Fridgemaster MC60283DFFB User Manual

MC60283DFFB

2014/35/EU and 2014/30/EU and 2009/125/EC and EC.643/2009

This appliance is in accordance with the following EU guidelines: This appliance is in accordance with the following EU guidelines:

Control panel _ _ _ _ _ _ _ _ _ _ _ _ _ _

Using your appliance _ _ _ _ _ _ _ _ _ _

Cleaning and care _ _ _ _ _ _ _ _ _ _ _

Installing your new appliance_ _ _ _ _ _
Description of the appliance _ _ _ _ _ _

15

17

8

14

Troubleshooting_ _ _ _ _ _ _ _ _ _ _ _ _

Disposal of the appliance_ _ _ _ _ _ _ _

21

23

25

Safety for children and others
who are vulnerable people

For your safety and
correct usage, before
installing and first using
the appliance, read this
user manual carefully,
including its hints and
warnings.
To avoid unnecessary
mistakes and accidents, it
is important to make sure
that all people using the
appliance are thoroughly
familiar with its operation
and safety features.
Save these instructions
and be sure that they
remain with the appliance
if it is moved or sold, so
that anyone, using it

throughout its life, will be
properly informed on
usage and safety notices.
For the safety of life and
property, keep the
precautions of these user's
instructions as the
manufacturer is not

responsible for damages
caused by omission.

This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or lack
of experience and
knowledge if they have
been given supervision or
instruction concerning
use of the appliance in a
safe way and understand
the hazards involved.
Children shall not play
with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
Keep all packaging away
from children as there is
risk of suf

and 2002/96/EC

2

Safety and warning information_ _ _ _ _ 2

Helpful and hints and tips _ _ _ _ _ _ _

19

3

If you are discarding the
appliance, pull the plug
out of the socket, cut the
connection cable (as
close to the appliance as
you can) and remove the
door to prevent children
playing from suffering an
electric shock or from
closing themselves inside
it.
If this appliance, featuring
a magnetic door seals, is
to replace an older
appliance having a spring
lock (latch) on the door or
lid, be sure to make the
spring lock unusable
before you discard the old
appliance. This will
prevent it from becoming
a death trap for a child.

General safety

WARNING - This
appliance is intended

to be used in household
and similar applications
such as

-staff kitchen areas in
shops, offices and other
working environments;

-farm houses and by
clients in hotels, motels
and other residential type
environments;

-bed and breakfast type
environments;

-catering and similar non­retail applications
WARNING - Do not store
explosive substances
such as aerosol cans with
a flammable propellant in
this appliance.
WARNING - If the supply
cord is damaged, it must
be replaced by the
manufacturer, its service
agent or similarly qualified
persons in order to avoid
a hazard.
WARNING - Keep
ventilation openings, in
the appliance enclosure
or in the built-in structure,
clear of obstruction.
WARNING - Do not use
mechanical devices or
other means to accelerate
the defrosting process,
other than those
recommended by the
manufacturer.
WARNING - Do not
damage the refrigerant
circuit.
WARNING - Do not use
electrical appliances
inside the food storage
compartments of the
appliance, unless they are
of the type recommended
by the manufacturer.
WARNING - The
refrigerant and insulation

4

1.The power cord must
not be lengthened.

2. Make sure that the
power plug is not crushed
or damaged. A crushed or
damaged power plug may
overheat and cause a
fire.

3. Make sure that you can
access the main plug of
the appliance.

4. Do not pull the main
cable.

5. If the power plug
socket is loose, do not
insert the power plug.
There is a risk of electric
shock or fire.

6.You must not operate
the appliance without the
interior lighting lamp
cover.

7.The fridge is only
applied with power supply
of single phase
alternating current of
220~240V/50Hz. If
fluctuation of voltage in
the district of user is so
large that the voltage
exceeds the above
scope, for safety sake, be

Electrical safety

blowing gas are
flammable.
When disposing of the
appliance, do so only at
an authorized waste
disposal centre. Do not
expose to flame.

