FPI RLGD-100 User Manual

RLGD-100
Remote Laser Gas Detector
User Manual
Focused Photonics Inc. UMRLGD1001504130
RLGD-100 REMOTE LASER GAS DETECTOR
ii
Copyright © 2014 Focused Photonics Inc.
All Rights Reserved. No part of this manual may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any other language or computer language in whole or in part, in any form or by any means, whether it be electronic, mechanical, magnetic, optical, manual, or otherwise, without the prior written consent of Focused Photonics Inc. (hereinafter referred to as FPI).
RLGD is an FPI registered trademark.
Warranty
This equipment is sold subject to the mutual agreement that it is warranted by us free from defects of material and of construction, and that our liability shall be limited to replacing or repairing at our factory (without charge, except for transportation), or at customer plant at our option, any material or construction in which defects become apparent within 12 months from shipment date, except in cases where quotations or acknowledgements provide for a shorter period. Components manufactured by others bear the warranty of their manufacturer. This warranty does not cover defects caused by wear, accident, misuse, neglect or repairs other than those performed by FPI or an authorized service center. We assume no liability for direct or indirect damages of any kind and the purchaser by the acceptance of the equipment will assume all liability for any damage which may result from its use or misuse.
We reserve the right to employ any suitable material in the manufacture of our apparatus, and to make any alterations in the dimensions, shape or weight of any parts, in so far as such alterations do not adversely affect our warranty.
Safety Messages
Your safety and the safety of others are very important. We have provided many important safety messages in this manual. Please read these messages carefully.
A safety message alerts you to potential hazards that could hurt you or others. Each safety message is associated with a safety alert symbol. These symbols are found in the manual and inside the instrument. The definition of these symbols is described below:
WARNING/CAUTION: Refer to the instructions for details on the specific danger. These cautions
warn of specific procedures which if not followed could cause bodily injury and/or damage the instrument.
CAUTION: LASER RADIATION HAZARD: This warning is specific to laser light emission and
associated dangers. Failure to heed the warning could result in serious eye damage.
NOTE: Additional information and comments regarding a specific component or procedure are
RLGD-100 REMOTE LASER GAS DETECTOR
iii
highlighted in the form of a note.
CAUTION: THE EQUIPMENT SHOULD ONLY BE USED FOR THE PURPOSE AND IN
THE MANNER DESCRIBED IN THIS MANUAL. IF YOU USE THE EQUIPMENT IN A MANNER OTHER THAN THAT FOR WHICH IT WAS
INTENDED, UNPREDICTABLE BEHAVIOR COULD RESULT POSSIBLY ACCOMPANIED WITH HAZARDOUS CONSEQUENCES.
This manual provides information designed to guide you through the operation and maintenance of your new equipment. Please read this manual and keep it available.
Occasionally, some instruments are customized for a particular application or features and/or options added per customer requests. Please check the front of this manual for any additional information in the form of an addendum which discusses specific information, procedures, cautions and warnings that may be peculiar to your instrument.
Manuals do get lost. Additional manuals can be obtained from FPI at the address given below. Some of our manuals are available in electronic form via the internet. Please visit our website at: www.fpi-inc.com.
RLGD-100 REMOTE LASER GAS DETECTOR
iv
Important Notice
The customer should ensure that the principle of operating of this instrument is well understood by the operator. Misuse of this equipment in any manner, tampering with its components, or unauthorized substitution of any component may adversely impair intrinsic safety of this instrument. No user serviceable components supplied within this instrument. Should the instrument not work properly, or indicate a fault or warning, please refer to the maintenance & troubleshooting section of this manual and contact FPI or an authorized service center immediately if further assistance required.
It is the customer's responsibility to ensure the operator is qualified to perform leak detection in the areas where flammable and hazardous gases probably exist. Since the use of this instrument is beyond the control of Focused Photonics Inc. (hereinafter referred to as FPI), no responsibility by FPI, its affiliates, and agents for damage or injury from misuse or neglect of this equipment is implied or assumed.
