Ford Super Duty (2022) Owner's Manual

2022 SUPER DUTY Owner’s Manual

2022 SUPER DUTY Owner’s Manual

owner.ford.com

ford.ca

April 2021

First Printing

Litho in U.S.A.

NC3J 19A321 AA

The information contained in this publication was correct at the time of going to print. In the interest of
continuous development, we reserve the right to change specifications, design or equipment at any time
without notice or obligation. No part of this publication may be reproduced, transmitted, stored in a
retrieval system or translated into any language in any form by any means without our written permission.
Errors and omissions excepted.

© Ford Motor Company 2021

All rights reserved.

Part Number: 202103 20210330115440

California Proposition 65

WARNING: Operating, servicing and

maintaining a passenger vehicle or off-highway
motor vehicle can expose you to chemicals
including engine exhaust, carbon monoxide,
phthalates, and lead, which are known to the
State of California to cause cancer and birth
defects or other reproductive harm. To minimize
exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle
in a well-ventilated area and wear gloves or wash
your hands frequently when servicing your vehicle.
For more information go to
www.P65Warnings.ca.gov/passenger-vehicle.

WARNING: Battery posts, terminals and
related accessories contain lead and lead
compounds, chemicals known to the State of
California to cause cancer and reproductive harm.

Wash your hands after handling.

Contacting Us

Contacting Us ..................................................17

Introduction

About This Publication ................................19

Using This Publication ................................20

Symbols Glossary

Symbols Used on Your Vehicle .................21

Data Privacy

Data Privacy ....................................................24

Service Data ....................................................25

Event Data .......................................................25

Settings Data ..................................................26

Connected Vehicle Data .............................26

Mobile Device Data - Vehicles With:

SYNC 3 ...........................................................27

Mobile Device Data - Vehicles With:

SYNC 4 ..........................................................27

Emergency Call System Data ...................28

Visual Search

Steering Wheel - Vehicles With: SYNC 4

..........................................................................29

Steering Wheel - Vehicles With: SYNC 3

..........................................................................30

Instrument Panel ............................................31

Vehicle Interior ................................................32

Front Exterior ..................................................33

Rear Exterior ....................................................34

Child Safety

Child Safety Precautions ............................35

Child Restraint Anchor Points ..................36

Child Restraints ..............................................38

Installing Child Restraints ..........................39

Booster Seats .................................................46

Child Safety Locks ........................................48

Seatbelts

Seatbelt Precautions ...................................49

Fastening and Unfastening the Seatbelts

..........................................................................50

Sensitive Locking Mode ...............................51

Automatic Locking Mode ............................51

Adjusting the Seatbelts During

Pregnancy ....................................................52

Adjusting the Seatbelt Height ..................52

Adjusting the Seatbelt Length .................53

Seatbelt Reminder ........................................53

Checking the Seatbelts ...............................55

Seatbelt Extensions .....................................56

Airbags

How Do the Front Airbags Work ..............57

How Do the Side Airbags Work ................57

How Does the Safety Canopy™ Work

..........................................................................58

Airbag Precautions .......................................59

Switching the Passenger Airbag On and

Off ..................................................................60

Properly Adjusting the Driver and Front

Passenger Seats .......................................64

Children and Airbags ...................................64

Crash Sensors and Airbag Indicator ......65

Disposing of Airbags ....................................66

911 Assist

What Is 911 Assist ..........................................67

How Does 911 Assist Work .........................67

Emergency Call Requirements .................67

Emergency Call Limitations ......................68

Keys and Remote Controls

Remote Control Limitations .....................69

Using the Remote Control .........................69

Opening and Closing the Flip Key ..........69

Removing the Key Blade ............................70

Sounding the Panic Alarm .........................70

1

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Locating Your Vehicle ..................................70

Changing the Remote Control Battery

............................................................................71

Changing the Remote Control Battery -

Vehicles With: Flip Key .............................72

Replacing a Lost Key or Remote Control

...........................................................................73

Programming the Remote Control .........74

Programming the Remote Control -

Vehicles With: Flip Key ............................75

Keys and Remote Controls –

Troubleshooting ........................................76

MyKey™

What Is MyKey .................................................77

MyKey Settings ...............................................77

Creating a MyKey ...........................................78

Creating a MyKey - Vehicles With: Flip

Key ..................................................................79

Programming a MyKey ................................79

Clearing All MyKeys ......................................79

Checking MyKey System Status .............80

Using MyKey With Remote Start

Systems .......................................................80

MyKey – Troubleshooting ..........................80

Doors and Locks

Operating the Doors From Outside Your

Vehicle ...........................................................83

Operating the Doors From Inside Your

Vehicle ...........................................................83

Autounlock ......................................................84

Autolock ...........................................................84

Mislock ..............................................................84

Doors and Locks Audible Warnings .......84

Doors and Locks – Troubleshooting

..........................................................................85

Keyless Entry

Keyless Entry Limitations ...........................87

Keyless Entry Settings .................................87

Using Keyless Entry ......................................87

Keyless Entry – Troubleshooting ............88

Keyless Entry Keypad

What Is the Keyless Entry Keypad ..........89

Keyless Entry Keypad Limitations ..........89

Locating the Keyless Entry Keypad ........89

Keyless Entry Keypad Master Access

Code ..............................................................89

Keyless Entry Keypad Personal Access

Codes ............................................................90

Using the Keyless Entry Keypad ...............91

Keyless Entry Keypad – Troubleshooting

...........................................................................91

Easy Entry and Exit

How Does Easy Entry and Exit Work

..........................................................................93

Switching Easy Entry and Exit On and

Off ...................................................................93

Tailgate - Vehicles With:

Manual Tailgate

Tailgate Precautions ....................................94

Opening the Tailgate ...................................94

Locking and Unlocking the Tailgate .......94

Removing and Installing the Tailgate

..........................................................................94

Tailgate Step ...................................................95

Bed Extender ..................................................96

Tailgate - Vehicles With:

