Foxwell Technology I70PRO User Manual
Vehicle diagnostic equipment
i70 Pro
User instruction
Trademarks
FOXWELL is trademark of Shenzhen Foxwell Technology Co., Ltd.
All other marks are trademarks or registered trademarks of their respective
holders.
Copyright Information
©2015 Shenzhen Foxwell Technology Co., Ltd.
All rights reserved.
Disclaimer
The information, specifications and illustrations in this manual are based on the
latest information available at the time of printing.
Foxwell reserves the right to make changes at any time without notice.
Visit our website at:
www.foxwelltech.com
For Technical Assistance, send us email at
support@foxwelltech.com
1
One-Year Limited Warranty
Subject to the conditions of this limited warranty, Shenzhen Foxwell
Technology Co., Ltd (“FOXWELL”) warrants its customer that this product is
free of defects in material and workmanship at the time of its original
purchase for a subsequent period of one (1) year.
In the event this product fails to operate under normal use, during the
warranty period, due to defects in materials and workmanship, FOXWELL will,
at its sole option, either repair or replace the product in accordance with the
terms and conditions stipulated herein.
Terms and Conditions
1 If FOXWELL repairs or replaces the product, the repaired or replaced
product shall be warranted for the remaining time of the original warranty
period. No charge will be made to the customer for replacement parts or
labor charges incurred by FOXWELL in repairing or replacing the defective
parts.
2 The customer shall have no coverage or benefits under this limited
warranty if any of the following conditions are applicable:
a) The product has been subjected to abnormal use, abnormal conditions,
improper storage, exposure to moisture or dampness, unauthorized
modifications, unauthorized repair, misuse, neglect abuse, accident,
alteration, improper installation, or other acts which are not the fault of
FOXWELL, including damage caused by shipping.
b) The Product has been damaged from external causes such as collision
with an object, or from fire, flooding, sand, dirt, windstorm, lightning,
earthquake or damage from exposure to weather conditions, an Act of God,
or battery leakage, theft, blown fuse, improper use of any electrical source, or
the product was used in combination or connection with other product,
attachments, supplies or consumables not manufactured or distributed by
FOXWELL.
2
3 The customer shall bear the cost of shipping the product to FOXWELL. And
FOXWELL shall bear the cost of shipping the product back to the customer
after the completion of service under this limited warranty.
4 FOXWELL does not warrant uninterrupted or error-free operation of the
product. If a problem develops during the limited warranty period, the
consumer shall take the following step-by-step procedure:
a) The customer shall return the product to the place of purchase for repair or
replacement processing, contact your local FOXWELL distributor or visit our
website www.foxwelltech.com to get further information.
b) The customer shall include a return address, daytime phone number
and/or fax number, complete description of the problem and original invoice
specifying date of purchase and serial number.
c) The customer will be billed for any parts or labor charges not covered by
this limited warranty.
d) FOXWELL will repair the Product under the limited warranty within 30 days
after receipt of the product. If FOXWELL cannot perform repairs covered
under this limited warranty within 30 days, or after a reasonable number of
attempts to repair the same defect, FOXWELL at its option, will provide a
replacement product or refund the purchase price of the product less a
reasonable amount for usage.
e) If the product is returned during the limited warranty period, but the
problem with the product is not covered under the terms and conditions of
this limited warranty, the customer will be notified and given an estimate of
the charges the customer must pay to have the product repaired, with all
shipping charges billed to the customer. If the estimate is refused, the
product will be returned freight collect. If the product is returned after the
expiration of the limited warranty period, FOXWELL’ normal service policies
shall apply and the customer will be responsible for all shipping charges.
5 ANY IMPLIED WARRANTY OF MERCHANTABILITY, OR FITNESS FOR
A PARTICULAR PURPOSE OR USE, SHALL BE LIMITED TO THE
DURATION OF THE FOREGOING LIMITED WRITTEN WARRANTY.
