Technical Summary

32-Bit Modular Microcontroller

1 Introduction

The MC68331, a highly-integrated 32-bit microcontroller, combines high-performance data manipulation capabilities with powerful peripheral subsystems. The MCU is built up from standard modules that interface through a common intermodule bus (IMB). Standardization facilitates rapid development of devices tailored for specific applications.

Freescale Semiconductor, Inc.

Order this document

by MC68331TS/D Rev. 2

MC68331

. nc

The MCU incorporates a 32-bit CPU (CPU32), a system integration module (SIM), a general-purpose timer (GPT), and a queued serial module (QSM).

The MCU can either synthesize an internal clock signal from an external reference or use an external clock input directly. Operation with a 32.768-kHz reference frequency is standard. The maximum system clock speed is 20.97 MHz. Because MCU operation is fully static, register and memory contents are not affected by a loss of clock.

High-density complementary metal-oxide semiconductor (HCMOS) architecture makes the basic power consumption of the MCU low. Power consumption can be minimized by stopping the system clock. The CPU32 instruction set includes a low-power stop (LPSTOP) command that efficiently implements this capability.

Freescale Semiconductor, I

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

Table 1 Ordering Information

. nc

Package Type Temperature Frequency

(MHz)

132-Pin PQFP –40 to +85 ° C 16 MHz 2 pc tray SPAKMC331CFC16

20 MHz 2 pc tray SPAKMC331CFC20

–40 to +105 ° C 16 MHz 2 pc tray SPAKMC331VFC16

20 MHz 2 pc tray SPAKMC331VFC20

–40 to +125 ° C 16 MHz 2 pc tray SPAKMC331MFC16

20 MHz 2 pc tray SPAKMC331MFC20

144-Pin QFP –40 to +85 ° C 16 MHz 2 pc tray SPAKMC331CFV16

20 MHz 2 pc tray SPAKMC331CFV20

–40 to +105 ° C 16 MHz 2 pc tray SPAKMC331VFV16

20 MHz 2 pc tray SPAKMC331VFV20

–40 to +125 ° C 16 MHz 2 pc tray SPAKMC331MFV16

20 MHz 2 pc tray SPAKMC331MFV20

Package Order

Quantity

36 pc tray MC68331CFC16

36 pc tray MC68331CFC20

36 pc tray MC68331VFC16

36 pc tray MC68331VFC20

36 pc tray MC68331MFC16

36 pc tray MC68331MFC20

44 pc tray MC68331CFV16

44 pc tray MC68331CFV20

44 pc tray MC68331VFV16

44 pc tray MC68331VFV20

44 pc tray MC68331MFV16

44 pc tray MC68331MFV20

Order Number

Freescale Semiconductor, I

2 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Section Page

1 Introduction 1

1.1 Features ......................................................................................................................................4

1.2 Block Diagram .............................................................................................................................5

1.3 Pin Assignments ..........................................................................................................................6

1.4 Address Map ...............................................................................................................................8

1.5 Intermodule Bus ..........................................................................................................................8

2 Signal Descriptions 9

2.1 Pin Characteristics ......................................................................................................................9

2.2 MCU Power Connections ..........................................................................................................10

2.3 MCU Driver Types .....................................................................................................................10

2.4 Signal Characteristics ................................................................................................................10

2.5 Signal Function ..........................................................................................................................11

3 System Integration Module 14

3.1 Overview ...................................................................................................................................14

3.2 System Configuration and Protection ........................................................................................16

3.3 System Clock ............................................................................................................................21

3.4 External Bus Interface ...............................................................................................................24

3.5 Chip Selects ..............................................................................................................................28

3.6 General-Purpose Input/Output ..................................................................................................35

3.7 Resets .......................................................................................................................................37

3.8 Interrupts ...................................................................................................................................39

3.9 Factory Test Block .....................................................................................................................41

4 Central Processor Unit 43

4.1 Overview ...................................................................................................................................43

4.2 Programming Model ..................................................................................................................43

4.3 Status Register ..........................................................................................................................45

4.4 Data Types ................................................................................................................................45

4.5 Addressing Modes .....................................................................................................................45

4.6 Instruction Set Summary ...........................................................................................................46

4.7 Background Debugging Mode ...................................................................................................50

5 Queued Serial Module 51

5.1 Overview ...................................................................................................................................51

5.2 Pin Function ..............................................................................................................................52

5.3 QSM Registers ..........................................................................................................................53

5.4 QSPI Submodule .......................................................................................................................56

5.5 SCI Submodule .........................................................................................................................64

6 General-Purpose Timer Module 70

6.1 Overview ...................................................................................................................................70

6.2 Capture/Compare Unit ..............................................................................................................71

6.3 Pulse-Width Modulator ..............................................................................................................74

6.4 GPT Registers ...........................................................................................................................75

7 Summary of Changes 82

Freescale Semiconductor, Inc.

TABLE OF CONTENTS

MC68331TS/D 3

For More Information On This Product,

Go to: www.freescale.com

. nc

1.1 Features

• Modular Architecture

• Central Processing Unit (CPU32) — Upward Object Code Compatible — New Instructions for Controller Applications — 32-Bit Architecture — Virtual Memory Implementation — Loop Mode of Instruction Execution — Table Lookup and Interpolate Instruction — Improved Exception Handling for Controller Applications — Trace on Change of Flow — Hardware Breakpoint Signal, Background Mode — Fully Static Operation

• System Integration Module (SIM) — External Bus Support — Programmable Chip-Select Outputs — System Protection Logic — Watchdog Timer, Clock Monitor, and Bus Monitor — System Protection Logic — System Clock Based on 32.768-kHz Crystal for Low Power Operation — Test/Debug Submodule for Factory/User Test and Development

• Queued Serial Module (QSM) — Enhanced Serial Communication Interface (SCI), Universal Asynchronous Receiver Transmit-

— Queued Serial Peripheral Interface (QSPI): 80-Byte RAM, Up to 16 Automatic Transfers — Dual Function I/O Ports — Continuous Cycling, 8 to 16 Bits per Transfer

• General-Purpose Timer (GPT) — Two 16-Bit Free-Running Counters With One Nine-Stage Prescaler — Three Input Capture Channels — Four Output Compare Channels — One Input Capture/Output Compare Channel — One Pulse Accumulator/Event Counter Input — Two Pulse-Width Modulation Outputs — Optional External Clock Input

Freescale Semiconductor, Inc.

ter (UART): Modulus Baud Rate, Parity

Freescale Semiconductor, I

4 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

1.2 Block Diagram

Freescale Semiconductor, Inc.

. nc

PWMA PWMA PWMB PWMB

PCLK PCLK

PAI PAI

PGP7/IC4/OC5/OC1

PGP6/OC4/OC1 PGP5/OC3/OC1 PGP4/OC2/OC1

PGP3/OC1

PGP2/IC3 PGP1/IC2 PGP0/IC1

RXD

PQS7/TXD PQS6/PCS3 PQS5/PCS2 PQS4/PCS1

PQS3/PCS0/SS

PQS2/SCK PQS1/MOSI PQS0/MISO

PORT GP

CONTROL

PORTQS

CONTROL

PGP7/IC4/OC5/OC1 PGP6/OC4/OC1 PGP5/OC3/OC1 PGP4/OC2/OC1 PGP3/OC1 PGP2/IC3 PGP1/IC2 PGP0/IC1

TXD PCS3 PCS2 PCS1 PCS0/SS SCK MOSI MISO

GPT

IMB

CHIP

SELECTS

BR BG

BGACK

CS[10:0]

FC2 FC1

FC0

ADDR[23:19]

ADDR[23:0]

SIZ1 PE7/SIZ1 SIZ0 PE6/SIZ0

DS AS PE4/AS

RMC PE3/RMC

AVEC PE2/AVEC DSACK1 PE1/DSACK1 DSACK0

PORT C

CONTROL

PORT E

CONTROL

CSBOOT

ADDR23/CS10 PC6/ADDR22/CS9

PC5/ADDR21/CS8 PC4/ADDR20/CS7 PC3/ADDR19/CS6 PC2/FC2/CS5

PC1/FC1/CS4 PC0/FC0/CS3

BGACK/CS2 BG/CS1 BR/CS0

ADDR[18:0]

PE5/DS

PE0/DSACK0

EBI

DATA[15:0]DATA[15:0]

R/W RESET HALT

CPU32QSM

IRQ[7:1]

PORT F

CONTROL

MODCLK

CLOCK

BERR

PF7/IRQ7 PF6/IRQ6 PF5/IRQ5 PF4/IRQ4

PF3/IRQ3 PF2/IRQ2 PF1/IRQ1 PF0/MODCLK

CLKOUT XTAL EXTAL

Freescale Semiconductor, I

BKPT/DSCLK

/DSI

IFETCH

/DSO

IPIPE

CONTROL

BKPT

TEST

TSC

QUOT

TSC

FREEZE/QUOT

CONTROL

331 BLOCK

FREEZE

DSI

DSO

DSCLK

IPIPE

IFETCH

Figure 1 MCU Block Diagram

MC68331TS/D 5

For More Information On This Product,

Go to: www.freescale.com

1.3 Pin Assignments

Freescale Semiconductor, Inc.

. nc

Freescale Semiconductor, I

DD NC

ADDR1

ADDR2 ADDR3

ADDR4 ADDR5

ADDR6 ADDR7

ADDR8

ADDR9

ADDR10 ADDR11

ADDR12

ADDR13 ADDR14

ADDR15 ADDR16

ADDR17 ADDR18

PQS0/MISO PQS1/MOSI

PQS2/SCK

PQS3/PCS0/SS

PQS4/PCS1 PQS5/PCS2

PQS6/PCS3

PGP0/IC1

PGP1/IC2

PGP2/IC3

PGP3/OC1

PGP4/OC2/OC1

PGP5/OC3/OC1NCPGP6/OC4/OC1

16151413121110 18 19 20 21

22 23

24 25

26 27

28 29

30 31

32 33

34 35

36 37

38 39

40 41

42 43 44 45 46 47 48 49 50

52535455565758596061626364656667686970717273747576777879808182

VSSV

9876543

PGP7/IC4/OC5/OC1

PAI

VSSV

MC68331

132

131

PWMA

130

PWMB

PCLK

129

128

127

126

PC4/ADDR20/CS7

PC5/ADDR21/CS8

PC6/ADDR22/CS9

ADDR23/CS10

125

124

123

122

PC0/FC0/CS3

PC1/FC1/CS4

PC2/FC2/CS5

PC3/ADDR19/CS6

119

118

117

116 115 114 113 112 111 110 109 108 107 106 105 104 103 102 101 100

121

120

99 98

97 96

95 94

93 92

91 90

89 88

87 86

85 84

BGACK/CS2 BG/CS1

BR/CS0 CSBOOT

DATA0 DATA1

DATA2 DATA3

DATA4 DATA5

DATA6 DATA7

DATA8 DATA9 DATA10 DATA11 V

SS DATA12 DATA13

DATA14 DATA15

ADDR0 PE0/DSACK0

PE1/DSACK1 PE2/AVEC PE3/RMC PE5/DS V

PE4/AS

PE6/SIZ0

331 132-PIN QFP

PQS7/TXD

RXD

/DSO

IPIPE

/DSI

/DSCLK

IFETCH

BKPT

TSC

FREEZE/QUOT

XTAL

EXTAL

DDSYN

XFC

VDDVDDV

CLKOUT

HALT

RESET

BERR

PF7/IRQ7

PF4/IRQ4

PF5/IRQ5

PF6/IRQ6

PF1/IRQ1

PF2/IRQ2

PF3/IRQ3

R/W

PE7/SIZ1

PF0/MODCLK

Figure 2 MC68331 132-Pin QFP Pin Assignments

6 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

/CS2

. nc

FC0/CS3 FC1/CS4

FC2/CS5 ADDR19/CS6 ADDR20/CS7 ADDR21/CS8 ADDR22/CS9

ADDR23/CS10

PGP7/IC4/OC5/OC1

PGP5/OC3/OC1 PGP4/OC2/OC1

PCLK PWMB PWMA

NC NC NC

PAI

PGP6/OC4

PGP3/OC1

PGP2/IC3 PGP1/IC2

PGP0/IC1

SS NC

BGACK

BG/CS1

BR/CS0

CSBOOT

142

141

ADDR1

ADDR2

DATA0

140

139

ADDR3

ADDR4

143

144

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36

383940414243444546474849505152535455565758596061626364

DATA1

DATA2

138

137

ADDR5

ADDR6

DATA3

136

135

ADDR7

ADDR8

VSSV

134

DATA4

DATA5

133

132

ADDR9

DATA6

DATA7NCDATA8NCDATA9

131

130

129

128

127

126

MC68331

ADDR10

ADDR11

ADDR12

DATA10NCDATA11

125

124

123

ADDR13

ADDR14

ADDR15NCADDR16

122

121

VSSDATA12

120

119

DATA13

DATA14

118

117

ADDR17

ADDR18

DATA15

ADDR0

PE0/DSACK0

PE1/DSACK1

116

115

114

113

6667697071

PQS2/SCK

PQS0/MISO

PQS1/MOSI

PQS3/PCS0/SS

PE2/AVEC

PE3/RMC

PE5/DS

109

112

111

110

108 107 106 105 104 103 102 101 100

99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76 75 74 73 72

PQS4/PCS1

PQS5/PCS2

PQS6/PCS3

NC V

PE4/AS PE6/SIZ0 PE7/SIZ1 R/W PF0/MODCLK PF1/IRQ1 PF2/IRQ2 PF3/IRQ3 PF4/IRQ4 PF5/IRQ5 PF6/IRQ6 PF7/IRQ7 BERR HALT RESET

SS CLKOUT V

DD NC

XFC V

DD EXTAL V

DD XTAL V

SS FREEZE/QUOT

TSC BKPT/DSCLK IFETCH/DSI IPIPE/DSO RXD PQS7/TXD

SS NC

Freescale Semiconductor, I

331 144-PIN QFP

Figure 3 MC68331 144-Pin QFP Pin Assignments

MC68331TS/D 7

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

1.4 Address Map

The following figure is a map of the MCU internal addresses. Unimplemented blocks are mapped externally.

$YFF000

$YFF900

$YFF93F

GPT

. nc

Freescale Semiconductor, I

$YFFA00

SIM

$YFFA7F

$YFFA80

$YFFAFF

$YFFC00

$YFFDFF $YFFFFF

1.5 Intermodule Bus

The intermodule bus (IMB) is a standardized bus developed to facilitate both design and operation of modular microcontrollers. It contains circuitry to support exception processing, address space partitioning, multiple interrupt levels, and vectored interrupts. The standardized modules in the MCU communicate with one another and with external components through the IMB. The IMB in the MCU uses 24 address and 16 data lines.

RESERVED

QSM

331 ADDRESS MAP

Figure 4 MCU Address Map

8 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

2 Signal Descriptions

2.1 Pin Characteristics

The following table shows MCU pins and their characteristics. All inputs detect CMOS logic levels. All inputs can be put in a high-impedance state, but the method of doing this differs depending upon pin function. Refer to Table 4 , for a description of output drivers. An entry in the discrete I/O column of Ta-

ble 2 indicates that a pin has an alternate I/O function. The port designation is given when it applies.

Refer to the MCU Block Diagram for information about port organization.

Table 2 MCU Pin Characteristics

. nc

Freescale Semiconductor, I

Mnemonic

ADDR23/CS10

ADDR[22:19]/CS[9:6]

ADDR[18:0] A Y N — —

BGACK

BKPT

CLKOUT A — — — —

CSBOOT

DATA[15:0]

DSACK1

DSACK0

DSI/IFETCH

DSO/IPIPE

EXTAL FC[2:0]/CS[5:3] A Y N O PC[2:0] FREEZE/QUOT A — — — —

IC4/OC5 A Y Y I/O GP4

IC[3:1] A Y Y I/O GP[7:5]

IRQ[7:1]

MODCLK

OC[4:1] A Y Y I/O GP[3:0]

PCLK

PCS0

PCS[3:1]

PWMA, PWMB A — — O —

RESET

/ECLK A Y N O —

AS AVEC BERR

/CS1 B — — — —

/CS2 B Y N — — /DSCLK — Y Y — — /CS0 BY N ——

HALT

B Y Y I/O PF[7:1]

MISO Bo Y Y I/O PQS0

MOSI Bo Y Y I/O PQS1

PAI

/SS Bo Y Y I/O PQS3

R/W

RMC

Output

Driver

A Y N O PC[6:3]

B Y N I/O PE5 B Y N I/O PE2 BY N — —

B — — — —

Aw Y N — —

B Y N I/O PE4 B Y N I/O PE1 B Y N I/O PE0 AY Y —— A— — ——

— — Special — —

Bo Y N — —

B Y N I/O PF0

— Y Y I — — Y Y I —

Bo Y Y I/O PQS[6:4]

AY N — —

Bo Y Y — —

B Y N I/O PE3

Input

Synchronized

Input

Hysteresis

Discrete

I/O

Designation

Port

MC68331TS/D 9

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

Table 2 MCU Pin Characteristics (Continued)

. nc

Mnemonic

RXD — N N — — SCK Bo Y Y I/O PQS2

SIZ[1:0] B Y N I/O PE[7:6]

TSC — Y Y — — TXD Bo Y Y I/O PQS7

XFC

XTAL

NOTES:

1. DATA[15:0] are synchronized during reset only. MODCLK is synchronized only when used as an input port pin.

2. EXTAL, XFC, and XTAL are clock reference connections.

3. PAI and PCLK can be used for discrete input, but are not part of an I/O port.

2.2 MCU Power Connections

DDSYN

SSE

DDE

SSI

DDI

Output

Driver

— — — Special — — — — Special —

Table 3 MCU Power Connections

Input

Synchronized

Input

Hysteresis

Clock Synthesizer Power

External Periphery Power (Source and Drain)

Internal Module Power (Source and Drain)

Discrete

I/O

Designation

Port

2.3 MCU Driver Types

Table 4 MCU Driver Types

Type I/O Description

A O Output-only signals that are always driven; no external pull-up required

Aw O Type A output with weak P-channel pull-up during reset

B O Three-state output that includes circuitry to pull up output before high impedance is es-

Bo O Type B output that can be operated in an open-drain mode

2.4 Signal Characteristics

Freescale Semiconductor, I

Signal Name MCU Module Signal Type Active State

ADDR[23:0] SIM Bus —

CLKOUT SIM Output —

CS[10:0]

CSBOOT

DATA[15:0] SIM Bus —

tablished, to ensure rapid rise time. An external holding resistor is required to maintain logic level while the pin is in the high-impedance state.

Table 5 MCU Signal Characteristics

AS AVEC BERR

BGACK

BKPT

SIM Output 0 SIM Input 0 SIM Input 0 SIM Output 0 SIM Input 0

CPU32 Input 0

SIM Input 0

SIM Output 0 SIM Output 0

SIM Output 0

10 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Signal Name MCU Module Signal Type Active State

DSACK[1:0]

PWMA, PWMB GPT Output —

2.5 Signal Function

Freescale Semiconductor, Inc.

Table 5 MCU Signal Characteristics (Continued)

DSCLK CPU32 Input Serial Clock

DSI CPU32 Input (Serial Data)

DSO CPU32 Output (Serial Data) EXTAL SIM Input — FC[2:0] SIM Output —

FREEZE SIM Output 1

HALT

IC[4:1] GPT Input —

IFETCH

IPIPE

IRQ[7:1]

MISO QSM Input/Output —

MODCLK SIM Input —

MOSI QSM Input/Output —

OC[5:1] GPT Output —

PAI GPT Input —

PC[6:0] SIM Output (Port)

PCS[3:0] QSM Input/Output —

PE[7:0] SIM Input/Output (Port) PF[7:0] SIM Input/Output (Port)

PQS[7:0] QSM Input/Output (Port)

PCLK GPT Input —

QUOT SIM Output —

RESET

RMC

R/W RXD QSM Input — SCK QSM Input/Output —

SIZ[1:0] SIM Output —

SS TSC SIM Input — TXD QSM Output — XFC SIM Input —

XTAL SIM Output —

SIM Input 0

SIM Input/Output 0

CPU32 Output — CPU32 Output —

SIM Input 0

SIM Input/Output 0 SIM Output 0 SIM Output 1/0

QSM Input 0

Freescale Semiconductor, I

Signal Name Mnemonic Function

Address Bus ADDR[23:0] 24-bit address bus Address Strobe AS Autovector AVEC Bus Error BERR Bus Grant BG Bus Grant Acknowledge BGACK Breakpoint BKPT Bus Request BR System Clockout CLKOUT System clock output Chip Selects CS[10:0]

Table 6 MCU Signal Function

Indicates that a valid address is on the address bus Requests an automatic vector during interrupt acknowledge Indicates that a bus error has occurred Indicates that the MCU has relinquished the bus Indicates that an external device has assumed bus mastership Signals a hardware breakpoint to the CPU Indicates that an external device requires bus mastership

Select external devices at programmed addresses

MC68331TS/D 11

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

Table 6 MCU Signal Function (Continued)

Signal Name Mnemonic Function

Boot Chip Select CSBOOT Data Bus DATA[15:0] 16-bit data bus Data Strobe DS

Data and Size Acknowledge DSACK[1:0] Development Serial In, Out,

Clock Crystal Oscillator EXTAL, XTAL Connections for clock synthesizer circuit reference;

Function Codes FC[2:0] Identify processor state and current address space Freeze FREEZE Indicates that the CPU has entered background mode Halt HALT Input Capture IC[3:1] When a specified transition is detected on an input capture pin, the

Input Capture 4/Output Compare 5IC4/OC5 Can be configured for either an input capture or output compare

Instruction Pipeline IPIPE Interrupt Request Level IRQ[7:1] Master In Slave Out MISO Serial input to QSPI in master mode;

Clock Mode Select MODCLK Selects the source and type of system clock Master Out Slave In MOSI Serial output from QSPI in master mode;

Output Compare OC[5:1] Change state when the value of an internal GPT counter matches

Pulse Accumulator Input PAI Signal input to the pulse accumulator Port C PC[6:0] SIM digital output port signals Auxiliary Timer Clock Input PCLK External clock dedicated to the GPT Peripheral Chip Select PCS[3:0] QSPI peripheral chip selects Port E PE[7:0] SIM digital I/O port signals Port F PF[7:0] SIM digital I/O port signals Port QS PQS[7:0] QSM digital I/O port signals Pulse-Width Modulation PWMA, PWMB Output for PWM Quotient Out QUOT Provides the quotient bit of the polynomial divider Reset RESET Read-Modify-Write Cycle RMC Read/Write R/W SCI Receive Data RXD Serial input to the SCI QSPI Serial Clock SCK Clock output from QSPI in master mode;

Size SIZ[1:0] Indicates the number of bytes to be transferred during a bus cycle Slave Select SS

Three-State Control TSC Places all output drivers in a high-impedance state SCI Transmit Data TXD Serial output from the SCI External Filter Capacitor XFC Connection for external phase-locked loop filter capacitor

Chip select for external boot startup ROM

During a read cycle, indicates when it is possible for an external device to place data on the data bus. During a write cycle, indicates that valid data is on the data bus.