1. Laser Radiation Hazard
WARNING: DO NOT VIEW DIRECTLY OR WITH OPTICAL INSTRUMENT INTO
THE LASER BEAM. DO NOT POINT LASER BEAM INTO ANOTHER PERSONS EYE.
In conformity with IEC60825-1.2007, a class 1 laser is equipped on this instrument as the detector and a class 2 or 3R laser used as the spotter.
1. Class 1 lasers and laser systems are considered safe and incapable of producing damaging laser radiation
levels during normal operation.
2. Class 2 is low-powered lasers with an output of approx. 1 MW continuous wave. All class 2 lasers
operate in the visible portion of the electromagnetic spectrum of 400-700nm. Eye protection is usually afforded by aversion response and blink reflex (0.25 seconds). However, a class 2 laser beam could be hazardous if one were to intentionally expose the eyes for longer than 0.25 seconds.
3. Class 3R lasers operate at 1-5 MW of continuous wave. Direct viewing of the Class 3R laser beam could
be hazardous to the eyes.
2. General Cautions
1. When operating the instrument, if any unusual odor or smoke is emitted, fire or possible short circuit is
observed, power off the instrument immediately and remove the battery. Contact FPI or its authorized service center for assistance.
2. If any liquid enters into the instrument, or damage caused to the instrument body, do not use it. Keep
using it may result in electric shock, fire or irreversible damage to the instrument. Contact FPI or its authorized service center for assistance.
RLGD-100 REMOTE LASER GAS DETECTOR
v
3. When charging the battery, if any unusual odor or smoke is emitted, fire or possible short circuit is
observed, unplug the charger cable immediately and remove the battery. Contact FPI or its authorized service center for assistance.
4. Do not charge or replace the battery in flammable or explosive atmospheres.
5. Do not insert any metallic or flammable material into the charger socket.
3. General Warnings
1. No attempt should be made to repair the instrument or substitute its components by other than trained
personnel of FPI. Unauthorized action may impair intrinsic safety of the instrument or cause irreversible damage to the instrument.
2. Do use the shoulder strap and wrist strap to ease fatigue of the personnel who carrying the instrument for
continuous operation. Accidental fall may result in damage to the instrument or hurting operator in the feet.
3. An accidental fall or severe strike may cause damage to the LCD screen and leaking of corrosive/toxic
liquid. Do not touch, inhale and ensure no splash of the liquid into the eyes.
4. Do not use any battery on the instrument other than the specified battery.
5. Do not short circuit the terminals of the battery. Do not store the battery with metallic or flammable
materials.
6. Do not try to disassemble or heat the battery, or cast the battery in fire. If the battery not properly
function, contact FPI or its authorized service center for assistance.
7. If any liquid leak from the battery, do not touch, inhale and ensure no splash of the liquid into the eyes.
8. Do not use any other than the specified AC adapter. Unplug the power cable when the battery charging
finished.
4. General Notes
1. When the instrument is not in use, power off and remove the battery.
2. If the instrument is operated in the environment with strong electromagnetic interference or electronic
noise, the detection may not properly function.
3. If the instrument is placed in the environment with high hydrogen sulfide or salinity, may shorten its life.
4. Operating temperature of this instrument is -20 ~ +50ºC and relative humidity is 30-95%, not to use in
condensing environment.
RLGD-100 REMOTE LASER GAS DETECTOR
vi
5. Storage temperature of this instrument is -30 ~ +60 ºC and relative humidity is 90%, not to store in
humid or condensing environment.
6. Keep the instrument, battery, changer and other accessories always in the specified toolkit during storage,
transportation or return to repair.
