FPVModel RESCUE-1 User Manual
10x3D
V1.1
RESCUE-1
10X Zoom Camera / Gimbal
User Manual
Make sure not to adjust the Gimbal or change it's mechanical structure by yourself. Be sure to
install the camera to gimbal before power on. And installation the gimbal to the aircraft.
Please do not add other peripherals for the camera (Filter, Hood, etc.). To avoid the gimbal perfor-
mance degradation or internal line road damage.
When aerial，please make sure your vehicle master flight control system work in the safest state.
We strongly recommend that when you set up PTZ remove the propeller on the aircraft. Use
non-power battery powered gimbal. And keep children away from the preset flight region.
Our company can not control the user's specific use, installation , assembly , modification
( including the use of non- specified parts ), and improper use. Direct or indirect damage or injury
caused by the above, our company will not be liable for any loss and liability.
RESCUE-1 Gimbal is specially designed for 10X Zoom Camera. Factory default setting with
parameters adjusted.The camera mounted on the gimal. And fix the gimbal on the aircraft upon
received.
Can achieve horizontal, rolling and pitching in three directions augmentation. Shock absorption
and gimbal integration design. Can significantly reduce the mechanical vibration , can be widely
used in entertainment, aerial and other sports.
Warning and Disclaimer
Product Introduction
RESCUE-1 Gimbal is specially designed for 10X Zoom Camera.
If you are using other cameras in the gimbal may appear other abnormality.
Gimbal Description
Make sure that the motor is not blocked by anything during the rotation. If the
gimbal from being blocked during the rotation , clear the obstacle immediately.
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[1] Gimbal mounting plate
[2] Cable connector
[3] Cable jack
[4] Heading direction motor
[5] Horizontal rollers direction motor
[6] Damping ball
[7] Cable jack
[8] Cable jack
[9] Pitch axis direction motor
[10] Camera Mounts
Packing list
Mounting plate dimension drawing
Gimbal x1
Screw package x1
Ｍ2 x４ Phillips screws
Ｍ2.５x５ Hex screw
Spare damping ball x4
Rack mount x2
70
70
54
54
24
54
44
Unit：mm
