KF-P27W

Air purifier instruction manual

Remove, unsupported

ABLE OF CONTENTS

ACKAGE CONTENTS

Package Contents Speciﬁcations Safety Information Getting to Know Your Air Puriﬁer LED Display Controls Getting Started

· VeSync App Setup

· Connect with Amazon, Google Assistant, or IFTTT

Using Your Puriﬁer

· General Operation

Keeping Things Clean

· Cleaning the Air Puriﬁer

· Air Filter Indicator

· When Should I Replace the Air Filters?

· Replacing the Air Filters

· Resetting the Filter Indicator

· Cleaning the Dust Sensor

Troubleshooting VeSync App Troubleshooting Warranty Information Customer Support

1 1 2 4 5 6 7 8

9 9 9 11 11 11

11 12 13 13 14 16 17 17

1 x Smart True HEPA Air Puriﬁer 1 x Activated Carbon Filter 1 x Preliminary/HEPA Combination Filter 1 x User Manual

SPECIFICATIONS

ower Supply AC 120V / 60Hz

Rated Power 40W

Eective Range ≤ 300 ft² (≤ 30 m²)

Operating

Conditions

Noise Level ≤ 52dB

Clean Air Delivery

Rate (CADR)

Standby Power < 0.8W

Temperature: 14°F - 104°F (-10°C - 40°C)

135 CFM (230 m³/h)

SAFETY INFORMATION

o reduce the risk of ﬁre, electric shock, or other injury, follow all instructions and safety guidelines.

General Safety Plug and Cord

• Only use your air puriﬁer as described in this manual.

• Do not use your air puriﬁer outdoors.

• K

eep your air puriﬁer away from water, and wet or damp

areas. Never place in water or liquid.

• K

eep your air puriﬁer away from heat sources.

• Do not use where combustible gases or vapors are present.

• Supervise children when they are near the air puriﬁer

• Do not place anything into any opening on the air puriﬁer

, unless directed by the manual.

• Do not sit or place heavy objects on the air puriﬁer

• A

void environments that may cause moisture to build up inside the puriﬁer (such as a room with major temperature changes, or underneath an air conditioner).

• Always unplug your air puriﬁer before servicing (such as changing air ﬁlters).

• Do not use your air puriﬁer if it is damaged or not working correctly

Do not try to repair it yourself. Contact Customer Support (page 18).

, or if the cord or plug is damaged.

• K

eep the air puriﬁer near the outlet it is plugged into.

Do not use with an extension cord.

• Never place the cord near any heat source

• Do not cover the cord with a rug, carpet, or other covering. Do not place the cord under furniture or appliances.

• K

eep the cord out of areas where people walk often.

Place the cord where it will not be tripped over.

• Y

our air puriﬁer has a polarized plug (one prong is wider than the other), which ﬁts into a polarized outlet only one way. This is a safety feature to reduce the risk of electric shock. If the plug does not ﬁt, reverse the plug. If it still does not ﬁt, do not use the plug in that outlet.

Do not bypass this safety feature.

READ AND

SAVE THESE

INSTRUCTIONS

• W

ARNING: Do not use this air puriﬁer with solid-state

speed controls (such as a dimmer switch).

FCC ST

ATEMENT :

This dev

two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

Warning: Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

receiver is connected.

FCC Radiation Exposure S

ice complies with Part 15 of the FCC Rules. Operation is subject to the following

Reorient or relocate the receiving an　 tenna.

Increase the separation between the equipment and receiver.　

Connect the equipment into an outlet on a circuit different from that to which the 　

Consult the dealer or an experienced radio/TV technician for help.　

tatement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

GETTING T

O KNOW YOUR AIR PURIFIER

1. LED Display

2. Touch-Control Panel

3. Dust Sensor

4. Dust Sensor Cover

5. Filter Reset Button

6. Button Vent

7. Housing

8. Safety Switch

9. Activated Carbon Filter

10. HEPA Filter

11. Fine Preliminary Filter

12. Back Cover

10 11

LED DISPLA

1. P

ower Indicator

2. WiFi Indicator

3. Filter Indicator

4. Timer

5. Air Quality Indicator

6. A

uto Mode Indicator

7. Sleep Mode Indicator

8. Fan Speed Indicator

CONTROLS

Replace the attachment icon,Other Reference locations correspond to substitution

Replace the attachment icon

ower Button

• Press to turn the air puriﬁer on or o

• Press and hold for 5 seconds to use Smart Conﬁguration Mode

• Press and hold for 10 seconds to use APN Conﬁguration Mode

• Press and hold for 15 seconds to reset to factory settings.

