Fosgate Audionics FAP T1 User Manual

HOME THEATER AUDIO

7.1 CHANNEL PREAMP/PROCESSOR

FAP T1

Introduction

Thank you and congratulations on your purchase of the Fosgate Audionics Preamp/Processor. The FAP T1 combines the best technologies, components, and software with a clean, user-friendly style, impeccable audio performance and leading edge capabilities, making it the perfect foundation for any music or home theater system.

This manual contains information on using the

FAP T1 Preamp/Processor. It is organized into two sections. “Installation” covers the location and connection of the preamp/processor in the system. Like many precision components, careful attention to the initial setup can yield dividends in higher performance and trouble-free use. “Operation” covers the controls and features of the preamp/processor, and how to use them to get the best effect. We strongly urge reading over the Installation and Operation portions of this manual before putting the

FAP T1 into service.

IMPORTANT: The FAP T1 is shipped from the factory in the following default mode:

Output Configuration 7.1

Speaker Size Small

All Crossovers 100Hz

After reading the rest of this manual and determining how your system should be set up, please refer to pages 18-24 to change these settings.

If your system will be operated in less than a 7.1 channel configuration, some DSP modes will not be available to you.

Fosgate Audionics .... a talented staff of experienced industry professionals.

Jim Fosgate, Senior Executive Consultant, one of the most renown surround processing circuit designers in the world, holds more than 25 patents in the audio industry. His latest efforts include Dolby®Pro Logic II—acclaimed as a milestone in matrix surround technology—and the FAVP1 tube surround processor/preamp. Jim continues to refine his designs in his home audio laboratories in Utah and Arizona.

Jim Strickland, Vice President of Engineering, has designed some extraordinary products including the famous and highly regarded Acoustat electrostatic loudspeakers, the

trans•nova®power amplifier series and now the Fosgate Audionics

trans•ana 1000.5 amplifier design. He has been a published AES member since 1970 and holds nine audio patents.

Charles Wood, Executive Consultant, originally founded Audionics of Oregon in 1969. In 1986 Audionics merged with

Fosgate Research to form Fosgate Audionics. Charles Wood and Jim Fosgate have been responsible for many industry "firsts" in multi-channel sound that have been widely adopted throughout the home theater industry.

Gary Church, Chief Acoustic Engineer, has been designing and developing loudspeakers for more than 25 years. His extensive experience and attention to detail has enabled him to lead a talented engineering team at our Rockford Acoustic Design (RAD) facility in Michigan.

The Best of All Worlds

Fosgate Audionics, part of Rockford Corporation, is one of the few companies with the resources to design and manufacture electronic components and loudspeakers to exacting world-class standards.

Fosgate Audionics customer support is second to none—a result of years of experience in designing, building and marketing sophisticated multi-channel audio products. We know home theater and multi-channel sound inside and out.

Record your

FAP T1's serial number and date of purchase here. The serial number is located on the back panel.

Serial Number:

Date of Purchase:

INTRODUCTION ................................................2

SAFETY ............................................................4-5

CONTENTS OF CARTON ....................................6

Unpacking ......................................................6

Contents ..........................................................6

FEATURES ......................................................6-11

Surround Format Information ..........................6

Front Panel ......................................................8

Remote Control ..............................................9

Rear Panel ....................................................10

INSTALLATION CONSIDERATIONS ..................12

INSTALLATION..............................................12-17

Connecting Audio Components ....................13

Connecting Video Components ....................14

FM Antenna ..................................................16

AM Antenna ..................................................16

Connecting an External Amplifier ..................16

Power Connection ........................................16

SYSTEM SETUP ..............................................18-24

Turning ON the Unit ....................................18

Navigating the Setup Menus..........................18

Input Configuration ......................................18

Speaker Configuration ..................................19

Channel Calibration ......................................22

System Configuration ....................................22

Multi–Zone....................................................24

Direct Operation ..........................................24

OPERATION ..................................................25-34

Power ............................................................25

Selecting a Source ........................................25

OPERATION (cont.) ......................................25-34

Volume Control ............................................25

Muting the Volume (Remote Control Only) ..25

Changing the Surround Mode........................26

Surround Data Format Lock ..........................26

Bypass Setting................................................26

Tuner Operation ............................................26

Night Mode ..................................................27

Channel Trim ................................................28

Theater Compensation ..................................28

Multichannel Source Playback ......................29

Analog Bass Management..............................29

Setting the FAP T1 Display Brightness............29

Setting the OSD Time Out ............................29

Sleep Timer ..................................................30

Multi–Zone Operation ..................................30

Remote Control Setup and Operation............31

Battery Installation ........................................31

Setup Using Preprogrammed Codes ..............31

Using the Remote Control ............................32

Macro Buttons ..............................................33

Learning Commands from Another Remote ..33

CARE & MAINTENANCE ....................................35

Cleaning ........................................................35

When You Are Away ....................................35

Troubleshooting ............................................35

System Reset..................................................35

SETUP CODES ..............................................36-37

SPECIFICATIONS................................................38

CONNECTION RECORD CHART ......................39

INDEX............................................................40-41

SERVICE POLICY & LIMITED WARRANTY ........43

Table of Contents

Safety

• Read All Instructions – All the safety and operating

instructions of your Fosgate Audionics equipment should be read before power is applied to the equipment.

• Retain Owner's Manual – These safety and operating

instructions should be retained for future reference.

• Heed Warnings – All warnings on the unit and in the

operating instructions should be adhered to,

• Follow Instructions – All operating and use instructions

should be followed.

• Cleaning – Unplug the unit from the wall outlet before

cleaning. The unit should be cleaned only as recommended by the manufacturer.

• Attachments – Do not use attachments not recommended by

the unit manufacturer as they may cause hazards.

• Water and Moisture – Do not use the unit near water-for

example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool.

• Accessories – Do not place the unit on an unstable cart,

stand, tripod, bracket, or table. The unit may fall, causing serious injury to a child or adult, and serious damage to the unit. Any mounting of the unit should follow the manufacturer's instructions, and should use a mounting accessory recommended by the manufacturer.

• Ventilation – Slots and openings in the cabinet are provided

for ventilation and to ensure reliable operation of the unit and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. The unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided. There should be free space of at least 6 inches (16cm) and an opening behind the unit,

• Grounding or Polarization – The unit may be equipped with

a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you cannot insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact a licensed electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

• Power Sources – The unit should be operated only from the

type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your unit dealer or local power company.

• Power-Cord Protection – Power-supply cords should be

routed so that they are unlikely to be walked on or pinched by items placed upon or against them, paying particular attention to cords where they enter a plug, or a convenience receptacle, and the point where they exit from the unit.

• Outdoor Antenna Grounding – If an outside antenna or

cable system is connected to the unit, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information regarding proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode,

• Lightning – For added protection for the unit during a

lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power-line surges.

• Power Lines – An outside antenna system should not be

located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, take extreme care to keep from touching such power lines or circuits as contact with them might be fatal.

• Overloading – Do not overload wall outlets, extension cords,

or integral convenience receptacles as this can result in a risk of fire or electric shock.

• Object and Liquid Entry – Never push objects of any kind

into the unit through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.

• Servicing – Do not attempt to service the unit yourself as

opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

• Damage Requiring Service – Unplug the unit from the wall

outlet and refer servicing to qualified service personnel under the following conditions:

When the power-supply cord or plug is damaged, If liquid has been spilled, or objects have fallen into the unit, If the unit has been exposed to rain or water, If the unit does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the unit to its normal operation,

If the unit has been dropped or damaged in any way, and great care should be exercised in handling, and the unit should be examined by qualified service personnel.

When the unit exhibits a distinct change in performance-this indicates a need for service.

• Replacement Parts – When replacement parts are required,

be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

• Safety Check – Upon completion of any service or repairs to

the unit, ask the service technician to perform safety checks to determine that the unit is in proper operation condition.

CAUTION: To reduce the risk of electric shock, do not remove the cover. No user service-able parts inside. Refer to qualified personnel.

WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user of the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

NOTICE – IMPORTANT SAFETY INFORMATION – PLEASE READ FIRST

Safety

• Wall or Ceiling Mounting – The unit should be mounted to a

wall or ceiling only as recommended by the manufacturer.

• Heat – The unit should be situated away from heat sources

such as radiators, heat registers, stoves, or other units (including amplifiers) that produce heat.

IMPORTANT SAFETY NOTE

Before connecting a new component such as the FAP T1 to your audio or home theater system it is always good practice to make certain that all components arc turned off, and preferably unplugged from their AC power source. Many modern electronics products feature automatic turn-on circuits that may be activated during an installation, causing the potential for damage to electronic components and/or speakers. Such damage is not covered by product warranties and Fosgate Audionics specifically disclaims responsibility for any such damage.

Power Cord

The removable power cord that is shipped with the FAP T1 is specifically designed to be used with this product.

DO NOT use

any other power cord, as that may reduce the unit's, performance and possibly create a safety hazard. In particular,

DO NOT use

standard IEC type power cords designed for computers and other business equipment products, as they have a three prong plug that is not meant for use with the

FAP T1. Should the power cord require replacement, use an identical type, or contact Fosgate Audionics for service.

AC Fuse

The fuse is located inside the chassis and is not user-service-able. If power does not come on, contact your authorized service station.

Wiring

Cables that run inside of walls should have the appropriate markings to indicate compliance with, and listing by the UL, CSA or other standards required by the UL, CSA, NEC or your local building code. Questions about cables inside of walls should be referred to a qualified custom installer, or a licensed electrician or low-voltage contractor.

Do Not Open The Cabinet

There are no user serviceable components inside this product. Opening the cabinet may present a shock hazard, and any modification to the product will void your guarantee. If water or any metal object, such as a paper clip, coin or a staple, accidentally falls inside the unit, disconnect it from the AC power source immediately, and contact Fosgate Audionics for further instructions.

Recording Copyright

Recording of copyrighted material for other than personal use is illegal without permission of the copyright holder.

Note to CATV system installer:

This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC, ANSI/NFPA 70, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

FCC Information for User

CAUTION: ANY changes or modifications not expressly

approved by the party responsible for compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

Tills equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Outdoor Antenna Installation

Safe Antenna and Cable Connection

If an outside antenna or cable system is connected to the equipment, be sure the antenna or cable system is grounded so as to provide some protection against built up static charges and voltage surges, Section 810 of the national Electrical Code, ANSI/NFPA 70 (in Canada, part 1 of the Canadian Electrical Code) provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes and requirements for the grounding electrode.

Keep Antenna Clear of High Voltage Power Lines or Circuits

An outside antenna system should be located well away from power lines, electric light or power circuits and where it will never come into contact with these power sources if it should happen to fall. When installing an outside antenna, extreme care should be taken to avoid touching power lines, circuits or other power sources as this could be fatal. Because of the hazards involved, antenna installation should be left to a professional.

Features

Contents of Carton

Your new FAP T1 Preamp/Processor is a state of the art, high performance audio device. The

FAP T1 provides maximum system connection flexibility with the latest surround processing technologies assuring compatibility with the widest range of source material.

• 6 Digital Inputs (2 coaxial, 4 optical) – Each input is assignable,

providing comprehensive connectivity.

• 2 Digital Outputs (1 coaxial, 1 optical) – For use with digital recorders

or distribution systems.

• High Bandwidth Professional Quality Component Video Switching –

HDTV compatible component switching for use with digital set top boxes and progressive scan DVD players.

• 5 Composite and S-Video Inputs – High-quality video circuitry for

connection to your video sources.

• 9 Analog Audio Inputs with Bypass Capability – All analog audio

inputs may be switched to Bypass mode for pure analog sound, or used with the latest surround processing algorithms.

• Video Output Conversion – Video inputs are automatically converted

from composite to S-Video or vice versa when using these outputs.

NOTE:When possible, always transmit video in it's native

connection format.

• High performance AM/FM/FM Stereo tuner with 32 presets

• Audiophile quality preamplifier stages

– Provide maximum

performance for critical audio listening.

• Dolby Digital®and Dolby Digital EX®Decoding* – Dolby Digital

decoding delivers 5.1 discrete channels from DVD, satellite, cable and HDTV sources, while the latest Dolby Digital EX process adds additional rear surround information for the ultimate home theater experience.

• Dolby Pro Logic®II* – The latest surround technology from Dolby

Laboratory, designed by Jim Fosgate, delivers 5.1 channel sound fields from matrix-encoded or stereo recordings.

• DTS®, DTS-ES®and NEO:6 Decoding** – The full suite of DTS

decoding and processing is available to provide multichannel reproduction from virtually any analog source as well as DTS encoded programs.

• Cirrus Extra Surround®– The FAP T1 is among the first to offer Cirrus

Extra Surround to provide realistic 6.1 or 7.1 surround sound from digital and analog sources.

• 5.1 Multichannel analog inputs – Connect 5.1-channel outputs from a

DVD-A or SACD multi-channel player or other multi-channel audio formats to these inputs.

Unpacking

The carton and packing materials used for your new Preamp/Processor were specially designed to cushion it from the shocks and vibration of shipping. Save the carton and packing materials to use if you move, or if the unit ever needs to be shipped back to us for any reason.

The

FAP T1 is heavy and has many front mounted controls and rear panel connectors, take care when lifting it so as not to cause damage.

Contents

After unpacking the FAP T1, please check that the following accessories are in the box:

• Remote Control with Four (4) AAA Batteries

• AC Power Cord

• FM Antenna

• AM Loop Antenna

• Owner's Manual

If for any reason any of the above is missing from your shipment, please contact Fosgate Audionics immediately.

• Complete Multi-room System – When properly connected, a second

source may be sent to a remote room, complete with remote volume control, source selection and tuner control. A trigger for the second zone allows a second amplifier to turn on and off independently of the main room. This system may also be used to record an input source that is different from the one being used in the main room.

• 2 low voltage triggers – One trigger provides automatic turn on/off of

compatible power amplifiers such as the Fosgate Audionics FAA

1000.5 amplifier or relay-controlled products such as projection screens, blinds and lighting systems. A separate trigger provides turn on/off control for an amplifier used with the multi-room system.

* Manufactured under license from Dolby Laboratories. ** Manufactured under license from Digital Theater Systems, Inc. US Pat. No.5,451,942

and other world-wide patents issues and pending. "Dolby," "Pro Logic" and the double-D symbol are trademarks of Dolby Laboratories. © 1992-1997 Dolby Laboratories, Inc. All rights reserved. "DTS" and "DTS Digital Surround" are trademarks of Digital Theater Systems, Inc. © 1996 Digital Theater Systems, Inc. All rights reserved. "Extra Surround" is a trademark of Cirrus Logic Inc.

SURROUND FORMAT INFORMATION

The FAP T1 employs the latest technology developed in conjunction with Cirrus Logic

, providing one of the most extensive arrays of surround decoding and processing currently available. You can choose from Dolby Pro Logic

II, Dolby Digital®5.1,Dolby Digital

, DTS®, DTS-ES®Discrete, DTS-ES®Matrix, DTS NEO:6®and

Cirrus Extra Surround

. Within each mode, the FAP T1 also offers a wide range of additional processing options. This means you can precisely match a surround mode to your program material, loudspeaker setup and personal taste. In addition, the

FAP T1 uses

Cirrus Logic's Triple Crossover

and Precision Bass Management

features to provide maximum flexibility when setting up your audio surround system (see "System Setup" on page 20 for further details).

The table on the following page lists the surround processing choices available within each mode. Depending on the selected source (

D-digital or A-analog) and your loud-speaker configuration,

certain processing options may not appear or operate.

Dolby Digital

This digital audio format provides 5.1 -channel surround sound. Dolby Digital source material includes DVDs, Laser Discs, HDTV broadcasts, some satellite delivered programming, and the output of some digital cable set top boxes.

Features

Dolby Digital Surround EX

Film soundtracks encoded with Dolby Digital Surround EX technology contain an extra channel, added to the soundtrack during mixing, called Surround Back, which places audio behind the listener in addition to the existing front left, front center, front right, surround left, sur-round right, and subwoofer channels. This additional channel provides more detailed imaging behind the listener creating more depth, spacious ambience and sound localization than before.

A list of movies created using Dolby Digital Surround EX can be found on the Dolby web site at www.dolby.com

NOTE:Surround EX mode can also be engaged during the playback

of 5.1 channel material that is not Dolby Digital Surround EX or DTS-ES Matrix or Discrete encoded. When used this way, signals from the left and right surrounds are used to synthesize the surround back channel. Results using this method will vary depending on the source material.

Dolby Pro Logic II

Dolby Pro Logic II, designed by Jim Fosgate, is a major enhancement to surround sound systems. In addition to the full range surrounds, Pro Logic II allows optimum playback of cinema and music soundtracks. There are three user adjustable options (found in the menu) that may be adjusted in Pro Logic II Music mode. In addition, when the Cirrus Extra Surround processing option is engaged for a

7.1 channel playback, these options remain engaged.

