Freescale Semiconductor TWR-MPC5125, TWR-MPC5125-KIT User guide

semiconductor

TWR-MPC5125

User Manual

TWR-MPC5125 User Manual

semiconductor

Table of Contents

1.0 General Description

Device Placement and Functions

1.1

Made by

www.

.com

02
02

2.0 Hardware Design & Architecture

2.1 General Description

2.2 Physical Specifications

2.3 Debugger Interface

2.4 Physical Specifications

3.0 Control & Configuration

3.1 Switch Settings

3.2 Sw7 – Power On Reset

3.3 Sw1 – Boot Mode

3.4 Configuration Header Settings

4.0 Schematic

5.0

Operation

5.1 Central Processing Unit

5.2 Power supplies

5.3 Resets

5.4 Memory

6.0 U-boot, Linux setup

6.1 Host Computer Setup

6.2 Target Setup

6.3 Configuring U-Boot

6.4 NFS Root Development Deployment

6.5 How to boot from net_ramboot

7.0 How to build U-Boot, Kernel and device-tree

7.1 Cross-compilation settings

7.2 How to build

8.0 How to program NAND

8.1 Program Loader and U-boot

8.2 Program Device-tree and Kernel

8.3 Upgrade Filesystem from the U-Disk

Appendix A
Appendix B

--Connector Pin Assignments

--Memory Map

07
07
07
07
08

09
09
09
09
10

11

12
12
12
12
13

14
14
15
16
19
19

21
21
21

23
23
26
26

28
29

TWR-MPC 5125

01

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

1.0 General Description

The MPC5125 Tower System is based on Freescale's MPC5125
microprocessor. The board provides on-board DDR2 SDRAM, NAND
FLASH,CAN ports, USB 2.0, 10/100 Ethernet, HDMI,USB Debug Port.All

powered from a 5 Volt wall mount power supply.

Freescale's Tower System. For information of Tower System, please go to

http://www.freescale.com/tower .

1.1 Device Placement and Functions

This section provides a description of the connectors, jumpers, switches and
main components of the MPC5125 board. Refer to Figures 1 and 2 for
location of the devices referenced below.

This board is compatible with

J2 JTAG Connector

1

CN1 RJ45 Ethernet Connector

2

J35 Serial Port Header

3

SW1 System

4

Config Switch

U13 USB PHY

5

Mini-AB USB Connector

6

CN3 HDMI Connector

7

U20 HMDI Transmitter

8

J27 Dual-Ethernet Jumper

9

J3 On-Board Microphone (MIC)

10

J1 Earphone Connector

11

U28 Audio CODEC

12

Secondary Elevator Connctor

13

TWR-MPC 5125

Figure 1

Primary Elevator connector

J4 Debug MCU Config Header

U14 Debug MCU

J19 USB Debug port

SW7 Reset Swich

SW8 Hibemate Swich

J33 Depopulated

SD Card Connector

J31 CAN Termination

S/ N: MPC 5 1 2 5 1 0 0 3 0 0 0 1

J34 CAN Connector

DC 5V

U6 DDR Memory

U7 DDR Memory

Battery Site

U1 MPC5125

Jumper

J20 DC In

02

14

15

16

17

18

19

20

21

22

23

24

25

26

27

semiconductor

U10 NAND Flash Memory

28

U4 Digital Accelerometer

29

TWR-MPC5125 User Manual

Made by

www.

A

7

-

9

-4

0

0
8-

7

-

2

-2

0

0

:
C

MA

.com

U2 Ethernet PHY

Figure 2

Additional descriptions of the functionality of switches and jumpers along with
their recommended settings can be found in Section 3 of this manual.

1

J2- JTAG Connector

Connector J2 is a 16-pin header used for the COP/JTAG input. This port is
made available to aid of debugging code running on the MPC5125.The pin­outs for the connector are listed in Appendix A

30

TWR-MPC 5125

03

TWR-MPC5125 User Manual

semiconductor

2

Cn1 RJ45 Ethernet Connector

Made by

www.

