Thank you and congratulations on your purchase of your new
Fractal Design Core 1000 USB 3.0 mATX Computer Case!
Before using the case, please take the time to read these instructions carefully.
About Fractal Design – our concept
The concept of Fractal Design is to provide products with an extraordinary
design level, without compromising the important factors of quality,
functionality and pricing. The computer of today has come to play a central role in
most people’s home, creating a demand for appealing design of the
computer itself and its accessories.
Our main product areas are computer enclosures, power supplies, cooling and Media
Center-products, such as Home Theatre-enclosures, keyboards and
remote controls.
Designed and engineered in Sweden
All Fractal Design products have been thoroughly designed, tested and
specifi ed in our Swedish head quarter. The well-known ideas of Scandinavian design
can be found through all of our products; a minimalistic but yet striking design - less
is more.
Limited Warranty and Limitation of Liability
This product is guaranteed for twelve (12) months from the date of delivery to enduser against defects in materials or workmanship. During this period, the product will
either be repaired or replaced, upon our discretion. The product
must be returned to the agent from whom it was purchased with shipping
prepaid.
The warranty does not cover:
I. A product which has been used for hire purposes, misused, handled
carelessly or other than in accordance with any instructions provided
with respects to it’s use.
II. A product with damages from acts of nature such as lightning, fi re, fl ood or earthquake are not covered by the warranty.
III. A product where the serial number have been removed or
tampered with.
2
Core Series - 1000 USB 3.0
The new Fractal Design Core Series offers a unique combination of design, features,
cooling performance and value.
Key features
• Simple yet elegant front panel with mesh and fi lter
• Optimized for performance in a small, micro atx form factor with multiple cooling
options
• A total of 3 fan slots (1x 120mm fi ltered in front, 1x 92mm in rear, 1x 120mm in
side panel)
• One fan included (1x 120mm in front)
• Innovative, easily removable HDD-tray which mounts the HDD’s vertically with
anti vibration silicone grommets
• Supports graphic cards with lengths up to 350mm when lower HDD mount is
not used
• Supports 3x 2.5” SSD
• Easily removable front panel with clip on fan slots
The Core 1000 USB 3.0 brings many features usually only seen in more expensive
and larger cases. It supports long graphics cards up to 350mm due to the innovative,
vertical and removable HDD mounting bracket. The front panel’s easily removable
and pre-fi tted with fan fi lters to ensure a dust free interior. The sleek black interior is
matched and contrasted with white expansion slots. Similar to the Defi ne Series, all the
HDD trays are fi tted with anti-vibration silicon grommets for optimal silence.
GB
3
Cooling system
• 1 front mounted Fractal Design 120mm fan @ 1200rpm included
• Additional 2 fan slots available for optional fans; one 92mm in rear and one
120mm in side panel
Specifi cations
• 2x 3.5 inch HDD trays or 3x 2.5” SSD - You can mount 1x 3.5 inch HDD tray
and 1x 2.5” SSD at the same time
• 2x 5.25 inch bays, with 1x 5.25>3.5 inch converter included
• 1x USB 2.0, 1x USB 3.0 and Audio I/O – mounted on side of front panel
• No PSU included
• M/B compatibility: Mini ITX and Micro ATX
• 4 expansion slots with sleek white painted brackets
• Supports graphic cards with lengths up to 210mm when lower HDD mount
is used
• Supports graphic cards with lengths up to 350mm when lower HDD mount
is not used
• Supports CPU coolers with height of 135mm
• Case size (WxHxD): 175x355x420mm with front and top bezel in place
• Net weight: 4.1kg
Additional information
* EAN/GTIN-13: 7350041081098
* UPC: 817301011099
* Product code: FD-CA-CORE-1000-USB3-BL
* Also available for System Integrators
44
How to Section:
Installing Graphic cards longer than 260mm
To be future proof, Core 1000 USB 3.0 supports graphic cards longer than 210mm
simply by only using the top HDD mount. When only one HDD is used, the chassis
supports graphic cards with lengths up to 350mm! Note however that you usually
cannot use the lower HDD mount when having a long graphics card, since the power
connector will hit the HDD tray.
Cleaning the fi lters
The fi lters are placed at the usual air intakes to prevent dust in the system. When they
get dirty they also obstruct the airfl ow and they need to be cleaned with a regular inter-
val for optimal cooling.
• To clean the front fi lter, the front fan needs to be disconnected from the power
source. When they are disconnected, remove the front panel using the handle in
the bottom, pull outwards and the front should come off. Clean the fi lters and then
snap it back on. Don’t forget to connect the fan afterwards.
GB
5
Tack för ditt köp av Fractal Design Defi ne Mini mATX datorchassi!
Innan du fortsätter med uppackning rekommenderar vi dig att läsa dessa anvisningar
noggrant.
Om Fractal Design – Vårt koncept
Fractal Designs vision är att leverera produkter med en tilltalande och snygg design
utan att kompromissa med viktiga faktorer såsom kvalitet, funktionalitet och pris.
Datorn har idag en central roll i många människors hem vilket ställer helt nya krav på
utseende och design. Våra viktigaste produktområden utgörs idag av datorlådor, nätaggregat, kylning och Media Center-produkter.