RLGD-100 REMOTE LASER GAS DETECTOR
vii
Content
Copyright © 2014 Focused Photonics Inc. ................................................................................................. ii
Warranty ...................................................................................................................................................... ii
Safety Messages ........................................................................................................................................... ii
Important Notice ........................................................................................................................................ iv
Content ........................................................................................................................................................... vii
1 Introduction ............................................................................................................................................... 1
1.1. Overview ............................................................................................................................................... 1
1.2. Features ................................................................................................................................................. 1
1.3. Principle of Operation ........................................................................................................................... 2
1.4. Main Components ................................................................................................................................. 2
1.5. Technical Data ....................................................................................................................................... 3
2 Packing List ............................................................................................................................................... 5
3 Accessories & Fittings .............................................................................................................................. 6
3.1. Shoulder Strap ....................................................................................................................................... 6
3.2. Wrist Strap ............................................................................................................................................. 7
3.3. Battery Charging ................................................................................................................................... 8
3.4. Lens Cover .......................................................................................................................................... 10
3.5. Sight Device ........................................................................................................................................ 10
4 Start/Stop ................................................................................................................................................. 11
4.1. Start Detection ..................................................................................................................................... 11
4.2. Stop Detection ..................................................................................................................................... 11
4.3. Power off ............................................................................................................................................. 11
5 Operation .................................................................................................................................................... 13
5.1. Front Panel .......................................................................................................................................... 13
5.2. Start-up ................................................................................................................................................ 14
5.3. Main Interface ..................................................................................................................................... 14
5.4. System Menu ....................................................................................................................................... 15
5.5. Alarm Level......................................................................................................................................... 16
5.6. Offset Value ......................................................................................................................................... 16
5.7. Sound & Light ..................................................................................................................................... 17
5.8. Brightness ............................................................................................................................................ 17
5.9. System Settings ................................................................................................................................... 18
5.9.1 Date & Time .............................................................................................................................. 18
5.9.2 Screen Standby .......................................................................................................................... 19
5.9.3 Language ................................................................................................................................... 20
5.9.4 Wireless ..................................................................................................................................... 20
5.9.5 Data storage ............................................................................................................................... 21
RLGD-100 REMOTE LASER GAS DETECTOR
viii
5.9.6 Status ......................................................................................................................................... 21
5.10. Others .................................................................................................................................................. 22
5.10.1 Low Battery ............................................................................................................................. 22
6 Maintenance & Troubleshooting ........................................................................................................... 23
6.1. General Maintenance ........................................................................................................................... 23
6.2. Troubleshooting ................................................................................................................................... 23
RLGD-100 REMOTE LASER GAS DETECTOR
1
1 Introduction
1.1. Overview
RLGD-100 the Remote Laser Gas Detector is an easy-to-operate portable device, capable of detecting methane leaks by just pointing it towards the survey areas. Utilizing proprietary technology of Tunable Diode Laser Absorption Spectroscopy (TDLAS), the RLGD-100 detects methane only with no cross­interference and will not false alarm on other gases. Featured OFFSET function further to eliminate the methane in air from affecting detection accuracy.
The RLGD-100 detects methane leak in average concentration along sight line of the laser pass from a remote distance. It enables easy access to hard-to-reach locations, and provides protection for operator and industrial applications against a wide range of potential leak sources.
Fig.1-1 Field Survey
1.2. Features
Detects methane from a remote distance up to 30 meters High sensitivity and ultra-fast response down to 0.1s Alarm on methane leak only, no cross-interference from other gases Self-test and automatic calibration before start-up Easy to operate and maintenance free Satisfy a continuous operation up to 8 hours Visual and audible alarms User-friendly LCD display Wireless data logging
RLGD-100 REMOTE LASER GAS DETECTOR
2
1.3. Principle of Operation
The RLGD-100 is possible to detect methane leak from a remote distance by pointing it towards the survey areas that are hard-to-reach. The methane absorbs a fraction of the laser light, the residual light is then reflected by survey objectives (like pipeline, ceiling, wall and ground, etc.) to the detector. The methane concentration is proportional to laser absorption by it thus analyzed and reported as ppm.m.
Fig.1-2 Working Principle
1.4. Main Components
The RLGD-100 main components are shown below as Fig.1-3.
RLGD-100 REMOTE LASER GAS DETECTOR
3
Fig.1-3 Main Components
1.5. Technical Data
The RLGD-100 technical datas are shown in below table .