Cn1 is a standard Ethernet input jack

3

J35 Serial Port Header

J35 is the serial port header with the following 2x2 header to MPC5125 pin
assignments:

.com

PSC2_2
PSC2_3

4

SW1 System config switch

PSC2_0
PSC2_1

See switch settings. Section 3

5

U13 USB PHY

U13 is a Hi-Speed USB 2.0 ULPI transceiver

6

Mini-AB USB Connector

DOWN4 is a USB mini AB connector that is compatible with the USB 2.0
format.

7

CN3 HDMI Connector

CN3 is a HDMI interface

8

U20 HMDI Transmitter

U20 is a HDMI transmitter

9

J27 Dual-Ethernet Jumper

J27 is the dual-Ethernet jumper. Connecting a jumper across the terminals
will enable a second Ethernet connection to be made over the Primary
Elevator Connector in addition to the CN1 RJ45 Ethernet jack. Connecting
this jumper will disable the Mini-AB USB Connector.

TWR-MPC 5125

04

TWR-MPC5125 User Manual

semiconductor

10

J3 On-Board Microphone (MIC)

Made by

www.

Audio input

11

J1 Earphone Connector

Audio output

12

U28 Audio CODEC

U28 is Audio CODEC

13

Secondary Elevator Connctor

Secondary Elevator Edge Connector for the Freescale TOWER system

14

Primary Elevator connector

Primary Elevator Edge Connector for the Freescale TOWER system

15

J4 Debug MCU Config Header

See section 3.4 for configuration header settings. A BDM module can be
connected as shown to debug code running on the Debug MCU.

.com

Pin 1
Pin 3

Pin 5

16

U14 Debug MCU

Pin 2
Pin 4

Pin 6

U14 is Debug MCU which performs the USB to MPC5125 debug bridge
from the USB Debug Port.

17

J19 USB Debug port

J19 is the USB Debug port for the MPC5125. Power can be provided to
the system over this USB port.

18

SW7 Reset switch

SW7 is a Hardware Reset switch. Push once causes a Power on reset.

TWR-MPC 5125

05

TWR-MPC5125 User Manual

semiconductor

19

SW8 Hibernate Switch

Made by

www.

SW8 is hibernate switch
Push it to wake up the system

20

J33 Depopulated Battery Site

Location to add a battery or capacitor for the Real Time Clock VBAT_RTC
power domain.Recommended capacitor is EECEN0F204RT from
Panasonic .

21

U1 MPC5125

U1 is Freescale's MPC5125 microprocessor

22

SD Card Connector

SD card interface

23

J31 CAN Termination Jumper

J31 is the CAN jumper location. Connecting a jumper across the terminals
will add termination to the CAN interface which is normally not terminated.

24

J34 CAN Connector

J34 is a CAN connector

25

U6 DDR Memory

U6 is DDR2 Memory for system running

26

J20 DC IN

J20 is the 5V DC input to the board

27

U7 DDR Memory

DC 5V

U7 is DDR2 Memory for system running

28

U10 NAND Flash Memory

U10 is a NAND Flash for uboot, Linux kernel, file system and user data

29

U4 Digital Accelerometer

U4 is a digital accelerometer

30

U2 Ethernet PHY

U2 is the Ethernet PHY with MII/RMII interface.

.com

TWR-MPC 5125

06

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

2.0 Hardware Design & Architecture

2.1 Memory

4GB MLC NAND flash storage
256MB DDR2 memory

2.2 Connectving & Features

Digital accelerometer

- HDMI(video/audio) port with HDMI to DVI--D adaptor

- RJ-45 10/100 Base T Ethernet port
Mini-AB USB2.0 OTG

-

USB host to hub (keyboard, mouse, sound , card, WiFi,....)

