heat Pumps

7k 9k 12k 18k 24k

INDOOR MODEL

SPECIFICATIONS

CAPACITY COOLING (RATED)

CAPACITY HEATING (RATED) MOISTURE REMOVAL AIRFLOW SOUND RATING (HIGH/MED/LOW)

Pts/h 2.5 2.5 3.2 4.2 5.3

CFM 424/382/323/247 424/382/323/247 424/382/323/247 618/565/482/382 735/665/559/441

dB-A 38/32/29 38/32/29 39/32/29 45/41/37 48/45/40

ELECTRICAL DATA

POWER SOURCE

V, Ø, Hz

REFRIGERATION SYSTEM

CONNECTIONS LIQUID LINE O.D. SUCTION LINE O.D.

DIMENSIONS & WEIGHT

W x H x D NET WEIGHT SHIPPING WEIGHT

PERFORMANCE RATINGS Multi Outdoor

OUTDOOR MODEL

SPECIFICATIONS

POWER SOURCE EST. YEARLY OPERATING COST RUNNING CURRENT COOLING RATED RUNNING CURRENT HEATING RATED POWER INPUT COOLING MIN. – RATED – MAX. POWER INPUT HEATING MIN. – RATED – MAX. POWER AND COMMUNICATION CABLE DIMENSIONS W x H x D NET WEIGHT SHIPPING WEIGHT

REFRIGERATION SYSTEM

REFRIGERANT FACTORY PRECHARGE LIQUID LINE O.D. SUCTION LINE O.D. MIN./MAX. LINE LENGTH (EACH) MIN./MAX. LINE LENGTH (TOTAL) MAX. HEIGHT DIFFERENCE SOUND PRESSURE LEVEL COOLING SOUND PRESSURE LEVEL HEATING OPERATING RANGE COOLING OPERATING RANGE HEATING MINIMUM AMPACITY MAX. TD FUSE/ BREAKER

FPHMW07A3A FPHFW09A3A FPHFW12A3A FPHFW18A3A FPHFW24A3A

Btu 7,000 9,000 12,000 18,000 24,000

Btu 8,500 9,500 13,000 19,000 24,200

208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1

Flare Flare Flare Flare Flare

lbs lbs

in in

18.7 18.7 18.7 32 32

24.3 24.3 24.3 37.5 37.5

37 3/8"x 10 3/4"x 8 1/8" 48"x 12 5/8"x 9 1/4"

24k 36k

FPHMR24A3A FPHMR36A3A

208~230/60/1 208~230/60/1 $ $172 $259 A A

W 1920 (420~2640) W 1920 (420~4020)

No. x AWG

8.7 11

8.7 13

2520(700~5000)

3060(600~6000)

4 x 14AWG 4 x 14AWG

37 3/8 x 33 x 13 3/8

/8 x 41 3/8 x 13 3/8

lbs 159 186 lbs 170 216

R410A R410A

in in

81.13 105.82

ft 66 66 ft 197 197 ft 49 49 A 59 59 A 59 59

°F DB 14~114.8 14~114.8

°F WB -13~75.2 -13~75.2

A 30A 30A A 45A 45A

48"x 12 5/8"x 9 1/4"

Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit w ww.ftc.gov/energy.

Due to continuing research in new energy-saving technology, specications are subject to change without notice.

Pro Series | Ductless Split Systems

MULTI ZONE • CEILING CASSETTE HEAT PUMPS

The contractor’s line with extensive features to make installation and service

faster and easier. Exceptional efficiency and dependable performance.

Features

Low prole indoor unit is recessed into the ceiling for a clean look and greater clearance.

NOTE: Grilles are sold separately.

