TWR-K60F120M Tower Module
User's Manual
Rev 1.0
Freescale Semiconductor Inc.
Table of Contents
1 TWR-K60F120M and TWR-K60F120M-KIT Overview ............................................................... 4
1.1 Contents .................................................................................................................................................................................. 5
1.2 Features .................................................................................................................................................................................. 5
1.3 Getting Started ..................................................................................................................................................................... 6
1.4 Reference Documents ....................................................................................................................................................... 6
2 Hardware Description ........................................................................................................................... 7
2.1 K60FN1M0 Microcontroller ........................................................................................................................................... 7
2.2 Clocking .................................................................................................................................................................................. 8
2.3 System Power ....................................................................................................................................................................... 9
2.3.1 RTC VBAT .............................................................................................................................................................................................. 9
2.4 Debug Interface ................................................................................................................................................................... 9
2.4.1 OSJTAG .................................................................................................................................................................................................... 9
2.4.2 Cortex Debug+ETM Connector ..................................................................................................................................................... 9
2.5 NAND Flash ........................................................................................................................................................................ 10
2.6 Infrared Port ...................................................................................................................................................................... 10
2.7 Accelerometer ................................................................................................................................................................... 10
2.8 Potentiometer, Pushbuttons, LEDs .......................................................................................................................... 10
2.9 General Purpose Tower Plug-in (TWRPI) Socket ............................................................................................... 11
2.10 Touch Interface .............................................................................................................................................................. 11
2.11 Ethernet ............................................................................................................................................................................ 12
2.12 USB ...................................................................................................................................................................................... 13
2.12.1 FS/LS USB ........................................................................................................................................................................................ 13
2.12.2 HS USB ............................................................................................................................................................................................... 13
2.13 Secure Digital Card Slot .............................................................................................................................................. 13
2.14 External Bus Interface – FlexBus ............................................................................................................................ 13
3 Jumper Table .......................................................................................................................................... 14
4 Input/Output Connectors and Pin Usage Table ......................................................................... 15
5 Tower Elevator Connections ............................................................................................................ 17
TWR-K60F120M Tower Module User's Manual Page 2 of 23
Revision
Date
Changes
0.1
Dec 13, 2011
Initial Release for PWA 700-27167 Rev B
1.0
Nov 20, 2012
Added information on running EVB at 150MHz
Added jumper details for rev C board
Added information on using trace
List of Figures
Figure 1. Freescale Tower System Overview .............................................................................................. 4
Figure 2. Callouts on front side of the TWR-K60F120M ............................................................................. 6
Figure 3. Callouts on back side of the TWR-K60F120M .............................................................................. 6
Figure 4. TWR-K60F120M Block Diagram ................................................................................................... 7
List of Tables
Table 1. Cortex Debug+ETM Connector Pinout .......................................................................................... 9
Table 2. General Purpose TWRPI socket pinout ....................................................................................... 11
Table 3. Touch TWRPI socket pinout ........................................................................................................ 12
Table 4. Ethernet operation jumper settings ........................................................................................... 12
Table 5. TWR-K60F120M Jumper Table .................................................................................................... 14
Table 6. I/O Connectors and Pin Usage Table........................................................................................... 15
Table 7. TWR-K60F120M Primary Connector Pinout ............................................................................... 17
Table 8. TWR-K60F120M Secondary Connector Pinout ........................................................................... 20
TWR-K60F120M Tower Module User's Manual Page 3 of 23
Revision History
1 TWR-K60F120M and TWR-K60F120M-KIT Overview
The TWR-K60F120M is a development board for the K10, K20 and K60 family 32-bit ARM® Cortex™-M4
MCUs. The TWR-K60F120M is populated with a device rated for 120 MHz operation across the full -40C
to 85C temperature range. At room temperatures the board can be over-clocked to 150 MHz to allow
for evaluation of the K10, K20, and K60 devices that are rated for 150 MHz operation across the full
temperature range.
The TWR-K60F120M is a Tower Controller Module compatible with the Freescale Tower System. It can
function as a stand-alone, low-cost platform for the evaluation of the Kinetis K10, K20, and K60 family
of microcontroller (MCU) devices. The TWR-K60F120M features the Kinetis K60 low-power
microcontroller based on the ARM® Cortex™-M4 architecture with USB 2.0 HS Controller, USB 2.0 fullspeed OTG controller and 10/100 Mbps Ethernet MAC.
The TWR-K60F120M is available as a stand-alone product or as a kit (TWR-K60F120M-KIT) with the
Tower Elevator Modules (TWR-ELEV) and the Tower Serial Module (TWR-SER). The TWR-K60F120M can
also be combined with other Freescale Tower peripheral modules to create development platforms for
a wide variety of applications. Figure 1 provides an overview of the Freescale Tower System.
Figure 1. Freescale Tower System Overview
TWR-K60F120M Tower Module User's Manual Page 4 of 23
1.1 Contents
The TWR-K60F120M contents include:
TWR-K60F120M board assembly
3ft USB cable
Interactive DVD with software installers and documentation
Quick Start Guide
The TWR-K60F120M-KIT contains:
TWR-K60F120M MCU module
TWR-ELEV – Primary and Secondary Elevator Modules
TWR-SER – Serial module including USB host/device/OTG, Ethernet, CAN, RS232 and RS485
1.2 Features
Figure 2 and Figure 3 show the TWR-K60F120M with some of the key features called out. The following
list summarizes the features of the TWR-K60F120M Tower MCU Module:
Tower compatible microcontroller module
MK60FN1M0VLQ12: K60FN1M in a 144 LQFP with 120 MHz operation
Touch Tower Plug-in Socket
General purpose Tower Plug-in (TWRPI) socket
On-board JTAG debug circuit (OSJTAG) with virtual serial port
2Gb of SLC NAND flash memory
Three axis accelerometer (MMA8451Q)
Four (4) user-controllable LEDs
Four (4) capacitive touch pads
Two (2) user pushbutton switches
Potentiometer
Battery Holder for 20mm lithium battery (e.g. 2032, 2025)
Micro-SD Card slot
TWR-K60F120M Tower Module User's Manual Page 5 of 23
Figure 2. Callouts on front side of the TWR-K60F120M
Figure 3. Callouts on back side of the TWR-K60F120M
1.3 Getting Started
Follow the Quick Start Guide found printed in the TWR-K60F120M box or the interactive DVD for the
list of recommended steps for getting started. There are also lab walk-through guides available on the
tool support page for the TWR-K60F120M: http://www.freescale.com/TWR-K60F120M.
