Grey Pro
Photoreactive Resin for Form 2
SAFETY DATA SHEET
Prepared: 12/12/2017
GHS-Labelling
Hazard pictograms:
Signal word: Warning
GHS FORMAT
1. Chemical Product and Company Identification
Product Identification: Photoreactive Resin
Product Class: Mixture of methacrylic acid esters, photoinitiators, proprietary pigment and additive package
Product Use: For use in Formlabs printer Form 2
Company: Formlabs, Inc.
35 Medford Street, Suite #201
Somerville, MA
Date of Preparation: 11/18/2016
For Emergencies: North America call +1 800 255 3924
Worldwide Intl. call +01 813 248 0585
Reference Contract Number MIS4707563
2. Hazards Identification in Accordance with EC 1272/2008
EMERGENCY OVERVIEW
COLOR: GREY
PHYSICAL STATE: LIQUID
ODOR: LIGHT ACRYLIC
* Classification of the substance or mixture:
Skin irritation, Category 2
Eye irritation, Category 2B
Skin sensitization, Category 1
Target organ systemic toxicity: Respiratory irritation, Single Exposure, Category 3
Chronic aquatic toxicity, Category 3
GHS LABELLING
Hazard pictograms:
SIGNAL WORD: WARNING
HAZARD STATEMENTS
H315 Causes skin irritation
H319 Causes serious eye irritation
H317 May cause an allergic skin reaction
H335 May cause respiratory irritation
H412 Harmful to aquatic life with long lasting eects
PRECAUTIONARY STATEMENT(S)
Prevention:
P261 Avoid breathing gas/mist/vapors/spray
P264 Wash skin thoroughly after handling
P272 Contaminated work clothing should not be allowed out of the workplace
P273 Avoid release into the environment
P280 Wear protective gloves/protective clothing/eye protection/face protection
FORMLABS SDS — GREY PRO: Photoreactive Resin for Form 2 2
Response:
P302 + P352: IF ON SKIN (or hair) : Wash with plenty of soap and water
P305 + P351 + P338: IF IN EYES : Rinse cautiously with water for several minutes. Remove contact lenses, if present and easy
to do. Continue rinsing.
P310: IF SWALLOWED : Immediately call a POISON CENTER or doctor/physician
P333 + P313 : If skin irritation or rash occurs: Get medical advice/attention
P362 : Take o contaminated clothing and wash before reuse
P391 : Collect spillage
SUPPLEMENTAL HEALTH INFORMATION
Potential Health Eects:
Eects due to processing releases:
Irritating to eyes, respiratory system and skin. Prolonged or repeated exposure may cause: headache, drowsiness, nausea,
weakness (severity of eects depends on extent of exposure).
Other:
This product may release fume and/or vapor of variable composition depending on processing time and temperature. Possible
cross sensitization with other acrylates and methacrylates.
3. Composition/Information on Ingredient
Components Approximate
% by weight
A. Methacrylated oligomers Proprietary Proprietary H315, H319, H335
B. Methacrylated monomer Proprietary Proprietary H315, H317, H319, H412
C. Photoinitiator(s) Proprietary Proprietary H317, H411
D. Pigments < 0.5 Proprietary
E. Specialty Additives < 1.5 Proprietary
C.A.S. No. &
EINECS No.
Hazard Statements in accordance with EC 1272/2008
UK/EU Classification according
to Directive 67/548/EEC
Xi; Irritant, R36/37/38, R43
S3, S7/9, S20, S26, S29, S37/39
Xi; Irritant, R36, R43
S3, S7/9, S20, S26, S29, S37/39
4. First-Aid Measures
Emergency Overview: This product is a grey colored liquid with a characteristic odor. This product may cause skin and eye
irritation. The inhalation of high vapor concentration may cause a headache and nausea.
Inhalation: In case of exposure to a high concentration of vapor or mist, remove person to fresh air. If breathing has stopped,
administer artificial respiration and seek medical attention.
Eye Contact: Immediately flush with plenty of clean water (under eye lids) for at least 20 minutes. Hold eyelids apart to ensure
flushing. Washing within one minute of contact is essential to achieve maximum eectiveness. Seek medical attention immediately.