Remote Release Tailgate

Tailgate Precautions ....................................99

Opening the Tailgate ...................................99

Removing and Installing the Tailgate

..........................................................................99

Tailgate Step .................................................100

Bed Extender ..................................................101

Tailgate – Troubleshooting .....................104

2

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Security

Passive Anti-Theft System ......................106

Anti-Theft Alarm System ........................106

Anti-Theft Alarm System Settings .......107

Security – Troubleshooting .....................108

Power Running Boards

Power Running Board Precautions ........110

Power Running Board Settings ...............110

Deploying and Stowing the Power

Running Boards ........................................110

Power Running Boards –

Troubleshooting .......................................110

Steering Wheel

Adjusting the Steering Wheel - Vehicles

With: Power Adjustable Steering

Column ..........................................................111

Adjusting the Steering Wheel - Vehicles

With: Manual Adjustable Steering

Column .........................................................112

Resetting the Stopping Position -

Vehicles With: Power Adjustable

Steering Column .......................................112

Horn ...................................................................112

Switching the Heated Steering Wheel

On and Off ...................................................112

Adjustable Pedals

Adjusting the Pedals ...................................114

Wipers and Washers

Wipers ...............................................................115

Autowipers ......................................................115

Checking the Wiper Blades ......................116

Replacing the Front Wiper Blades .........116

Washers ...........................................................116

Wipers and Washers – Troubleshooting

..........................................................................117

Exterior Lighting

Exterior Lighting Control ............................118

Headlamps .....................................................118

Headlamps – Troubleshooting ...............118

Autolamps ......................................................119

Exterior Lamps ..............................................119

Automatic High Beam Control ................121

Automatic High Beam Control –

Troubleshooting .......................................123

Interior Lighting

Switching All of the Interior Lamps On

and Off ........................................................124

Switching the Front Interior Lamps On

and Off ........................................................124

Switching the Rear Interior Lamps On

and Off ........................................................124

Interior Lamp Function ..............................124

Adjusting the Instrument Panel Lighting

Brightness ...................................................125

Ambient Lighting .........................................125

Interior Lighting – Troubleshooting ......125

Windows

Opening and Closing the Windows ......126

Window Bounce-Back ...............................126

Locking the Rear Window Controls .......127

Opening and Closing the Sliding

Windows .....................................................127

Interior Mirror

Interior Mirror Precautions .......................128

Manually Dimming the Interior Mirror

.........................................................................128

Auto-Dimming Interior Mirror ..................128

Exterior Mirrors

Adjusting the Exterior Mirrors ..................129

Folding the Exterior Mirrors - Vehicles

With: Manual Folding Mirrors ..............129

Folding the Exterior Mirrors - Vehicles

With: Power Folding Mirrors ................129

Extending the Exterior Mirrors ................130

Auto-Dimming Exterior Mirror ................130

3

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Moonroof

Opening and Closing the Sun Shade

..........................................................................131

Opening and Closing the Moonroof ......131

Venting the Moonroof .................................131

Moonroof Bounce-Back ............................132

Instrument Cluster

Instrument Cluster Overview - Vehicles

With: 2.3 Inch Screen ..............................133

Instrument Cluster Overview - Vehicles

With: 4.2 Inch Screen .............................134

Instrument Cluster Overview - Vehicles

With: 8 Inch Screen .................................135

What Is the Tachometer ...........................135

What Is the Speedometer ........................135

Fuel Gauge .....................................................136

What Is the Engine Coolant Temperature

Gauge ...........................................................136

What Is the Engine Oil Pressure Gauge

.........................................................................136

What Is the Transmission Fluid

Temperature Gauge ...............................136

What Is the Turbo Boost Gauge .............136

What Is the Diesel Exhaust Fluid Gauge

.........................................................................136

What Are the Instrument Cluster

Warning Lamps ........................................137

Instrument Cluster Warning Lamps ......137

What Are the Instrument Cluster

Indicators ....................................................138

Instrument Cluster Indicators .................138

Instrument Cluster Display

Using the Instrument Cluster Display

Controls ........................................................141

Instrument Cluster Display Main Menu -

Vehicles With: 2.3 Inch Screen ............141

Instrument Cluster Display Main Menu -

Vehicles With: 4.2 Inch Screen ............141

Instrument Cluster Display Main Menu -

Vehicles With: 8 Inch Screen ...............142

Customizing the Instrument Cluster

Display - Vehicles With: 8 Inch Screen

.........................................................................142

Personalized Settings ................................142

Trip Computer

Accessing the Trip Computer - Vehicles

With: 2.3 Inch Screen .............................145

Accessing the Trip Computer - Vehicles

With: 4.2 Inch Screen .............................145

Accessing the Trip Computer - Vehicles

With: 8 Inch Screen ................................145

Resetting the Trip Computer ...................145

Resetting the Individual Trip Values ......145

Configuring the Trip Computer ...............145

Trip Data .........................................................145

Remote Start

What Is Remote Start ................................146

Remote Start Precautions .......................146

Remote Start Limitations ........................146

Enabling Remote Start .............................146

Remotely Starting and Stopping the

Vehicle .........................................................146

Extending the Remote Start Duration

.........................................................................147

Remote Start Remote Control Indicators

.........................................................................147

Remote Start Settings ...............................147

Climate Control - Vehicles

With: Automatic
Temperature Control

Identifying the Climate Control Unit .....149

Switching Climate Control On and Off

.........................................................................149

Switching Recirculated Air On and Off

.........................................................................149

Switching Air Conditioning On and Off

.........................................................................149

Switching Defrost On and Off ................149

4

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Switching Maximum Defrost On and Off

.........................................................................149

Switching Maximum Cooling On and Off

.........................................................................150

Switching the Heated Rear Window On

and Off ........................................................150

Setting the Blower Motor Speed ...........150

Setting the Temperature ..........................150

Directing the Flow of Air ...........................150

Auto Mode .......................................................151

Climate Control Hints .................................152

Climate Control - Vehicles

With: Manual Temperature
Control

Identifying the Climate Control Unit .....154

Switching Climate Control On and Off

.........................................................................154

Switching Recirculated Air On and Off

.........................................................................154

Switching Air Conditioning On and Off

.........................................................................154

Switching Defrost On and Off ................154

Switching Maximum Defrost On and Off

.........................................................................154

Switching Maximum Cooling On and Off

.........................................................................154

Switching the Heated Rear Window On

and Off ........................................................155

Switching the Heated Mirrors On and Off

.........................................................................155

Setting the Blower Motor Speed ...........155

Setting the Temperature ..........................155

Directing the Flow of Air ............................155

Climate Control Hints ................................156

Interior Air Quality

What Is the Cabin Air Filter .......................157

Replacing the Cabin Air Filter ..................157

Front Seats

Front Seat Precautions .............................158

Sitting in the Correct Position .................158

Manual Seats ................................................159

Power Seats ...................................................161

Massage Seats .............................................164

Heated Seats ................................................165

Ventilated Seats ..........................................165

Rear Seats

Manual Seats ................................................167

Heated Seats ................................................169

Rear Occupant Alert System

What is the Rear Occupant Alert System

..........................................................................171

How Does the Rear Occupant Alert

System Work ..............................................171

Rear Occupant Alert System Precautions

..........................................................................171

Rear Occupant Alert System Limitations

..........................................................................171

Switching Rear Occupant Alert System

On and Off - Vehicles With: SYNC

..........................................................................171

Switching Rear Occupant Alert System

On and Off - Vehicles With: SYNC 3

..........................................................................172

Switching Rear Occupant Alert System

On and Off - Vehicles With: SYNC 4

..........................................................................172

Rear Occupant Alert System Indicators

- Vehicles With: SYNC ............................172

Rear Occupant Alert System Indicators

- Vehicles With: SYNC 3/SYNC 4 .......172

Rear Occupant Alert System Audible

Warnings .....................................................173

Memory Function

What Is the Memory Function ................174

Memory Function Precautions ...............174

Locating the Memory Function Buttons

.........................................................................174

Saving a Preset Position ...........................174

5

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Recalling a Preset Position .......................174

Garage Door Opener

What Is the Garage Door Opener ..........176

How Does the Garage Door Opener Work

.........................................................................176

Garage Door Opener Precautions .........176

Garage Door Opener Limitations ...........176

Programming the Garage Door Opener

to Your Hand-Held Transmitter ..........177

Programming the Garage Door Opener

to Your Garage Door Opener Motor

..........................................................................177

Programming the Garage Door Opener

to Your Gate Opener Motor .................178

Clearing the Garage Door Opener .........178

Reprogramming the Garage Door Opener

.........................................................................179

Garage Door Opener Radio Frequencies

.........................................................................179

USB Ports

Locating the USB Ports ............................180

Playing Media Using the USB Port .......180

Charging a Device .........................................181

Power Outlet - Vehicles With:

120V Power Outlet

What Is the Power Outlet .........................182

Power Outlet Precautions ........................182

Power Outlet Limitations .........................182

Locating the Power Outlet .......................182

Power Outlet Indicators ............................182

Power Outlet - Vehicles With:

12V Power Outlet

What Is the Power Outlet .........................184

Power Outlet Precautions ........................184

Locating the Power Outlet .......................184

Wireless Accessory Charger

What Is the Wireless Accessory Charger

.........................................................................185

Wireless Accessory Charger Precautions

.........................................................................185

Locating the Wireless Accessory Charger

.........................................................................185

Charging a Wireless Device .....................185

Storage

Cup Holders ...................................................187

Glove Compartment ...................................187

Center Console ............................................188

Under Seat Storage ....................................188

Glasses Holder .............................................190

Starting and Stopping the

Engine

Starting and Stopping the Engine –

Precautions .................................................191

Ignition Switch ...............................................191

Push Button Ignition Switch ....................192

Starting the Engine .....................................192

Engine Block Heater ...................................194

Stopping the Engine ...................................195

Automatic Engine Stop .............................196

Accessing the Passive Key Backup

Position ........................................................197

Starting and Stopping the Engine –

Troubleshooting ......................................198

Fuel and Refueling

Fuel and Refueling Precautions ............203

Fuel Quality ..................................................204

Running Out of Fuel ..................................208

Refueling .......................................................209

Fuel Tank Capacity .......................................211

Fuel and Refueling – Troubleshooting

..........................................................................211

6

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Diesel Particulate Filter

What Is the Diesel Particulate Filter ......212

How Does the Diesel Particulate Filter

Work ..............................................................212

Diesel Particulate Filter Precautions

.........................................................................212

Diesel Particulate Filter Requirements

.........................................................................213

Diesel Particulate Filter Manual

Regeneration .............................................213

Diesel Particulate Filter –

Troubleshooting .......................................215

Selective Catalytic Reduction

System

What Is the Selective Catalytic

Reduction System ...................................217

How Does the Selective Catalytic

Reduction System Work ........................217

Selective Catalytic Reduction System

Precautions ................................................217

Selective Catalytic Reduction System

Requirements ...........................................218

Selective Catalytic Reduction System

Guidelines ..................................................218

Filling the Selective Catalytic Reduction

System Tank ..............................................219

Checking the Selective Catalytic

Reduction System Status .....................221

Diesel Exhaust Fluid Capacity and

Specification ..............................................221

Selective Catalytic Reduction System –

Troubleshooting .......................................221

Catalytic Converter

What Is the Catalytic Converter ............223

Catalytic Converter Precautions ...........223

Catalytic Converter – Troubleshooting

........................................................................223

Automatic Transmission

Automatic Transmission Precautions

........................................................................224

Automatic Transmission Positions ......224

Shifting Your Vehicle Into Gear ..............224

Manually Shifting Gears ...........................225

Brake Shift Interlock ..................................225

Power Take-Off ............................................227

Four-Wheel Drive

How Does Four-Wheel Drive Work ......228

Four-Wheel Drive Precautions ..............228

Four-Wheel Drive Limitations ...............230

Selecting a Four-Wheel Drive Mode ....230

Four-Wheel Drive Modes ..........................231

Four-Wheel Drive Indicators ...................232

Four-Wheel Drive Driving Hints .............232

Four-Wheel Drive – Troubleshooting

........................................................................234

Electronic Locking Differential

What Is the Electronic Locking

Differential .................................................237

How Does the Electronic Locking

Differential Work .....................................237

Electronic Locking Differential

Precautions ...............................................237

Switching the Electronic Locking

Differential On and Off - 4x4 .............237

Switching the Electronic Locking

Differential On and Off - 4x2 .............238

Electronic Locking Differential Indicators

........................................................................239

Electronic Locking Differential –

Troubleshooting ......................................239

Brakes

Brake Precautions ......................................240

Anti-Lock Braking System ......................240

Brake Over Accelerator ............................240

Locating the Brake Fluid Reservoir ......240

Checking the Brake Fluid .........................240

Brake Fluid Specification ..........................241

7

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Brakes – Troubleshooting ........................241