• Precision Inverter® technology (variable speed compressor)

• Soft start compressor

• Natural air flow

• 4-Way cooling

• Surge Cool/Heat

• Cooling/Heating/Fan mode

• Dry mode

• Sleep mode

• Independent vane control

• 3 Fan speeds

• Evaporator frost control

• 24-hour on/off timer

• Auto restart

• Auto changeover

• Temperature display on remote

• Ultra-quiet turbo fan

• DiamonBlue Advanced

Corrosion Protection

• Clean, modern look

• Flexible installation

• ENERGY STAR

• Precise air distribution

• Capable of branch duct to

adjacent closet or bathroom

qualified models

Operates in extreme conditions

• Built-in low ambient standard, down to 14°F (Cooling mode)

• Low ambient operation down to

-13°F (Heating mode)

FPHMR24A3A

16 | FLOATING AIR® SERIES DUCTLESS

FPHMR36A3A

PRECISION

PARTS

WARRANTY

COMPRESSOR WARRANTY

PRO SERIES SPECIFICATIONS

PERFORMANCE RATINGS Multizone Cassette - Heat Pumps

9k 12k 18k 24k

INDOOR MODEL FPHFC09A3A FPHFC12A3A FPHFC18A3A FPHFC24A3A

SPECIFICATIONS

CAPACITY COOLING (RATED) Btu 9,000 12,000 18,000 24,000 CAPACITY HEATING (RATED) Btu 10,200 13,500 20,400 27,000 MOISTURE REMOVAL Pts/h 1.9 2.5 3.2 5.0 AIRFLOW (HIGH) CFM 306 471 559 1100 SOUND RATING (MAX.-MIN.) dB-A 40/28 40/28 40/28 40/28

ELECTRICAL DATA

POWER SOURCE 208/230/60/1 208/230/60/1 208/230/60/1 208/230/60/1 POWER AND COMMUNICATION CABLE No. x AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG

REFRIGERATION SYSTEM

CONNECTIONS Flare Flare Flare Flare LIQUID LINE O.D. in SUCTION LINE O.D. in

DIMENSIONS & WEIGHT

W X H X D in 22 7/16 x 8 7/16 x 22 33 x 9 3/4 x 33 NET WEIGHT lbs 31.9 34 61.8 59.5 SHIPPING WEIGHT lbs 38.5 40.7 81.6 79.5 PACKAGE DIMENSIONS W X H X D in 28

/4 x 11 1/2 x 26 39 1/4 x 37 1/16 x 14 39 1/4 x 37 1/16 x 14 9/16

/8 /8

PERFORMANCE RATINGS Multi Outdoor

24k 36k

OUTDOOR MODEL

FPHMR24A3A FPHMR36A3A

SPECIFICATIONS

$ $172 $259 A

A W 1920 (420~2640) W 1920 (420~4020)

No. x AWG

lbs 159 186 lbs 170 216

208~230/60/1 208~230/60/1

8.7 11

8.7 13

4 x 14AWG 4 x 14AWG

37 3/8 x 33 x 13 3/8

REFRIGERATION SYSTEM

in in

ft 66 66

ft 197 197

ft 49 49

A 59 59

°F DB 14~114.8 14~114.8

°F WB -13~75.2 -13~75.2

A 30A 30A

A 45A 45A

R410A R410A

81.13 105.82

2520 (700~5000)

3060 (600~6000)

/8 x 41 3/8 x 13 3/8

Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit w ww.ftc.gov/energy.

Models require grille. Sold separately. Due to continuing research in new energy-saving technology, specications are subject to change without notice.

Pro Series | Ductless Split Systems

MULTI ZONE • THE INSIDER® CONCEALED DUCTED HEAT PUMPS

The contractor’s line with extensive features to make installation and service

faster and easier. Exceptional efficiency and dependable performance.

Features

• Precision Inverter® technology (variable speed compressor)

• Soft start compressor

• BLDC motor

• Cooling/Heating/Fan mode

• Dry mode

• 3 Fan speeds

• Auto restart

• Auto changeover

• DiamonBlue Advanced Corrosion

Protection

• Control lock function on controller

• External Static Pressure Range

(ESP)

- 9,000 (0.1 – 0.6) WC

- 12,000 (0.1 – 0.6) WC

- 18,000 (0.1 – 0.6) WC

FPHMR24A3A

18 | FLOATING AIR® SERIES DUCTLESS

FPHMR36A3A

Operates in extreme conditions

• Built-in low ambient standard, down to 5°F (Cooling mode)

• Low ambient operation down to

-13°F (Heating mode)

