Freestyle Shark 789 User Manual

789 SHARK™

INSTRUCTIONS

FEATURES:

• CURRENTTIME (HR., MIN.,
& SEC.)

• DAY / M O N T H / D AT E

• CHRONOGRAPH WITH SPLIT

& LAPT I M E S

• DUALALARMS ( 1 DAILY
R E P E ATING, 1 NON­R E P E ATING REMINDER.)

• COUNTDOWN, COUNTDOWN
R E P E AT, COUNTDOWN
CHRONO
L A P & COUNTDOWN CHRONO
S P L I TT I M E R S

• DUALT I M E

• HOURLY C H I M E

• OPTIONAL24-HR. TIME
( M I L I TA RYTIME. )

• WATER RESIST A N TTO
300 FT.

• NIGHTV I S I O N™E L E C T R O ­L U M I N E S C E N T
B A C K L I G H T I N G

NORMAL TIME MODE

( The term “Mode” means the func­tion status of the watch.) N o r m a l
time mode shows hours, minutes,
seconds, day and date. To set time,
see operating instructions on How
to Set Normal Time.

LT

LB

NORMAL TIME MODE

KEY TO SYMBOLS
LT - Left Top (Light/Set)
LB - Left Bottom (Mode)
RT - Right Top (Start/Stop)
RB - Right Bottom (Lap/Reset)

HOW TO SETNORMAL TIME,
DATE AND24-HOUR FORMAT

Note: While in the setting mode,

the Night Vision™backlight will
remain illuminated. If no buttons
are pressed for approximately ten
seconds, the watch will exit the
setting mode.
From Normal Time mode, press
and hold the light/set button LT for
approximately three seconds; the
seconds digits will flash. Pressing
the Start/Stop button RT will reset
the seconds digits to 0. If seconds
are greater than 30, one will be
added to the minutes digit.

RT

RB

LT

LB

To set minutes, press M o d e b u t t o n
L B; single minutes digit will flash. To
advance flashing minutes digit, press
Start/Stop b u t t o n R T;hold for r a p i d

RT

RB

advance.

LT

LB

To set tens of minutes, press M o d e
b u t t o n LB; tens of minutes will flash.
To advance flashing tens of minutes

LT

LB

press Start/Stop button R T; hold for
rapid advance.
Continuing through the setting
mode, the setting sequence is a
continuous loop of: seconds • single
minutes • tens of minutes • hours •
day/month/date • 12/24-hour mode,
and looping back to seconds. When
setting is complete, press Light/Set
button LT to return to normal time
mode.

HOW TO OPERATE
CHRONOGRAPH/STOPWATCH

The chronograph will record a
maximum of 99 hours, 59 minutes
and 59 seconds. Press Mode
button LB once from normal time
mode to enter the chronograph
mode. Normal time will remain on

LT

LB

the lower row, chronograph on the
upper row. “CH” flag will be d i s p l a y e d .
Reset the chronograph to zero by
pressing Lap/Reset button RB.
Press the Light/Set button LT to
switch between Lap and Split
mode.

LT

LB

RT

RB

RT

RB

RT

RB

RT

RB

(“LAP” flag will be displayed for lap
mode and “SPL” flag will be
displayed for split time mode.)
Split time is the time elapsed since
the start of the chronograph. To use
the split time feature, “SPL” flag
must be displayed. Press
Start/Stop button RT to start
chronograph. “SPL” flag will begin
flashing. Press Lap/Reset button
RB to view split time. Chronograph
will continue to count while split
time is displayed. To release split
time and return to running chrono­graph, press Lap/Reset button RB.

LT

LB

Each press of Lap/Reset button RB
will display a split time.
To stop chronograph, press S t a r t / S t o p
button R T. Reset the chronograph to
zero by pressing the Lap/Reset b u t t o n
R B . Lap time is the time elapsed since
the previous lap. To use the lap time
feature, “LAP” flag must be displayed.
Reset the chronograph to zero by
pressing the Lap/Reset button R B .
Enter LAPmode by pressing L i g h t / S e t
button LT. Press Start/Stop button R T
to start chronograph. “LAP” flag will
begin flashing. Press Lap/Rest b u t t o n
RB to view lap time. Chronograph will
start counting next lap while lap time is
displayed. To release lap time and
return to running chrono, press

Lap/Reset button RB. Each press of
Lap/Reset button RB will display a lap

t i m e .