Framtagen och designad i Sverige
Alla Fractal Designs produkter är noggrant utformade och testade i vårt svenska
huvudkontor. Det välkända skandinaviska designspråket löper som en röd tråd genom
sortimentet. En minimalistisk men slående design – less is more.
Garanti och ansvarsbegränsning
Denna produkt är garanterad att under tolv (12) månader från dagen för leverans till
slutanvändare vara utan fel i material eller utförande under den angivna perioden.
Under denna period kommer produkten antingen att repareras eller bytas. Produkten
skall återlämnas till återförsäljaren från vilket den köptes med frakt förbetalt.
Garantin omfattar inte:
I. En produkt som har använts för uthyrning, missbrukas, hanteras vårdslöst
eller annat utöver anvisningar med avseenden på IT-användning.
II. Skador från naturkrafter som blixtnedslag, brand översvämning eller
jordbävning omfattas inte av garantin.
III. En produkt där serienumret har avlägsnats eller på annat sätt manipulerats.
6
Core Serien - 1000 USB 3.0
Core serien från Fractal Design erbjuder en unik kombination av design, smarta
lösningar, kylning, och prestanda.
Nyckelfunktioner
• Snygg mesh-front som har fl äktfi lter redan förmonterat
• Optimerad för prestanda, i en väldigt liten mATX förpackning utan att spara in på
kylningsmöjligheter
• Totalt 3 fl äktplatser (1x 120mm fram, 1x 92 bak, 1x 120mm i sidopanelen)
• 1x 120mm förmonterad i fronten ingår
• En HDD-Vagga för 2 hårddiskar sitter sidomonterad med vibrationsdämpande
silikon förmonterat
• Stödjer grafi kkort upp till 350mm i längd om ingen HDD sitter i nedre vaggan
• Stödjer upp till 3st 2,5” SSD
• Löstagbar frontpanel med snabbfäste för fl äkt
Core 1000 USB 3.0 har många funktioner som man normalt endast hittar i dyrare och
större chassin. Det är en väldigt liten mATX låda som lätt går att ställa undan, och ändå
har den plats för hela 350mm långa grafi kkort. Detta görs möjligt tack vare den smarta
lösningen där HDD monteras vertikalt utmed sidoplåten. HDD-platserna har självklart
vibrationsdämpare i silikon förmonterade för en tystare upplevelse, precis som Defi ne
serien.
• Ytterligare 2 fl äktplatser för extrafl äktar fi nns tillgängligt, en 92mm bak och en
120mm i sidopanelen
Specifi kationer
• 2x 3,5” vibrationsdämpade HDD-vaggor, kompatibla med upp till 3 SSD!
• 2x 5,25” fack, med en adapter från 5,25” till 3,5” för kortläsare eller FDD
• På fronten fi nns lättåtkomligt 1x USB2.0, 1x USB3.0 och Audio I/O
• Nätdel ingår ej (fi ltrerat luftintag för nätdel under lådan, som enkelt kan lossas
för att rengöras)
• Passande moderkort: Mini-ITX och mATX
• 4 expansionsplatser täckta med vita skyddsplåtar
• Stöd för grafi kkort med längd upp till 210mm med HDD i nedre platsen
• Stöd för grafi kkort med längd upp till 350mm om nedra platsen om nedre platsen
är ledig
• Stöd för CPU-kylare med en höjd på hela 135mm
• Storlek (BxHxD): 175x355x420mm (med front- och topp- paneler på plats)
• Nettovikt: 4,1kg
Övrig information
* EAN/GTIN-13: 7350041081098
* UPC: 817301011099
* Produkt kod: FD-CA-CORE-1000-USB3-BL
* Finns även anpassade för systemintegratörer
8
Praktiska tips:
Installera grafi kkort längre än 210mm
För att vara framtidssäker stöder Core 1000 USB 3.0 grafi kkort längre än 210mm om
den nedere HDD platsen ej används vilket gör att lådan stödjer grafi kkort med längd
upp till hela 350mm!
Rengöring av fi lter
Filter är placerade i fronten för att förhindra att damm hopar sig i lådan vilket leder till
sämre temperaturer och onödigt slitage. En regelbunden rengöring av fi ltret underlättar
luftfl ödet samt får datorn att gå kallare.
• För att rengöra det främre fi ltret måste först den främre fl äkten kopplas ur. När det
är gjort, lossa frontpanelen med hjälp av handtaget i botten, dra utåt och frontpanelen skall lossna. Rengör fi ltret och sätt tillbaka fronten. Glöm inte att koppla in fl äktarna efteråt.
SE
9
Herzlichen Glückwunsch und vielen Dank, dass Sie sich für den Kauf
des neuen Fractal Design Core 1000 USB 3.0 mATX Computergehäuses
entschieden haben!
Bevor Sie das Gehäuse benutzen, nehmen Sie sich die Zeit, um die Gebrauchsanweisung sorgfältig durchzulesen.