1.4 Reference Documents
The documents listed below should be referenced for more information on the Kinetis family, Tower
System, and MCU Modules. These can be found in the documentation section of freescale.com/TWR-
K60F120M or freescale.com/kinetis.
TWR-K60F120M Tower Module User's Manual Page 6 of 23
OSJTAG
JTAG, Power, SCI
K60FN1M0
144 LQFP
Tower Elevator Expansion Connectors
SDHC, I2S, SPI, I2C, ADC, USB, DAC, PWM, UARTs, Flexbus, Ethernet, and ULPI
50 MHz OSC
SCI
Freescale Device
External Connectors Interface Circuits Power
MMA8451Q
Infrared Port
IR Output
I
2
C
Comparator
GPIO / Interrupts
ADC
Reset
LED
JTAG
3.3V5.0V
General Purpose
Tower Plug-in
(TWRPI)
SPI, I2C, ADC, GPIO
Touch Tower Plug-in
(TWRPI)
TSI, GPIO
Capacitive
Touch
Pads
LED
LED
LED
SD Card Slot
SDHC
USB
Mini-B
Battery
Holder
VBAT (RTC)
5.0V
32.768 KHz XTAL
12 MHz XTAL
TWR-K60F120M-QSG: Quick Start Guide
TWR-K60F120M-SCH: Schematics
TWR-K60F120M-PWB: Design Package
K60 Family Product Brief
K60 Family Reference Manual
Tower Configuration Tool
2 Hardware Description
The TWR-K60F120M is a Tower Controller Module featuring the MK60FN1M0VLQ12—an ARM CortexM4 based microcontroller with USB 2.0 HS Controller, USB 2.0 full-speed OTG controller and 10/100
Mbps Ethernet MAC in a 144 LQFP package with a maximum core operating frequency of 120MHz. It is
intended for use in the Freescale Tower System but can operate stand-alone. An on-board debug
circuit, OSJTAG, provides a JTAG debug interface and a power supply input through a single USB miniAB connector. Figure 4 shows a block diagram of the TWR-K60F120M. The following sections describe
the hardware in more detail.
2.1 K60FN1M0 Microcontroller
The TWR-K60F120M module features the MK60FN1M0VLQ12. The K60 microcontroller family is part of
the Kinetis portfolio of devices built around an ARM Cortex-M4 core. Refer to the K60 Family Product
Brief and the K60 Family Reference Manual for comprehensive information on the MK60FN1M0VLQ12
device. The key features are listed here:
Figure 4. TWR-K60F120M Block Diagram
TWR-K60F120M Tower Module User's Manual Page 7 of 23
32-bit ARM Cortex-M4 core with DSP instructions
120MHz maximum core operating frequency
144 LQFP, 20mm x 20 mm, 0.5mm pitch package
1.71V – 3.6V operating voltage input range
1 Mbyte of program flash, 128 Kbytes of static RAM
NAND flash controller
External bus interface
Power management controller with 10 different power modes
Multi-purpose clock generator with PLL and FLL operation modes
16-bit SAR ADC, 12-bit DAC
High-speed analog comparator with 6-bit DAC
Programmable voltage reference
USB high-speed OTG controller
USB full-speed/low-speed OTG/Host/Device controller with device charge detect
10/100 Mbps Ethernet MAC
SPI, I
SD Host Controller (SDHC)
GPIO with pin interrupt support, DMA request capability, digital glitch filtering
Capacitive touch sensing inputs (TSI)
Debug interfaces: JTAG, cJTAG, SWD
Trace: TPIO, FPB, DWT, ITM, ETM, ETB
2
C (w/ SMBUS support), UART (w/ ISO7816, CEA709.1-B (LON), and IrDA support), CAN, I2S
2.2 Clocking
The Kinetis MCUs start up from an internal digitally controlled oscillator (DCO). Software can enable
one, two, or three external oscillators if desired. Two of the external oscillators provide clocks to the
Multipurpose Clock Generator (MCG) module and can range from 32.768 KHz up to a 32 MHz crystal or
ceramic resonator. The external oscillator for the Real Time Clock (RTC) module accepts a 32.768 kHz
crystal.
The EXTAL0 and EXTAL1 pins of the main external oscillators can also be driven directly from an
external clock source. The TWR-K60F120M features a 50 MHz on-board clock oscillator connected to
EXTAL0 as seen in sheet 4 of the schematics. However, when the K60 Ethernet MAC is operating in
RMII mode, synchronization of the MCU input clock and the 50 MHz RMII transfer clock is important.
In this mode, the MCU input clock must be kept in phase with the 50 MHz clock supplied to the
external PHY. Therefore, the TWR-K60F120M provides the option (see description for J19 in Table 5)
to select the clock input to the MCU from 1) the on-board 50MHz source or 2) an external clock from
the CLKIN0 pin on the Primary Connector. When the K60 is operating in Ethernet RMII mode, the
Tower peripheral module implementing the RMII PHY device should drive a 50 MHz clock on the
CLKIN0 signal that is kept in phase with the clock supplied to the RMII PHY. Refer to section 2.11
“Ethernet” for more information.
The TWR-K60F120M also includes a 12MHz crystal connected to EXTAL1/XTAL1.
TWR-K60F120M Tower Module User's Manual Page 8 of 23
Pin
Function
TWR-K60F120M Connection
1
VTref
3.3V MCU supply (P3V3_MCU)
2
TMS / SWDIO
PTA3/SCI0_RTS_b/FTM0_CH0/JTAG_MS/SWD_DIO
3
GND
GND
4
TCK / SWCLK
PTA0/SCI0_CTS_b/FTM0_CH5/JTAG_CLK/SWD_CLK/EZP_CLK
2.3 System Power
In stand-alone operation, the main power source for the TWR-K60F120M module is derived from the
5.0V input from either the USB mini-B connector, J13, or the debug header, J11, when a shunt is placed
on jumper J12. A low-dropout regulator provides a 3.3V supply from the 5.0V input voltage. Refer to
sheet 6 of the TWR-K60F120M schematics for more details.
When installed into a Tower System, the TWR-K60F120M can be powered from either an on-board
source or from another source in the assembled Tower System. If both the on-board and off-board
sources are available, the TWR-K60F120M will default to the off-board source.
The 3.3V power supplied to the MCU is routed through a jumpers, J8. J8 can be supplies VDD to the
processor. The jumper shunt can be removed to allow for either 1) alternate MCU supply voltages to
be injected or 2) the measurement of power consumed by the MCU.
