Freeman Speak T100 User Manual

Important security measures

PARTS THAT CAN BE REPAIRED BY THE USER NOT INCLUDED.
FOR SERVICE CONSULT QUALIFIED PERSONNEL

Symbol with lightning flash with arrowhead, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage inside the
product that may be of sufficient magnitude to
constitute a risk of electric shock.

Exclamation point within an equilateral triangle is
intended to alert the user to the presence instructions
for use and maintenance (servicing) instructions in the
literature accompanying the appliance.

WARNING: TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTION: TO PREVENT RISK OF ELECTRIC SHOCK MAKE SURE THE PLUG IS
INSERTED INTO THE WALL OUTLET.

Legal Statements

We reserve the reight to modify or eliminate any content in this manual at any
momrent. We do not guarantee and assume any legal liability or responsibility
for the accuracy, completeness or use of this manual. The content of this manual
can be modified without any notice in advance.
The screenshots used in this manual are for illistrative purpose only and can not
be representative for the real product.

Reccomendations

• AVOID DUSTY LOCATIONS: Excessive dust accumlation may cause
malfunctions.

• DO NOT EXPOSE TO MOISTURE: Exposing the unit to water presents a high
risc of electrocution.

• DO NOT DROP OR SUBJECT TO SHOCK: Dropping the product might damage
the internal components.

• DO NOT OPEN THE COVER: Inside are pieces that cannot be fixed by the user.

Please read this manual carefully to guarantee that you can use the mobile
phone optimally.

Getting started

Battery

Use only original approved batteries and recharge the battery only with the
original approved charger designated for this device. The use of an
unapproved battery or charger may present a risk of fire, explosion, leakage or
other hazards.

Connecting to the network

You must insert one or two valid SIM cards before using your mobile phone.
The connection settings, contacts and messages are saved in the SIM cards. Do
not touch the metal surface area and keep the SIM cards away from electricity
and magnet fields to avoid losing or damaging the information saved in them.

To install or remove the SIM cards, first switch off the phone, then remove the
battery and the external power supply, then insert the SIM cards with the gold
contacts facing down in the position indicated on the SIM card slot.

Switching on/off

Long press END KEY to switch on/off your device. It will automatically test
whether you have inserted SIM cards or not and prompt you to do so. If SIM
cards are installed, it will prompt you to enter the PIN code.

Settings

Press the Menu key to open the device’s main menu, then navigate to the

Settings icon and press the OK button (in the center of the directional keys) to
open the Settings menu.

Phone settings

1. Time and Date
Press the Up and Down direction keys to set the city. Press the Left and Right
direction keys to set the date format, the time format, and the time.

Note: If you remove the battery from the mobile phone or if the battery was
drained completely a long time ago, you may need to reset the time and date
when re-inserting the battery or powering on the mobile phone after recharging.

2. Schedule power on/off
Set the time when the mobile phone will be automatically powered on or off.

3. Language
Select the display language for the mobile phone.

4. Preferred input methods
Set the preferred input methods for the device according to your preferences.

5. Display characteristics
Set wallpaper, screen saver, power on image/animation, power off
image/animation, show date and time and/or show other number. Set LCD
backlight timeout or brightness.

6. Greeting text
Used to show a specific message on the screen when the phone is powered
on. You can set it to On or Off and customize the message.

Menu Description

Phone book

This allows you to save information like names and phone numbers. The phone
numbers can be saved to your device or the SIM cards. For the SIM cards the
quantity of the records depends on the capacity of the cards. To view the
phone book, press the right soft key in standby mode.

Messages

Access the Message menu and you will find entries as SMS, MMS, Chat and so
on.

Call history

To view information about call records, select Call History in the Main Menu.
The entries include Missed Calls, Received Calls, Delete Call Logs, Call Time,
Call Cost, SMS Counter, GPRS Counter.

Settings

Select Settings in the Main Menu, then you can perform Phone Setup, Call
Setup, Network Setup, Security Setup and Restore Factory Settings.

Multimedia

File Manager

The phone provides a certain space for users to manage files and supports a
Micro SD card. You can use the file manager to conveniently manage various
files on the phone and the Micro SD card. Choose File Manager>Options or
press the Left soft key to perform the operations. You can choose File
manager>Options>Format to format all the data in the memory. The system
will then re-create the default folders. The formatted data cannot be
recovered, therefore think twice before formatting.