Panorama extends the front stereo image to the surround channels. It is particularly useful when the source material has a narrow stereo mix.

Dimension allows the front sound-stage to be more coherently matched with the surround sound-field, particularly to compensate for differences between the front and surround speakers, and speaker location. Personal preference becomes the deciding factor as to how much Dimension to “dial in”.

Center Width allows blending of center front channel information into the front left and right channels. This is particularly useful to compensate when the center speaker is a different type or design from that of the left and right speakers. When Center Width is used to the fullest extent, a phantom center is created.

NOTE:In the Pro Logic II Music Mode time delay is disengaged.

Additionally, Panorama, Dimension and Center Width are not available in the Pro Logic II Cinema mode. Because the steering logic dynamics of Pro Logic II Cinema and Music are identical, many listeners often use the Music mode for both music and cinema playback.

DTS

This compressed digital data format is similar to Dolby Digital, but uses a higher data rate. DTS also provides a maximum of 5.1 channel surround channels and is available on compact disc, DVD and Laser Discs. Audio-only DTS discs may be used with any CD, LD or DVD player with a digital audio output, but DVD discs with DTS audio must be used on players with the "DTS Digital Out" logo.

DTS-ES

DTS-ES is an extension of the original DTS format that adds an additional sixth, or center surround, channel to a soundtrack. DTS-ES Matrix titles provide the sixth channel by a matrix process, while DTS-ES Discrete media deliver a true discrete center surround channel. Both DTS-ES formats are backwards compatible with the original DTS process, and will deliver a 5.1 channel output when no center or back surround speakers are available.

The

FAP T1 will automatically sense the availability of either DTS-ES format and automatically switch the processing mode when required.

DTS NEO:6

This processing mode can create up to 6 full bandwidth channels from any matrix-encoded 2-channel source. Additionally, this mode can produce the rear surround information from a 5.1 source.

In Music Mode it can expand stereo music material, such as from a CD, into a multichannel surround experience.

Cirrus Extra Surround

This unique decoding algorithm creates 6.1 or 7.1 output from either matrix-encoded or discrete audio signals. When Cirrus Extra Surround is selected using either the remote or the front panel controls the display will show the primary selected mode plus a CR identifier-such as PL2C-CR. To determine what mode is best for any specific program material it will be necessary to experiment to decide what suits your systems and personal taste best.

Stereo

This mode provides conventional 2 channel signals to the left and right front speakers only.

Additional Information

More detailed information about the various surround processing options contained in the

FAP T1 can be found on the following

websites:

www.dolby.com

www.dtsonline.com

www.cirrus.com

Display

D A Name Description

Text

PLII-C

PLII-M

DOLBY PL

PLIIC CR

PLIIM CR

NEO: 6C

NEO: 6M

5 STEREO

7 STEREO

DOLBY D

DOLBY EX

DD CR-C

DD CR-M

DTS

DTS-ES

Pro Logic II Cinema

Pro Logic II Music

Pro Logic Emulation

Pro Logic II Cinema with Cirrus EX Surr

Pro Logic II Music with Cirrus EX Surr

DTS NEO:6 Cinema

DTS NEO:6 Music

5-Channel Stereo

7-Channel Stereo

Dolby Digital

Dolby Digital Surround EX

Dolby Digital with Cirrus EX Surr Cinema

Dolby Digital with Cirrus EX Surr Music

DTS

DTS Extended Surround

Use for surround enhanced film soundtrack playback from any 2-Channel source such as VCR

For surround enhanced playback of 2-Channel (stereo) music

Equivilant to original Pro Logic surround processing with mono surround

Adds Cirrus Extra Surround processing of rear channels to Pro Logic II Cinema

Adds Cirrus Extra Surround processing of rear channels to Pro Logic II Music

Creates 6.1 channel surround from any movie-based source

Creates 6.1 channel surround from any music-based source

Creates a 5-Channel program (L/C/R/LS/RS) from any stereo source

Creates a 7-Channel program (L/C/R/LS/RS/ LSB/LSR) from any stereo source

5.1 channel processing for all Dolby Digital encoded sources

6.1 channel processing for soundtrack encoded with Dolby EX

Adds Cirrus Extra Surround post processing to Dolby Digital. Creates a rear surround channel

5.1 channel processing for all DTS encoded sources

5.1 channel processing for all sources encoded with DTS-ES

Features

FRONT PANEL

1 MENU button – Displays menu options on the FAP T1 Display

as well as the On Screen Display (OSD). Press the button again to exit the Menu mode.

2 (Select) button – Used to select options while in Menu Mode.

3 , , , (Navigation) buttons – Use these buttons to

navigate through and change options while in Menu Mode. Also used to change settings with some of the front panel controls.

4 REMOTE CONTROL IR SENSOR – Picks up signal from remote

control.

5 FAP T1 DISPLAY – This is a 5” color TFT (Thin Film Transistor

LCD Display) front panel video display. This display replaces the ordinary two or three line displays found on conventional processors and receivers. Indicates program source, DSP mode, tuner preset and/or frequency, digital input, volume level, and other operating information. Also displays entire full page of the system menu. This feature can also be used as a mini-TV monitor for news, weather, data display, or any other viewing purpose where you may not elect to turn on a full size TV monitor or projection system.

NOTE:The display is best viewed when set at eye level.

6 SOURCE buttons – Press these buttons to select an input source.

7 VOLUME control – Adjusts the volume level for the main zone

only. Remote zone (Zone 2) is not affected by this control.

8 MULTI ZONE indicator LED – Lights to indicate that the second

zone (Zone 2) is active.

NOTE:This light will remain lit when the other indicators are off, as

long as the second zone is active.

9 On/Standby/Mute indicator LED – Lights to indicate when

the unit is in STANDBY mode and goes out when the preamp/processor is active. Also blinks to indicate when the main volume is muted.

10STANDBY power button – When the main POWER switch on

the rear panel is in the ON position, pressing this button turns the unit on. The Blue STANDBY/MUTE indicator light goes out.

Pressing this button again returns the Preamp/Processor to STANDBY mode. The STANDBY/MUTE indicator illuminates.

While in STANDBY mode, the

FAP T1 Display is turned off, control functions are disabled, and all outputs to the main zone are turned off. However, outputs to the remote zone remain active and available.

11TRIM button – Press to select individual output channels to

adjust above or below the master volume level setting from

-15dB to +10dB. Press the or Navigation buttons to adjust the level for the channel indicated, and then press the TRIM button again to select another channel.

12MONITOR button – Press to select through the screen displays

in the following order;

Main: Displays the menu, or whatever composite or S-Video that is being fed into the main system. Component video feed will not display and remains free of any internally generated information.

Zone: Displays any composite video being fed into the Second Zone (Zone 2).

Security: Displays any composite video being fed into the Security Video Input.

Blank: Display is turned off completely.

13 (Headphone Output Jack) – This output jack may be used

with a standard size stereo headphones or use an adapter plug to use stereo headphones or powered media speakers, such as those used with a computer, that have a smaller plug.

14TUNE UP/TUNE DOWN buttons – When Tuner is selected as

the input source, the Up and Down buttons adjust the tuner's frequency up or down.

15FM/AM button – Toggles between AM and FM frequency bands.

Pressing this button when listening to any other source automatically changes the unit's input source to the tuner and the last station chosen.

Features

16PRESET SCAN button – Pressing this button scans the preset

stations in the tuner's memory. Pressing it again stops the scan at the preset indicated. The unit's input source automatically changes to Tuner when this button is pressed.

17FM MODE button – Sets the FM Tuner to Mono mode. The let-

ter "M" appears next to the Tuner Preset number on the

FAP T1

Display or the OSD. Pressing the button again returns the FM Tuner to Stereo mode.

18MEMORY button – Pressing this button when Tuner is selected

as the input source memorizes the current station frequency into one of the presets. You can preset up to 32 stations.

REMOTE CONTROL

The FAP T1 Universal Learning Remote Control duplicates most functions available from the front panel of the preamp/processor. It is designed to access all the configuration and operation menus of the

FAP T1. These are displayed on the

FAP T1 Display, as well as the ON SCREEN DISPLAY (OSD) The Remote Control

contains an extensive library of IR codes and may be programmed to operate a wide range of audio and video components. Additionally, you can teach the remote to control other audio/video units not included in the unit's built-in memory by entering their particular device codes (see pages 34-35).

Many of the buttons on the Remote Control serve several functions, depending on the source device being controlled. The list below describes each buttons main functions. For a complete description of their use, refer to "Remote Control Setup and Operation."

1 Status LED Indicator – Indicates when the remote control is in Programming or

Learning mode and flashes to indicate success or failure of these functions.

2 Source Selection buttons – When the FAP T1 is in Standby mode, pressing one of

these buttons turns the unit on and selects that source as the current input.

If the

FAP T1 is already on, pressing one of these buttons selects that source as

the new input.

In both cases, once properly programmed, the remote control operates the source device selected.

The AUD button tells the Remote to control the

FAP T1.

The Source button selected will light whenever you push one of the Remote's function buttons to indicate that you have sent a command to that component. If the command pressed is one that typically is not available on that type of unit (i.e. P SCAN on a CD player) the source button will not light even though you have pressed that button.

3 POWER button – Returns the FAP T1 to standby mode when the unit is on.

4 MUTE button – Mutes the main volume of the FAP T1. Does not mute the second

zone (Zone 2).

5 Multi-zone button – Press the MULTI button to call up and cycle through the

Multi-zone menu options on the

FAP T1 Display and the OSD, if active.

6 TEST button – Outputs an audio test tone for calibrating and setting speaker levels.

Pressing the button again restores the audio output from the previously selected input source.

7 TRIM button – Activates the Channel Trim function. Pressing the button cycles

through all the channels individually for trim adjustment 10dB above or 15dB below the master volume setting, in 1dB steps.

8 Numeric Keypad buttons – Use these buttons for control functions requiring you

to enter numbers. For numerals over 10, press the +10 button for every multiple of ten, followed by a second digit.

19ANALOG BYPASS button – Defeats the DSP processing section

and provides an unaltered, full-band-width stereo signal to the Left and Right channel outputs on the rear panel, However, the subwoofer DSP crossover remains active and bass frequencies are available at the subwoofer output should you wish to augment your front LR speaker's low frequency performance. The word BYPASS appears on the

FAP T1 Display or the OSD. Pressing the button again returns the unit to the previously selected DSP mode.

20SURROUND MODE buttons – Press this to select from the

various surround modes. Mode availability depends on setup configuration and input source.

21DIGITAL SELECT button – Press this button to select a digital

input. Each press scrolls to the next input type, as shown on the FAP T1 Display or the OSD. When ANALOG is shown, the L/R analog input associated with the input in use will be used.

Features

9 Theater Compensation button – The +10(Hi-EQ) button toggles

Theater Compensation processing on and off.

10Surround/Data Format buttons – Press the , DTS, CR SURR

or STEREO button once to select a surround processing format.

Press the same button again to cycle through the various processing modes available for the selected format.

Pressing and holding the button for five (5) seconds calls up the Data Format menu.

11DIGITAL button – Cycles between the six digital inputs and the

analog input on the

FAP T1. The selected input is shown on the

FAP T1 Display and the OSD, if active.

12NIGHT button – Cycles through the various Night dynamic

range compression modes.

13Macro Control buttons – The M1, M2, M3 and M4 buttons are

used to play back macros, which are preprogrammed sequences of IR commands that you have entered in the remote.

14Tuning and Volume buttons – Use the or CH/TUNE

buttons to adjust the

FAP T1 tuner's frequency down or up when AUD is selected as the input source. These buttons also operate the tuner or change channels of other devices that are selected as the current source.

Use the or VOL buttons to adjust the volume of the FAP T1 from -80dB to +10dB. These buttons also operate the volume control of other devices that are selected as the current source.

15MENU button – Calls up the Main Menu on the the FAP T1

Display and the OSD, if active.

16Navigation and Select buttons – Use the four Navigation buttons

to move through menu options shown on the

FAP T1 Display or

OSD. Use the SEL button to confirm selections made in menus.

17TONE button – Press this button to select either the Treble or

Bass for adjustment. Once the desired parameter is selected, use the or navigation buttons to change the setting. The Treble and Bass can be adjusted ±6dB. Settings are shown on the on the

FAP T1 Display and the OSD, if active.

18Auxiliary Input buttons – Use the AUX 1 and 2 buttons to

select the device connected to one of the two AUX inputs as the active source.

19 6 Channel Direct button – Pressing the 6 CH button selects as

the source the analog signal from the Multi Channel inputs (5 channels plus subwoofer) on the

FAP T1, as well as activating the dedicated Bass Management selected by the rear panel switch. Pressing the button again returns the unit to the previously selected source.

20BYPASS button – Activates Stereo Bypass mode, sending the sig-

nal from the analog input in use directly to the volume control, bypassing all digital processing. Pressing the button again returns the unit to the previously selected mode.

NOTE:In this mode, only 2-Channel audio output will be available.

21AM/FM button – Press this button to select the FAP T1's tuner

as the input source, or to switch between the AM and FM bands when the tuner is active. Pressing this button when the

FAP T1

is in Standby mode will also turn the unit on.

22Tuner Mode button – Press the T.MODE button to switch the FM

tuner between Mono and stereo.

23SLEEP button – Sets the FAP T1's built-in sleep function timer.

24P.SCAN button – Pressing this button scans the AM or FM

stations preset in the tuner's memory. Pressing it again stops the scan at the preset indicated in the

FAP T1 Display.

25Memory button – Press and hold the MEM button to store an

AM or FM station into a preset location. Once the

FAP T1

Display begins to flash Memory 01, enter the desired preset number using the numeric keypad on the remote.

26Light – Illuminates the Remote Control buttons for 7 seconds.

REAR PANEL

Below is a brief explanation of the connections and switches found on the rear panel of the

FAP T1 Preamp/Processor. Before connecting any audio or video components to the unit, familiarize yourself with the type and location of connectors available.

1 FM Antenna terminal – Connect the supplied FM antenna or an

external 75Ω antenna.

2 AM Antenna terminals – Connect the supplied AM loop antenna

or an external AM antenna to these terminals.

3 Remote Control jacks – Use the MAIN and ZONE EXT REMOTE

jacks to connect external IR sensors. When the unit is installed behind doors or where it is not otherwise visible to the remote, connect an optional, external sensor to the MAIN jack. To control the

FAP T1's Multi-room system from a remote location, connect an optional remote sensor in the second room to the ZONE jack

4 Remote Trigger jacks – Use the MAIN and ZONE DC TRIGGER

jacks to control external devices (such as a power amplifier) with a 3-32 VDC trigger input. The device connected to the MAIN jack will be activated when the

FAP T1 is turned on and should be used for connections to power amplifiers for the main room speakers. The device connected to the ZONE trigger will only be activated when the Multi-zone system is turned on. Connect it to the amplifier used to power the speakers in the second zone (Zone 2).

5 Component Video Input jacks – Use these three (3) sets of jacks

to connect devices with component video outputs such as a DVD player or HDTV tuner.

6 S-Video jacks – Connect the S-Video output of sources to the

appropriate input jacks. Connect the VCR-OUT jack to the input of a VCR or other recorder and connect the OUT jack to an S-Video input on your video display device.

7 Component Video Output jacks – Use these jacks to supply

component video output to an external monitor that accepts component video signals.

8 Monitor Out (S-Video/RCA Output jacks) – Use these jacks to

connect to the S-Video or RCA input on your video display device.

9 Digital Outputs – Use the coaxial and optical digital outputs to

connect the preamp/processor to a device such as CD recorder, DAT recorder, or other similar device that accepts a digital audio input.

Features

10Security Input jack – Use this input to connect to a security

video camera or any other composite video you wish to display of the

FAP T1 Display. This can be selected to view on the FAP

Display by using the Monitor button.

11Optical Digital Inputs – Use these inputs to connect the optical

digital audio signal output from such digital devices as CD, DVD or LD players. These inputs are fully assignable.

12Audio Source Input jacks – Use these inputs for connection to

analog audio sources such as a CD player. One in/out tape loop is provided for connection to an audio recorder.

13Video Source Input jacks – Use these inputs for connection to

the composite video and analog audio output from sources such as a DVD or LD player, satellite receiver, cable box, PVR or other video source. Note that when the Component Video inputs are used, connect the analog audio outputs of the source to the DVD or Video 1 jacks, as appropriate.

14VCR jacks – Use these input and output jacks to connect a VCR.

15Multi-zone Output jacks – Use these jacks to supply the analog

stereo audio output to an optional audio amplifier used to power the speakers in the remote zone.