2.3.1 RTC VBAT
The Real Time Clock (RTC) module on the K60 has two modes of operation, system power-up and
system power-down. During system power-down, the RTC is powered from the backup power supply,
VBAT. The TWR-K60F120M provides a battery holder for a coin cell battery that can be used as the
VBAT supply. The holder can accept common 20mm diameter 3V lithium coin cell batteries (e.g. 2032,
2025). Refer to the description J9 in Table 5 “TWR-K60F120M Jumper Table” for more information.
2.4 Debug Interface
There are two debug interface options provided: the on-board OSJTAG circuit and an external Cortex
Debug+ETM connector.
2.4.1 OSJTAG
An on-board MC9S08JM60 based Open Source JTAG (OSJTAG) circuit provides a JTAG debug interface
to the K60FN1M0. A standard USB A male to Mini-B male cable (provided) can be used for debugging
via the USB connector, J13. The OSJTAG interface also provides a USB to serial bridge. Drivers for the
OSJTAG interface are provided in the P&E Micro Kinetis Tower Toolkit (available on the included DVD).
2.4.2 Cortex Debug+ETM Connector
The Cortex Debug+ETM connector is a 20-pin (0.05") connector providing access to the SWD, SWV,
JTAG, cJTAG, EzPort and ETM trace (4-bit) signals available on the K60 device. The pinout and K60 pin
connections to the debug connector, J14, is shown in Table 1Table 1.
NOTE: The TRACE_CLKOUT signal is not connected to the debug connector by default. In order to use
trace functionality R137 should be populated and R138 and R11 should be removed.
Table 1. Cortex Debug+ETM Connector Pinout
TWR-K60F120M Tower Module User's Manual Page 9 of 23
Pin
Function
TWR-K60F120M Connection
5
GND
GND
6
TDO / SWO
PTA2/SCI0_TX/FTM0_CH7/JTAG_DO/TRACE_SWO/EZP_DO
7
Key ― 8
TDI
PTA1/SCI0_RX/FTM0_CH6/JTAG_DI/EZP_DI
9
GNDDetect
PTA4/FTM0_CH1/MS/NMI_b/EZP_CS_b
10
nRESET
RESET_b
11
Target Power
5V supply (via J12)
12
TRACECLK
PTA6/FTM0_CH3/TRACE_CLKOUT
13
Target Power
5V supply (via J12)
14
TRACEDATA[0]
PTA10/FTM2_CH0/FTM2_QD_PHA/TRACE_D0
15
GND
GND
16
TRACEDATA[1]
PTA9/FTM1_CH1/FTM1_QD_PHB/TRACE_D1
17
GND
GND
18
TRACEDATA[2]
PTA8/FTM1_CH0/FTM1_QD_PHA/TRACE_D2
19
GND
GND
20
TRACEDATA[3]
PTA7/FTM0_CH4/TRACE_D3
Note: Many of the trace signals connected to the debug connector are also connected elsewhere on
the TWR-K60F120M. Refer to Table 6 “I/O Connectors and Pin Usage Table” and Table 7 “ TWRK60F120M Primary Connector Pinout” for more information.
2.5 NAND Flash
The TWR-K60F120M includes 2Gb of SLC NAND flash memory (MT29F2G15ABAEAWP). The data lines
used for the NAND flash are shared between the NAND flash controller and the FlexBus interface.
Internal arbitration logic in the processor allows for dynamic sharing between the NAND flash and
FlexBus interfaces.
2.6 Infrared Port
An infrared transmit and receive interface is implemented on the board. The CMT_IRO pin directly
drives an infrared diode. The receiver uses an infrared phototransistor connected to an on-chip analog
comparator through a low-pass filter. Internal to the K60 device, the output of the analog comparator
can be routed to a UART module for easier processing of the incoming data stream.
2.7 Accelerometer
An MMA8451Q digital accelerometer is connected to the K60 MCU through an I2C interface and a
GPIO/IRQ signal. Refer to Table 6 “I/O Connectors and Pin Usage Table” for connection details.
2.8 Potentiometer, Pushbuttons, LEDs
The TWR-K60F120M features two pushbutton switches connected to GPIO/interrupt signals, one
pushbutton connected to the master reset signal, four capacitive touch pad electrodes, four usercontrollable LEDs, and a potentiometer connected to an ADC input signal. Refer to Table 6 “I/O
Connectors and Pin Usage Table” for information about which port pins are connected to these
features.
TWR-K60F120M Tower Module User's Manual Page 10 of 23
Left-side 2x10 Connector
Right-side 2x10 Connector
Pin
Description
1
5V VCC
2
3.3 V VCC
3
GND
4
3.3V VDDA
5
VSS (Analog GND)
6
VSS (Analog GND)
7
VSS (Analog GND)
8
ADC: Analog 0
9
ADC: Analog 1
10
VSS (Analog GND)
11
VSS (Analog GND)
12
ADC: Analog 2
13
VSS (Analog GND)
14
VSS (Analog GND)
15
GND
16
GND
17
ADC: TWRPI ID 0
18
ADC: TWRPI ID 1
19
GND
20
Reset
Pin
Description
1
GND
2
GND
3
I2C: SCL
4
I2C: SDA
5
GND
6
GND
7
GND
8
GND
9
SPI: MISO
10
SPI: MOSI
11
SPI: SS
12
SPI: CLK
13
GND
14
GND
15
GPIO: GPIO0/IRQ
16
GPIO: GPIO1/IRQ
17
GPIO: GPIO2
18
GPIO: GPIO3
19
GPIO: GPIO4/Timer
20
GPIO: GPIO5/Timer
2.9 General Purpose Tower Plug-in (TWRPI) Socket
The TWR-K60F120M features a socket that can accept a variety of different Tower Plug-in modules
featuring sensors, RF transceivers, and more. The General Purpose TWRPI socket provides access to
I2C, SPI, IRQs, GPIOs, timers, analog conversion signals, TWRPI ID signals, reset, and voltage supplies.
The pinout for the TWRPI Socket is defined in Table 2.
Refer to Table 6 “I/O Connectors and Pin Usage Table” for the specific K60 pin connections to the
General Purpose TWRPI socket.
Table 2. General Purpose TWRPI socket pinout
2.10 Touch Interface
The touch sensing input (TSI) module of the Kinetis MCUs provides capacitive touch sensing detection
with high sensitivity and enhanced robustness. Each TSI pin implements the capacitive measurement of
an electrode.
The TWR-K60F120M provides two methods for evaluating the TSI module. There are four individual
electrodes on-board the TWR-K60F120M that simulate pushbuttons. Additionally, twelve TSI signals
are connected to a Touch Tower Plug-in (TWRPI) socket that can accept Touch TWRPI daughter cards
that may feature keypads, rotary dials, sliders, etc.
