Clarity, elegance and harmony of material and form
are the factors that characterise today’s approach
to design. There is a growing feeling that even
objects destined for daily use should offer looks
that measure up to their advanced functionality.
SANITARY
ACCESSORIES
STRATOS
Product features:
Striking design -
Material thickness 1.5mm/2mm -
Satin finished brushed surface -
Surface mounted and recessed models available -
Safety lock with Franke standard key -
Dynamic profile -
Custom made sizes possible -
Mounting kit included -
Functional characteristics: -
- Self-closing lid
- Automatic loading of second roll of toilet paper after the first roll is finished
- Bag retainer
Description Page
Description Page
Dispensers 4, 5, 6, 7, 9
Hand Dryers 5
Waste Bins 6, 7
Toilet Roll Holders 8
Toilet Brush Holder 9
Shelves 9
Hooks 10
Pictograms 10
Recessed Dispensers 10-13
Picture / Diagram Code / Description
All dimensions in mm
4
Soap Dispensers STRATOS
Wall Mounted Soap Dispenser
Surface mounted soap dispenser, manufactured from grade EN 1.4301 (304)
stainless steel - satin polish finish, material thickness 1.2/1.5mm. The soap
dispenser incorporates a replaceable and refillable 1 litre - container which is
suitable for liquid soaps and lotions and is fitted with a cylinder lock with Franke
standard key. Screws and dowels included.
100x134x304
STRX618
Extras:
SO1L
Liquid soap (minimum order quantity is 6 bottles)
SO10L
Liquid soap in a canister, 10l
Wall Mounted Soap Dispenser
Surface mounted soap dispenser, manufactured from grade EN 1.4301 (304)
stainless steel - satin polish finish, material thickness 1.2/1.5mm. Screws and
dowels included.
186x92x154
STRX619
Extras:
SO1L
Liquid soap (minimum order quantity is 6 bottles)
SO10L
Liquid soap in a canister, 10l
Electronic Soap Dispenser
Electronic soap dispenser for wall mounting, made of stainless steel, surface satin
finished, material thickness 1.2/1.5mm, stainless steel lock with Franke standard
key, infrared sensor activity for non-touch operation, automatic power shut-off
during opening, includes six 1.5V (= 9V) Alkaline AA batteries, suitable for liquid
and antiseptic soaps and lotions, 800ml refillable bottle, depending on used soap
between 0.6 and 1.1ml is dispensed, incl. stainless steel screws and dowels.
116x128x303
STRX625
Extras:
SO1L
Liquid soap (minimum order quantity is 6 bottles)
SO10L
Liquid soap in a canister, 10l
Picture / Diagram Code / Description
All dimensions in mm
5
Hand Dryer, Dispensers STRATOS
Hand Dryer
Touch free controlled hand dryer for wall mounting, electronic warm air hand
dryer, made of stainless steel, surface satin finished, material thickness 1.5mm,
curved front cover, Infrared sensor activity for non-touch operation, sensor range
adjustable from 50 to 330mm, automatic power shut-off after 60 seconds, due to
the extreme high adjustable air velocity the drying time is significantly reduced
although the blower output is not that high, cable and plug not included.
Electrical data: 230V, 50Hz
Total output: 1500W
Heating: 800W
Motor: 700W
Blower output: 120m³/h
Air velocity: 75-110 m/s
300x197x305
STRX210
Paper Towel / Soap Dispenser Combination
Surface mounted paper towel and soap dispenser combination, manufactured
from grade EN 1.4301 (304) stainless steel - satin polish finish, material
thickness 1.2/1.5mm. The paper towel dispenser has a capacity of 300 - 400
towels depending on the type and their folding. Soap dispenser incorporates a
replaceable 1 litre container and is fitted with cylinder lock with Franke standard
key. Screws and dowels included.