The refrigerant isobutene
(R600a) is contained
within the refrigerant
circuit of the appliance, a
natural gas with a high
level of environmental
compatibility, which is
nevertheless flammable.
During transportation and
installation of the
appliance, ensure that
none of the components
of the refrigerant circuit
becomes damaged.
The refrigerant (R600a) is
flammable.

Refrigerant

If the refrigerant circuit
should be damaged:

-Avoid opening flames
and sources of ignition.

-Thoroughly ventilate the
room in which the
appliance is situated.
It is dangerous to alter
the specifications or
modify this product in any
way.

Caution:risk of fire

Any damage to the cord
may cause a shortcircuit,
fire, and/or electric shock.

sure to apply A.C.
Automatic voltage
regulator of more than
350W to the fridge. The
fridge must employ a
special power socket
instead of common one
with other electric
appliances. Its plug must
match the socket with
ground wire.

Do not store flammable
gass or liquids in the
appliance,There is a risk of
an explosion.
Do not operate any
electrical appliances in the
appliance(e.g.electric ice
cream makers,mixers
etc.).
When unplugging always
pull the plug from the
mains socket,do not pull
on the cable.
Do not place hot items
near the plastic
components of this
appliance.
Do not place food products
directly against the air
outlet on the rear wall.
Store pre-packed frozen
food in accordance with the
frozen food manufacture’s
instructions.
The appliances

Daily use

manufactures storage
recommendations
should be strictly adhered
to.Refer to relevant
instructions for storage.
Do not place carbonated
or fizzy drinks in the
freeze compartment as it
creates pressure on the
container, which may
cause it to explode,
resulting in damage to the
appliance.
Frozen food can cause
frost burns if consumed
straight from the freezer
compartment.
Do not place the
appliance in direct
sunlight.
Keep burning candles,
lamps and other items
with naked flames away
from the appliance so that
do not set the appliance
on fire.
The appliance is intended
for keeping food stuff
and/or beverages in
normal household as
explained in this
instruction booklet The
appliance is heavy.Care
should be taken when
moving it.
Do not remove or touch
items from the freezer
compartment if your

5

6

For electrical connection
carefully, follow the
instructions given in this
manual.
Unpack the appliance and
check if there are
damages on it. Do not
connect the appliance if it
is damaged. Report
possible damages
immediately to the place
you bought it. In this case
retain packing.
It is advisable to wait at
least four hours before
connecting the appliance
to allow the oil to flow
back in the compressor.
Adequate air circulation
should be around the
appliance, lacking this
leads to overheating. To
achieve sufficient
ventilation, follow the
instructions relevant to
installation.
Wherever possible the
back of the product
should not be close to a
wall to avoid touching or
catching warm parts
(compressor, condenser)
to prevent the risk of a
fire, follow the instructions

hands are damp/wet,as
this could cause skin
abrasions or frost/freezer
burns.
Never use the base,
drawers, doors etc. to
stand on or as supports.
Frozen food must not be
refrozen once it has been
thawed out.
Do not consume ice
popsicles or ice cubes
straight from the freezer
as this can cause freezer
burn to the mouth and
lips.
To avoid items falling and
causing injury or damage
to the appliance, do not
overload the door racks
or put too much food in
the crisper drawers.

Installation Important!

caution!
Care and cleaning

Before maintenance,
switch off the appliance
and disconnect the mains
plug from the mains
socket.
Do not clean the
appliance with metal
objects, steam cleaner,
ethereal oils, organic
solvents or abrasive
cleansers.
Do not use sharp objects
to remove frost from the

appliance. Use a plastic
scraper.

relevant to installation.
The appliance must not
be locate close to
radiators or cookers.
Make sure that the mains
plug is accessible after
the installation of the
appliance.

Service

Any electrical work
required to do the
servicing of the appliance
should be carried out by
qualified electrician or
competent person.
This product must be
serviced by an authorized
Service Center, and only
genuine spare parts must
be used.

1)If the appliance is Frost
Free.

2)If the appliance
contains freezer
compartment.

7

8

Installing your new appliance

Ventilation of appliance

Before using the appliance
for the first time, you should
be informed of the following
tips.