* See e

xtended manual (QR code on page 3).

Display Button

• T

urns the display o.

• Press any button (e display back on.

xcept

) to turn the

WiFi Indicator

is o

is on

s 1 time

blink

per second

s 2 times

blink per second

s 4 times

blink

per second

blinks 2 times

per 5 seconds

WiFi Indicator S

Air puriﬁer is not conﬁgured with the

Conﬁguration with the V

Air puriﬁer is in Smart Conﬁguration Mode.*

Air puriﬁer is in APN Conﬁguration Mode.*

Air puriﬁer has been factory reset.*

Air puriﬁer cannot connect with router.

tatus

eSync app.

complete.

eSync app is

Sleep Mode Button

Fan Speed Button

Timer Button

• Turns Sleep Mode on or o (see page 11).

uto Button

urns Auto Mode on or o

• T (see page 11).

• Cycles through fan speeds: low

medium, and high.

• The fan speed cannot be changed during A

uto Mode or Sleep Mode.

• Creates or cancels a timer (see page 11).

s 1 time

blink

per 5 seconds

Air puriﬁer has connected with router

successfully, but the router is not connected to the VeSync server.

* See extended manual (QR code on page 3).

Air Quality Indicator

• Displays air quality using the dust sensor inside the air puriﬁer

• The air puriﬁer may tak

e up to 1 minute to detect air

quality.

Air Quality Indicator Chart

Color Air Quality

Red Bad

Yellow

Green

Blue

Moderate

Good

ery Good

GETTING S

TARTED

1. Open the back cover of the air puriﬁer and remove both

ﬁlters from their plastic packaging. [Figure 1.1]

Carbon Filter

Figure 1.1

2. Place the black activated carbon ﬁlter back into the air

puriﬁer

. Then, place the white HEPA ﬁlter back into the air puriﬁer. Make sure the pull tabs on both ﬁlters are facing out. [Figure 1.2]

1st

2nd

3rd

Figure 1.2

eplace the back cover by lining up the cover’s feet

3. R

with the matching slots on the bottom of the housing. Make sure that the triangular piece at the bottom of the cover is touching the safety switch. [Figure 1.3]

HEP Filter

4. Push the cover closed. [Figure 1.4]

Figure 1.4

5. Place the air puriﬁer on a hard, ﬂat surface

Leave 15 inches (38 cm) of clearance on all sides of the puriﬁer.

Figure 1.5

TE:

Do not remove the foam piece attached to the dust sensor cover.

[Figure 1.6]

DO NOT remove

. [Figure 1.5]

Figure 1.3

Figure 1.6

VeSync App Setup

1. Scan the QR code

, or download the VeSync app from

the App Store or Google Play Store. [Figure 2.1]

GET IT ON

Google Play

2. Open the V

Available on the

App Store

Figure 2.

eSync app. If you have an existing account, tap Log In to sign in to your account. If not, tap Sign Up to create a new account. [Figure 2.2]

3. Connect your mobile device to a 2.4GHz WiFi network.

[Figure 2.3]

TE:

The air puriﬁer can only be set up on a 2.4GHz

network.

4. Plug in your air puriﬁer and turn it on. [Figure 2.4]

Figure 2.4

5. Follow the in-app instructions to add your air puriﬁer

[Figure 2.5]

Figure 2.2

2.4GHz

Figure 2.5

Figure 2.3

Connect with Amazon® Alexa™,

Remove, unsupported

Google Assistant™, or IFTTT™

USING Y

OUR PURIFIER

TE:

You must create your own VeSync account to connect with Alexa, Google Assistant, or IFTTT.