16Monitor Output jack – Connect this output to the composite

video input of your monitor or other video display device.

17 5.1 Channel Input jacks – Connect the multichannel signal from

the analog audio outputs of a device such as a DVD, DVD-A or SACD to these jacks.

18Amplifier Output jacks – Use the seven audio channel output

jacks to connect to an external power amplifier. The eighth jack supplies the output to a powered subwoofer or external subwoofer amplifier.

19 5.1 Input Bass Management Control – Setting this switch in the

ON position activates an 80Hz High Pass Filter for the 5.1 channel direct input, except the subwoofer. The bass signals from the 5 satellite channels are summed and sent on to the subwoofer output at all times. Setting the switch in the down position turns off the High Pass Filter and sends full-range audio to all channels. This Bass Management Control is totally separate from the DSP Bass Management set up using the front panel or remote control.

20Coaxial Digital Input jacks – Use these inputs to connect the

coaxial digital audio signal output from such digital devices as CD, DVD or LD players. These inputs are fully assignable.

21Product Serial Number – Write this number in the space provide

on page 2 for future reference.

22Main Power switch – Turns the current to the FAP T1 On or Off.

Setting this button to the On position (pushed in) supplies power to the unit, enabling use of the Standby Power button on the front panel. When this switch is in the Off position, current is cut off to the unit.

23AC Input – Use to connect the supplied AC power cord (see

Safety, pages 3-4).

Installation Considerations

Installation

Installation Location

To assure proper operation and to avoid the potential for safety hazards, place the unit on a firm and level surface capable of supporting it's weight. When placing the unit on a shelf, be certain that the shelf and any mounting hardware can support the weight of the unit and any additional items in the equipment rack, or on the shelf.

When positioning the

FAP T1 in its final location, make certain that it has adequate ventilation on all sides, as well as on the top and bottom. In particular, it is a good idea to provide at least two or three inches of room above the unit for air circulation.

DO NOT

place CDs, DVDs, videotapes, owner's manuals, or other paper on top of, or beneath, the unit, or in-between multiple amplifiers in a stack. This will block airflow, causing heat build-up, degraded performance, and may create a possible fire hazard.

Before proceeding, please observe the following precautions when connecting devices to your new

FAP T1.

• Do not plug the power cord into your FAP T1 until all other

connections have been made.

• Always refer to the instructions that came with the

component that you are connecting for specific procedures, warnings and options.

• For all analog connections, the red input jacks (

R) are used

for the right channel, white input jacks (

L) are used for the

left channel, and yellow input jacks (

V) are used for the

composite video connection.

• Make sure to insert all plugs and connectors securely.

Improper connections can result in noise, poor performance, or damage to the equipment.

• Do not bundle audio/video connection cables with power

cords and speaker cables. Doing so may adversely affect the picture and sound quality. For example, run all the power cords down one side of the cabinet, all the signal cords down the other side, and the speaker wires down the center.

• When connecting devices to the digital inputs and outputs,

you may also consider hooking up the analog connections to and from the components to insure that all signals can be employed by the preamp/processor.

• When using the optical input or output jacks, remove the protective cap and keep it in a safe place. When these jacks are not in use the protective cap should be replaced.

• When using an optical input or output jack, always use a high-quality optical fiber cable.

IMPORTANT:We strongly recommend that before you connect any

loudspeakers to your amplifiers, you complete all needed connections and set up procedures to your FAP T1 as outlined below. This will reduce the chance that a mis-connection or other error will produce audio output that might damage your speakers or other components.

Gives, the wide variety of components that can be connected to your

FAP T1, there are numerous ways in which your system can be assembled. To help you with this task, use the chart at the end of this manual to record the components connected to your unit, as well as which type of input (analog, coaxial, S-Video, etc.) is used. Keep this chart for future reference.

There are many possible ways to connect a particular device. Use the diagrams on the following pages as a guideline. The information in this section contains some of the more common situations you might encounter in your system. Always consult the owner's manual that came with the component you are connecting for more information on the source component's connections.

If the unit is to be enclosed in a cabinet or rack, make certain there is adequate air circulation. Sufficient ventilation should be provided so that hot air may exit, and cool air may enter the cabinet. In some instances, a small cooling fan may be required to insure adequate airflow through the cabinet. If you are in doubt as to the ventilation requirements for your specific installation, please contact us. Also, do not place the

FAP T1 directly on a carpeted surface, as this will inhibit airflow underneath as well as create a potential fire hazard.

Avoid installation in humid locations, in extremely hot or cold locations, or in areas that are exposed to direct sunlight or space heating equipment.

Installation

Connecting Audio Components

CONNECTING AUDIO COMPONENTS

CD Player

Analog: Connect the L and R channel outputs on the CD player to the CD IN jacks on the

FAP T1.

Digital: If your CD player has a digital output jack, connect it to one of the coaxial (COAX 1 or 2) or optical (OPT 1-4) input jacks on the preamp/processor, depending on the type of connector used by the CD player. Later, you will con-figure the

FAP T1 to use the specific input that you have chosen. For now, note which digital input you connected to on your system chart.

Audio Recorder

A recording device such as a cassette deck, MD recorder, DAT deck or CD recorder can be connected to the

FAP T1 using either

or both of the following methods.

Analog: Connect the L and R audio outputs on the recorder (usually marked PLAY) to the TAPE IN jacks on the rear of the preamp/processor and connect the L and R audio inputs (usually marked REC) to the TAPE OUT jacks of the

FAP T1.

Digital: If your recorder has a digital output jack, connect it to one of the coaxial (COAX1 or2) or optical (OPT1-4) input jacks on the preamp/processor, depending on the type of connector used by the device. Later, you will configure the

FAP T1 to use the specific input that you have chosen. For now, note which digital input you connected to on your system chart.

If your recorder has a digital input jack, connect it to either the coaxial or optical output jack on the preamp/processor. The signal from the selected digital input source of the

FAP T1 will be sent to

the recorder.

Installation

Connecting Video Components

CONNECTING VIDEO COMPONENTS

Before making connections to any video devices, understand how the

FAP T1 routes the video portion of the signal through its video

section.

• Any signal that appears at one of the composite video input jacks (DVD, VIDEO 1, 2 or 3) is automatically sent to the composite video OUT and VCR OUT jacks, as well as the S-Video OUT and VCR OUT jacks.

• Any signal that appears at the S-Video input jacks (DVD, VIDEO 1, 2 or 3) is automatically sent to the S-Video OUT and VCR OUT jacks, as well as the composite video OUT and VCR OUT jacks.

• Any signal that appears at the component video (DVD or VIDEO 1) input jacks is automatically sent to the component video MONITOR OUT connection only.

NOTE:To provide the greatest signal flexibility, connect all

available types of inputs and outputs from your video devices. For example, if only the composite video output (yellow RCA jack) connection is made to your display device, component sources will not be available, even if they are connected to the

FAP T1.

DVD Player

Composite: Connect the composite video output from the DVD player to the DVD video input jack on the rear of the

FAP T1 using

an RCA-type video cable.

S-Video: If there is an S-Video output on the DVD player, and you have an S-Video input on your TV or monitor, connect it to the S-Video DVD input on the rear of the

FAP T1 using an S-Video cable. S-Video delivers a better picture than composite connections and should be used whenever possible unless you can use component connections, which deliver better video than S-Video.

Component: If the DVD player has component video outputs, connect them to the DVD component video input jacks on the rear of the

FAP T1 using an appropriate cable set.

Analog Audio: Connect the L and R channel outputs on the DVD player to the DVD IN audio jacks on the rear of the

FAP T1.

Digital Audio: Connect one of the digital output jacks on the DVD player to one of the coaxial (COAX I or 2) or optical (OPT 1-4) input jacks on the rear of the preamp/processor, depending on the type of connector used by the DVD player. Later, you will configure the

FAP T1 to use the specific input that you haw chosen. For now, note which digital input you connected to on your system chart.

Installation

Multi-channel Audio If your DVD player supplies a multi-channel audio output (for DVD Audio or SACD playback), connect the six outputs (special cable sets for this are available from numerous sources) from your player to the six input jacks labeled MULTI CHANNEL INPUT on the rear panel of the

FAP T1. Be sure match the connections—left to left, right surround to right surround, and so on. If your player includes a built-in Dolby Digital decoder and has 5.1 channel analog audio outputs we suggest that you do not use them, but use the digital audio connection and the

FAP T1's

internal decoders instead.

If you are connecting a DVD-Audio or SACD player to the

FAP T1

using these jacks, you will need to consider the setting for the Analog Bass Management switch on the

FAP T1's rear panel. If your system uses all full range speakers, set. the switch in the OFF position. In that setting the signal will be routed directly from the input jacks to the volume control.

However, if your system uses small, frequency-restricted satellite speakers, the switch should be set to the ON position. In that setting the signals sent to the main speakers will be cut at 80 Hz and a summed bass signal will be sent to the subwoofer output. Note that you should place this switch in the OFF position if your playback source includes internal bass management circuitry.

Video Recorder

A video recording device such as a VCR, PVR (such as a TiVo®, Replay

, Uiti-mate TV®, DishPlayer®or similar device) or DVD

recorder can be connected to the

FAP T1 using the following

methods.

Composite: Connect the composite video output from the recording device to the VCR IN composite video jack on the rear of the preamp/processor. Connect the recording device's composite video input to the VCR OUT composite video jack of the

FAP T1

using an RCA-type video cable.

S-Video: If there is an S-Video output on the recording device, connect it to the S-Video VCR IN input on the rear of the preamp/processor and connect the S-Video input to the S-Video VCR OUT using an S-Video cable. S-Video delivers a better picture than composite connections and should be used whenever possible unless you can use component connections, which deliver better video than S-Video.

Component: If the recording device has component video outputs, connect them to one of the component video input jacks (DVD or VIDEO 1) on the rear of the preamp/processor using an appropriate cable set.

Analog Audio: Connect the L and R audio outputs on the recorder to the VCR IN audio jacks on the rear of the preamp/processor and connect the L and R inputs of the recorder to the VCR OUT audio jacks on the

FAP T1.

Digital Audio: If your recording device also has a digital audio output jack, connect it to one of the coaxial (COAX 1 or 2) or optical (OPT 1-4) input jacks on the rear of the preamp/processor, depending on the type of connector used by the device. Later, you will configure the

FAP T1 to use the specific input that you have chosen. For now, note which digital input you connected to on your system chart.

If your recording device also has a digital input jack, connect it to either the coaxial or optical output jack on the rear of the preamp/processor, depending on the type of connector used by the device. The signal from the selected input source of the FAP T1 will be sent to the recorder.

Video Display

A video display device such as a television monitor, fixed-pixel device (plasma or LCD) or video projector can be connected to the FAP T1 using the following methods.

Composite: Connect the composite video input from the display to the composite video OUT jack on the rear of the

FAP T1 using an

RCA-type video cable.

S-Video: If there is an S-Video input on the display, connect it to the S-Video OUT jack on the rear of the preamp/processor using an S-Video cable. S-Video delivers a better picture than composite connections and should be used whenever possible unless you can use component connections, which deliver better video than S-Video.

Component: If the display has component video inputs, connect them to the component video MONITOR OUT jacks on the rear of the

FAP T1 using an appropriate cable set.

NOTE: Since the FAP T1 converts composite video to S-Video and

vice versa, you need only make one of those two types of connections between the

FAP T1 and your video display. However, when component video connections are used it is still necessary to make either the composite or S-Video connections so that you are able to view the on-screen menus and displays which do not appear on the component outputs. The

FAP T1 does not convert from either composite

or S-Video to component or vice versa.

Satellite Tuner or Television

Composite: Connect the composite video output from the satellite tuner or television to one of the video input jacks (VIDEO 1,2 or 3) on the rear of the

FAP T1 using an RCA-type video cable.

S-Video: If there is an S-Video output on the satellite tuner or television, connect it to one of the S-Video inputs (VIDEO 1,2 or 3) on the rear of the

Component: If the satellite tuner or television has component video outputs, connect them to one of the component video input jacks (DVD or VIDEO 1) on the rear of the

FAP T1 using an appropriate

cable set.

Analog Audio: Connect the L and R channel outputs on the satellite tuner or television to the set of audio input jacks (VIDEO 1, 2 or 3) directly under the video jack used on the rear of the

FAP T1.

Digital Audio: If your satellite tuner or television has a digital output jack, connect it to one of the coaxial (COAX 1 or 2) or optical (OPT 1-4) input jacks on the rear of the preamp/processor, depending on the type of connector used by the device. Later, you will configure the

FAP T1 to use the specific input that you have chosen. For now, note which digital input you connected to on your system chart.

Installation

FM Antenna

Connect the supplied FM antenna to the terminal labeled FM75Ω. Do not over tighten as this may damage the connection.

The supplied FM antenna is for indoor use only. For best signal reception you must fully extend the antenna. Experiment with the antenna's position to obtain the strongest signal. You can attach it to a wall or other surface using push pins or similar apparatus.

If FM reception is poor with the supplied indoor antenna, the use of an amplified indoor or outdoor antenna is recommended.

NOTE:You can only connect a 75Ω type FM antenna to the

FAP T1. If you choose to use an antenna other than the one supplied, be sure to verify that it has the correct type of connector or that you obtain an appropriate adapter.

Try to ovoid using the same antenna for both FM and TV reception since the signals can interfere with each other. If you must use a com-mon FM/TV antenna, be sure that you install an splitter to separate the two signals.

AM Antenna

Connect the AM antenna to the terminals labeled AM and E(arth) on the rear panel of the preamp/processor. Start by pressing the lever on the side of one of the terminals to the right. Next, insert one of the antenna wires into the opening. Finish by returning the lever to the up position, securing the wire. Do the same for the other wire to complete installation.

Loop

Antenna

FM Antenna

Connecting an External Amplifier

IMPORTANT:Before attempting to plug any jacks into any power

amplifier verify that the power amplifier is turned off and/or disconnected from the AC mains. Failure to do so can potentially result in severe damage to your amplifier and loudspeakers.

Use the audio jacks labeled OUTPUT to connect the

FAP T1 to an external power amplifier such as the Fosgate Audionics FAA 1000.5 Power Amplifier. The

FAP T1 can output up to 7.1 channels of sound (seven satellite and one subwoofer channel) depending on source components and material.

The output jacks supplied by the

FAP T1 are: left Front, Center, Right Front, Left Surround, Right Surround, Left Surround Back, Right Surround Back, and Subwoofer.

Be sure to verify that the correct outputs are connected to the appropriate input jacks (Left Front to Left Front, Right Surround Back to Right Surround Back, etc.)

When a powered subwoofer is used, connect the Subwoofer output jack to the Line Input jack on your subwoofer and follow any specific connection and/or configuration, instructions supplied with the subwoofer. If your subwoofer is a passive speaker, connect the subwoofer output jack on the

FAP T1 to the input of the amplifier used to power the subwoofer, and then connect the subwoofer speaker itself to the amplifier.

Second Zone (Zone 2)

Use the L and R channel ZONE OUT audio jacks to connect the FAP T1 to the analog audio inputs of an external amplifier or other audio component in a second zone. The signal present will reflect the input selection of the

FAP T1. This may be adjusted using the

Zone Menu or the MULTI button on the remote control.

Power Control Connections

The DC TRIGGER jacks are used to remotely turn-on other devices in your system when the

FAP T1 is powered on. Power is applied

to the MAIN Trigger Output jack when the

FAP T1 is turned on from the Standby Mode. We recommend that this jack be used to turn on a compatible power amplifier such as those available from Fosgate Audionics, but it may also be used to activate compatible products such as projection screens or motorized blinds.

Connect a 3.5mm mono mini-plug between the DC Trigger MAIN jack on the rear panel of the

FAP T1 and the low voltage trigger jack of the device to be controlled to enable remote turn-on of that component. The ZONE Trigger jack is activated when the Multi-room system is turned on and should be used for control of amplifiers used to power the speakers installed in the remote zone. It will remain activated as long as the Multi-room system is on, even when the

FAP T1 is in the Standby mode for the main room.

Remote Control

The EXT REMOTE jacks allow you to extend the on-board remote control sensor on the

FAP T1's front panel so that you may

continue to control the

FAP T1 even when it is installed behind solid or smoked cabinet doors or when the front panel sensor is otherwise not visible to the remote control.

To extend the remote sensor connect an optional remote sensor to the MAIN jack.

The ZONE jack is provided to enable remote control of the FAP T1's multi-zone system through the use of an optional remote sensor in the second zone. Connect the sensor to the ZONE jack using a 3.5mm mono mini-plug and the wiring specified by the sensor's manufacturer.

Power Connection

Insert the supplied power cord into the AC input of the rear panel of the preamp/processor. Do not use a power cord other than the one supplied with the

FAP T1. It's designed for use with the

FAP T1 and should not be used with any other device.