Parking Brake

Applying the Parking Brake .....................243

Releasing the Parking Brake ...................243

Parking Brake – Troubleshooting .........243

Diesel Engine Exhaust Brake

Diesel Engine Exhaust Brake –

Precautions ..............................................244

Using the Diesel Engine Exhaust Brake

........................................................................244

Diesel Engine Exhaust Brake Indicators

........................................................................245

Diesel Engine Exhaust Brake –

Troubleshooting ......................................245

Hill Start Assist

What Is Hill Start Assist ...........................246

How Does Hill Start Assist Work ..........246

Hill Start Assist Precautions ..................246

Hill Start Assist – Troubleshooting ......246

Traction Control

What Is Traction Control ..........................247

How Does Traction Control Work .........247

Switching Traction Control On and Off

........................................................................247

Traction Control Indicator ........................247

Traction Control – Troubleshooting .....248

Stability Control

How Does Stability Control Work ........249

Switching Stability Control On and Off

........................................................................250

Stability Control Indicator ........................251

Trail Control

What Is Trail Control ..................................252

Switching Trail Control On and Off ......252

Setting the Trail Control Speed .............252

Canceling the Set Speed .........................252

Trail Control Indicators ..............................252

Trail Control – Troubleshooting ............253

Hill Descent Control

What Is Hill Descent Control ..................254

How Does Hill Descent Control Work

........................................................................254

Hill Descent Control Precautions .........254

Switching Hill Descent Control On and

Off ................................................................254

Setting the Hill Descent Speed .............254

Hill Descent Control Indicator ................254

Hill Descent Control – Troubleshooting

........................................................................255

Steering

Hydraulic Power Steering ........................256

Steering – Troubleshooting ....................258

Parking Aids

Parking Aid Precautions ..........................260

Rear Parking Aid .........................................260

Parking Aids – Troubleshooting .............261

Rear View Camera

What Is the Rear View Camera .............263

Rear View Camera Precautions ............263

Locating the Rear View Camera ...........263

Rear View Camera Guide Lines .............264

Rear View Camera Settings ...................264

360 Degree Camera

What Is the 360 Degree Camera .........266

How Does the 360 Degree Camera Work

........................................................................266

360 Degree Camera Precautions ........266

360 Degree Camera Limitations ..........266

Locating the 360 Degree Cameras ......266

8

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

360 Degree Camera Guide Lines ..........267

360 Degree Camera Settings ................268

Cruise Control

What Is Cruise Control ..............................270

Switching Cruise Control On and Off

........................................................................270

Setting the Cruise Control Speed .........270

Canceling the Set Speed ...........................271

Resuming the Set Speed ...........................271

Cruise Control Indicators ...........................271

Adaptive Cruise Control

How Does Adaptive Cruise Control Work

.........................................................................272

Adaptive Cruise Control Precautions

.........................................................................272

Adaptive Cruise Control Limitations

.........................................................................273

Switching Adaptive Cruise Control On

and Off ........................................................275

Adaptive Cruise Control Automatic

Cancellation ..............................................275

Setting the Adaptive Cruise Control

Speed ..........................................................275

Setting the Adaptive Cruise Control Gap

........................................................................276

Canceling the Set Speed ..........................277

Resuming the Set Speed ..........................277

Overriding the Set Speed .........................277

Adaptive Cruise Control Indicators .......277

Switching From Adaptive Cruise Control

to Cruise Control - Vehicles With: 2.3

Inch Screen ...............................................278

Switching From Adaptive Cruise Control

to Cruise Control - Vehicles With: 4.2

Inch Screen ...............................................278

Switching From Adaptive Cruise Control

to Cruise Control - Vehicles With: 8

Inch Screen ...............................................278

Adaptive Cruise Control –

Troubleshooting ......................................279

Drive Mode Control

What Is Drive Mode Control ....................281

How Does Drive Mode Control Work

.........................................................................281

Selecting a Drive Mode ..............................281

Drive Modes ..................................................282

Drive Mode Control – Troubleshooting

........................................................................283

Lane Keeping System

What Is the Lane Keeping System .......286

How Does the Lane Keeping System

Work ............................................................286

Lane Keeping System Precautions ......286

Lane Keeping System Limitations .......286

Switching the Lane Keeping System On

and Off - Vehicles With: 4.2 Inch

Screen .........................................................287

Switching the Lane Keeping System On

and Off - Vehicles With: 8 Inch Screen

........................................................................288

Alert Mode ....................................................288

Lane Keeping System Indicators ..........289

Lane Keeping System – Troubleshooting

.......................................................................290

Blind Spot Information

System

What Is Blind Spot Information System

........................................................................293

How Does Blind Spot Information

System Work ............................................293

Blind Spot Information System

Precautions ...............................................293

Blind Spot Information System

Limitations ................................................293

Blind Spot Information System

Requirements ..........................................293

Switching Blind Spot Information

System On and Off - Vehicles With:

4.2 Inch Screen ........................................293

9

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Switching Blind Spot Information

System On and Off - Vehicles With: 8

Inch Screen ...............................................294

Locating the Blind Spot Information

System Sensors ......................................294

Blind Spot Information System With

Trailer Coverage ......................................295

Blind Spot Information System

Indicators ...................................................296

Blind Spot Information System –

Troubleshooting ......................................297

Cross Traffic Alert

What Is Cross Traffic Alert ......................298

How Does Cross Traffic Alert Work ......298

Cross Traffic Alert Precautions .............298

Cross Traffic Alert Limitations ...............298

Switching Cross Traffic Alert On and Off

- Vehicles With: 4.2 Inch Screen .......299

Switching Cross Traffic Alert On and Off

- Vehicles With: 8 Inch Screen ..........299

Locating the Cross Traffic Alert Sensors

........................................................................299

Cross Traffic Alert Indicators .................300

Cross Traffic Alert – Troubleshooting

.......................................................................300

Pre-Collision Assist

What Is Pre-Collision Assist ....................301

How Does Pre-Collision Assist Work

.........................................................................301

Pre-Collision Assist Precautions ...........301

Pre-Collision Assist Limitations ............302

Switching Pre-Collision Assist On and

Off - Vehicles With: 2.3 Inch Screen

........................................................................302

Switching Pre-Collision Assist On and

Off - Vehicles With: 4.2 Inch Screen

........................................................................303

Switching Pre-Collision Assist On and

Off - Vehicles With: 8 Inch Screen

........................................................................303

Locating the Pre-Collision Assist Sensors

........................................................................303

Distance Indication ....................................304

Distance Alert ..............................................305

Automatic Emergency Braking .............306

Pre-Collision Assist – Troubleshooting

........................................................................307

Driver Alert

What Is Driver Alert ...................................309

How Does Driver Alert Work ..................309

Driver Alert Precautions ...........................309

Driver Alert Limitations ............................309

Switching Driver Alert On and Off -

Vehicles With: 4.2 Inch Screen ...........310

Switching Driver Alert On and Off -

Vehicles With: 8 Inch Screen ..............310

Driver Alert – Troubleshooting ...............310

Load Carrying

Load Carrying Precautions ........................311

Using a Slide-In Camper ...........................312

Locating the Safety Compliance

Certification Labels .................................312

What Is the Gross Axle Weight Rating

.........................................................................312

What Is the Gross Vehicle Weight Rating

.........................................................................312

What Is the Gross Combined Weight

Rating ...........................................................313

Calculating Payload ....................................314

Calculating the Load Limit .......................314

Pickup Bed

Pickup Bed Precautions ............................317

Pickup Bed Anchor Points ........................317

Tailgate Anchor Points ..............................319

Pickup Bed Ramps ......................................319

Connecting a Trailer

Connecting a Trailer Precautions ..........323

Hitches ............................................................323

Connecting a Trailer ...................................325

10

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Connecting a Trailer – Troubleshooting

