Franke PEX11028 Specs

Spec Sheet

PLANAR 8 PEX110-28

Overall Sink Size (OD)
Bowl Depth (ID)

Minimum Cabinet 33“ Material
Installation Type Undermount Drain Measurement 3.5“

Made In ITALY Code Approvals UPC & cUPC
Weight (lbs)

Optional Accesories

Sink Includes

29.5“W x 18.5“D

9.5“

Packed: 31 lbs
Unpacked: 21 lbs

Bottom Grid PE-28S
Cutting Board PE-40S

Colander PE-70S
Strainer Baskets 900 (Chrome) / 900SN (Satin Nickel)
Anti-noise pads 11 Pads (adhered to the sink)

Clip Fixing System EL-CLIPS

Cut Out Template

For reference only. All
templates are meant to be
guidelines. It is absolutely critical
that you have the sink and any
custom sink accessories on site
prior to any cut or modification to
the countertop. This is the only
way to ensure a proper custom
cut and installation.

FRANKE WILL NOT BE
RESPONSIBLE FOR ANY
ERRORS IN COUNTERTOP
PREPARATION AND SINK
INSTALLATION.

Bowl Size (ID) 28“W x 17“D
Inside Corner Radius 8mm or 3/8”

Type 304, 18GA Stainless Steel
18% Chromium / 10% Nickel

Box Dimensions 39“ x 24“ x 11.875“

Document Revision July 18, 2014