USB device to external USB host system

On-board microphone and audio stereo out jack

­SD Card expansion port

­CAN2.0 A/B port

-

2.3 Debugger Interface

On-board debugger over Mini-B USB port

JTAG/COP header for external BDM

TWR-MPC 5125

07

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

Serial Header

JATG

USB Debug Port

EMB_AD[ 0:31]

BUS @20 0MHz, (DDR2 -400)

DDRⅡ CON TROLL ER AND DATA

12C/1

LAN PH Y

2.4 Physical Specifications

This section contains general information on the MPC5125's physical
characteristics

Board Size: Freescale Tower specification(59mm x 90mm)
Power Requirement: 5VDC

Operating Temperature: 0℃ to +70℃
Weight: 50g
RoHS: Compliant
FCC/CE: Compliant

TWR-MPC 5125

08

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

3.0 Control & Configuration

This section contains general set-up information about the various jumpers,
switches on the MPC5125 board.

3.1 Switch Settings

This section provides a brief description of the functionality and recommended
settings for the switches located on the MPC5125

Refer to Figure 1 for the locations of these switches.

3.2 Sw7 – Power On Reset

Sw7 is a push button that provides a power on reset signal for the hardware
on the MPC5125.

3.3 Sw1 – Boot Mode

The mode switch provides configure the different operation of the MPC5125.

SW1 Position Reset Configuration Signal Description Default

6 RST_CONF_ROMLOC0 Boot Device Select

0 = LPC Boot, 1 = NAND (NFC) boot 1

5 RST_CONF_BMS Boot Mode Select

0 = boot low, 1 = boot high 1

4 RST_CONF_LPC_DBW0 LPC Data Port Size

3 RST_CONF_LPC_DBW1 00 = 8-bit, 01 = 16-bit, 10 = reserved, 11 = 32-bit 00

2 RST_CONF_LPCWA LPC Word/Byte Address Mode

0 = word address mode, 1 = byte address mode 1

1 RST_CONF_LPCMX LPC Multiplex Mode

0 = non-multiplexed mode, 1 = multiplexed mode 0

TWR-MPC 5125

09

TWR-MPC5125 User Manual

semiconductor

3.4 Configuration Header Settings

3.4.1 J4 USB Debug Port Mode

This Jump is function select:
1-2 Short USB Debug Port
1-2 Open Serial to USB bridge

3.4.2 J4 Debug MCU mode

3-4 Short Bootloader mode
3-4 Open UART to USB bridge mode

Made by

www.

.com

TWR-MPC 5125

10

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

4.0 Schematic

The schematic and basic assembly information in a portable document format
for the MPC5125 can be located on the CD with the board.

The MPC5125 design can be customized for optional flexibility and custom
interfaces so the embedded systems engineer can obtain a lower overall parts
cost using a variety of fixed and user selectable options.

These options inherently are contained in connectors, jumpers and switches
on the board.

The schematic provides guidelines for using the already installed as well as
user modifiable options available on the present design.

TWR-MPC 5125

11

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

5.0 Operation

5.1 Central Processing Unit

The MCP5125 provides the interface to local on board resources including:
NAND FLASH memory, DDR2-SDRAM memory, MII (10/100 Fast Ethernet
Controller), RMII (10/100 Fast Ethernet Controller), I2C (EEPROM), PSC
(programmable serial controller) for RS232 and AC97 (audio), Interrupt
controller, USB 2.0 (ULPI), Display Interface Unit (DIU) Controller, SD card
interface.

See MPC5125 user manual for detail descriptions for each interface.

5.2 Power supplies

The MPC5125 accepts +5Volts only.
Power Sequencing
Power sequencing rules require that the IO voltage rail is powered before the

Core Voltages.

5.3 Resets

SW1 is a push button that provides a power on reset signal for the hardware
on the MPC5125

The MPC5125 POREST_B signal is used for the Configuration system and its
internal registers. It also is used for CPU power on reset.

5.3.1 Clocks

The main clock driver is a programmable clock synthesizer IC.
The SYS_CLK is the main processor clock (32.768 Mhz).
The 4Mhz is used by the Debug MCU.
The CLK_24.000Mhz is used by the CPU's internal USB circuitry.
The CLK_50.000Mhz is used by both the CPU's internal fast Ethernet circuitry

and the Ethernet PHY.