Provide asynchronous data transfers and dynamic bus sizing

DSI, DSO,

DSCLK

, IFETCH Indicate instruction pipeline activity

Serial I/O and clock for background debugging mode

a crystal or an external oscillator can be used

Suspend external bus activity

value in an internal GPT counter is latched

Provides an interrupt priority level to the CPU

serial output from QSPI in slave mode

serial input to QSPI in slave mode

a value stored in a GPT control register

System reset Indicates an indivisible read-modify-write instruction Indicates the direction of data transfer on the bus

clock input to QSPI in slave mode

Causes serial transmission when QSPI is in slave mode; causes mode fault in master mode

12 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Freescale Semiconductor, I

MC68331TS/D 13

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

3 System Integration Module

The system integration module (SIM) consists of five functional blocks that control system start-up, initialization, configuration, and external bus.

SYSTEM CONFIGURATION

XTAL

CLOCK SYNTHESIZER

SYSTEM PROTECTION

CHIP SELECTS

CLKOUT EXTAL

MODCLK

CHIP SELECTS

EXTERNAL BUS

EXTERNAL BUS INTERFACE

RESET

FACTORY TEST

Figure 5 SIM Block Diagram

3.1 Overview

The system configuration and protection block controls MCU configuration and operating mode. The block also provides bus and software watchdog monitors.

The system clock generates clock signals used by the SIM, other IMB modules, and external devices. In addition, a periodic interrupt generator supports execution of time-critical control routines.

The external bus interface handles the transfer of information between IMB modules and external address space.

TSC

FREEZE/QUOT

300 S(C)IM BLOCK

Freescale Semiconductor, I

The chip-select block provides eleven general-purpose chip-select signals and a boot ROM chip-select signal. Both general-purpose and boot ROM chip-select signals have associated base address registers and option registers.

The system test block incorporates hardware necessary for testing the MCU. It is used to perform factory tests, and its use in normal applications is not supported.

The SIM control register address map occupies 128 bytes. Unused registers within the 128-byte address space return zeros when read. The “Access” column in the SIM address map below indicates which registers are accessible only at the supervisor privilege level and which can be assigned to either the supervisor or user privilege level, according to the value of the SUPV bit in the SIMCR.

14 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

Access Address 15 8 7 0

S $YFFA00 SIM CONFIGURATION (SIMCR) S $YFFA02 FACTORY TEST (SIMTR) S $YFFA04 CLOCK SYNTHESIZER CONTROL (SYNCR) S $YFFA06 NOT USED RESET STATUS REGISTER (RSR) S $YFFA08 MODULE TEST E (SIMTRE) S $YFFA0A NOT USED NOT USED S $YFFA0C NOT USED NOT USED

S $YFFA0E NOT USED NOT USED S/U $YFFA10 NOT USED PORT E DATA (PORTE0) S/U $YFFA12 NOT USED PORT E DATA (PORTE1) S/U $YFFA14 NOT USED PORT E DATA DIRECTION (DDRE)

S $YFFA16 NOT USED PORT E PIN ASSIGNMENT (PEPAR) S/U $YFFA18 NOT USED PORT F DATA (PORTF0) S/U $YFFA1A NOT USED PORT F DATA (PORTF1) S/U $YFFA1C NOT USED PORT F DATA DIRECTION (DDRF)

S $YFFA1E NOT USED PORT F PIN ASSIGNMENT (PFPAR)

S $YFFA20 NOT USED SYSTEM PROTECTION CONTROL

S $YFFA22 PERIODIC INTERRUPT CONTROL (PICR)

S $YFFA24 PERIODIC INTERRUPT TIMING (PITR)

S $YFFA26 NOT USED SOFTWARE SERVICE (SWSR)

S $YFFA28 NOT USED NOT USED

S $YFFA2A NOT USED NOT USED

S $YFFA2C NOT USED NOT USED

S $YFFA2E NOT USED NOT USED

S $YFFA30 TEST MODULE MASTER SHIFT A (TSTMSRA)

S $YFFA32 TEST MODULE MASTER SHIFT B (TSTMSRB)

S $YFFA34 TEST MODULE SHIFT COUNT (TSTSC)

S $YFFA36 TEST MODULE REPETITION COUNTER (TSTRC)

S $YFFA38 TEST MODULE CONTROL (CREG) S/U $YFFA3A TEST MODULE DISTRIBUTED REGISTER (DREG)

$YFFA3C NOT USED NOT USED $YFFA3E NOT USED NOT USED

S/U $YFFA40 NOT USED PORT C DATA (PORTC)

$YFFA42 NOT USED NOT USED S $YFFA44 CHIP-SELECT PIN ASSIGNMENT (CSPAR0) S $YFFA46 CHIP-SELECT PIN ASSIGNMENT (CSPAR1) S $YFFA48 CHIP-SELECT BASE BOOT (CSBARBT) S $YFFA4A CHIP-SELECT OPTION BOOT (CSORBT) S $YFFA4C CHIP-SELECT BASE 0 (CSBAR0) S $YFFA4E CHIP-SELECT OPTION 0 (CSOR0) S $YFFA50 CHIP-SELECT BASE 1 (CSBAR1) S $YFFA52 CHIP-SELECT OPTION 1 (CSOR1) S $YFFA54 CHIP-SELECT BASE 2 (CSBAR2) S $YFFA56 CHIP-SELECT OPTION 2 (CSOR2) S $YFFA58 CHIP-SELECT BASE 3 (CSBAR3) S $YFFA5A CHIP-SELECT OPTION 3 (CSOR3) S $YFFA5C CHIP-SELECT BASE 4 (CSBAR4)

Table 7 SIM Address Map

(SYPCR)

MC68331TS/D 15

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Access Address 15 8 7 0

S $YFFA5E CHIP-SELECT OPTION 4 (CSOR4) S $YFFA60 CHIP-SELECT BASE 5 (CSBAR5) S $YFFA62 CHIP-SELECT OPTION 5 (CSOR5) S $YFFA64 CHIP-SELECT BASE 6 (CSBAR6) S $YFFA66 CHIP-SELECT OPTION 6 (CSOR6) S $YFFA68 CHIP-SELECT BASE 7 (CSBAR7) S $YFFA6A CHIP-SELECT OPTION 7 (CSOR7) S $YFFA6C CHIP-SELECT BASE 8 (CSBAR8) S $YFFA6E CHIP-SELECT OPTION 8 (CSOR8) S $YFFA70 CHIP-SELECT BASE 9 (CSBAR9) S $YFFA72 CHIP-SELECT OPTION 9 (CSOR9) S $YFFA74 CHIP-SELECT BASE 10 (CSBAR10) S $YFFA76 CHIP-SELECT OPTION 10 (CSOR10)

$YFFA78 NOT USED NOT USED

$YFFA7A NOT USED NOT USED

$YFFA7C NOT USED NOT USED

$YFFA7E NOT USED NOT USED

Y = M111, where M is the logic state of the module mapping (MM) bit in the SIMCR.

Table 7 SIM Address Map (Continued)

3.2 System Configuration and Protection

This functional block provides configuration control for the entire MCU. It also performs interrupt arbitration, bus monitoring, and system test functions. MCU system protection includes a bus monitor, a HALT monitor, a spurious interrupt monitor, and a software watchdog timer. These functions have been made integral to the microcontroller to reduce the number of external components in a complete control system.

Freescale Semiconductor, I

16 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

RESET STATUS

. nc

Freescale Semiconductor, I

HALT MONITOR

BUS MONITOR

SPURIOUS INTERRUPT MONITOR

CLOCK

PRESCALER

Figure 6 System Configuration and Protection Block

3.2.1 System Configuration

The SIM controls MCU configuration during normal operation and during internal testing.

SIMCR —SIM Configuration Register

15 EXOFF FRZSW FRZBM 0 SLVEN 0 SHEN SUPV MM 0 0 IARB RESET:

0 0 0 0 DATA11 0 0 0 1 1 0 0 1 1 1 1

EXOFF —External Clock Off

14 13 12 11 10 9 8 7 6 5 4 3 0

The SIM configuration register controls system configuration. It can be read or written at any time, except for the module mapping (MM) bit, which can be written only once.

0 = The CLKOUT pin is driven from an internal clock source. 1 = The CLKOUT pin is placed in a high-impedance state.

SOFTWARE WATCHDOG TIMER

PERIODIC INTERRUPT TIMER

RESET REQUEST

BERR

RESET REQUEST

IRQ[7:1]

300 SYS PROTECT BLOCK

$YFFA00

FRZSW —Freeze Software Enable

0 = When FREEZE is asserted, the software watchdog and periodic interrupt timer counters con-

tinue to run.

1 = When FREEZE is asserted, the software watchdog and periodic interrupt timer counters are dis-

abled, preventing interrupts during software debug.

FRZBM —Freeze Bus Monitor Enable

0 = When FREEZE is asserted, the bus monitor continues to operate. 1 = When FREEZE is asserted, the bus monitor is disabled.

MC68331TS/D 17

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

SLVEN —Factory Test Mode Enabled

This bit is a read-only status bit that reflects the state of DATA11 during reset.

0 = IMB is not available to an external master. 1 = An external bus master has direct access to the IMB.

SHEN[1:0] —Show Cycle Enable

This field determines what the EBI does with the external bus during internal transfer operations. A show cycle allows internal transfers to be externally monitored. The table below shows whether show cycle data is driven externally, and whether external bus arbitration can occur. To prevent bus conflict, external peripherals must not be enabled during show cycles.

SHEN Action

00 Show cycles disabled, external arbitration enabled 01 Show cycles enabled, external arbitration disabled 10 Show cycles enabled, external arbitration enabled

11 Show cycles enabled, external arbitration enabled,

internal activity is halted by a bus grant

Freescale Semiconductor, I

SUPV —Supervisor/Unrestricted Data Space

The SUPV bit places the SIM global registers in either supervisor or user data space.

0 = Registers with access controlled by the SUPV bit are accessible from either the user or super-

visor privilege level.

1 = Registers with access controlled by the SUPV bit are restricted to supervisor access only.

MM —Module Mapping

0 = Internal modules are addressed from $7FF000 –$7FFFFF. 1 = Internal modules are addressed from $FFF000 –$FFFFFF.

IARB[3:0] —Interrupt Arbitration Field

Each module that can generate interrupt requests has an interrupt arbitration (IARB) field. Arbitration between interrupt requests of the same priority is performed by serial contention between IARB field bit values. Contention must take place whenever an interrupt request is acknowledged, even when there is only a single pending request. An IARB field must have a non-zero value for contention to take place. If an interrupt request from a module with an IARB field value of %0000 is recognized, the CPU processes a spurious interrupt exception. Because the SIM routes external interrupt requests to the CPU, the SIM IARB field value is used for arbitration between internal and external interrupts of the same priority. The reset value of IARB for the SIM is %1111, and the reset IARB value for all other modules is %0000, which prevents SIM interrupts from being discarded during initialization.

3.2.2 System Protection Control Register

The system protection control register controls system monitor functions, software watchdog clock prescaling, and bus monitor timing. This register can be written only once following power-on or reset, but can be read at any time.

SYPCR —System Protection Control Register

NOT USED SWE SWP SWT HME BME BMT

RESET:

SWE —Software Watchdog Enable

0 = Software watchdog disabled 1 = Software watchdog enabled

8 7 6 5 4 3 2 1 0

1 MODCLK 0 0 0 0 0 0

$YFFA21

18 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

SWP —Software Watchdog Prescale

This bit controls the value of the software watchdog prescaler.

0 = Software watchdog clock not prescaled 1 = Software watchdog clock prescaled by 512

SWT[1:0] —Software Watchdog Timing

This field selects the divide ratio used to establish software watchdog time-out period. The following table gives the ratio for each combination of SWP and SWT bits.

SWP SWT Ratio

000 001 010 011 100 101 110 111

HME —Halt Monitor Enable

0 = Disable halt monitor function 1 = Enable halt monitor function

BME —Bus Monitor External Enable

0 = Disable bus monitor function for an internal to external bus cycle. 1 = Enable bus monitor function for an internal to external bus cycle.

BMT[1:0] —Bus Monitor Timing

This field selects a bus monitor time-out period as shown in the following table.

BMT Bus Monitor Time-out Period

00 64 System Clocks 01 32 System Clocks 10 16 System Clocks 11 8 System Clocks

3.2.3 Bus Monitor

The internal bus monitor checks for excessively long DSACK and for excessively long DSACK or AVEC response times during interrupt acknowledge cycles. The

Freescale Semiconductor, I

monitor asserts BERR if response time is excessive. DSACK and AVEC response times are measured in clock cycles. The maximum allowable response

time can be selected by setting the BMT field.

response times during normal bus cycles

The monitor does not check DSACK response on the external bus unless the CPU initiates the bus cycle. The BME bit in the SYPCR enables the internal bus monitor for internal to external bus cycles. If a system contains external bus masters, an external bus monitor must be implemented and the internal to external bus monitor option must be disabled.

3.2.4 Halt Monitor

The halt monitor responds to an assertion of HALT on the internal bus. A flag in the reset status register (RSR) indicates that the last reset was caused by the halt monitor. The halt monitor reset can be inhibited by the HME bit in the SYPCR.

MC68331TS/D 19

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

3.2.5 Spurious Interrupt Monitor

The spurious interrupt monitor issues BERR knowledge cycle.

3.2.6 Software Watchdog

The software watchdog is controlled by SWE in the SYPCR. Once enabled, the watchdog requires that a service sequence be written to SWSR on a periodic basis. If servicing does not take place, the watchdog times out and issues a reset. This register can be written at any time, but returns zeros when read.

if no interrupt arbitration occurs during an interrupt-ac-

. nc

Freescale Semiconductor, I

SWSR —Software Service Register

NOT USED 0 0 0 0 0 0 0 0

RESET:

1. Write $55 to SWSR.

2. Write $AA to SWSR.

Both writes must occur before time-out in the order listed, but any number of instructions can be executed between the two writes.

The watchdog clock rate is affected by SWP and SWT in SYPCR. When SWT[1:0] are modified, a watchdog service sequence must be performed before the new time-out period takes effect.

The reset value of SWP is affected by the state of the MODCLK pin on the rising edge of reset, as shown in the following table.

MODCLK SWP

3.2.7 Periodic Interrupt Timer

The periodic interrupt timer (PIT) generates interrupts of specified priorities at specified intervals. Timing for the PIT is provided by a programmable prescaler driven by the system clock.

PICR — Periodic Interrupt Control Register

0 0 0 0 0 PIRQL PIV

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1

14 13 12 11 10 8 7 0

This register contains information concerning periodic interrupt priority and vectoring. Bits [10:0] can be read or written at any time. Bits [15:11] are unimplemented and always return zero.

8 7 6 5 4 3 2 1 0

0 0 0 0 0 0 0 0

01 10

$YFFA27

$YFFA22

PIRQL[2:0] —Periodic Interrupt Request Level

The following table shows what interrupt request level is asserted when a periodic interrupt is generated. If a PIT interrupt and an external IRQ terrupt is serviced first. The periodic timer continues to run when the interrupt is disabled.

signal of the same priority occur simultaneously, the PIT in-

20 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

PIV[7:0] —Periodic Interrupt Vector

The bits of this field contain the vector generated in response to an interrupt from the periodic timer. When the SIM responds, the periodic interrupt vector is placed on the bus.

PIRQL Interrupt Request Level

000 Periodic Interrupt Disabled 001 Interrupt Request Level 1 010 Interrupt Request Level 2 011 Interrupt Request Level 3 100 Interrupt Request Level 4 101 Interrupt Request Level 5 110 Interrupt Request Level 6 111 Interrupt Request Level 7

. nc

Freescale Semiconductor, I

PITR —Periodic Interrupt Timer Register $YFFA24

15 14 13 12 11 10 9 8 7 0

0 0 0 0 0 0 0 PTP PITM

RESET:

0 0 0 0 0 0 0 MODCLK 0 0 0 0 0 0 0 0

The PITR contains the count value for the periodic timer. A zero value turns off the periodic timer. This register can be read or written at any time.

PTP —Periodic Timer Prescaler Control

0 = Periodic timer clock not prescaled 1 = Periodic timer clock prescaled by a value of 512

The reset state of PTP is the complement of the state of the MODCLK signal during reset.

PITM[7:0] —Periodic Interrupt Timing Modulus Field

This is an 8-bit timing modulus. The period of the timer can be calculated as follows:

PIT Period = [(PITM)(Prescaler)(4)]/EXTAL

where

PIT Period = Periodic interrupt timer period PITM = Periodic interrupt timer register modulus (PITR[7:0]) EXTAL Frequency = Crystal frequency Prescale = 512 or 1 depending on the state of the PTP bit in the PITR

3.3 System Clock

The system clock in the SIM provides timing signals for the IMB modules and for an external peripheral bus. Because MCU operation is fully static, register and memory contents are not affected when the clock rate changes. System hardware and software support changes in the clock rate during operation.

The system clock signal can be generated in three ways. An internal phase-locked loop can synthesize the clock from an internal or external frequency source, or the clock signal can be input from an external source.

Following is a block diagram of the clock submodule.

MC68331TS/D 21

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

. nc

32.768 KHz

22 pF 22 pF

SSI

EXTAL

1. MUST BE LOW-LEAKAGE CAPACITOR (INSULATION RESISTANCE 30,000 MΩ OR GREATER).

2. RESISTANCE AND CAPACITANCE BASED ON A TEST CIRCUIT CONSTRUCTED WITH A DAISHINKU DMX-38 32.768-kHz CRYSTAL.

SPECIFIC COMPONENTS MUST BE BASED ON CRYSTAL TYPE. CONTACT CRYSTAL VENDOR FOR EXACT CIRCUIT.

330K

R3 10M

CRYSTAL

OSCILLATOR

SSI

XTAL XFC PIN

PHASE

COMPARATOR

FEEDBACK DIVIDER

SYSTEM CLOCK CONTROL

LOW-PASS

FILTER

DDSYN

XFC

0.1µF

DDSYN

0.1µF

0.01µF

VCO

SSI

SYSTEM

CLOCK

CLKOUT

SYS CLOCK

BLOCK 32KHZ

Figure 7 System Clock Block Diagram

3.3.1 Clock Sources

The state of the clock mode (MODCLK) pin during reset determines the clock source. When MODCLK is held high during reset, the clock synthesizer generates a clock signal from either a crystal oscillator or an external reference input. Clock synthesizer control register SYNCR determines operating frequency and various modes of operation. When MODCLK is held low during reset, the clock synthesizer is disabled, and an external system clock signal must be applied. When the synthesizer is disabled, SYNCR control bits have no effect.

A reference crystal must be connected between the EXTAL and XTAL pins to use the internal oscillator. Use of a 32.768-kHz crystal is recommended. These crystals are inexpensive and readily available. If an external reference signal or an external system clock signal is applied through the EXTAL pin, the XTAL pin must be left floating. External reference signal frequency must be less than or equal to max-

Freescale Semiconductor, I

imum specified reference frequency. External system clock signal frequency must be less than or equal to maximum specified system clock frequency.

When an external system clock signal is applied (i.e., the PLL is not used), duty cycle of the input is critical, especially at near maximum operating frequencies. The relationship between clock signal duty cycle and clock signal period is expressed:

Minimum external clock period =

minimum external clock high/low time

50% — percentage variation of external clock input duty cycle

22 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

3.3.2 Clock Synthesizer Operation

A voltage controlled oscillator (VCO) generates the system clock signal. A portion of the clock signal is fed back to a divider/counter. The divider controls the frequency of one input to a phase comparator. The other phase comparator input is a reference signal, either from the internal oscillator or from an external source. The comparator generates a control signal proportional to the difference in phase between its two inputs. The signal is low-pass filtered and used to correct VCO output frequency.

The synthesizer locks when VCO frequency is identical to reference frequency. Lock time is affected by the filter time constant and by the amount of difference between the two comparator inputs. Whenever comparator input changes, the synthesizer must re-lock. Lock status is shown by the SLOCK bit in SYNCR.

The MCU does not come out of reset state until the synthesizer locks. Crystal type, characteristic frequency, and layout of external oscillator circuitry affect lock time.