OTHERWISE, THE FOREGOING LIMITED WARRANTY IS THE
3
CONSUMER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED. FOXWELL SHALL NOT
BE LIABLE FOR SPECIAL, INCIDENTAL, PUNITIVE OR CONSEQUENTIAL
DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF ANTICIPATED
BENEFITS OR PROFITS, LOSS OF SAVINGS OR REVENUE, LOSS OF
DATA, PUNITIVE DAMAGES, LOSS OF USE OF THE PRODUCT OR ANY
ASSOCIATED EQUIPMENT, COST OF CAPITAL, COST OF ANY
SUBSTITUTE EQUIPMENT OR FACILITIES, DOWNTIME, THE CLAIMS OF
ANY THIRD PARTIES, INCLUDING CUSTOMERS, AND INJURY TO
PROPERTY, RESULTING FROM THE PURC HASE OR USE OF THE
PRODUCT OR ARISING FROM BREACH OF THE WARRANTY, BREACH
OF CONTRACT, NEGLIGENCE, STRICT TORT, OR ANY OTHER LEGAL
OR EQUITABLE THEORY, EVEN IF FOXWELL KNEW OF THE
LIKELIHOOD OF SUCH DAMAGES. FOXWELL SHALL NOT BE LIABLE
FOR DELAY IN RENDERING SERVICE UNDER THE LIMITED
WARRANTY, OR LOSS OF USE DURING THE PERIOD THAT THE
PRODUCT IS BEING REPAIRED.
6. Some states do not allow limitation of how long an implied warranty lasts,
so the one-year warranty limitation may not apply to you (the Consumer).
Some states do not allow the exclusion or limitation of incidental and
consequential damages, so certain of the above limitations or exclusions may
not apply to you (the Consumer). This limited warranty gives the Consumer
specific legal rights and the Consumer may also have other rights which vary
from state to state.
4
Safety Information
For your own safety and the safety of others, and to prevent damage to the
equipment and vehicles, read this manual thoroughly before operating your
tool. The safety messages presented below and throughout this user’s
manual are reminders to the operator to exercise extreme care when using
this device. Always refer to and follow safety messages and test procedures
provided by vehicle manufacturer. Read, understand and follow all safety
messages and instructions in this manual.
Safety Message Conventions Used
We provide safety messages to help prevent personal injury and equipment
damage. Below are signal words we used to indicate the hazard level in a
condition.
Indicates an imminently hazardous situation which, if not avoided, will result
in death or serious injury to the operator or to bystanders.
Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury to the operator or to bystanders.
Indicates a potentially hazardous situation which, if not avoided, may result in
moderate or minor injury to the operator or to bystanders.
Important Safety Instructions
And always use your tool as described in the user’s manual, and follow all
safety messages.
● Do not route the test cable in a manner that would interfere with driving
controls.
5
● Do not exceed voltage limits between inputs specified in this user’s manual.
● Always wear ANSI approved goggles to protect your eyes from propelled
objects as well as hot or caustic liquids.
● Fuel, oil vapors, hot steam, hot toxic exhaust gases, acid, refrigerant and
other debris produced by a malfunction engine can cause serious injury or
death. Do not use the tool in areas where explosive vapor may collect, such
as in below-ground pits, confined areas, or areas that are less than 18 inches
(45 cm) above the floor.
● Do not smoke, strike a match, or cause a spark near the vehicle while
testing and keep all sparks, heated items and open flames away from the
battery and fuel / fuel vapors as they are highly flammable.
● Keep a dry chemical fire extinguisher suitable for gasoline, chemical and
electrical fires in work area.
● Always be aware of rotating parts that move at high speed when an engine
is running and keep a safe distance from these parts as well as other
potentially moving objects to avoid serious injury.
● Do not touch engine components that get very hot when an engine is
running to avoid severe burns.
● Block drive wheels before testing with engine running. Put the transmission
in park (for automatic transmission) or neutral (for manual transmission). And
never leave a running engine unattended.