CAUTION: Before you plug the power cord into an AC

wall outlet, ensure all connections to the preamp/processor have been made correctly.

WARNING: Never disconnect the power cord from the

FAP T1 while the other end is plugged into an AC outlet. Doing so may cause an electric shock. Always connect power by plugging into the AC outlet last and disconnect by unplugging from the AC outlet first.

Installation

Connecting to an External Amplifier in a Second Zone (Zone 2)

Connecting an External Amplifier

System Setup

At this point you should have made all the necessary physical connections between the

FAP T1 and your source equipment, amplifiers and speakers. All that remains is to properly configure the system to reflect your specific equipment and room characteristics.

To turn the FAP T1 on:

1. Plug the cord into an AC wall outlet or UL approved power

strip or surge protection device.

Make certain that the AC power cord supplied with the FAP T1 is firmly inserted into the socket on the unit's rear panel.

2. Press the rear panel POWER switch to the On position to

set the

FAP T1 to Standby mode.

The Standby Indicator on the Front Panel will light up.

3. Press the front panel Standby Power button to turn on the

FAP T1 or press the AUD button on the remote control.

The FAP T1 DISPLAY will light up and the standby indicator will turn off.

Navigating the Setup Menus

Setup of the FAP T1 can be performed from the front panel of the unit, or by using the remote control. Information is shown on the FAP T1 Display, or the On Screen Display (OSD). All selections are made using a combination of the following buttons:

Front Panel: The MENU, Navigation ( , , and ) and

(Select) buttons left of the FAP T1 Display

Remote Control: The MENU, Navigation ( , , and ) and SEL/PLAY buttons in the center of the remote.

These buttons will be referred, unless otherwise specified, when navigating the Setup Menus.

The following example demonstrates how to navigate the

FAP T1

menu system in general using the Speaker Configuration menu as an illustration. For detailed information on a specific part of the setup process, consult the pages relating to that topic.

To use the FAP T1 menu system:

NOTE:The following selected menus appear on the FAP T1

Display and the OSD (On Screen Display)

1. Press the MENU button to display the Main Menu.

2. Press or to select a Setup menu. Then press

(Select) to enter into the menu.

3. Press or to select the item to be adjusted. Then press or to adjust a selected item.

Once you have made your selections, you can use the and to return to the Main Menu and/or exit the menu system. Alternatively, pressing the MENU button once will return you to the Main Menu. Pressing the MENU button a second time will exit the menu system. Note that the menus will remain visible on the

FAP T1 Display and

OSD until you exit the menu system.

IMPORTANT:When viewing static images such as on screen menus

or video game images using a CRT-based projector, plasma display or direct-view CRT monitor or television, there is a risk of permanently 'burning in" the image. Do not leave these images on for an extended period of time. This type of damage is not covered by the Fosgate Audionics

FAP T1 warranty.

INPUT CONFIGURATION – Setup and Selection

Before calibrating your FAP T1 and adjusting loudspeaker setup and configuration, you should first set up the sources connected to it. You will make your selections using the Input Configuration menu, shown below.

NOTE:The following selected menus appear on the FAP T1

Display and the OSD (On Screen Display)

Figure 1

Because of the extensive options available for each input source, we strongly recommend you use the chart at the end of this manual to record the settings for each input and component. Later, if you re-configure your system, this chart will help avoid confusion.

To configure an input:

1. Press the MENU button to enter the Main Menu.

The Main Menu appears and the cursor should be pointing to INPUT CONFIG.

2. Press (Select) to enter the Input Configuration menu.

The Input Configuration menu appears and the cursor should be pointing to

SOURCE.

System Setup

3. Use the and buttons to change the Source you wish to configure.

The Source choices appear as follows as you scroll through them:

DVD > VIDE01 > VIDE02 > VIDE03 > VCR > TUNER (FM) > TUNER (AM) > CD > TAPE > AUX1 > AUX 2

You can scroll in either direction using the and buttons.

4. Press the button once to select INPUT.

5. Use the and buttons to change the Input for that source.

The input choices appear as follows as you scroll through them:

ANALOG > OPTICAL1 > OPTICAL2 > OPTICAL3 > OPTICAL4 > COAXIAL1 > COAXIAL2

You can scroll in either direction using the and buttons. If you connected the source to the Analog inputs, select: ANALOG.

If you connected the source to one of the Optical Digital inputs, select the appropriate one by choosing: OPTICAL 1, 2, 3, or 4.

If you connected the source to one of the Coaxial Digital inputs, select the appropriate one by choosing: COAXIAL 1 or 2.

NOTE:Always connect and configure the digital input source

option if available from the specific component, as this will provide maximum performance and best sound quality.

Remember that you can always return to any menu to change your selection, should that be required.

6. Press the button once to select MODE.

7. Use the and buttons to change the Mode for that source.

The available surround modes appear as follows as you scroll through them:

PLII CINEMA > PLII MUSIC > DOLBY PRO LOGIC > 7 STEREO > 5 STEREO > STEREO > PLII CINEMA+CS > PLII MUSIC+CS > DTS > DTS NEO:6 CINEMA > DTS NEO:6 MUSIC > DOLBY DIGITAL > DOLBY DIGITAL EX > DTS ES

You can scroll in either direction using the and buttons.

You should choose a surround mode to be the default for this source. Please refer to the table on page 7 for a detailed listing of all options. Remember that all available mode options can be selected for a Digital input source, but certain modes will not be available through the Analog input for that source.

Selecting the default mode will not exclude other modes of surround decoding. In fact, certain digital signals (Dolby Digital, DTS, some Dolby Digital EX, and others) contain a special digital "flag" that tells the

FAP T1 to switch to that surround

mode. When the

FAP T1 receives one of these bitstreams it will switch to that mode of operation. Additionally, you can manually cycle through the available modes while the source is playing to choose the one you wish to use.

8. Press the button once to select TREBLE

9. Use the and buttons to adjust the Treble.

Treble boost can be adjusted from -6dB to +6dB in 2dB increments (default is 0dB).

10.Press the button once to select BASS.

11.Use the and buttons to adjust the Bass.

Bass boost can be adjusted from -6dB to +6dB in 2dB increments (default is 0dB).

NOTE:Any tone control setting you make in this mode are global,

and will affect all input sources and all output channels. They will remain in effect until you go back into the setup menu and change them or change them using the TONE button on the remote control.

12.Press the button to select NIGHT.

NOTE:This option only operates with a Dolby Digital or Dolby

Digital EX source and one of these modes is active.

This option allows you to set the amount of Dynamic Range Compression used when the

FAP T1 is placed into the NIGHT mode. This mode can also be selected by pressing the NIGHT button on the remote control.

There are two types of automatic compression control built into the Dolby Digital process. Compression makes the loud parts softer and the soft parts louder to reduce the difference between the two.

One type of compression is most useful for situations such as late night viewing of programs with a wide dynamic range (like many action movies) that might disturb others in your home. This function can also be used to provide compression for program material that may require enhancement of overall intelligibility (such as some older soundtracks). Another feature provided by this option is the necessary peak limiting required to avoid signal overload when "down-mixing" functions are selected.

The second variable provides additional peak limiting to allow overall average program level to be increased by adding even more compression to the signal.

These two algorithms can provide sufficient overall gain reduction to allow even wide dynamic range soundtracks with very soft parts and very loud parts to maintain good audibility at low volume levels.

In most cases a minimum amount of dynamic range reduction is automatically included in the bitstream to ensure safe down-mixing.

13.Use the and buttons to select a Dynamic Range option you prefer for the Night setting,

NO COMP This option leaves the compression at 0% change. DR COMP1 This option increases the compression by 25%. DR COMP2 This option increases the compression by 50%, DR COMP3 This option increases the compression by 75%. DR COMP4 This option increases the compression by 100%.

Each option increases the amount of Dynamic Range compression to the signal. Depending on your family, neighbors, circumstances, and the overall volume you wish to achieve, we recommend you start with DR COMP1 or DR COMP2 as your initial setting. You will have to experiment with program material and your personal preferences to determine what is acceptable and best for you.

14.Press the button to select RETURN TO MAIN MENU.

15.Press the

(Select) or MENU button to return to the Main Menu, or press the MENU button twice to exit the menu system.

NOTE:Except for the input source and surround mode, the settings

chosen during this input setup process are universal and apply to all sources. You will need to correctly set each digital source to the appropriate input and select a default surround mode for each source connected to your

FAP T1. Once you have completed these selections, proceed to the next step: configuring your loudspeaker setup and calibrating your system.

System Setup

SPEAKER CONFIGURATION – Setup and Selection

You are now ready to configure the FAP T1 for your particular loudspeaker system. Before proceeding please read the following information carefully:

Speaker Placement

The best speaker placement for your particular room will depend on its size, furnishings, seating arrangement, the acoustical properties of the space, including wall type, coverings, and various other factors.

Due to the complex nature of these variables it is impossible to recommend any one-size-fits-all placement. You may well have to experiment with various placement options to determine the best configuration for your specific situation. Please note that, the configuration and placement of your speakers is critical for creating the best possible surround sound playback.

Here are some basic recommendations you should consider when positioning your speakers.

Front left, center and right speakers:

• These speakers should be placed at the same relative height from the floor and a similar distance from any walls. Most speakers sound best when located with the tweeter at ear height when you're seated. Typically, the further away from the walls the speakers are, the better they will sound.

• Insure that the speakers are aimed at the listener's ears within your chosen seating position.

Surround left and right speakers

• Place these speakers so that their height is approximately 3 feet (1 meter) higher than that of the listener's ears if feasible.

Surround back left and right speakers

These speakers are required for Surround EX, DTS-ES, DTS NEO:6 and Cirrus Extra Surround playback.

• Place these speakers behind the listener so that the angle between each speaker and the listener is approximately 30 degrees.

• Place these speakers so that their height is 3 feet (1 meter) higher than that of the listener's ears.

Note on dipole surround loudspeakers: Most dipole surround

speakers have an arrow which indicates their proper orientation relative to your video display/screen. Dipoles placed on side walls should have the arrows pointing forward. Dipoles placed on a rear or back wall should have the arrows pointing towards each other to achieve the correct acoustical image in the room.

Subwoofer

Subwoofer placement can frequently be a trial and error affair as bass energy set up "standing waves" in most every room. These standing waves can cause areas with too much bass, areas with too little bass, and areas in between. You may have to move the subwoofer and or the prime listening area to improve the bass response. Be aware that every surface you place the woofer close to (one wall, floor, two walls in a comer) will increase the overall apparent bass in the room. But

this can potentially lead to boomy and muddy sounding bass.

When connecting any speakers, be sure to read the instruction manuals that came with the product and check your power amplifier's instruction manual for proper hook-up of the loudspeakers.

IMPORTANT: The FAP T1 is shipped from

the factory in the following default mode:

Output Configuration 7.1

Speaker Size Small

All Crossovers 100Hz

System Setup

To configure the FAP T1 for your speaker system:

The first step in configuring the FAP T1 to operate with your speaker system is to set the type, number and crossover frequencies of your particular loudspeakers. You make these selections using the Speaker Configuration menu shown below.

NOTE:The following selected menus appear on the FAP T1

Display and the OSD (On Screen Display)

Figure 2

1. Press the MENU button to enter the Main Menu.

The Main Menu appears and the cursor should be pointing to INPUT CONFIG.

2. Press the button once to select SPEAKER CONFIG.

3. Press (Select) to enter the Speaker Configuration menu.

The Speaker Configuration menu appears and the cursor should be pointing to FRONT.

The first three settings in the Speaker configuration menu deal with the type of speakers you are using in your system. It is very important that you understand what is meant by the LARGE and SMALL settings in this menu. They do not refer to the physical size of the speakers, but to their ability to handle very powerful deep bass. Most loudspeaker systems on the market should be classified as Small, since they do not have the capability to handle the often extraordinary amount of deep bass content film soundtracks can contain.

It is strongly recommended that you consult your loudspeaker instruction manual regarding the capabilities of your particular system with regard to low bass/low frequency reproduction.

Please note that all THX certified loudspeaker systems are classified under this method as SMALL since a subwoofer is required for any THX certified loudspeaker system.

Always consider using a subwoofer for any system which you expect to effectively handle the low frequency dynamics of modern motion picture soundtrack sources such as DVD or HDTV feeds, and many other discrete multi-channel programming sources.

If you aren't sure about your speaker's real world capabilities and you are using a subwoofer, choose Small, since this will insure that all the appropriate low frequency information is directed to the subwoofer where it can be most effectively handled.

4. Use the and buttons to cycle through the speaker

options for the FRONT speaker.

The following options are available for each group of speakers:

• For FRONT you can select SMALL or LARGE.

• For CENTER you can select SMALL, LARGE or NONE.

• For SURR(OUNDS) you can select SMALL, LARGE or

NONE.

• For SURR(OUNDS) REAR you can select BS(LB), LB/RB or

NONE.

LB/RB means you have a Left Back and Right Back rear surround speaker setup for use in a 7.1 configuration. BS(LB) means you have a single centrally placed BACK Surround speaker for use in a 6.1 (EX) type configuration.

• For SUBWOOFER you can select 0N or 0FF

5. Press the button when you have made a selection.

Repeat steps 4 and 5 until you have completed selecting the speaker type for each loudspeaker in your system.

6. Press the button when you are finished to select FRONT

XOVER (Crossover).

The Front, Center and Surround Crossover menus are used to independently set the internal High Pass filter of the

FAP T1's

Cirrus Triple Crossover for each of these three speaker groups.

7. Use the and buttons to adjust the Front Crossover.

The crossover settings appear as follows as you scroll through them:

40Hz > 60Hz > 80Hz > 100Hz > 120Hz > 150Hz

You can scroll in either direction using the and buttons.

Consult the material that came with your loudspeakers to determine the correct settings, if any are recommended. The THX standard is 80Hz. In general, if you are not sure about the frequency response of your speakers, we recommend you set the crossover at 80Hz, unless otherwise directed by the manufacturer. If you are using very small satellite speakers you may need to set the crossovers to 100 or even 120Hz. When correctly set, you should hear a smooth transition of lower to upper bass between the satellites and the subwoofer.

8. Press the button when you have made a selection.

Repeat steps 7 and 8 until you have completed the speaker crossover settings for each group of speakers.

9. Press the button to select RETURN TO MAIN MENU.

10.Press the (Select) or MENU button to return to the

Main Menu, or press the MENU button twice to exit the menu system.

System Setup

CHANNEL CALIBRATION – Setup and Selection

The next step is to adjust the output level of each channel so that they are properly matched. This must be done to insure a correct presentation of multi-channel sound sources. The adjustment must be as precise as possible, and is almost impossible to accomplish by ear. Therefore, we recommend that you use a Sound Level Meter. This device insures that all loudspeaker levels are precisely matched and set accurately. (The Radio Shack Analog Sound level Meter is inexpensive and suitable for this task.)

NOTE:If for any reason you are not sure that you can accomplish

this calibration task or have any doubts as to how it should be done, please contact Fosgate Audionics' technical support BEFORE attempting this process.

Set the meter to Slow response and "C" weighting. Set it to the 70 or 80dB sensitivity scale. Position the meter at the approximate center of your listening area, at average ear height [approximately 40-46 inches (102-117cm)] with its microphone positioned vertically (pointing at the ceiling). Don't aim the microphone at the speakers, as this will produce inaccurate results.

To proceed with the adjustments, you will access the Channel Calibration menu shown below.

NOTE:The following selected menus appear on the FAP T1

Display and the OSD (On Screen Display)

Figure 3

With no source playing, set the volume level of the FAP T1, using the main volume control, to 0dB.

To set the channel levels for your system:

1. Press the MENU button to enter the Main Menu.

The Main Menu appears andhe cursor should be pointing to INPUT CONFIG.

2. Press the button until CHANNEL CALIB is selected.

3. Press (Select) to enter the Channel Calibration menu.

The Channel Calibration menu appears and the cursor should be pointing to LEFT FRONT.

A special test tone will be generated allowing you to measure the output of the speaker that's playing.

NOTE: If the test tone is too loud with the main volume level set at

0dB, reset it to -10dB and proceed with the calibration as described.

4. Use the and buttons to adjust the speaker level.

You can adjust the selected channel level in 1dB steps across a range of -15dB to + 10dB. The recommended calibration level is 75dB/SPL as displayed on the meter.

5. Press the button when you have finished making the Left Front level adjustment.

Repeat steps 5 and 6 until you have completed setting the level for each speaker in your system. Set all the levels to 75dB.

6. When you have finished adjusting the level for all the speakers in your system, press the button to select the Return to Main Menu option.

