Totally Waterproof.……. it even Floats!

The Miccus eXtreme SPX7 is an extreme climate, floating, waterproof, full range 3W x 2 wireless speaker
system with built-in rechargeable battery. Stream & Play your music from your Bluetooth enabled devices
such as Smartphone, Tablet, Laptop or transmitter such as the Miccus mini-jack TX. Take and make
phone calls thanks to the built-in microphone. The design and floatation of the speaker will keep it positio­ned upright when floating so you can enjoy your music in the pool, bath or lake. Clip on your bike, back­pack or other gear and you have portable all weather music.

Contents of the Package:

● Miccus® eXtreme SPX7

● USB Charging cable

● USB to AC Wall Adapter

● Bike Mount

● Suction Mount

● User Manual

*If items are missing or damaged please email us directly at [e-mail]

Quick Start (pairing):

Getting Acquainted:

Power on: Press and hold Power ON/OFF button for 4 seconds; two short beeps will indicate the SPX7 is
powered on.

1. The SPX Speaker will automatically enter pairing mode and begin searching for other Bluetooth
wireless enabled devices.

2. In the Bluetooth settings of your Smartphone, tablet, or media player switch Bluetooth ON and
select the option to “Search for Devices”.

3. Find & select (tap) “Miccus SPX7” on your Smartphone/Tablet to complete a successful pairing.
(If prompted for a passcode use 0000.)

4. Once the pairing is complete and the Bluetooth connection made you will hear a “beep” tone from
the speaker.

5. Now navigate to your music player or music app, press play and enjoy your music wirelessly.

6. For reconnection ensure Bluetooth is enabled and then press the Multi-function button to power
the speaker on and it will look for the last paired device first.

Note:

If you are using a Bluetooth transmitter such as the Miccus Mini-jack TX then put them both into pairing
mode and set them next to each other, they will automatically negotiate and connect.

(1) MULTI-FUNCTION BUTTON: Power On/Off, Play/Pause & Answer calls
Power On: Press and hold button approx. 4 seconds; 2 short beeps indicate unit is powered on.
Power Off: Press and hold button approx. 4 seconds; red LED will turn off indicating the unit is
powered off.
Play or Pause: While music is playing, quickly press and release button to pause playback. Press
button again to resume playback.
Answer Call: Press to answer incoming calls press again to hang up; the SPX7 features built in
microphone with hands free technology for phone calls.

(2) DUAL FUNCTION BUTTON: (+)
Volume Increase (+): Press and hold (+) to increase the Volume level; 2 short beeps sound when
maximum volume reached.
Next Track (+): Quickly press & release to select next track.

(3) DUAL FUNCTION BUTTON: (-) - Volume Decrease (-): Press and hold (-) to increase the Volume
level; 2 short beeps sound when minimum volume reached.
Previous Track (-): Quickly press & release to select previous track.

The speaker performance and sound may vary when wet.

**For optimal performance the battery should be fully charged before first use.

1 2

(4) MICROPHONE: Locate the built in microphone on the top left side of the unit. While making use of
the extreme SPX’s speaker phone feature, it’s best to speak within 50cm (20”) of the Microphone
during call

(5) INDICATOR LED:
Charging: Red LED is lit; LED turns off when charging is complete.
Pairing: Blue LED is flashing; the unit is powered on and in pairing mode. When successfully
paired Blue LED stops flashing and stays lit.

CAP & USB CHARGING CONNECTION:

Rubber gasket Ring Micro USB Charging Socket

Top of the unit Protective Cap

The Micro USB charging port is located under the Protective Cap. Unscrew the Protective Cap in a counter
clockwise motion to gain access.

Warning:

How to use the Bike Mount Kit:

If the Protective Cap is off or loosely secured then the speaker is NOT watertight and can cause damage to
the speaker. To maintain a watertight seal, make sure the Protective Cap is attached firmly to the top of the
speaker

Charging the Battery

The built-in Lithium Ion battery uses the included USB cable to recharge; for optimal charging connect the
USB cable to your computer or any USB wall or car adapter that outputs a minimum of 5V @1Amp or
higher. The red LED will be solid during charging and turn off when charging is complete. Playtime lasts up
to 5 hours on a full charge. When battery energy is low, a voice will indicate “Battery Low” with 30 minutes
of approximate playtime remaining.

BACK OF UNIT

Speaker Mount Bike Handlebar Mount
(Fig. 2A) (Fig. 2B) (Fig. 2C)

To remove the mounting hole cover (Fig. 1B), unscrew it from the speaker using a counter clockwise
motion.

Once the cover is removed take the Speaker Mount (Fig. 2A) and twist it 90 degrees in a clockwise
motion into the accessories mounting hole (Fig. 1A)

To attach the Bike Handlebar mount (Fig. 2B) to your bicycle, remove the mount screw with a No.2
philips screw driver. Open the Bike Mount and position on your handlebars keeping in mind the overall
size of the speaker. Re-insert the mount screw and tighten until firm (Fig.2C). Once secured the Handle­bar Mount should not rotate or move on the handlebars..

Next take the speaker and slide the open end of the Speaker Mount (Fig. 2A) onto the Bike Handlebar
Mount (Fig. 2B). Push the speaker mount all the way until it clicks securely into place. To remove the
speaker from the Bike Mount press the button on the Bike Mount and slide the speaker off.

How to use the Shower Mount Kit:

Accessories Mounting Hole Mounting Hole Cover
(Fig. 1A) (Fig. 1B)

3

Shower Mount
(Fig. 3A) (Fig. 3B) (Fig. 3C) (Fig. 3D)