● Do not wear jewelry or loose fitting clothing when working on engine.
6
Table of Contents
SAFETY MESSAGE CONVENTIONS USED..........................................................................................................5
IMPORTANT SAFETY INSTRUCTIONS..................................................................................................................5
1.1 BOLD TEXT................................................................................................................................................ 10
1.2 SYMBOLS AND ICONS................................................................................................................................ 10
1.2.1 Solid Spot.........................................................................................................................................10
1.2.2 Arrow Icon........................................................................................................................................10
1.2.3 Note and Important Message....................................................................................................... 10
2.1 SCANNER DESCRIPTIONS..........................................................................................................................12
2.2 VCI DESCRIPTIONS................................................................................................................................... 14
2.3 ACCESSORIES............................................................................................................................................15
2.4 TECHNICAL SPECIFICATIONS.....................................................................................................................17
3.1 POWERING UP THE SCANNER...................................................................................................................17
3.1.1 Internal Battery Pack......................................................................................................................18
3.1.2 5V AC/DC Power Supply...............................................................................................................18
3.2 SHUTTING DOWN THE SCANNER..............................................................................................................18
3.3 SCREEN LAYOUT OF HOME SCREEN....................................................................................................... 19
3.3.1 Application Buttons.........................................................................................................................19
3.3.2 Android Toolbar...............................................................................................................................20
4.1 ESTABLISHING VEHICLE COMMUNICATION...............................................................................................22
4.1.2 VCI Connection...............................................................................................................................23
4.1.2.1 Bluetooth Communication..........................................................................................................24
4.1.2.1 USB Communication...................................................................................................................25
4.2 VEHICLE IDENTIFICATION.......................................................................................................................... 25
4.2.1 VIN Scan Hotkey.............................................................................................................................26
4.2.2 Automatic VIN Aquisition...............................................................................................................26
4.2.3 Manual VIN Entry............................................................................................................................28
4.2.4 Manual Vehicle Selection.............................................................................................................. 29
4.3 SYSTEM SELECTION..................................................................................................................................29
4.3.1 Auto Scan.........................................................................................................................................30
ONE-YEAR LIMITED WARRANTY...................................................................................................................2
SAFETY INFORMATION.................................................................................................................................... 5
1 USING THIS MANUAL.................................................................................................................................. 10
2 INTRODUCTION............................................................................................................................................. 11
3 GETTING STARTED......................................................................................................................................17
4 DIAGNOSTIC OPERATIONS.......................................................................................................................22
7
4.3.2 Control Unit......................................................................................................................................32
4.4 DIAGNOSTIC OPERATIONS........................................................................................................................33
4.4.1 ECU Information............................................................................................................................. 33
4.4.2 Read Codes.....................................................................................................................................34
4.4.3 Freeze Frame Data........................................................................................................................35
4.4.4 Erase Codes....................................................................................................................................36
4.4.5 Live Data..........................................................................................................................................37
4.4.5.1 All Data..........................................................................................................................................37
4.4.5.2 Custom Data List.........................................................................................................................39
5 BI-DIRECTIONAL TEST OPERATIONS.................................................................................................... 41
5.1 ACTIVE TESTS........................................................................................................................................... 41
5.2 ADAPTATION.............................................................................................................................................. 43
5.3 CODING AND PROGRAMMING....................................................................................................................43