PRECISION

PARTS

WARRANTY

COMPRESSOR WARRANTY

PRO SERIES SPECIFICATIONS

PERFORMANCE RATINGS Multizone - The Insider™ Concealed Ducted Heat Pumps

9k 12k 18k

INDOOR MODEL FPHFD09A3A FPHFD12A3A FPHFD18A3A

SPECIFICATIONS

CAPACITY COOLING (RATED) Btu 9,000 12,000 18,000 CAPACITY HEATING (RATED) Btu 10,000 12,500 19,000 MOISTURE REMOVAL Pts/h 1.9 3.2 3.2 AIRFLOW CFM 294 353 529 SOUND RATING (MAX.-MIN.) dB-A 33/26 34/27 35/31

ELECTRICAL DATA

POWER SOURCE 208/230, 1, 60 208/230, 1, 60 208/230, 1, 60 POWER AND COMMUNICATION CABLE No. x AWG 4 x 14AWG 4 x 14AWG 4 x 14AWG

REFRIGERATION SYSTEM

CONNECTIONS Flare Flare Flare LIQUID LINE O.D. in 1/4 1/4 1/4 SUCTION LINE O.D. in 3/8 3/8 1/2

DIMENSIONS & WEIGHT

W X H X D in

35 7/8 x 7 7/16 x 17

NET WEIGHT lbs 45.2 45.2 66.2 SHIPPING WEIGHT lbs 51.8 51.8 77.2

PERFORMANCE RATINGS Multi Outdoor

24k 36k

OUTDOOR MODEL

FPHMR24A3A FPHMR36A3A

SPECIFICATIONS

$ $172 $259 A

A W 1920 (420~2640) W 1920 (420~4020)

No. x AWG

lbs 159 186 lbs 170 216

208~230/60/1 208~230/60/1

8.7 11

8.7 13

4 x 14AWG 4 x 14AWG

37 3/8 x 33 x 13 3/8

REFRIGERATION SYSTEM

in in

ft 66 66

ft 197 197

ft 49 49

A 59 59

°F DB 5~114.8 5~114.8

°F WB -13~75.2 -13~75.2

A 30A 30A

A 45A 45A

R410A R410A

81.13 105.82

46 7/16 x 7 1/2 x 17 1/2

2520(700~5000)

3060(600~6000)

/8 x 41 3/8 x 13 3/8

Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $ .12 per kWh. For more information, visit w ww.ftc.gov/energy.

Due to continuing research in new energy-saving technology, specications are subject to change without notice.

Premier Series | Ductless Split Systems

SINGLE ZONE • WALL-MOUNTED HEAT PUMPS

Top cooling and heating performance in extreme climates.

28.0 SEER - our highest efficiencies ever!

Features

• Precision Inverter® technology

• Soft start compressor

• BLDC motor

• High efficiency for low operating

• DiamonBlue Advanced Corrosion

• Auto Clean indoor coil

• Cooling/Heating/Fan/Auto mode

• Surge Cool/Heat

• Natural air flow

• Ultra quiet operation

• Sleep mode

• Auto restart

• Auto changeover

WIRELESS

REMOTE CONTROL

• 24-hour on/off timer

• ENERGY STAR

• Hidden display (only visible during

(variable speed compressor)

cost

Protection

qualified model

operation)

FRHSR09A2A, FRHSR12A2A

20 | FLOATING AIR® SERIES DUCTLESS

Operates in extreme conditions

• Low ambient operation down to 0°F (Cooling mode)

• Low ambient operation down to

-13°F (Heating mode)