LT

LB

To stop chronograph, press
Start/Stop button RT. Reset the
chronograph to zero by pressing
the Lap/Reset button RB.

HOW TO SET AND OPERAT E THE
ALARMS AND HOURLY CHIME

From normal time mode, press
Mode button LB twice to enter the
alarm mode. Normal time remains
on the lower row, alarm time on the
upper row. Pressing Lap/Reset but­ton RB will toggle between alarm 1,
indicated by “A1” flag, and alarm 2,
indicated by “A2” flag. Alarm 1 is a
daily, repeating alarm,and alarm 2

LT

LB

RT

RB

RT

RB

RT

RB

is a one time only reminder alarm.
Press and hold Light/Set b u t t o n LT

for approximately three seconds to
enter alarm setting mode. The min­utes digit will flash. Press S t a r t / S t o p
b u t t o n RT to advance the flashing
minutes digit.

LT

LB

Press Mode button LB to advance
tens of minutes. Press Start/Stop
button RT to advance the flashing
tens of minutes digit.

LT

LB

Press mode button L B to advance the
hours digit. P r e s s Start/Stop b u t t o n
R T to advance the flashing hours
digit. While setting the flashing hours
digit, “A” or “P” is displayed next to
alarm. “A” designates a.m. and “P”
designates p.m.

LT

LB

Press Light/Set button LT to exit
the alarm setting mode. To activate
the alarm while in alarm mode:
Press Start/Stop button RT to
activate the alarm ( (•) ) and/or
hourly chime .

LT

LB

Note the setting sequence is: alarm
on, chime on, both alarms on, both
alarms andchime off.
Again, press Lap/Reset button RB
to toggle between alarm 1 and
alarm 2. Alarm 2 is set and
activated the same way as alarm 1.
A1 ((•)) = alarm 1 set.
A2 ((•)) = alarm 2 set.
A1 A2 ((•)) = alarm 1 & 2 set.

= hourly chime on.

HOW TO OPERATE THE
COUNTDOWN TIMER

Press Mode button LB three times
from the normal time mode to enter
the countdown timer mode. Normal
time will remain in the lower row
and the timer will appear on the

RT

RB

RT

RB

RT

RB

RT

RB

continued...

upper row. “TR” flag will be
displayed. (Minimum time setting is
one minute; maximum time setting
is 99 hours, 59 minutes).

*Note: there are four timer functions
in this mode. To select between
these features, press Lap/Reset
button RB until the desired function
(noted by its respective flag) is dis­played.

TIMER COUNTDOWN - “TR” flag
will be displayed. This function will
countdown from a preset time.
When the countdown time is r e a c h e d ,
the timer will beep and will automat­ically reset to the preset time.

LT

LB

RT

RB

TIMER COUNTDOWN REPEAT­Press Lap/Reset button RB; “TR”
and “RE” flags will be
displayed. This function will
countdown from a preset time.
When the countdown time is
reached, the timer will beep,
automatically reset, and begin
counting down repeatedly until the
Start/Stop button RT is pressed.
TIMER COUNTDOWN CHRONO

LT

LB

RT

RB

LAP- Press Lap/Reset button RB,
“CH,” “LAP” and ”TR” flags will be
displayed. This function will c o u n t­down from a preset time. When the
countdown time is reached, the
timer will beep and automatically
start a chronograph. This chronograph
has a chrono lap timer, identical to
that in the chronograph/stopwatch
“LAP” mode.

LT

LB

RT

RB

TIMER COUNTDOWN CHRONO
SPLIT- Press Lap/Reset button
RB; “CH,” “SPL” and “TR” flags will
be displayed. This function will
countdown from a preset time. When
the countdown time is reached, the
timer will beep and automatically
start a chronograph. This chrono­graph has a chrono split timer,
identical to that in the
chronograph/stopwatch “SPL” mode.

To set the countdown time, press

LT

LB

RT

RB

and hold the Light/Set button LT
for three seconds. The minutes digit
will flash. To advance the flashing
minutes digit, press Start/Stop b u t t o n

RT.