7. Press the (Select) or MENU button to return to the Main Menu, or press the MENU button twice to exit.

You can also perform this calibration at any time by pressing the TEST button on the remote control.

To set channel levels using the Test Tone function:

1. Press the TEST (Guide ) button on the remote.

This display will show at the bottom:

When you select this function, the FAP T1's Test Tone will automatically cycle every few seconds through all the speakers connected and which have been setup in the Speaker Config menu on the

FAP T1.

The unit cycles through the speakers in the following sequence:

LEFT FRONT > CENTER FRONT > RIGHT FRONT > RIGHT SURR(OUND) > RIGHT BACK (SURROUND) > LEFT BACK (SURROUND) > LEFT SURR(OUND) > SUBWOOFER

2. Use the and buttons to adjust the speaker level.

You can adjust the selected channel level in 1dB steps across a range of -15dB to +10dB.

While you are adjusting each speaker, the Test Tone will remain on that channel until you have stopped changing the volume for a few seconds. The unit will then resume cycling the Test Tone from speaker to speaker, until you touch the TEST button again.

NOTE:Speakers that you selected "None" for in the Speaker Config

menu will not appear.

3. Press the TEST (Guide ) button on the remote control again to exit the Test Tone function.

SYSTEM CONFIGURATION – Setup and Selection

The System Configuration menu is used to enter Speaker Distances (for proper sound delay), set Display parameters, operate the Sleep Timer, and turn Theater Compensation on or off. The Display, Sleep Timer and Theater Compensation settings are covered in the section titled "Operation." The System Configuration menu is shown below.

NOTE:The following selected menus appear on the FAP T1

Display and the OSD (On Screen Display)

Figure 4

System Setup

Setting The Speaker Distance Delays

Setting the speaker delay is crucial to the proper performance of any surround decoder component like the

FAP T1. Your home theater

system will not perform properly if this process is not completed.

To accomplish this process you will need a tape measure or other means of determining the distance of each speaker from the primary listening position.

To set the speaker distance delays for your speakers:

1. Press the MENU button to enter the Main Menu.

The Main Menu appears and the cursor should be pointing to INPUT CONFIG.

2. Press the button until SYSTEM CONFIG is selected.

3. Press the (Select) button to enter the System Configuration menu.

The System Configuration menu appears and the cursor should be pointing to FRONT DISTANCE.

Before setting the speaker distances, you need to choose what unit of distance you will be using.

4. Press the button repeatedly until DISTANCE UNIT is selected.

5. Use the and buttons to select between Feet and Meters.

6. Press the button repeatedly until you return to

FRONT

DISTANCE

To set the distance for each group speakers in your system, you will need to measure, as precisely as possible, the distances from your chosen listening/viewing position to the various loudspeakers in your system.

Set the distance for the Front L/R speakers to the nearest foot/meter. Rounding up is OK. Distances can be set in the following increments:

Feet 0 to 20 feet in 1 foot increments. Meters 0 to 6 meters in

0.3 meter increments.

You can scroll in either direction using the

and buttons.

7. Press the button when you have made a selection.

Repeat steps 6 and 7 for the Center and Surround speakers.

You should note your final settings above for future reference. Use the spaces below to enter the distances for your speaker setup.

L/R [ ]m/ft C [ ]m/ft SL/SR [ ]m/ft

NOTE:There is no delay function for the subwoofer

8. Press the button to select RETURN TO MAIN MENU

9. Press the MENU button to return to the Main Menu, or press the MENU button twice to exit.

Dolby Pro Logic II (PLII) Music Parameter

The PLII Music Parameter menu is used to adjust the Panorama, Dimension and Center Width processing options when listening to music in the Dolby Pro Logic II surround mode. For a description of these options, see page 6 in the section tided "

Surround Format

Information

". The PLII Parameter menu is shown below.

NOTE:The following selected menus appear on the FAP T1

Display and the OSD (On Screen Display)

Figure 5

To adjust the PLII Music Parameters:

1. Press the MENU button to enter the Main Menu.

The Main Menu appears and the cursor should be pointing to INPUT CONFIG.

2. Press the button until the PLII MUSIC PARAMETER is selected.

3. Press

(Select) to enter the PLII MUSIC PARAMETER

menu.

The PLII MUSIC PARAMETER menu appears and the cursor should be pointing to

PANORAMA.

4. Use the and buttons to select between On and Off.

When this setting is On, Pro Logic II's Panorama circuits will blend an amount of the front channel information into the side speakers so that the soundfield appears to wrap around the front and sides of the soundstage. Experiment with a variety of program sources to see if this effect is one you prefer.

5. Press the button to select DIMENSION.

6. Use the and buttons to cycle through the Dimension options.

The Dimension settings appear as follows as you scroll through them:

STEP0 > STEP1 > STEP2 > STEP3 > STEP-3 > STEP-2 > STEP-1

You can scroll in either direction using the and buttons.

The Dimension Control uses special circuitry to give the impression that the "center" of the soundfield is moving towards the front or rear of the room. Experiment with a variety of program sources to see if this effect is one you prefer. Use as much or as little Dimension as you feel is needed.

System Setup

7. Press the button to select C WIDTH.

8. Use the and buttons to cycle through the C Width options.

The C Width settings appear as follows as you scroll through them:

STEP 0 > STEP 1 > STEP 2 > STEP 3 > STEP 4- > STEP 5 > STEP 6 > STEP 7

You can scroll in either direction using the and buttons.

Depending on how the Center Width control is set, you may adjust the apparent placement of the center channel image so that it is heard only from the center speaker, so that it is blended into the left and right speakers as a phantom image, or that it is blended among the front left, center and right speakers in varying amounts. As with the other Pro Logic II controls, the use of this setting and the degree to which it is used is a matter of personal preference.

9. Press the button to select RETURN TO MAIN MENU

10.Press the MENU button to return to the Main Menu, or press the MENU button twice to exit.

MULTI–ZONE – Setup and Selection

This menu controls the setting for your second zone (zone 2) and the output from the ZONE OUT jacks on the rear of the

FAP T1.

This function can be accessed in two ways. You can press the MULTI (T/V) button on the remote control, or you can access this feature through the MAIN MENU. The Multi-zone menu is shown below.

NOTE:The following selected menus appear on the FAP T1

Display and the OSD (On Screen Display)

Figure 6

To adjust the Multi-zone settings:

1. Press the MENU button to enter the Main Menu.

The Main Menu appears and the cursor should be pointing to INPUT CONFIG.

2. Press the button until MULTI–ZONE is selected.

3. Press

(Select) to enter the MULTI–ZONE menu.

The MULTI–ZONE menu appears the cursor should be pointing to MULTI-ZONE.

4. Use the and buttons to select whether you want the MULTI–ZONE feature ON or OFF.

If ON is selected, the blue LED below the word ZONE on the front panel will illuminate indicating activation of the second stereo zone.

5. Press the button to select INPUT.

6. Use the and buttons to select which source signal will be sent through the ZONE OUT outputs to the second zone (Zone 2).

The Source choices appear as follows as you scroll through them:

DVD > VIDE01 > VIDE02 > VIDE03 > VCR > TUNER > CD > TAPE > AUX1 > AUX 2

You can scroll in either direction using the and buttons.

7. Press the button to select MUTE.

8. Use the and buttons to select whether the MULTI–ZONE mute function is ON or OFF.

9. Press the button to select VOLUME.

10.Use the and buttons to increase or decrease the volume level of the signal being sent to the second zone (Zone 2).

The range available is from -80dB to 10dB. Use caution as you can set a very high volume level and not be aware of it because of the distance between you and the second zone.

11.Press the button to select RETURN TO MAIN MENU.

12.Press the (Select) or MENU button to return to the Main Menu, or press the MENU button twice to exit.

Direct Operation

In addition to entering settings into the FAP T1 using the Menu System, as described, many of the controls may be changed directly at any time using the remote control or front panel buttons. To change one of these settings (for example, Channel Trim), simply press the appropriate button on the remote or front panel and use the navigation buttons as required to change the settings.

Operation

Now that you have completed the initial setup and configuration of the

FAP T1, it is simple to operate and enjoy. Reading the following section will help you get the maximum pleasure from your new equipment. Make sure the unit is plugged in and the Main Power switch on the rear panel of the

FAP T1 is in the On

position, as outlined in the "

System Setup" section.

NOTE:The following selectionss appear on the FAP T1 Display and

the OSD (On Screen Display).

POWER

To turn the FAP T1 on and off:

1. Press the front panel Standby Power button to turn on the

FAP T1, or press the AUD button on the remote control.

The FAP T1 DISPLAY will light up and the Standby indicator will turn off.

Alternatively, pressing any of the source selection buttons (DVD, CD, VCR, etc.) on the remote control will turn on the

FAP T1.

Powering the unit on this way sets the

FAP T1 to the selected source and sets control of the remote control to that source device. To control the

FAP T1, press the AUD (FAP T1) button

on the remote.

2. Press the Standby Power button on the front panel again or press the POWER button on the remote control to return the

FAP T1 to Standby mode.

The FAP T1 DISPLAY will go out and the Standby Indicator will light up.

NOTE:The remote needs to be set to control the FAP T1 (by

pressing the AUD button) before the POWER button will turn off the unit.

SELECTING A SOURCE

Before you can listen to any input, you must first select that input as the source. This tells the

FAP T1 which input source to send out

to the speakers and monitor.

To select an input source:

1. Press one of the Source buttons (DVD, CD, VCR, etc.) on the remote control or press the UP or DOWN SOURCE buttons on the front panel of the FAP T1 to cycle through the input sources.

The display will show the source you have selected. The settings displayed will be those that you set in the Input Configuration menu during initial setup. An example is shown below:

2. Press AUX 1 or AUX 2 on the remote to select one of the auxiliary audio input sources

NOTE:When a video input has been selected as the current source,

its video signal will appear on the connected television or monitor. Changing the selected input to an audio-only source (CD, AUX1, AUX2, etc) will switch the audio output to the new source, while leaving the previously selected video input active.

Selecting a Source Input

When you select a source from the FAP T1's remote or front panel, the input selected during Input Configuration is automatically used as the source input.

To select a source input type:

1. Press the DIGITAL button on the remote control or the DIGITAL SELECT button on the front panel.

The next input in order will be chosen and displayed.

The input type choices will display in the following order:

ANALOG > OPTICAL1 > OPTICAL2 > OPTICAL3 > OPTICAL4 > COAXIAL1 > COAXIAL2

2. Press the same button repeatedly to cycle through inputs.

Your selection becomes the new default input for that source.

VOLUME CONTROL

Use this control to adjust the volume level of all currently connected speakers.

To adjust the main volume level:

• Press the or and VOL buttons on the remote or turn

the VOLUME knob on the front panel to adjust the volume of the

FAP T1.

You can adjust the main volume level from -80dB to +10dB. 0dB corresponds to the approximate level you would hear in a properly calibrated movie theater. The volume level appears in front of the dB indicator on the display.

NOTE:The main volume control does not affect the volume level in

the second zone (Zone 2).

MUTING THE VOLUME (Remote Control Only)

Use this control to turn the sound off momentarily.

To mute the main volume:

1. Press the MUTE button on the remote control.

The sound will be muted and the On/Standby/Mute indicator will blink continuously. The word MUTE replaces the volume level on the display.

NOTE: The volume level in the second zone (Zone 2) is not affected.

2. Press either MUTE button again to restore the volume to its previous level.

The On/Standby/Mute indicator will go out.

Operation

CHANGING THE SURROUND MODE

Use these controls to change the surround mode from the default selected during Input Configuration.

1. Press one of the Surround mode buttons ( , DTS, CR SURR or STEREO) on the remote or the SURROUND MODE button on the front panel.

When the FAP T1 acquires a digital bitstream, the display will show what type it is (PCM, S/PDIF) and the number of channels (2/2,2/0,3/2.1, etc.) contained in the signal. An example is shown below:

2. Press the button again to cycle through the available surround modes.

Only those modes that can be used with the currently selected source will be available as you cycle through the choices. Your selection will appear above the volume level on the display.

Use the information on pages 6-7 to learn more about the available surround mode options.

SURROUND DATA FORMAT LOCK

The FAP T1 will automatically set the surround format based on the signal it receives from the selected source. To avoid the slight delay occasionally encountered in the Auto Select process, you can choose to override the Auto Data Format detection circuitry by following the procedure below.

To lock a specific surround mode:

1. Press the desired Surround Mode button ( , DTS, CR SURR or STEREO) on the remote control repeatedly to cycle through the available processing options.

Your selection will appear on the display.

2. Press the same button for five (5) seconds to choose from among three data format options for digital audio sources.

The following is shown on the display:

Auto is the Default setting for this option, and means that when the unit detects the special code imbedded within certain data streams such as Dolby Digital or DTS it will set itself to properly decode that type of incoming signal.

3. Use the and buttons to select one of the Data Format options.

You can select either Dolby D(igital), DTS, or PCM (for Pro Logic II), as the default format. If you do this, signals that are not in the selected format won't be recognized. Therefore, we recommend that you leave the system in Auto Mode unless you wish to use the selected mode exclusively.

The Data Format menu will disappear automatically approximately 10 seconds after you make your selection.

BYPASS SETTING

When playing an analog input source you may bypass the FAP T1's digital processing system and listen to the source in "pure" two-channel stereo.

To change the FAP T1 to Stereo bypass mode:

1. Press the BYPASS button on the remote or the ANALOG BYPASS button on the front panel

The source signal will be passed through without any digital processing. If the currently selected source input is digital (Coaxial or Optical), the

FAP T1 will automatically change to the analog input for that source and the show the information on the display as shown below:

2. Press the button again to return the signal path to the digital system.

TUNER OPERATION

The FAP T1 Tuner can receive AM, FM and FM stereo broadcasts. Up to 32 stations can be preset and accessed from the front panel or remote. Stations can also be tuned manually.

NOTE:Tuner reception cannot take place unless an appropriate

AM and/or FM antenna is connected to the rear panel of the FAP T1 as described on page 16.

To operate the tuner:

1. Press the AM/FM button on the remote control once, or press either SOURCE button on the front panel until the display shows:

This indicates that the Tuner is in FM, with Stereo selected as the Surround mode. The number displayed next to the Tuner text is the Preset number currently selected or last selected, followed by the Stereo reception indicator if the station is being received in stereo. The numbers next to the FM text are the frequency of the selected preset or station. The numbers in front of the dB indication are the current volume setting.

2. Press the AM/FM button on the remote control or the front panel to change between AM and FM bands.

3. Use the Tune Up and Tune Down buttons on the front panel or CH/TUNE and on the remote to change tuner frequency.

The new frequency will be displayed to the left of the volume level on the display.

Pressing a TUNE button once increases or decreases the FM frequency by 0.1 MHz and the AM frequency by 10 KHz.

4. Press and hold either the Tune Up or Tune Down buttons on the front panel or CH/TUNE and on the remote to scan continuously up or down the selected band. The tuner will stop on the next available station when you release the button.

5. Press the T.MODE button on the remote or the FM MODE button on the front panel to toggle between Stereo and Mono.

If an FM station produces lots of noise or sound that cuts in and out while in stereo, use this control to change the FM mode from Stereo to Mono. If you select Mono as the operating mode an "

M" will appear next to the preset number.

To preset a radio station into memory:

1. Tune to the radio station you desire.

2. Press and hold the MEM button on the remote or the MEMORY button on the front panel to store a station into a preset location.

The display will change to show the word Memory along with a flashing number as shown below:

3. Quickly enter the desired preset/memory location (01 through 32) using the numeric keypad on the remote.

This programs the radio station to that memory location. You have approximately 5 seconds to enter a number.

Up to 32 stations can be stored, randomly between AM and FM, in memory as presets.

To tune to a radio station that you have preset:

1. Set the FAP T1 to Tuner.

2. Use the numeric keypad on the remote control to enter the 2-digit number of the preset that you want to hear.

The tuner frequency (and band if it is different then the previously tuned station) changes to the new station in the preset memory of the

FAP T1.

To change a preset radio station:

1. Tune to the new radio station you desire.

2. Press and hold the MEM button on the remote or the MEMORY button on the front panel.

The display will change to show the word Memory along with a flashing number.

3. Quickly enter the new preset/memory location (01 through

32) using the numeric keypad on the remote.

This replaces the previously memorized preset with your new selection. You have approximately 5 seconds to enter a number.

RECORDING A SOURCE

You can record from any input source available to the FAP T1 when you have an audio or video recorder properly connected to the appropriate output jacks on the rear panel of the unit as outlined in the section titled "Installation" starting on page 12.

NOTE:You can not monitor the output from the recorder while the

recording is in progress.

To record from the currently selected input source:

1. Prepare your recording device.

Follow the recommended procedures from the recorder manufacturer regarding settings in order to properly make a recording.