• In the V

• T

eSync app, tap More at the bottom right of the

screen.

Link to Ale

Link to Google Assistant to view instructions.

o pair your VeSync app to the IFTTT app, see the

extended digital manual.

xa to view instructions.

General Operation

1. Press to turn on the air puriﬁer

will start automatically at low speed.

2. Optionally

also select Auto Mode or Sleep Mode, or create a timer.

NOTE:

• Y

• For best results, run the air puriﬁer at maximum

• T

3. Press

, press

ou can use the VeSync app to control all these functions, and more. See the extended manual (QR code on page 3).

speed for 15-20 minutes before using a lower speed or A

o eectively clean air, keep windows closed while the air puriﬁer is operating.

to turn o the air puriﬁer

to increase fan speed. Y

uto Mode.

. The air puriﬁer fan

ou can

For full instructions on using the VeSync app with your air puriﬁer, scan the QR code on page 3 to see the extended digital manual.

Auto Mode

Timer

Auto Mode uses the sensor inside the air puriﬁer to adjust the fan speed automatically based on air quality. For example, if the air quality is bad, the fan will automatically be set to high speed. See chart.

1. Press to turn on A

2. Press again to e

will also e

xit Auto Mode.

uto Mode.

xit Auto Mode. Pressing

uto Mode Chart

Color Air Quality Fan Speed

ellow

Green

Blue

Bad High

Moderate Medium

Good Lo

ery Good Sleep Mode

Sleep Mode

Sleep Mode uses the lowest possible fan speed to create a quiet environment.

1. Press to turn on Sleep Mode

2. Press again to e

will also e

xit Sleep Mode.

xit Sleep Mode. Pressing

You can set a timer between 1 and 12 hours.

1. Press

repeatedly to choose a time

2. When you stop pressing , the display will ﬂash 3

times and the timer will start.

3. The air puriﬁer will automatically power o once the

timer is ﬁnished.

To cancel a timer:

1. Press repeatedly until the display reads “ -:-- ”.

ait until “ -:-- ” ﬂashes 3 times, and the timer will

2. W

cancel.

Memory Function

When the air puriﬁer is plugged in, it will remember its programmed settings when turned o, and will resume these settings when turned back on.

Automatic Shuto

As a safety feature, the air puriﬁer will automatically turn o if the back cover is removed.

KEEPING THINGS CLEAN

Cleaning the Air Puriﬁer

Wipe the outside of the air puriﬁer with a dry cloth. Do not clean with water or any other liquid, to avoid risk of electric shock.

Air Filter Indicator

The Filter Indicator will light up as a reminder to check the air ﬁlters. The indicator will turn on automatically. You may not need to change your ﬁlters yet, but you need to check them when the indicator light turns on.

Reset the Filter Indicator by pressing the black reset button inside the vent on the side of the air puriﬁer (page 14).

When Should I Replace the Air Filters?

The air ﬁlters should be replaced every 6–8 months. You may need to replace your ﬁlters sooner or later depending on how often you use your air puriﬁer. Using your air puriﬁer in an environment with relatively high pollution may mean you will need to change the ﬁlters more often (even if the Filter Indicator is o).

Watch out for the signs of expired ﬁlters:

• Increased noise when the air puriﬁer is on

• Decreased airﬂow

• Unusual odors

• Visibly clogged ﬁlters

NOTE:

• The ﬁlters cannot be cleaned, only replaced.

• Only use L ﬁlters for this air puriﬁer.

• Scan the QR code to purchase new air ﬁlters.

evoit LV-PUR131-RF replacement

Replacing the Air Filters

1. Unplug the air puriﬁer and remove the back cover

2. Remove the old air ﬁlters and properly dispose of them.

3. Unwrap the new air ﬁlters. Place the Activated Carbon

Filter inside the housing ﬁrst. Make sure the pull tabs are facing out.

4. Install the T

the pull tabs are facing out.

5. R

eplace the back cover. The air puriﬁer will not power

on unless the back cover is replaced correctly.