The low-pass filter requires an external low-leakage capacitor, typically 0.1 µF, connected between the XFC and V

V and can be used to run the clock when the MCU is powered down. Use a quiet power supply as the

V ternal bypass capacitors as close as possible to the V

is used to power the clock circuits. A separate power source increases MCU noise immunity

DDSYN

source, since PLL stability depends on the VCO, which uses this supply. Place adequate ex-

DDSYN

pins.

pin to ensure stable operating frequency.

DDSYN

When the clock synthesizer is used, control register SYNCR determines operating frequency and various modes of operation. SYNCR can be read only when the processor is operating at the supervisor privilege level.

The SYNCR X bit controls a divide by two prescaler that is not in the synthesizer feedback loop. Setting X doubles clock speed without changing VCO speed. There is no VCO relock delay. The SYNCR W bit controls a 3-bit prescaler in the feedback divider. Setting W increases VCO speed by a factor of four. The SYNCR Y field determines the count modulus for a modulo 64 down counter, causing it to divide by a value of Y + 1. When either W or Y value changes, there is a VCO relock delay.

Clock frequency is determined by SYNCR bit settings as follows:

SYSTEM

In order for the device to perform correctly, the clock frequency selected by the W, X, and Y bits must be within the limits specified for the MCU. The VCO frequency is twice the system clock frequency if X = 1 or four times the system clock frequency if X = 0.

The reset state of SYNCR ($3F00) produces a modulus-64 count.

= F

REFERENCE

[4(Y + 1)(2

2W +X

)]

Freescale Semiconductor, I

3.3.3 Clock Control

The clock control circuits determine system clock frequency and clock operation under special circumstances, such as following loss of synthesizer reference or during low-power operation. Clock source is determined by the logic state of the MODCLK pin during reset.

SYNCR —Clock Synthesizer Control Register $YFFA04

15 14 13 8 7 6 5 4 3 2 1 0

W X Y EDIV 0 0 SLIMP SLOCK RSTEN STSIM STEXT

RESET:

0 0 1 1 1 1 1 1 0 0 0 U U 0 0 0

MC68331TS/D 23

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

When the on-chip clock synthesizer is used, system clock frequency is controlled by the bits in the upper byte of SYNCR. Bits in the lower byte show status of or control operation of internal and external clocks. The SYNCR can be read or written only when the CPU is operating at the supervisor privilege level.

W —Frequency Control (VCO)

This bit controls a prescaler tap in the synthesizer feedback loop. Setting the bit increases the VCO speed by a factor of four. VCO relock delay is required.

X —Frequency Control Bit (Prescale)

This bit controls a divide by two prescaler that is not in the synthesizer feedback loop. Setting the bit doubles clock speed without changing the VCO speed. There is no VCO relock delay.

Y[5:0] —Frequency Control (Counter)

The Y field controls the modulus down counter in the synthesizer feedback loop, causing it to divide by a value of Y + 1. Values range from 0 to 63. VCO relock delay is required.

. nc

Freescale Semiconductor, I

EDIV —E Clock Divide Rate

0 = ECLK frequency is system clock divided by 8.

1 = ECLK frequency is system clock divided by 16. ECLK is an external M6800 bus clock available on pin ADDR23. Refer to 3.5 Chip Selects for more information.

SLIMP —Limp Mode Flag

0 = External crystal is VCO reference.

1 = Loss of crystal reference. When the on-chip synthesizer is used, loss of reference frequency causes SLIMP to be set. The VCO continues to run using the base control voltage. Maximum limp frequency is maximum specified system clock frequency. X-bit state affects limp frequency.

SLOCK —Synthesizer Lock Flag

0 = VCO is enabled, but has not locked.

1 = VCO has locked on the desired frequency (or system clock is external). The MCU maintains reset state until the synthesizer locks, but SLOCK does not indicate synthesizer lock status until after the user writes to SYNCR.

RSTEN —Reset Enable

0 = Loss of crystal causes the MCU to operate in limp mode.

1 = Loss of crystal causes system reset.

STSIM —Stop Mode SIM Clock

0 = When LPSTOP is executed, the SIM clock is driven from the crystal oscillator and the VCO is

turned off to conserve power.

1 = When LPSTOP is executed, the SIM clock is driven from the VCO.

STEXT —Stop Mode External Clock

0 = When LPSTOP is executed, the CLKOUT signal is held negated to conserve power.

1 = When LPSTOP is executed, the CLKOUT signal is driven from the SIM clock, as determined by

the state of the STSIM bit.

3.4 External Bus Interface

The external bus interface (EBI) transfers information between the internal MCU bus and external devices. The external bus has 24 address lines and 16 data lines.

The EBI provides dynamic sizing between 8-bit and 16-bit data accesses. It supports byte, word, and long-word transfers. Ports are accessed through the use of asynchronous cycles controlled by the data transfer (SIZ1 and SIZ0) and data size acknowledge pins (DSACK1 may be required for a transfer to or from an 8-bit port.

and DSACK0). Multiple bus cycles

24 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Port width is the maximum number of bits accepted or provided during a bus transfer. External devices must follow the handshake protocol described below. Control signals indicate the beginning of the cycle, the address space, the size of the transfer, and the type of cycle. The selected device controls the length of the cycle. Strobe signals, one for the address bus and another for the data bus, indicate the validity of an address and provide timing information for data. The EBI operates in an asynchronous mode for any port width.

To add flexibility and minimize the necessity for external logic, MCU chip-select logic can be synchronized with EBI transfers. Chip-select logic can also provide internally-generated bus control signals for these accesses. Refer to 3.5 Chip Selects for more information.

3.4.1 Bus Control Signals

The CPU initiates a bus cycle by driving the address, size, function code, and read/write outputs. At the beginning of the cycle, size signals SIZ0 and SIZ1 are driven along with the function code signals. The size signals indicate the number of bytes remaining to be transferred during an operand cycle. They are valid while the address strobe (AS read/write (R/W) signal determines the direction of the transfer during a bus cycle. This signal changes state, when required, at the beginning of a bus cycle, and is valid while AS is asserted. R/W only changes state when a write cycle is preceded by a read cycle or vice versa. The signal can remain low for two consecutive write cycles.

) is asserted. The following table shows SIZ0 and SIZ1 encoding. The

Table 8 Size Signal Encoding

SIZ1 SIZ0 Transfer Size

0 1 Byte 1 0 Word 1 1 Three Byte 0 0 Long Word

3.4.2 Function Codes

The CPU32 automatically generates function code signals FC[2:0]. The function codes can be considered address extensions that automatically select one of eight address spaces to which an address applies. These spaces are designated as either user or supervisor, and program or data spaces. Address space 7 is designated CPU space. CPU space is used for control information not normally associated with read or write bus cycles. Function codes are valid while AS is asserted.

Table 9 CPU32 Address Space Encoding

FC2 FC1 FC0 Address Space

0 0 0 Reserved

Freescale Semiconductor, I

0 0 1 User Data Space 0 1 0 User Program Space 0 1 1 Reserved 1 0 0 Reserved 1 0 1 Supervisor Data Space 1 1 0 Supervisor Program Space 1 1 1 CPU Space

3.4.3 Address Bus

Address bus signals ADDR[23:0] define the address of the most significant byte to be transferred during a bus cycle. The MCU places the address on the bus at the beginning of a bus cycle. The address is valid while AS is asserted.

MC68331TS/D 25

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

3.4.4 Address Strobe

AS is a timing signal that indicates the validity of an address on the address bus and the validity of many control signals. It is asserted one-half clock after the beginning of a bus cycle.

3.4.5 Data Bus

Data bus signals DATA[15:0] make up a bidirectional, non-multiplexed parallel bus that transfers data to or from the MCU. A read or write operation can transfer 8 or 16 bits of data in one bus cycle. During a read cycle, the data is latched by the MCU on the last falling edge of the clock for that bus cycle. For a write cycle, all 16 bits of the data bus are driven, regardless of the port width or operand size. The MCU places the data on the data bus one-half clock cycle after AS is asserted in a write cycle.

3.4.6 Data Strobe

Data strobe (DS) is a timing signal. For a read cycle, the MCU asserts DS to signal an external device to place data on the bus. DS DS signals an external device that data on the bus is valid. The MCU asserts DS one full clock cycle after the assertion of AS during a write cycle.

3.4.7 Bus Cycle Termination Signals

During bus cycles, external devices assert the data transfer and size acknowledge signals (DSACK1 and DSACK0). During a read cycle, the signals tell the MCU to terminate the bus cycle and to latch data. During a write cycle, the signals indicate that an external device has successfully stored data and that the cycle can end. These signals also indicate to the MCU the size of the port for the bus cycle just completed. (Refer to 3.4.9 Dynamic Bus Sizing.)

is asserted at the same time as AS during a read cycle. For a write cycle,

The bus error (BERR) signal is also a bus cycle termination indicator and can be used in the absence of DSACK1 and DSACK0 to indicate a bus error condition. It can also be asserted in conjunction with these signals, provided it meets the appropriate timing requirements. The internal bus monitor can be used to generate the BERR signal for internal and internal-to-external transfers. When BERR and HALT are asserted simultaneously, the CPU takes a bus error exception.

Autovector signal (AVEC) can terminate external IRQ pin interrupt acknowledge cycles. AVEC indicates that the MCU will internally generate a vector number to locate an interrupt handler routine. If it is continuously asserted, autovectors will be generated for all external interrupt requests. AVEC is ignored during all other bus cycles.

3.4.8 Data Transfer Mechanism

The MCU architecture supports byte, word, and long-word operands, allowing access to 8- and 16-bit data ports through the use of asynchronous cycles controlled by the data transfer and size acknowledge inputs (DSACK1 and DSACK0).

Freescale Semiconductor, I

3.4.9 Dynamic Bus Sizing

The MCU dynamically interprets the port size of the addressed device during each bus cycle, allowing operand transfers to or from 8- and 16-bit ports. During an operand transfer cycle, the slave device signals its port size and indicates completion of the bus cycle to the MCU through the use of the DSACK0 and DSACK1 inputs, as shown in the following table.

Table 10 Effect of DSACK Signals

DSACK1 DSACK0 Result

1 1 Insert Wait States in Current Bus Cycle 1 0 Complete Cycle —Data Bus Port Size is 8 Bits 0 1 Complete Cycle —Data Bus Port Size is 16 Bits 0 0 Reserved

26 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

For example, if the MCU is executing an instruction that reads a long-word operand from a 16-bit port, the MCU latches the 16 bits of valid data and then runs another bus cycle to obtain the other 16 bits. The operation for an 8-bit port is similar, but requires four read cycles. The addressed device uses the DSACK0 and DSACK1 signals to indicate the port width. For instance, a 16-bit device always returns DSACK0 = 1 and DSACK1 = 0 for a 16-bit port, regardless of whether the bus cycle is a byte or word operation.

Dynamic bus sizing requires that the portion of the data bus used for a transfer to or from a particular port size be fixed. A 16-bit port must reside on data bus bits [15:0] and an 8-bit port must reside on data bus bits [15:8]. This minimizes the number of bus cycles needed to transfer data and ensures that the MCU transfers valid data.

The MCU always attempts to transfer the maximum amount of data on all bus cycles. For a word operation, it is assumed that the port is 16 bits wide when the bus cycle begins. Operand bytes are designated as shown in the following figure. OP0 is the most significant byte of a long-word operand, and OP3 is the least significant byte. The two bytes of a word-length operand are OP0 (most significant) and

OP1. The single byte of a byte-length operand is OP0.

Freescale Semiconductor, I

Operand Byte Order

31 24 23 16 15 8 7 0 Long Word OP0 OP1 OP2 OP3 Three Byte OP0 OP1 OP2

Word OP0 OP1

Byte OP0

Figure 8 Operand Byte Order

3.4.10 Operand Alignment

The data multiplexer establishes the necessary connections for different combinations of address and data sizes. The multiplexer takes the two bytes of the 16-bit bus and routes them to their required positions. Positioning of bytes is determined by the size and address outputs. SIZ1 and SIZ0 indicate the remaining number of bytes to be transferred during the current bus cycle. The number of bytes transferred is equal to or less than the size indicated by SIZ1 and SIZ0, depending on port width.

ADDR0 also affects the operation of the data multiplexer. During an operand transfer, ADDR[23:1] indicate the word base address of the portion of the operand to be accessed, and ADDR0 indicates the byte offset from the base.

3.4.11 Misaligned Operands

CPU32 processor architecture uses a basic operand size of 16 bits. An operand is misaligned when it overlaps a word boundary. This is determined by the value of ADDR0. When ADDR0 = 0 (an even address), the address is on a word and byte boundary. When ADDR0 = 1 (an odd address), the address is on a byte boundary only. A byte operand is aligned at any address; a word or long-word operand is misaligned at an odd address. MC68300 devices do not support misaligned operand transfers.

The largest amount of data that can be transferred by a single bus cycle is an aligned word. If the MCU transfers a long-word operand via a 16-bit port, the most significant operand word is transferred on the first bus cycle and the least significant operand word on a following bus cycle.

3.4.12 Operand Transfer Cases

The following table summarizes how operands are aligned for various types of transfers. OPn entries are portions of a requested operand that are read or written during a bus cycle and are defined by SIZ1, SIZ0, and ADDR0 for that bus cycle.

MC68331TS/D 27

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

Table 11 Operand Alignment

. nc

Freescale Semiconductor, I

Transfer Case SIZ1 SIZ0 ADDR0 DSACK1 DSACK0 DATA

[15:8]

Byte to 8-Bit Port (Even/Odd) 0 1 X 1 0 OP0 (OP0) Byte to 16-Bit Port (Even) 0 1 0 0 X OP0 (OP0) Byte to 16-Bit Port (Odd) 0 1 1 0 X (OP0) OP0 Word to 8-Bit Port (Aligned) 1 0 0 1 0 OP0 (OP1)

Word to 8-Bit Port (Misaligned) Word to 16-Bit Port (Aligned) 1 0 0 0 X OP0 OP1

Word to 16-Bit Port (Misaligned) 3 Byte to 8-Bit Port (Aligned) 3 Byte to 8-Bit Port (Misaligned) 3 Byte to 16-Bit Port (Aligned) 3 Byte to 16-Bit Port (Misaligned)

Long Word to 8-Bit Port (Aligned) 0 0 0 1 0 OP0 (OP1) Long Word to 8-Bit Port (Misaligned)

Long Word to 16-Bit Port (Aligned) 0 0 0 0 X OP0 OP1 Long Word to 16-Bit Port (Misaligned)

NOTES:

1. Operands in parentheses are ignored by the CPU32 during read cycles.

2. Three-byte transfer cases occur only as a result of a long word to byte transfer.

3. The CPU32 does not support misaligned word or long-word transfers.

3.5 Chip Selects

Typical microcontrollers require additional hardware to provide external chip-select signals. Twelve independently programmable chip selects provide fast two-cycle access to external memory or peripherals. Address block sizes of 2 Kbytes to 1 Mbyte can be selected.

Chip-select assertion can be synchronized with bus control signals to provide output enable, read/write strobes, or interrupt acknowledge signals. Logic can also generate DSACK signals internally. A single DSACK generator is shared by all circuits. Multiple chip selects assigned to the same address and control must have the same number of wait states.

Chip selects can also be synchronized with the ECLK signal available on ADDR23. When a memory access occurs, chip-select logic compares address space type, address, type of ac-

cess, transfer size, and interrupt priority (in the case of interrupt acknowledge) to parameters stored in chip-select registers. If all parameters match, the appropriate chip-select signal is asserted. Select signals are active low. Refer to the following block diagram of a single chip-select circuit.

2, 3

1 0 1 1 0 OP0 (OP0)

1 0 1 0 X (OP0) OP0 1 1 0 1 0 OP0 (OP1) 1 1 1 1 0 OP0 (OP0) 1 1 0 0 X OP0 OP1 1 1 1 0 X (OP0) OP0

1 0 1 1 0 OP0 (OP0)

1 0 1 0 X (OP0) OP0

DATA

[7:0]

28 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

. nc

Freescale Semiconductor, I

INTERNAL

SIGNALS

ADDRESS

BUS CONTROL

AVEC

DSACK

The following table lists allocation of chip-selects and discrete outputs on the pins of the MCU.

3.5.1 Chip-Select Registers

Pin assignment registers CSPAR0 and CSPAR1 determine functions of chip-select pins. These registers also determine port size (8- or 16-bit) for dynamic bus allocation.

BASE ADDRESS REGISTER

ADDRESS COMPARATOR

OPTION COMPARE

OPTION REGISTER

AVEC

GENERATOR

Figure 9 Chip-Select Circuit Block Diagram

Pin Chip Select Discrete Outputs

CSBOOT

BR BG

BGACK

FC0 CS3 FC1 CS4

FC2 CS5 ADDR19 CS6 ADDR20 CS7 ADDR21 CS8 ADDR22 CS9 ADDR23 CS10

DSACK

GENERATOR

CSBOOT —

CS0 — CS1 — CS2 —

ASSIGNMENT

TIMING

AND

CONTROL

PC0 PC1 PC2 PC3 PC4 PC5 PC6

ECLK

DATA

CHIP SEL BLOCK

A pin data register (PORTC) latches discrete output data. Blocks of addresses are assigned to each chip-select function. Block sizes of 2 Kbytes to 1 Mbyte can

be selected by writing values to the appropriate base address register (CSBAR). Address blocks for separate chip-select functions can overlap.

Chip-select option registers (CSORBT and CSOR[10:0]) determine timing of and conditions for assertion of chip-select signals. Eight parameters, including operating mode, access size, synchronization, and wait state insertion can be specified.

Initialization code often resides in a peripheral memory device controlled by the chip-select circuits. A set of special chip-select functions and registers (CSORBT, CSBARBT) is provided to support bootstrap operation.

MC68331TS/D 29

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

3.5.2 Pin Assignment Registers

The pin assignment registers (CSPAR0 and CSPAR1) contain pairs of bits that determine the function of chip-select pins. The pin assignment encodings used in these registers are shown below.

CSPAR0 —Chip Select Pin Assignment Register 0 $YFFA44

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

0 0 CSPA0[6] CSPA0[5] CSPA0[4] CSPA0[3] CSPA0[2] CSPA0[1] CSBOOT

RESET:

0 0 DATA2 1 DATA2 1 DATA2 1 DATA1 1 DATA1 1 DATA1 1 1 DATA0

CSPAR0 contains seven 2-bit fields that determine the functions of corresponding chip-select pins. CSPAR0[15:14] are not used. These bits always read zero; writes have no effect. CSPAR0 bit 1 always reads one; writes to CSPAR0 bit 1 have no effect.

Table 12 Pin Assignment Encodings

Bit Field Description

00 Discrete Output 01 Alternate Function 10 Chip Select (8-Bit Port) 11 Chip Select (16-Bit Port)

Table 13 CSPAR0 Pin Assignments

CSPAR0 Field Chip Select Signal Alternate Signal Discrete Output

CSPA0[6] CS5 CSPA0[5] CS4 CSPA0[4] CS3 CSPA0[3] CS2 CSPA0[2] CS1 CSPA0[1] CS0

CSBOOT

CSPAR1 —Chip Select Pin Assignment Register 1 $YFFA46

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

0 0 0 0 0 0 CSPA1[4] CSPA1[3] CSPA1[2] CSPA1[1] CSPA1[0]

RESET:

0 0 0 0 0 0 DATA7 1 DATA

Freescale Semiconductor, I

CSPAR1 contains five 2-bit fields that determine the functions of corresponding chip-select pins. CSPAR1[15:10] are not used. These bits always read zero; writes have no effect.

CSPAR0 Field Chip Select Signal Alternate Signal Discrete Output

CSPA1[4] CS10 CSPA1[3] CS9 CSPA1[2] CS8 CSPA1[1] CS7 CSPA1[0] CS6

CSBOOT ——

[7:6]

Table 14 CSPAR1 Pin Assignments

FC2 PC2 FC1 PC1 FC0 PC0

BGACK —

BG — BR —

1 DATA

[7:5]

ADDR23 ECLK ADDR22 PC6 ADDR21 PC5 ADDR20 PC4 ADDR19 PC3

1 DATA

[7:4]

1 DATA

[7:3]

30 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

At reset, either the alternate function (01) or chip-select function (11) can be encoded. DATA pins are driven to logic level one by a weak internal pull-up during reset. Encoding is for chip-select function unless a data line is held low during reset. Note that bus loading can overcome the weak pull-up and hold pins low during reset. The following table shows the hierarchical selection method that determines the reset functions of pins controlled by CSPAR1.

Data Bus Pins at Reset Chip-Select/Address Bus Pin Function

DATA7 DATA6 DATA5 DATA4 DATA3 CS10

11111CS10 11110 CS10 CS9 CS8 CS7 ADDR19 111 11 1 0XXXXADDR23 ADDR22 ADDR21 ADDR20 ADDR19

A pin programmed as a discrete output drives an external signal to the value specified in the port C pin

data register (PORTC), with the following exceptions:

0 X X X CS10 ADDR22 ADDR21 ADDR20 ADDR19

0 X X CS10 CS9 ADDR21 ADDR20 ADDR19

Table 15 Reset Pin Function of CS[10:6]

CS9/

ADDR23

0 X CS10 CS9 CS8 ADDR20 ADDR19

ADDR22

CS9 CS8 CS7 CS6

CS8/

ADDR21

CS7/

ADDR20

CS6/

ADDR19

A. No discrete output function is available on pins BR, BG, or BGACK. B. ADDR23 provides E-clock output rather than a discrete output signal.

When a pin is programmed for discrete output or alternate function, internal chip-select logic still functions and can be used to generate DSACK

Port size is determined when a pin is assigned as a chip select. When a pin is assigned to an 8-bit port, the chip select is asserted at all addresses within the block range. If a pin is assigned to a 16-bit port, the upper/lower byte field of the option register selects the byte with which the chip select is associated.