2. Set the device to the record mode and begin recording.

The source audio signals appear at the TAPE OUT and VCR-OUT audio jacks of the

FAP T1. If the source contains a video signal, the output appears at both the S-Video and Composite VCR-OUT video jacks.

Any digital source selected automatically appears at the DIGITAL OUTPUT jacks.

NOTE:If you change the input source during recording, you will

record the signals from the newly selected input source from that point on.

NIGHT MODE

Night Mode is a special feature of Dolby Digital that compensates for difficult listening situations by compressing the dynamic range of the speaker output. An example would be when you are watching a movie with a soundtrack that contains very loud passages and you don't want to disturb others in the house.

Information on the various compression options can be found on page 19. Night Mode compensation is only available when the surround mode of the selected input source is set to Dolby Digital or Dolby Digital EX.

To enable/disable Night Mode compensation:

1. Press the NIGHT button on the remote control.

The Night Mode selected during Input Configuration appears on the display under the currently selected input source.

2. Use the and buttons to change the Night Mode setting in the following sequence:

NO COMP > DR COMP1 > DR COMP2 > DR COMP 3 > DR COMP4

The Night Mode menu will disappear automatically approximately 10 seconds after you make your selection.

Operation

CHANNEL TRIM

Channel Trim allows you to fine tune the channel levels to compensate for various soundtrack anomalies. For example, you may play a movie and find that the center (dialogue) channel is weak, making the movie hard to follow. Simply trimming the Center channel up a dB or two can fix the problem. Or another film may have substantially more bass than normal and trimming the Subwoofer channel down a dB or two may help balance the sound correctly.

This function can be accessed in two ways. You can press the TRIM button on the front panel or the remote control, or you can access this feature through the Main Menu. The Channel Trim menu is shown below.

Figure 7

To adjust channel trim from the Main Menu:

1. While playing the program material with output that you wish to fine tune, press the MENU button to enter the Main Menu.

The Main Menu appears on the FAP T1 Display and the OSD. The cursor should be pointing to

INPUT CONFIG.

2. Press the button until CHANNEL TRIM selected.

3. Press (Select) to enter the Channel Trim menu.

The Channel Trim menu appears and the cursor should be pointing to LEFT FRONT.

4. Use the and buttons to adjust the channel trim.

You can adjust the selected channel trim level in 1dB steps across a range of -15dB to +10dB.

5. Press the button when you have finished making the channel trim adjustment.

If necessary, repeat steps 4 and 5 until you have completed setting the level for each speaker in your system. The sequence is as follows:

LEFT FRONT > CENTER FRONT > RIGHT FRONT > RIGHT SURR(OUND) > RIGHT BACK (SURROUND) > LEFT BACK (SURROUND) > LEFT SURR(OUND) > SUBWOOFER

6. Press the button when you have finished making the channel trim adjustment to all the speakers in your system to select the Return to Main Menu option.

7. Press the (Select) or MENU button to return to the Main Menu, or press the MENU button twice to exit.

To adjust channel trim using the TRIM function:

1. Press the TRIM button on the front panel or the remote control.

The displaywill show the following:

2. Use the and buttons to adjust the channel trim level.

You can adjust the selected channel level in 1dB steps across a range of -15dB to +10dB.

3. When you are finished adjusting the Channel. Trim for the selected speaker, press TRIM again to cycle to the next channel.

The unit cycles through the speakers in the following sequence:

LEFT FRONT > CENTER FRONT > RIGHT FRONT > RIGHT SURR(OUND) > RIGHT BACK (SURROUND) > LEFT BACK (SURROUND) > LEFT SURR(OUND) > SUBWOOFER

If necessary, repeat steps 2 and 3 until you have adjusted the channel trim of all the speakers in your system.

4. Press the TRIM button on the front panel or the remote control again to exit the Channel Trim function.

Remember to return any channel(s) that you have trimmed back to the original setting when you are done watching the particular program. If you find you are continually trimming the same channel(s) by the same amount for every film, you might want to consider re-calibrating the speaker levels as shown in the section, "Channel Calibration" on page 22. Set the levels for the channel(s) up or down by the amount you normally trim them.

THEATER COMPENSATION

Theater Compensation provides special equalization within any of the selected DSP modes. Most theatrical soundtracks are mixed on large dubbing stages for playback in large movie theaters. When these are played back in your home, they may appear to have too much treble, sounding harsh and "bright." Theater Compensation modifies the audio signal to reduce these characteristics and make the soundtrack reproduction more natural sounding.

Theater Compensation can be accessed from the Main Menu or the +10 (Hi-EQ) button on the remote.

To turn on Theater Compensation from the Main Menu:

1. Press the MENU button to enter the Main Menu.

The Main Menu appears and the cursor should be pointing to INPUT CONFIG.

2. Press the button until SYSTEM CONFIG is selected.

3. Press the (Select) button to enter the System Configuration menu.

The System Configuration menu appears and the cursor should be pointing to FRONT DISTANCE.

4. Press the button until THEATER COMPEN is selected.

5. Use the and buttons to choose between On and Off.

6. After making your selection, press the MENU button twice to exit the Main Menu.

Turn on Theater Compensation using the +10(Hi-EQ) button:

1. Press the +10(Hi-EQ) button on the remote control.

The display will show the following:

2. Press the +10(Hi-EQ) button again to toggle the between On and Off.

The Theater Compensation menu will disappear automatically approximately 15 seconds after you make your selection.

Dolby Pro Logic II Cinema and DTS-ES NEO:6 Cinema include a form of equalization of their own to address the same conditions. When using these modes the addition of Theater Compensation may cause excessive reduction of the upper frequencies. However, you may wish to experiment with different soundtracks to find what sounds best to you.

IMPORTANT:Theater Compensation is not recommended for Music

modes, as the equalization added is not normally needed.

MULTICHANNEL SOURCE PLAYBACK

Access to a 5.1 channel source connected to the Multichannel Inputs is accomplished by using the 6 Channel Direct mode. Examples of a 5.1 channel source would be a DVD-A or SACD multi-channel player.

Analog Bass Management

The FAP T1 provides Analog Bass Management when 6 Channel Direct is selected. This function, which only applies to a source connected to the Multi-channel inputs, is controlled via a small toggle switch on the rear panel of the

FAP T1.

If the switch is set in the Bypass-Down position, no crossover filtering occurs, providing the full bandwidth signal, including all bass information, to the speakers. Also no information below 80Hz is sent to the subwoofer output.

If the switch is set in the OFF-Center position, no crossover filtering occurs, providing the full bandwidth signal, including all bass information, to the speakers. However, all information below 80Hz is still summed and sent to the subwoofer output.

When the switch is in the On-Up position, the Analog Bass Management function is On, and the unit will provide an 80Hz crossover for the Left, Center, Right, Left Surround and Right Surround loudspeakers. Bass below 80Hz from all these channels will be sent into the subwoofer (.1) channel.

NOTE: Since in the Off position bass information is not removed

from the speakers outputs, it is recommended that, unless you are absolutely sure your loudspeakers can handle the low frequency information, or that this function is supplied within your DVD player, you leave this switch in the Up/On position.

Once you have connected a component to the Multichannel inputs and set the Analog Bass Management, you should never have to change it, unless you get different speakers or a player that includes its own bass management.

To enter 6 Channel Direct mode:

1. Press the 6 CH button on the remote control.

The FAP T1 is set to Bypass mode, circumventing any internal surround processing and the display will read:

2. Press the 6 CH button again to turn off 6 Channel Direct mode, or use the Source selection buttons on the remote or front panel to select another source.

If you use the remote 6 CH button, the unit will return to the previously chosen source and settings.

SETTING THE FAP T1 DISPLAY BRIGHTNESS

This control sets the FAP T1 Display brightness. The default display bright-ness is set to be easily visible in a normally lit room. If you prefer to dim the display, for example, during movie viewing in a darkened room, you can access the VFD Brightness setting from the System Configuration menu.

To set the FAP T1 Display brightness;

1. Press the MENU button to enter the Main Menu.

The Main Menu appears and the cursor should be pointing to INPUT CONFIG.

2. Press the button until SYSTEM CONFIG is selected.

3. Press the (Select) button to enter the System Configuration menu.

The System Configuration menu appears and the cursor should be pointing to FRONT DISTANCE.

4. Press the button until the VFD BRIGHTNESS is selected.

5. Use the and buttons to choose between Full and Half.

6. After making your selection, press the MENU button twice to exit the Main Menu.

SETTING THE ON SCREEN DISPLAY (OSD) TIME OUT

Use this to set how long the On Screen Display (OSD) will remain visible after a button is pushed or setting is changed on the

FAP T1.

To set the On Screen Display Time Out:

1. Press the MENU button to enter the Main Menu.

The Main Menu appears and the cursor should be pointing to INPUT CONFIG.

2. Press the button until SYSTEM CONFIG is selected.

3. Press the (Select) button to enter the System Configuration menu.

The System Configuration menu appears and the cursor should be pointing to FRONT DISTANCE.

4. Press the button until OSD TIME OUT is selected.

5. Use the and buttons to cycle through the available options.

The following times appear as you scroll through them:

30Sec > 25Sec > 20Sec > 15Sec > 10sec > 5Sec > 3Sec

6. After making your selection, press the MENU button twice to exit the Main Menu.

Operation

SLEEP TIMER

This option allows you set how long the unit will remain on before automati-cally shutting off. This mode can be accessed using the SLEEP button on the remote control, or from System Configuration menu.

To set the Sleep Timer from the Main Menu:

1. Press the MENU button to enter the Main Menu.

The Main Menu appears on the FAP T1 Display and the OSD. The cursor should be pointing to

INPUT CONFIG.

2. Press the button until SYSTEM CONFIG is selected.

3. Press the (Select) button to enter the System Configuration menu.

The System Configuration menu appears and the cursor should be pointing to FRONT DISTANCE.

4. Press the button until SLEEP TIME SET is selected.

5. Use the and buttons to cycle through the available choices.

The following times appear as you scroll through them:

60Min > 50Min > 40Min > 30Min > 20Min > 10Min > 5Min

6. After making your selection, Press the MENU button twice to exit the Main Menu.

To set the Sleep Timer using the SLEEP button:

1. Press the SLEEP button on the remote control.

The display will show the following:

2. Press the SLEEP button repeatedly to cycle through the time remaining options.

The following times appear as you press the SLEEP button:

60Min > 50Min > 40Min > 30Min > 20Min > 10Min > 5Min

The Sleep Timer menu will disappear automatically approximately 5 seconds after you make your selection.

MULTI-ZONE OPERATION

The FAP T1 allows you to send a stereo signal to a remote second zone. This signal must be amplified by an optional external power amplifier and sent into speakers in the remote zone. You can choose to feed any analog stereo source connected to the inputs of the FAP T1 to the second zone and you can independently control its volume, regardless of what source has been chosen to play on the main system.

To turn ON the Multi-zone system from the main listening area:

1. Press the MULTI button on the remote control.

The Multi-zone menu appears on the display.

2. Use the and buttons to select On.

The blue LED below the word Zone on the front panel will illuminate indicating activation of the second stereo zone. Your selection will appear on the display.

The low voltage ZONE output jack on the back of the

FAP T1

will be energized. Its output can be used to turn on the remote power amplifier (if it has such capability) or trigger another low voltage switchable device.

3. Press the MULTI button again to view the Input menu.

4. Use the and buttons to select which source signal will be sent through the ZONE OUT outputs to the second zone.

The Source choices appear as follows as you scroll through them:

DVD > VIDE01 > VIDE02 > VIDE03 > VCR > TUNER > CD > TAPE > AUX1 > AUX 2

You can scroll in either direction using the and buttons.

Your selection will appear on the display.

Only analog input sources can be used with the Multi-Zone system.

5. Press the MULTI button again to view the Mute menu.

6. Use the and buttons to select whether the Multi-zone mute function is On or Off.

Your selection will appear on the display.

The Multi-zone Mute function is unaffected when pressing the MUTE button on the remote control.

7. Press the MULTI button again to view the Volume menu.

8. Use the and buttons to increase or decrease the volume level of the signal being sent to the second zone.

Your selection will appear on the display.

The range available is from -80dB to +10dB. Use caution as you can set a very high volume level and not be aware of it because of the distance between you and the second zone.

The Multi-zone volume level is unaffected by the VOL buttons on the remote control or

FAP T1 volume control.

9. Press the MULTI button again to exit the Multi-zone menu.

Audio from the source you selected will be heard through the speakers in the second zone.

The Multi-Zone system will remain on until it is specifically turned off. Thus, you may see the Zone indicator on even when the FAP T1 is in the Standby mode with regard to the main room.

If you do not wish to use the Multi-Zone system to send sound to a second zone (Zone 2), you can use it as a separate audio-only record buss output that allows you to record one source while listening to another.

Operation

REMOTE CONTROL SETUP AND OPERATION

The FAP T1 remote control is preprogrammed to operate over 1,000 audio and video components. Programming is done by punching in a three digit code number that matches your equipment.

In addition to the

FAP T1 itself, the remote control can operate up to seven other audio and video devices in your home entertainment system. Examples are listed below:

• TVs, Monitors, Video/LCD Projectors

• Compact disc players, Multi-Disc changers, DVD players,

Laser disc players, VCRs, TV/VCR combination units

• Cable boxes, Internet set-top boxes, Satellite receivers such as

Direct TV, Dish, C-Band

• Audio receivers, Preamplifiers, Surround processors

• Cassette Tape Players, DAT, MiniDisc, Switchers, Lighting,

Home Control Devices, and Line Doublers

For the best performance when operating your remote control, please follow the guidelines listed below.

• Remember to point the remote control toward the remote

control sensor on the FAP T1, not the TV screen. Place the FAP T1 away from strong light such as direct sunlight or fluorescent light, which can prevent proper operation of the remote control.

• Using another remote control of a similar type or placing the

FAP T1 near equipment which also uses infrared control may cause operational interference.

• Do not put objects on the remote control. The buttons of the

remote control may be pressed and drain the batteries.

• Make sure any doors, which may cover the front panel of the

FAP T1, do not have colored glass. Placing the unit behind such doors may prevent proper remote control operation.

• If there is any obstacle between the remote control and the

remote control sensor, the remote control will not operate.

The remote control also has many advanced features that can add ease and enjoyment to the operation of your home entertainment system. After becoming familiar with the layout of the buttons on the remote (see page 10), use the following steps to customize the remote for your particular setup.

Battery Installation

This remote control uses four (4) AAA 1.5 V batteries (supplied). Please be sure to match the batteries with the (+) and (-) markings inside the battery compartment during installation.

To install batteries in the remote control:

1. Open the battery cover by pushing the latch toward the top

of the remote and lifting up

2. Insert four (4) AAA batteries into the compartment, being

careful to match the polarity shown on the diagram inside.

3. Slide the battery cover straight back in (toward the top of

the remote) and push down until it snaps into place.

NOTE: Do not mix new and old batteries or different kinds of batteries.

To ovoid corrosion, remove the batteries if the remote control will not be used for one month or more. Remove dead batteries immediately to avoid damage from corrosion.

Under normal conditions the life of the batteries supplied is about six months, but this may vary depending on usage.

The remote control will retain its programmed memory for up to one year after the batteries are removed, and up to ten years after the batteries go "dead".

Setup Using Preprogrammed Codes

Each of the Source Selection Buttons can be programmed to operate a particular audio or video component in your system. The AUD button is used exclusively for control of the

FAP T1.

More than one setup code number may work with your device. You should test the functions for each of the code numbers that work with your device to determine the best one.

NOTE:Some devices, such as CD players and DVD Decks that do

not have POWER buttons on their original remote controls, may not shut off during programming. For these devices, it may be necessary to first store the setup code number and then test functions like PLAY, STOP, etc., to determine if the correct number has been selected.

If your system has more than one VCR for example, any available Source button can be used to select that device. Use the steps below to program the remaining seven source buttons (TV, VCR, SAT, CBL, CD, DVD, and AUX) on the remote for your devices.

To program using Three Digit Codes:

1. Turn on the device you would like the remote control to operate, either manually or with its original remote control.

2. Find the three digit setup code number for your device from the tables on pages 36-37.

3. Press the corresponding Source button and the MUTE button on the remote control simultaneously.

The red LED and the selected Source button will illuminate.

NOTE: These will remain lit for approximately 10 seconds to indicate

that the remote is ready to be programmed. The following steps must be entered while they are lit. If they go out, simply press the Source and MUTE button again to re-enter the setup code.

4. Point the remote control toward the device that was turned on in Step 1 and press in the first three-digit setup code number for that device using the number buttons (0-9).

The LED and selected Source button will blink and then stay lit after you enter a setup code.