TWR-MPC 5125

12

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

The RTC_CLK_32.768Khz is used by the CPU's internal XTAL_RTC drive
circuitry.

5.4 Memory

5.4.1 DDR2 SDRAM

The dedicated DDR2 memory bus is 32 bits wide, single bank, 200MHz clock
frequency, no ECC. It uses the MPC5125 DDR2 SDRAM controller and is
directly connection to the MPC5125.

5.4.2 NAND FLASH

Dedicated NAND FLASH memory is directly connected to the MPC5125 NFC
NAND flash controller.

TWR-MPC 5125

13

TWR-MPC5125 User Manual

semiconductor

Made by

www.

6.0 U-boot, Linux setup (Target Deployment ）

6.1 Host Computer Setup

Host computer setup is critical for your BSP to function. The host must be
running tftp and nfs servers in order for deployment to work. The following
instructions are generic. Your system may be different and the commands
should be adjusted accordingly.

The following instructions are for a Linux host computer.

1). Turn off firewall for tftp to work

$ sudo iptables –F

2). Install tftp-server on the host computer

3). Install nfs-server on the host computer

4). Create the tftpboot directory if it does not already exist

$ sudo mkdir -p /tftpboot
$ sudo chmod 777 /tftpboot

5). Copy over kernel, bootloader and devicetree for your deployment to the
/tftpboot directory

6). Tar the base filesystem to <ROOTFS_PATH> directory

.com

$ sudo tar xpf <ROOTFS_PACKAGE>.tar –C /<ROOTFS_PATH>

7). Edit /etc/exp orts and add the following line

/<ROOTFS_PATH>/ *(rw,anonuid=0,anongid=0,no_subtree_check)

8). Edit /etc/xin etd.d/tftp to enable t ftp like this:

{
disable = no

socket_type = dgram

TWR-MPC 5125

14

TWR-MPC5125 User Manual

semiconductor

Made by

www.

protocol = udp
wait = yes
user = root
server = /usr/sbin/in.tftpd
server_args =/tftpboot

}

9). Restart the nfs a nd tftp servers on your ho st computer

$ sudo /etc/init.d/xinetd restart
$ sudo /etc/init.d/nfsserver restart

6.2 Target Setup

1). Connect your board to the network via the Ethernet port.

2). Connect your board to your host machine via a serial port.

3). Connect the board power supply.

4). Start minicom or other serial communications program of your choice.
Serial settings are 115200 baud, 8 bit chars, even parity.

5). Power on board and see the u-boot bootup message.

U-Boot 2009.03-00012-g21a175a-dirty (Jan 21 2010 - 11:03:07) MPC5125

CPU: MPC5125 rev. 1.0, Core e300c4 at 400 MHz, CSB at 200 MHz
board: mpc5125_mpu
I2C: ready
DRAM: 256 MB
NAND: 2048 MiB
In: serial
Out: serial
Err: serial
Net: FEC ETHERNET

.com

Type run nfsboot to mount root filesystem over NFS

TWR-MPC 5125

15

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

6.3 Configuring U-Boot

To boot the Linux kernel u-boot must have device tree support compiled in. To
verify this support is enabled, type help bootm at the u-boot prompt.

=> help bootm
bootm [addr [arg ...]]

- boot application image stored in memory
passing arguments 'arg ...'; when booting a Linux kernel, 'arg' can be the

address of an initrd image
When booting a Linux kernel which requires a flat device-tree
a third argument is required which is the address of the of the device-tree blob.

To boot that kernel without an initrd image, use a '-' for the second argument. If
you do not pass a third a bd_info struct will be passed instead

If the help message indicates that bootm takes three arguments then device
tree support is enabled. If not then it will be necessary to install a new u-boot.
See the Flashing U-Boot chapter below for details.

