Foxpro 680 User Manual
Important Information
FOXPRO®’s goal is to provide our customers with the highest quality products in the
industry. We take great pride in manufacturing our products in the USA. Please do not
hesitate to contact us for assistance, comments or questions.
FOXPRO® Inc.
14 Fox Hollow Drive
Lewistown, PA 17044
Hours of Operation
Monday – Friday
8AM – 5PM EST
Contact Us
Customer Service: (717) 248-2507
Toll Free Orders Only: 866-463-6977
Fax: (717) 247-3594
General Inquiry E-mail: sales@gofoxpro.com
Stay up to date with the latest sounds by visiting our online sound library. Watch for
new products and upgrades from FOXPRO®. Visit us online:
www.gofoxpro.com
This manual, the animal sounds stored in your caller, and animal sounds purchased from FOXPRO® Inc. for
installation in your caller are protected by copyright.
Copyright ©℗ 2017 by FOXPRO® Inc.
Publication Date: February 27, 2017 – REV1
2
Table of Contents
Getting Started ............................................................................................................................................ 4
Quick Start Guide ......................................................................................................................................... 4
2-1 Patriot Requirements.......................................................................................................................... 4
2-2 Playing Sounds .................................................................................................................................... 4
Auxiliary Jack Function................................................................................................................................. 5
Using External Speakers .............................................................................................................................. 5
TX433 Transmitter Detailed Information ..................................................................................................... 5
5-1 Primary Display Area........................................................................................................................... 5
5-2 Main Menu ......................................................................................................................................... 5
5-3 Sound Settings: Volume Step .............................................................................................................. 5
5-4 Sound Settings: Play Mode ................................................................................................................. 5
5-5 Sound Settings: Fav Mute OR ............................................................................................................. 6
5-6 Display/Power: Backlight .................................................................................................................... 6
5-7 Display/Power: Bklt T.O. ..................................................................................................................... 6
5-8 Display/Power: Contrast ..................................................................................................................... 6
5-9 Display/Power: LCD Mode .................................................................................................................. 6
5-10 Display/Power: Auto Off ..................................................................................................................... 6
5-11 Timer/User: Stand Tmr ....................................................................................................................... 7
5-12 Timer: Alarm ....................................................................................................................................... 7
5-13 Remote Settings: Download List ......................................................................................................... 7
5-14 Remote Settings: AUX Cntrl ................................................................................................................ 7
5-15 Remote Settings: Snd Nums................................................................................................................ 7
5-16 Remote Settings: User 1 and User 2 ................................................................................................... 7
5-17 Remote Settings: About Info ............................................................................................................... 7
5-18 Remote Settings: Cable Detect ........................................................................................................... 8
Programming the Patriot ............................................................................................................................. 8
6-1 Obtaining New Sounds ....................................................................................................................... 8
6-2 Programming the Patriot .................................................................................................................... 8
6-3 Updating the Transmitter Playlist ....................................................................................................... 9
Maximizing Remote Range .......................................................................................................................... 9
Product Care & Maintenance .................................................................................................................... 10
Troubleshooting ........................................................................................................................................ 10
FCC & IC Information ............................................................................................................................... 10
Warranty Statement ................................................................................................................................ 11
3
Getting Started
IMPORTANT NOTE
THE PATRIOT TRANSMITTER IS NOT INTENDED TO OPERATE THE CALLER AT DISTANCES SHORTER THAN
1 METER (3 FEET). IF THE TRANSMITTER IS LOCATED TOO CLOSE TO THE CALLER, PROPER OPERATION
CANNOT BE ENSURED.
Congratulations on your purchase of the FOXPRO Patriot digital game call! To avoid personal injury and
product damage, be sure to read all operating instructions before operating.
Quick Start Guide
This is a brief operational overview to help you get started. We strongly recommend that you read the
manual in its entirety to fully understand all of the capabilities of the product.
2-1 Patriot Requirements
The Patriot is shipped without batteries. The Patriot requires 4 ‘AA’ batteries.
Installing Batteries in the Patriot
1. Open the battery compartment on the side of the Patriot.
2. Remove the plastic battery holder from the battery compartment.
3. Place the batteries into each cavity while observing polarity as indicated.
4. Place the battery tray back into the battery compartment and replace the battery compartment
door.
The TX433 remote control operates on a single 9V battery. It is recommended that you use a high-quality
alkaline battery.
Installing the Battery in the Patriot Remote:
1. Access the battery compartment by removing the door from the back of the remote. The door
slides down and off the remote.
2. Insert the 9V battery in the back of the remote.
3. Slide the battery compartment door back onto the remote.
2-2 Playing Sounds
1. Turn on the Patriot by moving the power switch to the on position (to the right). When powered
on, the Patriot pilot lamp illuminates green, indicating that it is powered on.
2. Turn on the Patriot speaker by moving the speaker switch to the right.
3. Turn on the TX433 transmitter by pushing and holding the power button for approximately 1-2
seconds.
4. Notice the black horizontal highlight bar on the display. The bar moves up and down the screen
as you use the scroll up or down arrow buttons.
5. Select the “Sound List” menu item to view the sounds installed or select the “Favorites” option
to view your favorites (by default, there will be no Favorites established).
6. After moving the highlight bar to the sound you wish to play, push the “Select” button a single
time to begin playback.
7. Use the volume up button to raise the volume level to your desired setting. The transmitter has
20 volume steps.
To mute the sound: Push the “Mute” button a single time. When muted, the mute status indicator on the
transmitter display shows an “M”. Un-muting is accomplished by pushing the “Mute” button a second time
and the “M” will no longer be displayed. To switch sounds: Use the scroll buttons to navigate to a different
4
