Freedom Zed 5 Tier Modular Shelving Assembly Instruction

Assembly Instructions

Zed 5 Tier Modular Shelving

Before you begin to assemble your new piece of furniture, please check to ensure that all parts have been supplied.

Follow instructions closely as deviation from them may void your warranty and present a possible safety risk.

It is recommended that assembly is done on a soft surface like carpet to avoid any damage.

If you experience any problems with your new purchase please phone Freedom Customer Service (FCS) on 1300 135 588
(Customers outside Australia should contact their closest Freedom store.)

Care Information:

Periodically check and re-tighten all fasteners. Wipe down all surfaces using a clean cloth weekly. Never clean with harsh
abrasives or chemicals.

The glass used in this product is known as tempered glass. Although it is up to four times tougher than regular glass, it is not

unbreakable. Tempered glass should be cared for like normal glass. Careless handling or use sometimes produces damage
which may not be visible to the eye. Damaged glass may spontaneously shatter if subjected to thermal or mechanical stress.

Avoid dropping objects on the glass. Do not allow hard or pointed objects to come into contact with the glass.
Do not clean glass with substances containing abrasives as these can scratch the glass.

Wall Fixing Hardware for 5 Tier Panels:

For enhanced stability, Zed 5 Tier Panels come with hardware to secure it against the wall.

The fixing hardware supplied is suitable for masonry walls only. Please consult your local hardware store if you have a different
wall type. To install the wall - fixing hardware, a power drill is required.

.

.

Hardware and Components

Zed Shelving Glass Packs

Page 1

Zed 5 Tier Shelf Pack

Assembly Instructions

Zed 5 Tier Modular Shelving

Hardware and Components cont

Zed 5 Tier Side Panel (5SP)

Part A x 20 5SP Part B x 20 Part C x 4 Part D x 4 Part E x 20 Part F x 20 Part G x 1

5SP Part H x 2 5SP Part I x 2 5SP Part J x 2

5SP Part K x 1

(Left Hand)

5SP Part L x 1

(Right Hand)

Part M x 10 Part N x 1

Zed 5 Tier Extension Panel (5EP)

Part A x 20 5EP Part B x 10 Part C x 4 Part D x 4 Part E x 20 Part F x 20 Part G x 1

5EP Part H x 1 Part I x 10 Part J x 1

Page 2

Assembly Options

Zed 5 Tier Side Panel
+
Zed Glass Shelves 5 Tier

Assembly Instructions

Zed 5 Tier Modular Shelving

=

4

Zed 5 Tier Side Panel
+
Zed 5 Tier Extension Panel =
+
Zed Glass Shelves 5 Tier x 2

Multiple Zed 5 Tier Extensions

7

11

Page 3

Step 1 of 5

3 8

5SP Part B

Assembly Instructions

Zed 5 Tier Side Panel

x 20

Part A

Step 2 of 5

5SP Part K

Part M

5SP Part L

Part D

x 4

Part C

Part G

Part N

Page 4