.........................................................................327

Towing a Trailer

Towing a Trailer Precautions ..................328

Trailer Brake Precautions .........................328

Towing a Trailer Limitations ...................329

Loading Your Trailer ...................................329

Trailer Towing Hints ...................................329

Launching or Retrieving a Boat or

Personal Watercraft ..............................330

Towing Weights and Dimensions ..........331

Towing a Trailer – Troubleshooting ......333

Integrated Trailer Brake

Controller

What Is the Integrated Trailer Brake

Controller ...................................................334

Integrated Trailer Brake Controller

Precautions ...............................................334

Using the Integrated Trailer Brake

Controller ...................................................334

Adjusting the Integrated Trailer Brake

Controller Mode ......................................335

Integrated Trailer Brake Controller –

Troubleshooting ......................................336

Trailer Sway Control

How Does Trailer Sway Control Work

........................................................................338

Trailer Sway Control Precautions .........338

Switching Trailer Sway Control On and

Off ................................................................338

Trailer Backup Assistance

What is Trailer Backup Assistance .......339

How Does Trailer Backup Assistance

Work ............................................................339

Trailer Backup Assistance Precautions

........................................................................339

Setting Up the Trailer Backup Assistance

for a Conventional Trailer ....................339

Setting Up the Trailer Backup Assistance

for a Fifth-Wheel or Gooseneck Trailer

........................................................................343

Switching Trailer Backup Assistance On

and Off .......................................................346

Using the Trailer Backup Assistance

Controller ..................................................346

Using the Trailer Backup Assistance

Views ...........................................................347

Trailer Backup Assistance –

Troubleshooting .....................................349

Trailer Reverse Guidance

What Is Trailer Reverse Guidance .........357

How Does Trailer Reverse Guidance

Work .............................................................357

Trailer Reverse Guidance Precautions

........................................................................357

Setting Up Trailer Reverse Guidance for

a Conventional Trailer ...........................357

Setting Up Trailer Reverse Guidance for

a Fifth-Wheel or Gooseneck Trailer

.......................................................................360

Switching Trailer Reverse Guidance On

and Off .......................................................362

Using Trailer Reverse Guidance Views

........................................................................363

Trailer Reverse Guidance –

Troubleshooting .....................................364

Driving Hints

Off-Road Driving ..........................................371

Cold Weather Precautions .......................373

Breaking-In ....................................................373

Driving Economically .................................373

Driving Through Shallow Water .............373

Floor Mats ......................................................374

Snow Plowing

Snow Plowing Precautions .....................376

Operating Your Vehicle With a

Snowplow .................................................376

11

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Crash and Breakdown

Information

Roadside Assistance .................................378

Switching the Hazard Flashers On and

Off ................................................................379

Jump Starting the Vehicle .......................379

Post-Crash Alert System ..........................381

Automatic Crash Shutoff .........................381

Recovery Towing .........................................382

Transporting the Vehicle ..........................383

Towing Your Vehicle

Towing Your Vehicle Precautions .........384

Recreationally Towing Your Vehicle -

4x4 ...............................................................384

Recreationally Towing Your Vehicle - 4x2

.......................................................................386

Emergency Towing ....................................386

Towing Your Vehicle – Troubleshooting

.......................................................................386

Fuses

Fuse Precautions ........................................387

Under Hood Fuse Box ...............................387

Body Control Module Fuse Box .............392

Identifying Fuse Types ..............................395

Fuses – Troubleshooting .........................395

Maintenance

Maintenance Precautions .......................396

Opening and Closing the Hood ............396

Under Hood Overview - 6.2L ..................397

Under Hood Overview - 6.7L Diesel .....398

Under Hood Overview - 7.3L ..................399

Engine Oil ......................................................400

Checking the Coolant ...............................402

Engine Air Filter ...........................................405

Draining the Fuel Filter Water Trap -

Diesel ..........................................................407

Changing the Fuel Filter - Diesel ..........408

Changing the Fuel Filter - Gasoline ......409

Changing the 12V Battery .......................409

Adjusting the Headlamps ..........................411

Exterior Bulbs ................................................412

Interior Bulbs .................................................419

Drive Belt Routing - 6.2L ...........................419

Drive Belt Routing - 6.7L Diesel, Vehicles

With: Dual Generators ...........................419

Drive Belt Routing - 6.7L Diesel, Vehicles

With: Single Generator ..........................419

Drive Belt Routing - 7.3L, Vehicles With:

Dual Generators .....................................420

Drive Belt Routing - 7.3L, Vehicles With:

Single Generator ....................................420

Vehicle Care

Cleaning Products .......................................421

Cleaning the Exterior ..................................421

Cleaning the Interior ..................................424

Repairing Minor Paint Damage .............426

Waxing Your Vehicle ..................................426

Storing Your Vehicle

Preparing Your Vehicle for Storage ......427

Removing Your Vehicle From Storage

........................................................................428

Wheel and Tire Information

Locating the Tire label ..............................429

Department of Transportation Uniform

Tire Quality Grades ................................429

Information on the Tire Sidewall .........430

Glossary of Tire Terminology .................435

Tire Replacement Requirements .........436

Using Snow Chains ....................................438

Tire Care

Checking the Tire Pressures ....................441

Inflating the Tires .........................................441

Inspecting the Tire for Wear ...................444

Inspecting the Tire for Damage ............445

12

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Inspecting the Wheel Valve Stems ......446

Tire Rotation ................................................446

Tire Pressure Monitoring

System

What Is the Tire Pressure Monitoring

System .......................................................448

Tire Pressure Monitoring System

Overview ...................................................448

Tire Pressure Monitoring System

Precautions ..............................................449

Tire Pressure Monitoring System

Limitations ................................................449

Viewing the Tire Pressures .....................450

Resetting Tire Pressure Monitoring

System .......................................................450

Tire Pressure Monitoring System –

Troubleshooting ......................................453

Changing a Road Wheel

Changing a Flat Tire ..................................455

Wheel Nuts ...................................................465

Capacities and Specifications

Engine Specifications - 6.2L ...................467

Engine Specifications - 6.7L Diesel ......467

Engine Specifications - 7.3L ...................468

Motorcraft Parts - 6.2L ............................469

Motorcraft Parts - 6.7L Diesel .................471

Motorcraft Parts - 7.3L ..............................472

Engine Oil Capacity and Specification -

6.2L ...............................................................473

Engine Oil Capacity and Specification -

6.7L Diesel .................................................474

Engine Oil Capacity and Specification -

7.3L ................................................................477

Cooling System Capacity and

Specification - 6.2L ................................479

Cooling System Capacity and

Specification - 6.7L Diesel ..................480

Cooling System Capacity and

Specification - 7.3L ................................480

Fuel Tank Capacity - Diesel .....................481

Fuel Tank Capacity - Gasoline ...............482

Air Conditioning System Capacity and

Specification - 6.2L ...............................483

Air Conditioning System Capacity and

Specification - 6.7L Diesel ..................484

Air Conditioning System Capacity and

Specification - 7.3L ................................485

Washer Fluid Specification .....................485

Diesel Exhaust Fluid Capacity and

Specification ............................................486

Automatic Transmission Fluid Capacity

and Specification - Diesel ...................487

Automatic Transmission Fluid Capacity

and Specification - Gasoline ..............487

Brake Fluid Specification ........................489

Transfer Case Fluid Capacity and

Specification ...........................................490

Front Axle Fluid Capacity and

Specification ...........................................490

Rear Axle Fluid Capacity and

Specification - Diesel .............................491

Rear Axle Fluid Capacity and

Specification - Gasoline ......................493

Hydraulic Power Steering Fluid Capacity

and Specification ...................................496

Vehicle Identification

Vehicle Identification Number ...............497

Connected Vehicle - Vehicles

With: SYNC 3

What Is a Connected Vehicle ................498

Connected Vehicle Requirements .......498

Connected Vehicle Limitations .............498

Connecting the Vehicle to a Mobile

Network .....................................................498

Connecting the Vehicle to a Wi-Fi

Network .....................................................498

Connected Vehicle – Troubleshooting -

Vehicles With: Modem .........................499

13

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Connected Vehicle – Troubleshooting -

Vehicles With: SYNC 3 .........................500

Connected Vehicle - Vehicles

With: SYNC 4

What Is a Connected Vehicle .................502

Connected Vehicle Requirements .......502

Connected Vehicle Limitations .............502

Connecting the Vehicle to a Mobile

Network .....................................................502

Connecting the Vehicle to a Wi-Fi

Network .....................................................502

Connected Vehicle – Troubleshooting

........................................................................503

Vehicle Wi-Fi Hotspot

Creating a Vehicle Wi-Fi Hotspot ........506

Changing the Vehicle Wi-Fi Hotspot

Name or Password ................................506

Audio System - Vehicles With:

