Page 1
FOURBUDZ INC.
USA: 914.29.4BUDZ
CAN: 647.812.1455
Unit 3, 1800 Ironside Manor
Pickering, ON, CA
L1W 3J9
www.fourbudz.com
1 YEAR WARRANTY
ETL CERTIFIED
MULTIPLE SPECTRUM
MODES
WORLD CLASS
COMPONENTS
pro3
640W LED GROW LIGHT
LGTFB6LGL
Page 2
FEATURES
A 3.0mm aluminum heat sink
dissipates heat while a PWM
system directs ultra-quiet dual
fans to cool the entire unit with
maximum eff
Built strong with world class
componentry, steel framing, and
a step up transformer to reduce
actual power draw without losing
light intensity.
iciency.
.
The best quality dual chip 5w
LED chips from Epistar, Bridgelux,
Semiled and Edison are used, all
protected by a 3w bypass system.
90° magnifying lenses focus
light strength, optimizing PAR
performance and directing light
strength with maximum eff
iciency.
.
WARRANTY INFORMATION REQUEST
In order to fulfull the promises outlined in the warranty, please send all
the requested information below to our customer support team.
WARRANTY INFORMATION REQUEST
PRODUCT INFORMATION
MODEL NAME ____________________________________________________
MODEL SKU ____________________________________________________
PURCHASING AGENT ____________________________________________________
DATE PURCHASED ____________________________________________________
AGENT ADDRESS ____________________________________________________
AGENT PHONE ____________________________________________________
AGENT EMAIL ____________________________________________________
CUSTOMER INFORMATION
NAME ____________________________________________________
PHONE ____________________________________________________
ADDRESS ____________________________________________________
EMAIL ____________________________________________________
EXPLANATION OF ISSUE
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
***Please include in your request clear pictures of the defect or issue, an
explanation of the issue and your proof of purchase***
Each channel can be manually
adjusted for intensity, allowing
for the creation of a specturm
that is optimal for your plants
growth.
Remote control operated,
with WiFi compatibility upon
upgrade (*WiFi componentry is
NOT standard, but available at
additional cost)
2
Four channels separately control
Deep Red, Red, Blue and mid
range spectrum light to ensure
plants get the exact spectrum of
light for their stage of growth.
Digital screen displays spectrum
mode, channel light intensity, and
alerts of any issues related to fan
cooling operation.
[email protected]WWW.FOURBUDZ.COM
7
Page 3
ONE YEAR LIMITED WARRANTY
SPECIFICATIONS
CHANNELS
FOURBUDZ guarantees its lights against any defects in materials and workmanship. We
rigorously quality test our products, though defective parts may occur. Within one year of
the purchase date we will send a replacement for any defective parts quickly and free of
charge.
In the event that you require replacement parts, please take clear photos of the defective
parts to help us determine how we can help. As all FOURBUDZ lights are built on a
purely modular design, any defective parts will be easy to replace based on a ‘plug and
play’ format. Little more than a screwdriver will be needed. We pride ourselves on our
helpful customer support team, should the need for us arise during the procurement or
replacement of any defective parts.
In the event that you request the product be shipped back to us for repair, please provide
your name, address, phone number, email, product serial number, an explanation of the
issue and proof of purchase. Please note FOURBUDZ will not assume any costs related to
shipping the product to and from our location for repairs.
If for whatever reason your light is damaged or not working and it is not the result of a
defect in materials or workmanship, repairs or replacement parts will not be covered under
warranty (Please see the ‘technical support’ section below for further direction in this
regard). If the light has been repaired or altered by any entity other than FOURBUDZ Inc,
this will void the warranty indef.initely.
This warranty does not cover any ‘surface’ damage such as scratches, dents, or the like,
caused by any means, accidental or otherwise.
TECHNICAL SUPPORT
If you have any problems with the operation of your light, either before or after the
warranty period, feel free to contact us for support. Take a picture of the issue and send it
to us so we can help diagnose the problem and help in every way we can.
In the event that you may need a replacement part or repairs to your light outside the
purview of the one year limited warranty, FOURBUDZ will not assume any costs related to
the parts, repairs, or costs of shipping the light to or from our repair location.
Power Draw 180~200 watts
Output Wattage 640 watts
HPS Wattage
Equivalent
LED Source
LED Chip Make
Spectrum Modes Veg, Bloom, Full
Light Array
*all 5W double
chip*
Coverage Area
Operation
Beam Angle 90°
Magnifying Lens Yes
Driver Mean Well
Fan
Heat Sink Aluminum; 3.0 mm
Channels
Working Temp. -25°C to 55°C
Working Humidity 0-60%
Input Voltage 110V
Current Input 900mA
Frequency 50-60Hz
Certif
ications ETL; CE; RoHS
.
600 watts
64 pcs x 5w double
chip
Epistar, Bridgelux,
Semiled, Edison
22 pcs Red
16 pcs Deep Red
2 pcs Infrared
4 pcs Warm White
4 pcs Cool White
4 pcs Blue
10 pcs Royal Blue
2 pcs UV
up to 5.6 ft x 5.6 ft,
or 170cm x 170cm
Remote Control; WiFi
iOS/Android app
upgrade compatible
Dual fans, PWM
controlled
4; adjustable
intensity
Each channel controls a range of light on
the light spectrum.