Über Fractal Design – unser Konzept
Das Konzept von Fractal Design besteht darin, Produkte auf einem außergewöhnlichen Design-Level anzubieten, ohne dabei andere wichtige Features wie Qualität, Funktionalität und Preis zu vernachlässigen. Der Computer spielt heutzutage eine wichtige
Rolle in den Haushalten der meisten Menschen und erweckt bei ihnen das Bedürfnis
auf ein ansprechendes Design des Computers selbst, sowie seines Zubehörs.
Der Umfang unserer Hauptprodukte reicht von Gehäusen über Netzteile, Kühlungsund Media-Center-Produkten wie Home-Theatre-Gehäuse bis hin zu Keyboards und
Remote Controls.
Konzipiert und entwickelt in Schweden
Sämtliche Fractal Design Produkte werden in unserem schwedischen Hauptsitz sorgfältig konzipiert, entwickelt und geprüft. Die außergewöhnlichen Eindrücke des Scandinavian Designs fi nden sich überall in unseren Produkten – ein elegantes und dennoch
beeindruckendes Design – weniger ist mehr.
Befristete Garantie und Haltbarkeit
10
Dieses Produkt bietet eine Herstellergarantie von zwölf (12) Monaten beginnend mit
dem Lieferdatum an den Endverbraucher auf Materialschäden oder Produktionsfehler.
Während dieser Zeit wird das Produkt bei Beeinträchtigungen nach unserem Ermessen
entweder repariert oder komplett ausgetauscht. Das Produkt muss dann als freie Lieferung an den Händler, von dem es erworben wurde zurück gesandt werden.
Die Garantie umfasst nicht:
I. Ein Produkt, das zur Vermietung verwendet wurde, unsachgemäß und fahr
lässig behandelt oder zu anderen Zwecken als in der beigefügten Gebrauchs
anweisung beschrieben, in Gebrauch genommen wurde.
II. Ein Produkt, das unwetterbedingte Schäden genommen hat durch Blitz,
Feuer, Flut und Erdbeben oder andere Ursachen, die durch den Gebrauch
der mitgelieferten Anleitung auszuschließen sind.
III. Ein Produkt, bei dem die Seriennummer entfernt oder manipuliert wurde.
Core Serie - 1000 USB 3.0
Die neue Core Serie kombiniert exklusives, stilvolles und modernes Design, Features,
Kühlungs-Performance und Nutzen.
Key Features
• Elegantes Front Panel Design mit Gitter und Filter
• Optimiert für Performance in einer kleinen Micro atx Größe mit mehreren
Kühlungsoptionen
• Insgesamt 3 Lüfter-Halterungen(Front: 1x 120mm, Rückseite: 1x 920mm und
Seitenteil: 1x 120mm)
• 120mm Fractal Design Silent Series 15dB Lüfter vorne enthalten
• Innovativer, leicht herausnehmbarer HDD Schlitten, der die HDDs vertikal mit
Anti-Vibrations Silikonscheibchen befestigt hält
• Unterstützt Grafi kkarten bis zu einer Länge von etwa 350mm
• Unterstützt bis zu 3x 2.5” SSD
• Leicht abnehmbares Front Panel mit Clip-Halterung für Lüfter-Halterung
Das Core 1000 USB 3.0 bietet viele Features, die man normalerweise nur in teuren
und großen Gehäusen fi ndet. Es unterstützt Grafi kkarten bis zu einer Länge von
350mm dank des innovativen herausnehmbaren HDD Käfi gs. Das Front Panel ist
leicht abnehmbar und vormontiert mit Lüfterfi ltern um einen staubfreien Innenraum zu
gewährleisten. Das glänzend schwarze Innere ist passend abgestimmt im Kontrast mit
den weißen Erweiterungssteckplätze. Ähnlich wie bei der Defi ne Serie, sind alle HDD
Schlitten mit Silikon-Vibrationsdämpfern ausgestattet für optimale Geräuschlosigkeit.
• Zusätzliche 2 Lüfter-Halterungen für weitere Lüfter; ein 92mm an der Rückseite und
ein 120mm am Seitenteil
Technische Daten
• 2x 3.5 Zoll HDD-Schlitten oder 3x 2.5 Zoll SSD. Sie können 1x 3.5 Zoll HDD
Schlitten und 1x 2,5 Zoll SSD gleichzeitig montieren
• 2x 5.25 Zoll Käfi ge inklusive 1x 5.25 auf 3.5-Zoll-Konverter
• Am oberen Teil des Front Panels: 1x USB 2.0, 1x USB 3.0 und Audio I/O
• Kein Netzteil enthalten
• M/B Kompatibilität: Mini ITX und Micro ATX
• 4 Erweiterungssteckplätze mit weiß lackierten Halterungen
• Unterstützt Grafi kkarten mit einer Länge bis zu 350mm ohne den HDD Käfi g
• Unterstützt Grafi kkarten mit einer Länge bis zu 210 mit eingesetzten HDD Käfi g
• Unterstützt CPU Kühler mit einer Höhe bis zu 135mm
• Gehäuseabmessungen: (BxHxT): 175x355x420mm einschließlich der eingesetzten
Front- und Oberfassungen.