SYNC

General Information .................................508

Audio Unit .....................................................508

Digital Radio ..................................................510

Satellite Radio ..............................................513

USB Port .........................................................516

Audio System - Vehicles With:

SYNC 3

General Information ....................................517

Audio Unit .......................................................517

Digital Radio ..................................................518

Satellite Radio ..............................................521

USB Port ........................................................524

Audio System - Vehicles With:

SYNC 4

Audio System Precautions ......................525

Switching the Audio Unit On and Off

........................................................................525

Selecting the Audio Source ....................525

Playing or Pausing the Audio Source

........................................................................525

Adjusting the Volume ................................525

Switching Shuffle Mode On and Off

........................................................................526

Switching Repeat Mode On and Off

........................................................................526

Setting a Memory Preset .........................526

Muting the Audio ........................................526

Adjusting the Sound Settings ................526

Setting the Clock and Date .....................526

AM/FM Radio ................................................527

Switching the Display On and Off ........528

Digital Radio .................................................528

Satellite Radio .............................................529

Audio System – Troubleshooting .........532

Identifying the Audio Unit .......................535

SYNC™

General Information ..................................536

Using Voice Recognition ...........................537

Using SYNC™ With Your Phone ...........539

SYNC™ Applications and Services ......540

Using SYNC™ With Your Media Player

........................................................................542

SYNC™ Troubleshooting ........................542

SYNC™ 3

General Information ..................................552

Using Voice Recognition ..........................554

Entertainment .............................................560

Climate ...........................................................570

Phone ..............................................................572

Navigation .....................................................574

Apps ................................................................580

Settings ..........................................................582

SYNC™ 3 Troubleshooting ....................584

14

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Center Display Overview -

Vehicles With: SYNC 4

Center Display Precautions ....................597

Center Display Limitations ......................597

Status Bar ......................................................597

Feature Bar ...................................................598

Information On Demand Screen ..........599

Voice Interaction - Vehicles

With: SYNC 4

What is Voice Interaction .......................600

Setting the Wake Word ...........................600

Beginning a Voice Interaction ...............600

Voice Interaction Examples ...................600

Phone - Vehicles With: SYNC

4

Phone Precautions ....................................602

Connecting Your Phone ...........................602

Phone Menu .................................................602

Making and Receiving a Phone Call ....604

Sending and Receiving a Text Message

.......................................................................605

Switching Text Message Notification On

and Off ......................................................606

Bluetooth® - Vehicles With:

SYNC 4

Connecting a Bluetooth® Device .........607

Playing Media Using Bluetooth® .........607

Apps - Vehicles With: SYNC 4

App Precautions ........................................608

App Requirements ....................................608

Accessing Apps ..........................................608

Enabling Apps on an iOS Device .........608

Enabling Apps on an Android Device

.......................................................................608

Switching Apple CarPlay On and Off

.......................................................................609

Switching Android Auto On and Off ....609

Navigation - Vehicles With:

SYNC 4

Accessing Navigation ................................610

Navigation Map Updates .........................610

Adjusting the Map .......................................610

Live Traffic .....................................................610

Setting a Destination .................................610

Waypoints .......................................................611

Route Guidance ............................................611

Trailer Towing Navigation .........................612

Vehicle System Updates -

Vehicles With: SYNC 4

Updating the Vehicle Systems Wirelessly

.........................................................................613

Performing a Master Reset ......................614

Accessories

Accessories ....................................................615

Auxiliary Switches .......................................616

Auxiliary Switches

What Are the Auxiliary Switches ...........618

Locating the Auxiliary Switches ............618

Locating the Auxiliary Switch Wiring

........................................................................618

Identifying the Auxiliary Switch Wiring

........................................................................619

Ford Protect

What Is Ford Protect .................................620

Scheduled Maintenance

General Maintenance Information .......622

Normal Scheduled Maintenance - Diesel

........................................................................625

Normal Scheduled Maintenance -

Gasoline .....................................................628

15

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

Special Operating Conditions Scheduled

Maintenance - Diesel .............................631

Special Operating Conditions Scheduled

Maintenance - Gasoline ......................636

Customer Information

Rollover Warning ........................................640

Our Sustainability Report .......................640

The Better Business Bureau Auto Line

Program - United States of America

.......................................................................640

The Mediation and Arbitration Program

- Canada .....................................................641

Ordering a Canadian French Owner's

Manual ........................................................641

Reporting Safety Defects in the United

States .........................................................642

Reporting Safety Defects in Canada

........................................................................642

Radio Frequency Certification Labels

........................................................................643

Perchlorate ...................................................684

Replacement Parts Recommendation

.......................................................................684

Mobile Communications Equipment

.......................................................................685

End User License Agreement ................685

Emission Law ................................................710

Export Unique Options ...............................711

Appendices

Electromagnetic Compatibility ...............713

16

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Table of Contents

If you require assistance or clarification on
policies or procedures, please contact the
customer relationship center.

United States

Ford Motor Company
Customer Relationship Center
PO Box 6248
Dearborn, MI 48126
1-800-392-3673 (FORD)
(TDD for the hearing impaired:
1-888-658-6805
www.ford.com/help/contact/

Canada

Customer Relationship Center
Ford Motor Company of Canada Limited
P.O. Box 2000
Oakville, Ontario L6J 5E4
1-800-565-3673 (FORD)
www.ford.ca
Facebook: FordServiceCA (English),
FordServiceQC (Francais)

Europe

Telephone: [phone]
E-mail: [e-mail]
Twitter: @forduk

Australia

Ford Motor Company
Attention: Customer Relationship Centre
Private Mail Bag 5
Fairlane Business Park #3
Campbellfield, Victoria, 3061
Telephone: 13 3673 (FORD)
E-mail: [e-mail]

New Zealand

Ford Motor Company
Attention: Customer Relationship Centre
Private Bag 76912
Manukau City 2241
Telephone: [phone] (FORDNZ)
E-mail: [e-mail]

China - Imported Vehicle

Customer Relationship Center
Telephone: [phone]
Website: https://www.ford.com.cn/

China - Chang’An Ford

Customer Relationship Center
Telephone: [phone]
Mobile: [phone]
Website: https://www.ford.com.cn/

Asia Pacific

E-mail: [e-mail]

Caribbean, Central America and
Israel

Ford Motor Company
Ford Export Operations
Attention: Owner Relations
1555 Fairlane Drive
Fairlane Business Park #3
Allen Park, MI 48101
Fax: [phone]
Telephone: [phone]
E-mail: [e-mail]

U.S. Virgin Islands and Puerto Rico

Ford Motor Company
Ford Export Operations
Attention: Owner Relations
1555 Fairlane Drive
Fairlane Business Park #3
Allen Park, MI 48101
Telephone: [phone]
E-mail: [e-mail]

Argentina

Telephone: [phone]

Brazil

www.ford.com.br

17

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Contacting Us

North Africa

E-mail: [e-mail]

Sub-Saharan Africa

E-mail: [e-mail]

Puerto Rico

Ford International Business Development,
Inc.
P.O. Box 11957
Caparra Heights Station
San Juan, PR 00922-1957
1-800-392-3673 (FORD)
Fax: [phone]
E-mail: [e-mail]
www.ford.com.pr

Middle East

Ford Middle East Customer Relationship
Center
P.O. Box 21740
Dubai, United Arab Emirates
Telephone: [phone]
Toll-free number for the Kingdom of Saudi
Arabia: 8008443673
Mobily and Zain cell phone users in Saudi
Arabia: 800850078
Kuwait: 22280384
Local telephone number for Kuwait: +965
1 898900
Fax: [phone]
E-mail: [e-mail]
www.me.ford.com

South Korea

Telephone: [phone]
E-mail: [e-mail]

Ford Credit - US Only

Ford Credit offers a full range of financing
and lease plans to help you acquire your
vehicle. If you have financed or leased your
vehicle through Ford Credit, thank you for
your business.

For assistance call 1-800-727-7000, or for
more information about Ford Credit and
access to an account manager, visit
www.ford.com/finance.

18

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Contacting Us

ABOUT THIS PUBLICATION

WARNING: Driving while distracted

can result in loss of vehicle control, crash
and injury. We strongly recommend that
you use extreme caution when using any
device that may take your focus off the
road. Your primary responsibility is the
safe operation of your vehicle. We
recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.

WARNING: You risk death, fire, or
serious injury to yourself and others if you
do not follow the instruction highlighted
by the warning symbol.

Thank you for choosing Ford. We
recommend that you take some time to
get to know your vehicle in order to benefit
from greater safety and pleasure from
driving it. Use this publication to familiarize
yourself with the basics and then read the
digital version, that is available in your
vehicle. You can also view the
comprehensive manual through the
FordPass app and through the local Ford
website.

