Freedom Easel TV Stand Assembly Instruction

Assembly Instructions

Easel TV Stand

Page 1

Care Information

Hardware

Parts

Before you begin to assemble your new tv stand, please check to ensure that all parts have been supplied.

Follow instructions closely as deviation from them may void your warranty and present a possible safety risk.

It is recommended that assembly is done on a soft surface like carpet to avoid any damage.

If you experience any problems with your new purchase please phone our Customer Service Hotline [phone]
(Customers outside Australia should contact their closest Freedom store.)

12xPart A

1xPart G

1xPart L

1xPart N

1xPart O

1xPart P

1xPart B

1xPart C

2xPart D

2xPart E

1xPart F

Periodically check and re-tighten any fasteners. Wipe down all surfaces weekly with a clean cloth. Do not clean any surfaces with
harsh abrasives or chemicals.

1xPart H

2xPart I

2xPart J

2xPart K

1 x Spacer X

1 x Spacer Y

small

small

large

large

1xPart M

Assembly Instructions

Easel TV Stand

Page 2

Step: 1

Step: 3

Step: 2

Part L

Part E

Part C

Part O

Part D

Part N

Part G

Part H

Part B

Part B

Part A

Part A

Part J

Part I

Assembly Instructions

Easel TV Stand

Page 3

Finished:

Step: 4

Part F

release wing nuts to install part F

Part P

Cable organizer

Part B

Part A

Part K

Part M

Assembly Instructions

Easel TV Stand

Page 4

STEP 1.

Adjust desired view ing height ( refer to options provided below )

TO INSTALL TV TO EASEL TV STAND

Part H

Part G

This step may require 2 people.
Never adjust height w ith TV on stand.

!

Assembly Instructions

Easel TV Stand

Page 5

STEP 3.

STEP 2.

a.

a.

b.

Extend a. b. c. to the maximum as arrows indicated

fasten up wing nuts to ax b.

fasten knob to ax a.

adjust knob to desired angle

Fasten tight

Carefully place TV onto stand ( ensure TV is
always held by at least one person ).
Adjust a.b.c. in the direction as arrows indicated
and fasten tight a.b.c. as indicated in diagram

c.

c.

c.

b.

b,

c.

Part B

This step will require 2 people.

!

Assembly Instructions

Easel TV Stand

Page 6

1

2

3

3

SPACER ( parts “ X ” )

Cut to size required

For TV thickness more than 7cm
to maximum 13cm

For TV thickness less than 7cm
add spacer ( parts “Y” )

PLATFORM

PLATFORM

TV

TV

TV

SPACER

For TV thickness
more than 10cm

For TV thickness less
10cm, spacer is required

SPACER

7cm

7cm

7cm

(not included)