• Netto Gewicht: 4.1kg
Zusätzliche Informationen
12
* EAN/GTIN-13: 7350041081098
* UPC: 817301011099
* Produkt Code: FD-CA-CORE-1000-USB3-BL
* Auch erhältlich für System Integratoren
Praktischer Anwendungsteil:
Installieren von Grafi kkarten mit einer Länge über 260mm
Um mit der Zukunft Schritt zu halten, unterstützt das Core 1000 USB 3.0 Grafi kkarten,
die länger als 210mm sind, in dem Sie nur den oberen HDD Käfi g nutzen. Wenn nur
ein HDD Käfi g verwendet wird, unterstützt das Gehäuse Grafi kkarten mit einer Länge
bis zu 350mm. Beachten Sie, dass Sie den unteren HDD Käfi g nicht verwenden kön-
nen, wenn Sie eine längere Grafi kkarte einsetzen wollen, da der Stromstecker der
Grafi kkarte an den Käfi g stößt.
Säuberung der Filter
Die Filter sitzen an den herkömmlichen Lufteinlassöffnungen, um zu verhindern, dass
Staub in das System gelangt. Wenn sie verschmutzen, hindern sie ebenfalls das
Fördervolumen und sie müssen daher in regelmäßigen Abständen gereinigt werden,
um eine optimale Kühlung zu gewährleisten.
• Um die Filter vorne zu reinigen, müssen der Front Lüfter vom Netzteil getrennt
werden. Danach entfernen Sie die Frontblende, indem Sie den Griff am Boden
benutzen und nach vorne ziehen. Die Frontblende sollte sich dann abnehmen las
sen. Säubern Sie die Filter und rasten Sie sie wieder ein. Vergessen Sie nicht, die
Front Lüfter danach wieder anzuschließen.
DE
13
Nous vous remercions et vous félicitons pour l’achat de votre nouveau
boitier mATX FRACTAL Core 1000 USB 3.0!
Avant d’utiliser celui-ci, nous vous invitons à prendre le temps de lire les instructions
ci-dessous.
À propos de Fractal Design – notre concept
Le concept de Fractal Design est de proposer des produits à une niveau de design
extraordinairement élevé, sans pour autant faire de compromis sur les importants
facteurs de qualité, fonctionnalité et prix. L’ordinateur d’aujourd’hui joue un rôle centrale dans la plupart des foyers, créant ainsi une demande. L’essentiel de notre gamme
comprend des boitiers PC, des alimentations, les systèmes de refroidissement ainsi
que les accessoires média center, tels que les boitiers home cinéma, le claviers et
autres télécommandes.
Conception et design suédois
Tous les produits Fractal Design sont intégralement designés, testés et améliorés dans
nos bureaux en Suède. Le design suédois reconnu mondialement agrémente chacun
de nos produits, minimaliste et aiguisé. Less is more
Conditions de garantie et limite des responsabilités
Ce produit est garantie pour une durée de 12 mois depuis la date de livraison au client
fi nal , contre tout défaut matériel ou malfaçon.
Pendant cette période, le produit peut être soit réparé soit remplacé, à la discrétion du
constructeur.Le produit doit être retourné au lieux d’achat en port prépayé.
La garantie ne couvre pas:
I. Un produit qui aurait été utilisé pour la location, pour une autre utilisation que
celle prévue initialement, un produit qui aurait été malmené, ou utilisé sans
respect des consignes situé dans le manuel.
II. Un produit endommagé suite aux effets d’une catastrophe naturelle tels que
l’orage, le feu, les inondations ou tremblement de terre, ne sera pas couvert
par la garantie.
III. Un produit dont le numéro de série aura été retiré ou dont la lecture est
impossible.
14
Core Series – Core 1000 USB 3.0
La nouvelle gamme CORE de Fractal Design offre une combinaison unique entre
design, technicité, refroidissement, et prix compétitif.
Caractéristiques principales
• Simplet et élégant panneau avant avec grille et fi ltre
• Optimisé pour la performance avec de multiples possibilités de refroidissement
• 3 emplacements Ventilateurs (1x 120mm fi ltré à l avant, 1x 92mm à l’arrière,
1x 120mm panneau latéral)
• Un ventilateur 120mm inclus
• Cage HDD innovante et facilement extractible montable verticalement équipée de
gommes anti vibration
• Supporte des cartes graphique jusqu’à 350mm
• Supporte 3x 2.5” SSD
• Panneau frontale facilement amovible équipé de clip sur les emplacement
ventilateurs
Le Core 1000 USB 3.0 apporte de nombreuses caractéristiques généralement présente sur des gammes de produits plus onéreuses et de taille plus importante. Il accueille
des cartes graphiques allant jusqu’à 350mm grâce à sa cage HDD innovante et facilement extractible disposant de bracket amovible. Le panneau avant est facilement amovible et pré équipé de fi ltres prévient de toute intrusion de la poussier au sein du boitier.
Son intérieur noir et lisse contraste à merveille avec les slot d’extension blanc qui l
accompagnent. Comme pour la Gamme Defi ne, tous les plateau HDD sont équipées
de gomme anti vibration pour un silence optimal.
FR
15
Système de refroidissement
• 1 ventilateur de façade Fractal Design 120mm fan @ 1200trs/m inclus
• Deux slots supplémentaires disponibles pour ventilateurs optionnels.