In order to improve
efficiency of the cooling
system and save energy, it
is necessary to maintain
good ventilation around the
appliance for the dissipation
of heat. For this reason,
sufficient clear space
should be available around
the refrigerator.
Suggest :It is advisable for
there to be at least 75mm of
space from the back to the
wall, at least 100mm from its
top,at last 100mm from its
side to the wall and a clear
space in front to allow the
doors to open 130°. As
shown in following diagrams.

Note:
This appliance performs
well within the climate class
from SN to T showed in the
table below.

●

It may not work properly if
being left at a temperature
above or below the
indicated range for a long
period.

Climate class

Ambient temperature

SN

N

ST

T

+10°C to +32°C

+16°C to +32°C

+16°C to +38°C

+16°C to +43°C

Stand your appliance in a
dry place to avoid high
moisture.
Keep the appliance out of
direct sunlight rain or frost.
Stand the appliance away
from heat sources such as
stoves, fires or heaters.

Leveling of appliance

For sufficient leveling and
air circulating in the lower
rear section of the
appliance, the bottom feet
may need to be adjusted.
You can adjust them
manually by hand or by

●

●

●

75

100

100

130°

100

100

7

22

.5

1

2

6

7

960

using a suitable spanner.
To allow the doors to self­close, tilt the top backwards
by about 10mm.

●

Reversing the door

The side at which the door
opens can be changed,
from the right side (as
supplied) to the left side, if
the installation site requires.
Warning! When reversing
the door, the appliance
must not be connected to
the mains. Ensure that the
plug is removed from the
mains socket.

Note: Before you start lay
the refrigerator on its back
in order to gain access to
the base, you should rest
it on soft foam packaging
or similar material to avoid
damaging the backboard
of the refrigerator. To
reverse the door, the
following steps are
generally recommended.

1. Stand the refrigerator
upright. Open the upper
door to take out all door
racks and tank (to avoid
them damaged) and then
close the door.

≤10mm

Tools you will need

9

Stop Block

Left Hinge Cover

8mm wrench

8mm socket wrench

Monkey wrench

Thin-blade screwdriver

Cross-shaped screwdriver

Door racks

2. Remove the upper cover
①and corner cover ② on
top of the upper door, then
remove right hinge cover ③
and hinge cover ④, and
block cover ⑤on top of the
cabinet.

Water tank

3. Remove the 2 screws
which are used for fixing
the right upper hinge part ⑥
(see the picture above).

4. Remove the upper door
from the middle hinge by
carefully lifting the door
straight up.

Caution! Please hold the
upper door by hand during
step 3 to prevent door
dropping.

10

5.
a smooth surface with its
panel upwards. Loose
screw ④ and part ③,
then loose screw ② and
part ①. Install another
stop block (in the plastic
bag) to the left side with
screw ②, then install part
③ with screw ④. Keep
part ① into the plastic bag
with the appliance for future
reference.

Place the upper door on

① Upper cover

② Corner cover

③ Right Hinge Cover

⑥ Right upper hinge part

⑤ B

l

o

c

k C

o

ve

r

④ Hinge Cover

① Door holder

①

② Self-tapping screw

②

④ Self-tapping screw

④

③ Stop block

③

6. Loose screws used to fix
the middle hinge and
remove middle hinge. Then
remove the lower door.

7. Place the lower door on a
smooth surface with its
panel upwards. Loose
screw ④ and part ③,
then loose screw ② and
part ①. Turn part ① by

180 and install it with screw
②, then install part ③

with screw ④.

°

11

8. Change screw hole
covers on middle cover
plate from left to right (as
shown in figure below).

① Door holder

①

② Self-tapping screw

②

④ Self-tapping screw

④

③ Stop block

③

9. Place refrigerator
flatwise, remove part③and
then loose screws④.
Remove part ②and part①.

①

① Lower h inge pa rt (rig ht)

washe r

Note: w asher ma y
stick t o lower do or

② Front f oot fix ed bo ar d

②

④

④ Self- tappi ng scre ws

③

③ Adjust able bo ttom fe et pa rt

10. Screw out the lower
hinge axis, change it to
the near hole site, and
then screw up it and the
mount washer (see the
picture above).