3.5.3 Base Address Registers

A base address is the starting address for the block enabled by a given chip select. Block size determines the extent of the block above the base address. Each chip select has an associated base register so that an efficient address map can be constructed for each application. If a chip-select base address register is programmed with the same address as a microcontroller module or memory array, an access to that address goes to the module or array and the chip-select signal is not asserted.

CSBARBT — Chip-Select Base Address Register Boot ROM $YFFA48

15 14 13 12 11 10 9 8 7 6 5 4 3 2 0

Freescale Semiconductor, I

ADDR23ADDR22ADDR21ADDR20ADDR19ADDR18ADDR17ADDR16ADDR15ADDR14ADDR13ADDR12ADDR

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1

or AVEC internally on an address match.

BLKSZ

CSBAR[10:0] —Chip-Select Base Address Registers $YFFA4C–$YFFA74

15 14 13 12 11 10 9 8 7 6 5 4 3 2 0

ADDR23ADDR22ADDR21ADDR20ADDR19ADDR18ADDR17ADDR16ADDR15ADDR14ADDR13ADDR12ADDR

RESET:

BLKSZ —Block Size Field

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

This field determines the size of the block that must be enabled by the chip select. The following table shows bit encoding for the base address registers block size field.

BLKSZ

MC68331TS/D 31

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Block Size Field Block Size Address Lines Compared

000 2 K ADDR[23:11] 001 8 K ADDR[23:13] 010 16 K ADDR[23:14] 011 64 K ADDR[23:16] 100 128 K ADDR[23:17] 101 256 K ADDR[23:18] 110 512 K ADDR[23:19] 111 1 M ADDR[23:20]

ADDR[23:11] —Base Address Field

This field sets the starting address of a particular address space. The address compare logic uses only the most significant bits to match an address within a block. The value of the base address must be a multiple of block size. Base address register diagrams show how base register bits correspond to address lines.

3.5.4 Option Registers

The option registers contain eight fields that determine timing of and conditions for assertion of chipselect signals. For a chip-select signal to be asserted, all bits in the base address register must match the corresponding internal upper address lines, and all conditions specified in the option register must be satisfied. These conditions also apply to providing DSACK or autovector support.

CSORBT —Chip-Select Option Register Boot ROM $YFFA4A

15 14 13 12 11 10 9 6 5 4 3 1 0

MODE BYTE R/W STRB DSACK SPACE IPL AVEC

RESET:

0 1 1 1 1 0 1 1 0 1 1 1 0 0 0 0

CSOR[10:0] —Chip-Select Option Registers $YFFA4E–$YFFA76

15 14 13 12 11 10 9 6 5 4 3 1 0

MODE BYTE R/W STRB DSACK SPACE IPL AVEC

RESET:

Freescale Semiconductor, I

MODE —Asynchronous/Synchronous Mode

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

CSORBT, the option register for CSBOOT tions from peripheral memory devices.

The following bit descriptions apply to both CSORBT and CSOR[10:0] option registers.

0 = Asynchronous mode selected (chip-select assertion determined by internal or external bus con-

trol signals)

1 = Synchronous mode selected (chip-select assertion synchronized with ECLK signal) In asynchronous mode, the chip select is asserted synchronized with AS or DS. The DSACK field is not used in synchronous mode because a bus cycle is only performed as a synchronous operation. When a match condition occurs on a chip select programmed for synchronous operation, the chip select signals the EBI that an ECLK cycle is pending.

, contains special reset values that support bootstrap opera-

BYTE —Upper/Lower Byte Option

This field is used only when the chip-select 16-bit port option is selected in the pin assignment register. The following table lists upper/lower byte options.

32 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

R/W —Read/Write

This field causes a chip select to be asserted only for a read, only for a write, or for both read and write. Refer to the following table for options available.

STRB —Address Strobe/Data Strobe

0 = Address strobe

1 = Data strobe This bit controls the timing for assertion of a chip select in asynchronous mode. Selecting address strobe causes chip select to be asserted synchronized with address strobe. Selecting data strobe causes chip select to be asserted synchronized with data strobe.

Byte Description

00 Disable 01 Lower Byte 10 Upper Byte 11 Both Bytes

R/W

Description

00 Reserved 01 Read Only 10 Write Only 11 Read/Write

DSACK

Freescale Semiconductor, I

—Data and Size Acknowledge This field specifies the source of DSACK in asynchronous mode. It also allows the user to adjust bus timing with internal DSACK generation by controlling the number of wait states that are inserted to optimize bus speed in a particular application. The following table shows the DSACK field encoding. The fast termination encoding (1110) is used for two-cycle access to external memory.

DSACK

Description

0000 No Wait States 0001 1 Wait State 0010 2 Wait States 0011 3 Wait States 0100 4 Wait States 0101 5 Wait States 0110 6 Wait States 0111 7 Wait States 1000 8 Wait States 1001 9 Wait States 1010 10 Wait States 1011 11 Wait States 1100 12 Wait States 1101 13 Wait States 1110 Fast Termination 1111 External DSACK

MC68331TS/D 33

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

SPACE —Address Space

Use this option field to select an address space for the chip-select logic. The CPU32 normally operates in supervisor or user space, but interrupt acknowledge cycles must take place in CPU space.

Space Field Address Space

IPL —Interrupt Priority Level

If the space field is set for CPU space (00), chip-select logic can be used for interrupt acknowledge. During an interrupt acknowledge cycle, the priority level on address lines ADDR[3:1] is compared to the value in the IPL field. If the values are the same, a chip select is asserted, provided that other option register conditions are met. The following table shows IPL field encoding.

00 CPU Space 01 User Space 10 Supervisor Space 11 Supervisor/User Space

. nc

IPL Description

000 Any Level 001 IPL1 010 IPL2 011 IPL3 100 IPL4 101 IPL5 110 IPL6 111 IPL7

This field only affects the response of chip selects and does not affect interrupt recognition by the CPU. Any level means that chip select is asserted regardless of the level of the interrupt acknowledge cycle.

—Autovector Enable

AVEC

0 = External interrupt vector enabled

1 = Autovector enabled This field selects one of two methods of acquiring the interrupt vector during the interrupt acknowledge cycle. It is not usually used in conjunction with a chip-select pin.

If the chip select is configured to trigger on an interrupt acknowledge cycle (SPACE = 00) and the AVEC field is set to one, the chip select automatically generates an AVEC in response to the interrupt cycle. Otherwise, the vector must be supplied by the requesting device.

The AVEC bit must not be used in synchronous mode, as autovector response timing can vary because of ECLK synchronization.

Freescale Semiconductor, I

3.5.5 Port C Data Register

Bit values in port C determine the state of chip-select pins used for discrete output. When a pin is assigned as a discrete output, the value in this register appears at the output. This is a read/write register. Bit 7 is not used. Writing to this bit has no effect, and it always returns zero when read.

PORTC — Port C Data Register $YFFA41

15 8 7 6 5 4 3 2 1 0

NOT USED 0 PC6 PC5 PC4 PC3 PC2 PC1 PC0

RESET:

0 1 1 1 1 1 1 1

34 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

3.6 General-Purpose Input/Output

SIM pins can be configured as two general-purpose I/O ports, E and F. The following paragraphs describe registers that control the ports.

PORTE0, PORTE1 —Port E Data Register $YFFA11, $YFFA13

15 8 7 6 5 4 3 2 1 0

NOT USED PE7 PE6 PE5 PE4 PE3 PE2 PE1 PE0

RESET:

A write to the port E data register is stored in the internal data latch and, if any port E pin is configured as an output, the value stored for that bit is driven on the pin. A read of the port E data register returns the value at the pin only if the pin is configured as a discrete input. Otherwise, the value read is the value stored in the register.

The port E data register is a single register that can be accessed in two locations. When accessed at

$YFFA11, the register is referred to as PORTE0; when accessed at $YFFA13, the register is referred to as PORTE1. The register can be read or written at any time. It is unaffected by reset.

U U U U U U U U

Freescale Semiconductor, I

DDRE — Port E Data Direction Register $YFFA15

15 8 7 6 5 4 3 2 1 0

NOT USED DDE7 DDE6 DDE5 DDE4 DDE3 DDE2 DDE1 DDE0

RESET:

0 0 0 0 0 0 0 0

The bits in this register control the direction of the pin drivers when the pins are configured as I/O. Any bit in this register set to one configures the corresponding pin as an output. Any bit in this register cleared to zero configures the corresponding pin as an input. This register can be read or written at any time.

PEPAR — Port E Pin Assignment Register $YFFA17

15 8 7 6 5 4 3 2 1 0

NOT USED PEPA7 PEPA6 PEPA5 PEPA4 PEPA3 PEPA2 PEPA1 PEPA0

RESET:

DATA8 DATA8 DATA8 DATA8 DATA8 DATA8 DATA8 DATA8

The bits in this register control the function of each port E pin. Any bit set to one configures the corresponding pin as a bus control signal, with the function shown in the following table. Any bit cleared to zero defines the corresponding pin to be an I/O pin, controlled by PORTE and DDRE.

Data bus bit 8 controls the state of this register following reset. If DATA8 is set to one during reset, the register is set to $FF, which defines all port E pins as bus control signals. If DATA8 is cleared to zero during reset, this register is set to $00, configuring all port E pins as I/O pins.

Any bit cleared to zero defines the corresponding pin to be an I/O pin. Any bit set to one defines the corresponding pin to be a bus control signal.

Table 16 Port E Pin Assignments

PEPAR Bit Port E Signal Bus Control Signal

PEPA7 PE7 SIZ1 PEPA6 PE6 SIZ0 PEPA5 PE5 AS PEPA4 PE4 DS PEPA3 PE3 RMC PEPA2 PE2 AVEC PEPA1 PE1 DSACK1 PEPA0 PE0 DSACK0

MC68331TS/D 35

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

PORTF0, PORTF1 — Port F Data Register $YFFA19, $YFFA1B

15 8 7 6 5 4 3 2 1 0

NOT USED PF7 PF6 PF5 PF4 PF3 PF2 PF1 PF0

RESET:

The write to the port F data register is stored in the internal data latch, and if any port F pin is configured as an output, the value stored for that bit is driven onto the pin. A read of the port F data register returns the value at the pin only if the pin is configured as a discrete input. Otherwise, the value read is the value stored in the register.

The port F data register is a single register that can be accessed in two locations. When accessed at $YFFA19, the register is referred to as PORTF0; when accessed at $YFFA1B, the register is referred to as PORTF1. The register can be read or written at any time. It is unaffected by reset.

U U U U U U U U

. nc

Freescale Semiconductor, I

DDRF — Port F Data Direction Register $YFFA1D

15 8 7 6 5 4 3 2 1 0

NOT USED DDF7 DDF6 DDF5 DDF4 DDF3 DDF2 DDF1 DDF0

RESET:

0 0 0 0 0 0 0 0

The bits in this register control the direction of the pin drivers when the pins are configured for I/O. Any bit in this register set to one configures the corresponding pin as an output. Any bit in this register cleared to zero configures the corresponding pin as an input.

PFPAR — Port F Pin Assignment Register $YFFA1F

15 8 7 6 5 4 3 2 1 0

NOT USED PFPA7 PFPA6 PFPA5 PFPA4 PFPA3 PFPA2 PFPA1 PFPA0

RESET:

DATA9 DATA9 DATA9 DATA9 DATA9 DATA9 DATA9 DATA9

The bits in this register control the function of each port F pin. Any bit cleared to zero defines the corresponding pin to be an I/O pin. Any bit set to one defines the corresponding pin to be an interrupt request signal or MODCLK. The MODCLK signal has no function after reset.

Table 17 Port F Pin Assignments

PFPAR Field Port F Signal Alternate Signal

PFPA7 PF7 IRQ7 PFPA6 PF6 IRQ6 PFPA5 PF5 IRQ5 PFPA4 PF4 IRQ4 PFPA3 PF3 IRQ3 PFPA2 PF2 IRQ2 PFPA1 PF1 IRQ1 PFPA0 PF0 MODCLK

Data bus pin 9 controls the state of this register following reset. If DATA9 is set to one during reset, the register is set to $FF, which defines all port F pins as interrupt request inputs. If DATA9 is cleared to zero during reset, this register is set to $00, defining all port F pins as I/O pins.

36 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

3.7 Resets

Reset procedures handle system initialization and recovery from catastrophic failure. The MCU performs resets with a combination of hardware and software. The system integration module determines whether a reset is valid, asserts control signals, performs basic system configuration based on hardware mode-select inputs, then passes control to the CPU.

Reset occurs when an active low logic level on the RESET pin is clocked into the SIM. Resets are gated by the CLKOUT signal. Asynchronous resets are assumed to be catastrophic. An asynchronous reset can occur on any clock edge. Synchronous resets are timed to occur at the end of bus cycles. If there is no clock when RESET is asserted, reset does not occur until the clock starts. Resets are clocked in order to allow completion of write cycles in progress at the time RESET is asserted.

Reset is the highest-priority CPU32 exception. Any processing in progress is aborted by the reset exception, and cannot be restarted. Only essential tasks are performed during reset exception processing. Other initialization tasks must be accomplished by the exception handler routine.

. nc

Freescale Semiconductor, I

3.7.1 SIM Reset Mode Selection

The logic states of certain data bus pins during reset determine SIM operating configuration. In addition, the state of the MODCLK pin determines system clock source and the state of the BKPT what happens during subsequent breakpoint assertions. The following table is a summary of reset mode selection options.

Table 18 Reset Mode Selection

Mode Select Pin Default Function

(Pin Left High)

DATA0 CSBOOT DATA1 CS0

DATA2 CS3

DATA3 DATA4 DATA5 DATA6 DATA7

DATA8 DSACK0

AVEC

DATA9 IRQ[7:1]

DATA11 Test Mode Disabled Test Mode Enabled

MODCLK VCO = System Clock EXTAL = System Clock

BKPT

Background Mode Disabled Background Mode Enabled

16-Bit CSBOOT 8-Bit

CS1 CS2

CS4 CS5

CS6 CS[7:6] CS[8:6] CS[9:6]

CS[10:6]

, DSACK1,

, DS, AS,

SIZ[1:0]

MODCLK

Alternate Function

(Pin Pulled Low)

BR BG

BGACK

FC0 FC1 FC2

ADDR19 ADDR[20:19] ADDR[21:19] ADDR[22:19] ADDR[23:19]

PORTE

PORTF

pin determines

3.7.2 Functions of Pins for Other Modules During Reset

Generally, pins associated with modules other than the SIM default to port functions, and input/output ports are set to input state. This is accomplished by disabling pin functions in the appropriate control registers, and by clearing the appropriate port data direction registers. Refer to individual module sections in this manual for more information. The following table is a summary of module pin function out of reset.

MC68331TS/D 37

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Module Pin Mnemonic Function

CPU32 DSI/IFETCH

GPT PGP7/IC4/OC5 Discrete Input

QSM PQS7/TXD Discrete Input

Table 19 Module Pin Functions

DSI/IFETCH

DSO/IPIPE DSO/IPIPE

BKPT/DSCLK BKPT/DSCLK

PGP[6:3]/OC[4:1] Discrete Input

PGP[2:0]/IC[3:1] Discrete Input

PAI Discrete Input

PCLK Discrete Input

PWMA, PWMB Discrete Output

PQS[6:4]/PCS[3:1] Discrete Input

PQS3/PCS0/SS

PQS2/SCK Discrete Input PQS1/MOSI Discrete Input PQS0/MISO Discrete Input

RXD RXD

Discrete Input

3.7.3 Reset Timing

The RESET input must be asserted for a specified minimum period in order for reset to occur. External RESET assertion can be delayed internally for a period equal to the longest bus cycle time (or the bus monitor time-out period) in order to protect write cycles from being aborted by reset. While RESET is asserted, SIM pins are either in a disabled high-impedance state or are driven to their inactive states.

When an external device asserts RESET for the proper period, reset control logic clocks the signal into an internal latch. The control logic drives the RESET pin low for an additional 512 CLKOUT cycles after it detects that the RESET signal is no longer being externally driven, to guarantee this length of reset to the entire system.

If an internal source asserts a reset signal, the reset control logic asserts RESET cycles. If the reset signal is still asserted at the end of 512 cycles, the control logic continues to assert RESET until the internal reset signal is negated.

After 512 cycles have elapsed, the reset input pin goes to an inactive, high-impedance state for 10 cycles. At the end of this 10-cycle period, the reset input is tested. When the input is at logic level one, reset exception processing begins. If, however, the reset input is at logic level zero, the reset control logic drives the pin low for another 512 cycles. At the end of this period, the pin again goes to highimpedance state for 10 cycles, then it is tested again. The process repeats until RESET is released.

Freescale Semiconductor, I

3.7.4 Power-On Reset

When the SIM clock synthesizer is used to generate the system clock, power-on reset involves special circumstances related to application of system and clock synthesizer power. Regardless of clock source, voltage must be applied to clock synthesizer power input pin V

operate. The following discussion assumes that V mizes crystal start-up time. When V crystal parameters and by oscillator circuit design. V

is applied at power-on, start-up time is affected by specific

DDSYN

is applied before and during reset. This mini-

DDSYN

ramp-up time also affects pin state during reset.

DDSYN

for a minimum of 512

in order for the MCU to

During power-on reset, an internal circuit in the SIM drives the internal (IMB) and external reset lines. The circuit releases the internal reset line as V

pins are initialized. When V operation. Clock frequency ramps up to the specified limp mode frequency. The external RESET

remains asserted until the clock synthesizer PLL locks and 512 CLKOUT cycles elapse.

reaches the specified minimum value, the clock synthesizer VCO begins

ramps up to the minimum specified value, and SIM

line

38 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

The SIM clock synthesizer provides clock signals to the other MCU modules. After the clock is running and the internal reset signal is asserted for four clock cycles, these modules reset. V

VCO frequency ramp time determine how long these four cycles take. Worst case is approximately 15 milliseconds. During this period, module port pins may be in an indeterminate state. While input-only pins can be put in a known state by means of external pull-up resistors, external logic on input/output or output-only pins must condition the lines during this time. Active drivers require high-impedance buffers or isolation resistors to prevent conflict.

3.7.5 Use of Three State Control Pin

Asserting the three-state control (TSC) input causes the MCU to put all output drivers in an inactive, high-impedance state. The signal must remain asserted for 10 clock cycles in order for drivers to change state. There are certain constraints on use of TSC during power-on reset:

When the internal clock synthesizer is used (MODCLK held high during reset), synthesizer rampup time affects how long the 10 cycles take. Worst case is approximately 20 milliseconds from TSC assertion.

When an external clock signal is applied (MODCLK held low during reset), pins go to high-impedance state as soon after TSC assertion as 10 clock pulses have been applied to the EXTAL pin.

When TSC assertion takes effect, internal signals are forced to values that can cause inadvertent mode selection. Once the output drivers change state, the MCU must be powered down and restarted before normal operation can resume.

ramp time and

3.8 Interrupts

Interrupt recognition and servicing involve complex interaction between the central processing unit, the system integration module, and a device or module requesting interrupt service.

The CPU32 provides for eight levels of interrupt priority (0–7), seven automatic interrupt vectors and 200 assignable interrupt vector. All interrupts with priorities less than 7 can be masked by the interrupt priority (IP) field in the status register. The CPU32 handles interrupts as a type of asynchronous exception.

Interrupt recognition is based on the states of interrupt request signals IRQ[7:1] Each of the signals corresponds to an interrupt priority. IRQ1 has the lowest priority, and IRQ7 has the highest priority.

The IP field consists of three bits. Binary values %000 to %111 provide eight priority masks. Masks prevent an interrupt request of a priority less than or equal to the mask value (except for IRQ7) from being recognized and processed. When IP contains %000, no interrupt is masked. During exception processing, the IP field is set to the priority of the interrupt being serviced.

and the IP mask value.

Freescale Semiconductor, I

Interrupt request signals can be asserted by external devices or by microcontroller modules. Request lines are connected internally by means of a wired NOR — simultaneous requests of differing priority can be made. Internal assertion of an interrupt request signal does not affect the logic state of the corresponding MCU pin.

External interrupt requests are routed to the CPU via the external bus interface and SIM interrupt control logic. The CPU treats external interrupt requests as though they come from the SIM.

External IRQ[6:1] tive input. IRQ7 requires both an edge and a voltage level for validity.

IRQ[6:1] are maskable. IRQ7 is nonmaskable. The IRQ7 input is transition-sensitive in order to prevent redundant servicing and stack overflow. A nonmaskable interrupt is generated each time IRQ7 is asserted, and each time the priority mask changes from %111 to a lower number while IRQ7 is asserted.

are active-low level-sensitive inputs. External IRQ7 is an active-low transition-sensi-

MC68331TS/D 39

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

Interrupt requests are sampled on consecutive falling edges of the system clock. Interrupt request input circuitry has hysteresis. To be valid, a request signal must be asserted for at least two consecutive clock periods. Valid requests do not cause immediate exception processing, but are left pending. Pending requests are processed at instruction boundaries or when exception processing of higher-priority exceptions is complete.

The CPU32 does not latch the priority of a pending interrupt request. If an interrupt source of higher priority makes a service request while a lower priority request is pending, the higher priority request is serviced. If an interrupt request of equal or lower priority than the current IP mask value is made, the CPU does not recognize the occurrence of the request in any way.

3.8.1 Interrupt Acknowledge and Arbitration

Interrupt acknowledge bus cycles are generated during exception processing. When the CPU detects one or more interrupt requests of a priority higher than the interrupt priority mask value, it performs a CPU space read from address $FFFFF : [IP] : 1.

. nc

Freescale Semiconductor, I

The CPU space read cycle performs two functions: it places a mask value corresponding to the highest priority interrupt request on the address bus, and it acquires an exception vector number from the interrupt source. The mask value also serves two purposes: it is latched into the CCR IP field in order to mask lower-priority interrupts during exception processing, and it is decoded by modules that have requested interrupt service to determine whether the current interrupt acknowledge cycle pertains to them.