Do not apply oil or oily ointments unless ordered by a physician.
Skin Contact: Remove contaminated clothing and rinse contact area thoroughly with soap and water. Particular attention
should be paid to hair, nose, and ears, and other areas not easily cleaned. Wash clothing before reuse. If irritation develops,
consult a physician.
Ingestion: If ingested, dilute with water by giving glasses of water or milk to the victim. Do not give anything by mouth if the
victim is rapidly losing consciousness, is unconscious, or convulsing. Do not induce vomiting. If vomiting occurs naturally, keep
airways clear. Get medical attention. Provide an estimate of the time at which the material was ingested and the amount of the
substance that was swallowed.
FORMLABS SDS — GREY PRO: Photoreactive Resin for Form 2 3
5. Fire-Fighting Measures
Flash Point: > 93 °C / 200 °F
Method: Setaflash
Ignition Temperature: No data
Lower Explosion Limit: No data
Upper Explosion Limit: No data
Extinguishing Media: Use carbon dioxide or dry chemical for small fires; aqueous foam or water spray for large fires.
Special Firefighting Procedures: Firefighters should wear full protection clothing and self-contained breathing apparatus
(SCBA). Thoroughly decontaminate firefighting equipment including all firefighting apparel after the incident.
Unusual Fire & Explosion: Emits irritating vapors. High temperatures, accidental impurities, or exposure to radiation
or oxidizers may cause spontaneous polymerization generating heat/pressure and rupture/explosion of closed containers.
Exposure Hazard(s): Material — Irritant
6. Accidental Release Measures
Procedures of Personal Precautions: Wear adequate personal protective clothing and equipment, as outlined in Section 8.
Environmental Precautions: Contain spill to prevent spread into drains, sewers, water supplies, or soil. Avoid release into the
environment. Dispose of in accordance with all applicable federal, state and local regulations.
Methods of Cleaning Up: In the event of a spill, immediately remove all sources of ignition. Cover the liquid with inert absorbent.
Using appropriate personal protective equipment and non-sparking tools, contain spilled material.
Waste Disposal Method: Do not dispose of in sewers, lakes, rivers or streams. Scoop all contaminated material into compatible
bottles or drums for proper disposal. Dispose of in accordance with all applicable federal, state and local regulations. National
or regional provisions may also be in force.
7. Handling and Storage
Handling Precautions: User Exposure — This product should be used in well-ventilated areas. Product may cause irritation.
Avoid contact with eyes. Avoid prolonged or repeated contact with skin. Wash hands with soap and water before eating, drinking,
smoking, applying cosmetics, or using toilet facilities. Launder contaminated clothing before reuse. Contaminated leather articles,
including shoes, cannot be decontaminated and should be destroyed to prevent reuse. Solvents should never be used to clean
hands or skin because they increase the penetration of the material into skin.
Storage Precautions: Suitable — Store in a cool, dry place out of direct sun light, in opaque or amber containers. Store the containers
at 10-35°C (50-95°F). Do not exceed 60°C (140°F) when in storage. Keep containers closed. Avoid ignition sources.
Special Requirements: Do not heat containers with steam or electrical equipment. Heating this product above 150 °C (300 °F) in
the presence of air may cause slow oxidative decomposition; above 260 °C (500 °F) polymerization may occur. Fumes and vapors
from this thermal decomposition may be dangerous (nitrous vapors, carbon monoxide, carbon dioxide). Do not breathe fumes.
8. Exposure Controls & Personal Protection
EXPOSURE LIMITS
Component HSIS Australia IOELVs (UK) ACGIH TLV OSHA PEL WEEL
1. Methacrylated oligomer None None None None None
2. Methacrylated monomer None None None None None
3. Photoinitiator(s) None None None None None
4. Specialty Additives None None None None None
No occupational exposure limit values exist for the materials contained in this product.