Un de 92mm à l’arrière et un 120mm sur le panneau latéral.
• Baies 2x 5.25” , avec convertisseur 1x 5.25”>3.5”
• 1x USB 2.0, 1x USB 3.0 et Audio I/O – monté sur le côté du panneau avant
• Pas d’alimentation incluse
• Compatible avec les cartes mères Mini ITX et Micro ATX
• 4 slots d’extensions avec brackets blancs
• Supporte les cartes graphique jusqu’à 210mm avec la cage HDD en position basse
• Supporte les cartes graphique jusqu’à 350mm avec cage HDD retirée
• Supporte les ventirads CPU jusqu’à 135mm
• Dimensions (LxHxP):175x355x420mm avec les panneaux top et latéral en place
• Poids net: 4.1kg
Informations complémentaires
* EAN/GTIN-13: 7350041081098
* UPC: 817301011099
* Code produit: FD-CA-CORE-1000-USB3-BL
* Également disponible pour les intégrateurs de systèmes
16
Section comment faire?:
Installer une carte graphique supérieur à 260mm
Afi n d’assurer sa pérennité dans le temps, le Core 1000 USB 3.0 supporte des cartes
graphiques d’une longueur supérieure à 210mm en n’utilisant simplement que le berceau HDD du haut du boitier. Si un seul HDD est utilisé le boitier peut même accepter
une carte graphique allant jusqu’à 350mm! De plus notons également qu’il est rare
d’utiliser le berceau inférieur de tout boitier lors d’utilisation de carte graphique de cette
dimension, puisque le connecteur d’alimentation percuterait le berceau HDD
Nettoyage des fi ltres
Les fi ltres sont placés sur les prises d’air habituelles afi n d’éviter tout entrée de la
poussière au sein du système. Quand ceux-ci deviennent sales, ils obstruent alors
la circulation de l’air à l intérieur du boitier. Ceux-ci nécessitent donc d’être nettoyer
fréquemment afi n de conserver un refroidissement optimal.
• Pour nettoyer les fi ltre avant, les ventilateurs y étant associés doivent être décon
nectés de leur source d’alimentation. Une fois les ventilateurs débranchés, démont
er le panneau frontale en utilisant la poignée prévue à cet effet et située à la base
de celui ci. Nettoyez les fi ltres puise remettez le dispositif en place. N’oubliez pas
alors de reconnecter les ou les ventilateurs déconnectés auparavant.
FR
17
새로운 프랙탈 디자인 Core 1000 USB 3.0 mATX 컴퓨터 케이스를 구매해 주셔서
감사 드리며 축하드립니다!
케이스를 사용하기 전에 다음 지침을 주의 깊게 읽으십시오.
프랙탈 디자인 – 기본적 테마
프랙탈 디자인의 컨셉은 품질의 중요 요소, 기능 및 가격에 타협하지 않고 특별한
디자인의 제품을 제공하는 것입니다. 오늘날의 컴퓨터는 대부분의 가정에서 중요한
역할을 하고 있으며 컴퓨터 자체 및 액세서리의 매력적인 디자인에 대한 요구 또한
증가하고 있습니다.
당사의 주요 제품은 홈 씨어터 케이스, 키보드 및 리모콘 같은 컴퓨터 케이스, 전원 공급,
냉각기 및 미디어 센터 제품입니다.
스웨덴에서 디자인 및 설계
모든 프랙탈 디자인 제품은 당사의 스웨덴 본사에서 완벽하게 디자인하고 규격을
정하고 테스트를 거쳤습니다. 잘 알려진 뛰어난 디자인과 단순함의 극치인
스칸디나비아 디자인의 컨셉을 당사 제품 전체에서 찾아 볼 수 있습니다.
보증 및 책임의 한계
본 제품은 재료 또는 제조 공정상의 결함에 대해 구입한 날부터 12개월간 보증합니다.
보증 기간 동안 당사의 재량 하에 수리되거나 교체됩니다. 제품을 대리점으로 보내야
하며 운송 비용은 소비자가 부담해야 합니다.
다음은 보증에 포함되지 않습니다:
I. 제품의 임대, 오용, 부주의한 취급 또는 기타 사용 지침에 따르지 않은 사용으로
인한 파손.
II. 번개, 화재, 홍수또는지진과같은천재지변으로인한파손.
III. 제품 번호가제거되었거나변조된제품.
18
Core 시리즈 - 1000 USB 3.0
새 프랙탈 디자인 Core 시리즈는 디자인, 기능, 냉각 성능 및 가치의 독특한 결합을
제공합니다.
주요 특징
메시 필터를 갖춘 단순미의 우아한 전면 패널
다양한 냉각 옵션을 갖춘 작고, 마이크로 atx 폼 팩터의 최적화된 성능
총 3개의 팬 슬롯(전면 120mm 1개, 후면 92mm 1개, 옆면 120mm 1개)
전면에 120mm 팬 한 개 포함
진동을 방지하는 실리콘 그로멧의 수직으로 HDD가 장착된 혁신적이고 쉽게
탈장착이 가능한 HDD 트레이
최대 350mm 길이의 그래픽 카드 지원
클립으로 고정되는 팬 슬롯과 쉽게 탈장착되는 전면 패널
Core 1000 USB 3.0은 주로 값이 비싸고 큰 케이스에서 보았던 여러 특징이 있습니다.
