Produc t Sheet
Dynamic X2
Aerodynamic technology. Cool design.
Fractal Design Dynamic X2 GP-12 and GP-14 are true all-purpose fans, offering
good airflow and best in class 100,000 hours MTBF thanks to the new LLS bearing.
Their customized design creates a beautifully aesthetic fan to help keep your
system cool, yet quiet.
Designed together with our high-end Venturi Series, the Dynamic X2 Series fans
feature aerodynamic elements, similarly found in airplane wing designs, with
significant noise-reducing elements.
Available in two color combinations: pure black, or the classic Fractal Design
signature color scheme with white blades and black frame. The Dynamic X2 series
are the perfect companion for users looking to make use of an all-purpose fan with
an exceptional lifespan.
Produc t Sheet
Key features
● High grade LLS bearing with class leading 100,000 hours MTBF.
● Equipped with a counter-pull magnet that reduces the axial tension on the bearing
● Fan geometry optimized for a good balance between static pressure and maximum airflow, resulting in good performance in all usage scenarios
● Aerodynamically shaped stator struts including the wire strut. Helps reduce noise and unwanted turbulence.
● Stator struts sit on a wide angle to the trailing edge of the blades which result in a lower noise level and smoother noise profile
● Strategically placed notches near the fan hub on the trailing edge of the blades further reducing the humming noise produced when the blades
pass the stator struts
● A "trip wire" on the rear side of the blades near the leading edge. The trip wire introduces a larger turbulent boundary layer at an earlier stage,
this delays the layer separation and improves both airflow and noise characteristics.
● The customized design of the Dynamic Series fans contributes to a beautiful, cool build
● Available in two color combinations
● Available in 120mm and 140mm fan sizes
Package contents
● Dynamic X2 series fan
● Screw pack with 4 metal fan screws
Produc t Sheet
General specifications
Fan
Size (mm)
Colors available
Screw hole pattern
Connector
Bearing
Number of blades
Rotational speed (RPM)
Acoustical noise (dB (A))
Maximum air flow (CFM)
Maximum pressure (mm H2O)
Actual input power (W)
Maximum rated input current (A)
Nominal input voltage (V)
Minimum startup voltage (V)
MTBF (hours)
Unit weight (g)
Package weight (g)
Cable length (mm)
Cable type
Packaging dimensions (mm) ( Including hanging tab)
Packaging dimensions (mm) (Excluding hanging tab)
• X2 GP-12
• 120*120*25mm
• Black blades, black frame
• White blades, black frame
• 105*105mm
• 3-pin fan header
• LLS
• 7
• 1200
• 19.4
• 52.3
• 0.88
• 1.32
• 0.18
• 12
• 4.0
• 100,000
• 119
• 160
• 500
• Black ribbon cable
• 180*122*26
• 147*122*26
• X2 GP-14
• 140*140*25mm
• Black blades, black frame
• White blades, black frame
• 125*125mm
• 3-pin fan header
• LLS
• 7
• 1000
• 18.9
• 68.4
• 0.71
• 1.32
• 0.2
• 12
• 4.0
• 100,000
• 142
• 190
• 500
• Black ribbon cable
• 200*142*26
• 167*142*26
Produc t Sheet
Additional information
Product Code EAN UPC
Dynamic X2 GP-12 Black │ FD-FAN-DYN-X2-GP12-BK │ 7350041084372 │ 817301014373
Dynamic X2 GP-12 White │ FD-FAN-DYN-X2-GP12-WT │ 7350041084389 │ 817301014380
Dynamic X2 GP-14 Black │ FD-FAN-DYN-X2-GP14-BK │ 7350041084396 │ 817301014397
Dynamic X2 GP-14 White │ FD-FAN-DYN-X2-GP14-WT │ 7350041084402 │ 817301014403