The pinout for the Touch TWRPI socket is defined in Table 3. Refer to Table 6 “I/O Connectors and Pin
Usage Table” for the specific K60 pin connections to the Touch TWRPI socket.
TWR-K60F120M Tower Module User's Manual Page 11 of 23
Pin
Description
1
5V VCC
2
3.3 V VCC
3
Electrode 0
4
3.3V VDDA
5
Electrode 1
6
VSS (Analog GND)
7
Electrode 2
8
Electrode 3
9
Electrode 4
10
Electrode 5
11
Electrode 6
12
Electrode 7
13
Electrode 8
14
Electrode 9
15
Electrode 10
16
Electrode 11
17
ADC: TWRPI ID 0
18
ADC: TWRPI ID 1
19
GND
20
Reset
Tower Module
Jumper
Setting
TWR-K60F120M(revB)
J18
OFF
TWR-K60F120M(revC)
J6
ON
Table 3. Touch TWRPI socket pinout
2.11 Ethernet
The K60FN1M0 features a 10/100 Mbps Ethernet MAC with MII and RMII interfaces. The TWRK60F120M routes the RMII interface signals from the K60 MCU to the Primary Connector, allowing the
connection to an external Ethernet PHY device on a Tower peripheral module.
When the K60 Ethernet MAC is operating in RMII mode, synchronization of the MCU clock and the 50
MHz RMII transfer clock is important. The MCU input clock must be kept in phase with the 50 MHz
clock supplied to the external PHY. Therefore, the TWR-K60F120M provides the option (see
description for J18 in Table 5) to clock the MCU from an external clock from the CLKIN0 pin on the
Primary Connector. The Tower peripheral module implementing the RMII PHY device should drive a 50
MHz clock on the CLKIN0 pin that is kept in phase with the clock supplied to the RMII PHY.
The TWR-SER module that comes as part of the TWR-K60F120M-KIT provides a 10/100 Ethernet PHY
that can operate in either MII or RMII mode. By default the PHY is boot strapped to operate in MII
mode; therefore jumper configuration changes may be required. Table 4 shows the settings for proper
interoperability between the Ethernet interface on the TWR-SER and the TWR-K60F120M.
Table 4. Ethernet operation jumper settings
TWR-K60F120M Tower Module User's Manual Page 12 of 23
TWR-SER
J2
3-4
TWR-SER
J3
2-3
TWR-SER
J12
9-10
2.12 USB
The K60FN1M0 features two different USB modules--a USB full-speed/low-speed OTG/Host/Device
controller with built-in transceiver and a high-speed OTG/Host/Device controller that requires a
external ULPI PHY.
2.12.1 FS/LS USB
The TWR-K60F120M routes the USB D+ and D- signals from the K60 MCU to the Primary Connector,
allowing the connection to external USB connectors or additional circuitry on a Tower peripheral
module.
The TWR-SER module included as part of the TWR-K60F120M-KIT provides a USB OTG/Host/Device
interface with a mini-AB USB connector. There are many configuration options that can be selected to
evaluate different USB modes of operation. By default, the TWR-SER is configured for USB Device
operation. Please refer to the documentation included with the TWR-SER for more information on the
configuration options.
2.12.2 HS USB
The TWR-K60F120M routes the ULPI interface signals for the high-speed USB module to the Secondary
Connector allowing the connection to an external ULPI PHY or additional circuitry on a Tower
peripheral module.
The TWR-SER2 module includes a ULPI PHY that can be used with the TWR-K60F120M in order to
evaluate the high-speed USB functionality. The TWR-SER2 is not included as part of the TWRK60F120M-KIT, but the boards can be ordered individually from Freescale.
2.13 Secure Digital Card Slot
A Micro-Secure Digital (SD) card slot is available on the TWR-K60F120M connected to the SD Host
Controller (SDHC) signals of the K60 MCU. This slot will accept micro-SD memory cards. Refer to Table
6 “I/O Connectors and Pin Usage Table” for the SDHC signal connection details.
2.14 External Bus Interface – FlexBus
The K60 device features a multi-function external bus interface called the FlexBus interface controller
capable of interfacing to slave-only devices. The FlexBus interface is not used directly on the TWRK60F120M. Instead, a subset of the FlexBus is connected to the Primary Connector so that the external
bus can access devices on Tower peripheral modules. Refer to Table 7 “ TWR-K60F120M Primary
Connector Pinout” and sheet 9 of the TWR-K60F120M schematics for more details.
TWR-K60F120M Tower Module User's Manual Page 13 of 23
Jumper
Option
Setting
Description
J1
USB VREGIN Power
Connection
*ON*
Connect USB0_VBUS from Primary Elevator (A57) to
VREGIN
OFF
Disconnect VREGIN from Primary Elevator
J2
Infrared Transmitter
Connection
ON
Connect PTD7/CMT_IRO/UART0_TX to IR Transmitter (D1)
*OFF*
Disconnect PTD7/CMT_IRO/UART0_TX from IR Transmitter
(D1)
J6 (revC
board)
50 MHz oscillator output
enable
ON
On-board 50MHz oscillator disabled. Off-board clock drives
main EXTAL.
NOTE: This option should be selected whenever a tower
module card that provides a clock on primary elevator pin
B24 is connected to the CPU module. Otherwise there will be
contention between the two clock sources.
*OFF*
On-board 50MHz oscillator enabled. On-board 50 MHz clock
drives main EXTAL.
J8
MCU Power Connection
*ON*
Connect on-board 3.3V supply to MCU
OFF
Isolate MCU from power supply (allows for external supply
or power measurements)
J9
VBAT Power Selection
*1-2*
Connect VBAT to on-board 3.3V supply
2-3
Connect VBAT to the higher voltage between on-board 3.3V
supply or coin-cell supply
J10
OSJTAG Mode Selection
ON
OSJTAG bootloader mode (OSJTAG firmware
reprogramming)
*OFF*
Debugger mode
J12
JTAG Power Connection
ON
Connect on-board 5V supply to JTAG port (supports
powering board from external JTAG probe)
*OFF*
Disconnect on-board 5V supply from JTAG port
J16
Infrared Receiver
Connection
ON
Connect PTC6/CMP0_IN0 to IR Receiver
*OFF*
Disconnect PTC6/CMP0_IN0 to IR Receiver
J18
(revB
board)
50MHz clock disable
*ON*
On-board 50MHz oscillator enabled. On-board 50 MHz clock
drives main EXTAL.
OFF
On-board 50MHz oscillator disabled. Off-board clock drives
main EXTAL.