RLGD-100 REMOTE LASER GAS DETECTOR
4
ITEM
DESCRIPTION
Detection Method
Tunable Diode Laser Absorption Spectroscopy (TDLAS)
Detection Gas
Methane (CH4) or Methane contained gases
Measurement Range
0~50,000 ppm·m
Detection Distance
0.5~30 m nominal, actual detection distance may vary from objectives and conditions
Sensitivity
5 ppm·m at distance from 0-10m
Accuracy
±10% (100~1,000) ppm·m
Response Time
0.1s
Alarm Range
1~9,999 ppm·m
Alarm Modes
Audible tone, visual flash and concentration reported on the display
Selftest & Calibration
Built-in self-test and automatic calibration before startup
Laser Safety Class
In conformity with IEC60825-1.2007, a class 1 laser is equipped on this instrument as the detector and a class 2 or 3R laser used as the spotter
Explosion Proof
Ex ib IIA T3 Gb
Enclosure Protection
IP54
Operating Conditions
(-20 ~ +50)ºC, (30~95)%RH (non-condensing)
Storage Conditions
(-30 ~ +60) ºC, ≤90%RH (non-condensing)
Power Supply
Rechargeable lithium-ion battery
Battery Duration
≥8h at 25 ºC under screen brightness level 3 and sound volume level 2
Battery Charging Time
≤4h
Weight
<1.5kg
RLGD-100 REMOTE LASER GAS DETECTOR
5
2 Packing List
The RLGD-100 is shipped with all components and accessories packed in a carry case. Carefully unpack the instrument case and inspect it for damage. Immediately report any damage to the shipping agent.
The RLGD-100 consists of the Main Detecor and other accessories including Battery, AC Adaptor, Charger, Shoulder Strap, Wrist Strap and User Manual.
Main Detector
Battery
AC Adaptor
Charger
Shoulder Strap
Wrist Strap
User Manual
RLGD-100 REMOTE LASER GAS DETECTOR
6
3 Accessories & Fittings
This chapter is to demonstrate fully how to use below accessories & fittings.
Shoulder Strap Wrist Strap Battery Charging Lens Cover
3.1. Shoulder Strap
Step 1: Thread the strap through mounting hole on the top of the handle.
Step 2: Thread the other end through the mounting hole on the side bottom of the handle. Step 3: Move the buckle to adjust the strap to a proper length.
RLGD-100 REMOTE LASER GAS DETECTOR
7
3.2. Wrist Strap
Step 1: Thread the strap through mounting hole on the side bottom of the handle.
Step 2: Thread the other end through the mounting hole on the top of the handle.
Step 3: Move the buckle to adjust the strap to a proper length.
RLGD-100 REMOTE LASER GAS DETECTOR
8
3.3. Battery Charging
Step 1: Lay the battery into the charger.
Step 2: Connect the charger to the AC adapter.
Step 3: Plug to get power supply.
Step 4: Unplug and remove the battery after the charging finished.
CAUTION: DO NOT CHARGE THE BATTERY IN FLAMMABLE OR EXPLOSIVE
ATMOSPHERES.
RLGD-100 REMOTE LASER GAS DETECTOR
9
NOTE: The red indicator refers to under charging, the green indicator refers to charging
finished.
Step 5: Loose the screw and open the battery compartment lid.
Step 6: Put the battery into the compartment at right polarity.
Step 7: Put the lid back and tighten the screw.
RLGD-100 REMOTE LASER GAS DETECTOR
10
CAUTION: DO NOT LOAD OR REPLACE THE BATTERY IN FLAMMABLE OR
EXPLOSIVE ATMOSPHERES.
3.4. Lens Cover
Remove the lens cover before operating the instrument.
NOTE: Keep the lens covered when the instrument is not in use.
3.5. Sight Device
Dependent to some probable conditions or if operates from a long distance where the spotter laser may not be observed, the sight device on the top, as shown below Fig.3-1, can be used to aim the detector to the objective.
Fig.3-1 Sight Device
Align all 3 planes (front sight, rear sight, and the target) of focus.
RLGD-100 REMOTE LASER GAS DETECTOR
11
4 Start/Stop
4.1. Start Detection
Take off the lens cover, point the instrument towards the survey area and press detection switch (Fig.4-1 Detection Switch). The spotter laser emitted from the instrument is used to help align to the detection target.