The factory installed u-boot has several commands predefined in the default
environment.

1). Print the existing u-boot configuration by typing “print” at the u-boot

prompt.

=> print
bootcmd=run nfsboot
bootdelay=5
baudrate=115200
loads_echo=1
preboot=echo;echo Type \"run flash_nfs\" to mount root filesystem over

NFS;echo
loadaddr=400000
u-boot_addr_r=200000
u-boot_addr=FFF00000
kernel_addr=FC040000

TWR-MPC 5125

16

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

fdt_addr=FC2C0000
ramdisk_addr=FC300000
u-boot=ads5125/u-boot.bin
netdev=eth0
nfsargs=setenv bootargs root=/dev/nfs rw nfsroot=${serverip}:${rootpath}
ramargs=setenv bootargs root=/dev/ram rw
addip=setenv bootargs

${bootargs}ip=${ipaddr}:${serverip}:${gatewayip}:${netmask}:${hostname}:$
{netdev}:off panic=1

addtty=setenv bootargs ${bootargs}console=${consdev},${baudrate}
flash_nfs=run nfsargs addip addtty;bootm ${kernel_addr}- ${fdt_addr}
flash_self=run ramargs addip addtty;bootm

${kernel_addr}${ramdisk_addr}${fdt_addr}
net_nfs=tftp ${kernel_addr_r}${bootfile};tftp ${fdt_addr_r}${fdtfile};run

nfsargs addip addtty;bootm ${kernel_addr_r}- ${fdt_addr_r}
net_self=tftp ${kernel_addr_r}${bootfile};tftp

${ramdisk_addr_r}${ramdiskfile};tftp ${fdt_addr_r}${fdtfile};run ramargs
addip addtty;bootm ${kernel_addr_r}${ramdisk_addr_r}${fdt_addr_r}

load=tftp ${u-boot_addr_r}${u-boot}
update=protect off ${u-boot_addr}+${filesize};era ${u-

boot_addr}+${filesize};cp.b ${u-boot_addr_r}${u-boot_addr}${filesize}
upd=run load update
ethact=FEC ETHERNET
ethaddr=AA:BB:CC:DD:EE:FF
ramdiskfile=rootfs.ext2.gz.uboot
hostname=limeos
net_ramboot=setenv bootargs root=/dev/ram rw console=$consdev,$baudrate;tftp

${kernel_addr_r}${bootfile};tftp ${ramdisk_addr_r}${ramdiskfile};tftp
${fdt_addr_r}${fdtfile};bootm $kernel_addr_r $ramdisk_addr_r $fdt_addr_r

bootargs=root=/dev/ram rw console=ttyPSC0,115200
filesize=3000
fileaddr=400000
gatewayip=192.168.10.1
netmask=255.255.255.0

TWR-MPC 5125

17

TWR-MPC5125 User Manual

semiconductor

Made by

www.

ipaddr=192.168.10.205
serverip=192.168.10.227
kernel_addr_r=3000000
fdt_addr_r=4000000
ramdisk_addr_r=5000000
rootpath=/home/tony/nfs
consdev=ttyPSC1
fdtfile=mpc5125-twr.dtb
bootfile=vmlinux-5125-twr.bin
stdin=serial
stdout=serial
stderr=serial

Environment size: 1947/131067 bytes

If your u-boot environment does not match then use the u-boot setenv
command to add or modify it to match what is printed here.

2). Tell the linux kernel which serial port to use for a console from the kernel
command line. Add a u-boot variable for setting the console on the kernel
command line.

=> setenv consoledev ttyPSC1

3). Set the board's network configuration using values appropriate for your
installation.

.com

=> setenv ipaddr 172.27.152.21
=> setenv serverip 172.27.152.6
=> setenv netmask 255.255.0.0
=> setenv gatewayip 172.27.255.254

4). Set some pathnames needed later

=> setenv rootpath <ROOTFS-PATH>
=> setenv bootfile vmlinux-5125-twr.bin
=> setenv fdtfile mpc5125-twr.dtb

TWR-MPC 5125

18

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

5). Save the configuration to flash

=> saveenv

6.4 NFS Root Development Deployment

During developement one typically downloads the kernel via tftp and uses nfs
for the root filesystem.