The device will turn off when the correct setup code number has been selected. If the device does not, press in the next setup code number from the listing. The remote will remain in this programming mode as long as you continue to enter codes within 10 seconds of each other.

Continue entering setup code numbers until your device turns off, then proceed to Step 5.

NOTE:If you have tried all of the three digit setup code numbers

listed for your device and it still did not turn off, please proceed to the Auto Search Method to program your remote.

5. Once your device turns off, press the Device Button selected in Step 3 once again to store the setup code number.

The LED and Source button will blink twice and then go out,

6. Test the remote control for your device. Try the POWER, CH/TUNE and , VOL and buttons, etc.

If any of the buttons do not work as they should, repeat the setup from Step 1 using the next setup code number for your device.

NOTE:Some audio/video devices have separate buttons for POWER

ON and POWER OFF. To operate these devices on the remote, press the corresponding Source button to turn the equip-ment ON and press the POWER button to turn the equipment OFF.

7. Please repeat the above steps to program the remote control for each of your other devices.

If none of the setup code numbers worked for your device during the standard setup procedure, or if the manufacturer or brand for your device is not listed in Setup Code Tables, use the following steps.

Operation

To program using Auto Search

1. Turn on the device you would like the remote control to operate, either manually or with its original remote control.

2. Press the corresponding Source button and the MUTE button on the remote control simultaneously.

The red LED and the selected Source button will illuminate.

NOTE:The selected button and LED will remain for approximately

10 seconds to indicate that the remote control is ready to be programmed. The following steps must be entered while they are lit. If the lights go out, simply press the Source and MUTE button again to re-enter the auto search mode.

3. Point the remote control toward the device and press the CH/TUNE button on the remote control.

Each press of the CH/TUNE button sends the signal for one setup code number. The LED and Source button will blink each time you press the CH/TUNE button. Keeping the CH/TUNE button pressed quickly scans through the setup code numbers.

Release the CH/TUNE button as soon as the device turns off. Confirm that you have the correct code by pressing the MUTE button on the remote. You should be able to turn your device on and off with this button.

If you pass the correct setup code number, you can return to it by pressing the CH/TUNE button, one number at a time, until your device turns back on.

NOTE:During programming, the signal for POWER ON and

POWER OFF is located on the MUTE button. For devices that use separate POWER ON and POWER OFF buttons, pressing the MUTE button on the remote control during programming will only turn the device OFF.

4. Once the correct code is confirmed, press the Source button to store the setup code number.

The LED and Source button will blink twice and then go out.

5. Test the remote control for your device. Try the POWER, CH/TUNE and , VOL and buttons, etc.

If any of the buttons do not perform as they should, repeat the setup from Step 1 using the next setup code number.

NOTE:Some audio/video devices have separate buttons for POWER

ON and POWER OFF. To operate these devices on the remote, press the corresponding DEVICE Button to turn the equipment ON and press the POWER button to turn the equipment OFF.

6. Please repeat the above steps to program the remote control for each of your other devices.

To display the stored three digit setup code number for a device:

1. Press the corresponding Source button and the MUTE button on the remote control simultaneously.

The red LED and the selected Source button will illuminate.

2. Press the T/V button.

The LED and Source button will quickly flash the three digit setup code number, pausing between numerals, that was stored for your device. The number zero (0) is indicated by ten flashes.

3. Please write your setup code numbers in the chart at the end of this manual for future reference.

USING THE REMOTE CONTROL

After you have programmed the remote control for your equipment, use the following procedures to operate the components of your home entertainment system:

To operate a device that you have programmed:

1. Press the Source button for the device that you wish to operate

For example, to operate a TV, press the TV button; to operate a VCR, press the VCR button, etc.

2. Aim the remote control at the device and press the POWER button to turn ON the device.

3. Press the buttons that send out the commands you desire.

NOTE:Some audio/video devices have separate buttons for POWER

ON and OFF. To operate these devices on the remote, press the corresponding DEVICE Button to turn the equipment ON and press the POWER button to turn the equipment OFF.

Please try all the functions of this remote control with your device. The most common functions are labeled on the remote. However, some of the secondary functions might be stored under a button that has a different name from the one on your original remote.

Source Selection Buttons

Pressing a Source button at the top of the remote control performs the following functions:

• If the FAP T1 is in Standby mode, powers up the unit.

• Changes the Source input mode on the remote control.

Backlighting

Pressing the LIGHT button illuminates all the buttons on the remote control for 7 seconds. The backlight is extended an additional 7 seconds with any button press while the backlight is on.

Volume Control Punch Through

You can program the remote control so that the FAP T1 VOL , VOL and MUTE functions will operate while the remote is set to control another source.

For example, using the Punch Through function, you can raise, lower or mute the volume of the preamp/processor while the remote control is in the SAT mode.

NOTE: When this feature is active, the AUDIO or TV VOLUME and

MUTE will override any existing volume controls in that mode.

To program the remote for volume control Punch Through:

1. Press the Source button of the device you wish to program for volume control Punch Through and the MUTE button simultaneously

The red LED and the selected Source button will illuminate.

2. Press the VOL button.

The red LED and the selected Source button will blink.

3. Press the AUD button to enable volume control of the FAP T1.

Press the TV button to enable volume control of the television.

The LED and Source button will blink twice and then go out.

The VOL , VOL and MUTE buttons will now control the Punch Through device while another Source is selected.

Operation

To turn off volume control Punch Through for a source:

1. Press the Source and MUTE buttons simultaneously to remove the Punch Through program from the device you wish.

The red LED and the selected Source button will illuminate.

2. Press the VOL button.

The red LED and the selected Source button will blink.

3. Press the Source button again.

The FAP T1 Punch Through function is now turned off. The VOLUME and MUTE of the original device will operate on the remote control.

Macro Buttons

The four Macro buttons (M1-M4) are used to store and send a sequence of up to 10 commands each. They can be programmed in the AUD mode, but can also be accessed in other modes. Macros can be used to turn components on or off or select favorite channels.

NOTE:The MUTE button is used to designate POWER commands

during Macro Button programming. See the Example: Memory Button Programming for further description.

To program a macro button:

1. Press AUD and MUTE buttons simultaneously. The red LED and the AUD button remain lit.

2. Press the Macro button you wish to program.

3. Press up to 10 commands you want the Macro sequence to do.

Pressing a Device button to change modes is counted as one command.

4. Press the CH/TUNE button to store the commands.

The red LED and the AUD button will blink twice to confirm the program and then turn off.

The Macro button will now send the sequence of commands you programmed when pressed.

To erase a Macro sequence:

1. Press AUD and MUTE buttons simultaneously. The red LED and the AUD button remain lit.

2. Press the Macro button that you wish to erase.

3. Press the CH/TUNE button to store the commands.

The red LED and the AUD button will blink twice to confirm the program and then turn off.

The stored sequence is now erased from the Macro button.

NOTE:Any previously stored commands on a Macro Button will be

erased when new commands are stored.

Example of Programming a Macro Sequence:

To program the M1 button in the AUD mode to turn on the Audio receiver, turn on the TV and turn on the VCR,

1. Press AUD and MUTE buttons simultaneously. The red LED and the AUD button remain lit.

2. Press the M1 button.

3. Press the following buttons:

Press the Power button to select the Audio Power command. Press the TV Device button to select the TV mode. Press the Power button to select the TV Power command. Press the VCR Device button to select the VCR mode. Press the Power button to select the VCR Power command.

4. Press the CH/TUNE button.

The red LED and the Device button will blink twice to confirm the program and then turn off.

NOTE: Each insertion of a Device Button adds a 1/2 second delay to

the command sequence. It can take up to 10 seconds to send out 10 commands from a macro button. Continue to point the remote control at the device(s) until all the commands have been sent out. This will ensure that all the commands are received by the device(s).

Learning Commands from Another Remote

The FAP T1's remote control allows you to transfer a command from a button on your original equipment remote to a button on the

FAP T1's remote. Commands can be taught to any button in the DVD, VCR, CD, CBL, AUX, SAT and TV modes except the 8 Source buttons.

The remote provides distinct visual feedback with the Status LED, located at the top left of the remote control, and with the Source buttons. The LED operates in three colors (red, orange and green). The Device buttons have a red color LED. These LEDs will assist you in programming the learning feature of the remote control.

Learning a New Command

Select a Source mode in which you would like to teach the new command. For example, if you wanted to learn a new command to the MENU button in the SAT mode on the remote, you would select the SAT Source button and then use the instructions below to teach the new command to the MENU button.

To learn a new command from another remote control:

1. Press a Source button and the SEL/PLAY buttons

simultaneously until the orange LED and the Device button turn on and remain lit.

2. On the

FAP T1 remote, press the button that is to be taught

the new command.

The orange Status LED will begin to flash continuously. The Device LED will turn off.

3. Place both remote controls next to each other with the IR

emitters face to face.

4. On the source remote (original remote), press and hold the

button for the command to be learned until the Status LED on the

FAP T1 remote turns green. Release the button.

5. Press the same button on the source remote once again to

verify that the new command has been learned correctly. The Status LED will flash green twice and then turn to a steady orange color indicating that the programming was successful.

Repeat Steps 2 through 5 for any other buttons to be taught in the Device mode selected in Step 1. Once you have completed learning new commands to buttons, proceed to Step 6.

6. To save the learned commands, press and hold the Source

and SEL/PLAY buttons simultaneously until the orange Status LED flashes twice.

The Source button light will turn off. Please repeat for any other Source modes starting from Step 1.

Operation

To erase a learned command from a button:

1. Press the Source button and SEL buttons simultaneously until the orange Status LED and the Device button turn on and remain lit.

2. On the remote control, press the button that is to be erased.

The orange Status LED will flash continuously and the Device button will turn off.

3. Press the Light button.

The green status LED will flash twice, then turn to a steady orange. The Device button will turn on.

Repeat from Step 2 for any other buttons to be erased in the selected Source mode.

4. To exit, press and hold the Source button and the SEL/PLAY button simultaneously once again. The orange Status LED will flash twice and then turn off. The Device button will turn off.

To erase all the learned commands in one device mode:

1. Press the Source button and SEL buttons simultaneously until the orange Status LED and the Device button turn on and remain lit.

2. Press the LIGHT button until the red Status LED flashes five times and then flash green twice.

The Device button will turn off. The Status LED will go to a constant orange indicating that all the learned information on buttons in the Device mode have been erased. The Device button will turn on.

3. To exit, press and hold the Source button and the SEL/PLAY button simultaneously once again. The orange Status LED will flash twice and then turn off. The Device button will turn off.

To erase all the learned commands in all device modes:

NOTE:This procedure will erase all learned commands on all but-

tons in the CD, TV, DVD, SAT, CBL, VCR and AUX Source modes.

• Press and hold the TV Source button and the LIGHT button

simultaneously.

The red Status LED will flash continuously. The Status LED will then flash green once, orange once then turn off, indicating that all of the learned commands on all of the device modes on the remote control have been erased.

Care & Maintenance

Troubleshooting

Cleaning

When the unit becomes dirty, wipe it with a clean, soft, dry cloth. If necessary, first wipe the surface with a soft cloth slightly dampened with mild soapy water, then with a fresh cloth dampened with clean water. Wipe dry immediately with a dry cloth. NEVER use benzene, thinner, alcohol or any other volatile cleaning agent. Do not use abrasive cleaners, as they may damage the finish of the metal parts. Avoid spraying insecticide, waxes, polishing agents, or any aerosol product near the unit.

When You Are Away

If you will not be using your home theater system for an extended period of time, it is always a good idea to turn the unit off using the Power Switch on the rear panel of the

FAP T1. This will prevent the automatic turn on circuits from accidentally turning the system on during your absence.

Troubleshooting

Your new FAP T1 is designed to provide years of trouble free operation. However, the complexity of today's sophisticated home theater systems means that you might encounter an occasional problem with your system involving the

FAP T1. Listed below are some of the more common issues you could encounter. For additional hints on using the

FAP T1 or resolving problems we

suggest that you look at the

FAP T1 section of our website at www.fosgateaudionics.com. If your problem persists, please contact us via e-mail at support@fosgateaudionics.com, or call us at 866-888-4404.

System Reset

In rare cases the FAP T1's internal processor may freeze or lock-up causing abnormal operation. This is common to all micro-processor controlled devices when the unit is subject to excessive static discharge, AC line noise, or power spikes.

In most cases it is easy to solve mis problem by simply unplugging the

FAP T1 from its AC power source for about five minutes. After waiting, reconnect the power cord and turn the unit on. If the unit functions normally, no further action is needed.

In the event that the unit still does not operate properly, it may be necessary to manually reset the processor. Note, however, that when the processor is reset you will lose all settings including digital audio assignments, surround mode settings, speaker configurations, tuner presets and any other memory items. For this reason we strongly recommend that you record these settings on the chart provided at the end of this manual so that it is easy to restore them after resetting the processor.

To reset the unit, locate the reset button to the left side of the volume knob, in the space between the volume knob and front casing. With the unit on, use a toothpick or unfolded paper clip to gently press the button. Hold the button for a second and then release it. This should reset the system.

If the manual reset does not solve the problem, contact Fosgate Audionics for further advice.

Symptom Possible Cause Solutions

Unit does not turn on when remote of front panel buttons are pressed

No sound from digital audio source

No DTS when playing DVD

No sound from rear surround speakers

Intermittent buzzing in tuner

Unit does not respond to remote commands

No sound from one or more channels

No AC Power

Input not properly selected

Incorrect bitstream output from DVD player

Incorrect speaker configuration

Interference from local sources

Low remote battery power

Remote set to different device

Remote IR sensor is obscured

Poor connections

Incorrect surround mode

Incorrect speaker configuration

Make certain AC power cord is plugged into live outlet

Make certain rear panel power switch is ON

Make certain the correct digital input is associated to the source

Check the DVD player's setup menus to make certain DTS output is selected

Check the disc menu to make certain DTS is selected

Check SPEAKER CONFIG menu to make certain the "BS(LB)" or "LB/RB" is selected for SURR REAR

Move or relocate the antenna

Move the antenna or unit away from computers, fluorescent or neon lights, or appliances with motors

Change the batteries

Press the AUD button to make sure the remote is outputting

FAP T1 codes

Make certain the

FAP T1 Remote Control IR Sensor is visible or connect a

remote sensor

Check interconnects to the amplifier and connections from the amplifier to the speakers

Check surround mode to make certain it provides output to all speakers

Check SPEAKER CONFIG menu to make certain all speakers are set to SMALL or LARGE

TV (continued)

Manufacturer/Brand Setup Code Number

TELERENT 072 TERA 172 TMK 004 TOSHIBA 015 030 040 062 101 TOTEVISION 143 UNIVERSAL 008 VIDEO CONCEPTS 146 VIDIKRON 174 VIDTECH 004 VORK 004 WARDS 004 008 009 019 028 060

061 063 064 072 074 164 WESTING HOUSE 076 YAMAHA 001 004 YUPITERU 043 ZENITH 072 073 095 103 ZONDA 112

TV (continued)

Manufacturer/Brand Setup Code Number

AWIA 034 161 AKIA 043 046 124 142 146 AMPRO 072 ANAM 031 103 AUDIO DYNAMICS 012 023 043 BROKSONIC 035 037 129 CANON 028 031 CAPEHART 108 CRAIG 001 040 135 CURTIS MATHES 031 041 DAEWOO 005 010 017 108 116 117 DAYTRON 108 DBX 012 023 043 DYNATECH 034 053 ELECTROHOME 059 EMERSON 005 006 017 025 027 029

031 034 035 036 037 046

101 116 129 131 138 153 FISHER 001 008 009 010 FUNAI 034 GE 031 063 072 107 109 144

147 GO VIDEO 132 136 151 GOLDSTAR 004 012 020 101 123 HARMON KARDON 012 045 HITACHI 018 026 034 043 063 137

150 INSTANTREPLAY 031 JCL 031 JCPENNY 004 012 040 101 JENSEN 043 JVC 012 031 043 048 055 060

130 150 152 KENWOOD 014 034 047 048 LLOYD 034 LXI 001 004 009 017 034 101 MAGIN 040 MAGNAVOX 031 034 041 067 068 154

164 MARANTZ 012 031 067 069 MARTA 101 MATSUI 027 MEI 031

VCR

Manufacturer/Brand Setup Code Number

Setup Codes

The following tables contain the setup codes for most brands of audio and video components.