Fig.4-1 Detection Switch
NOTE: Detection value in white digits represents detection successfully finished, while the detection value in grey digits is only for reference due to low laser intensity cannot ensure a high accuracy.
4.2. Stop Detection
Press detection switch again, the spotter laser is off and the instrument enters to standby mode.
NOTE: Detection value and maximum value displayed every 0.5s, when detection stopped, last
values displayed. The 4 panel buttons are deactivated during operation status, and again will be activated when detection stopped.
4.3. Power off
Press button about 3s, soon after heard of the beep tone, the instrument will power off.
Detection Switch
RLGD-100 REMOTE LASER GAS DETECTOR
12
NOTES:
1. A few factors that could possibly affect the detection: 1) extremely low methane may not able to be
detected; 2) Meteorological conditions (like strong wind or high temp) may cause quick dissipation of the leak that not able to detect; 3) Condensated droplets on the lens due to severe temp difference may impact the capability of detection.
2. Make sure that the survey objective is able to reflect infrared light.
3. Make sure that the alarm limit is set to meet safety detection needs.
4. Try to set offset value as close as possible to actual ambient methane, to minimize its influence.
5. An over-reflective objective may cause false alarm, check if light intensity is too strong, according to
which adjust detection angle to avoid over reflection.
6. The instrument may false alarm on the pipeline that is too thin (<10mm) possibly being penetrated
and detected actually the gas passing inside.
7. Please check if the time display right during every power-on of the instrument.
Tips:
1. Move steadily and scan smoothly, manage a relative slow moving rate.
2. Use adaptive scanning paths for specific survey areas. Scan known areas (like pipelines, or locations
where fixed gas detector employed) in ‘S’ path and unknown areas in ‘X’ path.
3. How to locate precisely the leak point? Survey the suspect area at a best possible position, if alarms,
do it repeatedly, meanwhile minish scanning scope and scan around till locate the point where alarm continues.
RLGD-100 REMOTE LASER GAS DETECTOR
13
5 Operation
The RLGD-100 is an easy-to-operate device that can be fully controlled all through the front panel. This chapter provides the information on how to work with the menu, set the parameters and enable functions of the instrument.
5.1. Front Panel
The front panel consists of 4 Buttons, LCD Screen and an Alarm Indicator as shown in Fig.5-1.
Fig.5-1 Front Panel
BUTTON
NAME
DESCRIPTION
ESC
Power on/off
ESC
Long press 3 seconds to power on/off, or press to exit. Press to switch from graphical to numeric display on main page.
Up
Press to scroll up the menu options or press to increase a value.
Down
Press to scroll down the menu options or press to decrease a value.
MENU
Enter
MENU/
ENTER
Press to enter ‘setting’ page or press to save input or
setting.
RLGD-100 REMOTE LASER GAS DETECTOR
14
5.2. Start-up
Press button to power on, the system will enter into start-up mode and then perform self-test. The procedure takes about 1 minute, as shown in below Fig.5-2.
Fig.5-2. Start-up Page
5.3. Main Interface
After self-test completed, the system enters into its main interface, as shown in below Fig.5-3, which displays detection value, graph, other operational parameters and used as an access to setting’ pages.
Fig.5-3 Main Interface
Laser Intensity
Wireless
Laser status
Offset status
Alarm limit
Dynamic Graph
Sound, Battery, Time
Detection Value
Maximum Value
RLGD-100 REMOTE LASER GAS DETECTOR
15
MAIN
PAGE
NAME
DESCRIPTION
Status Bar
(4 icons)
Wireless
Indicates WiFi on/off by enabling or disabling the function.
Sound
Sound volume. Configurable among mute, low, medium and high.
Battery
Indicates remaining capacity of the battery. If low battery<5%, the system will power off automatically
in 30s.
Time
Current time hh/mm.
Display Panel
(7 items)
Light Intensity
<3 grids, indicates laser too low. The more grids, the
higher laser intensity.