Modules that have requested interrupt service decode the IP value placed on the address bus at the beginning of the interrupt acknowledge cycle, and if their requests are at the specified IP level, respond to the cycle. Arbitration between simultaneous requests of the same priority is performed by means of serial contention between module interrupt arbitration (IARB) field bit values.

Each module that can make an interrupt service request, including the SIM, has an IARB field in its configuration register. An IARB field can be assigned a value from %0001 (lowest priority) to %1111 (highest priority). A value of %0000 in an IARB field causes the CPU to process a spurious interrupt exception when an interrupt from that module is recognized.

Because the EBI manages external interrupt requests, the SIM IARB value is used for arbitration between internal and external interrupt requests. The reset value of IARB for the SIM is %1111, and the reset IARB value for all other modules is %0000. Initialization software must assign different IARB values in order to implement an arbitration scheme.

Each module must have a unique IARB value. When two or more IARB fields have the same nonzero value, the CPU interprets multiple vector numbers simultaneously, with unpredictable consequences.

Arbitration must always take place, even when a single source requests service. This point is important for two reasons: the CPU interrupt acknowledge cycle is not driven on the external bus unless the SIM wins contention, and failure to contend causes an interrupt acknowledge bus cycle to be terminated by a bus error, which causes a spurious interrupt exception to be taken.

When arbitration is complete, the dominant module must place an interrupt vector number on the data bus and terminate the bus cycle. In the case of an external interrupt request, because the interrupt acknowledge cycle is transferred to the external bus, an external device must decode the mask value and respond with a vector number, then generate bus cycle termination signals. If the device does not respond in time, a spurious interrupt exception is taken.

The periodic interrupt timer (PIT) in the SIM can generate internal interrupt requests of specific priority at predetermined intervals. By hardware convention, PIT interrupts are serviced before external interrupt service requests of the same priority. Refer to 3.2.7 Periodic Interrupt Timer for more information.

40 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

3.8.2 Interrupt Processing Summary

A summary of the interrupt processing sequence follows. When the sequence begins, a valid interrupt

service request has been detected and is pending.

A. The CPU finishes higher priority exception processing or reaches an instruction boundary. B. Processor state is stacked. The contents of the status register and program counter are saved. C. The interrupt acknowledge cycle begins:

1. FC[2:0] are driven to %111 (CPU space) encoding.

2. The address bus is driven as follows. ADDR[23:20] = %1111; ADDR[19:16] = %1111, which indicates that the cycle is an interrupt acknowledge CPU space cycle; ADDR[15:4] = %111111111111; ADDR[3:1] = the level of the interrupt request being acknowledged; and ADDR0 = %1.

3. Request priority level is latched into the IP field in the status register from the address bus.

D. Modules or external peripherals that have requested interrupt service decode the request level

in ADDR[3:1]. If the request level of at least one interrupting module or device is the same as the value in ADDR[3:1], interrupt arbitration contention takes place. When there is no contention, the spurious interrupt monitor asserts BERR cessed.

E. After arbitration, the interrupt acknowledge cycle can be completed in one of three ways:

1. The dominant interrupt source supplies a vector number and DSACK signals appropriate to the access. The CPU32 acquires the vector number.

2. The AVEC signal is asserted (the signal can be asserted by the dominant interrupt source or the pin can be tied low), and the CPU32 generates an autovector number corresponding to interrupt priority.

3. The bus monitor asserts BERR and the CPU32 generates the spurious interrupt vector number.

F. The vector number is converted to a vector address. G. The content of the vector address is loaded into the PC, and the processor transfers control to

the exception handler routine.

3.9 Factory Test Block

The test submodule supports scan-based testing of the various MCU modules. It is integrated into the SIM to support production testing.

Test submodule registers are intended for Motorola use. Register names and addresses are provided to indicate that these addresses are occupied.

SIMTR — System Integration Module Test Register $YFFA02

SIMTRE — System Integration Module Test Register (E Clock) $YFFA08

TSTMSRA — Master Shift Register A $YFFA30

, and a spurious interrupt exception is pro-

TSTMSRB — Master Shift Register B $YFFA32

TSTSC — Test Module Shift Count $YFFA34

TSTRC — Test Module Repetition Count $YFFA36

CREG — Test Module Control Register $YFFA38

DREG — Test Module Distributed Register $YFFA3A

MC68331TS/D 41

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Freescale Semiconductor, I

42 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

4 Central Processor Unit

Based on the powerful MC68020, the CPU32 processing module provides enhanced system performance and also uses the extensive software base for the Motorola M68000 family.

4.1 Overview

The CPU32 is fully object code compatible with the M68000 Family, which excels at processing calculation-intensive algorithms and supporting high-level languages. The CPU32 supports all of the MC68010 and most of the MC68020 enhancements, such as virtual memory support, loop mode operation, instruction pipeline, and 32-bit mathematical operations. Powerful addressing modes provide compatibility with existing software programs and increase the efficiency of high-level language compilers. Special instructions, such as table lookup and interpolate and low-power stop, support the specific requirements of controller applications. Also included is the background debugging mode, an alternate operating mode that suspends normal operation and allows the CPU to accept debugging commands from the development system.

. nc

Ease of programming is an important consideration in using a microcontroller. The CPU32 instruction set is optimized for high performance. The eight 32-bit general-purpose data registers readily support 8-bit (byte), 16-bit (word), and 32-bit (long word) operations. Ease of program checking and diagnosis is further enhanced by trace and trap capabilities at the instruction level.

Use of high-level languages is increasing as controller applications become more complex and control programs become larger. High-level languages aid rapid development of software, with less error, and are readily portable. The CPU32 instruction set supports high-level languages.

4.2 Programming Model

The CPU32 has sixteen 32-bit general registers, a 32-bit program counter, one 32-bit supervisor stack pointer, a 16-bit status register, two alternate function code registers, and a 32-bit vector base register.

The programming model of the CPU32 consists of a user model and supervisor model, corresponding to the user and supervisor privilege levels. Some instructions available at the supervisor level are not available at the user level, allowing the supervisor to protect system resources from uncontrolled access. Bit S in the status register determines the privilege level.

The user programming model remains unchanged from previous M68000 Family microprocessors. Application software written to run at the nonprivileged user level migrates without modification to the CPU32 from any M68000 platform. The move from SR instruction, however, is privileged in the CPU32. It is not privileged in the M68000.

Freescale Semiconductor, I

MC68331TS/D 43

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

31 16 15 8 7 0

31 16 15 0

D0 D1 D2 D3 Data Registers D4 D5 D6 D7

. nc

31 16 15 0

31 0

Figure 10 User Programming Model

31 16 15 0

15 8 7 0

A0 A1 A2 A3 Address Registers A4 A5 A6

A7 (USP) User Stack Pointer

PC Program Counter

CCR Condition Code Register

A7' (SSP) Supervisor Stack Pointer

Freescale Semiconductor, I

31 0

Figure 11 Supervisor Programming Model Supplement

(CCR) SR Status Register

VBR Vector Base Register

SFC Alternate Function DFC Code Registers

44 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

4.3 Status Register

The status register contains the condition codes that reflect the results of a previous operation and can be used for conditional instruction execution in a program. The lower byte containing the condition codes is the only portion of the register available at the user privilege level; it is referenced as the condition code register (CCR) in user programs. At the supervisor privilege level, software can access the full status register, including the interrupt priority mask and additional control bits.

SR —Status Register

RESET:

System Byte

User Byte (Condition Code Register)

4.4 Data Types

4.5 Addressing Modes

14 13 12 11 10 8 7 6 5 4 3 2 1 0 T0 S 0 0 IP 0 0 0 X N Z V C

0 1 0 0 1 1 1 0 0 0 U U U U U

T[1:0] —Trace Enable S —Supervisor/User State Bits [12:11] —Unimplemented IP[2:0] —Interrupt Priority Mask

Bits [7:5] —Unimplemented X —Extend N —Negative Z —Zero V —Overflow C —Carry

Six basic data types are supported:

• Bits

• Packed Binary Coded Decimal Digits

• Byte Integers (8 bits)

• Word Integers (16 bits)

• Long-Word Integers (32 bits)

• Quad-Word Integers (64 bits)

Addressing in the CPU32 is register-oriented. Most instructions allow the results of the specified operation to be placed either in a register or directly in memory. This flexibility eliminates the need for extra instructions to store register contents in memory. The CPU32 supports seven basic addressing modes:

• Register direct

• Register indirect

• Register indirect with index

• Program counter indirect with displacement

• Program counter indirect with index

• Absolute

• Immediate

Included in the register indirect addressing modes are the capabilities to post-increment, predecrement, and offset. The program counter relative mode also has index and offset capabilities. In addition to these addressing modes, many instructions implicitly specify the use of the status register, stack pointer, or program counter.

MC68331TS/D 45

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

4.6 Instruction Set Summary

Instruction Syntax Operand Size Operation

ABCD Dn, Dn

ADD Dn, <ea>

ADDA <ea>, An 16, 32

ADDI #<data>, <ea> 8, 16, 32 ADDQ # <data>, <ea> 8, 16, 32 ADDX Dn, Dn

AND <ea>, Dn

ANDI # <data>, <ea> 8, 16, 32

ANDI to CCR # <data>, CCR 8

ANDI to SR1

ASL Dn, Dn

ASR Dn, Dn

Bcc label 8, 16, 32

BCHG Dn, <ea>

BCLR Dn, <ea>

BGND none none

BKPT # <data> none

BRA label 8, 16, 32

BSET Dn, <ea>

BSR label 8, 16, 32

BTST Dn, <ea>

CHK <ea>, Dn 16, 32

CHK2 <ea>, Rn 8, 16, 32

CLR <ea> 8, 16, 32

CMP <ea>, Dn 8, 16, 32

CMPA <ea>, An 16, 32

CMPI # <data>, <ea> 8, 16, 32

− (An), − (An)

<ea>, Dn

− (An), − (An)

Dn, <ea>

# <data>, SR 16

# <data>, Dn

<ea>

# <data>, Dn

<ea>

# <data>, <ea>

Table 20 Instruction Set Summary

8 8

8, 16, 32 8, 16, 32

8, 32 8, 32

Source10 + Destination10 + X ⇒ Destination

Source + Destination ⇒ Destination Source + Destination ⇒ Destination

Immediate data + Destination ⇒ Destination Immediate data + Destination ⇒ Destination

Source + Destination + X ⇒ Destination

Source • Destination ⇒ Destination Data • Destination ⇒ Destination

Source • CCR ⇒ CCR Source • SR ⇒ SR

X/C 0

If condition true, then PC + d ⇒ PC

bit number〉of destination) Z bit of destinati

bit number〈〉of destination()

0 ⇒ bit of destination If background mode enabled, then enter background

mode, else format/vector ⇒ − (SSP); PC ⇒ − (SSP); SR ⇒ − (SSP); (vector) ⇒ PC

If breakpoint cycle acknowledged, then execute returned operation word, else trap as illegal instruction

PC + d ⇒ PC

bit number〈〉of destination()Z;⇒

1 ⇒ bit of destination SP − 4 ⇒ SP; PC ⇒ (SP); PC + d ⇒ PC

bit number〈〉of destination()Z⇒

If Dn < 0 or Dn > (ea), then CHK exception If Rn < lower bound or Rn > upper bound, then

CHK exception 0 ⇒ Destination (Destination − Source), CCR shows results (Destination − Source), CCR shows results (Destination − Data), CCR shows results

⇒⇒

X/C

46 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

Table 20 Instruction Set Summary (Continued)

Instruction Syntax Operand Size Operation

CMPM (An) +, (An) + 8, 16, 32

CMP2 <ea>, Rn 8, 16, 32

DBcc Dn, label 16

DIVS/DIVU <ea>, Dn 32/16 ⇒ 16 : 16

DIVSL/DIVUL <ea>, Dr : Dq

EOR Dn, <ea> 8, 16, 32

EORI # <data>, <ea> 8, 16, 32

EORI to CCR # <data>, CCR 8

EORI to SR

EXG Rn, Rn 32

EXT Dn

EXTB Dn 8 ⇒ 32

ILLEGAL none none

JMP <ea> none

LINK An, # d 16, 32

LPSTOP

LSR Dn, Dn

MOVE <ea>, <ea> 8, 16, 32

MOVEA <ea>, An 16, 32 ⇒ 32

MOVEA

MOVE from CCR CCR, <ea> 16

MOVE to CCR <ea>, CCR 16

MOVE from SR

MOVE to SR

MOVE USP

MOVEC

MOVEM list, <ea>

JSR <ea> none LEA <ea>, An 32

LSL Dn, Dn

<ea>, Dq

<ea>, Dr : Dq

# <data>, SR 16

# <data> 16

# <data>, Dn

<ea>

#<data>, Dn

<ea>

USP, An An, USP

SR, <ea> 16 <ea>, SR 16

USP, An An, USP

Rc, Rn Rn, Rc

<ea>, list

64/32 ⇒ 32 : 32

32/32 ⇒ 32

32/32 ⇒ 32 : 32

8 ⇒ 16

16 ⇒ 32

8, 16, 32 8, 16, 32

32 32

16, 32

16, 32 ⇒ 32

(Destination − Source), CCR shows results Lower bound ≤ Rn ≤ Upper bound, CCR shows result If condition false, then Dn − 1 ⇒ PC;

if Dn ≠ (− 1), then PC + d ⇒ PC Destination / Source ⇒ Destination

(signed or unsigned) Destination / Source ⇒ Destination

(signed or unsigned) Source ⊕ Destination ⇒ Destination

Data ⊕ Destination ⇒ Destination Source ⊕ CCR ⇒ CCR Source ⊕ SR ⇒ SR Rn ⇒ Rn

Sign extended Destination ⇒ Destination Sign extended Destination ⇒ Destination

SSP − 2 ⇒ SSP; vector offset ⇒ (SSP); SSP − 4 ⇒ SSP; PC ⇒ (SSP); SSP − 2 ⇒ SSP; SR ⇒ (SSP); Illegal instruction vector address ⇒ PC

Destination ⇒ PC SP − 4 ⇒ SP; PC ⇒ (SP); destination ⇒ PC <ea> ⇒ An SP − 4 ⇒ SP, An ⇒ (SP); SP ⇒ An, SP + d ⇒ SP Data ⇒ SR; interrupt mask ⇒ EBI; STOP

X/C 0

Source ⇒ Destination Source ⇒ Destination USP ⇒ An

An ⇒ USP CCR ⇒ Destination Source ⇒ CCR SR ⇒ Destination Source ⇒ SR USP ⇒ An

An ⇒ USP Rc ⇒ Rn

Rn ⇒ Rc Listed registers ⇒ Destination

Source ⇒ Listed registers

X/C

MC68331TS/D 47

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

Table 20 Instruction Set Summary (Continued)

Instruction Syntax Operand Size Operation

MOVEP Dn, (d16, An)

16, 32

Dn [31 : 24] ⇒ (An + d); Dn [23 : 16] ⇒ (An + d + 2); Dn [15 : 8] ⇒ (An + d + 4); Dn [7 : 0] ⇒ (An + d + 6)

. nc

Freescale Semiconductor, I

(d16, An), Dn

MOVEQ #<data>, Dn 8 ⇒ 32

MOVES

MULS/MULU <ea>, Dn

ORI to CCR #<data>, CCR 16

ORI to SR

RESET

NBCD <ea> 8

NEG <ea> 8, 16, 32

NEGX <ea> 8, 16, 32

NOP none none NOT <ea> 8, 16, 32

OR <ea>, Dn

ORI #<data>, <ea> 8, 16, 32

PEA <ea> 32

ROL Dn, Dn

ROR Dn, Dn

ROXL Dn, Dn

ROXR Dn, Dn

RTD #d 16

RTE

RTR none none

RTS none none

SBCD Dn, Dn

Scc <ea> 8

STOP

Rn, <ea> <ea>, Rn

<ea>, Dl

<ea>, Dh : Dl

Dn, <ea>

#<data>, SR 16

none none

#<data>, Dn

<ea>

#<data>, Dn

<ea>

#<data>, Dn

<ea>

#<data>, Dn

<ea>

none none

− (An), − (An)

#<data> 16

8, 16, 32

16 ∗ 16 ⇒ 32 32 ∗ 32 ⇒ 32 32 ∗ 32 ⇒ 64

8, 16, 32 8, 16, 32

(An + d) ⇒ Dn [31 : 24]; (An + d + 2) ⇒ Dn [23 : 16]; (An + d + 4) ⇒ Dn [15 : 8]; (An + d + 6) ⇒ Dn [7 : 0]

Immediate data ⇒ Destination Rn ⇒ Destination using DFC

Source using SFC ⇒ Rn Source ∗ Destination ⇒ Destination

(signed or unsigned)

8 8

0 − Destination 0 − Destination ⇒ Destination

0 − Destination − X ⇒ Destination PC + 2 ⇒ PC Destination

Source + Destination ⇒ Destination Data + Destination ⇒ Destination

Source + CCR ⇒ SR Source ; SR ⇒ SR SP − 4 ⇒ SP; <ea> ⇒ SP Assert RESET

C X

(SP) ⇒ PC; SP + 4 + d ⇒ SP (SP) ⇒ SR; SP + 2 ⇒ SP; (SP) ⇒ PC;

SP + 4 ⇒ SP; Restore stack according to format

(SP) ⇒ CCR; SP + 2 ⇒ SP; (SP) ⇒ PC; SP + 4 ⇒ SP

(SP) ⇒ PC; SP + 4 ⇒ SP Destination10 − Source10 − X ⇒ Destination If condition true, then destination bits are set to 1;

else, destination bits are cleared to 0 Data ⇒ SR; STOP

− X ⇒ Destination

⇒ Destination

line

48 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

Table 20 Instruction Set Summary (Continued)

Instruction Syntax Operand Size Operation

SUB <ea>, Dn

SUBA <ea>, An 16, 32

SUBI #<data>, <ea> 8, 16, 32 SUBQ #<data>, <ea> 8, 16, 32

SUBX Dn, Dn

SWAP Dn 16

Dn, <ea>

− (An), − (An)

8, 16, 32

8, 16, 32 8, 16, 32

Destination − Source ⇒ Destination Destination − Source ⇒ Destination

Destination − Data ⇒ Destination Destination − Data ⇒ Destination

Destination − Source − X ⇒ Destination

MSW LSW

. nc

TAS <ea> 8

TBLS/TBLU <ea>, Dn

Dym : Dyn, Dn

TBLSN/TBLUN <ea>, Dn

Dym : Dyn, Dn

TRAP #<data> none

TRAPcc none

#<data>

TRAPV none none

TST <ea> 8, 16, 32

UNLK An 32

1. Privileged instruction.

8, 16, 32

none

16, 32

Destination Tested Condition Codes bit 7 of Destination

Dyn − Dym ⇒ Temp (Temp ∗ Dn [7 : 0]) ⇒ Temp (Dym ∗ 256) + Temp ⇒ Dn

Dyn − Dym ⇒ Temp (Temp ∗ Dn [7 : 0]) / 256 ⇒ Temp Dym + Temp ⇒ Dn

SSP − 2 ⇒ SSP; format/vector offset ⇒ (SSP); SSP − 4 ⇒ SSP; PC ⇒ (SSP); SR ⇒ (SSP); vector address ⇒ PC

If cc true, then TRAP exception If V set, then overflow TRAP exception

Source − 0, to set condition codes An ⇒ SP; (SP) ⇒ An, SP + 4 ⇒ SP

Freescale Semiconductor, I

MC68331TS/D 49

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

4.7 Background Debugging Mode

The background debugger on the CPU32 is implemented in CPU microcode. The background debugging commands are summarized below.

Command Mnemonic Description

Read D/A Register RDREG/RAREG

Write D/A Register WDREG/WAREG

Read System Register RSREG

Write System Register WSREG

Read Memory Location READ

Write Memory Location WRITE

Dump Memory Block DUMP

Fill Memory Block FILL

Resume Execution GO

Patch User Code CALL

Reset Peripherals RST

No Operation NOP

Table 21 Background Debugging Mode

Read the selected address or data register and return the results through the serial interface.

The data operand is written to the specified address or data register.

The specified system control register is read. All registers that can be read in supervisor mode can be read in background mode.

The operand data is written into the specified system control register.

Read the sized data at the memory location specified by the long-word address. The source function code register (SFC) determines the address space accessed.

Write the operand data to the memory location specified by the long-word address. The destination function code (DFC) register determines the address space accessed.

Used in conjunction with the READ command to dump large blocks of memory. An initial READ is executed to set up the starting address of the block and retrieve the first result. Subsequent operands are retrieved with the DUMP command.

Used in conjunction with the WRITE command to fill large blocks of memory. Initially, a WRITE is executed to set up the starting address of the block and supply the first operand. The FILL command writes subsequent operands.

The pipe is flushed and refilled before resuming instruction execution at the current PC.

Current program counter is stacked at the location of the current stack pointer. Instruction execution begins at user patch code.

Asserts RESET for 512 clock cycles. The CPU is not reset by this command. Synonymous with the CPU RESET instruction.

NOP performs no operation and can be used as a null command.

Freescale Semiconductor, I

50 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

5 Queued Serial Module

The QSM contains two serial interfaces, the queued serial peripheral interface (QSPI) and the serial communication interface (SCI).