6. Press the Filter Indicator reset button inside the vent

(see page 14).

rue HEPA Filter into the housing. Make sure

Resetting the Filter Indicator

Cleaning the Dust Sensor

Reset the ﬁlter indicator after changing the air ﬁlters.

1. Plug in the air puriﬁer and turn it on.

2. Locate the button vent on the side of the air puriﬁer.

[Figure 3.1]

Figure 3.1

3. Use a pen, pencil, or small object to press the black

reset button inside the vent. Press for 5 seconds. [Figure 3.2]

4. The ﬁlter indicator will turn o, indicating that the reset

is complete.

1. Turn o and unplug the air puriﬁer.

2. Open the dust sensor cover. [Figure 4.1]

Figure 4.

3. Use a cotton swab

[Figure 4.2]

4. Wipe the lens dry with a dry cotton swab

, dipped in water, to clean the lens.

Figure 4.2

TE:

Do not remove the foam piece attached to the dust sensor cover.

[Figure 4.3]

DO NOT remove

Figure 3.2

Figure 4.3

TROUBLESHOO

TING

Problem Possible Causes Solution

Air puriﬁer is not plugged into an outlet. Plug in to a powered electrical outlet.

Try plugging the air puriﬁer into a dierent outlet.

Properly replace the back cover (see page 8).

Immediately stop using the air puriﬁer and contact Customer Support (page 18).

Properly replace the back cover, activating the safety switch (see page 8).

Immediately stop using the air puriﬁer and contact Customer Support (page 18).

Immediately stop using the air puriﬁer and contact Customer Support (page 18). Do not try to open the air puriﬁer.

Press

eplace the air ﬁlters (see page 13).

Make sure there is clearance of at least 15 inches (38 cm) on all sides of the puriﬁer.

Air puriﬁer does not power on.

Air puriﬁer does not respond to button controls.

The air quality indicator always stays red, and the air puriﬁer is running on high speed.

The air quality indicator always stays blue, even though air quality is poor.

Air puriﬁer makes an unusual noise while operating.

Signiﬁcantly reduced airﬂow.

Outlet is not working properly

Back cover is not properly placed on the air puriﬁer.

Power cord is damaged.

Air puriﬁer is defective or malfunctioning.

Air puriﬁer is not plugged into an outlet. Plug in to a powered electrical outlet.

Back cover is not properly placed on the air puriﬁer.

Air puriﬁer is defective or malfunctioning.

The dust sensor needs to be cleaned. Clean the dust sensor (see page 14).

Air ﬁlters are dirty. Replace the air ﬁlters (see page 13).

Filters do not ﬁt properly. Properly place ﬁlters (see page 8).

A foreign object is inside the air puriﬁer.

Filter packaging has not been removed. Remove ﬁlters from packaging before use.

Fan speed is low.

Filter needs to be replaced. R

There is not enough clearance on all sides of the puriﬁer.

to adjust fan speed.

TROUBLESHOO

TING (cont.)

Problem Cause Solution

Room is too large for the air puriﬁer’s applicable area.

oor air puriﬁcation quality.

Filter reset button is still illuminated after replacing the air ﬁlter.

Air puriﬁer randomly turns o.

Air puriﬁer beeps repeatedly after being powered on or plugged in.

If your problem is not listed, please contact Customer Support (page 18).

Air inlet or outlet is blocked. Remove objects blocking air inlet or outlet.

Filters are not properly placed in housing.

The dust sensor needs to be cleaned. Clean the dust sensor (see page 14).

The ﬁlter indicator has not been reset correctly.

Air puriﬁer is defective or malfunctioning.

Make sure the room is smaller than 300 ft² (30 m²).

Properly place ﬁlters (see page 8).

Resetting the Filter Indicator (see page 14).

Immediately stop using the air puriﬁer and contact Customer Support (page 18).

VES

YNC APP TROUBLESHOOTING

Q: Why isn

• During the setup process, you must be on a

• Mak

Q: I already have another smart appliance connected. Why won’t this air puriﬁer connect?

• Close and relaunch the V

• Use APN Mode to set up the air puriﬁer

Q: I’m using APN Mode, but can’t ﬁnd the “VeSync” access point.