1). On the host, copy the kernel and device tree file to the tftpboot directory

2). Set nfsboot parameter

=> set nfsboot 'set bootargs ip=dhcp root=/dev/nfs rw
nfsroot=$serverip:$rootpath,proto=tcp,nolock console=$consoledev,$baudrate
$othbootargs;tftp $loadaddr $bootfile;tftp $fdtaddr $fdtfile;bootm $loadaddr ­$fdtaddr'

3). Now boot the board

=> run nfsboot

4). To have u-boot automatically run nfsboot at boottime set the bootcmd

variable.

=> setenv bootcmd run nfsboot
=> saveenv

6.5 How to boot from net_ramboot

1). Copy the kernel, device tree file and ram file system (rootfs.ext2.gz.uboot-

common) to tftpboot on the host computer.

Ram file system, rootfs.ext2.gz.uboot-common is generated by ltib
packages. Please refer to the LTIB help documentation.

TWR-MPC 5125

19

TWR-MPC5125 User Manual

semiconductor

Made by

www.

2). Set net_ramboot parameter

=> set net_ramboot 'setenv bootargs root=/dev/ram rw
console=$consdev,$baudrate;tftp $kernel_ld_addr $kernel_name;tftp
$fdt_ld_addr $fdt_name;tftp $ramdisk_ld_addr $ramdisk_name;bootm
$kernel_ld_addr $ramdisk_ld_addr $fdt_ld_addr'

=> setenv kernel_ld_addr 0x2000000

=> setenv fdt_ld_addr 0x2800000

=> setenv ramdisk_ld_addr 0x3000000

=> setenv kernel_name vmlinux-5125-twr.bin

=> setenv fdt_name mpc5125-twr.dtb

=> setenv ramdisk_name rootfs.ext2.gz.uboot-common

=> saveenv

3). Now boot the board

.com

=> run net_ramboot

TWR-MPC 5125

20

TWR-MPC5125 User Manual

semiconductor

Made by

www.

7.0 How to build U-Boot, Kernel

and device-tree

7.1 Cross-compilation settings

1). Install cross compiler tool chains
Tools install from the LTIB package, you can refer to the LTIB help

documentation for detailed installation instructions

2). Before cross compiling anything, you must set the environment variable:
ARCH, CROSS_COMPILE and PATH.
Set environment variables script file "ppc”

#!/bin/sh
TOOLCHAIN=/opt/freescale/usr/local/gcc-4.1.78-eglibc-2.5.78-1/powerpc-

e300c3-linux-gnu
LTIB=/opt/freescale/ltib/usr
export ARCH=powerpc
export CROSS_COMPILE=powerpc-e300c3-linux-gnu­export PATH=$TOOLCHAIN/bin:$LTIB/bin:$PATH

$ source ppc

7.2 How to build

1). Build U-boot

.com

$ make distclean
$ make ads5125_nand_config
$ make –j 4

2). Build Kernel

$ cp arch/powerpc/configs/mpc5125_twr_defconfig .config
$ make –j 4

TWR-MPC 5125

21

TWR-MPC5125 User Manual

semiconductor

Made by

www.