MISO/PQS0 MOSI/PQS1 SCK/PQS2

QSPI

PCS0/SS/PQS3 PCS1/PQS4

PCS2/PQS5 PCS3/PQS6

. nc

Freescale Semiconductor, I

IMB

5.1 Overview

The QSPI provides easy peripheral expansion or interprocessor communication through a full-duplex, synchronous, three-line bus: data in, data out, and a serial clock. Four programmable peripheral chipselect pins provide addressability for up to 16 peripheral devices. A self-contained RAM queue allows up to 16 serial transfers of 8 to 16 bits each, or transmission of a 256-bit data stream without CPU intervention. A special wraparound mode supports continuous sampling of a serial peripheral, with automatic QSPI RAM updating, which makes the interface to A/D converters more efficient.

The SCI provides a standard nonreturn to zero (NRZ) mark/space format. It operates in either full- or half-duplex mode. There are separate transmitter and receiver enable bits and dual data buffers. A modulus-type baud rate generator provides rates from 64 to 524 kbaud with a 16.78-MHz system clock, or 110 to 655 kbaud with a 20.97 MHz system clock. Word length of either 8 or 9 bits is software selectable. Optional parity generation and detection provide either even or odd parity check capability. Advanced error detection circuitry catches glitches of up to 1/16 of a bit time in duration. Wakeup functions allow the CPU to run uninterrupted until meaningful data is available.

INTERFACE

LOGIC

SCI

Figure 12 QSM Block Diagram

PORT QS

TXD/PQS7

RXD

QSM BLOCK

An address map of the QSM is shown below. The “Access” column indicates which registers are accessible only at the supervisor privilege level and which can be assigned to either the supervisor or user privilege level, according to the value of the SUPV bit in the QSMCR.

MC68331TS/D 51

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

Access Address 15 8 7 0

S $YFFC00 QSM MODULE CONFIGURATION (QSMCR) S $YFFC02 QSM TEST (QTEST)

S $YFFC04 QSM INTERRUPT LEVEL (QILR) QSM INTERRUPT VECTOR (QIVR) S/U $YFFC06 NOT USED S/U $YFFC08 SCI CONTROL 0 (SCCR0) S/U $YFFC0A SCI CONTROL 1 (SCCR1) S/U $YFFC0C SCI STATUS (SCSR) S/U $YFFC0E SCI DATA (SCDR) S/U $YFFC10 NOT USED S/U $YFFC12 NOT USED S/U $YFFC14 NOT USED PQS DATA (PORTQS) S/U $YFFC16 PQS PIN ASSIGNMENT (PQSPAR) PQS DATA DIRECTION (DDRQS) S/U $YFFC18 SPI CONTROL 0 (SPCR0) S/U $YFFC1A SPI CONTROL 1 (SPCR1) S/U $YFFC1C SPI CONTROL 2 (SPCR2) S/U $YFFC1E SPI CONTROL 3 (SPCR3) SPI STATUS (SPSR) S/U $YFFC20–

$YFFCFF

S/U $YFFD00–

$YFFD1F

S/U $YFFD20–

$YFFD3F

S/U $YFFD40–

$YFFD4F

Y = M111, where M is the logic state of the module mapping (MM) bit in the SIMCR

5.2 Pin Function

The following table is a summary of the functions of the QSM pins when they are not configured for general-purpose I/O. The QSM data direction register (DDRQS) designates each pin except RXD as an input or output.

QSPI Pins Slave Serial Data Output from QSPI

SCI Pins TXD Transmit Serial Data Output from SCI

Table 22 QSM Address Map

NOT USED

RECEIVE RAM (RR[0:F])

TRANSMIT RAM (TR[0:F])

COMMAND RAM (CR[0:F])

Pin Mode Pin Function

MISO Master Serial Data Input to QSPI

MOSI Master Serial Data Output from QSPI

Slave Serial Data Input to QSPI

SCK Master Clock Output from QSPI

Slave Clock Input to QSPI

PCS0/SS

Master Input: Assertion Causes Mode Fault

Output: Selects Peripherals

Slave Input: Selects the QSPI

PCS[3:1] Master Output: Selects Peripherals

Slave None

RXD Receive Serial Data Input to SCI

52 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

5.3 QSM Registers

QSM registers are divided into four categories: QSM global registers, QSM pin control registers, QSPI submodule registers, and SCI submodule registers. The QSPI and SCI registers are defined in separate sections below. Writes to unimplemented register bits have no meaning or effect, and reads from unimplemented bits always return a logic zero value.

The module mapping bit of the SIM configuration register (SIMCR) defines the most significant bit (ADDR23) of the address, shown in each register figure as Y (Y = $7 or $F). This bit, concatenated with the rest of the address given, forms the absolute address of each register. Refer to the SIM section of this technical summary for more information about how the state of MM affects the system.

5.3.1 Global Registers

The QSM global registers contain system parameters used by both the QSPI and the SCI submodules. These registers contain the bits and fields used to configure the QSM.

. nc

QSMCR — QSM Configuration Register $YFFC00

15 14 13 12 11 10 9 8 7 6 5 4 3 0

STOP FRZ1 FRZ0 0 0 0 0 0 SUPV 0 0 0 IARB

RESET:

0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0

The QSMCR contains parameters for the QSM/CPU/intermodule bus (IMB) interface.

STOP — Stop Enable

0 = Normal QSM clock operation

1 = QSM clock operation stopped STOP places the QSM in a low-power state by disabling the system clock in most parts of the module. The QSMCR is the only register guaranteed to be readable while STOP is asserted. The QSPI RAM is not readable. However, writes to RAM or any register are guaranteed to be valid while STOP is asserted. STOP can be negated by the CPU and by reset.

The system software must stop each submodule before asserting STOP to avoid complications at restart and to avoid data corruption. The SCI submodule receiver and transmitter should be disabled, and the operation should be verified for completion before asserting STOP. The QSPI submodule should be stopped by asserting the HALT bit in SPCR3 and by asserting STOP after the HALTA flag is set.

FRZ1 — Freeze 1

0 = Ignore the FREEZE signal on the IMB

1 = Halt the QSPI (on a transfer boundary) FRZ1 determines what action is taken by the QSPI when the FREEZE signal of the IMB is asserted. FREEZE is asserted whenever the CPU enters the background mode.

Freescale Semiconductor, I

FRZ0 — Freeze 0

Reserved

Bits [12:8] — Not Implemented SUPV — Supervisor/Unrestricted

0 = User access

1 = Supervisor access SUPV defines the assignable QSM registers as either supervisor-only data space or unrestricted data space.

IARB — Interrupt Arbitration Identification Number

The IARB field is used to arbitrate between simultaneous interrupt requests of the same priority. Each module that can generate interrupt requests must be assigned a unique, non-zero IARB field value. Refer to 3.8 Interrupts for more information.

MC68331TS/D 53

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

QTEST — QSM Test Register $YFFC02

QTEST is used during factory testing of the QSM. Accesses to QTEST must be made while the MCU is in test mode.

QILR — QSM Interrupt Levels Register $YFFC04

15 14 13 11 10 8 7 0

0 0 ILQSPI ILSCI QIVR

RESET:

0 0 0 0 0 0 0 0

QILR determines the priority level of interrupts requested by the QSM and the vector used when an interrupt is acknowledged.

ILQSPI — Interrupt Level for QSPI

ILQSPI determines the priority of QSPI interrupts. This field must be given a value between $0 (interrupts disabled) to $7 (highest priority).

ILSCI — Interrupt Level of SCI

ILSCI determines the priority of SCI interrupts. This field must be given a value between $0 (interrupts disabled) to $7 (highest priority). If ILQSPI and ILSCI are the same nonzero value, and both submodules simultaneously request interrupt service, QSPI has priority.

QIVR — QSM Interrupt Vector Register $YFFC05

QILR

RESET:

QIVR determines which two vector numbers in the exception vector table are to be used for QSM interrupts. The seven MSB of a user-defined vector number ($40–$FF) must be written into the INTV field during initialization. The value of INTV0 is supplied by the QSM when an interrupt service request is acknowledged.

During an interrupt-acknowledge cycle, INTV[7:1] are driven on DATA[7:1] IMB lines. DATA0 is negated for an SCI interrupt and asserted for a QSPI interrupt. Writes to INTV0 have no meaning or effect. Reads of INTV0 return a value of one.

At reset, QIVR is initialized to $0F, which corresponds to the uninitialized interrupt vector in the exception table.

8 7 0

INTV

0 0 0 1 1 1 1

Freescale Semiconductor, I

5.3.2 Pin Control Registers

The QSM uses nine pins, eight of which form a parallel port (PORTQS) on the MCU. Although these pins are used by the serial subsystems, any pin can alternately be assigned as general-purpose I/O on a pin-by-pin basis.

Pins used for general-purpose I/O must not be assigned to the QSPI by register PQSPAR. To avoid driving incorrect data, the first byte to be output must be written before DDRQS is configured. DDRQS must then be written to determine the direction of data flow and to output the value contained in register PORTQS. Subsequent data for output is written to PORTQS.

54 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

PORTQS — Port QS Data Register $YFFC14

15 8 7 6 5 4 3 2 1 0

NOT USED PQS7 PQS6 PQS5 PQS4 PQS3 PQS2 PQS1 PQS0

PORTQS latches I/O data. Writes drive pins defined as outputs. Reads return data present on the pins. To avoid driving undefined data, first write a byte to PORTQS, then configure DDRQS.

PQSPAR — PORT QS Pin Assignment Register $YFFC16 DDRQS — PORT QS Data Direction Register $YFFC17

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

PQSPA6 PQSPA5 PQSPA4 PQSPA3

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

Clearing a bit in the PQSPAR assigns the corresponding pin to general-purpose I/O; setting a bit assigns the pin to the QSPI. The PQSPAR does not affect operation of the SCI.

PQSPA1 PQSPA0

RESET:

0 0 0 0 0 0 0 0

DDQS7 DDQS6 DDQS5 DDQS4 DDQS3 DDQS2 DDQS1 DDQS0

Table 23 QSPAR Pin Assignments

PQSPAR Field PQSPAR Bit Pin Function

PQSPA0 0

PQSPA1 0

PQSPA2 0

PQSPA3 0

PQSPA4 0

PQSPA5 0

PQSPA6 0

PQSPA7 0

Freescale Semiconductor, I

NOTES:

1. PQS2 is a digital I/O pin unless the SPI is enabled (SPE in SPCR1 set), in which case it becomes SPI serial clock SCK.

2. PQS7 is a digital I/O pin unless the SCI transmitter is enabled (TE in SCCR1 = 1), in which case it becomes SCI serial output TXD.

PQS0

MISO

PQS1

MOSI

PQS2

SCK

PQS3

PCS0/SS

PQS4

PCS1

PQS5

PCS2

PQS6

PCS3

PQS7

TXD

MC68331TS/D 55

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

DDRQS determines whether pins are inputs or outputs. Clearing a bit makes the corresponding pin an input; setting a bit makes the pin an output. DDRQS affects both QSPI function and I/O function.

Table 24 Effect of DDRQS on QSM Pin Function

. nc

QSM Pin Mode DDRQS

Bit

MISO Master DDQ0 0 Serial Data Input to QSPI

Slave 0 Disables Data Output

MOSI Master DDQ1 0 Disables Data Output

Slave 0 Serial Data Input to QSPI

SCK

PCS0/SS

PCS[3:1] Master DDQ[4:6]0 Disables Chip-Select Output

TXD

RXD Receive None NA Serial Data Input to SCI

NOTES:

1. PQS2 is a digital I/O pin unless the SPI is enabled (SPE in SPCR1 set), in which case it becomes SPI serial clock SCK.

2. PQS7 is a digital I/O pin unless the SCI transmitter is enabled (TE in SCCR1 = 1), in which case it becomes SCI serial output TXD.

DDRQS determines the direction of the TXD pin only when the SCI transmitter is disabled. When the SCI transmitter is enabled, the TXD pin is an output.

Master DDQ2 0 Disables Clock Output

Slave 0 Clock Input to QSPI

Master DDQ3 0 Assertion Causes Mode Fault

Slave 0 QSPI Slave Select Input

Slave 0 Inactive

Transmit DDQ7 X Serial Data Output from SCI

Bit

State

1 Disables Data Input

1 Serial Data Output from QSPI

1 Disables Data Input

1 Clock Output from QSPI

1 Disables Clock Input

1 Chip-Select Output

1 Disables Select Input

1 Chip-Select Output

1 Inactive

Pin Function

Freescale Semiconductor, I

5.4 QSPI Submodule

The QSPI submodule communicates with external devices through a synchronous serial bus. The QSPI is fully compatible with the serial peripheral interface (SPI) systems found on other Motorola products. A block diagram of the QSPI is shown below.

56 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

QUEUE CONTROL

BLOCK

Freescale Semiconductor, Inc.

. nc

Freescale Semiconductor, I

QUEUE

POINTER

COMPARATOR

END QUEUE

POINTER

CONTROL

LOGIC

STATUS

CONTROL

REGISTERS

DELAY

COUNTER

PROGRAMMABLE

LOGIC ARRAY

5.4.1 QSPI Pins

Seven pins are associated with the QSPI. When not needed for a QSPI application, they can be configured as general-purpose I/O pins. The PCS0/SS pin can function as a peripheral chip select output, slave select input, or general-purpose I/O. Refer to the following table for QSPI input and output pins and their functions.

DONE

A D D R

CHIP SELECT

I S T E

COMMAND

MSB LSB

8/16-BIT SHIFT REGISTER

Rx/Tx DATA REGISTER

80-BYTE

QSPI RAM

Figure 13 QSPI Block Diagram

BAUD RATE

GENERATOR

MOSI

MISO

PCS0/SS PCS[2:1]

SCK

QSPI BLOCK

MC68331TS/D 57

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Pin Names Mnemonics Mode Function

Master In Slave Out MISO Master

Master Out Slave In MOSI Master

Serial Clock SCK Master

Peripheral Chip Selects PCS[3:1] Master Select Peripherals Peripheral Chip Select

Slave Select

5.4.2 QSPI Registers

The programmer's model for the QSPI submodule consists of the QSM global and pin control registers, four QSPI control registers, one status register, and the 80-byte QSPI RAM.

The CPU can read and write to registers and RAM. The four control registers must be initialized before the QSPI is enabled to ensure defined operation. SPCR1 should be written last because it contains QSPI enable bit SPE. Asserting this bit starts the QSPI. The QSPI control registers are reset to a defined state and can then be changed by the CPU. Reset values are shown below each register.

PCS0

Slave

Master Master

Slave

Serial Data Input to QSPI Serial Data Output from QSPI

Serial Data Output from QSPI Serial Data Input to QSPI

Clock Output from QSPI Clock Input to QSPI

Selects Peripheral Causes Mode Fault Initiates Serial Transfer

Refer to the following memory map of the QSPI.

Address Name Usage

$YFFC18 SPCR0 QSPI Control Register 0 $YFFC1A SPCR1 QSPI Control Register 1 $YFFC1C SPCR2 QSPI Control Register 2 $YFFC1E SPCR3 QSPI Control Register 3 $YFFC1F SPSR QSPI Status Register

$YFFD00 RAM QSPI Receive Data (16 Words)

$YFFD20 RAM QSPI Transmit Data (16 Words)

$YFFD40 RAM QSPI Command Control (8 Words)

Writing a different value into any control register except SPCR2 while the QSPI is enabled disrupts operation. SPCR2 is buffered to prevent disruption of the current serial transfer. After completion of the current serial transfer, the new SPCR2 values become effective.

Writing the same value into any control register except SPCR2 while the QSPI is enabled has no effect

Freescale Semiconductor, I

on QSPI operation. Rewriting NEWQP in SPCR2 causes execution to restart at the designated location.

SPCR0 — QSPI Control Register 0 $YFFC18

15 14 13 10 9 8 7 0

MSTR WOMQ BITS CPOL CPHA SPBR

RESET:

0 0 0 0 0 0 0 1 0 0 0 0 0 1 0 0

SPCR0 contains parameters for configuring the QSPI before it is enabled. The CPU can read and write this register. The QSM has read-only access.

58 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

MSTR — Master/Slave Mode Select

0 = QSPI is a slave device and only responds to externally generated serial data.

1 = QSPI is system master and can initiate transmission to external SPI devices. MSTR configures the QSPI for either master or slave mode operation. This bit is cleared on reset and may only be written by the CPU.

WOMQ — Wired-OR Mode for QSPI Pins

0 = Outputs have normal MOS drivers.

1 = Pins designated for output by DDRQS have open-drain drivers. WOMQ allows the wired-OR function to be used on QSPI pins, regardless of whether they are used as general-purpose outputs or as QSPI outputs. WOMQ affects the QSPI pins regardless of whether the QSPI is enabled or disabled.

BITS — Bits Per Transfer

In master mode, when BITSE in a command is set, the BITS field determines the number of data bits transferred. When BITSE is cleared, eight bits are transferred. Reserved values default to eight bits. BITSE is not used in slave mode.

The following table shows the number of bits per transfer.

CPOL — Clock Polarity

0 = The inactive state value of SCK is logic level zero.

1 = The inactive state value of SCK is logic level one. CPOL is used to determine the inactive state value of the serial clock (SCK). It is used with CPHA to produce a desired clock/data relationship between master and slave devices.

BITS Bits per Transfer

0000 16 0001 Reserved 0010 Reserved 0011 Reserved 0100 Reserved 0101 Reserved 0110 Reserved 0111 Reserved 1000 8 1001 9 1010 10 1011 11 1100 12 1101 13 1110 14 1111 15

CPHA — Clock Phase

0 = Data is captured on the leading edge of SCK and changed on the following edge of SCK.

1 = Data is changed on the leading edge of SCK and captured on the following edge of SCK. CPHA determines which edge of SCK causes data to change and which edge causes data to be captured. CPHA is used with CPOL to produce a desired clock/data relationship between master and slave devices. CPHA is set at reset.

MC68331TS/D 59

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

SPBR — Serial Clock Baud Rate

The QSPI uses a modulus counter to derive SCK baud rate from the MCU system clock. Baud rate is selected by writing a value from 2 to 255 into the SPBR field. The following equation determines the SCK baud rate:

where SPBR equals {2, 3, 4,..., 255} Giving SPBR a value of zero or one disables the baud rate generator. SCK is disabled and assumes its inactive state value. No serial transfers occur. At reset, baud rate is initialized to one eighth of the system clock frequency.

SPCR1 — QSPI Control Register 1 $YFFC1A

15 14 8 7 0

SPE DSCKL DTL

RESET:

0 0 0 0 0 1 0 0 0 0 0 0 0 1 0 0

SPCR1 contains parameters for configuring the QSPI before it is enabled. The CPU can read and write this register, but the QSM has read access only, except for SPE, which is automatically cleared by the QSPI after completing all serial transfers, or when a mode fault occurs.

SCK Baud Rate = System Clock/(2SPBR)

SPBR = System Clock/(2SCK)(Baud Rate Desired)

SPE — QSPI Enable

0 = QSPI is disabled. QSPI pins can be used for general-purpose I/O.

1 = QSPI is enabled. Pins allocated by PQSPAR are controlled by the QSPI.

DSCKL — Delay before SCK

When the DSCK bit in command RAM is set, this field determines the length of delay from PCS valid to SCK transition. PCS can be any of the four peripheral chip-select pins. The following equation determines the actual delay before SCK:

PCS to SCK Delay = [DSCKL/System Clock] where DSCKL equals {1, 2, 3,..., 127}. When the DSCK value of a queue entry equals zero, then DSCKL is not used. Instead, the PCS valid-

to-SCK transition is one-half SCK period.

DTL — Length of Delay after Transfer

When the DT bit in command RAM is set, this field determines the length of delay after serial transfer. The following equation is used to calculate the delay:

Freescale Semiconductor, I

where DTL equals {1, 2, 3,..., 255}. A zero value for DTL causes a delay-after-transfer value of 8192/System Clock.

Delay after Transfer = [(32DTL)/System Clock]

If DT equals zero, a standard delay is inserted.

Standard Delay after Transfer = [17/System Clock]

Delay after transfer can be used to provide a peripheral deselect interval. A delay can also be inserted between consecutive transfers to allow serial A/D converters to complete conversion.

60 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

SPCR2 — QSPI Control Register 2 $YFFC1C

15 14 13 12 11 8 7 6 5 4 3 0

SPIFIE WREN WRTO 0 ENDQP 0 0 0 0 NEWQP

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

SPCR2 contains QSPI configuration parameters. The CPU can read and write this register; the QSM has read access only. Writes to SPCR2 are buffered. A write to SPCR2 that changes a bit value while the QSPI is operating is ineffective on the current serial transfer, but becomes effective on the next serial transfer. Reads of SPCR2 return the current value of the register, not of the buffer.

SPIFIE — SPI Finished Interrupt Enable

0 = QSPI interrupts disabled 1 = QSPI interrupts enabled

SPIFIE enables the QSPI to generate a CPU interrupt upon assertion of the status flag SPIF.

WREN — Wrap Enable

0 = Wraparound mode disabled 1 = Wraparound mode enabled

WREN enables or disables wraparound mode.

WRTO — Wrap To

When wraparound mode is enabled, after the end of queue has been reached, WRTO determines which address the QSPI executes.

Bit 12 — Not Implemented ENDQP — Ending Queue Pointer

This field contains the last QSPI queue address.

Bits [7:4] — Not Implemented NEWQP — New Queue Pointer Value

This field contains the first QSPI queue address.

SPCR3 — QSPI Control Register 3 $YFFC1E

15 14 13 12 11 10 9 8 7 0

0 0 0 0 0 LOOPQ HMIE HALT SPSR

RESET:

0 0 0 0 0 0 0 0

Freescale Semiconductor, I

SPCR3 contains QSPI configuration parameters. The CPU can read and write SPCR3, but the QSM has read-only access.

Bits [15:11] — Not Implemented LOOPQ — QSPI Loop Mode

0 = Feedback path disabled 1 = Feedback path enabled

LOOPQ controls feedback on the data serializer for testing.