CH1 controls deep reds for the f.lowering
stage, CH2 controls the mid range spectrum
to create a full spectrum of light, CH3
controls royal blue light for the vegetative
stage and CH4 controls red light to promote
optimum yields when f.lowering.
The LED light intensity for each channel can
be manually adjusted by the remote control.
To generate a custom spectrum, simply
press (+) or (-) on the remote and track the
intensity percentage of the channel on the
display. See page 4 of this manual for more.
LED Chip Channel Layout
CH1 16 pcs Deep Red (660nm)
2 pcs Infrared (730nm)
CH2 4 pcs Warm White (2700k)
4 pcs Blue (465~470nm)
2 pcs UV (395nm)
2 pcs Day White (6500k)
CH3 10 pcs Royal Blue (450~455nm)
2 pcs Day White (6500k)
CH4 22 pcs Red (620~630nm)
TIME & DISTANCE
The distance and amount of light plants
need will vary depending on what plants are
being grown, but general recommendations
for the amount of light and distance the
f
ixture should be from the plant canopy can
.
be found below.
Stage Time Distance
Seedling 12-14 hrs 22” - 24”
Vegetative 12-14 hrs 18” - 20”
Flowering 12-18 hrs 12” - 18”
6
[email protected]WWW.FOURBUDZ.COM
3
Page 4
COVERAGE AREA & P.A.R.
PRECAUTIONS
The distance of the light from the plant canopy will affect the coverage area and strength of
the light. We suggest you plan your crop according to how much canopy area your plants
will need as fully grown adult plants. During the f
recommend the light be from the plant canopy is 18-20” before there is a noticable drop in
yields. Light coverage at this distance is about 3 square feet, so plan your crops accordingly.
Distance of Light Footprint (Coverage Area) P.A.R.
12” or 30cm 2’ x 2’ or 60cm x 60cm 1066
24” or 60cm 3’ x 3’ or 90cm x 90cm 302
36” or 90cm 4.3’ x 4.3’ or 130cm x 130cm 153
48” or 120cm 5.6’ x 5.6’ or 170cm x 170cm 90
lowering stage, the furthest distance we
.
REMOTE CONTROL MANUAL
WiFi SIGNAL SWITCH
*Upgrade Necessary*
Press WiFi button to
switch to WiFi iOs/
Android phone app.
(+) ICON
Increase the intensity
of the LEDs controlled
under this channel by 5%
(observe display screen)
VEG MODE
Press button to activate
spectrum range optimal
for vegetative growth.
(CH1-20%; CH2-50%;
CH3-100%; CH4-0%)
Turn the light on or off by
Decrease the intensity
of the LEDs controlled
under this channel by 5%
(observe display screen)
Press button to activate
ON/OFF
pressing this button.
(-) ICON
BLOOM MODE
spectrum range
optimal for bloom
stage of growth. (all
channels-100%; full
spectrum)
FOURBUDZ lights are delivered to your door ready to use. Be sure to examine the entirety
of the casing and test all channel settings, display, remote and all other functionality. Be
sure to contact us immediately if there are any defective parts, and DO NOT operate the
system it is believed there may be defective parts.
FOURBUDZ lights are NOT waterproof. Therefore if the light must be stored prior to use, be
sure to store it in a location free from water, condensation and dust. Failure to do so could
result in personal injury or equipment damage.
DO NOT operate our lights under the wrong voltage conditions. Our lights are
manufactured with the expectation that they will run off of a standard 110V North
American power supply, although if it is run off 220V circuit conditions the lights will burn
out and you could damage other interior components.
DO NOT attempt to install and operate the light when it is touching the surface of any
water. A failure to abide by this precaution could result in equipment damange, personal
injury or damage to crops.
DO NOT install or store the light where it can be exposed to weather or temperatures
below freezing.
DO NOT install our lights barefoot, or with moist or wet hands.
DO NOT expose the light to water. If any electrical components of the f.ixture get wet,
unplug the appliance as soon as it is safe to do so.
DO NOT plug the light into a HID ballast.
Make sure the light is securely and correctly installed before attempting to operate it.
GENERAL MAINTENANCE
FOURBUDZ lights do not generally require maintenance aside from light cleaning. Be sure
to clean with non-conductive materials ONLY. Visually inspect the light while cleaning for
any obvious damage, faults or defects and contact us if you deem the light may need
servicing. The light may be dusted with a non-conductive brush. No f
luids should be used.
.
REMOTE CONTROL NOTES
Please aim the remote control at the display on the light when pressing any buttons. Each
time a (+) or (-) button is pressed, it changes the intensity of the channel by 5%. WiFi
controls are available with a light upgrade package ONLY. Contact the FOURBUDZ sales
team at [email protected] to purchase the WiFi upgrade package.
4
If the above cleaning methods do not work, contact the FOURBUDZ support team for
advice before attempting any other procedures yourself.
Do not attempt to service electrical equipment if standing water is present. Use caution
when servicing electrical equipment in a high-humidity environment. Use tools with
insulated handles when working with electrical equipment.
[email protected]WWW.FOURBUDZ.COM
5