혁신적이고 수직 및 탈장착이 가능한 HDD 장착 브래킷으로 인해 최대 350mm 길이의
그래픽 카드를 지원합니다. 전면 패널은 쉽게 탈장착이 가능하고 사전에 장착된 팬
필터는 내부에 먼지가 쌓이지 않게 합니다. 매끄러운 검은색의 내부는 흰색의 확장
슬롯과 대조되는 조화미가 있습니다. Defi ne 시리즈와 마찬가지로 모든 HDD 트레이는
최고의 소음 방지를 위해 진동을 방지하는 실리콘 그로멧으로 고정되어 있습니다.
KO
19
냉각 시스템
1개의전면프랙탈디자인 120mm 팬 @ 1200rpm 포함
옵션 팬에 대한 추가 팬 2 개; 후면 92mm 1개 및 옆면 120mm 1개
규격
2개의 3.5인치 HDD 트레이 또는 3개의 2.5인치 SSD – 동시에 3.5인치 HDD
트레이 1개 및 2.5인치 SSD 1개 장착 가능
5.25와 3.5 인치컨버터포함 5.25 베이 2개
USB 2.0 1개, USB 3.0 1개, 오디오 I/O – 전면패널상단에장착
PSU 미포함
M/B 호환성: Mini ITX및Micro ATX
매끄러운 디자인의 흰색 브래킷의 4 개의 확장 슬롯
아래쪽 HDD 마운트 사용시 최대 210mm 길이의 그래픽 카드 지원
아래쪽 HDD 마운트 미 사용시 최대 350mm 길이의 그래픽 카드 지원
135mm 높이의 CPU 냉각기지원
케이스 크기(WxHxD): 전면 및 상단 베즐 장착 시 175x355x420
순 중량: 4.1kg
Core 1000 USB 3.0은 향후 간단히 상단 HDD 마운트만 사용하면 210mm보다 긴
그래픽 카드를 지원할 수 있습니다. HDD만 사용하면 최대 350mm 길이의 그래픽
카드를 지원합니다! 그러나 긴 그래픽 카드를 사용하면 전원 커넥터가 HDD 트레이를
치기 때문에 HDD 마운트를 사용할 수 없다는 것을 숙지하십시오.
필터 청소
필터는 시스템으로 먼지가 들어가지 않도록 하기 위해 보통 공기 흡입구에 위치합니다.
더러워 지거나 공기 흐름을 방해하지 않도록 정기적으로 청소하여 최적의 냉각이
되도록 합니다.
전면 필터를 청소하려면 전면 팬에서 전원 코드를 뺍니다. 연결이 해제되면
밑면에 있는 손잡이를 사용하여 바깥 방향으로 잡아당겨 전면 패널을 빼 냅니다.
필터를 청소한 후 다시 제자리에 놓습니다. 청소한 후 팬을 다시 연결합니다.
KO
21
Grazie e complimenti per l’acquisto del nuovo case per computer
Fractal Design Core 1000 USB 3.0 mATX!
Prima di usare il case, si prega si leggere attentamente le presenti istruzioni.
Fractal Design – il concetto
Il concetto di Fractal Design è di offrire prodotti con un livello di design sensazionale,
senza pregiudicare qualità, funzionalità e prezzo. I computer di oggi svolgono un ruolo
centrale in tutte le case, creando così una domanda di computer e accessori dal
design ricercato.
La nostra area di prodotti principale è costituita da case per computer, alimentatori,
ventole e prodotti Media Center quali sistemi Home Theatre, tastiere e telecomandi.
Progettati e prodotti in Svezia
Tutti i prodotti Fractal Design sono stati progettati, testati e specifi cati nella nostra sede
svedese. Le ben rinomate idee del design scandinavo si trovano in tutti i nostri prodotti;
un design minimalista, ma sorprendente all’insegna del concetto “Meno è meglio”.
Garanzia limitata e limitazione delle responsabilità
Il presente prodotto è garantito agli utenti per dodici (12) mesi dalla data di acquisto in
caso di difetti nei materiali o nella lavorazione. Durante questo periodo, il prodotto verrà
riparato o sostituito a nostra discrezione. Il prodotto deve essere consegnato all’agente
presso il quale si è acquistato con il pagamento anticipato dei costi di spedizione.
La garanzia non copre:
I. I prodotti noleggiati, utilizzati in modo improprio, maneggiati senza cura o altro,
non in conformità con le istruzioni per l’uso fornite in dotazione.
II. I prodotti danneggiati da fenomeni naturali, quali fulmini, incendi, alluvioni o
terremoti.
III. I prodotti con etichette di garanzia rimosse o manomesse.
22
Serie Core - 1000 USB 3.0
La nuova Serie Core Fractal Design offre una combinazione unica di design, funzioni,
prestazioni di raffreddamento e valore.