HMIE — HALTA and MODF Interrupt Enable

0 = HALTA and MODF interrupts disabled 1 = HALTA and MODF interrupts enabled

HMIE controls CPU interrupts caused by the HALTA status flag or the MODF status flag in SPSR.

MC68331TS/D 61

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

HALT — Halt

0 = Halt not enabled

1 = Halt enabled When HALT is asserted, the QSPI stops on a queue boundary. It is in a defined state from which it can later be restarted.

SPSR — QSPI Status Register $YFFC1F

15 8 7 6 5 4 3 0

SPCR3 SPIF MODF HALTA 0 CPTQP

SPSR contains QSPI status information. Only the QSPI can assert the bits in this register. The CPU reads this register to obtain status information and writes it to clear status flags.

SPIF — QSPI Finished Flag

0 = QSPI not finished

1 = QSPI finished SPIF is set after execution of the command at the address in ENDQP.

MODF — Mode Fault Flag

0 = Normal operation

1 = Another SPI node requested to become the network SPI master while the QSPI was enabled

in master mode (SS The QSPI asserts MODF when the QSPI is the serial master (MSTR = 1) and the SS input pin is negated by an external driver.

RESET:

0 0 0 0 0 0 0 0

input taken low).

HALTA — Halt Acknowledge Flag

0 = QSPI not halted 1 = QSPI halted

HALTA is asserted when the QSPI halts in response to CPU assertion of HALT.

Bit 4 — Not Implemented CPTQP — Completed Queue Pointer

CPTQP points to the last command executed. It is updated when the current command is complete. When the first command in a queue is executing, CPTQP contains either the reset value ($0) or a pointer to the last command completed in the previous queue.

5.4.3 QSPI RAM

The QSPI contains an 80-byte block of dual-access static RAM that is used by both the QSPI and the

Freescale Semiconductor, I

CPU. The RAM is divided into three segments: receive data, transmit data, and command control data. Receive data is information received from a serial device external to the MCU. Transmit data is information stored by the CPU for transmission to an external peripheral. Command control data is used to perform the transfer.

Refer to the following illustration of the organization of the RAM.

62 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

. nc

500

51E

Once the CPU has set up the queue of QSPI commands and enabled the QSPI, the QSPI can operate independently of the CPU. The QSPI executes all of the commands in its queue, sets a flag indicating that it is finished, and then either interrupts the CPU or waits for CPU intervention. It is possible to execute a queue of commands repeatedly without CPU intervention.

RR[0:F] — Receive Data RAM $YFFD00

Data received by the QSPI is stored in this segment. The CPU reads this segment to retrieve data from the QSPI. Data stored in receive RAM is right-justified. Unused bits in a receive queue entry are set to zero by the QSPI upon completion of the individual queue entry. The CPU can access the data using byte, word, or long-word addressing.

The CPTQP value in SPSR shows which queue entries have been executed. The CPU uses this information to determine which locations in receive RAM contain valid data before reading them.

TR[0:F] — Transmit Data RAM $YFFD20

Data that is to be transmitted by the QSPI is stored in this segment. The CPU usually writes one word of data into this segment for each queue command to be executed.

Information to be transmitted must be written to transmit data RAM in a right-justified format. The QSPI cannot modify information in the transmit data RAM. The QSPI copies the information to its data serializer for transmission. Information remains in transmit RAM until overwritten.

CR[0:F] — Command RAM $YFFD40

RR0 RR1

RR2

RECEIVE

RAM

RRD RRE RRF

520

53E

Figure 14 QSPI RAM

TRANSMIT

TR0 TR1

TR2

RAM

TRD TRE

TRF

WORD

540

54F

CR0 CR1

CR2

COMMAND

RAM

CRD CRE CRF

BYTEWORD

Freescale Semiconductor, I

7 6543210

CONT BITSE DT DSCK PCS3 PCS2 PCS1 PCS0*

— — — — — — — —

CONT BITSE DT DSCK PCS3 PCS2 PCS1 PCS0*

*The PCS0 bit represents the dual-function PCS0/SS.

Command RAM is used by the QSPI when in master mode. The CPU writes one byte of control information to this segment for each QSPI command to be executed. The QSPI cannot modify information in command RAM.

MC68331TS/D 63

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Command RAM consists of 16 bytes. Each byte is divided into two fields. The peripheral chip-select field enables peripherals for transfer. The command control field provides transfer options.

A maximum of 16 commands can be in the queue. Queue execution by the QSPI proceeds from the address in NEWQP through the address in ENDQP. (Both of these fields are in SPCR2.)

CONT — Continue

0 = Control of chip selects returned to PORTQS after transfer is complete. 1 = Peripheral chip selects remain asserted after transfer is complete.

BITSE — Bits per Transfer Enable

0 = 8 bits 1 = Number of bits set in BITS field of SPCR0

DT — Delay after Transfer

The QSPI provides a variable delay at the end of serial transfer to facilitate the interface with peripherals that have a latency requirement. The delay between transfers is determined by the SPCR1 DTL field.

DSCK — PCS to SCK Delay

0 = PCS valid to SCK transition is one-half SCK. 1 = SPCR1 DSCKL field specifies delay from PCS valid to SCK.

PCS[3:0] — Peripheral Chip Select

Use peripheral chip-select bits to select an external device for serial data transfer. More than one peripheral chip select can be activated at a time, and more than one peripheral chip can be connected to each PCS pin, provided that proper fanout is observed.

— Slave Mode Select

Initiates slave mode serial transfer. If SS is taken low when the QSPI is in master mode, a mode fault will be generated.

5.4.4 Operating Modes

The QSPI operates in either master or slave mode. Master mode is used when the MCU originates data transfers. Slave mode is used when an external device initiates serial transfers to the MCU through the QSPI. Switching between the modes is controlled by MSTR in SPCR0. Before entering either mode, appropriate QSM and QSPI registers must be properly initialized.

In master mode, the QSPI executes a queue of commands defined by control bits in each command RAM queue entry. Chip-select pins are activated, data is transmitted from transmit RAM and received into receive RAM.

In slave mode, operation proceeds in response to SS pin activation by an external bus master. Opera-

Freescale Semiconductor, I

tion is similar to master mode, but no peripheral chip selects are generated, and the number of bits transferred is controlled in a different manner. When the QSPI is selected, it automatically executes the next queue transfer to exchange data with the external device correctly.

Although the QSPI inherently supports multimaster operation, no special arbitration mechanism is provided. A mode fault flag (MODF) indicates a request for SPI master arbitration. System software must provide arbitration. Note that unlike previous SPI systems, MSTR is not cleared by a mode fault being set, nor are the QSPI pin output drivers disabled. The QSPI and associated output drivers must be disabled by clearing SPE in SPCR1.

5.5 SCI Submodule

The SCI submodule is used to communicate with external devices through an asynchronous serial bus. The SCI is fully compatible with the SCI systems found on other Motorola MCUs, such as the M68HC11 and M68HC05 Families.

64 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

5.5.1 SCI Pins

There are two unidirectional pins associated with the SCI. The SCI controls the transmit data (TXD) pin when enabled, whereas the receive data (RXD) pin remains a dedicated input pin to the SCI. TXD is available as a general-purpose I/O pin when the SCI transmitter is disabled. When used for I/O, TXD can be configured either as input or output, as determined by QSM register DDRQS.

The following table shows SCI pins and their functions.

Pin Names Mnemonics Mode Function

Receive Data RXD Receiver Disabled

Transmit Data TXD Transmitter Disabled

5.5.2 SCI Registers

The SCI programming model includes QSM global and pin control registers, and four SCI registers. There are two SCI control registers, one status register, and one data register. All registers can be read or written at any time by the CPU.

Changing the value of SCI control bits during a transfer operation may disrupt operation. Before changing register values, allow the transmitter to complete the current transfer, then disable the receiver and transmitter. Status flags in the SCSR may be cleared at any time.

Receiver Enabled

Transmitter Enabled

Not Used Serial Data Input to SCI

General-Purpose I/O Serial Data Output from SCI

SCCR0 — SCI Control Register 0 $YFFC08

15 14 13 12 0

0 0 0 SCBR

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0

SCCR0 contains a baud rate selection parameter. Baud rate must be set before the SCI is enabled. The CPU can read and write this register at any time.

Bits [15:13] — Not Implemented SCBR — Baud Rate

SCI baud rate is programmed by writing a 13-bit value to BR. The baud rate is derived from the MCU system clock by a modulus counter. The SCI receiver operates asynchronously. An internal clock is necessary to synchronize with an incoming data stream. The SCI baud rate generator produces a receiver sampling clock with a frequency 16 times that of the expected baud rate of the incoming data. The SCI determines the position of bit

Freescale Semiconductor, I

boundaries from transitions within the received waveform, and adjusts sampling points to the proper positions within the bit period. Receiver sampling rate is always 16 times the frequency of the SCI baud rate, which is calculated as follows:

SCI Baud Rate = System Clock/(32SCBR)

SCBR = System Clock(32SCK)(Baud Rate Desired) where SCBR is in the range {1, 2, 3, ..., 8191} Writing a value of zero to SCBR disables the baud rate generator. The following table lists the SCBR settings for standard and maximum baud rates using 16.78-MHz and

20.97-MHz system clocks.

MC68331TS/D 65

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

Table 25 SCI Baud Rates

. nc

Freescale Semiconductor, I

Nominal Baud Rate Actual Rate with

16.78-MHz Clock

64* 64.0 $1FFF — — 110 110.0 $129E 110.0 $1745 300 299.9 $06D4 300.1 $0888 600 599.9 $036A 600.1 $0444

1200 1199.7 $0165 1200.3 $0222 2400 2405.0 $00DA 2400.6 $0111 4800 4810.0 $006D 4783.6 $0089

9600 9532.5 $0037 9637.6 $0044 19200 19418.1 $0016 19275.3 $0022 38400 37449.1 $000E 38550.6 $0011 76800 74898.3 $0007 72817.8 $0009

Maximum Rate 524288.0 $0001 655360.0 $0001

*A rate of 64 baud is not available with a 20.97-MHz system clock. To achieve this rate, the SYNCR can be pro-

grammed to generate a lower system clock rate.

SCCR1 — SCI Control Register 1 $YFFC0A

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

0 0 0 SCBR

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

SCCR1 contains SCI configuration parameters. The CPU can read and write this register at any time. The SCI can modify RWU in some circumstances. In general, interrupts enabled by these control bits are cleared by reading SCSR, then reading (receiver status bits) or writing (transmitter status bits)

SCDR. Bit 15 — Not Implemented LOOPS — Loop Mode

0 = Normal SCI operation, no looping, feedback path disabled

1 = Test SCI operation, looping, feedback path enabled LOOPS controls a feedback path on the data serial shifter. When loop mode is enabled, SCI transmitter output is fed back into the receive serial shifter. TXD is asserted (idle line). Both transmitter and receiver must be enabled before entering loop mode.

WOMS — Wired-OR Mode for SCI Pins

0 = If configured as an output, TXD is a normal CMOS output.

1 = If configured as an output, TXD is an open-drain output. WOMS determines whether the TXD pin is an open-drain output or a normal CMOS output. This bit is used only when TXD is an output. If TXD is used as a general-purpose input pin, WOMS has no effect.

SCBR Value Actual Rate with

20.97-MHz Clock

SCBR Value

ILT — Idle-Line Detect Type

0 = Short idle-line detect (start count on first one)

1 = Long idle-line detect (start count on first one after stop bit(s))

66 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

PT — Parity Type

0 = Even parity

1 = Odd parity When parity is enabled, PT determines whether parity is even or odd for both the receiver and the transmitter.

PE — Parity Enable

0 = SCI parity disabled

1 = SCI parity enabled PE determines whether parity is enabled or disabled for both the receiver and the transmitter. If the received parity bit is not correct, the SCI sets the PF error flag in SCSR. When PE is set, the most significant bit (MSB) of the data field is used for the parity function, which results in either seven or eight bits of user data, depending on the condition of M bit. The following table lists the available choices.

M PE Result

0 0 8 Data Bits 0 1 7 Data Bits, 1 Parity Bit 1 0 9 Data Bits 1 1 8 Data Bits, 1 Parity Bit

M — Mode Select

0 = SCI frame: 1 start bit, 8 data bits, 1 stop bit (10 bits total)

1 = SCI frame: 1 start bit, 9 data bits, 1 stop bit (11 bits total)

WAKE — Wakeup by Address Mark

0 = SCI receiver awakened by idle-line detection

1 = SCI receiver awakened by address mark (last bit set)

TIE — Transmit Interrupt Enable

0 = SCI TDRE interrupts inhibited

1 = SCI TDRE interrupts enabled

TCIE — Transmit Complete Interrupt Enable

0 = SCI TC interrupts inhibited

1 = SCI TC interrupts enabled

RIE — Receiver Interrupt Enable

0 = SCI RDRF interrupt inhibited

1 = SCI RDRF interrupt enabled

ILIE — Idle-Line Interrupt Enable

Freescale Semiconductor, I

TE — Transmitter Enable

0 = SCI IDLE interrupts inhibited

1 = SCI IDLE interrupts enabled

0 = SCI transmitter disabled (TXD pin may be used as I/O)

1 = SCI transmitter enabled (TXD pin dedicated to SCI transmitter) The transmitter retains control of the TXD pin until completion of any character transfer in progress when TE is cleared.

RE — Receiver Enable

0 = SCI receiver disabled (status bits inhibited)

1 = SCI receiver enabled

MC68331TS/D 67

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

RWU — Receiver Wakeup

0 = Normal receiver operation (received data recognized)

1 = Wakeup mode enabled (received data ignored until awakened) Setting RWU enables the wakeup function, which allows the SCI to ignore received data until awakened by either an idle line or address mark (as determined by WAKE). When in wakeup mode, the receiver status flags are not set, and interrupts are inhibited. This bit is cleared automatically (returned to normal mode) when the receiver is awakened.

SBK — Send Break

0 = Normal operation

1 = Break frame(s) transmitted after completion of current frame SBK provides the ability to transmit a break code from the SCI. If the SCI is transmitting when SBK is set, it will transmit continuous frames of zeros after it completes the current frame, until SBK is cleared. If SBK is toggled (one to zero in less than one frame interval), the transmitter sends only one or two break frames before reverting to idle line or beginning to send data.

. nc

SCSR — SCI Status Register $YFFC0C

15 9 8 7 6 5 4 3 2 1 0

NOT USED TDRE TC RDRF RAF IDLE OR NF FE PF

RESET:

1 1 0 0 0 0 0 0 0

SCSR contains flags that show SCI operational conditions. These flags can be cleared either by hardware or by a special acknowledgment sequence. The sequence consists of SCSR read with flags set, followed by SCDR read (write in the case of TDRE and TC). A long-word read can consecutively access both SCSR and SCDR. This action clears receive status flag bits that were set at the time of the read, but does not clear TDRE or TC flags.

If an internal SCI signal for setting a status bit comes after the CPU has read the asserted status bits, but before the CPU has written or read register SCDR, the newly set status bit is not cleared. SCSR must be read again with the bit set. Also, SCDR must be written or read before the status bit is cleared.

Reading either byte of SCSR causes all 16 bits to be accessed. Any status bit already set in either byte will be cleared on a subsequent read or write of register SCDR.

TDRE — Transmit Data Register Empty Flag

0 = Register TDR still contains data to be sent to the transmit serial shifter.

1 = A new character can now be written to register TDR. TDRE is set when the byte in register TDR is transferred to the transmit serial shifter. If TDRE is zero, transfer has not occurred and a write to TDR will overwrite the previous value. New data is not transmitted if TDR is written without first clearing TDRE.

Freescale Semiconductor, I

TC — Transmit Complete Flag

0 = SCI transmitter is busy

1 = SCI transmitter is idle TC is set when the transmitter finishes shifting out all data, queued preambles (mark/idle line), or queued breaks (logic zero). The interrupt can be cleared by reading SCSR when TC is set and then by writing the transmit data register (TDR) of SCDR.

RDRF — Receive Data Register Full Flag

0 = Register RDR is empty or contains previously read data.

1 = Register RDR contains new data. RDRF is set when the content of the receive serial shifter is transferred to the RDR. If one or more errors are detected in the received word, flag(s) NF, FE, and/or PF are set within the same clock cycle.

68 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

RAF — Receiver Active Flag

0 = SCI receiver is idle

1 = SCI receiver is busy RAF indicates whether the SCI receiver is busy. It is set when the receiver detects a possible start bit and is cleared when the chosen type of idle line is detected. RAF can be used to reduce collisions in systems with multiple masters.

IDLE — Idle-Line Detected Flag

0 = SCI receiver did not detect an idle-line condition.

1 = SCI receiver detected an idle-line condition. IDLE is disabled when RWU in SCCR1 is set. IDLE is set when the SCI receiver detects the idle-line condition specified by ILT in SCCR1. If cleared, IDLE will not set again until after RDRF is set. RDRF is set when a break is received, so that a subsequent idle line can be detected.

OR — Overrun Error Flag

0 = RDRF is cleared before new data arrives.

1 = RDRF is not cleared before new data arrives. OR is set when a new byte is ready to be transferred from the receive serial shifter to the RDR, and RDRF is still set. Data transfer is inhibited until OR is cleared. Previous data in RDR remains valid, but data received during overrun condition (including the byte that set OR) is lost.

NF — Noise Error Flag

0 = No noise detected on the received data

1 = Noise occurred on the received data NF is set when the SCI receiver detects noise on a valid start bit, on any data bit, or on a stop bit. It is not set by noise on the idle line or on invalid start bits. Each bit is sampled three times. If none of the three samples are the same logic level, the majority value is used for the received data value, and NF is set. NF is not set until an entire frame is received and RDRF is set.

FE — Framing Error Flag

0 = No framing error on the received data.

1 = Framing error or break occurred on the received data. FE is set when the SCI receiver detects a zero where a stop bit was to have occurred. FE is not set until the entire frame is received and RDRF is set. A break can also cause FE to be set. It is possible to miss a framing error if RXD happens to be at logic level one at the time the stop bit is expected.

PF — Parity Error Flag

0 = No parity error on the received data

1 = Parity error occurred on the received data PF is set when the SCI receiver detects a parity error. PF is not set until the entire frame is received and RDRF is set.

Freescale Semiconductor, I

SCDR — SCI Data Register $YFFC0E

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

0 0 0 0 0 0 0 R8/T8 R7/T7 R6/T6 R5/T5 R4/T4 R3/T3 R2/T2 R1/T1 R0/T0

RESET:

0 0 0 0 0 0 0 U U U U U U U U U

SCDR contains two data registers at the same address. Receive data register (RDR) is a read-only register that contains data received by the SCI. The data comes into the receive serial shifter and is transferred to RDR. Transmit data register (TDR) is a write-only register that contains data to be transmitted. The data is first written to TDR, then transferred to the transmit serial shifter, where additional format bits are added before transmission. R[7:0]/T[7:0] contain either the first eight data bits received when SCDR is read, or the first eight data bits to be transmitted when SCDR is written. R8/T8 are used when the SCI is configured for 9-bit operation. When it is configured for 8-bit operation, they have no meaning or effect.

MC68331TS/D 69

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

6 General-Purpose Timer Module

The 11-channel general-purpose timer (GPT) is used in systems where a moderate level of CPU control is required. The GPT consists of a capture/compare unit, a pulse accumulator, and two pulse-width modulators. A bus interface unit connects the GPT to the intermodule bus.

OC1/PGP3

IC1/PGP0

IC2/PGP1

IC3/PGP2

CAPTURE/COMPARE UNIT

OC2/OC1/PGP4 OC3/OC1/PGP5 OC4/OC1/PGP6 IC4/OC5/OC1/PGP7

. nc

Freescale Semiconductor, I

PULSE ACCUMULATOR

PRESCALER

PWM UNIT

BUS INTERFACE

IMB

Figure 15 GPT Block Diagram

6.1 Overview

The capture/compare unit features three input capture channels, four output compare channels, and one channel that can be selected as an input capture or output compare channel. These channels share a 16-bit free-running counter (TCNT) which derives its clock from a nine-stage prescaler or from the external clock input signal, PCLK.

Pulse accumulator channel logic includes an 8-bit counter; the pulse accumulator can operate in either event counting mode or gated time accumulation mode.

Pulse-width modulator outputs are periodic waveforms whose duty cycles can be independently selected and modified by user software. The PWM circuits share a 16-bit free-running counter that can be clocked by the same nine-stage prescaler used by the capture/compare unit or by the PCLK input.

PAI

PCLK

PWMA PWMB

GPT BLOCK

All GPT pins can also be used for general-purpose input/output. The input capture and output compare pins form a bidirectional 8-bit parallel port (PORTGP). PWM pins are outputs only. PAI and PCLK pins are inputs only.

GPT input capture/output compare pins are bidirectional and can be used to form an 8-bit parallel port. The pulse-width modulator outputs can be used as general-purpose outputs. The PAI and PCLK inputs can be used as general-purpose inputs.

The GPT control register address map is shown below. The “Access” column in the GPT address map indicates which registers are accessible only at the supervisor privilege level and which can be assigned to either the supervisor or user privilege level, according to the value of the SUPV bit in the GPTMCR.

