Freescale MC68HC908JL8, MC68HC908JK8, MC68HC908KL8, MC68HC08JL8, MC68HC08JK8 User Manual

Download

MC68HC908JL8 MC68HC908JK8 MC68HC908KL8 MC68HC08JL8 MC68HC08JK8

Data Sheet

M68HC08 Microcontrollers

MC68HC908JL8 Rev. 3.1 3/2005

freescale.com

MC68HC908JL8 MC68HC908JK8 MC68HC908KL8 MC68HC08JL8 MC68HC08JK8

Data Sheet

To provide the most up-to-date information, the revision of our documents on the World Wide Web will be the most current. Your printed copy may be an earlier revision. To verify you have the latest information available, refer to:

http://www.freescale.com

The following revision history table summarizes changes contained in this document. For your convenience, the page number designators have been linked to the appropriate location.

Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc. This product incorporates SuperFlash® technology licensed from SST.

MC68HC908JL8/JK8 • MC68HC08JL8/JK8 • MC68HC908KL8 Data Sheet, Rev. 3.1

Freescale Semiconductor 3

Revision History

Date

Mar 2005 3.1

Nov 2004 3

Nov 2002 2 First general release. —

Revision

Level

Description

Added IRQ timing to Table 17-5 . Control Timing (5V) and Table 17-8 .

Control Timing (3V)

Chapter 9 Serial Communications Interface (SCI) — Corrected SCI

module clock source from OSCCLK to Bus Clock throughout.

Figure 13-2 . Keyboard Interrupt Block Diagram —

Removed incorrect Schmitt trigger in block diagram.

14.7.2 Stop Mode — STOP_ICLKDIS bit does not affect stop mode

conditions for COP. Replaced section with new text.

Added Appendix A MC68HC08JL8 — ROM parts. 201

Added Appendix B MC68HC908KL8. 207

Page

Number(s)

188, 190

121–206

168

176

MC68HC908JL8/JK8 • MC68HC08JL8/JK8 • MC68HC908KL8 Data Sheet, Rev. 3.1

4 Freescale Semiconductor
