Mitsubishi Chemical Holdings Group www.freecom.comwww.facebook.com/freecom 1 / 3
Designed by Arman Emami
THE MOBILE HARD DRIVE DESIGNED FOR USB RECORDING
USB recording - record TV programmes directly from your TV to an external hard drive**, connected to a USB port on your TV. More and more
TVs have this feature enabled. Why not make full use of it? And when you do, why not use a uniquely designed external hard drive which looks
stunning next to your TV? The Mobile Drive Sq TV has it all. Looks and performance. For your convenience it also comes with a cradle with
which you can fix the Mobile Drive Sq to the back of your TV, should you want to keep it out of sight.
Designed by acclaimed industrial designer Arman Emami from Germany, the Mobile Drive Sq TV features a unique organic design, like nothing
you’ve ever seen before. Smooth lines and a square form factor. To make it less susceptible to scratches and fingerprints, the Mobile Drive
Sq TV’s enclosure cover is made from sandblasted stainless steel. In short - the Sq is guaranteed to turn some heads! The drive can of course
also be used as a standard external hard drive. The Mobile Drive Sq TV boasts the latest USB 3.0 interface, ensuring ultra fast transfer speeds
compared to standard USB 2.0. The drive is fully downwards compatible with older USB 2.0 ports, so you can use it on any computer and
be ready for the future at the same time! The Mobile Drive Sq TV is powered by the USB port, no need for additional long cables or power
adapters. If you’re looking for an exclusive looking hard drive with matching performance and ultimate portability features, look no further the Mobile Drive Sq TV is the drive to have!
FREECOM MOBILE DRIVE Sq TV
• Mobile hard drive in stylish organic design
• Ideal for use as recording media for TV programmes**
• High quality enclosure with stainless steel cover
• Also available in slimline version, only 1.05 cm thin!
• Including cradle to fix the Mobile Drive Sq to the back of your TV
• USB 3.0 for ultra fast data transfer speed. Can also be connected to USB 2.0 ports
• Including compact sized USB cable
• Power provided by the USB port, no need to carry a bulky power adapter
• No cooling fan – ensures quiet operation at all times
• Can also be used as standard external hard drive - the perfect storage expansion for your notebook or desktop computer
• Including Nero backup software, Green Button power consumption application and FHD Formatting tool
• Two years manufacturer’s warranty and unlimited free helpdesk support
MOBILE DRIVE Sq TV
MOBILE HARD DRIVE / 2.5” / USB 3.0
UNIQUE DESIGN
WITH STAINLESS STEEL COVER
INCLUDING
FREE
TV CRADLE
Page 2
Mitsubishi Chemical Holdings Group
www.freecom.com
www.facebook.com/freecom 2 / 3
USB RECORDING
USB Recording enables you to record digital
TV programmes to an external storage device
directly connected to your TV via USB**.
Your external HDD basically acts as a videorecorder, and can replace your current HDD/
DVD recorder. You can also use it to pause live
TV. Most new TVs now offer USB recording
functionality. The Mobile Drive Sq TV is the
first external hard drive dedicated to USB
recording. With the included cradle you can
easily fix the drive to the back of your TV.
IT’S ALL ABOUT DESIGN
There is nothing standard about the Mobile
Drive Sq’s design. Flowing lines, rounded
edges, and a square form factor. This drive
really stands out from the crowd! Designed
by Arman Emami, winner of numerous
industrial design awards. The uniqueness of
the Mobile Drive Sq predominantly lies in its
shape. Rather than your standard external
hard drive box, this drive has an almost
square form factor and features organic
shapes with rounded edges.
STAINLESS STEEL
To prevent the drive from scratches and
fingerprints, the Mobile Drive Sq’s enclosure
cover is made out of stainless steel. The
surface has been sandblasted to give it an
exclusive look and feel. It will look stunning
next to your notebook!