Note: To download the FordPass app, visit
your device's app store.

Note: To find the local Ford website, visit

https://corporate.ford.com/operations/
locations/global-links.html.

Note: Use and operate your vehicle in line
with all applicable laws and regulations.

Note: Pass on all printed owner’s
information when selling this vehicle.

Our digital resources include a
comprehensive digital Owner’s Manual
dynamically created according to the
features on your vehicle by using the
vehicle identification number. See

Locating the Vehicle Identification
Number (page 497). The digital Owner’s

Manual includes visual and full text search
functions so that you can quickly locate
the information you are looking for. It also
includes links to a number of how-to
videos created to help you understand
some of the advanced technologies on
your vehicle.

Features and Options

This publication describes product features
and options available throughout the range
of available models, sometimes even
before they are generally available. It could
describe options that are not available on
the vehicle you have purchased.

Illustrations

Some of the illustrations in this publication
could show features as used in different
models, so they could appear different to
you on your vehicle.

Location of Components

This manual may qualify the location of a
component as left-hand side or right-hand
side. The side is determined when facing
forward in the seat.

19

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Introduction

E154903

Right-hand side.A
Left-hand side.B

USING THIS PUBLICATION

To quickly locate information about your
vehicle, use the word search within the
Owner's Manual application.

20

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Introduction

SYMBOLS USED ON YOUR VEHICLE

These are some of the symbols you may
see on your vehicle.

E162384

Air conditioning system

E231157

Air conditioning system lubricant
type

Anti-lock braking system

Avoid smoking, flames or sparks

Battery

Battery acid

Brake fluid - non petroleum
based

Brake system

E270480

Brake system

E139223

Cabin air filter

Check fuel cap

Child safety door lock or unlock

Child seat lower anchor

E141128

Child seat tether anchor

E332905

Cruise control

Do not open when hot

Electric Parking brake

Engine air filter

Engine coolant

Engine coolant temperature

Engine oil

Explosive gas

Fan warning

Fasten seatbelt

E231160

Flammable

Airbag

Front fog lamps

Fuel pump reset

21

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Symbols Glossary

Fuse compartment

Hazard flashers

Heated rear window

Windshield defrosting system

Interior luggage compartment
release

Jack

Keep out of reach of children

Lighting control

Low tire pressure warning

Maintain correct fluid level

Note operating instructions

E270945

Horn control

Panic alarm

E139213

Parking aid

Passenger airbag activated

Passenger airbag deactivated

Power steering fluid

Power windows front/rear

Power window lockout

E231159

Requires registered technician

E65963

Safety alert

See Owner's Manual

E231158

See Service Manual

Malfunction Indicator Lamp
(MIL)

Side airbag

Shield the eyes

E138639

Stability control

Hill descent control

E332910

Trail control

Windshield wiping system

22

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Symbols Glossary

E132353

Windshield wash and wipe

23

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Symbols Glossary

WARNING: Do not connect

wireless plug-in devices to the data link
connector. Unauthorized third parties
could gain access to vehicle data and
impair the performance of safety related
systems. Only allow repair facilities that
follow our service and repair instructions
to connect their equipment to the data
link connector.

We respect your privacy and are
committed to protecting it. The
information contained in this manual was
correct at the time of publication but as
technology rapidly changes, we
recommend that you visit the local Ford
website for the latest information.

Your vehicle has electronic control units
that have data recording functionality and
the ability to permanently or temporarily
store data. This data could include
information on the condition and status of
your vehicle, vehicle maintenance
requirements, events and malfunctions.
The types of data that can be recorded are
described in this section. Some of the data
recorded is stored in event logs or error
logs.

Note: Error logs are reset following a service
or repair.

Note: We may provide information in
response to requests from law enforcement,
other government authorities and third
parties acting with lawful authority or
through a legal process. Such information
could be used by them in legal proceedings.

Data recorded includes, for example:

• Operating states of system
components, for example fuel level,
tire pressure and battery charge level.

• Vehicle and component status, for
example wheel speed, deceleration,
lateral acceleration and seatbelt
status.

• Events or errors in essential systems,
for example headlamps and brakes.

• System responses to driving situations,
for example airbag deployment and
stability control.

• Environmental conditions, for example
temperature.

Some of this data, when used in
combination with other information, for
example an accident report, damage to a
vehicle or eyewitness statements, could
be associated with a specific person.

Services That We Provide

If you use our services, we collect and use
data, for example account information,
vehicle location and driving characteristics,
that could identify you. We transmit this
data through a dedicated, protected
connection. We only collect and use data
to enable your use of our services to which
you have subscribed, with your consent or
where permitted by law. For additional
information, see the terms and conditions
of the services to which you have
subscribed.

For additional information about our
privacy policy, refer to the local Ford
website.

Services That Third Parties
Provide

We recommend that you review the terms
and conditions and data privacy
information for any services equipped with
your vehicle or to which you subscribe. We
take no responsibility for services that third
parties provide.

Where equipped, SiriusXM with 360L may
use the modem. To disable, turn off the
SiriusXM 360L or Vehicle Connectivity
setting. See Enabling and Disabling the
Modem (page 498).

24

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Data Privacy

SERVICE DATA

Service data recorders in your vehicle are
capable of collecting and storing
diagnostic information about your vehicle.
This potentially includes information about
the performance or status of various
systems and modules in the vehicle, such
as engine, throttle, steering or brake
systems. In order to properly diagnose and
service your vehicle, Ford Motor Company
(Ford of Canada in Canada), and service
and repair facilities may access or share
among them vehicle diagnostic
information received through a direct
connection to your vehicle when
diagnosing or servicing your vehicle.
Additionally, Ford Motor Company (Ford
of Canada, in Canada) may, where
permitted by law, use vehicle diagnostic
information for vehicle improvement or
with other information we may have about
you, for example, your contact information,
to offer you products or services that may
interest you. Data may be provided to our
service providers such as part suppliers
that may help diagnose malfunctions, and
who are similarly obligated to protect data.
We retain this data only as long as
necessary to perform these functions or to
comply with law. We may provide
information where required in response to
official requests to law enforcement or
other government authorities or third
parties acting with lawful authority or court
order, and such information may be used
in legal proceedings. For U.S. only (if
equipped), if you choose to use connected
apps and services, you consent that certain
diagnostic information may also be
accessed electronically by Ford Motor
Company and Ford authorized service
facilities, and that the diagnostic
information may be used to provide
services to you, personalizing your
experience, troubleshoot, and to improve
products and services and offer you
products and services that may interest

you, where permitted by law. For Canada
only, for more information, please review
the Ford of Canada privacy policy at
www.ford.ca, including our U.S. data
storage and use of service providers in
other jurisdictions who may be subject to
legal requirements in Canada, the United
States and other countries applicable to
them, for example, lawful requirements to
disclose personal information to
governmental authorities in those
countries.

EVENT DATA

This vehicle is equipped with an event data
recorder. The main purpose of an event
data recorder is to record, in certain crash
or near crash-like situations, such as an
airbag deployment or hitting a road
obstacle; this data will assist in
understanding how a vehicle’s systems
performed. The event data recorder is
designed to record data related to vehicle
dynamics and safety systems for a short
period of time, typically 30 seconds or less.

The event data recorder in this vehicle is
designed to record such data as:

• How various systems in your vehicle
were operating.

• Whether or not the driver and
passenger seatbelts were
buckled/fastened.

• How far (if at all) the driver was
depressing the accelerator and/or the
brake pedal.

• How fast the vehicle was traveling.

• Where the driver was positioning the

steering wheel.

This data can help provide a better
understanding of the circumstances in
which crashes and injuries occur.

25

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Data Privacy

Note: Event data recorder data is recorded

by your vehicle only if a non-trivial crash
situation occurs; no data is recorded by the
event data recorder under normal driving
conditions and no personal data or
information (for example name, gender,
age, and crash location) is recorded.
However, parties, such as law enforcement,
could combine the event data recorder data
with the type of personally identifying data
routinely acquired during a crash
investigation.

To read data recorded by an event data
recorder, special equipment is required,
and access to the vehicle or the event data
recorder is needed. In addition to the
vehicle manufacturer, other parties, such
as law enforcement, that have such special
equipment, can read the information if they
have access to the vehicle or the event
data recorder.

SETTINGS DATA

Your vehicle has electronic control units
that have the ability to store data based
on your personalized settings. The data is
stored locally in the vehicle or on devices
that you connect to it, for example, a USB
drive or digital music player. You can delete
some of this data and also choose whether
to share it through the services to which
you subscribe. See Settings (page 582).

Comfort and Convenience Data

Data recorded includes, for example:

• Seat and steering wheel position.

• Climate control settings.

• Radio presets.

Entertainment Data

Data recorded includes, for example:

• Music, videos or album art.

• Contacts and corresponding address

book entries.