6.1 OIL LIGHT RESET...................................................................................................................................... 44
6.1.1 Oil Reset With One Button............................................................................................................ 44
6.1.2 Manual Reset.................................................................................................................................. 44
6.1.3 Auto Reset.......................................................................................................................................45
6.2 ELECTRONIC PARKING BRAKE (EPB) SERVICE...................................................................................... 45
6.3 TIRE PRESSURE MONITORING SYSTEM (TPMS) PROGRAMMING..........................................................47
6.4 ABS/AIRBAG SERVICES............................................................................................................................47
6.5 STEERING ANGLE SENSOR (SAS) CALIBRATION....................................................................................47
6.6 DIESEL PARTICULATE FILTER (DPF) REGENERATION............................................................................47
7.1 BROWSE PICTURE.....................................................................................................................................48
7.1.1 How to Take a Screenshot............................................................................................................48
7.1.2 Review Screenshot.........................................................................................................................48
7.2 PLAYBACK DATA........................................................................................................................................49
7.3 DATA LOGGING & STORED DATA MANAGEMENT.................................................................................... 50
10.1 LANGUAGE...............................................................................................................................................52
10.2 CHANGE DISPLAY MODE........................................................................................................................ 52
10.3 CHANGE UNITS........................................................................................................................................53
10.4 USER INFORMATION................................................................................................................................53
10.5 RESET SETTING...................................................................................................................................... 53
6 SERVICE AND MAINTENANCE OPERATIONS...................................................................................... 43
7 DATA MANAGER...........................................................................................................................................48
8 PRINT OPERATIONS....................................................................................................................................50
9 REMOTE CONTROL......................................................................................................................................51
10 SETTING........................................................................................................................................................ 51
11 ABOUT........................................................................................................................................................... 53
8
12 REGISTRATION AND UPDATE................................................................................................................54
12.1 CREATE A FOXWELL ID.......................................................................................................................... 54
12.1.1 Register with Built-in Update Client FoxScanner....................................................................55
12.1.2 Register through Website............................................................................................................57
12.2 REGISTER YOUR SCANNER.................................................................................................................... 61
12.2.1 Register Through Website.......................................................................................................... 61
12.2.2 Register With Built-in Update Client FoxScanner................................................................... 63
12.3 UPDATE THE SCANNER...........................................................................................................................64
9
1 Using This Manual
1.Connect the 5V power adapter to scanner and plug it to the wall socket.
2.Press the power switch of the scan tool to power it on; meanwhile the
We provide tool usage instructions in this manual. Below are the conventions
we used in the manual.
1.1 Bold Text
Bold text is used to highlight selectable items such as buttons and menu
options.
Example:
Press the ENTER button to select.
1.2 Symbols and Icons
1.2.1 Solid Spot
Operation tips and lists that apply to specific tool are introduced by a solid
spot ●.
Example:
When System Setup is selected, a menu that lists all available options
displays. Menu options include:
● Languages
● Display Mode
● Unit
● User Information
● Resetting
1.2.2 Arrow Icon
An arrow icon indicates a procedure.
Example:
To connect to wall plug:
scanner tool starts charging automatically also.
1.2.3 Note and Important Message
Note
A NOTE provides helpful information such as additional explanations, tips,
and comments.
Example:
10
NOTE
Test results do not necessarily indicate a faulty component or system.
Important
IMPORTANT indicates a situation which, if not avoided, may result in
damage to the test equipment or vehicle.
Example:
IMPORTANT
Do not soak scanner as water might find its way into the scanner.
2 Introduction
i70Pro, an Automotive Diagnostic Platform Generation Il from Foxwell, is
IP67 rated waterproof, dustproof, and shockproof automotive diagnostic
system and is built to resist the impact and damage of even the toughest
workshop environment. Equipped with INTEL QUAD-core processor and
super-sensitive multi-touch screen that responds to glove use and greasy
fingers and genuine WINDOWS 10 operating system, i70Pro delivers faster
and much more reliable diagnosis for workshops and technicians. In addition,
it provides professional diagnosis on more than 67 American, Asian and
European vehicle makes and has access to a vast range of controllers (ABS,
airbags, instrument cluster, etc.), live sensor data, and
system/component-level bi-directional controls.
The latest tablet scanner i70Pro delivers faster and smarter diagnosis for
workshops and technians. With IP67 rated waterproof, dustproof and
shockproof design, i70Pro can resist the impact and the damage of even the
toughest workshop environment and road tests. Through hardware and
software upgrades, technical staff cna now approach problems with greater
speed and accuracy, and produce comprehensive, professional reports.