Suitable for paper towels:
min: 240x85
max: 250x105
ideal: 250x95
396x134x304
STRX601
Extras:
FH68
Paper towels (168 pieces)
Paper Towel Dispenser
Surface mounted paper towel dispenser, manufactured from grade EN 1.4301
(304) stainless steel - satin polish finish, material thickness 1.2/1.5mm. Includes
cylinder lock with Franke standard key. The paper towel dispenser has a capacity
of 300 - 400 towels depending on the type and their folding. Screws and dowels
included.
Suitable for paper towels:
min: 240x85
max: 250x105
ideal: 250x95
300x134x304
STRX600
Extras:
FH68
Paper towels (168 pieces)
Picture / Diagram Code / Description
All dimensions in mm
6
Dispensers, Waste Bins STRATOS
Touch Free Controlled Paper Towel Dispenser
Touch free controlled paper towel dispenser for wall mounting, stainless steel,
surface satin finished, material thickness 0.8mm, curved front cover, cylinder
lock with Franke standard key, Infrared sensor activity for non-touch operation,
integrated tear-off edge, needs four pieces standard D 1.5V batteries, maintenance
free mechanic and easy paper roll change mechanism, for rolls with max. width
210mm and max. diameter 220mm, paper length adjustable to 200, 250 and
300mm, incl. stainless steel screws and dowels.
300x234x380
STRX630
Paper Roll Box With Centre Feed
Centre feed paper roll box for wall mounting, stainless steel, surface satin finished,
material thickness 1.5mm, soft edges, cylinder lock with Franke standard key,
integrated stress relief for paper, for rolls max. Ø 190mm and max. height 220mm,
incl. stainless steel screws and dowels.
220x300x200
STRX635
Waste Bin
Surface mounted waste bin, manufactured from grade EN 1.4301 (304) stainless
steel - satin polish finish, material thickness 1.2/1.5mm. The container has an
approx. 34 litre capacity and is fitted with a Franke cylinder lock with Franke
standard key. Screws and dowels included.
300x270x520
STRX605
Waste Bin
Surface mounted waste bin, manufactured from grade EN 1.4301 (304) stainless
steel - satin polish finish, material thickness 1.2/1.5mm. The container has an
approx. 45 litre - capacity and is fitted with a cylinder lock with Franke standard
key. Screws and dowels included.
396x270x520
STRX607
Picture / Diagram Code / Description
All dimensions in mm
7
Waste Bins, Dispensers STRATOS
Lid (suitable for waste bin)
Lid to waste bin STRX607, manufactured from grade EN 1.4301 (304) stainless
steel - satin polish finish, material thickness 1.2/1.5mm. Cylinder lock with Franke
standard key, delivery without waste bin STRX607.
396x270x680 (including waste bin STRX607)
STRX608
Sanitary Towel Disposal Bin
Surface mounted sanitary towel disposal bin, manufactured from grade EN 1.4301
(304) stainless steel - satin polish finish, material thickness 1.2/1.5mm. The
disposal bin incorporates a plastic container with a 6 litre capacity and is for the
disposal of sanitary towels and minor waste and has a stainless steel continuous
piano hinge. Screws and dowels included.
205x134x304
STRX611
Hygienic Bag Dispenser
For wall mounting, chrome-nickel steel, surface satin finished, material thickness
1.2mm, circular opening for removal of hygienic bags, corners not welded, incl.
fixing material and premounted double sided self adhesive tape on the back, incl.
acetone rag for surface to be cleaned.
150x92x22
HBD191
Face Towel Dispenser
Surface mounted face towel dispenser, manufactured from grade EN 1.4301 (304)
stainless steel - satin polish finish, material thickness 1.2/1.5mm. For use with
face towel packs. Screws and dowels included.
300x65x160
STRX650
Picture / Diagram Code / Description
All dimensions in mm
8
Toilet Roll Holders STRATOS
Jumbo Toilet Roll Holder
Surface mounted toilet roll holder, manufactured from grade EN 1.4301 (304)
stainless steel - satin polish finish, material thickness 1.2/1.5mm. Screws and
dowels included.