Compressed kernel ulmage in the path: arch/powerpc/boot/uImage
Uncompress the kerenl uImage script file "mkvm":

#!/bin/bash

cat vmlinux.bin.gz | gunzip > vmlinux.bin

mkimage -A ppc -O Linux -T kernel -C none -a 0x0 -e 0x0 -n Linux-2.6 -d
vmlinux.bin $1

$ mkvm vmlinux-5125-twr.bin

3). Build Device-tree

Compile the DTS script file "mkdts":

#!/bin/bash
# checks for correct cmdline usage
if [ "$#" != "1" -a "$#" != "3" ]; then
echo "Usage: `basename $0` <dts-filename> [-o dtb-filename]"
exit 1
fi

DTS_FILE=$1
DTB_FILE=${DTS_FILE%%dts}dtb

if [ "${DTS_FILE##*.}" != "dts" ]; then
echo “`basename $0`: '$DTS_FILE' input file type error."
exit 1
fi

shift

.com

if [ "$1" == "-o" ]; then
shift
DTB_FILE=$1
if [ "${DTB_FILE##*.}" != "dtb" ]; then
echo “`basename $0`: '$DTB_FILE' output file type error."
exit 1
fi
fi

./arch/powerpc/boot/dtc -I dts -O dtb -S 0x3000 -o $DTB_FILE $DTS_FILE

$ mkdts arch/powerpc/boot/dts/mpc5125-twr.dts -o mpc5125-twr.dtb

TWR-MPC 5125

22

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

8.0 How to program NAND

8.1 Program Loader and U-boot

There are two ways, using CodeWarrior JTAG port program NAND, from
CodeWarrior for MobileGT IDE or from CodeWarrior Connection Server
command line script.

8.1.1 IDE method

What tools are needed:

· CodeWarrior IDE for MobileGT v9.2

· CodeWarrior IDE patch for MPC5125 platform

· Codewarrior USB Tap

U-Boot source code is compiled on the linux server, and Codewarrior
MobileGT v9.2 is running on windows computer. The CW-IDE create project
needed to retrieve the source of information on U-Boot directory, so customer
need to map the network drive through the linux samba service.

How to map the network drive from the windows computer:

Configure the samba server on the linux server

·

· Open "My Computer" on the desktop, select Menu “Tools->Map Network

Drive"

· Like the following configuration:

Drive: Z:
Folder: \\server_ip\<U-Boot code directory on linux server>

1). Create project

. Start the CodeWarrior IDE

· Click "File->Open" and use the browse option to select u-boot in the samba

directory, CodeWarrior IDE will import u-boot and create one project.

TWR-MPC 5125

23

TWR-MPC5125 User Manual

semiconductor

Made by

www.

If prompt “can't find the file libgcc2.c”, select “Continue with next file”, this
tip does not affect the previous work.

2). Settings: Edit->Default Project Settings

Target Settings Panels->Debugger->EPPC Debugger Settings:

Processor: 52xx Target: 5125
Use Target Initialization File: 5125-twr-init.cfg, this is important initialization

DDR parameters. ( See Annex)

.com

TWR-MPC 5125

24

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

3). Press F5, start to run u-boot, serial port will see the u-boot bootup
message, entery command line.

4). Copy nand_spl/u-boot-spl-2k.bin and u-boot-second.bin to /tftpboot.

5). Program loader:

=>

tftp 0x4000000 u-boot-spl-2k.bin
=> nand_e 0x00 0x01
=> nand_loader 0x4000000 0x00 0x800 (file size)
=> nand_r 0x2000000 0x00 0x800
=> md 0x2000000

6). Program u-boot:

tftp 0x4000000 u-boot-second.bin

=>
=> nand_e 0x100 0x101
=> nand_w 0x4000000 0x100 0x40000 (file size)
=> nand_r 0x2000000 0x100 0x800
=> md 0x2000000

7). Reboot u-boot

=> reset

8.1.2 Comm nd line methoda

1). Run “CodeWarrior Connection Server “C:\ Program Files\ Freescale\
CodeWarrior for MobileGT V9.2\ccs\bin\ccs.exe” .

2). Copy u-boot-second-scrip.txt and nand_spl/loader-script-5125.txt to windows
directory, example: c:\u-boot.

3). Copy 5125_init.txt to c:\u-boot ( See Annex).

4). Loader and U-boot Program.