There are two main components:
•i70Pro Tablet -- the central processor and monitor for the system
•Vehicle Communication Interface (VCI) -- the device for accessing vehicle
data
11
2.1 Scanner Descriptions
This section illustrates external features, ports and connectors of the
scanner.
Figure 2-1 Front View
1 8” LED IPS Capacitive Touch Screen - shows menus, test results and
operation tips.
2 Power Status Indicator - indicates the power status of the scanner.
3 Charge Status Indicator - indicates the charge status of the scanner.
Figure 2-2 Back View
4 Fingerprint Recognition- avoids repetitive password entry and just need
you put your finger on the induction zone to enter the system within 5
seconds.
12
5 Rear-Facing Camera - takes pictures of VIN number, faulty parts and
plates and shoots test videos.
6 Near Field Communication (NFC) - allows portable devices to establish
peer-to-peer radio communications, passing data from one device to
another by touching them or putting them very close together for Mobile
payments.
Figure 2-3 Top View
7 Power Switch - turns on the scanner, goes to sleep mode or wake up the
scanner from sleep mode, press and hold for 3 seconds for emergency
shutdown.
8 VOL + / VOL- -Short press to adjust the volume.
Figure 2-4 Right View
3 Charge Port
10 HDMI (high-definition multimedia interface) Port - outputs display of
the scanner for demonstration and training of the products.
11 USB Port - provides a USB connection for the PC or laptop.
NOTE
NFC and Fingerprint Recognition are optional facilities and not included in
the standard version
IMPORTANT
Do not use solvents such as alcohol to clean display. Use a mild nonabrasive
detergent and a soft cotton cloth.
13
2.2 VCI Descriptions
The Vehicle Communication Interface is a device used to connect the
vehicle ’ s diagnostic connector (DLC) with the Display Tablet for vehicle
data transmission.
Figure 2-7 Front View of VCI
1 Error Light - turns to red when hardware failure occurs or no
communication
2 USB Light - turns to green when the VCI is properly connected and
communicating with i70Pro tablet via USB cable.
3 Bluetooth Light -turns to green when the VCI is properly connected with
i70Pro tablet via Bluetooth communication.
4 Power Light - turns to green when powered on
Figure 2-8 Top View of VCI
5 Vehicle Data Connector-provides connection between vehicle and the
and VCI through the 16 pin diagnostic cable.
14
Figure 2-9 Bottom View of VCI
Main Unit
VCI
AC/DC Power Supply
Charger
USB Cable for VCI
6 USB Port-provides connection between vehicle and i70Pro through a USB
cable.
2.3 Accessories
This section lists the accessories that go with the scanner. If you find any of
the following items missing from your package, contact your local dealer for
assistance.
Item Item
DB15 Data Cable OBDII Adapter
Mercedes Benz
Audi 4 Pin Adapter
38 Pin Adapter
Clip Cable
Cigarette Lighter
15
Toyota 22 Pin Adapter Fiat 3 Pin Adapter
GM/Daewoo 12
Pin Adapter PSA 2 Pin Adapter
Kia 20 Pin Adapter Honda 3 Pin Adapter
Nissan 14 Pin Adapter
BMW 20 Pin Adapter
Mazda 17 Pin Adapter
Mitsubishi 12+16
Pin Adapter
Toyota 17 Pin Adapter
Table 2-1 Accessories
16
2.4 Technical Specifications
y
Item Description
Touch Screen 8’’ diagnonal, daylight readable color LCD screen, 1280*800 pixel
Dustproof and
Waterproof
Level
Operation
System
Processor MT8163(ARM Cortex, a53x4,1.3GHz)
Memory 2GB DDR3L
SSD Hard drive 32GB
System Type 32-bit operating Systems, x64-based processor
Display Backlit 1280*800 pixel 8” LED capacitive touch screen
Communication
interface
Camera 5 megapixels rear-facing
Built-in Battery
Protocols
Dimensions 230*155*21mm
IP67
Andriod
Built-in WIFI 802.11 b/g/n Wireless LAN
USB2.0 OTG/standard USB 2.0 HOST
Bluetooth 4.0 (10-20 m)
8000 mAh, Lithium-polymer battery, chargeable via 5V AC/DC power
suppl
ISO9141-2, ISO14230-2, ISO15765-4, K/L lines, Double K Line
SAE-J1850 VPW, SAE-J1850PWM, CAN ISO 11898, High-speed,
Middle-speed, Lows-peed and Single wire CAN, KW81, KW82, GM
UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6,
SAE J1939, SAE J1939, SAE J1708, Fault-Tolerant CAN
Table 2-2 Technical Specifications
3 Getting Started
This section describes how to power on/down the scanner, provides brief
introductions of applications loaded on the scanner and display screen layout
of the scan tool.