11. Just remount to the step
9, change part ① to left
and part ② to right and
then fix them with screws ④.
Finally install part ③.

Lower hinge part (left)

12. Move the lower door
and adjust its position to
align lower hole site and
upper hinge axis. Turn the

13. Screw out the upper
hinge axis①, turn the upper
hinge over and fix the
axis on it.

Caution! Fix the axis until
its top come to the
underside of the upper
hinge.

②

12

① Upper Hin ge Axis

washe r

Note: washer may
stick to lower door.

② Upper Hin ge

Top of th e axi s

Underside of the upper hinge

14. Move the upper door
to an appropriate position,
adjust upper hinge and
upper door, then fix the
hinge axis into the hinge
front the top down.
(Please hold upper door
by hand when installing)

middle hinge by 180°,
change the washer on the
axis to the upper side,
adjust the middle hinge to
the appropriate position and
then install it.

15. Assemble the cover to
match the hinge.

16. Switch the handles from
the left to the right (only for
the model with handles).

13

Caution! You should fix the
axis tightly in order to keep
the upper door being steady
and durable.

Description of the appliance

9

10

11

13

14

15

17

18

19

20

12

2.

3.

4.

5.

6. )

11.

12.

13.

14.

15.

16.

17.

18.

19.

20. Freezer door

21. Freezer door

1. Cabinet
LED light
Glass shelf
Crisper cover
Fruit and vegetables crisper

(inside

Lower freezer drawer
Adjustable bottom feet
Fridge door
Upper rack
Egg tray (inside)
Water tank
Lower rack
Fridge door seal
Handle

seal

ice tray

7. Upper freezer drawer

8. Upper freezer glass shelf

9. Middle freezer drawer

10. Lower freezer glass shelf

View of the appliance

Note: Due to unceasing modification of our products, your

refrigerator may be slightly different from this instruction
manual, but its functions and using methods remain the
same. To get more space in the freezer, you can remove
drawers (except lower freezer drawer), ice tray.

2

1

4

3

5

6
7

11

10

12

15

16

17

18

20

21

13

14

8

9

19

14

1. Fridge

Press the middle part of
button to set fridge
temperature between 2℃
and 8℃ as needed, and
control panel will display
corresponding figures
according to the following
sequence.

Control panel

Use your appliance according to the following control
regulations, your appliance has the corresponding functions
as the control panels showed in the pictures below.

Controlling the temperature

We recommend that when
you start your refrigerator
for the first time, the
temperature for the
refrigerator is set to 4°C and
the freezer to -18°C. If you
want to change the
temperature, follow the
instructions below.
Caution! When you set a
temperature, you set an
average temperature for the
whole refrigerator cabinet.
Temperatures inside each
compartment may vary from
the temperature values
displayed on the panel,

depending on how much
food you store and where
you place them. Ambient
temperature may also affect
the actual temperature
inside the appliance.

8

3

20

15

2. Freezer
Press the middle part of
button to set fridge
temperature between -16℃
and -24℃ as needed, and
control panel will display
corresponding figures
according to the following
sequence.

-16

-18

-20

-24

-22

3. Super Freeze

Super Freeze will
quickly lower the
temperature within

the freezer so food will
freeze vitamins and faster.
This can lock in the
nutrients of fresh food and
keep food fresh longer.
Press the middle part of
button for 3 seconds to
activate the super freeze
function. The light will
come on.
Super freeze automatically
switches off after 26 hours .
When super freeze function
is on, you can switch off
super freeze function by

●

●

●

pressing the middle part of
button and the freezer
temperature setting will
revert back to the previous
setting.

If you are going to
be away for a long
period of time, you

4. Holiday

can activate this function by
pressing the middle part of
button for 3 seconds
until the light comes on.
When the holiday function is
activated, the temperature
of the refrigerator is
automatically switched to
15℃ to minimize the
energy consumption.
Important! Do not store any
food in the fridge during this
time.
When the holiday function is
on, you can switch it off by
pressing the middle part of
button. The fridge
temperature setting will
revert back to the previous
setting.

●

●

16

Shelf in Refrigerator
chamber

There are shelves in
refrigerator chamber, and
they can be taken out to be
cleaned.