Dynamic Graph
Indicates latest 200 detection value, refreshed every 0.5s. Detection value exceeding alarm value displayed in red
curve, while not, shown in green.
The previous graph will be deleted every time press the
detection switch.
Detection Value
Light intensity>3 grids, displayed in white digits that indicates accuracy is high.
Light intensity<3 grids, shown in grey digits that indicates accuracy is low.
The previous detection value will be deleted every time press the detection switch.
Laser
Indicates LASER on/off when start/stop detection.
Offset
Indicates OFFSET being non-zero (on) or zero (off).
Maximum Value
Maximum value within current detection period. The previous maximum value will be deleted every time
press the detection switch.
Alarm Level
Set by operator. Trigger sound-light alarm when detection value exceeds the alarm value.
5.4. System Menu
The RLGD-100 system menu is shown in below Fig.5-4.
Fig.5-4 System Menu
RLGD-100 REMOTE LASER GAS DETECTOR
16
5.5. Alarm Level
Scroll down to Alarm Level, press ENTER, then use ‘▲’or ‘▼’ to increase or derease the value. Press ENTER to save the setting, or press ‘ESC’ to cancel.
Press ‘ENTER’ to enter
submenu
Press ‘▲’ or ‘▼’ to increase or decrease the value
Fig.5-5 Alarm Level Setting Menu
5.6. Offset Value
Scroll down to Offset Value, press ENTER, then use ‘▲’or ‘▼’ to increase or derease the value. Press ENTER to save the setting, or press ‘ESC’ to cancel.
Press ‘ENTER’ to enter
submenu
Press ‘▲’ or ‘▼’ to increase or decrease the value
Fig.5-6 Offset Value Setting Menu
RLGD-100 REMOTE LASER GAS DETECTOR
17
NOTE: Set offset = (1-100), the offset indicator is on, set offset = 0, the offset indicator is off.
Restarting system will not change the offset value.
5.7. Sound & Light
Scroll down to Sound & Light, press ENTER, then use ‘▲’ or ‘▼’ to select sound volume among mute, low, medium and high. Press ENTER’ to continue setting Alarm LED, tick the selections to Enable or Disable. Press ENTER’ to save the settings, or press ‘ESC’ to cancel.
Press ‘ENTER’ to enter submenu
Press ‘▲’ or ‘▼’ to increase or decrease volume
Press ‘▲’ or ‘▼’ to Enable or Disable
Fig.5-7 Sound & Light Setting Menu
NOTE: if set sound volume’ = mute, or disable alarm LED, no sound or light alarm
available when methane leak detected.
5.8. Brightness
Scroll down to Brightness, press ENTER, then use ‘▲’or ‘▼’ to increase or derease the value. Press ENTER to save the setting, or press ‘ESC’ to cancel.
RLGD-100 REMOTE LASER GAS DETECTOR
18
Press ‘ENTER’ to enter submenu
Press ‘▲’ or ‘▼’ to increase or decrease brightness
Fig.5-8 Sound & Light Setting Menu
5.9. System Settings
Scroll down to System Set., press ENTER, it shows the secondary menu comprising Date & Time, Screen Standby, Language, Wireless, Data Storage and Status.
Press ‘ENTER’ to enter submenu
Press ‘▲’ or ‘▼’ to scroll up or down
Fig.5-9 System Setting
5.9.1 Date & Time
Enter into Data & Time, press ENTER to edit, then use ‘▲’or ‘▼’ to increase or derease the value. Press ENTER to save the setting, or press ‘ESC’ to cancel.
RLGD-100 REMOTE LASER GAS DETECTOR
19
Press ‘ENTER’ to enter submenu
Press ‘ENTER’ to start edit, then
press ‘▲’ or ‘▼’ to increase or decrease the value
Fig.5-10 Data & Time Setting Menu
NOTE: After a long shut-off or pulling-out of the battery, please reset data & time.
5.9.2 Screen Standby
Scroll down to Screen Standby’, press ‘ENTER’, then use ‘▲’or ‘▼’ to select standby time. Press ENTER’ to save the setting, or press ‘ESC’ to cancel.