• Press and hold the power button on the air puriﬁer

• During APN Mode

’t my air puriﬁer connecting?

2.4GHz WiFi network. e sure the WiFi password you entered is

correct.

eSync app, then reset the

air puriﬁer.

for 10-14 seconds to trigger APN Mode “VeSync” access point will appear in your list of available WiFi connections.

, the WiFi indicator on the air puriﬁer will slowly blink. You will have 5 minutes to pair the air puriﬁer with your phone.

. The

Q: How do I change my WiFi network to a 2.4GHz WiFi network?

• Most dual-band routers support both 2.4G and 5G network

s. Select the WiFi name that does not end

in “_5G”.

• If your phone is attempting to connect to the 5G network, try “forgetting” or temporarily disabling the 5G network.

• If you are unsure do not have separate names, please contact your internet service provider.

Q: What is APN mode?

• APN Mode uses an access point (appearing in your phone puriﬁer to a WiFi network.

Q: My air puriﬁer is oine.

• Delete the oine air puriﬁer from the V

• Hard reset the air puriﬁer by pressing and holding the power button for more than 15 seconds. The WiFi indicator will blink 10 times and turn o

• Once the air puriﬁer has been deleted and reset, reconﬁgure your air puriﬁer with the V

NOTE: Power outages or changing WiFi routers may cause your air puriﬁer to go oine.

, or if the 2.4G and 5G networks

’s WiFi networks list) to connect the air

eSync app.

If your problem is not listed, please contact Customer Support (page 18).

ARRANTY INFORMATION

Product Name Smart True HEPA Air Puriﬁer

Model Number KF-P27W

Default Warranty Period 1 Year

For your own reference

TERMS & POLIC

Levoit warrants all products to be of the highest quality in material, craftsmanship, and service, eective from the date of purchase to the end of the warranty period.

Levoit will replace any product found to be defective due to manufacturer ﬂaws based on eligibility. Refunds are available within the ﬁrst 30 days of purchase. Refunds are only available to the original purchaser of the product. This warranty extends only to personal use and does not extend to any product that has been used for commercial, rental, or any other use in which the product is not intended for. There are no warranties other than the warranties expressly set forth with each product.

This warranty is non-transferrable. Levoit is not responsible in any way for any damages, losses, or inconveniences caused by equipment failure by user negligence, abuse, or use noncompliant with the user manual or any additional safety, use, or warnings included in the product packaging and manual.

This warranty does not apply to the following:

• Damage due to abuse vandalism.

• Improper or inadequate maintenance

• Damage in return transit.

• Unsupervised use by children under 18 years of age

Levoit and its subsidiaries assume no liability for damage caused by the use of the product other than for its intended use or as instructed in the user manual. Some states do not allow this exclusion or limitation of incidental or consequential losses so the foregoing disclaimer may not apply to you. This warranty gives you speciﬁc legal rights and you may also have other rights which may vary from state to state.

your order number and date of purchase.

, we strongly recommend that you record

Date of Purchase

Order Number

, accident, alteration, misuse, tampering, or

ALL EXPRESSED AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.

Additional 1-Year Warranty

You can extend your 1-year warranty by an additional year. Log onto www.levoit.com/warranty and enter your order number (for example, from Amazon or Houzz) to register your new product for the extended warranty.

If you are unable to provide the order number for your product, please type a short note in the order number ﬁeld along with the date you received your product.

Defective Products & Returns

If your product proves defective within the speciﬁed warranty period, please contact Customer Support via support@levoit.com with your order number. DO NOT dispose of your product before contacting us. Once Customer Support has approved your request, please return the unit with a copy of the invoice or your order number.

CUSTOMER SUPPORT

If you encounter any issues or have any questions regarding your new product, feel free to contact our helpful Customer Support Team. Your satisfaction is our goal!

Foshan Samyoo Electronic Co.,Ltd

No.2, 6th East Road , Jiangcun Industrial Zone, Leliu,

Shunde, Foshan, Guangdong, China 528322

Foshan Samyoo Electronic KFP72W User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