305x171x355
STRX670
Toilet Roll Holder
Surface mounted toilet paper roll holder, manufactured from grade EN 1.4301
(304) stainless steel - satin polish finish. Takes 2 rolls with maximum Ø 108mm ,
the reserve roll is not visible and drops automatically into the dispensing position
by tipping up the tongue. Fitted with cylinder lock with Franke standard key.
Screws and dowels included.
170x166x343
STRX671L
Toilet Roll Holder with Spindle System
Wall mounted toilet roll holder with spindle system. Manufactured from grade
EN 1.4301 (304) stainless steel - satin polish finish, material thickness 1.2/1.5mm.
For 2 rolls max. Ø 108mm, the reserve roll is not visible and drops automatically
into the dispensing position after finishing of the first roll. Cylinder lock with Franke
standard key. Screws and dowels included.
156x140.7x304
STRX672
Toilet Roll Holder
Wall mounted toilet paper roll holder with lid made of 0.9mm thick stainless steel;
satin finished. The dispenser takes one roll with a maximum 130mm Ø. Screws
and dowels are included.
145x25x130
BS677
Picture / Diagram Code / Description
All dimensions in mm
9
Dispenser, Brush Holder, Shelf STRATOS
Toilet Seat Paper Cover Dispenser
Surface mounted toilet seat paper cover dispenser, manufactured from grade
EN 1.4301 (304) stainless steel - satin polish finish, material thickness 1.2/1.5mm.
Screws and dowels included.
393x54x263
STRX680
Extras:
E-STRX680
1 carton (10 packets with 200 sheets)
Toilet Brush Holder
Surface mounted and floor standing toilet brush holder, manufactured from grade
EN 1.4301 (304) stainless steel - satin polish finish, material thickness 1.2/1.5mm.
Nylon brush supplied, with holder. Screws and dowels included.
110x111x230
STRX687
Extras:
E-BS686
Replacement toilet brush with white plastic handle
E-BS687
Black toilet brush with stainless steel handle
Shelf
Surface mounted shelf, manufactured from grade EN 1.4301 (304) stainless steel satin polish finish, material thickness 2mm. Screws and dowels included.
640x110x45
STRX623
Picture / Diagram Code / Description
All dimensions in mm
10
Hooks, Pictograms, Recessed Dispenser STRATOS
Coat Hook
Single coat hook for wall mounting, made of stainless steel, surface satin finished,
18mm diameter, hidden fixing screw, incl. mounting set.
Ø 18x60
STRX692
Double Coat Hook
Double coat hook for wall mounting, stainless steel, surface satin finished, 18mm
diameter, hidden fixing screw, incl. mounting set.
Ø 18x60
STRX694
Pictograms
Pictograms, made of stainless steel.
125x125x1.5
BS630
Gents-WC
BS631
Ladies-WC
BS632
Disabled-WC
Recessed Paper Towel / Soap Dispenser Combination
Recessed paper towel and soap dispenser combination, manufactured from grade
EN 1.4301 (304) stainless steel - satin polish finish, material thickness 1.2/1.5mm.
Cylinder lock with Franke standard key. The soap dispenser is fitted with a 1 litre container. The paper towel dispenser has a capacity of 300 - 400 towels depending
on the type and their folding. Screws and dowels included.
Suitable for paper towels:
min: 240x85
max: 250x105
ideal: 250x95
424x147x632
STRX601E
Extras:
FH68
Paper towels (168 pieces)
Picture / Diagram Code / Description
All dimensions in mm
11
Recessed Dispensers & Waste Bins STRATOS
Recessed Paper Towel Dispenser
Recessed paper towel dispenser, manufactured from grade EN 1.4301 (304)
stainless steel - satin polish finish, material thickness 1.2/1.5mm. Fitted with a
cylinder lock with Franke standard key. The paper towel dispenser has a capacity
of 300 - 400 towels depending on the type and their folding. Screws and dowels
included.
Suitable for paper towels:
min: 240x85
max: 250x105
ideal: 250x95
328x147x632
STRX600E
Extras:
FH68
Paper towels (168 pieces)
Recessed Paper Towel Dispenser / Waste Bin Combination
Recessed paper towel dispenser and waste bin combination, manufactured from
grade EN 1.4301 (304) stainless steel - satin polish finish, material thickness
1.2/1.5mm. Both parts are fitted with a cylinder lock with Franke standard key.