• Navigation destinations.

CONNECTED VEHICLE DATA

The modem has a SIM. The
modem was enabled when your

vehicle was built and periodically
sends messages to stay connected to the
cell phone network, receive automatic
software updates and send vehicle-related
information to us, for example diagnostic
information. These messages could
include information that identifies your
vehicle, the SIM and the electronic serial
number of the modem. Cell phone network
service providers could have access to
additional information, for example cell
phone network tower identification. For
additional information about our privacy
policy, visit www.FordConnected.com or
refer to your local Ford website.

Note: The modem continues to send this
information unless you disable the modem
or stop the modem from sharing vehicle
data by changing the modem settings. See
Connected Vehicle (page 502).

Note: The service can be unavailable or
interrupted for a number of reasons, for
example environmental or topographical
conditions and data plan coverage.

Note: To find out if your vehicle has a
modem, visit www.FordConnected.com.

26

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Data Privacy

MOBILE DEVICE DATA ­VEHICLES WITH: SYNC 3

If you connect a mobile device to your
vehicle, you can display data from your
device on the touchscreen for example,
music and album art. You can share your
vehicle data with mobile apps on your
device through the system. See App
Precautions (page 608).

The mobile apps function operates by your
connected device sending data to us in the
United States. The data is encrypted and
includes, for example, the vehicle
identification number of your vehicle, the
SYNC module serial number, odometer,
enabled apps, usage statistics and
debugging information. We retain it only
as long as necessary to provide the service,
to troubleshoot, for continuous
improvement and to offer you products
and services that may be of interest to you
according to your preferences and where
allowed by law.

If you connect a cell phone to the system,
the system creates a profile that links to
that cell phone. The cell phone profile
enables more mobile features and efficient
operation. The profile contains, for
example data from your phonebook, read
and unread text messages and call history,
including history of calls when your cell
phone was not connected to the system.

If you connect a media device, the system
creates and retains a media device index
of supported media content. The system
also records a short diagnostic log of
approximately 10 minutes of all recent
system activity.

The cell phone profile, media device index
and diagnostic log remain in your vehicle
unless you delete them and are generally
accessible only in your vehicle when you
connect your cell phone or media device.
If you no longer plan to use the system or
your vehicle, we recommend you use the
master reset function to erase the stored
information. See Settings (page 582).

System data cannot be accessed without
special equipment and access to your
vehicle's module.

For additional information about our
privacy policy, refer to the local Ford
website.

Note: To find out if your vehicle has
connectivity technology, visit

www.FordConnected.com.

MOBILE DEVICE DATA ­VEHICLES WITH: SYNC 4

If you connect a mobile device to your
vehicle, you can display data from your
device on the touchscreen for example,
music and album art. You can share your
vehicle data with mobile apps on your
device through the system. See App
Requirements (page 608).

The mobile apps function operates by your
connected device sending data to us in the
United States. The data is encrypted and
includes, for example, the vehicle
identification number of your vehicle, the
SYNC module serial number, odometer,
enabled apps, usage statistics and
debugging information. We retain it only
as long as necessary to provide the service,
to troubleshoot, for continuous
improvement and to offer you products
and services that may be of interest to you
according to your preferences and where
allowed by law.

27

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Data Privacy

If you connect a cell phone to the system,
the system creates a profile that links to
that cell phone. The cell phone profile
enables more mobile features and efficient
operation. The profile contains, for
example data from your phonebook, read
and unread text messages and call history,
including history of calls when your cell
phone was not connected to the system.

If you connect a media device, the system
creates and retains a media device index
of supported media content. The system
also records a short diagnostic log of
approximately 10 minutes of all recent
system activity.

The cell phone profile, media device index
and diagnostic log remain in your vehicle
unless you delete them and are generally
accessible only in your vehicle when you
connect your cell phone or media device.
If you no longer plan to use the system or
your vehicle, we recommend you use the
master reset function to erase the stored
information. See Performing a Master
Reset (page 614).

System data cannot be accessed without
special equipment and access to your
vehicle's module.

For additional information about our
privacy policy, refer to the local Ford
website.

Note: To find out if your vehicle has
connectivity technology, visit

www.FordConnected.com.

EMERGENCY CALL SYSTEM DATA

When the emergency call system is active,
it may disclose to emergency services that
your vehicle has been in a crash involving
the deployment of an airbag or activation
of the fuel pump shut-off. Certain versions
or updates to the emergency call system
may also be capable of electronically or

verbally disclosing to emergency services
operators your vehicle location or other
details about your vehicle or crash to assist
emergency services operators to provide
the most appropriate emergency services.
If you do not want to disclose this
information, do not activate the emergency
call system.

Note: You cannot deactivate emergency
call systems that are required by law.

28

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Data Privacy

STEERING WHEEL - VEHICLES WITH: SYNC 4

A

B

D

C

E346226

See Using the Instrument Cluster Display Controls (page 141).A
See Adjusting the Volume (page 525).B
See Making and Receiving a Phone Call (page 604).C
See Setting the Cruise Control Speed (page 270). See Setting the Adaptive

Cruise Control Speed (page 275).

D

29

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Visual Search

STEERING WHEEL - VEHICLES WITH: SYNC 3

A

B

D

C

E346226

See Using the Instrument Cluster Display Controls (page 141).A
See Audio Unit (page 517).B
See Phone (page 572).C
See Setting the Cruise Control Speed (page 270). See Setting the Adaptive

Cruise Control Speed (page 275).

D

30

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Visual Search

INSTRUMENT PANEL

E346227

A B C E F

D

HLM IJ

KN

G

See Instrument Cluster Overview (page 133). See Instrument Cluster
Overview (page 134). See Instrument Cluster Overview (page 135).

A

See Push Button Ignition Switch (page 192).B
See Switching Stability Control On and Off (page 250).C
See Switching the Hazard Flashers On and Off (page 379).D
See Switching the 360 Degree Camera On and Off (page 268).E
See Opening the Glove Compartment (page 187).F
See Status Bar (page 597).G
See Opening the Glove Compartment (page 187).H
See Locating the Power Outlet (page 182).I
See Switching the Audio Unit On and Off (page 525).J
See Identifying the Climate Control Unit (page 149).K
See Using the Integrated Trailer Brake Controller (page 334).L

31

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Visual Search

See Selecting a Four-Wheel Drive Mode (page 230).M
See Releasing the Parking Brake (page 243).N

VEHICLE INTERIOR

A

B C

D

E346228

See Sitting in the Correct Position (page 158).A
See Opening the Center Console (page 188).B
See Unfolding the Seats (page 168).C
See Folding the Seats (page 168).D

32

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Visual Search

FRONT EXTERIOR

E346229

A C

B

D

F

E

See Opening and Closing the Hood (page 396).A
See Replacing the Front Wiper Blades (page 116).B
See Unlocking and Locking the Doors Using the Key Blade (page 83).C
See Deploying and Stowing the Power Running Boards (page 110).D
See Accessing the Front Towing Point (page 382).E
See Locating the 360 Degree Cameras (page 266).F

33

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Visual Search

REAR EXTERIOR

E346230

A DB

C

E

See Opening the Tailgate From Outside Your Vehicle (page 99).A
See Opening and Closing the Sliding Windows (page 127).B
See Locating the 360 Degree Cameras (page 266).C
See Folding the Exterior Mirrors (page 129). See Folding the Exterior Mirrors

(page 129).

D

See Connecting a Trailer (page 325).E

34

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Visual Search

CHILD SAFETY PRECAUTIONS

WARNING: Always make sure your

child is secured properly in a device that
is appropriate for their height, age and
weight. Child safety restraints must be
bought separately from your vehicle.
Failure to follow these instructions and
guidelines may result in an increased risk
of serious injury or death to your child.

WARNING: All children are shaped
differently. The National Highway Traffic
Safety Administration and other safety
organizations, base their
recommendations for child restraints on
probable child height, age and weight
thresholds, or on the minimum
requirements of the law. We recommend
that you check with a NHTSA Certified
Child Passenger Safety Technician
(CPST) to make sure that you properly
install the child restraint in your vehicle
and that you consult your pediatrician to
make sure you have a child restraint
appropriate for your child. To locate a
child restraint fitting station and CPST,
contact NHTSA toll free at
1-888-327-4236 or go to
www.nhtsa.dot.gov. In Canada, contact
Transport Canada toll free at
1-800-333-0371 or go to www.tc.gc.ca
to find a Child Car Seat Clinic in your
area. Failure to properly restrain children
in child restraints made especially for
their height, age and weight, may result
in an increased risk of serious injury or
death to your child.

WARNING: On hot days, the
temperature inside the vehicle can rise
very quickly. Exposure of people or
animals to these high temperatures for
even a short time can cause death or
serious heat related injuries, including
brain damage. Small children are
particularly at risk.

