1 TWR-KL25Z
The TWR-KL25Z microcontroller module is designed to work either in standalone mode or as part of the
Freescale Tower System, a modular development platform that enables rapid prototyping and tool re-use
through reconfigurable hardware. Take your design to the next level and begin constructing your Tower
System today by visiting www.freescale.com/tower for additional Tower System microcontroller modules
and compatible peripherals. For TWR-KL25Z specific information and updates visit
www.freescale.com/TWR-KL25Z
Figure 1 Freescale Tower System Overview
TWRKL25ZUM TWR-KL25Z Page 3 of 17
2 Contents
The TWR-KL25Z contents include:
TWR-KL25Z board assembly
3ft A to mini-B USB cable for debug interface and power
3ft A to micro-B USB cable for MKL25Z128VLK4 USB interface
Micro-B to A adapter for MKL25Z128VLK4 USB Host applications
Quick Start Guide
3 TWR-KL25Z Features
Tower compatible microcontroller module
MKL25Z128VLK4 MCU (48 MHz, 128KB Flash, 16 KB RAM, Low power, 80LQFP package
Dual role USB interface with Micro-AB USB connector
Touch Tower Plug-in Socket
General purpose Tower Plug-in (TWRPI) socket
On-board debug circuit MK20 openSDA serial debug interface with virtual serial port and mass storage device
bootloader
Three axis accelerometer (MMA8451Q)
Four (4) user-controllable LEDs
Two (2) capacitive touch pads
Two (2) user pushbutton switches
Infrared transmit and receive
Potentiometer for ADC measurements
GPIO header for prototyping
TWRKL25ZUM TWR-KL25Z Page 4 of 17
4 Get to Know the TWR-KL25Z
Figure 2 Top side of TWR-KL25Z module
Figure 3 Bottom side of TWR-KL25Z module
TWRKL25ZUM TWR-KL25Z Page 5 of 17
5 Reference Documents
The documents listed below should be referenced for more information on the Kinetis family, Tower System,
and MCU Modules. These can be found in the documentation section of http://www.freescale.com/TWR-KL25Z
or http://www.freescale.com/kinetis
TWRKL25ZQSG: Quick Start Guide
TWR-KL25Z-SCH: Schematics
TWR-KL25Z-PWA: Design Package
MKL25Z128VLK4 Reference Manual
Tower Configuration Tool
Tower Mechanical Drawing
6 Hardware description
The TWR-KL25Z is a Tower MCU Module featuring the MKL25Z128VLK4 —a Kinetis microcontroller with USB 2.0
full-speed OTG controllers in a 80 LQFP package. It is intended for use in the Freescale Tower System but can
operate stand-alone. An on-board debug circuit, openSDA, provides a JTAG interface and a power supply input
through a single USB mini-AB connector, as well as a serial to USB, CDC class compliant UART interface.
6.1 Block Diagram
Figure 4 Block Diagram of TWR-KL25Z
TWRKL25ZUM TWR-KL25Z Page 6 of 17