NOTE: This option must be selected whenever a tower
module card that provides a clock on primary elevator pin
3 Jumper Table
There are several jumpers on the TWR-K60F120M that provide configuration selection and signal
isolation. Refer to the following table for details. The default installed jumper settings are shown in
bold with asterisks.
Table 5. TWR-K60F120M Jumper Table
TWR-K60F120M Tower Module User's Manual Page 14 of 23
B24 is connected to the CPU module. Otherwise there will be
contention between the two clock sources.
J18
(revC
board)
50 MHz oscillator power
*ON*
Power supply to 50MHz oscillator enabled.
OFF
Power supply to 50MHz oscillator disabled.
J19
Potentiometer Connection
*ON*
Connect ADC1_DM1 to the potentiometer
OFF
Disconnect ADC1_DM1 from the potentiometer
J21
I2S0_TXD0 source
1-2
PTA12 is used as I2S0_TXD0 (Ethernet cannot be used
when this option is selected)
2-3
PTC1 is used as I2S0_TXD0 (NFC cannot be used when this
option is selected)
J22
I2S0_TX_FS source
1-2
PTA13 is used as I2S0_TX_FS (Ethernet cannot be used
when this option is selected)
2-3
PTC2 is used as I2S0_TX_FS (NFC cannot be used when this
option is selected)
J23
I2S0_RX_BCLK/I2S0_TXD1
source
1-2
PTA14 is used as I2S0_RX_BCLK/I2S0_TXD1 (Ethernet
cannot be used when this option is selected)
2-3
PTC0 is used as I2S0_RX_BCLK/I2S0_TXD1 (NFC cannot be
used when this option is selected)
J24
I2S0_RX_FS/I2S0_RXD1
source
1-2
PTA16 is used as I2S0_RX_FS/I2S0_RXD1 (Ethernet cannot
be used when this option is selected)
2-3
PTC11 is used as I2S0_RX_FS/I2S0_RXD1 (NFC cannot be
used when this option is selected)
Feature
Connection
Port Pin
Pin Function
OSJTAG USB-to-
serial Bridge
OSJTAG Bridge RX Data
PTE9
UART5_RX
OSJTAG Bridge TX Data
PTE8
UART5_TX
SD Card Slot
SD Clock
PTE2
SDHC0_DCLK
SD Command
PTE3
SDHC0_CMD
SD Data0
PTE1
SDHC0_D0
SD Data1
PTE0
SDHC0_D1
SD Data2
PTE5
SDHC0_D2
SD Data3
PTE4
SDHC0_D3
SD Card Detect
PTE28
PTE28
Infrared Port
IR Transmit
PTD7
CMT_IRO
IR Receive
PTC6
CMP0_IN0
Pushbuttons
SW1 (IRQ0)
PTA19
PTA19
SW2 (IRQ1)
PTE26
PTE26
4 Input/Output Connectors and Pin Usage Table
The following table provides details on which K60FN1M0 pins are used to communicate with the LEDs,
switches, and other I/O interfaces onboard the TWR-K60F120M.
Note: Some port pins are used in multiple interfaces on-board and many are potentially connected to
off-board resources via the Primary and Secondary Connectors. Take care to avoid attempted
simultaneous usage of mutually exclusive features.
Table 6. I/O Connectors and Pin Usage Table
TWR-K60F120M Tower Module User's Manual Page 15 of 23
SW3 (RESET)
RESET_b
RESET_b
Touch Pads
E1 / Touch
PTA4
TSI0_CH5
E2 / Touch
PTB3
TSI0_CH8
E3 / Touch
PTB2
TSI0_CH7
E4 / Touch
PTB16
TSI0_CH9
LEDs
E1 / Orange LED
PTA11
PTA11
E2 / Yellow LED
PTA28
PTA28
E3 / Green LED
PTA29
PTA29
E4 / Blue LED
PTA10
PTA10
Potentiometer
Potentiometer (R52)
―
ADC1_DM1
Accelerometer
I2C SDA
PTD9
I2C0_SDA
I2C SCL
PTD8
I2C0_SCL
INT1
PTB4
PTB4
INT2
PTB7
PTB7
General Purpose
TWRPI Socket
TWRPI AN0 (J4 Pin 8)
―
ADC0_DP0/ADC1_DP3
TWRPI AN1 (J4 Pin 9)
―
ADC0_DM0/ADC1_DM3
TWRPI AN2 (J4 Pin 12)
―
ADC1_DP0/ADC0_DP3
TWRPI ID0 (J4 Pin 17)
―
ADC0_DP1/ADC2_DP0/ADC3_DP3
TWRPI ID1 (J4 Pin 18)
―
ADC0_DM1/ADC2_DM0/ADC3_DM3
TWRPI I2C SCL (J5 Pin 3)
PTD8
I2C0_SCL
TWRPI I2C SDA (J5 Pin 4)
PTD9
I2C0_SDA
TWRPI SPI MISO (J5 Pin 9)
PTD14
SPI2_SIN
TWRPI SPI MOSI (J5 Pin
10)
PTD13
SPI2_SOUT
TWRPI SPI SS (J5 Pin 11)
PTD15
SPI2_PCS1
TWRPI SPI CLK (J5 Pin 12)
PTD12
SPI2_SCK