(bin) 1 % cd /u-boot/
(bin) 2 % source 5125_init.txt
(bin) 3 % source loader-script-5125.txt
(bin) 4 % source u-boot-second-scrip.txt

TWR-MPC 5125

25

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

8.2 Program Device-tree and Kernel

1). Device-tree

=> setenv fdt_name mpc5125-twr.dtb
=> setenv flash_dtb 0xb00
=> tftp 0x3000000 $fdt_name
=> nand_e $flash_dtb 0xb01
=> nand_w 0x3000000 $flash_dtb 0x3000

2). Kernel

setenv kernel_name vmlinux-5125-twr.bin

=>
=> setenv flash_kernel 0x300
=> tftp 0x3000000 $kernel_name
=> nand_e $flash_kernel 0xaff
=> nand_w 0x3000000 $flash_kernel 0x400000 (file size)

8.3 Upgrade Filesystem from a USB Disk

1. Copy the ram file system, rootfs.ext2.gz.uboot-common, to /tftpboot on the
host computer.

2. Copy the nand flash file system, <ROOTFS_PACKAGE>.tar, to a USB disk
drive.

3. Plug the USB disk drive into the target system.

4. Start ramdisk filesystem at the u-boot prompt.

=> run net_ramboot

5. Type "3" to exit the utility.

6. Install NAND rootfs by using the USB disk in ramdisk filesystem.
Type the following commands at ramdisk filesystem prompt.

TWR-MPC 5125

26

TWR-MPC5125 User Manual

semiconductor

Made by

www.

$ sudo flash_eraseall /dev/mtd6
$ sudo mkdir -p /tmp/udisk /tmp/mtd
$ sudo mount -t vfat /dev/sda1 /tmp/udisk
$ sudo mount -t yaffs2 /dev/mtdblock6 /tmp/mtd
$ sudo tar xpf /tmp/udisk/<ROOTFS_PACKAGE>.tar -C /tmp/mtd
$ sudo umount /tmp/mtd
$ sudo umount /tmp/udisk

.com

TWR-MPC 5125

27

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

Appendix A

– Connector Pin Assignments

J2 – MPC5125 JTAG (16 pin Header)

Pin No Description

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

MPC JTAG COP TDO

NC

MPC JTAG COP TDI

MPC JTAG TRST

NC

3.3V DC

MPC JTAG TCK

NC

MPC JTAG TMS

NC

MPC SRESET

GND

HRESET

NC

MPC CKSTP OUT

GND

TWR-MPC 5125

28

TWR-MPC5125 User Manual

semiconductor

Made by

www.

.com

Appendix B – Memory Map

The following memory map is only an example, refer to the MPC5125 Quick
Guide for specific memory map configurations, many of these memory map
settings are user defined.

Function

IMMRBAR Default
setting at reset
FF40 0000

DDR SDRAM

BOOT Space
EBC NAND
FLASH
Boot High

NAND FLASH
Upto 2GB

SRAM

USB ULPI 2.0 Device

Local Configuration
Registers

Rs232 on MPU

RS232 on TWR

IIC1

IIC2

Fast Ethernet
Controller

Bytes

Reserved

256MB

2048MB

1MB

256KB

4KB

1KB

PSC1

PSC9

32 Bit Address

Start

0x8000 0000

0x0000 0000

0xFFF0 0000

0x4000 0000

0x3000 0000

IMMR_0x3000

IMMR_0x1 0000

IMMR_0x1 1100

IMMR_0x1 1900

IMMR_0x0 1720

IMMR_0x0 1740

IMMR_0x0 2800

End

0x803F FFFF

0x0FFF FFFF

0xFFFF FFFF

0x400F FFFF

0x3001 FFFF

IMMR_3FFF

IMMR_0x1 01FF

IMMR_0x1 11FF

IMMR_0x1 19FF

IMMR_0x0 173F

IMMR_0x0 17FF

IMMR_0x0 2FFF

CS# Size

1M Recommend
4M For future

DDR_MCSN

NFC_CE0_B

256MB

1MB

1MB

32KB

4KB

32B

32B

256B

TWR-MPC 5125

29

Made by

www.

.com