AMERICAST 005 JERROLD 006 007 MITSUBISHI 014 PHILIPS 011 012 PIONEER 001 002 003 SCIENTIFIC ATLANTA 004 SONY 013 TOCOM 010 ZENITH 008 009

CABLE

Manufacturer/Brand Setup Code Number

ALPHASTAR 007 ECHOSTAR 006 GE 001 HITACHI 011 012 HUGHES 003 PANASONIC 013 PRIMESTAR 002 005 RCA 001 SONY 004 TOSHIBA 008 UNIDEN 009 010

SAT

Manufacturer/Brand Setup Code Number

A MARK 112 ADMIRAL 072 081 161 AKAI 001 146 AMPRO 073 167 ANAM 043 056 080 104 108 112

118 121 AOC 001 004 112 AUDIOVOX 076 103 CANDLE 001 003 004 CETRONIC 043 CITIZEN 001 003 004 101 143 CLASSIC 043 CONCERTO 004 CONTEC 043 CORONADO 143 CROWN 143 CURTIS MATHES 001 004 101 143 CXC 043 DAEWOO 004 076 103 114 127 143 DAYTRON 004 143 DYNASTY 043 DYNATECH 062 ELECTROHOME 024 143 EMERSON 001 004 005 028 043 048

076 096 143 151 154 155 FISHER 007 057 FUNAI 028 043 FUTURETECH 043 GE 004 008 034 056 073 074

130 144 155 160 161 GOLDSTAR 004 106 110 112 113 119

127 143 HALL MARK 004 HITACHI 004 007 010 011 012 023

075 143 158 163 INFINITY 164 JBL 164 JCP 001

Manufacturer/Brand Setup Code Number

JCPENNY 004 008 024 030 065 101

143 160 JVC 034 038 070 083 KENWOOD 001 070 KLOSS 059 KTV 043 143 154 LODGENET 072 LOGIK 072 LUXMAN 004 LXI 007 015 052 081 160 164 MAGNAVOX 001 003 004 022 059 060

061 063 064 127 164 MARANTZ 001 164 MATSUI 164 MEMOREX 004 007 072 MGA 001 004 024 042 MITSUBISHI 004 024 040 042 109 146

191 MTC 001 004 062 101 AND 015 025 NEC 001 019 024 040 056 130

134 NIKEI 043 ONKING 043 ONWA 043 OPTONIC 019 081 PANASONIC 034 056 080 164 PHILCO 001 003 004 024 056 059

060 063 064 127 143 164 PHILIPS 001 003 004 005 038 059

093 164 PIONEER 004 018 023 025 135 176 PORTLAND 004 143 PROSCAN 144 160 161 167 PROTON 004 143 171 173 QUASAR 034 056 RADIO SHACK 004 019 127 143 RCA 001 004 023 024 056 065

074 144 152 156 160 161 REALISTIC 007 019 RUNCO 072 169 SAMPO 001 004 SAMSUNG 004 101 127 133 143 160 SANYO 007 057 082 SCOTT 004 028 043 048 143 SEARS 004 007 015 028 030 057

082 094 143 160 SHARP 004 014 019 022 028 081

143 175 SIGNATURE 072 SONY 070 085 126 139 SOUNDESIGN 003 004 028 043 SPECTRICO112 SSS 004 043 SYLVANIA 001 003 059 060 063 064

127 160 164 SYMPHONICS 052 TANDY 081 TATUNG 056 062 TECHNICS 034 080 TECHWOOD 004 TEKNIKA 003 004 024 028 043 072

101 143

MEMOREX 001 010 014 031 034 040

053 072 101 134 139 MGA 045 046 059 MINOLTA 004 020 MITSUBISHI 004 020 046 051 059 061

142 MTC 034 040 MULTITECH 024 034 NEC 012 023 043 048 NORDMENDE 043 OPTONICA 053 054 PANASONIC 031 070 133 140 PENTAX 004 020 031 063 PHILCO 031 034 067 PHILIPS 031 034 054 067 101 PILOT 101 PIONEER 004 021 048 PORTLAND 108 PULSAR 072 QUARTZ 014 RADIO SHACK 101 123 RCA 004 020 031 034 040 041

107 109 140 144 147 158 REALISTIC 001 008 010 014 031 034

040 053 054 101 RICO 058 RUNCO 072 SALORA 014 SAMSUNG 017 040 107 109 113 115

124 SANSUI 043 048 135 SANYO 001 010 014 040 134 SCOTT 017 037 129 131 SEARS 001 004 008 009 010 014

017 020 081 101 SHARP 031 053 054 165 SHINTOM 024 SONY 001 002 009 031 052 053

056 057 058 155 SOUNDESIGN 034 STS 004 SYLVANIA 031 034 059 067 SYMPHONIC 034 TANDY 010 034 TATUNG 043 TEAC 034 043 TECHNICS 031 070 TEKNIKA 031 034 101 THOMAS 034 TMK 006 TOSHIBA 004 008 017 047 059 082

131 150 TOTEVISION 040 101 UNITECH 040 VECTOR RESEARCH 012 VICTOR 048 VIDEO CONCEPTS 012 034 046 141 VIDEOSONIC 040 WARDS 001 004 017 024 031 034

040 053 054 131 WESTINGHOUSE 005 YAMAHA 012 034 043 ZENITH 034 048 056 058 072 080

101 153

VCR (continued)

Manufacturer/Brand Setup Code Number

DENON 014 GE 005 006 JVC 012 LG 057 074 MAGNAVOX 013 MITSUBISHI 002 ONKOYO 017 PANASONIC 003 PHILIPS 013 PIONEER 004 PROSCAN 005 006 RCA 005 006 SAMSUNG 011 015 SHERWOOD 001 057 074 112 114 116 SONY 007 THOMPSON 005 006 TOSHIBA 008 VIETA 116 YAMAHA 009 ZENITH 057 074

DVD

Manufacturer/Brand Setup Code Number

DENON 030 GOLDSTAR 027 KENWOOD 025 MAGNAVOX 026 OPTIMUS 032 PANASONIC 021 PHILIPS 026 PIONEER 020 034 RCA 031 REALISTIC 032 SAMSUNG 023 029 SHARP 025 028 SONY 022 TECHNICS 021 TOSHIBA 025 YAMAHA 033

Manufacturer/Brand Setup Code Number

ADCOM 062 AIWA 089 170 187 AKAI 202 AUDIO TECHNICA 046 CARVER 041 050 135 138 139 167

203 DENON 205 226 FISHER 016 H/K 033 046 047 208 JVC 004 136 163 KENWOOD 007 016 023 055 137 MARANTZ 041 044 MONDIAL 147 AND 005 178 215 NAKAMICHI 218 NIKKO 046 ONKYO 030 038 062 168 169 PANASONIC 068 172 PHILIPS 041 PIONEER 010 020 174

Manufacturer/Brand Setup Code Number

RCA 017 021 REALISTIC 187 SANSUI 171 SHARP 051 173 SHERWOOD 001 051 096 166 SONY 097 126 133 225 TEAC 079 140 TECHNICS 008 068 172 VICTOR 004 YAMAHA 012 046 183 186

CD (continued)

Manufacturer/Brand Setup Code Number

Setup Codes

Please write your setup code numbers in the chart at the end of this manual for future reference.

Specifications

Preamplifier Analog Section

Input Impedance 26kΩ

Output Impedance (Main RCA) <600Ω

Rated Input 2.0V rms

Maximum Input 3.0V rms

Rated Output (100kΩ load) 1.5V rms

Minimum Load 5kΩ

Maximum Output 6.3V rms

Volume Range

Main -80dB to +10.0dB (1dB resolution)

Zone -80dB to +10.0dB (1dB resolution)

Bass Management

High-Pass Slope Crossover Frequency (Small Speaker Setting) (Adjustable

40/60/80/100/120/150Hz) 12dB/octave (2nd order)

Low-Pass Slope 24dB/octave (4th order), 40-150Hz

as above

Tone Control

Bass Center Frequency/Range 30Hz / ±6dB

Treble Center Frequency/Range 10kHz / ±6dB

Channel Separation (at 1kHz) 82dB

Crosstalk Between Inputs (at 1kHz) 86dB

Preamplifier Digital Section

Frequency Response

Direct Inputs 10Hz to 20kHz +0 / -0.2dB

Analog-DSP Inputs 10Hz to 20kHz +0 / -0.5dB

Digital Inputs 10Hz to 20kHz +0 / -0.4dB

THD+N (at Rated Input & Output)

6-Channel Direct Inputs 0.0035% (80kHz BW)

Analog Direct Inputs 0.0035% (AES17 filter)

Analog-DSP Inputs 0.005% (AES17 filter)

Digital Inputs 0.006% (80kHz BW)

IMD (CCIF) @ 15kHz & 16kHz

6-Channel S/E Inputs 0.003%

All Other Analog Inputs 0.002%

Digital Inputs 0.005%

S/N Ratio (ref. 2.0V rms A-weighted)

All Direct Inputs 101dB

Analog-DSP Inputs 98dB

Digital Inputs 100dB

FM Tuner Section

Sensitivity

IHF 10dBµ typ.

50dB S/N 13dBµ typ.

S/N Ratio

Mono 75dB typ.

Stereo 69dB typ.

Distortion

Mono 0.2% typ.

Stereo 0.3% typ.

Stereo Separation 40dB typ.

Adjacent Channel Selectivity 70dB ±400kHz

Frequency Response 20Hz to 15kHz ±1dB

AM Tuner Section

Sensitivity (20dB S/N) 200uV

S/N 50dB

Distortion 0.7%

One Signal Selectivity (±10kHz) 20dB

Video Section

Bandwidth

Composite & S-Video 6MHz -3dB

Component Green 60MHz -3dB

Component Red 60MHz -3dB

Component Blue 60MHz -3dB

All video inputs and outputs are 75Ω (ohms), 1.5V p-p. Component and outputs work with any Video Standard requiring ultra-wide bandwidth including Component-RGB, HDTV, line doublers, quadruplers, and scalers.

Digital Audio

All digital audio inputs and outputs are to S/PDIF electrical (75Ω (ohms),

0.5V p-p), S/PDIF optical (Toslink), or AES / EBU (110Ω (ohms), 5V p-p) standards as appropriate.

Processor Crystal CS493263

Audio Converters

Digital Audio Inputs CS8415A Digital Audio Interface up

to 96kHz

Analog to Digital CS5360 up to 24-bit/48kHz

Digital to Analog CS4396 up to 24-bit/192kHz

General

Supply Voltage 105-130V AC, 60Hz only

Power Consumption 45W (Watts)

Fuse Rating 1.0Amp slow-blow 5x20mm,

2.0Amp slow-blow 5x20mm

Dimensions Width 17 inches (432mm)

Height 6.25 inches (159mm) includes feet

Depth 16 inches (408mm) Allow 2 inches

(51mm) behind unit for connections

Weight 23 lbs. (10.4kg)

Trigger Outputs 1. 2 (Zone) Sequential Delay 50mA @ 12V DC

Second Zone (Zone 2) Section

Frequency Response and Bandwidth 10Hz to 20kHz +0 / -0.2dB

THD+N (at Rated Input & Output) 0.01% (80kHz BW)

IMD (CCIF) @ 15kHz & 16kHz 0.01%

S/N Ratio (ref. 2.0V rms A-weighted) 97dB

Connection Record Chart

Use this chart to record the settings and connections made from your system components to the FAP T1.

Device Surr Mode

Video

Composite S-Video Component

Audio

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

Device Surr Mode

DVD

VIDEO 1 VIDEO 2 VIDEO 3 VCR

Device Surr Mode

Video

Composite S-Video Component

Audio

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

TAPE AUX 1 AUX 2

Device Surr Mode

Video

Composite S-Video Component

Audio

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

Device Surr Mode

Video

Composite S-Video Component

Audio

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

Device Surr Mode

Video

Audio

SECURITY IN

Device

Composite S-Video Component

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

MONITOR

OUTPUT

Device

Video

Composite S-Video Component

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

ZONE OUTPUT

Device

Write your set-up code numbers in the chart below for future reference

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

DIGITAL OUTPUT

COAXIAL

Device

Analog

Coaxial 1 Coaxial 2

Optical 1 Optical 2 Optical 3 Optical 4

DIGITAL OUTPUT

OPTICAL

Device

REMOTE CONTROL SET-UP CODES

DVD

SAT

CBL

DC TRIGGER

Main In

Zone

EXT REMOTE

Main In

Main Out

Zone

MULTI CHANNEL

INPUT

Device

Video

Composite S-Video Component

AUX

Permission to photocopy this page for personal use.

VCR

Index

AM Antenna 16 Analog Bass Management 29 Analog Bypass 26

Battery Installation 31 BYPASS 26

C WIDTH (Center Width) 23 CENTER DISTANCE 23 Changing the Surround Mode 26 CHANNEL CALIB (Channel Calibration) 22 CHANNEL TRIM 28 Cirrus Extra Surround 7 Cleaning 35 Connecting an External Amplifier 16 Connecting Audio Components 13

Audio Recorder 13 CD Player 13

Connecting Video Components 14

DVD Player 14 Satellite Tuner or Television 15 Video Display 15 Video Recorder 15

Contents 6 Crossover (XOVER) 21

DATA FORMAT 26 Digital Select 25 DIMENSION 23 DISTANCE UNIT 23 Dolby Digital 6 Dolby Digital Surround EX 7 Dolby Pro Logic II 7 DTS 7 DTS NEO:6 7 DTS-ES 7

FCC Information 5

Features 8

Front Panel 8 Rear Panel 10 Remote Control 9

FM Antenna 16 FM Mode 27 FM/AM 26 FRONT DISTANCE 23

Headphone Jack 8 Hi-EQ 29

INPUT CONFIG (Input Configuration) 18

Learning Commands from Another Remote 33

Macro Buttons 33 MAIN MENU 18 Main Power Switch 11 Memory 27 Menu 18 Monitor 8 MULTI 30 MULTI-ZONE Operation 30 MULTI–ZONE 24 Muting the Volume 25

Navigating the Setup Menus 18 NIGHT 27 Night Mode 27

OSD TIME OUT (On Screen Display) 29

Index

P.SCAN 10

PANORAMA 23

PLII Music Parameter 23

Power Control Connections 16 Power Cord 5

Power Connection 16

Preset Scan 9 Programming Remote 31 Punch Through Feature 32

Recording a Source 27 Reset Button 35

6 CH 29 Safety 4 Second Zone (Zone 2) Connections 16 Selecting a Source 25 Setting The Speaker Distance Delays 23 Setup Codes 36 SLEEP 30 SLEEP TIME SET 30 SPEAKER CONFIG (Speaker Configuration) 20 Speaker Placement 20 Speaker Type (SMALL/LARGE) 21 Specifications 38 Standby 8 Station Presets 27 SURR DISTANCE (Surround) 23 Surround Data Format Lock 26 Surround Format 6 Surround Mode 26 SYSTEM CONFIG (System Configuration) 22 System Reset 35

T.MODE 10 TEST 22 Test Tone Function 22 THEATER COMPEN (Theater Compensation) 28 Trim 28 Troubleshooting 35 Tune Down 26 Tune Up 26 Tuner Operation 26 Turning OFF the Unit 25 Turning ON the Unit 25

Unpacking 6

VFD BRIGHTNESS 29 Volume Control 25

XOVER (Crossover) 21

Zone 24

Notes

Service Policy and Limited Warranty

Rockford Corporation (Fosgate Audionics Division) offers a limited warranty on Fosgate Audionics products on the following terms:

•Length of Warranty

Five (5) years

•What is Covered

This warranty applies only to products sold to the original owner and is non-transferable. This warranty only applies to units sold in the continental United States. A copy of the receipt is required stating the customer’s name, dealer name, product purchased and date of purchase.

•Products Found to be Defective During the Warranty Period

Defective products will be repaired or replaced (with product deemed to be equivalent) at Fosgate Audionics’ discretion.

•What is NOT Covered

1. Damage caused by accident, abuse, improper operations, water, theft

2. Service performed by anyone other than Fosgate Audionics or an Authorized Fosgate Audionics service center

3. Any product purchased outside the United States (please contact your local dealer)

4. Shipping charges to get the unit to Fosgate Audionics

5. Subsequent damage to other components

6. Any product which has had the serial number defaced, altered, or removed

•Limit on Implied Warranties

Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the period of the express warranty set forth above. Some states do not allow limitations on the length of an implied warranty, so this limitation may not apply. No person is authorized to assume for Fosgate Audionics any other liability in connection with the sale of the product.

•How to Obtain Service or Technical Support

Please call 1-866-888-4404 for Rockford/Fosgate Audionics support. You must obtain an RA # (return authorization number) to return any products to Fosgate Audionics. You are responsible for shipment of product to Fosgate Audionics.

Technical Repair

Rockford Corporation Fosgate Audionics Division 2055 E. 5th Street Tempe, Arizona 85281

04/03 BM

MAN-4559-B

546 SOUTH ROCKFORD DRIVE

TEMPE, ARIZONA 85281 U.S.A.

1-866-777-7282

Printed in U.S.A.

A Division of Rockford Corporation

Fosgate Audionics FAP T1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