TWRPI GPIO0 (J5 Pin 15)
PTD10
PTB4
TWRPI GPIO1 (J5 Pin 16)
PTB8
PTB8
TWRPI GPIO2 (J5 Pin 17)
PTB9
PTB9
TWRPI GPIO3 (J5 Pin 18)
PTA19
PTA19
TWRPI GPIO4 (J5 Pin 19)
PTE26
PTE26
Touch Pad /
Segment LCD TWRPI
Socket
Electrode 0 (J3 Pin 3)
PTB0
TSI0_CH0
Electrode 1 (J3 Pin 5)
PTB1
TSI0_CH6
Electrode 2 (J3 Pin 7)
PTB2
TSI0_CH7
Electrode 3 (J3 Pin 8)
PTB3
TSI0_CH8
Electrode 4 (J3 Pin 9)
PTC0
TSI0_CH13
Electrode 5 (J3 Pin 10)
PTC1
TSI0_CH14
Electrode 6 (J3 Pin 11)
PTC2
TSI0_CH15
Electrode 7 (J3 Pin 12)
PTA4
TSI0_CH5
Electrode 8 (J3 Pin 13)
PTB16
TSI0_CH9
Electrode 9 (J3 Pin 14)
PTB17
TSI0_CH10
Electrode 10 (J3 Pin 15)
PTB18
TSI0_CH11
Electrode 11 (J3 Pin 16)
PTB19
TSI0_CH12
TWR-K60F120M Tower Module User's Manual Page 16 of 23
TWRPI ID0 (J3 Pin 17)
―
ADC1_DP1
TWRPI ID1 (J3 Pin 18)
―
ADC1_SE16
TWR-K60F120M Primary Connector
Pi
n
#
Side B
Pi
n
#
Side A
Name
Group
Usage
Name
Group
Usage
B1
5V
Power
5.0V Power
A1
5V
Power
5.0V Power
B2
GND
Power
Ground
A2
GND
Power
Ground
B3
3.3V
Power
3.3V Power
A3
3.3V
Power
3.3V Power
B4
ELE_PS_SENSE
Power
Elevator Power
Sense
A4
3.3V
Power
3.3V Power
B5
GND
Power
Ground
A5
GND
Power
Ground
B6
GND
Power
Ground
A6
GND
Power
Ground
B7
SDHC_CLK /
SPI1_CLK
SDHC /
SPI 1
PTE2
A7
SCL0
I2C 0
PTD8
B8
SDHC_D3 /
SPI1_CS1_b
SDHC /
SPI 1
A8
SDA0
I2C 0
PTD9
B9
SDHC_D3 /
SPI1_CS0_b
SDHC /
SPI 1
PTE4
A9
GPIO9 / CTS1
GPIO /
UART
PTE10
B10 SDHC_CMD /
SPI1_MOSI
SDHC /
SPI 1
PTE3
A10 GPIO8 /
SDHC_D2
GPIO /
SDHC
PTE5
B11 SDHC_D0 /
SPI1_MISO
SDHC /
SPI 1
PTE1
A11 GPIO7 /
SD_WP_DET
GPIO /
SDHC
PTE27
B1
2
ETH_COL
Ethernet
A12
ETH_CRS
Etherne
t
B1
3
ETH_RXER
Ethernet
PTA5
A1
3
ETH_MDC
Etherne
t
PTB1
B1
4
ETH_TXCLK
Ethernet
A14
ETH_MDIO
Etherne
t
PTB0
B1
5
ETH_TXEN
Ethernet
PTA15
A1
5
ETH_RXCLK
Etherne
t
B1
6
ETH_TXER
Ethernet
A16
ETH_RXDV
Etherne
t
PTA14
B1
7
ETH_TXD3
Ethernet
A17
ETH_RXD3
Etherne
t
B1
8
ETH_TXD2
Ethernet
A18
ETH_RXD2
Etherne
t
B19
ETH_TXD1
Ethernet
PTA17
A1
9
ETH_RXD1
Etherne
t
PTA12
5 Tower Elevator Connections
The TWR-K60F120M features two expansion card-edge connectors that interface to the Primary and
Secondary Elevator boards in a Tower system. The Primary Connector (comprised of sides A and B) is
utilized by the TWR-K60F120M while the Secondary Connector (comprised of sides C and D) only
makes connections to the GND pins. Table 7 provides the pinout for the Primary Connector.
Table 7. TWR-K60F120M Primary Connector Pinout
TWR-K60F120M Tower Module User's Manual Page 17 of 23
B2
0
ETH_TXD0
Ethernet
PTA16
A2
0
ETH_RXD0
Etherne
t
PTA13
B2
1
GPIO1 / RTS1
GPIO /
UART
PTE11
A2
1
SSI_MCLK
SSI
PTE6
B2
2
GPIO2 / SDHC_D1
GPIO /
SDHC
PTE0
A2
2
SSI_BCLK
SSI
PTE12
B2
3
GPIO3
GPIO
PTE28
A2
3
SSI_FS
SSI
PTA13/PTC2
(determined by J22)
B2
4
CLKIN0
Clock
PTA18
A2
4
SSI_RXD
SSI
PTE7
B2
5
CLKOUT1
Clock
PTE26
A2
5
SSI_TXD
SSI
PTA12/PTC1
(determined by J21)
B2
6
GND
Power
Ground
A2
6
GND
Power
Ground
B2
7
AN7
ADC
PTB7
A2
7
AN3
ADC
PGA0_DP/ADC0_DP0/A
DC1_DP3
B2
8
AN6
ADC
PTB6
A2
8
AN2
ADC
PGA0_DM/ADC0_DM0/
ADC1_DM3
B2
9
AN5
ADC
PTB5
A2
9
AN1
ADC
PGA1_DP/ADC1_DP0/A
DC0_DP3
B3
0
AN4
ADC
PTB4
A3
0
AN0
ADC
PGA1_DM/ADC1_DM0/
ADC0_DM3
B3
1
GND
Power
Ground
A3
1
GND
Power
Ground
B3
2
DAC1
DAC
DAC1_OUT
A3
2
DAC0
DAC
DAC0_OUT
B3
3
TMR3
Timer
A33
TMR1
Timer
PTA9
B3
4
TMR2
Timer
PTD6
A3
4
TMR0
Timer
PTA8
B3
5
GPIO4
GPIO
PTB8
A3
5
GPIO6
GPIO
PTB9
B3
6
3.3V
Power
3.3V Power
A3
6
3.3V
Power
3.3V Power
B3
7
PWM7
PWM
PTA2
A3
7
PWM3
PWM
PTA6
B3
8
PWM6
PWM
PTA1
A3
8
PWM2
PWM
PTC3
B3
9
PWM5
PWM
PTD5
A3
9
PWM1
PWM
PTC2
B4
0
PWM4
PWM
PTA7
A4
0
PWM0
PWM
PTC1
B4
