Page 1
DARKLIGHT
USER’S GUIDE
F-Vision LLC © All Rights Reserved.
F-PEDALS
PULSE OF REBELLION
Page 2
Congratulations on your new F-Pedal !
I know you are ready to rock but Please Read
through this guide before you start.
You will find important information about this pedal
and useful tips.
F-Vision LLC © All Rights Reserved.
DarkLight - User’s Guide F-Pedals - PULSE OF REBELLION SERIES
Please don’t be shy to share photos, videos or
stories of your epic moments rockin’ out F-pedals!
Stay connected with us and many other cool artists
on our social medias and be part of our F-amily.
I truly hope our pedals will inspire you to create
amazing music.
Page 3
STEP 1 Plug in audio and power cables
STEP 2 Stomp on the foot switch and turn on the Robotholic
STEP 3 Figure it out yourself….!
End of this User’s Guide
DarkLight - User’s Guide F-Pedals - PULSE OF REBELLION SERIES
STEP 4 If STEP 3 Failed…
…keep reading.
A tremendous amount of time and
brain power has been dumped into
this User’s Guide.
You’d be better off reading it !
F-Vision LLC © All Rights Reserved.
Page 4
TOP PANEL CONTROLS
DARK
TONE!
When the Tone control is set in in the
center, the
signal is unchanged. Turning the Tone
control clockwise Increases the high
frequencies (treble) of your sound.
Turning the Tone control
counterclockwise boosts the low
frequencies (bass) of the signal.
This Control has a built in LED light to
indicate the state on/off of the unit.
TRUE BYPASS FOOT SWITCH!
Turns the pedal ON/OFF.
BOOST
Use this control to increase the
main boost/drive of DarkLight
F-Pedals - PULSE OF REBELLION SERIESDarkLight - User’s Guide
F-Vision LLC © All Rights Reserved.
LIGHT !
Over-boosts the distortion only of
high frequencies.
Over-boosts the distortion only of low frequencies.
DISTORTION
Use this knob to set the amount of distortion
you wish to apply to the original signal.
Page 5
RIGHT PANEL CONNECTIONS
A.C. Adapter !
(Not included) Use a standard Center Negative 9V Power Supply.
You can use a power supply up to 18V (make sure it’s regulated)
There is No Battery Slot inside this pedal.
Input Jack 1/4 Inches
This is where you plug your guitar (or any
other instrument of your choice) using
a standard 1/4 Inch Jack cable.
F-Pedals - PULSE OF REBELLION SERIESDarkLight - User’s Guide
F-Vision LLC © All Rights Reserved.
Page 6
Please do not try to open
the pedal! Keep in mind
that if the stickers on the
screws are removed or
damaged you will lose
your Warranty.
FXP!
Here you can connect an External Pedal
Control (Optional) to control the BOOST
by foot.
Output Jack 1/4 Inches
Connect here the 1/4 inch Jack that goes to
your Amplifier or other system of your choice.
F-Pedals - PULSE OF REBELLION SERIES
LEFT PANEL CONNECTIONS
DarkLight - User’s Guide
F-Vision LLC © All Rights Reserved.
Page 7
Warranty !
If you experience a malfunction of the pedal, depending on the country and region
you are!in,!you may either contact the dealer where you purchased the pedal from, or
you can reach us directly!at [email protected].
We will ask you to ship your pedals to us ONLY IF!we find it necessary to perform a
factory repair or replacement. Our!warranty is effective for 1 year (from the date of
purchase of a new unit) and only for issues caused by our manufacturing defects.!The
warranty will be voided if the unit has been misused, abused, modified by any
unauthorized parties, or if any seal sticker on the bottom screws is removed or
broken.!
Although you don’t need to register your product, we will ask for your original
receipt in order to process your request.
F-Pedals reserves the right to make changes or improvements on this
product!without incurring any obligation to install the same on!products previously
manufactured. F-Pedals is not responsible for injuries and/or damages related to the
use of our products.!
F-Pedals - PULSE OF REBELLION SERIES
DarkLight - User’s Guide
F-Vision LLC © All Rights Reserved.