70 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

Access Address 15 8 7 0

S $YFF900 GPT MODULE CONFIGURATION (GPTMCR) S $YFF902 (RESERVED FOR TEST) S $YFF904 INTERRUPT CONFIGURATION (ICR) U $YFF906 PGP DATA DIRECTION (DDRGP) PGP DATA (PORTGP) U $YFF908 OC1 ACTION MASK (OC1M) OC1 ACTION DATA (OC1D) U $YFF90A TIMER COUNTER (TCNT) U $YFF90C PA CONTROL (PACTL) PA COUNTER (PACNT) U $YFF90E INPUT CAPTURE 1 (TIC1) U $YFF910 INPUT CAPTURE 2 (TIC2) U $YFF912 INPUT CAPTURE 3 (TIC3) U $YFF914 OUTPUT COMPARE 1 (TOC1) U $YFF916 OUTPUT COMPARE 2 (TOC2) U $YFF918 OUTPUT COMPARE 3 (TOC3) U $YFF91A OUTPUT COMPARE 4 (TOC4) U $YFF91C INPUT CAPTURE 4/OUTPUT COMPARE 5 (TI4/O5) U $YFF91E TIMER CONTROL 1 (TCTL1) TIMER CONTROL 2 (TCTL2) U $YFF920 TIMER MASK 1 (TMSK1) TIMER MASK 2 (TMSK2) U $YFF922 TIMER FLAG 1 (TFLG1) TIMER FLAG 2 (TFLG2) U $YFF924 FORCE COMPARE (CFORC) PWM CONTROL C (PWMC) U $YFF926 PWM CONTROL A (PWMA) PWM CONTROL B (PWMB) U $YFF928 PWM COUNT (PWMCNT) U $YFF92A PWMA BUFFER (PWMBUFA) PWMB BUFFER (PWMBUFB) U $YFF92C GPT PRESCALER (PRESCL)

$YFF92E–

$YFF93F

Y = M111, where M is the logic state of the modmap (MM) bit in SIMCR.

6.2 Capture/Compare Unit

The capture/compare unit features three input capture channels, four output compare channels, and one input capture/output compare channel (function selected by control register). These channels share a 16-bit free-running counter (TCNT), which derives its clock from seven stages of a 9-stage prescaler or from external clock input PCLK. This section, which is similar to the timer found on the MC68HC11F1, also contains one pulse accumulator channel. The pulse accumulator logic includes its own 8-bit counter and can operate in either event counting mode or gated time accumulation mode. Refer to the following block diagrams of the GPT timer and prescaler.

Table 26 GPT Address Map

NOT USED

MC68331TS/D 71

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, I

PCLK

SYSTEM

CLOCK

PRESCALER – DIVIDE BY

4, 8, 16, 32, 64, 128, 256

1 OF 8 SELECT

CPR2 CPR1

16-BIT TIMER BUS

16-BIT LATCH

TIC1 (HI) TIC1 (LO)

16-BIT LATCH

TIC2 (HI) TIC2 (LO)

16-BIT LATCH

TIC3 (HI) TIC3 (LO)

16-BIT COMPARATOR TOC1 (HI) TOC1 (LO)

16-BIT COMPARATOR TOC2 (HI) TOC2 (LO)

16-BIT COMPARATOR TOC3 (HI) TOC3 (LO)

16-BIT COMPARATOR TOC4 (HI) TOC4 (LO)

16-BIT COMPARATOR

TI4/O5 (HI) TI4/O5 (LO)

16-BIT LATCH CLK

CLK

Freescale Semiconductor, Inc.

CPR0

TCNT (HI) TCNT (LO)

16-BIT FREE RUNNING

COUNTER

IC1F

IC2F

IC3F

OC1F

OC2F

OC3F

OC4F

OC5

I4/O5F

IC4

TOI

TOF

IC1I

IC2I

IC3I

OC1I

FOC1

OC2I

FOC2

OC3I

FOC3

OC4I

FOC4

I4/O5I

FOC5

INTERRUPT REQUESTS

BIT 0

BIT 1

BIT 2

BIT 3

BIT 4

BIT 5

BIT 6

BIT 7

FUNCTIONS

PGP0

IC1

PGP1

IC2

PGP2

IC3

PGP3

OC1

PGP4

OC2/OC1

PGP5

OC3/OC1

PGP6

OC4/OC1

PGP7

IC4/OC5/

OC1

16/32 CC BLOCK

I4/O5

TFLG1

STATUS

FLAGS

CFORC

FORCE OUTPUT

COMPARE

TMSK1

INTERRUPT

ENABLES

PARALLEL PORT

PIN CONTROL

Figure 16 GPT Timer Block Diagram

72 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

SYSTEM CLOCK

Freescale Semiconductor, Inc.

. nc

DIVIDER

÷64

÷32

÷16

÷8

÷4

÷2

PCLK

÷128

÷256

÷512

SYNCHRONIZER AND

DIGITAL FILTER

Figure 17 Prescaler Block Diagram

÷512

EXT.

CPR2 CPR1 CPR0

÷256 ÷128

÷64 ÷32 ÷16

EXT.

÷128

÷64 ÷32 ÷16

EXT.

SELECT

÷8 ÷4

SELECT

÷8 ÷4 ÷2

PPR2 PPR1 PPR0

TO PULSE ACCUMULATOR TO PULSE ACCUMULATOR

TO PULSE ACCUMULATOR

TO CAPTURE/

COMPARE

TIMER

PWM UNIT

GPT PRE BLOCK

Freescale Semiconductor, I

MC68331TS/D 73

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

16-BIT DATA BUS

PWMA REGISTER PWMB REGISTER

PWMABUF REGISTER PWMBBUF REGISTER

"A" COMPARATOR "B" COMPARATOR

PWMA

F1A

BIT

16-BIT COUNTER

FROM

PRESCALER CLOCK

LATCH

ZERO DETECTOR

SFA

BIT

[14:0]

8-BIT

"A" MULTIPLEXER "B" MULTIPLEXER

8-BIT

LATCH

ZERO DETECTOR

SFB

BIT

PWMB

F1B

BIT

16/32 PWM BLOCK BLOCK

Freescale Semiconductor, I

Figure 18 PWM Unit Block Diagram

6.3 Pulse-Width Modulator

The pulse-width modulation submodule has two output pins. The outputs are periodic waveforms controlled by a single frequency whose duty cycles can be independently selected and modified by user software. Each PWM can be independently programmed to run in fast or slow mode. The PWM unit has its own 16-bit free-running counter, which is clocked by an output of the nine-stage prescaler (the same prescaler used by the capture/compare unit) or by the clock input pin, PCLK.

74 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

6.4 GPT Registers GPTMCR — GPT Module Configuration Register $YFF900

15 14 13 12 11 10 9 8 7 6 5 4 3 0

STOP FRZ1 FRZ0 STOPP INCP 0 0 0 SUPV 0 0 0 IARB

RESET:

0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0

The GPTMCR contains parameters for configuring the GPT.

STOP — Stop Clocks

0 = Internal clocks not shut down

1 = Internal clocks shut down

FRZ1 — Not implemented at this time

. nc

FRZ0 — FREEZE Response

0 = Ignore FREEZE

1 = FREEZE the current state of the GPT

STOPP — Stop Prescaler

0 = Normal operation

1 = Stop prescaler and pulse accumulator from incrementing. Ignore changes to input pins.

INCP — Increment Prescaler

0 = Has no meaning

1 = If STOPP is asserted, increment prescaler once and clock input synchronizers once.

SUPV — Supervisor/Unrestricted Data Space

0 = Registers with access controlled by SUPV bit are accessible from either user or supervisor priv-

ilege level.

1 = Registers with access controlled by SUPV bit are restricted to supervisor access only.

IARB — Interrupt Arbitration Field

MTR — GPT Module Test Register (Reserved) $YFF902

This address is currently unused and returns zeros if read. It is reserved for GPT factory test.

Freescale Semiconductor, I

ICR — GPT Interrupt Configuration Register $YFF904

15 12 11 10 8 7 4 3 2 1 0

IPA 0 IPL IVBA 0 0 0 0

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

IPA — Interrupt Priority Adjust

Specifies which GPT interrupt source is given highest internal priority

IPL — Interrupt Priority Level

Specifies the priority level of interrupts generated by the GPT.

IVBA — Interrupt Vector Base Address

Most significant nibble of interrupt vector number generated by the GPT when an interrupt service request is acknowledged.

MC68331TS/D 75

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

DDRGP/PORTGP — Port GP Data Direction Register/Port GP Data Register $YFF906

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 DDGP7 DDGP6 DDGP5 DDGP4 DDGP3 DDGP2 DDGP1 DDGP0 PGP7 PGP6 PGP5 PGP4 PGP3 PGP2 PGP1 PGP0 RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

When GPT pins are used as an 8-bit port, DDRGP determines whether pins are input or output and PORTGP holds the 8-bit data.

DDRGP[7:0] — Port GP Data Direction Register

0 = Input only 1 = Output

Each bit in DDRGP determines whether the corresponding PORTGP bit is input or output.

OC1M/OC1D — OC1 Action Mask Register/OC1 Action Data Register $YFF908

15 11 10 9 8 7 3 2 1 0

OC1M 0 0 0 OC1D 0 0 0

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

All OC outputs can be controlled by the action of OC1. OC1M contains a mask that determines which pins are affected. OC1D determines what the outputs are.

OC1M[5:1] — OC1 Mask Field

0 = Corresponding output compare pin is not affected by OC1 compare. 1 = Corresponding output compare pin is affected by OC1 compare.

OC1M[5:1] correspond to OC[5:1].

OC1D[5:1] — OC1 Data Field

0 = If OC1 mask bit is set, clear the corresponding output compare pin on OC1 match. 1 = If OC1 mask bit is set, set the corresponding output compare pin on OC1 match.

OC1D[5:1] correspond to OC[5:1].

TCNT — Timer Counter Register $YFF90A

TCNT is the 16-bit free-running counter associated with the input capture, output compare, and pulse accumulator functions of the GPT module.

PACTL/PACNT — Pulse Accumulator Control Register/Counter $YFF90C

15 14 13 12 11 10 9 8 7 0

Freescale Semiconductor, I

PAIS PAEN PAMOD PEDGE PCLKS I4/O5 PACLK PACNT

RESET:

U 0 0 0 U 0 0 0 0 0 0 0 0 0 0 0

PACTL enables the pulse accumulator and selects either event counting or gated mode. In event counting mode, PACNT is incremented each time an event occurs. In gated mode, it is incremented by an

internal clock. PAIS — PAI Pin State (Read Only) PAEN — Pulse Accumulator System Enable

0 = Pulse accumulator disabled 1 = Pulse accumulator enabled

76 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

PAMOD — Pulse Accumulator Mode

0 = External event counting 1 = Gated time accumulation

PEDGE — Pulse Accumulator Edge Control

The effects of PEDGE and PAMOD are shown in the following table.

PAMOD PEDGE Effect

0 0 PAI falling edge increments counter 0 1 PAI rising edge increments counter 1 0 Zero on PAI inhibits counting 1 1 One on PAI inhibits counting

PCLKS — PCLK Pin State (Read Only) I4/O5 — Input Capture 4/Output Compare 5

0 = Output compare 5 enabled 1 = Input capture 4 enabled

Freescale Semiconductor, I

PACLK[1:0] — Pulse Accumulator Clock Select (Gated Mode)

PACLK[1:0] Pulse Accumulator Clock Selected

00 System Clock Divided by 512 01 Same Clock Used to Increment TCNT 10 TOF Flag from TCNT 11 External Clock, PCLK

PACNT — Pulse Accumulator Counter

8-bit read/write counter used for external event counting or gated time accumulation.

TIC[1:3] — Input Capture Registers 1–3 $YFF90E, $YFF910, $YFF912

The input capture registers are 16-bit read-only registers which are used to latch the value of TCNT

when a specified transition is detected on the corresponding input capture pin. They are reset to $FFFF.

TOC[1:4] — Output Compare Registers 1–4 $YFF914, $YFF916, $YFF918, $YFF91A

The output compare registers are 16-bit read/write registers which can be used as output waveform

controls or as elapsed time indicators. For output compare functions, they are written to a desired match

value and compared against TCNT to control specified pin actions. They are reset to $FFFF.

TI4/O5 — Input Capture 4/Output Compare 5 Register $YFF91C

This register serves either as input capture register 4 or output compare register 5, depending on the

state of I4/O5 in PACTL.

TCTL1/TCTL2 — Timer Control Registers 1–2 $YFF91E

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

OM5 OL5 OM4 OL4 OM3 OL3 OM2 OL2 EDGE4 EDGE3 EDGE2 EDGE1

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

TCTL1 determines output compare mode and output logic level. TCTL2 determines the type of input

capture to be performed.

MC68331TS/D 77

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

OM/OL[5:2] — Output Compare Mode Bits and Output Compare Level Bits

Each pair of bits specifies an action to be taken when output comparison is successful.

OM/OL[5:2] Action Taken

EDGE[4:1] — Input Capture Edge Control Bits

Each pair of bits configures input sensing logic for the corresponding input capture.

EDGE[4:1] Configuration

00 Timer Disconnected from Output Logic 01 Toggle OCx Output Line 10 Clear OCx Output Line to 0 11 Set OCx Output Line to 1

00 Capture Disabled 01 Capture on Rising Edge Only 10 Capture on Falling Edge Only 11 Capture on Any (Rising or Falling) Edge

Freescale Semiconductor, I

TMSK1/TMSK2 — Timer Interrupt Mask Registers 1–2 $YFF920

15 14 11 10 8 7 6 5 4 3 2 0

I4/O5I OCI ICI TOI 0 PAOVI PAII CPROUT CPR

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

TMSK1 enables OC and IC interrupts. TMSK2 controls pulse accumulator interrupts and TCNT func-

tions. I4/O5I — Input Capture 4/Output Compare 5 Interrupt Enable

0 = IC4/OC5 interrupt disabled 1 = IC4/OC5 interrupt requested when I4/O5F flag in TFLG1 is set

OCI[4:1] — Output Compare Interrupt Enable

0 = OC interrupt disabled 1 = OC interrupt requested when OC flag set

OCI[4:1] correspond to OC[4:1]. ICI[3:1] — Input Capture Interrupt Enable

0 = IC interrupt disabled 1 = IC interrupt requested when IC flag set

ICI[3:1] correspond to IC[3:1]. TOI — Timer Overflow Interrupt Enable

0 = Timer overflow interrupt disabled 1 = Interrupt requested when TOF flag is set

PAOVI — Pulse Accumulator Overflow Interrupt Enable

0 = Pulse accumulator overflow interrupt disabled 1 = Interrupt requested when PAOVF flag is set

PAII — Pulse Accumulator Input Interrupt Enable

0 = Pulse accumulator interrupt disabled 1 = Interrupt requested when PAIF flag is set

CPROUT — Compare/Capture Unit Clock Output Enable

0 = Normal operation for OC1 pin 1 = TCNT clock driven out OC1 pin

78 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

CPR[2:0] — Timer Prescaler/PCLK Select Field

This field selects one of seven prescaler taps or PCLK to be TCNT input.

TFLG1/TFLG2 — Timer Interrupt Flag Registers 1–2 $YFF922

15 14 11 10 8 7 6 5 4 3 2 1 0

I4/O5F OCF ICF TOF 0 PAOVF PAIF 0 0 0 0

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

These registers show condition flags that correspond to various GPT events. If the corresponding inter-

rupt enable bit in TMSK1/TMSK2 is set, an interrupt occurs.

CPR[2:0] System Clock

Divide-By Factor

000 4 001 8 010 16 011 32 100 64 101 128 110 256 111 PCLK

I4/O5F — Input Capture 4/Output Compare 5 Flag

When I4/O5 in PACTL is zero, this flag is set each time TCNT matches the value in TOC5. When I4/O5

in PACTL is one, the flag is set each time a selected edge is detected at the I4/O5 pin. OCF[4:1] — Output Compare Flags

An output compare flag is set each time TCNT matches the corresponding TOC register. OCF[4:1] cor-

respond to OC[4:1]. ICF[3:1] — Input Capture Flags

A flag is set each time a selected edge is detected at the corresponding input capture pin. ICF[3:1] cor-

respond to IC[3:1]. TOF — Timer Overflow Flag

This flag is set each time TCNT advances from a value of $FFFF to $0000. PAOVF — Pulse Accumulator Overflow Flag

This flag is set each time the pulse accumulator counter advances from a value of $FF to $00.

Freescale Semiconductor, I

PAIF — Pulse Accumulator Flag

In event counting mode, this flag is set when an active edge is detected on the PAI pin. In gated time

accumulation mode, PAIF is set at the end of the timed period.

CFORC/PWMC — Compare Force Register/PWM Control Register C $YFF924

15 11 10 9 8 7 6 4 3 2 1 0

FOC 0

RESET:

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

FPWMA FPWMB PPROUT

PPR SFA SFB F1A F1B

Setting a bit in CFORC causes a specific output on OC or PWM pins. PWMC sets PWM operating con-

ditions.

MC68331TS/D 79

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

FOC[5:1] — Force Output Compare

0 = Has no meaning 1 = Causes pin action programmed for corresponding OC pin, but the OC flag is not set.

FOC[5:1] correspond to OC[5:1]. FPWMA — Force PWMA Value

0 = Normal PWMA operation 1 = The value of F1A is driven out on the PWMA pin, regardless of the state of PPROUT.

FPWMB — Force PWMB Value

0 = Normal PWMB operation 1 = The value of F1B is driven out on the PWMB pin.

PPROUT — PWM Clock Output Enable

0 = Normal PWM operation on PWMA 1 = TCNT clock driven out PWMA pin

. nc

Freescale Semiconductor, I

PPR[2:0] — PWM Prescaler/PCLK Select

This field selects one of seven prescaler taps, or PCLK, to be PWMCNT input.

PPR[2:0] System Clock

Divide-By Factor

000 2 001 4 010 8 011 16 100 32 101 64 110 128 111 PCLK

SFA — PWMA Slow/Fast Select

0 = PWMA period is 256 PWMCNT increments long. 1 = PWMA period is 32768 PWMCNT increments long.

SFB — PWMB Slow/Fast Select

0 = PWMB period is 256 PWMCNT increments long.

1 = PWMB period is 32768 PWMCNT increments long. The following table shows the effects of SF settings on PWM frequency for a 16.78-MHz system clock and a 20.97-MHz system clock.

PPR[2:0] Prescaler Tap SFA/B = 0 SFA/B = 1

16.78 MHz 20.97 MHz 16.78 MHz 20.97 MHz 16.78 MHz 20.97 MHz

000 Div 2 = 8.39 MHz Div 2 = 10.5 MHz 32.8 kHz 41 kHz 256 Hz 320 Hz 001 Div 4 = 4.19 MHz Div 4 = 5.25 MHz 16.4 kHz 20.5 kHz 128 Hz 160 Hz 010 Div 8 = 2.10 MHz Div 8 = 2.62 MHz 8.19 kHz 10.2 kHz 64.0 Hz 80.0 Hz 011 Div 16 = 1.05 MHz Div 16 = 1.31 MHz 4.09 kHz 5.15 kHz 32.0 Hz 40.0 Hz 100 Div 32 = 524 kHz Div 32 = 655 kHz 2.05 kHz 2.56 kHz 16.0 Hz 20.0 Hz 101 Div 64 = 262 kHz Div 64 = 328 kHz 1.02 kHz 1.28 kHz 8.0 Hz 10.0 Hz 110 Div 128 = 131 kHz Div 128 = 164 kHz 512 Hz 641 Hz 4.0 Hz 5.0 Hz 111 PCLK PCLK PCLK/256 PCLK/256 PCLK/32768 PCLK/32768

F1A — Force Logic Level One on PWMA

0 = Force logic level zero output on PWMA pin

1 = Force logic level one output on PWMA pin

80 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

F1B — Force Logic Level One on PWMB

0 = Force logic level zero output on PWMB pin

1 = Force logic level one output on PWMB pin

PWMA/PWMB — PWM Control Registers A/B $YFF926, $YFF927

These registers are associated with the pulse-width value of the PWM output on the corresponding PWM pin. A value of $00 loaded into one of these registers results in a continuously low output on the corresponding pin. A value of $80 results in a 50% duty cycle output. Maximum value ($FF) selects an output that is high for 255/256 of the period.

PWMCNT — PWM Count Register $YFF928

PWMCNT is the 16-bit free-running counter associated with the PWM functions of the GPT module.

PWMBUFA/B — PWM Buffer Registers A/B $YFF92A, $YFF92B

These read-only registers contain values associated with the duty cycles of the corresponding PWM. Reset state is $0000.

Freescale Semiconductor, I

PRESCL — GPT Prescaler $YFF92C

The 9-bit prescaler value can be read from bits [8:0] at this address. Bits [15:9] always read as zeros. Reset state is $0000.

MC68331TS/D 81

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

7 Summary of Changes

This is a complete revision, with complete reprint. All known errors in the publication have been corrected. The following summary lists significant changes. Typographical errors that do not affect content are not annotated.

Page 2 Revised ordering information. Page 5 New block diagram drawn. Page 6 New 132-pin assignment diagram drawn. Page 7 New 144-pin assignment diagram drawn. Page 8 New address map drawn. Page 9-13 Added Signal Description section.

. nc

Page 14-46 Expanded and revised SIM section. Made all register diagrams and bit mnemonics

consistent. Incorporated new information concerning the system clock, resets, interrupts, and chip-select circuits.

Page 47-55 Expanded and revised CPU section. Made all register diagrams and bit mnemon-

ics consistent. Revised instruction set summary information.

Page 56-76 Expanded and revised QSM section. Made all register diagrams and bit mnemon-

ics consistent. Added information concerning SPI and SCI operation.

Page 77-89 Expanded and revised GPT section. Made all registerdiagrams and bit mnemonics

consistent. Added information concerning input capture, output compare, and PWM operation.

Freescale Semiconductor, I

82 MC68331TS/D

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Freescale Semiconductor, I

MC68331TS/D 83

For More Information On This Product,

Go to: www.freescale.com

. nc

Freescale Semiconductor, Inc.

Freescale Semiconductor, I

For More Information On This Product,

Go to: www.freescale.com

MC68331TS/D

Freescale MC68331 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