Press Mode button LB to advance
to the tens of minutes digits, and

LT

LB

RT

RB

hours digits. Press Start/Stop
button RT to advance the flashing
digit. When desired timer time is
set, press Light/Set button LT to
exit the setting mode. To start or
stop timer, press Start/Stop button

RT. To reset a stopped timer, press
Lap/Reset button RB.

LT

LB

RT

RB

HOW TO SET DUAL TIME

Press Mode button LB four times to
enter the dual time mode from the
normal time mode. The dual time
mode is indicated by the “T2” flag.
Press and hold the Light/Set button
LT for approximately three seconds;

LT

LB

RT

RB

the minutes digits will flash. Press
Start/Stop button RT to advance.
Continue through the setting
sequence as done in normal time set­ting by cycling between Mode b u t t o n
LB and Start/Stop button R T.
Press Light/Set button LT to exit
the setting mode.

LT

LB

RT

RB

Note: Press and hold Start/Stop
button RT to temporarily display the
day and date of the normal time
mode. Note: The alarm and chime

flags are visible in this mode,
however, they are set to the normal
time mode.

LT

LB

RT

RB

HOW TO OPERATE THE NIGHT
VISION™ELECTROLUMINESCENT
BACKLIGHT

Press Light/Set button LT to activate
the Night Vi s i o n™e l e c t r o l u m i n e s c e n t
backlight. This light will remain illumi­nated for approximately four seconds.

CARE AND MAINTENANCE

1. Back case cover should only be
removed by an authorized watch
repair specialist.

2. Always rinse your watch in fresh
water after immersion in salt or chlo­rinated water.

3. Do not expose watch or band to
chemicals such as gasoline, aerosol
sprays, paint or solvents.

4. Periodically clean with a soft cloth
and fresh water.

WARRANTY INFORMATION

Freestyle warrants, to the original purchaser,
that its watches are free from defects in
materials and workmanship for a period of
ten (10) years under normal use. The war­ranty excludes batteries, crystal, watch case
plating, and strap/bracelet/band. The war­ranty excludes normal wear and tear and
abuse.

Special note: Freestyle®watches are
designed and engineered to be highly
water-resistant, and to withstand the most
active of lifestyles. The most important
component in keeping your watch water­resistant is the case back O-ring, which pre­vents water from entering the watch through
the case back.

Water leakage most often occurs after
improper battery replacement. We strongly
recommend having a certified jeweler, watch
repair technician or Freestyle's service cen­ter replace your battery. Water leakage due
to improper battery replacement is not cov­ered under warranty.

Should your Freestyle®watch require war­ranty service, send it along with the follow­i n g :

1. Acopy of your sales receipt

2. Your printed name and address

3. Your telephone number

4. Abrief description of the problem

5. If your watch was purchased within the
last year, there is no charge for process­ing and handling; if your watch was pur­chased more than 12 months ago, please
include $8.00 for processing and han­dling, using one of the following payment
m e t h o d s :

- C h e c k

-Money Order

-Credit Card (be sure to include card num­ber and expiration date)

REMEMBER: NEVER INCLUDE A S P E­C I A L WATCHBAND OR A N YO T H E R
A RTICLE OF PERSONALA RTICLES OF
VALUE IN YOUR SHIPMENT.

Send to the following address and be sure
to mark ATTN: INDIVIDUAL R E T U R N S .

F r e e s t y l e

Attn: Individual Returns

5855 Olivas Park Drive

Ventura, CA 9 3 0 0 3

[phone] ext.240

Please allow 20 days for return of your
w a t c h .

Neither this warranty, nor any other war­ranty expressed, is assumed for any inci­dental or consequential damages, includ­ing but not limited to the mathematical
accuracy of the product. Some states do
not allow limitations on how long an
implied warranty lasts, or the exclusions of
or limitations on consequential damages,
so the above limitations may not apply to
you. This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.

This warranty applies to watches pur­chased in the United States. For watches
purchased outside the United States,
please contact your authorized Freestyle
dealer for warranty information.

Visit our website at:

w w w. f r e e s t y l e u s a . c o m

789004-1-2 rev. 3/02
