Four-Faith F-IPC110 User Manual
F-IPC110 Industrial
Computer User Manual
Document Version
Page
V2.0.0
Product Name: F-IPC110
Total: 26
F-IPC110 Industrial Computer
Model
Product Type
F-IPC110
Industrial Computer
User Manual
the user manual is suitable fort and the following model:
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen
Tel：+86 592-5907276 Fax:+86 592-5912735
Web:en.four-faith.com
Files Revised Record
Date
Version
Remark
Author
2016-1-21
V1.0.0
CYB/WZQ
2017-5-22
V1.1.0
Add accessibility and system update
XGF
2017-07-12
V1.1.1
Update hardware functions
Harven
2017-10-10
V2.0.0
Change of company address
LXP
F-IPC110 Industrial Computer USER MANUAL
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 26
Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China
http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735
F-IPC110 Industrial Computer USER MANUAL
Copyright Notice
All contents in the files are protected by copyright law, and all copyrights are reserved by
Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all
commercial use of the files from Four-Faith are forbidden, such as copy, distribute,
reproduce the files, etc., but non-commercial purpose, downloaded or printed by
individual (all files shall be not revised, and the copyright and other proprietorship notice
shall be reserved) are welcome.
Trademark Notice
Four-Faith、四信、 、 、 are all registered trademarks of Xiamen
Four-Faith Communication Technology Co., Ltd., illegal use of the name of Four-Faith,
trademarks and other marks of Four-Faith is forbidden, unless written permission is
authorized in advance.
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 3 of 26
Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China
http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735
Product appearance
F-IPC110 Industrial Computer USER MANUAL
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 26
Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China
http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735
F-IPC110 Industrial Computer USER MANUAL
Contents
Contents
Contents.............................................................................................................................................5
Contents
Chapter 1 Brief Introduction of Product........................................................................................ 7
1.1 General.................................................................................................................................. 7
1.2 Features and Benefits............................................................................................................ 8
1.3 Product Specification.......................................................................................................... 10
1.3.1Cellular Specification............................................................................................... 10
1.3.2 Hardware System..................................................................................................... 10
1.3.3Hardware Specification.............................................................................................11
Chapter 2 Installation Introduction................................................................................................... 13
2.1 Overview............................................................................................................................. 13
2.2 Encasement List.................................................................................................................. 13
2.3 Installation and Cable Connection...................................................................................13
Chapter 3 Hardware Functions......................................................................................................... 15
3.1 External Interface................................................................................................................15
3.1.1 Front view................................................................................................................ 15
3.1.2 Back view.................................................................................................................15
3.2 The front panel I/O connector.............................................................................................15
3.2.1 Audio Port(Speak-out, Mic-in)................................................................................ 15
3.2.2 LED Lights...............................................................................................................16
3.2.3 Serial（COM1-COM6）........................................................................................ 16
3.2.4 USB Interface...........................................................................................................17
3.2.5 Ethernet Interface（LAN/WAN）.......................................................................... 18
3.2.6 Display Interface(HDMI&VGA).............................................................................18
3.2.7 Power Interface........................................................................................................ 19
3.3 Internal interface specifications.......................................................................................... 19
3.3.1 SSD Interface(mSATA&J23)...................................................................................19
3.3.2 Display Interface (LVDS&CN3)............................................................................. 20
3.3.4 Mricro SD cards lot..................................................................................................20
3.3.5 SIM card slot............................................................................................................21
Chapter 4 Software Functions...........................................................................................................22
4.1 Android System...................................................................................................................22
4.1.1Display Interface.......................................................................................................22
4.1.2 USB.......................................................................................................................... 22
4.1.3 COM.........................................................................................................................22
4.1.4 TF Card.................................................................................................................... 22
4.1.5 Hard Disk................................................................................................................. 22
4.1.6 WIFI......................................................................................................................... 23
4.1.7 Ethernet.................................................................................................................... 23
4.1.8 Network Auto Switch...............................................................................................23
4.1.9 USB Camera............................................................................................................ 24
4.1.10 Voice.......................................................................................................................24
4.1.11 Hide navigation...................................................................................................... 24
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 26
Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China
http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735
F-IPC110 Industrial Computer USER MANUAL
4.1.12 Display Interface Setting....................................................................................... 24
4.1.13 Accessibility...........................................................................................................24
4.1.14 System update........................................................................................................ 25
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 26
Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China
http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735
F-IPC110 Industrial Computer USER MANUAL
Chapter 1 Brief Introduction of Product
1.1 General
IPC (Industrial Personal Computer, IPC) is industrial control computer, a bus
structure of the production process, electrical and mechanical equipment, process
equipment tools collectively performed to detect and control. IPC has important attributes
and characteristics of a computer, such as a computer having a CPU, hard drive, memory,
peripherals and interfaces, and operating system, network and protocol control,
computing power, user-friendly interface. Industrial products and technologies industry is
very special, are intermediate products, to provide reliable, embedded, intelligent
industrial computers for various other industries.
F-IPC110 ARM architecture processors combine Android operating system, and
device manufacturers emphasize video image processing effects to bring new solutions.
F-IPC110 integrates Freescale Cortex™-A9 i.MX6, support the Android operating system,
device manufacturers rely on conventional X86 architecture computing platform,
especially advertising media playback device manufacturers to bring lower power
consumption less heat s solution.
F-IPC110 is a function of the transmission belt 3G/4G ARM IPC, support 3G / 4G
dial-up Internet access, support for firewall, VPN, QOS, port mapping, DDNS, system log
storage, remote device management and other functions, support for open secondary
customer development, support BS media distribution system architecture graphics, 2D /
3D accelerator Open VG™1.1 for 2D; Open GLES2.0 for 3D video codecs: H.264 HP,
MPEG4 ASP, MPEG2 MP image processing BMP, JPG, PNG, GIF, temperature sensor
measuring industrial machine operating temperature to provide API, support for USB
infrared touch screen, supports USB camera, USB mouse, keyboard encryption lamp,
support HDMI, support for VGA, 1 Ethernet port, support for 3G / 4G networks, WIFI, 4
USB, 6 RS232, 2 RS485, solid state drives(SSD), SD external interface, supports OTG
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 26
Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China
http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735
F-IPC110 Industrial Computer USER MANUAL
High-powered industrial cellular module
Freescale Cortex™-A9 i.MX6 processor
Professional power supply design, with undervoltage, overvoltage, overcurrent,
Power range: DC 5~36V
Temperature（-35℃~75℃）
Air power connector, tightening does not fall off
Metal casing, heat resistance, impact resistance
Machine fanless design
TF, SIM card with anti-theft design
Built-in Android, LINUX (optional) Operating System
Support hardware and software WDT
Support auto recovery mechanism, including online detect, auto redial when
SSD storage (optional)，High-speed data read and write and to ensure security
Ethernet port: 1.5KV magnetic isolation
RS232port: 15KV ESD protection
SIM/UIM port: 15KV ESD protection
Antenna port: lightning protection(optional)
interface.
F-IPC110 support DC 5-36V DC wide input voltage and wide temperature properties
are industrial applications, offers a variety of API, easy to read hardware information
equipment manufacturers to achieve more development.
1.2 Features and Benefits
Design for Industrial Application
reverse polarity, short circuit, surge protection function
Stability and Reliability
offline to make Machine always online
and stability
Standard and Convenience
Xiamen Four-Faith Communication Technology Co.,Ltd. Page 8 of 26
Add： Floor 11, Area A06, No 370, chengyi street, Jimei, Xiamen.China
http://en.four-faith.com Tel： +86 592-5907276 Fax：+86 592-5912735
