F605

Headphone Amplifier

(Can Amp)

Operating Manual

Fredenstein F605 Headphone Amplifier

The F605 is a high performance professional headphone amplifier, offering an effective headphone
volume control for live or studio applications out of a Fredenstein Bento rack. The F605 features
balanced inputs, extended signal manipulation and a low output impedance to connect headphones
from 20 Ohms to 600 Ohms.

As all Fredenstein products, the F605 is designed by a German-American team and manufactured in
Taiwan.

Overview:

LED Indicators:

PWR : A green LED indicates presence of power
CLIP : A red CLIP indicator turns on at 2db below

clipping output level

Rotary Controls:

Volume : Volume control

Switches:

L<->R : flips the channels, left on right ear, right on left

ear

L CH : Both sides are reproducing the left channel only
R CH : Both sides are reproducing the right channel

only
if L CH and R CH are activated a mono signal is
reproduced on both sides

L POL : Selects the phase of the left channel
R POL : Selects the phase of the right channel

Connector:

Headphones : Unbalanced Stereo headphone output (TRS)