• Low temperature compressor start-up protection

PRECISION

PARTS

WARRANTY

COMPRESSOR WARRANTY

PREMIER SERIES SPECIFICATIONS

PERFORMANCE RATINGS Single Zone Wall-Mounted - Heat Pumps

9k 12k

SYSTEM MODEL NO. FRHW093 FRHW123 INDOOR MODEL FRHSW09A3A FRHSW12A3A OUTDOOR MODEL FRHSR09A3A FRHSR12A3A

SPECIFICATIONS

CAPACITY COOLING (RATED) Btu 9000 12000 CAPACITY COOLING (MIN~MAX) Btu 3600-10000 4000-13500

CAPACITY HEATING CAPACITY HEATING@170F (RATED) Btu 6500 8000 CAPACITY HEATING (MIN~MAX) Btu 3600-10500 4000-14000 COOLING AMPS 2.3 4.6 HEATING AMPS 3.4 4.8 SENSIBLE HEAT RATIO 76% 77% SEER 28 25 EER 16.1 15.4 HSPF 12.5 12 ENERGY STAR Yes Yes MOISTURE REMOVAL Pts/h 1.9 2.5 AIRFLOW (QUIET, LOW, MED, HIGH) CFM 416/384/355/279 598/536/446/345 SOUND RATING - INDOOR dB-A 39/34/31 45/41/39 SOUND RATING - OUTDOOR dB-A 55 55 OPERATING RANGE (COOLING) °F 0˚-115˚ 0˚-115˚ OPERATING RANGE (HEATING) °F -13˚-75˚ -13˚-75˚ EST. YEARLY OPERATING COST $ 50 70

ELECTRICAL DATA

POWER SOURCE V 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P MINIMUM AMPACITY A 10A 12A COOLING WATTS W 559 779 HEATING WATTS W 905 856 MAX. TD FUSE/ BREAKER A 15A 15A POWER AND COMMUNICATION CABLE

REFRIGERATION SYSTEM

REFRIGERANT R410a R410a COMPRESSOR TYPE Rotary Rotary CONNECTIONS Flare Flare LIQUID LINE O.D. in SUCTION LINE O.D. in FACTORY PRECHARGE ft 25 25 REFRIGERANT CHARGE oz 38.8 45.9 MIN./MAX. LINE LENGTH ft 10-66 10-66 MAX. HEIGHT DIFFERENCE ft 33 33

DIMENSIONS & WEIGHT

INDOOR UNIT

W X H X D in 33 NET WEIGHT lbs 22 28.5 SHIPPING WEIGHT lbs 26.5 34

OUTDOOR UNIT

W X H X D in 31 7/8 x 23 x 11 31 7/8 x 23 x 11 NET WEIGHT lbs 75 84 SHIPPING WEIGHT lbs 81.5 92.5 TOTAL NET WEIGHT lbs 97 112.5 TOTAL SHIPPING WEIGHT lbs 108 126.5

470F (RATED) Btu 10500 13000

No. x AWG

4 x 14AWG 4 x 14AWG

/8 x 11 3/16 x 8 1/2 38 1/8 X 13 1/8 X 9 15/16

Your operating costs will depend on your utility rates and use. The estimated operating cost is based on a electricity cost of $.12 per kWh. For more information, visit ww w.ftc.gov/energy.

Due to continuing research in new energy-saving technology, specications are subject to change without notice.

Select Series | Ductless Split Systems

SINGLE ZONE • WALL-MOUNTED HEAT PUMPS

Superb performance and excellent value, you get both at exceptional pricing.

115 volt models

MWM09Y1J, MWM12Y1J

230/208 volt models

WIRELESS

REMOTE CONTROL

MWM18Y3J, MWM24Y3J

MWM36Y3J

Features

• Inverter technology is more energy efficient and can self-adjust capacity to match cooling needs

• Multiple operating modes including: auto, cool, dry, fan only and heat

• TURBO mode operates the unit at maximum performance to quickly bring the room to set temperature

• 4 fan speeds heating or cooling: high, medium, low, “quiet”, plus auto-fan

• Continuous ‘Air Sweep’ up & down

• LCD remote

• 24-hour timer and sleep timer

• Indoor unit will briefly display set

or room temperature

• Auto-restart after power interruptions

• Auto-shut flaps close when unit is off for a sleek appearance

• Washable antimicrobial air filters

• 230 volt models will provide

cooling in outdoor temperatures down to 5°F

MRM09Y1J, MRM12Y1J MRM18Y3J, MRM24Y3J, MRM36Y3J

22 | FLOATING AIR® SERIES DUCTLESS

OPTIONAL ACCESSORY FOR FLOATING AIR® SELECT MODELS

DFAC C

LCD remote for cooling only operation of all Floating Air Select heat pump models.