Image viewer

Access the submenu, and you can view the list consisting of the images
captured with the device camera. Press Options to choose View, Browse styles,
Forward, Rename, Delete, Delete all files, Sort, Storage.
Specifically, the images can be forwarded to wallpaper, screen saver, power on
display, power off display, phone book. The successful MMS forwarding
depends on factors like the size of the screen.

Sound recorder

The sound file saved in FILES/MEMORY CARD/AUDIO are listed in the
submenu. Press the left soft key, Options, to show the options menu.

FM Radio

To listen to FM Radio you first need to connect the earphones. In the FM Radio
interface press Up key to enable/disable auto mode of FM radio; press Down
key to switch on/off FM radio; press Left key to tune forward; press Right key
to tune backwards.

Audio player

The audio player provides four buttons: Play, Stop, Back, and Forward. You can
press Up or Down key to go to the previous or next song, and the Left or Right
key to adjust the sound volume. The audio player supports Mp3, WAV, MIDI,
and IMY formats. Press the Left key or select List to open the play list and then

choose Options to perform the following operations: Play, Detail, Add to ring,
Refresh list, Settings.

Video player

With the video player you can play video files, forward video files, rename
video files, delete a video file, delete all video files, sort video files by name,
type, or size, and specify the path for saving video files.
Play the selected video file.
Forward: forward the current video file to the phonebook, screensaver, power
on animation, power off animation, or Bluetooth.
Rename: Rename the selected video file.
Delete: Delete the selected video file.
Delete all files: Delete all video files.
Sort by: Sort video files by name, type, time, or size.
Storage: Select whether to save the video files in the Phone or Micro SD card
memory.

Camera

Select Options to perform the following operations:
Photos: It saves the image files for photo. You can view images, set the
browsing style, forward images, rename, delete images, delete all images, sort
images by name, type, time, or size, and specify the path for saving images.

Camera settings: You can set the shutter sound, EV, banding, delay timer and
continuous shot, so that the camera operates in good condition and produces
the optimal photo-taking effect.
Image settings: Set the image size and image quality. You can press the
numerical key “7” to quickly set the image quality and numerical key “8” to
quickly set the image size.
White balance: Set it to Auto, Daylight, Tungsten, Fluorescent, Cloud, or
Incandescence.
Scene mode: Set it to Auto or Night.
Effect settings: Set it to Normal, Grayscale, Sepia, Sepia green, Sepia blue, or
Color invert.
Storage: Select where to save photos – phone memory or Micro SD card.
Restore default: Restore settings to their default values.

Fun and games

Some games are embedded in the mobile phone. For details, refer to the
operation instructions of the installed games.

Profiles

With this function you can set different profiles to adapt to different
environments. There are five preset profiles available, each of them with its
own default value that you can fully customize.

General

Activate: Activate the chosen profile.
Settings: Set the following options as required.
Ring set: Set the call ring or message ring for SIM1 and SIM2.
Adjust volume: Adjust the volume of incoming calls, messages etc. Press the
navigation keys to adjust the volume.
Call alert: Set the desired call tone mode for SIM1 and SIM2.
Message alert: Set the desired message tone for SIM1 and SIM2.
Alarm remind: Set the desired alarm reminding mode.
Keypad tones: set the desired Keypad tones.
Battery low alert: Turn the low battery alert tone on or off.
Rename: Modify the name of the selected profile.

Meeting

For settings, please refer to “General”.

Outdoor

For settings, please refer to “General”.

Indoor

For settings, please refer to “General”.

Organizer

You can use various daily tools like Bluetooth, Calendar, Alarm Clock, Unit
Converter and Currency Converter.

Bluetooth

Open/Close Bluetooth: This function allows you to switch the Bluetooth on or
off.
Bluetooth visibility: Set to show or hide the Bluetooth of your phone. If you

select to hide the phone, other devices cannot detect your phone’s Bluetooth,

even if it is activated.
Paired devices: You can search for the nearby Bluetooth devices.
My Bluetooth: The name of your phone when another Bluetooth device is
searching for it.

Calendar

In the submenu, the screen displays the calendar for the current month and
the actual date is marked with a frame. To view the date, press the
Up/Down/Left/Right key.

Alarm

Three alarm clocks are set but deactivated by default. You can activate each
one of them individually. For each alarm you can set the ringing time and day.
When the alarm is ringing you can select Stop to stop the ringing or Snooze to
postpone the alarm for a set number of minutes. The phone will ring even if it
