Foxpro 617 Users Manual

TOPIC

PAGE

Using the FOXPRO FX3 Digital Game Call

1

Quick Operating Guide

2

3

4

5

Using the Remote Control

6

6

6

7

10

10

11

About the FX3 Speakers

Batteries and Charging

Auxiliary Jack Function

Reprogramming Sounds
Online Programming Support Center

Downloading the FOXPRO Programming Utility

Programming Your FOXPRO FX3

Printing a Sound List

Maximizing Remote Control Range

Important Information

FOXPRO’s goal is to provide our customers with the highest quality products in
the industry. We take great pride in manufacturing our products in the USA.
Please do not hesitate to contact us for assistance, comments or questions.

FOXPRO Inc.

14 Fox Hollow Drive

Lewistown, PA 17044

[phone]

Fax: [phone]

Hours of Operation

Monday – Friday
8AM – 5PM EST

Contact Us

Customer Service: [phone]

Toll Free Orders Only: 866-463-6977

General Inquiry E-mail: [e-mail]

Stay up to date with the latest sounds by visiting our online sound library.
Watch for new products and upgrades from FOXPRO. Visit us online:

www.gofoxpro.com

Using the FOXPRO FX3 Digital Game Call

Congratulations on the purchase of your FOXPRO FX3 digital wildlife caller!
You have chosen a highly advanced product with reliability, ease-of-use, and
features that are second to none. The FX3 is the product of an engineering
effort that spanned several years. Please take this time to read and understand
the information in this instruction booklet. This will ensure that you receive the
maximum benefit from your new FOXPRO FX3.

Features

1. Rugged injection molded ABS housing

2. On/Off switch-manual volume control

3. Rear Speaker Slide Switch

4. Front Speaker Slide Switch

5. Low Battery Indicator LED

6. Sound Up/Down Keys

7. Reflex Horn Speaker

8. Rear Cone Speaker

9. Charger Jack

10. Rear Ext Speaker Jack

11. Auxiliary Jack

12. Front Ext. Speaker Jack

QUICK OPERATING GUIDE

Since the FX3 is shipped from the factory with no batteries installed, the first
step is to install 8 “AA” batteries. These may be alkaline or rechargeable
types. We strongly recommend high capacity NiMH rechargeable batteries over
alkaline types for maximum performance, particularly when using loud volume
levels.

Installing Batteries in the FX3

1. To install batteries, remove the battery door. The battery door is
located on the side of the caller, and is held in place with a knurled
thumbscrew.

2. Orient the batteries as per the directions shown in each cavity within
the holder.
NOTE: The battery polarity alternates.

3. Replace the battery door after the batteries are installed.

Installing Batteries in the TX5-LRB

The TX5-LRB transmitter operates from a 9V battery. Please use a high quality
alkaline battery.

1. Remove the battery compartment cover located on the rear of the
transmitter.

2. Connect the 9V battery to the connector plug, and orient the battery in
the transmitter.

3. Replace the battery compartment cover.

Playing Sounds Manually

1. Make sure that at least 1 of the speaker selector slide switches is set to
the right, or “ON” position.