PRECISION

SELECT SERIES SPECIFICATIONS

PERFORMANCE RATINGS 115 volt models 230/208 volt models

SYSTEM MODEL NO.

INDOOR MODEL

OUTDOOR MODEL

SPECIFICATIONS

CAPACITY COOLING (RATED) Btu

CAPACITY COOLING MIN - MAX Btu

COOLING AMPS

HEATING AMPS

SENSIBLE HEAT RATIO

CAPACITY HEATING (RATED) @ 47°F Btu

CAPACITY HEATING MIN - MAX Btu

CAPACITY HEATING (RATED) @ 17°F Btu

HSPF

SEER

EER

MOISTURE REMOVAL Pts/h

AIRFLOW (HIGH/MED/LOW/QUIET) CFM

SOUND RATING - INDOOR (HIGH/MED/LOW/QUIET) dB-A

SOUND RATING - OUTDOOR dB-A

OPERATING RANGE (HEATING) °F

OPERATING RANGE (COOLING) °F

EST. YEARLY OPERATING COST U.S. $

ELECTRICAL DATA

POWER SOURCE V/Hz/Phase

MIN. AMPACITY A

COOLING WATTS W

HEATING WATTS W

MAX. TD FUSE/ BREAKER A

REFRIGERATION SYSTEM

REFRIGERANT

COMPRESSOR TYPE

CONNECTIONS

LIQUID LINE O.D. in

SUCTION LINE O.D. in

REFRIGERANT CHARGE oz.

FACTORY PRECHARGE ft

MIN. / MAX. LINE LENGTH ft

MAX. HEIGHT DIFFERENCE ft

DIMENSIONS & WEIGHT

INDOOR UNIT

W x H x D in

NET WEIGHT lbs

SHIPPING WEIGHT lbs

OUTDOOR UNIT

W x H x D in

NET WEIGHT lbs

SHIPPING WEIGHT lbs

TOTAL NET WEIGHT lbs

TOTAL SHIPPING WEIGHT lbs

MM09YJ MM12YJ MM18YJ MM24YJ MM36YJ

MWM09Y1J MWM12Y1J MWM18Y3J MWM24Y3J MWM36Y3J

MRM09Y1J MRM12Y1J MRM18Y3J MRM24Y3J MRM36Y3J

9000 11800 18000 22000 33600

3500~11000 3300~12500 4500~21000 6400~24000 7404~35997

9.00 15.00 7.85/7.10 11.50/10.50 17.0/17.0

9.50 15.5 11.77/10.65 12.80/13.00 16.5/16.5

0.79 0.73 0.77 0.77 0.75

9800 13000 19200 24200 34600

2500~11000 3400~13500 4000~23000 4100~26600 14979~35997

5400 8500 13500 18600 20200

8.6 8.6 8.5 8.5 9.0

16.0 16.0 16.0 16.0 18.0

12.0 9.4 11.0 10.0 8.20

1.69 2.96 3.80 4.50 7.40

330/277/224/188 341/288/235/200 471/400/330/271 588/441/306/206 736/647/530/412

41/37/35/32 43/39/35/32 48/43/38/34 49/43/39/34 54/49/44/37

53 55 56 53 65

5-75 5-75 5-75 5-75 -4-75

32*-113 32*-113 5-118 5-115 0~109

$67 $113 $146 $198 $368

115/60/1 115/60/1 208/230/60/1 208/230/60/1 208/230/60/1

13 15 15 16 24

750 1260 1620 2200 4100

830 1320 2400 2800 3800

20 25 25 25 40

R410A R410A R410A R410A R410A

Inverter Inverter Inverter Inverter Inverter

Flare Flare Flare Flare Flare

35.3 35.3 45.8 54.7 91.7

24.6 24.6 24.6 24.6 24.6

7 / 65 7 / 65 10 / 82 10 / 82 98

32 32 32 32 32

30"× 11"× 8" 34"× 12"× 8" 39

"× 12

"× 8" 53"x 13"x 10"

19 19 26 33 42

25 25 35 44 52

"× 24

"× 12

" 37

"x 27

"x 15

" 38

68 68 106 115 161

77 77 117 126 172

87 87 132 148 203

102 102 152 170 224

"x 31"x 17"

* Capacity is reduced as 32 degrees Fahrenheit is approached.