Press ‘ENTER’ to enter submenu
Press ‘▲’ or ‘▼’ to select standby time
Fig.5-11 Screen Standby Setting Menu
RLGD-100 REMOTE LASER GAS DETECTOR
20
5.9.3 Language
Scroll down to Language, press ENTER, then use ‘▲’or ‘▼’ to select language. Press ENTER to save the setting, or press ‘ESC’ to cancel.
Press ‘ENTER’ to enter submenu
Press ‘▲’ or ‘▼’ to select language
Fig.5-12 Language Setting Menu
5.9.4 Wireless
Scroll down to Wireless, press ENTER, then use ‘▲’or ‘▼’ to enable or disable wireless fucntion. Press ENTER to save the setting, or press ‘ESC’ to cancel.
Press ‘ENTER’ to enter submenu
Press ‘▲’ or ‘▼’ to enable or disable
Fig.5-13 Wireless Setting Menu
RLGD-100 REMOTE LASER GAS DETECTOR
21
NOTE: The wireless symbol will display on status bar when its enabled, and indicates ID, IP
and Port number after setting succeeded.
5.9.5 Data storage
Scroll down to Data Storage, press ENTER, then use ‘▲’ or ‘▼’ to enable or disable the fucntion. Press ENTER to save the setting, or press ‘ESC’ to cancel.
Press ‘ENTER’ to enter
submenu
Press ‘▲’ or ‘▼’ to enable or disable
Fig.5-14 Data Storage Setting Menu
NOTE: All detection data will be stored in the instrument when data storage enabled, and can be
read through the client software provided by FPI.
5.9.6 Status
Scroll down to Status, press ENTER’ to check operation status, instrument ID and version.
RLGD-100 REMOTE LASER GAS DETECTOR
22
Press ‘ENTER’ to enter submenu
Operation status
Fig.5-15 Status
5.10. Others
5.10.1 Low Battery
If the battery symbol turns to yellow, is to remind low battery only to last another 15 mins. Up to the indication Low Battery’, as shown in below Fig.5-16, the instrument will power off automatically in 30s.
Fig.5-16 Low Battery
RLGD-100 REMOTE LASER GAS DETECTOR
23
6 Maintenance & Troubleshooting
The advanced design of the RLGD-100 makes it one of the most reliable leak survey instruments available. However, should you experience problems with the instrument or suspect that the instrument is not operating properly, do not use the instrument for leak survey work until the problem is resolved.
Only a qualified RLGD-100 repair technician should attempt to repair or adjust the instrument. There are no user serviceable components within the instrument that can be repaired or replaced.
6.1. General Maintenance
Preventive maintenance of the RLGD-100 is limited to: Please use soft wet cloth to clean dirt or contaminates from the lens, no organic solvent should be used for
cleaning.
Please always keep the lens covered when the instrument is not in use. Please remove the battery when the instrument is not in use, and store the battery in a proper manner. Do not point the laser directly to sunlight to avoid possible damage to internal components.
6.2. Troubleshooting
The following table provides a list of common problems and solution. Should you have a problem not listed or the solution doesn’t work, please contact FPI for further assistance.
SYMPTOM
SOLUTION
Unable to power on
Try to press again the detection switch about 3 seconds till heard of the beep tone.
Check if out of battery? (refer to section 3.3 ‘Battery Charging’ in this manual. )
No detection tone
Check if the sound volume is on? (refer to section 5.7 ‘Sound & Light’ in this manual.)
No alarm sound
Check if the alarm limit is too high? (refer to section 5.5 ‘Alarm Level’ in this manual.)
Check if the sound volume is on? (refer to section 5.7 ‘Sound & Light’ in this manual.)
Unable to charge the battery
Check if the battery laid in right polarity? Check if the charger, adapter and power supply properly connected? Check if the charger
red indicator is on? (refer to section 3.3 ‘Battery Charging’ in this
manual.)
RLGD-100 REMOTE LASER GAS DETECTOR
24
Should you request information or assistance not included in this manual, please contact FPI or its authorized service center.
Loading...