●

Your appliance has the
accessories as the
“Description of the
appliance” showed in
general, with this part
instruction you can have the
right way to use them.

Using your appliance

Door rack

It is suitable for the storage

of eggs, canned liquid,

bottled drinks and packed

food, etc. Do not place too

many heavy things in the

racks.

●

Water Dispenser

The water dispenser,
located in the fridge door, is
for storing drinking water.
With this appliance you can
obtain chilled water easily
without opening the
refrigerator. You should be
informed of following tips.

Before using
Before using this appliance
for the first time, you should
use it as follows.

1. Hold the two sides of the
water tank tightly, then pull
up the water tank by

.

2. Unscrew the head, then
clean it and the inside of
water tank.

shaking up and down

①

Head

②

17

18

Assembling
Be fore assembl ing , ple ase drai n the
water insi de the tank, and chec k whether

the washer is reversed or no t.

1.Insert the he ad into the h ole.

2.Fit the tank along the guides on t he
door.

3.Press down on the two side of t he tank.

4.When you hear a click sound, that
means the installation i s complet ed.

Warning!

1.Be careful not to press on t he head;

2.When fitting the wat er tank, ensure th e
head inserted into the hol e first;

3.If y ou found t he w asher reverse d or
loosed when removing t he tank, you must
take off the fixed holder by co ntrarot ating
it first, then pu t the washe r to the corr ect
position, and in stall t he fi xed h older a t
last.

Warning!

Don't touch other parts of the appliance
when filli ng wat er, it may ca use the
water leakage.

1. Ma ke sure the cover of the wate r tank
is fitted on.

2. Close the fridge door and check the
dispenser.

Dispensing wa ter

Lock

Before y ou d ispense the water, ma ke
sure the lock device is o n “UNLOCK”
situation.

Warning!

The lock is defined as “chil d lock”.
Don't push the dispenser lever forward
strong ly, when the dispe nser is on

“LOCK” situ ation, it may damage the
mechanism.

fixed hol der

washer

wr ong position

co rrect position

Before you fi ll the drinking wa ter into the
water tank, ensure that the wat er ta nk is
steady and in a correct posi tion.

Filling water

Caution!

Fill with water up to 3L (which is
suggested), and not abov e the level .
Otherwise, it m ay overfl ow when the l id is
close.

We rec ommend that you fill the water by
the following ways.

1. R emove the s mall li d and fil l water f rom
the inlet of the la rge lid.

2. Remove t he cove r of th e tank, and then
fill water inside direct ly.

Small lid

Large lid

Head

Slot

Guide

① ②

④

③

You shoul d us e the corre ct cups to
re c e i v e water u n d e r n e a t h t he water
dispenser.

Receiving Water

Warning!

Don't push the dispenser lever f orward
without cup, i t may cause the wa ter leak
from the dispenser.

1. Put the wa ter tank o ut of the door
carefully, and t hen was h the tank, lid, a nd
head lightly in water.

2. After you have successfully cleaned
th e appliance, yo u should dry it by
natural drying or using th e dryer.

3.If you hav e used the water dispenser
for many tim es, t he water in t he re ceiving
tank may drop on the floor, which may
make your flo or wet, and you should
clean the tank with dry towel r egularl y
before overflow.

Cleaning

Dispens er lever

Suggest ed posi ti on

Receivi ng tank

Helpful hints and tips

Energy saving tips

We recommend that you
follow the tips below to save
energy.
Try to avoid keeping the
door open for long periods
in order to conserve energy.
Ensure the appliance is
away from any sources of
heat (Direct sunlight,
electric oven or cooker
etc).
Don't set the temperature
colder than necessary.

Don't store warm food or
evaporating liquid in the
appliance.

Installing your new
appliance chapter.
If the diagram shows the
correct combination for the
drawers, crisper and
shelves, do not adjust the
combination as this is
designed to be the most

Place the appliance in a
well ventilated, humidity
free, room. Please refer to

●

●

●

●

●

●

19

●

●

●

●

●

●

●

●

●

airtight

Iced products, if consumed
immediately after removal
from the freezer compartment,
will probably cause frost burns
to the skin.

foil or plastic film
wrap.
Milk bottles:
Should have a lid and be
stored in the door racks.