Caratteristiche principali
Pannello anteriore semplice ed elegante con mascherina e fi ltro
Prestazioni ottimizzate in formato compatto e micro atx con varie opzioni di
raffreddamento
Un totale di 3 slot per ventole (1x 120 mm nella parte anteriore, 1x 92 mm nella
parte posteriore, 1x 120 mm nel pannello laterale)
Una ventola inclusa (1x 120 mm nella parte anteriore)
Vano HDD innovativo e facilmente rimovibile per il montaggio dell'HDD in
verticale con gommini in silicone anti-vibrazioni
Supporto di schede grafi che lunghe fi no a 350 mm
Pannello anteriore facilmente rimovibile con fermagli sugli slot per ventole
Il Core 1000 USB 3.0 offre varie funzioni di cui sono dotati di norma solo case più
cari e più grandi. Supporta schede grafi che grandi fi no a 350 mm grazie alla staffa di
montaggio HDD innovativa, verticale e rimovibile. Il pannello anteriore è facilmente
rimovibile e dotato di fi ltri per ventola con interno anti-polvere. L'interno nero lucido è
abbinato e in contrasto con slot di espansione bianchi. Come per la Serie Defi ne, tutti i
vani HDD sono dotati di gommini in silicone anti-vibrazioni per una silenziosità ottimale.
IT
23
Sistema di raffreddamento
1 ventola Fractal Design montata nella parte anteriore da 120 mm @ 1200 giri/
min inclusa
Sono disponibili 2 slot per ventole opzionali: uno di 92 mm nella parte posteriore
e uno di 120 mm nel pannello laterale
Specifi che tecniche
2x vani HDD da 3.5” o 3x SSD da 2.5” - È possibile montare
contemporaneamente 1x vano HDD da 3.5” e 1x SSD da 2.5”
2x bay da 5.25” con 1x convertitore 5.25>3.5” inclusi
1x USB 2.0, 1x USB 3.0 e Audio I/O - montati sulla parte superiore del pannello
anteriore
Nessuna PSU inclusa
Compatibilità M/B: Mini ITX e Micro ATX
4 slot di espansione con staffe verniciate di bianco lucido
Supporto di schede grafi che lunghe fi no a 210 mm quando si usa il supporto
HDD inferiore
Supporto di schede grafi che lunghe fi no a 350 mm quando si usa il supporto
HDD inferiore
Supporto di radiatori CPU alti 160 mm
Dimensioni del case (LxAxP): 175x355x420 mm con mascherina anteriore e
superiore in posizione
Peso netto: 4.1 kg
24
Informazioni supplementari
* EAN/GTIN-13: 7350041081098
* UPC: 817301011099
* Codice prodotto: FD-CA-CORE-1000-USB3-BL
* Disponibile anche per integratori di sistema
Sezione Come fare:
Installazione di schede grafi che di lunghezza superiore a 260 mm
Per essere pronto per i futuri prodotti, Core 1000 USB 3.0 supporta schede grafi che di
lunghezza superiore a 210 mm utilizzando semplicemente il supporto HDD superiore.
Quando si usa un solo HDD, lo chassis supporta schede grafi che di lunghezza fi no a
350 mm! Tuttavia, di solito, non è possibile utilizzare il supporto HDD inferiore quando
si dispone di una scheda grafi ca lunga, in quanto il connettore di alimentazione tocca
il vano HDD.
Pulizia dei fi ltri
I fi ltri sono situati nelle solite prese d’aria per evitare che la penetrazione di polvere
nel sistema. Quando si sporcano, ostacolano anche il fl usso d’aria, per cui devono
essere puliti con un intervallo regolare per un raffreddamento ottimale.
Per pulire il fi ltro anteriore, è necessario scollegare la ventola anteriore
dall’alimentazione. Una volta scollegate, rimuovere il pannello anteriore
utilizzando la maniglia nella parte anteriore, tirare verso l’esterno ed estraendo
la parte anteriore. Pulire e riporre i fi ltri. Non dimenticarsi di collegare la ventola.
IT
25
Gratulujemy i dziękujemy za zakup obudowy komputerowej
Fractal Design Core 1000 USB 3.0!
Przed rozpoczęciem korzystania z obudowy prosimy poświęcić chwilę czasu na
zapoznanie się z treścią instrukcji.
Fractal Design – koncepcja i idea
Komputer osobisty stał się jednym z ważnych punktów wyposażenia domu i biura
co stworzyło potrzebę wprowadzenia miłego dla oka wzornictwa obudów oraz peryferiów. Dlatego głównym celem fi rmy Fractal Design jest dostarczania produktów o
ponadprzeciętnym designie, przy zachowaniu wysokiej funkcjonalności, jakości oraz
korzystnej ceny. Produktami fi rmy są głównie stylowe obudowy i zasilacze komputer-
owe, układy chłodzenia oraz komponenty dla komputerów typu Media Center.
Zaprojektowane w Szwecji
Wszystkie produkty zostały szczegółowo zaprojektowane i przetestowane w szwedzkiej centrali fi rmy Fractal Design. W procesie projektowania wykorzystywane są idee
skandynawskiego wzornictwa, tworzenia produktów prostych w formie lecz praktycznych, świetnie wykonanych oraz charakteryzujących się przystępną ceną.
