UV-4 Flame Detector
e Forney UV-4 is an ultraviolet detector
head utilizing remote amplification with
advanced signal processing capabilities for
gas or light oil flames.
Features & Benefits
Ult ra viole t Se nSit ive
•
Detects flames produced by the combustion
of gas or light oil.
Se lf-chec king electr onicS
•
Provides automatic system diagnostics to
enhance operational safety.
fiber op ti c con nect ionS
•
Base configurations are available for tilting
burner designs.
neMa 4 r ated hoUSin g
•
e rugged yet light weight housing
provides the protection necessary to
withstand a burner front environment.
Si Mplif ied inS tall at ion and
•
Mai nten ance
Product Overview
e UV-4 is exceptional at sensing ultraviolet radiation that is emitted
from the combustion of gas or light oil. e spectral radiation of these fuels
in the ultraviolet range is significantly greater than other fuels, and allows the
UV-4 to positively sense and discriminate a targeted flame. e UV-4 can be
applied to both wall-fired and tilting-tangential type burners. e UV-4 is used
in conjunction with the Forney IDD 9000 or DR-6101E Amplifier and is
connected by a four conductor, shielded prefabricated cable.
e UV-4 assembly is available with two different base configurations:
“front mount” for wall burners and “fiber optic mount” for tilting type burners
or where special sighting is required. e UV-4 is self checking for use as a main
flame detector or Class 1 or 2 igniter detector. e UV-4 uses a high quality
photoionization tube sensor with a rugged aluminum mechanical shutter.
Quick disconnects available for ease of
replacement.
fact ory MUt Ual app ro ved
•
Factory Mutual (FM) approval means safe
operation and lower insurance rates.
Forney Corporation • 3405 Wiley Post Road • Carrollton, TX 75006 • 800-356-7740 • Fax 972-458-6650 • www.forneycorp.com
Page 2
UV-4 DETECTOR
1" FNPT COOLING
AIR CONNECTION
SIGHT TUBE
5.25
8.09
3.5"
4.0"
UV FLAME DETEC TOR
MODEL UV-4
B-379189-02
UV-4 Flame Detector
Pub # 404005-17
Rev 01/2011
Products and Accessories:
UV-4 Detector Part #37918902
UV-4 Base (Front Mount w/lens) Part #37900901
UV-4 Base (Fiber-optic Mount) Part #37850301
Isolation Valve & Wye Part #35275001
Four Conductor Cable (40 feet) Part #37997205
Specications:
Mounting: 1” FNPT
Material: Die cast aluminum housing with matte black, anti-slip nish
Electrical: 15 VDC (supplied by the amplier)
Electrical Connections: MS Bayonet Connector supplied with cable, 1/2” exible conduit
required
Temperature Ratings: 32°F to 140°F (0°C to 60°C)
Humidity: 0-95% relative humidity, non-condensing
Cooling Air: 10 SCFM
Cooling Air Connection: 1” FNPT
Weight: 4 lbs 6 oz
Check Cycle: Once every two minutes
Sensor/Wave Length: UV photoionization tube, 190-260 nm
Approvals: Factory Mutual (FM)