Due to continuing research in new energy-saving technology, specications are subject to change without notice. All Friedrich ductless split products require a licensed contractor for installation.

MULTIZONE SEER, HSPF RATINGS

Model Number

FPHMR24A3A

FPHMR36A3A

AHRI

Reference

IndoorType

Number

204101246 Non-ducted Indoor Units 24000 12.50 22.00 24000 11.00 15400

204005731 Ducted Indoor Units 24000 12.10 21.00 24000 10.00 15400

203999079 Mixed Ducted and Non-ducted Indoor Units 24000 12.30 21.50 24000 10.50 15400

204101247 Non-Ducted Indoor Units 32000 12.50 21.00 36000 11.00 23200

203996910 Ducted Indoor Units 32000 12.00 19.50 36000 10.80 22600

203999080 Mixed Ducted and Non-ducted Indoor Units 32000 12.25 20.25 36000 10.90 22600

System

Capacity

ACCESSORIES

REFRIGERATION LINE SETS

Length

Kit#

T32150 15' 1/4" 3/8"

T32350 35' 1/4" 3/8"

T42150 15' 1/4" 1/2" T42350 35' 1/4" 1/2" MM24YJ T52150 15' 1/4" 5/8" T52350 35" 1/4" 5/8" T53150 15’ 3/8" 5/8" FPHW243 C24YJ

T53350 35' 3/8" 5/8"

T63150 15' 3/8" 3/4" T63350 35' 3/8" 3/4"

(ft.) Liquid Suction System Model

FPHW091 FPHW093 MM09YJ

FPHW121 FPHW123 MM12YJ

FPHMR24A3A FRHW123 MM09YJ FPHMR36A3A FRHW093 MM12YJ

FPHW183

D24YJ C36YJ D36YJ

FPHW363

MM18YJ

MM36YJ

CONTROLLER

FPWC1

Wired wall controller option for Floating Air Premier and Pro Single/Multizone

CEILING CASSETTE GRILLES (REQUIRED ACCESSORY)

Required decorative grille for ceiling cassette models

Decorative Grille

FPCG0912 FPCG182436

FPHFC09A3A, FPHFC12A3A FPHFC18A3A, FPHFC24A3A

Decorative Grille

DCG2436

MC24Y3J MC36Y3J

Many Friedrich ductless models qualify for rebates

Many utility companies offer rebates on ductless air conditioners. Contact your local energy provider for information on ductless rebates or visit: http://www.dsireusa.org

Find a factory trained Friedrich ductless installer at www.friedrich.com

Low Heat 17°F

EER SEER

High Heat 47°F

HSPF

REFRIGERATION LINE SETS MIN./MAX. LENGTHS

Floating Air® Pro

System Model Min. (ft.) Max. (ft.) FPHW091 10 50 FPHW121 10 50 FPHW093 10 50 FPHW123 10 50 FPHW183 10 66 FPHW243 10 66 FPHW363 10 66 C24YJ 25 164 C36YJ 25 246 D24YJ 25 164 D36YJ 25 246 FPHMR24A3A 25 66 FPHMR36A3A 25 66

Floating Air

System Model Min. (ft.) Max. (ft.) FRHW123 10 66 FRHW093 10 66

Floating Air

System Model Min. (ft.) Max. (ft.) MM09YJ 10 66 MM12YJ 10 66 MM18YJ 10 82 MM24YJ 10 82 MM36YJ 15 98

Premier

Select

TORQUE WRENCH SETTINGS

Outside Diameter Torque

mm inch ft-lbs. N·m

6.35

9.52

12.7

15.88

13 – 18 17.6 – 24.5

25 – 30 33.3 – 41.2

40 – 47 53.9 – 64.7

45 – 59 61.7 – 80.4

Friedrich Air Conditioning Co. l 10001 Reunion Place, Suite 500 l San Antonio, TX 78216 l 877.599.5665 l www.friedrich.com

BRO_FADSS_2019_Rev.4 (8-14-19) Printed in USA

Friedrich FPHW091, FPHW121, FPHW093, FPHW123, FPHSW09A1A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