3.1 Powering up the Scanner
Before using the i70Pro applications (including updating the scanner), please
make sure to provide power to the scanner.
The unit operates on any of the following sources:
● Internal Battery Pack
17
● 5V AC/DC Power Supply
1.
Connect the 5V power adapter to scanner and plug it to the wall socket.
2.
Press the power switch of the scan tool to power it on; meanwhile the
1.Swipe the rightmost side of the display and you will see the Settings icon of
2.Press the Settings icon and you will see the Power switch.
3.Press the Power switch and select the shut down option to power the
3.1.1 Internal Battery Pack
The tablet scanner can be powered with the internal rechargeable battery.
The fully charged battery is capable of providing power for 6.5 hours of
continuous operation.
For the first three times charging the battery, please make sure the charging
time should be 8-10 hours at least. After it, the battery can be fully charged
about 4 hours. These make lithium battery achieved its best performance in
the future.
NOTE
Please turn off the tablet to save power when not use.
3.1.2 5V AC/DC Power Supply
The scan tool can also be powered from a wall socket using the AC/DC
power supply. The AC/DC power supply also powers the internal battery pack
charging.
To connect to wall plug:
scanner tool starts charging automatically also.
3.2 Shutting Down the Scanner
All vehicle communication must be terminated before shutting down the
scanner. Forcing a shut down while communicating may lead to ECM
problems on some vehicles. Exit the Diagnostic application before powering
down.
To shut down the scanner:
the Windows system.
scanner off.
NOTE
In case of emergency, press and hold the Power button of the scanner for 5
seconds to force shutdown.
18
3.3 Screen Layout of Home Screen
When the scan tool boots up, press the Desktop tab from the Home screen of
the tablet. Then press the i70Pro desktop icon twice to launch the diagnostic
application.
Figure 3-1Sample Home Screen
1.Application Buttons
2.Android Tool Bar
3.3.1 Application Buttons
Figure 3-2 Sample Application Screen
This section briefly introduces the applications that are preloaded into the
scanner:
● Diagnostic – leads to test screens for diagnostic trouble code
information, live datastream,ECU information, active tests, coding and
other functions.
● Data Manager – leads to screens for saved screenshots and
19
pictures and playing back recorded live datastream，as well as stored
logging data.
●
Oscilloscope – leads to oscilloscope OS100 software to perform
electrical and electronic circuit tests.
●
Videoscope – leads to videoscope software connecting i70 to
videoscope with an Imager head cable for close vehicle inspection.
● Update – leads to screens for registration and updating of the scanner
and managing your scanner serial numbers and sending us feedbacks
about the scanner.
● Setting – leads to screens for adjusting default settings to meet your own
preference and view information about the scanner.
● About – leads to screen of product information such as serial number
and password, which is required for product registration.
● Customer Management – leads to screens for logging and managing
the client information of the workshop.
● Remote Control– leads to the application TeamViewer for remote
control when you need any support from Foxwell support team.
● Technical Data – stores some guided operation information etc.
3.3.2 Android Toolbar
Operation of the buttons located on the bwlow bar are described in the table
below:
20