FORMLABS SDS — GREY PRO: Photoreactive Resin for Form 2 4
NOTATIONS
IOELVs — Indicative Occupational Exposure Limit Values
TWA — Time Weighted Average
OEL — Occupational Exposure Limits
PEL — Permissible Exposure Limit
TLV — Threshold Limit Value
STEL — Short Term Exposure Limit
WEEL — Workplace Environmental Exposure Level by the American Industrial Hygiene Association
EXPOSURE CONTROLS
Ventilation Controls: Ensure adequate ventilation.
Respiratory Protection: Respirators are generally not needed under normal conditions of use. If this material is handled at
elevated temperature, under mist forming conditions or in case of accidental release of large quantities of product use a fullface respirator with multi-purpose combination (US) or type ABEK (EN 14387) respirator cartridges as a backup to engineering
controls. Use respirators and components tested and approved under appropriate government standards such as NIOSH (US)
or CEN (EU).
Protective Gloves: Wear impervious gloves (nitrile or neoprene) for routine handling.
Eye and Face Protection: Chemical splash goggles or a face shield is recommended during operations where splashing could occur.
Skin Protection: Avoid all skin contact. Depending on the conditions of use, cover as much of the exposed skin area as possible
by wearing gloves, aprons, long pants, and long sleeved shirts.
Other Controls: For operations where contact can occur a safety shower and eye wash facility should be available. Always use
good personal hygiene and housekeeping practices. Wash hands thoroughly after handling.
Environmental Exposure Controls: Keep product from waterways and watersheds. This substance is not readily biodegradable
and is dangerous for the environment. Avoid release into the environment.
9. Physical & Chemical Properties
Appearance: Liquid, grey color
Odor: Light/Characteristic/Acrylate
Value Unit Method
Specific Gravity 1.09 –1.12 g/cm³
Boiling Point > 100 °C
Flash Point > 100 °C
Ignition Temperature no data
Lower Explosion Limit no data
Upper Explosion Limit no data
Viscosity 1700 - 1750 cps @ 25 °C (77 °F)
Vapour Pressure: Not established
Solubility in Water: Only very slightly soluble
Solubility in Organic Solvents: Soluble in organic solvents
Volatile Characteristics: Negligible
Electrostatic Discharge: Safe
Electric Conductivity: Dielectric
FORMLABS SDS — GREY PRO: Photoreactive Resin for Form 2 5
10. Stability and Reactivity
Stability: Stable when stored in original container designed for use with light sensitive materials under 35 °C (95 °F) in dark, cool place.
Conditions to Avoid: Storage > 38 °C (100 °F), exposure to light, loss of dissolved air, and contamination with incompatible materials.
Incompatible Materials to Avoid: Polymerization initiators, including peroxides, strong oxidizing agents, alcohols, copper, copper
alloys, carbon steel, iron, rust, and strong bases.
Hazardous Decomposition Products: Hazardous decomposition products may include oxides of carbon, nitrogen and various
hydrocarbon fragments.
Hazardous Polymerization: Hazardous polymerization may occur. Uncontrolled polymerization may cause rapid evolution of
heat and increase in pressure that could result in violent rupture of sealed storage vessels or containers.
11. Toxicological Information
A. Methacrylated oligomers No data available. Not tested on animals to obtain numerical data.
B. Methacrylated monomer Acute Oral Toxicity (rat) LD50 > 2000 mg/kg body weight (vendor literature)
Acute Dermal toxicity (rabbit) LD50 > 3000 mg/kg body weight (vendor literature)
C. Photoinitiator(s) Acute Oral Toxicity (rat) LD50 > 2000 mg/kg body weight (vendor literature)
Acute Dermal Toxicity LD50 > 2000 mg/kg body weight (vendor literature)
D. Specialty additives No data available
Individual components of this product are not reported to produce mutagenic eects in humans. None of the components of
this material are listed by IARC, NTP, OSHA or ACGIH as carcinogens.
12. Ecological Information
Keep product from waterways and watersheds. This substance is not readily biodegradable. Dispose of in accordance with all
applicable federal, state and local regulations.
A. Methacrylated oligomers No data available
B. Methacrylated monomer May be harmful to various species of fish, algae and water microorganisms
C. Photoinitiator(s) May be harmful to various species of fish, algae and water microorganisms
D. Specialty additives No data available
13. Disposal Considerations
Dispose of in accordance with governmental regulations (community, national or regional). Contact a licensed professional
waste disposal service to dispose of this mixture. As with all foreign substances, do not allow to enter storm or sewer drainage
systems. Avoid release into the environment.