Gwarancja i ograniczenie odpowiedzialności
Produkt objęty jest 12-miesięczną gwarancją, której okres liczony jest od daty dostarczenia do odbiorcy końcowego. W tym okresie wadliwe produkty zostaną naprawione
lub wymienione na nowe wg uznania producenta. W celu dokonania naprawy lub
wymiany gwarancyjnej produkt musi zostać dostarczony do miejsca zakupu.
Niniejsza gwarancja obejmuje wyłącznie wady fabrycznie tkwiące w produkcie.
Gwarancje NIE obejmuje:
I. Produktu, który był użytkowany niezgodnie z przeznaczeniem lub został usz
kodzony umyślnie. Produktu, w który dokonano nieuprawnionej ingerencji.
II. Produktu, który został uszkodzony wskutek działania sił natury takich jak
wyładowanie elektryczne, pożar, powódź lub trzęsienie ziemi.
III. Produktu, którego numer seryjny został zmieniony, zatarty lub usunięty
26
Seria Core – 1000 USB 3.0
Seria obudów Fractal Design Core oferuje unikalną kombinację stylu, wyposażenia,
skutecznej wentylacji oraz korzystnego stosunku jakości do ceny.
Główne cechy
• Prosty i elegancki panel przedni z siatką i fi ltrem przeciwpyłowym
• Konstrukcja zoptymalizowana pod kątem wydajności i przepływu powietrza przy
zachowaniu niewielkich gabarytów
• Łącznie 3 miejsca na wentylatory (1x 120mm z przodu, 1x 92mm z tyłu oraz 1x
120mm z boku)
• W komplecie cichy wentylator Fractal Design 120mm @ 1200rpm z przodu
• Innowacyjne, łatwo wyjmowalne tacki na dyski twarde; dyski montowane pionowo
• Obsługa kart grafi cznych o długości do 350mm
• Wsparcie 3x2.5” SSD
• Łatwo zdejmowalny panel przedni
Obudowa Core 1000 USB 3.0 oferuje wiele cech spotykanych wyłącznie w większych
i droższych konstrukcjach. Dzięki zmyślnemu systemowi montażu dysków twardych
obsługuje karty grafi czne o długości dochodzącej do 350mm. Panel przedni jest łatwo zdejmowalny i wyposażony dodatkowo w fi ltr przeciwpyłowy zapobiegający
przedostawaniu się kurzu do wnętrza komputera. Polakierowane na czarne wnętrze
oraz kontrastujące białe dodatki tworzą ciekawy schemat kolorystyczny. Podobnie jak
w serii Defi ne tacki na dyski na dyski twarde wyposażone zostały w silikonowe, anty-
wibracyjne podkładki.
PL
27
System chłodzenia
• 1 x przedni wentylator Fractal Design 120mm @ 1200rpm (w komplecie)
• Opcje montażu wentylatorów; 1 x tylny wentylator 92mm (opcja) oraz
1 x boczny wentylator 120mm (opcja)
Dane techniczne
• 2 tacki na dyski twarde; możliwość jednoczesnej instalacji 1 x 3.5” HDD i
• Porty z boku obudowy: 1 x USB2.0, 1 x USB3.0 oraz Audio I/O
• Brak zasilacza w standardzie
• Obsługa płyt w standardach: Mini ITX, MicroATX
• 4 sloty rozszerzeń PCI
• Wsparcie kart grafi cznych o długości do 210mm lub 350mm (przy jednym HDD
umieszczonym w dolnej tacce)
• Supports graphic cards with lengths up to 350mm gdy dolne mocowanie HDD nie
jest w użyciu
• Wsparcie coolerów CPU o wysokości do 135mm
• Wymiary: 175mm (szerokość) x 355mm (wysokość) x 420mm (długość)
• Waga: 4.1 kg netto
28
Additional information
* EAN/GTIN-13: 7350041081098
* UPC: 817301011099
* Kod produktu: FD-CA-CORE-1000-USB3-BL
* Dostępna także w wersji dla integratorów
Porady:
Montaż kart grafi cznych dłuższych niż 210mm
Obudowa Core 1000 USB 3.0 zapewnia kompatybilność z kartami grafi cznymi o
długości przekraczającej 210mm. W tym celu należy korzystać wyłącznie z górnego
miejsca do montażu dysku twardego, wówczas do dyspozycji jest aż 350mm przestrzeni!
Czyszczenie fi ltrów
Filtry umieszczone są we wszystkich wlotach powietrza, zapobiegając przedostawaniu
się kurzu do wnętrza obudowy. Zabrudzone mogą ograniczać przepływ powietrza i
muszą być regularnie czyszczone dla zachowania optymalnej wydajności.
• W celu wyczyszczenia przednich fi trów wentylatory umieszczone w panelu przed-
nim muszą zostać odłączone od źródła zasilania. Następnie należy zdemontować
przedni panel chwytając dolną rączkę i ciągnąc do siebie. Po wyczyszczeniu
fi ltrów należy osadzić panel z powrotem oraz podłączyć wentylatory
PL
29
Fractal Design Core 1000 USB 3.0 mATX Computer Case をご購入頂き誠に有難うご
ざいます