1
CANRX0
CAN 0
PTC16
A4
1
RXD0
UART 0
PTA1
B4
2
CANTX0
CAN 0
PTC17
A4
2
TXD0
UART 0
PTA2
B4
3
1WIRE
1-Wire
A43
RXD1
UART 1
PTE9
B4
4
SPI0_MISO
SPI 0
PTD14
A4
4
TXD1
UART 1
PTE8
B4
5
SPI0_MOSI
SPI 0
PTD13
A4
5
VSS
Analog
Vref
VSSA
B4
6
SPI0_CS0_b
SPI 0
PTD11
A4
6
VDDA
Analog
Vref
VDDA
TWR-K60F120M Tower Module User's Manual Page 18 of 23
B4
7
SPI0_CS1_b
SPI 0
PTD15
A4
7
CANRX1
CAN 1
B4
8
SPI0_CLK
SPI 0
PTD12
A4
8
CANTX1
CAN 1
B4
9
GND
Power
Ground
A4
9
GND
Power
Ground
B5
0
SCL1
I2C 1
PTD8
A5
0
GPIO14
GPIO
B5
1
SDA1
I2C 1
PTD9
A5
1
GPIO15
GPIO
B52 GPIO5 /
SD_CARD_DET
GPIO /
SDHC
PTE28
A5
2
GPIO16
GPIO
B53
RSRV_B53
USB 0
A53
GPIO17
GPIO
B5
4
RSRV_B54
USB 0
A54
USB0_DM
USB 0
USB0_DM
B5
5
IRQ_H
Interrupt
PTB4
A5
5
USB0_DP
USB 0
USB0_DP
B5
6
IRQ_G
Interrupt
PTB4
A5
6
USB0_ID
USB 0
B5
7
IRQ_F
Interrupt
PTB5
A5
7
USB0_VBUS
USB 0
VREGIN
B5
8
IRQ_E
Interrupt
PTB5
A58 I2S0_DIN_SC
K
I2S
PTA14/PTC0
(determined by J23)
B5
9
IRQ_D
Interrupt
PTB6
A5
9
I2S0_DIN_WS
I2S
PTA16/PTC11
(determined by J24)
B6
0
IRQ_C
Interrupt
PTB6
A6
0
I2S0_DIN1
I2S
PTA16/PTC11
(determined by J24)
B6
1
IRQ_B
Interrupt
PTB7
A6
1
I2S0_DOUT1
I2S
PTA14/PTC0
(determined by J23)
B6
2
IRQ_A
Interrupt
PTB7
A6
2
RSTIN_b
Reset
RESET_b
B63 EBI_ALE /
EBI_CS1_b
EBI
PTD0
A6
3
RSTOUT_b
Reset
PTB8
B6
4
EBI_CS0_b
EBI
PTD1
A6
4
CLKOUT0
Clock
PTC3
B6
5
GND
Power
Ground
A6
5
GND
Power
Ground
B6
6
EBI_AD15
EBI
PTB18
A6
6
EBI_AD14
EBI
PTC0
B6
7
EBI_AD16
EBI
PTB17
A6
7
EBI_AD13
EBI
PTC1
B6
8
EBI_AD17
EBI
PTB16
A6
8
EBI_AD12
EBI
PTC2
B6
9
EBI_AD18
EBI
PTB11
A6
9
EBI_AD11
EBI
PTC4
B7
0
EBI_AD19
EBI
PTB10
A7
0
EBI_AD10
EBI
PTC5
B7
1
EBI_R/W_b
EBI
PTC11
A7
1
EBI_AD9
EBI
PTC6
B7
2
EBI_OE_b
EBI
PTB19
A7
2
EBI_AD8
EBI
PTC7
B7
3
EBI_D7
EBI
PTB20
A7
3
EBI_AD7
EBI
PTC8
TWR-K60F120M Tower Module User's Manual Page 19 of 23
B7
4
EBI_D6
EBI
PTB21
A7
4
EBI_AD6
EBI
PTC9
B7
5
EBI_D5
EBI
PTB22
A7
5
EBI_AD5
EBI
PTC10
B7
6
EBI_D4
EBI
PTB23
A7
6
EBI_AD4
EBI
PTD2
B7
7
EBI_D3
EBI
PTC12
A7
7
EBI_AD3
EBI
PTD3
B7
8
EBI_D2
EBI
PTC13
A7
8
EBI_AD2
EBI
PTD4
B7
9
EBI_D1
EBI
PTC14
A7
9
EBI_AD1
EBI
PTD5
B8
0
EBI_D0
EBI
PTC15
A8
0
EBI_AD0
EBI
PTD6
B8
1
GND
Power
Ground
A8
1
GND
Power
Ground
B8
2
3.3V
Power
3.3V Power
A8
2
3.3V
Power
3.3V Power
TWR-K60F120M Secondary Connector
Pi
n
#
Side D
Pi
n
#
Side C
Name
Group
Usage
Name
Group
Usage
D1
5V
Power
5.0V Power
C1
5V
Power
5.0V
Power
D2
GND
Power
Ground
C2
GND
Power
Ground
D3
3.3V
Power
3.3V Power
C3
3.3V
Power
3.3V
Power
D4
ELE_PS_SENSE
Power
Elevator Power
Sense
C4
3.3V
Power
3.3V
Power
D5
GND
Power
Ground
C5
GND
Power
Ground
D6
GND
Power
Ground
C6
GND
Power
Ground
D7
SPI2_CLK
SPI 2
C7
SCL2
I2C 2
D8
SPI2_CS1_b
SPI 2
C8
SDA2
I2C 2
D9
SPI2_CS0_b
SPI 2
C9
GPIO25
GPIO
D1
0
SPI2_MOSI
SPI 2
C1
0
ULPI_STOP
ULPI
PTA9
D1
1
SPI2_MISO
SPI 2
C1
1
ULPI_CLK
ULPI
PTA6
D1
2
ETH_COL
Ethernet
C1
2
GPIO26
GPIO
D1
3
ETH_RXER
Ethernet
C1
3
ETH_MDC
Ethernet
D1
4
ETH_TXCLK
Ethernet
C1
4
ETH_MDIO
Ethernet
D1
5
ETH_TXEN
Ethernet
C1
5
ETH_RXCLK
Ethernet
D1
6
GPIO18
GPIO
C1
6
ETH_RXDV
Ethernet
Table 8. TWR-K60F120M Secondary Connector Pinout
TWR-K60F120M Tower Module User's Manual Page 20 of 23
D1
7
GPIO19 / SDHC_D4
GPIO /
SDHC
C1
7
GPIO27 / SDHC_D6
GPIO /
SDHC
D1
8
GPIO20 / SDHC_D5
GPIO /
SDHC
C1
8
GPIO28 / SDHC_D7
GPIO /
SDHC
D1
9
ETH_TXD1
Ethernet
C1
9
ETH_RXD1
Ethernet
D2
0
ETH_TXD0
Ethernet
C2
0
ETH_RXD0
Ethernet
D21 ULPI_NEXT /
USB1_DM
ULPI / USB
1
PTA8
C21 ULPI_DATA0 /
USB3_DM
ULPI /
USB 3
PTA10
D22 ULPI_DIR /
USB1_DP
ULPI / USB
1
PTA7
C22 ULPI_DATA1 /
USB3_DP
ULPI /
USB 3
PTA11
D23 UPLI_DATA5 /