Capacity of 300 - 400 towels depending on the type and their folding. The container
has a capacity of approx. 22 litres. Screws and dowels included.
328x203x1162
Suitable for paper towels:
min: 240x85
max: 250x105
ideal: 250x95
STRX602E
Extras:
FH68
Paper towels (168 pieces)
Recessed Waste Bin
Recessed waste bin, manufactured from grade EN 1.4301 (304) stainless steel satin polish finish, material thickness 1.2/1.5mm. The container has an approx. 22
litre capacity and is fitted with a cylinder lock with Franke standard key. Screws and
dowels included.
328x203x862
STRX605E
Picture / Diagram Code / Description
All dimensions in mm
12
Recessed Waste Bins & Dispensers STRATOS
Recessed Sanitary Towel Disposal Bin
Recessed sanitary towel disposal bin, manufactured from grade EN 1.4301 (304)
stainless steel - satin polish finish, material thickness 1.2/1.5mm. The disposal
bin incorporates a plastic container with a 6 litre capacity and is for the disposal of
sanitary towel and minor waste and has a stainless steel continuous piano hinge.
Screws and dowels included.
232x135x331
STRX611E
Recessed Soap Dispenser
Recessed soap dispenser combination, manufactured from grade EN 1.4301 (304)
stainless steel - satin polish finish, material thickness 1.2/1.5mm. Cylinder lock
with Franke standard key. The soap dispenser is fitted with a 1 litre - container.
Screws and dowels included.
211x90x181
STRX619E
Recessed Soap Dispenser
Recessed soap dispenser combination, manufactured from grade EN 1.4301 (304)
stainless steel - satin polish finish, material thickness 1.2/1.5mm. Cylinder lock
with Franke standard key. The soap dispenser is fitted with a 1 litre - container.
Screws and dowels included.
128x147x632
STRX618E
Recessed Paper Towel / Soap Dispenser / Waste Bin Combination
Recessed paper towel/soap dispenser and waste bin combination, manufactured
from grade EN 1.4301 (304) stainless steel - satin polish finish, material thickness
1.2/1.5mm. Cylinder lock with Franke standard key. The soap dispenser is fitted
with a 1 litre - container. The paper towel dispenser has a capacity of 300 - 400
towels depending on the type and their folding. Screws and dowels included.
424x203x1162
STRX617E
Picture / Diagram Code / Description
All dimensions in mm
13
Recessed Toilet Roll Holders STRATOS
Recessed Toilet Roll Holder
Recessed toilet roll holder, manufactured in grade EN 1.4301 (304) stainless steel
- satin polish finish, material thickness 0.8mm. For 2 rolls with max. Ø 108mm.
Screws and dowels included.
183x135x331
STRX671E
Recessed Toilet Roll Holder with Spindle System
Recessed toilet roll holder with spindle system. Manufactured from grade
EN 1.4301 (304) stainless steel - satin polish finish, material thickness
1.2/1.5mm. For 2 rolls max. Ø 108mm, the reserve roll is not visible and drops
automatically into the dispensing position after finishing the first roll. Fitted with a
cylinder lock with Franke standard key. Screws and dowels included.
156x140x304
STRX672E
197x171x371
STRX672LE
Recessed Toilet Roll Holder
Recessed toilet roll holder, manufactured in grade EN 1.4301 (304) stainless steel satin polish finish, material thickness 0.8mm.
For 1 roll with max. Ø 110mm. Screws and dowels included.
153x153x65
STRX673E
FSI/08/2009
Franke Sissons Ltd
Carrwood Road
Sheepbridge
Chesterfield S41 9QB
England
Tel +44 (0)1246 450255
Fax +44 (0)1246 451276
Email ws.uk@franke.com
www.franke-sissons.co.uk
www.franke-ws.com
Smart
Hygiene
Solutions
Loading...
