FEATURES
•All brass conforms to AWWAStandard C800 (ASTM B-62, UNS NO C83600 - 85-5-5-5)
• Valve is non-directional and is water tight with flow in either direction.
• Ends are integral or secured with adhesive to prevent unintentional disassembly.
• Hole for attaching curb box rod or handle is provided in Tee Head.
• 300 PSI working pressure.
Optional Padlock Wing for locking valve in closed position. Insert “W” into Part Number.
Optional Full 360° Tee Head Rotation. Insert “R” into of Part Number.
QUICK JOINT FOR COPPER OR PLASTIC TUBING (CTS) INLET BY FEMALE IRON PIPE THREAD OUTLET
Inlet
Length
APPROX
.PART
✓ SUBMITTED
VALVE SIZE INLET SIZE OUTLET SIZE LENGTH
WT. LBS NUMBER ITEM(S)
3/4" 3/4" 3/4" 2-5/8" 2.0 B41-333 -Q
3/4" 1? 3/4" 4-1/8" - B41-343 -Q
3/4" 1" 1" 2-23/32" 2.4 B41-344 -Q
3/4" 1" 1" 4-7/8" - BL41-344 -4.875-Q
1" 1" 1" 3-1/8" 2.8 B41-444 -Q
1-1/2" 1-1/2" 1-1/2" 5-7/8" - B41-666 -Q
2" 2" 2" 6-5/16" - B41-777 -Q
Ford recommends Insert Stiffeners when using plastic pipe or tubing.
Solid one piece tee-head and stem.
Sturdy stops allow 90° motion and
are enclosed and protected.
A restraining ring locks the
stem into the body of the valve.
EPDM O-rings in the stem.
Molded Buna-N rubber
seats support the ball.
Spherical fluorocarboncoated brass ball.
Outlet
The Ford Meter Box Company, Inc.
P.O. Box 443, Wabash, Indiana U.S.A. 46992-0443
Phone: 260-563-3171 / Fax: 800-826-3487
Overseas Fax: 260-563-0167
http://www.fordmeterbox.com
Submitted By:
The Ford Meter Box Company considers the information in this submittal form to be correct at the time of publication. Item and option availability,
including specifications, are subject to change without notice. Please verify that your product information is current.
09/15/00
External Nut Stop.
Stainless Steel Gripper
Ball Valve Curb Stop - (B41-xxx-Q style)
SUBMITTAL INFORMATION
Optional Padlock Wing for
locking valve in closed position
Quick Joint Nut
Female Iron Pipe Outlet
Molded Buna-N
Spring Tip Gasket
Provides Hydraulic Seal