USB2_DM
ULPI / USB
2
PTA27
C23 ULPI_DATA2 /
USB4_DM
ULPI /
USB 4
PTA24
D24 ULPI_DATA6 /
USB2_DP
ULPI / USB
2
PTA28
C24 ULPI_DATA3 /
USB4_DP
ULPI /
USB 4
PTA25
D2
5
ULPI_DATA7
ULPI
PTA29
C2
5
ULPI_DATA4
ULPI
PTA26
D2
6
GND
Power
Ground
C2
6
GND
Power
Ground
D27 LCD_HSYNC /
LCD_P24
Display
C2
7
AN11
ADC
D28 LCD_VSYNC /
LCD_P25
Display
C2
8
AN10
ADC
D2
9
AN13
ADC
C2
9
AN9
ADC
D3
0
AN12
ADC
C3
0
AN8
ADC
D3
1
GND
Power
Ground
C3
1
GND
Power
Ground
D32 LCD_CLK /
LCD_P26
Display
C3
2
GPIO29
GPIO
D3
3
TMR11
Timer
C3
3
TMR9
Timer
D3
4
TMR10
Timer
C3
4
TMR8
Timer
D3
5
GPIO21
GPIO
C35
GPIO30
GPIO
D3
6
3.3V
Power
3.3V Power
C3
6
3.3V
Power
3.3V
Power
D3
7
PWM15
PWM
C3
7
PWM11
PWM
D3
8
PWM14
PWM
C3
8
PWM10
PWM
D3
9
PWM13
PWM
C3
9
PWM9
PWM
D4
0
PWM12
PWM
C4
0
PWM8
PWM
D4
1
CANRX1
CAN 1
C4
1
RXD2 / TSI0
UART 2 /
TSI
D4
2
CANTX1
CAN 1
C4
2
TXD2 / TSI1
UART 2 /
TSI
D4
3
LCD_CONTRAST
Display
C4
3
RTS2 / TSI2
UART 2 /
TSI
TWR-K60F120M Tower Module User's Manual Page 21 of 23
D4
4
LCD_OE / LCD_P27
Display
C4
4
CTS2 / TSI3
UART 2 /
TSI
D4
5
LCD_D0 / LCD_P0
Display
C4
5
RXD3 / TSI4
UART 3 /
TSI
D4
6
LCD_D1 / LCD_P1
Display
C4
6
TXD3 / TSI5
UART 3 /
TSI
D47
LCD_D2 / LCD_P2
Display
C4
7
RTS3 / TSI6
UART 3 /
TSI
D4
8
LCD_D3 / LCD_P3
Display
C4
8
CTS3 / TSI7
UART 3 /
TSI
D4
9
GND
Power
Ground
C4
9
GND
Power
Ground
D5
0
GPIO23
GPIO
C5
0
LCD_D4 / LCD_P4
Display
D5
1
GPIO24
GPIO
C5
1
LCD_D5 / LCD_P5
Display
D52 LCD_D12 /
LCD_P12
Display
C52
LCD_D6 / LCD_P6
Display
D53
LCD_D13 /
LCD_P13
Display
C53
LCD_D7 / LCD_P7
Display
D54 LCD_D14 /
LCD_P14
Display
C54
LCD_D8 / LCD_P8
Display
D55 IRQ_P /
SPI2_CS2_b
Interrupt /
SPI 2
PTB4
C5
5
LCD_D9 / LCD_P9
Display
D56 IRQ_O /
SPI2_CS3_b
Interrupt /
SPI 2
PTB4
C5
6
LCD_D10 / LCD_P10
Display
D5
7
IRQ_N
Interrupt
PTB5
C5
7
LCD_D11 / LCD_P11
Display
D5
8
IRQ_M
Interrupt
PTB5
C5
8
TMR16
Timer
D5
9
IRQ_L
Interrupt
PTB6
C5
9
TMR15
Timer
D6
0
IRQ_K
Interrupt
PTB6
C6
0
TMR14
Timer
D6
1
IRQ_J
Interrupt
PTB7
C6
1
TMR13
Timer
D6
2
IRQ_I
Interrupt
PTB7
C6
2
LCD_D15 / LCD_P15
Display
D63 LCD_D18 /
LCD_P18
Display
C6
3
LCD_D16 / LCD_P16
Display
D64 LCD_D19 /
LCD_P19
Display
C6
4
LCD_D17 / LCD_P17
Display
D65
GND
Power
Ground
C6
5
GND
Power
Ground
D66 EBI_AD20 /
LCD_P42
EBI /
Display
C66 EBI_BE_32_24_b /
LCD_P28
EBI /
Display
D67 EBI_AD21 /
LCD_P43
EBI /
Display
C67 EBI_BE_23_16_b /
LCD_P29
EBI /
Display
D68 EBI_AD22 /
LCD_P44
EBI /
Display
C68 EBI_BE_15_8_b /
LCD_P30
EBI /
Display
D69 EBI_AD23 /
LCD_P45
EBI /
Display
C69 EBI_BE_7_0_b /
LCD_P31
EBI /
Display
D70 EBI_AD24 /
LCD_P46
EBI /
Display
C70 EBI_TSIZE0 /
LCD_P32
EBI /
Display
TWR-K60F120M Tower Module User's Manual Page 22 of 23
D71 EBI_AD25 /
LCD_P47
EBI /
Display
C71 EBI_TSIZE1 /
LCD_P33
EBI /
Display
D72 EBI_AD26 /
LCD_P48
EBI /
Display
C7
2
EBI_TS_b / LCD_P34
EBI /
Display
D73 EBI_AD27 /
LCD_P49
EBI /
Display
C73 EBI_TBST_b /
LCD_P35
EBI /
Display
D74 EBI_AD28 /
LCD_P50
EBI /
Display
C7
4
EBI_TA_b / LCD_P36
EBI /
Display
D75 EBI_AD29 /
LCD_P51
EBI /
Display
C75 EBI_CS4_b /
LCD_P37
EBI /
Display
D76 EBI_AD30 /
LCD_P52
EBI /
Display
C76 EBI_CS3_b /
LCD_P38
EBI /
Display
D77 EBI_AD31 /
LCD_P53
EBI /
Display
C77 EBI_CS2_b /
LCD_P39
EBI /
Display
D78 LCD_D20 /
LCD_P20
Display
C78 EBI_CS1_b /
LCD_P40
EBI /
Display
D79 LCD_D21 /
LCD_P21
Display
C7
9
GPIO31 / LCD_P41
GPIO
D80 LCD_D22 /
LCD_P22
Display
C8
0
LCD_D23 / LCD_P23
Display
D8
1
GND
Power
Ground
C8
1
GND
Power
Ground
D8
2
3.3V
Power
3.3V Power
C8
2
3.3V
Power
3.3V
Power
TWR-K60F120M Tower Module User's Manual Page 23 of 23
Loading...