Page 3
Mitsubishi Chemical Holdings Group www.freecom.comwww.facebook.com/freecom 3 / 3
REV1238/21092012/PWCN
12 cm
12 cm
1.05 cm
Tested to comply with
FCC standards for
home and office use
PRODUCT SPECIFICATIONS
CAPACITY: 500GB , 1TB
INTERFACE: USB 3.0, also connects to USB 2.0*
HARD DRIVE TYPE: 2.5” SATA, low noise, low power consumption
DATA TRANSFER SPEED: max. 5000 Mbit/s (USB 3.0), theoretical maximum data transfer speed
POWER REQUIREMENTS: power via USB port, no power adapter required
MTBF: 50.000 POH
ENCLOSURE: stainless steel cover, pvc frame
TV CRADLE: pvc frame, can be fixed to the back of a TV with a screw or with double sided adhesive tape
DIMENSIONS: 12 x 12 x 1.05 cm (slimline) / 12 x 12 x 1.3 cm
WEIGHT: 195 g (slimline) / 210 g
ENVIRONMENTAL SPECIFICATIONS:
Operating temperature: 10° C / 35° C
Storage temperature: -20° C / 70° C
MINIMUM SYSTEM REQUIREMENTS
PC: Intel Pentium III / AMD Duron 900 MHz or higher, 256MB RAM (Vista: 512MB RAM) or higher, available USB 3.0 or USB 2.0* port,
Windows XP / Vista / 7
MAC: PowerPC G3/G4/G5, Power Book G3/G4 or Intel Mac, 256MB RAM or higher, available USB 2.0 port*, Mac OS X v10.4.8 or higher
* When connected to USB 2.0, the data transfer speed will be according to USB 2.0 specification.
** For recording digital programmes from a TV to the drive, a TV is required that supports USB recording. Please refer to your TV’s user manual. Please note that
your TV will reformat the drive and that it can then only be used for recording from that particular TV. It is not possible to view recorded programmes from the
HDD on another TV or a computer. USB recording is not available in the USA.
PACKAGE INCLUDES
• Freecom Mobile Drive Sq TV • Quick Install Guide
• TV mounting cradle • Free unlimited helpdesk support
• USB 3.0 connection cable • Two years manufacturer’s warranty
MOBILE DRIVE Sq TV
500GB (slimline) 1TB
Art.-Nr. 56155 56156
EAN-Code 4021801561558 4021801561565
Colour Silver / Black Silver / Black
Freecom is a Mitsubishi Kagaku Media company. Freecom and the logo are trademarks of Freecom BV.
All other names are trademarks of their respective owners.
Errors and omissions excepted.
FREECOM
QUALITY
WHAT WILL IT HOLD
500GB 750GB 1TB 1.5TB
MP3 songs 100.000 150.000 200.000 300.000
JPEG pictures 330.000 500.000 660.000 1.000.000
DVD movies 110 165 220 330
DivX/Xvid movies 500 750 1.000 1.500
Since 19 89 Freecom stan ds for
creating innovative and profe ssional
digital (storag e) solut ions. Al l Freecom product s are
designe d, engine ered and certifie d in G ermany a ccording
to the hig hest qualit y standards to g uarantee cust omer
satisfa ction. O ur in-hou se techni cal develo pment pro cess,
the use of the hig hest quality com ponents and Germ an
product inspec tion sta ndards e nsure sup erior q uality a nd
reliabi lity. To meet the high exp ectations of profes sional
users Fre ecom product s are delive red with ext ensive
warrant y and unlim ited free h elpdesk sup port.
Definitions: 1GB = 1000MB – 1 MP3 song = approx. 5MB / 1 JPEG
photo = approx. 1.5MB / 1 DVD movie = approx. 4.5GB / 1Xvid/DivX
movie = approx. 1GB.
Some of the hard drive capacity is used for pre-loaded software,
formatting and other functions, and thus is not available for data
storage. As a result, your operating system may report fewer
gigabytes/terabytes.
