Franke Contina BROCHURE

Contina

GRAB RAILS AND SPECIAL NEEDS PRODUCTS

Smart Hygiene Solutions.

Franke Sissons

Franke Sissons Ltd.....serving our customers for 225 years. Sustainability and longevity to support your business.

In 2009 Franke Sissons are 225 years old. The original Company was formed in 1784 as silversmiths in Sheffield, England
and during the past 225 years has gained an international reputation for manufacturing and supplying quality, well
designed and durable products for a wide range of commercial applications.

Franke Sissons are suppliers to many well known blue chip clients in the UK, Ireland and Worldwide including:

Asda and the Walmart Group
Marks and Spencer
Sainsburys
Warner Holidays
Youth Hostel Association
Astra Zenica
Wolseley Group
Saint Gobain Group
BSS Group
NHS Trusts
Unilever
ARUP

Franke Sissons products are covered in part or wholly by the following Approvals and Standards:

001

ISO9001:2000

Nightingale Architects
Lorne Stewart
Haden Young
Interserve
Balfour Kilpatrick
N G Bailey
Sheperd Engineering Services
British Airport Authority
Capita Percy Thomas Architects
Ministry of Defence
Midland Mainline
Emcor

HSBC
University of London
University of Leicester
Rugby Football Union
Scott Tallon Walker Architects
Skanska
Mitie Group
Briggs & Forrester
Crown House Engineering
Spie Matthew Hall
News International

Franke Sissons Ltd, Carrwood Road, Sheepbridge, Chesterfield S41 9QB, England
Tel [phone], Fax [phone], Email [e-mail], www.franke-sissons.co.uk, www.franke-ws.com

Franke CONTINA grab rails offer effective solutions for
use in private homes and the public, clinical and care
sectors. Folding and grab handles offer strong support.

GRAB RAILS, CONTINA

AND SPECIAL NEEDS

PRODUCTS

Product features

Reliable stability (LGA test-approved) -

Easy to grip matt polished surface finish -

With ergonomically ideal diameter of approximately 31.8mm -

Cover rosettes in stainless steel, with concealed fixing brackets -

Easy to fit fixing brackets -

Long service life -

Ergonomic white seats -

Special configurations and individual items available with short delivery times -

Made of stainless steel -

Description Page

Grab Rails 4
Angle Bars 4-5
Side Bars 5
Two Way Bar 6
Horizontal Corner bar 6
Fold Down Bar 6-7

Description Page

Fold Down & Hanging Shower Seats 8
Back Supports 9
Disabled WC 10
Disabled Washbasin 11
Mirror 11
Installation Frames 10, 11

Picture / Diagram Code / Description
All dimensions in mm

4

Grab Rails CONTINA

Grab Rail

Manufactured from grade Ø 32mm EN 1.4301 (304) stainless steel with matt
polished finish to prevent slipping with an ergonomical, comfortable diameter
of about 32mm. Stainless steel cover plates conceal screw fixing. 600mm rails
available in either blue or yellow (indicated by suffix letter in code).

300

CNTX300

450

CNTX450

550

CNTX550

600

CNTX600 / CNTX600B (Blue) / CNTX600Y (Yellow)

650

CNTX650

750

CNTX750

900

CNTX900

1100

CNTX1100

Angle Bar 135°

Manufactured from grade Ø 32mm EN 1.4301 (304) stainless steel with matt
polished finish to prevent slipping with an ergonomical, comfortable diameter of
about 32mm. Stainless steel cover plates conceal screw fixing.

660x95x338

CNTX700A

Angle Bar 90°

Manufactured from Ø 32mm grade EN 1.4301 (304) stainless steel with matt
polished finish to prevent slipping with an ergonomical, comfortable diameter of
about 32mm. Stainless steel cover plates conceal screw fixing.

1250x600

CNTX20L

1250x600

CNTX20R

750x415

CNTX22L

750x415

CNTX22R