Contaminated Packaging: Dispose of as unused product. Expose the open emptied container to light until material has solidifed,
then dispose.
FORMLABS SDS — GREY PRO: Photoreactive Resin for Form 2 6
14. Transport Information
Department of transportation classification: Not hazardous by D.O.T. regulations
D.O.T. proper shipping name: Not regulated
International Maritime Dangerous Goods Code (IMDG): not regulated
International Air Transportation Association (IATA): not regulated
Other requirements: N/A
Australian HazChem Code: N/A
15. Regulatory Information
EUROPEAN ECONOMIC COMMUNITY (EEC) CANADA REGS
Ingredient EPA*
TSCA
A. Methacrylated
oligomers
B. Methacrylated
monomer
C. Photoinitiator(s) Ye s No Ye s None No H317, H411 Ye s No
D. Specialty
additives
All the components present in this product at concentrations equal to or greater than 0.1% are listed, or excluded from listing,
on the United States Environmental Protection Agency Toxic Substances Control Act (TSCA) inventory.
Substance Preparation Classification:
Irritant
The following provides a summary of the legal requirements.
Ye s No Ye s None No H319, H335 Yes Ye s
Ye s No Ye s None No
Ye s No Ye s None No No
EINECS European
CA
Prop
65
Community
Standards
Listed as dangerous
chemicals per ESIS
EC 1272/2008 DSL NDSL
GHS07, Wng
H315, H317,
H319, H412
Ye s Ye s
FULL TEXT OF ANY R-PHRASES AND S-PHRASES:
Risk Phrases:
R36/37/38 — Irritating to eyes, respiratory system and skin
R43 — May cause sensitization by skin contact
Safety Phrases:
S3 — Keep in a cool place
S7/9 — Keep container
S20 — When using do not eat or drink
S26 — In case of contact with eyes, rinse immediately with plenty of water and seek medical advice
S29 — Do not empty into drains
S36 — Wear suitable protective clothing
S37/39 — Wear suitable gloves and eye/face protection
SARA 302: No chemicals in this material are subject to the reporting requirements of SARA Title III, Section 302.
Pursuant to Title III of the Superfund Amendments and Reauthorization Act of 1986, (SARA) and 40 CFR 372 Part 372, this product
does not contain chemicals subject to the reporting requirements under Section 313.
California Proposition 65: This product does not contain chemicals which are known to the state of California to cause cancer.
FORMLABS SDS — GREY PRO: Photoreactive Resin for Form 2 7
16. Other Information
HMIS (Hazardous Materials Information System) for secondary labelling:
HEALTH 2
FIRE HAZARD 1
REACTIVITY 1
PERSONAL PROTECTIVE EQUIPMENT D
REFERENCES:
1. 2011 Threshold Limit Values and Biological Exposure Indices. American Conference of Governmental Industrial Hygienists.
2. MSDS + Cheminfo CD-ROM, Canadian Centre for Occupational Health and Safety
3. SAX’S Dangerous Properties of Industrial Materials, Tenth Edition
4. TSCA & SARA Title III, U.S. Environmental Protection Agency and the National Technical Information Services
5. Raw Material Manufacturers Material Safety Data Sheets
6. US National Institute of Medicines Toxnet current edition
7. ESIS: European Chemical Substance Information System, http://ecb.jrc.it/esis
8. NOHSC Hazardous Information Substances Information System, Department of Employment and Workplace Relations,
Australian Government, 2005
To the best of our knowledge the information contained herein is accurate. However, Formlabs, Inc. makes no warranty, expressed
or implied, regarding the accuracy of these results to be obtained from the use thereof. Although certain hazards are described
herein, we cannot guarantee that these are the only hazards that exist. Formlabs, Inc. assumes no responsibility for injury from the
use of the product described herein.
FORMLABS SDS — GREY PRO: Photoreactive Resin for Form 2 8
Loading...