Hints for freezing

When first starting-up or
after a period out of use, let
the appliance run at least 2
hours on the higher settings
before putting food in the
compartment.
Prepare food in small
portions to enable it to be
rapidly and completely
frozen and to make it
possible to subsequently
thaw only the quantity
required.
Wrap up the food In aluminum
foil or polyethylene food wraps
which are airtight.
Do not allow fresh，
unfrozen food to touch the
food which is already frozen
to avoid temperature rise of
the latter.

●

●

energy efficient configuration.

Hints for fresh food
refrigeration

Do not place hot food
directly into the refrigerator
or freezer, the internal
temperature will increase
resulting in the compressor
having to work harder and
will consume more energy.
Do cover or wrap the food,
articularly if it has a strong
flavor.
Place food properly so that
air can circulate freely
around it.

Hints for refrigeration

Meat (All Types) Wrap in
polythene food: wrap and
place on the glass shelf
above the vegetable
drawer. Always follow food
storage times and use by
dates suggested by
manufacturers.
Cooked food, cold dishes,
etc.:
They should be covered
and may be placed on any
shelf.
Fruit and vegetables:
They should be stored in
the special drawer provided.
Butter and cheese:
Sh ou ld be wra pp ed i n

●

●

20

Cleaning and care

For hygienic reasons the
appliance (including exterior
and interior accessories)
should be cleaned regularly
at least every two months.
Caution! The appliance
must not be connected to
the mains during cleaning.
Danger of electrical shock!
Before cleaning switch the
appliance off and remove
the plug from the mains
socket.

Exterior cleaning

To maintain good appearance
of your appliance, you should
clean it regularly.

It is recommended to label
and date each frozen
package in order to keep
track of the storage time.

Hints for the storage of
frozen food

Ensure that frozen food has
been stored correctly by the
food retailer.
Once defrosted, food will
deteriorate rapidly and
should not be re-frozen. Do
not exceed the storage
period indicated by the food
manufacturer.

Switching off your
appliance

If the appliance needs to be
switched off for an extended
period, the following steps
should be taken prevent
mould on the appliance.

1. Remove all food.

2. Remove the power plug
from the mains socket.

3. Clean and dry the interior
thoroughly.

4. Ensure that all the doors
are wedged open slightly to
allow air to circulate.

●

●

●

-Wipe the control panel with
a clean, soft cloth.

-Spray water onto the
cleaning cloth instead of
spraying directly on the
surface of the appliance.
This helps ensure an even
distribution of moisture to
the surface.

-Clean the doors, handles
and cabinet surfaces with a
mild detergent and then
wiped dry with a soft cloth.
Caution!

-Don't use sharp objects as
they are likely to scratch
the surface.

21

unplug the appliance from
the mains power and leave
the doors open. Ventilate
the room thoroughly to
accelerate the thawing
process.

2. When defrosting is
completed, clean your
freezer as described above.
Caution! Don't use sharp
objects to remove frost from
the freezer compartment.
Only after the interior is
completely dry should the
appliance be switched back
on and plugged back into
the mains socket.

Door seals cleaning

Take care to keep door
seals clean. Sticky food and
drinks can cause seals to
stick to the cabinet and tear
when you open the door.
Wash seal with a mild
detergent and warm water.
Rinse and dry it thoroughly
after cleaning.
Caution! Only after the
door seals are completely
dry should the appliance be
powered on.

­detergent, Clorox, ethereal
oil, abrasive cleansers or
organic solvent such as
Benzene for cleaning. They
may damage the surface of
the appliance and may
cause fire.
Interior cleaning
You should clean the
appliance interior regularly.
It will be easier to clean
when food stocks are low.
Wipe the inside of the fridge
freezer with a weak solution
of bicarbonate of soda, and
then rinse with warm water
using a wrung-out sponge
or cloth. Wipe completely
dry before replacing the
shelves and baskets.
Thoroughly dry all surfaces
and removable parts.
Although this appliance
automatically defrosts, a
layer of frost may occur on
the freezer compartment's
interior frequently or kept

Don't use Thinner, Car

open too long. If the frost is
too thick, choose a time
when the supply of food
stocks are low and proceed
as follows:

1.Remove existing food and
accessories baskets,

22

Troubleshooting

If you experience a problem with your appliance or are
concerned that the appliance is not functioning correctly, you
can carry out some easy checks before calling for service,
please see below. You can carry out some easy checks
according to this section before calling for service.

Warning! Don't try to repair the appliance yourself. If the
problem persists after you have made the checks mentioned
below, contact a qualified electrician, authorized service
engineer or the shop where you purchased the product.

Replacing the LED light:

Warning: The LED light
must not be replaced by the
user! If the LED light is
damaged, contact the
customer helpline for
assistance. To replace the
LED light, the below steps
can be followed:

1. Unplug your appliance.

2. Remove light cover by
pushing up and out.

3. Hold the LED cover with
one hand and pull it with the
other hand while pressing
the connector latch.

4. Replace LED light and
snap it correctly in place.

Problem

Possible cause & Solution

Appliance is
not working
correctly

Check whether the power cord is plugged
into the power outlet properly.

Check whether the “Power” funtion is on
by pressing the “power” button for 1
second.

Check the fuse or circuit of your power
supply, replace if necessary.

The ambient temperature is too low. Try
setting the chamber temperature to a
colder level to solve this problem.

23

It is normal that the refrigerator is not
operating during the automatic defrost
cycle, or for a short time after the
appliance is switched on to protect the
compressor.

Appliance is
not working
correctly

Odours from the
compartments

The interior may need to be cleaned.

Some food, containers or wrapping cause
odours.

Noise from the
appliance

The sounds below are quite normal:

Compressor running noises.

Air movement noise from the small fan
motor in the fridge compartment or other
compartments.

Gurgling sound similar to water boiling.

Pop ping nois e during aut omatic
defrosting.

Clicking noise before the compressor
starts.

●

●

●

Other unusual noises are due to the
reasons below and may need you to
check and take action:

The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or rolling.

The motor runs
continuously

●

●

●

●

It is normal to frequently hear the sound
of the motor, it will need to run more
when in following circumstances:

Temperature setting is set colder than

necessary

Large quantity of warm food has

recently been stored within the appliance.

The temperature outside the appliance

is too high.

Doors are kept open too long or too

often.

24

The motor runs
continuously

After your installing the appliance or it
has been switched off for a long time.

A layer of frost
occurs in the
compartment

Check that the air outlets are not blocked
by food and ensure food is placed within
the ap pliance to all ow s uffi cie nt
ventilation. Ensure that door is fully
closed. To remove the frost, please refer
to cleaning and care chapter.

Tem pe rat ur e
inside is too
warm

You may have left the doors open too
long or too frequently; or the doors are
kept open by some obstacle; or the
appliance is located with insufficient
clearance at the sides, back and top.

●

It is prohibited to dispose of this appliance as household
waste.

Packaging materials

Packaging materials with the recycle symbol are
recyclable. Dispose of the packaging into a suitable
waste collection container to recycle it.

Before disposal of the appliance

1. Pull out the mains plug from the mains socket.

2. Cut off the power cord and discard with the mains
plug.
Warning! Refrigerators contain refrigerant and gases in
the insulation. Refrigerant and gases must be disposed
of professionally as they may cause eye injuries or
ignition. Ensure that tubing of the refrigerant circuit is
not damage prior to proper disposal.

25

This marking indicates that this product
should not be disposed with other household
wa ste s t hro ugh out the EU. To p rev ent
possible harm to the environment or human
health from uncontrolled waste disposal,
rec yc le i t r es pon si b ly t o p ro mo t e th e
sustainable reuse of material resources. To
return your used device, please use the
return and collection systems or contact the
retailer where the product was purchased.
They can take this product for environmental
safe recycling.

Correct Disposal of this product

26

Unit 2 Meadow Court
Millshaw Lane Leeds,
West Yorkshire,
LS11 8LZ,
United Kingdom

FRIDGEMASTER