WARNING: Do not place a
rearward facing child restraint in front of
an active airbag. Failure to follow this
instruction could result in personal injury
or death.

WARNING: Properly secure
children 12 years old and under in a rear
seating position whenever possible. If
you are unable to properly secure all
children in a rear seating position,
properly secure the largest child on the
front seat. If you must use a forward
facing child restraint on the front seat,
move the seat as far back as possible.
Failure to follow these instructions could
result in personal injury or death.

WARNING: Always carefully follow
the instructions and warnings provided
by the manufacturer of any child
restraint to determine if the restraint
device is appropriate for your child's size,
height, weight, or age. Follow the child
restraint manufacturer's instructions and
warnings provided for installation and
use in conjunction with the instructions
and warnings provided by your vehicle
manufacturer. A safety seat that is
improperly installed or utilized, is
inappropriate for your child's height, age,
or weight or does not properly fit the
child may increase the risk of serious
injury or death.

35

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

WARNING: Do not allow a

passenger to hold a child on their lap
when your vehicle is moving. Failure to
follow this instruction could result in
personal injury or death in the event of a
sudden stop or crash.

WARNING: Do not use pillows,
books or towels to boost your child's
height. Failure to follow this instruction
could result in personal injury or death.

WARNING: Properly secure child
restraints or booster seats when they are
not in use. They could become projectiles
in a sudden stop or crash. Failure to
follow this instruction could result in
personal injury or death.

WARNING: Do not put the shoulder
section of the seatbelt or allow the child
to put the shoulder section of the
seatbelt under their arm or behind their
back. Failure to follow this instruction
could reduce the effectiveness of the
seatbelt and increase the risk of injury or
death in a crash.

WARNING: Do not leave children
or pets unattended in your vehicle.
Failure to follow this instruction could
result in personal injury or death.

When installing a child restraint with
seatbelts:

• Place the vehicle seat in the upright
position before you install the child
restraint.

• Use the correct seatbelt buckle for that
seating position.

• Insert the belt tongue into the buckle.
Make sure the tongue is securely
fastened in the buckle.

• Keep the buckle release button
pointing up and away from the child
restraint, with the tongue between the
child restraint and the release button,
to prevent accidental unbuckling.

• Put the seatbelt in the automatic
locking mode.

CHILD RESTRAINT ANCHOR POINTS

WHAT ARE THE CHILD RESTRAINT
ANCHOR POINTS

Anchor points allow you to quickly and
safely install a child restraint.

LOCATING THE CHILD RESTRAINT
LOWER ANCHOR POINTS

Crew Cab

E308373

Super Cab

36

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

E308385

E312604

The lower child restraint anchors are at the
rear section of the rear seat between the
cushion and seat backrest.

Note: Regular Cab vehicles do not have
lower anchors.

LOCATING THE CHILD RESTRAINT
TOP TETHER ANCHOR POINTS

Regular Cab

E308389

Crew Cab

E308390

Super Cab

37

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

E308396

CHILD RESTRAINTS

CHILD RESTRAINT POSITION
INFORMATION

Install the child restraint tightly against the
vehicle seat. It may be necessary to lift or
remove the head restraint.

Rear Facing Child Restraints

Seatbelt Only

LATCH (Lower Anchors

Only)

Combined Weight of Child

and Child Restraint

XXUp to 65 lb (29 kg)

XOver 65 lb (29 kg)

Forward Facing Child Restraints

Seatbelt and LATCH
(Lower Anchors and

Top Tether Anchor)

Seatbelt and Top

Tether Anchor

LATCH (Lower

Anchors and Top

Tether Anchor)

Combined Weight of

Child and Child

Restraint

XXXUp to 65 lb (29 kg)

XXOver 65 lb (29 kg)

38

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

CHILD RESTRAINTS RECOMMENDATION

Recommended Restraint TypeChild Size, Height, Weight, or Age

Use a child restraint (sometimes

called an infant carrier, convertible

seat, or toddler seat).

Children weighing 40 lb (18 kg) or less (generally

age four or younger).

Use a belt-positioning booster

seat.

Children who have outgrown or no longer properly

fit in a child restraint (generally children who are
less than 57 in (1.45 m) tall, are greater than age

four and less than age 12, and between 40 lb (18 kg)

and 80 lb (36 kg) and upward to 100 lb (45 kg) if

recommended by your child restraint manufacturer).

Use a vehicle seatbelt having the
lap belt snug and low across the

hips, shoulder belt centered across

the shoulder and chest, and seat

backrest upright.

Children who have outgrown or no longer properly

fit in a belt-positioning booster seat (generally chil-

dren who are at least 57 in (1.45 m) tall or greater

than 80 lb (36 kg) or 100 lb (45 kg) if recommended

by child restraint manufacturer).

You are required by law to properly use
child restraints for infants and toddlers in
the United States, Canada and Mexico.

Many states and provinces require that
small children use approved booster seats
until they reach age eight, a height of 57 in
(1.45 m) tall, or 80 lb (36 kg). Check your
local and state or provincial laws for
specific requirements about the safety of
children in your vehicle.

When possible, properly restrain children
12 years of age and under in a rear seating
position of your vehicle. Accident statistics
suggest that children are safer when
properly restrained in the rear seating
positions than in a front seating position.

When installing a rear facing child restraint,
adjust the vehicle seats to avoid
interference between the child restraint
and the vehicle seat in front of the child
restraint.

INSTALLING CHILD RESTRAINTS

USING SEATBELTS

WARNING: Depending on where

you secure a child restraint, and
depending on the child restraint design,
you may block access to certain seatbelt
buckle assemblies and LATCH lower
anchors, rendering those features
potentially unusable. To avoid risk of
injury, make sure occupants only use
seating positions where they are able to
be properly restrained.

Note: The following does not apply to the
front center position of Super Cab and Crew
Cab vehicles.

Note: Although the child restraint
illustrated is a forward facing child restraint,
the steps are the same for installing a rear
facing child restraint.

39

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

Perform the following steps when
installing a child restraint with seatbelts.

1. Position the child restraint in a seat
with a seatbelt.

E142529

2. Pull down on the shoulder belt and
then grasp the shoulder belt and lap
belt together.

E142530

3. While holding the shoulder and lap belt
portions together, route the tongue
through the child restraint according
to the child restraint manufacturer's
instructions. Make sure you did not
twist the belt webbing.

E142531

4. Insert the belt tongue into the proper
buckle for that seating position until
the latch engages. Make sure the
tongue is latched securely by pulling
on it.

E142875

5. To put the retractor in the automatic
locking mode, grasp the shoulder
portion of the belt and pull downward
until you pull all of the seatbelt out.

Note: The automatic locking mode is
available on the front passenger and rear
seats. This mode is also available on the
center seat of a Regular Cab. This vehicle
does not require the use of a locking clip.

6. Allow the belt to retract to remove
slack. The seatbelt clicks as it retracts
to indicate it is in the automatic locking
mode.

40

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

7. Pull the seatbelt out of the retractor to
make sure the retractor is in the
automatic locking mode. You should
not be able to pull more belt out. If the
retractor is not locked, unbuckle the
belt and repeat Steps 5 and 6.

E142533

8. Remove remaining slack from the belt.
Force the seat down with extra weight,
for example, by pressing down or
kneeling on the child restraint while
pulling up on the shoulder belt in order
to force slack from the belt. This is
necessary to remove the remaining
slack that exists once you add the extra
weight of the child to the child restraint.
It also helps to achieve the proper
snugness of the child restraint to your
vehicle. Sometimes, a slight lean
toward the buckle helps to remove
remaining slack from the belt.

9. If the child restraint has a tether strap,
attach it.

E142534

10. Before placing the child in the seat,
forcibly move the seat forward and
back to make sure the seat is securely
held in place.

To check this, grab the seat at the belt path
and attempt to move it side to side and
forward and back. There should be no
more than 1 in (2.5 cm) of movement.

We recommend checking with a NHTSA
Certified Child Passenger Safety
Technician to make certain the child
restraint is properly installed. In Canada,
check with Transport Canada for referral
to a Child Car Seat Clinic.

Using Seatbelts

WARNING: Always use both the

lap and shoulder portion of the seatbelt
in the center seating position.

Note: The following applies to the front
center position of Super Cab and Crew Cab
vehicles.

The seatbelt webbing below the tongue is
the lap portion of the seatbelt. The
webbing above the tongue is the shoulder
belt portion of the seatbelt.

1. Position the child restraint in the front

center seat.

41

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

E162708

2. Slide the tongue up the webbing.

E142530

3. While holding both shoulder and lap
portions next to the tongue, route the
tongue and webbing through the child
restraint according to the child restraint
manufacturer's instructions. Make sure
you did not twist the belt webbing.

E142531

4. Insert the belt tongue into the proper
buckle for that seating position until
the latch engages. Make sure the
tongue is latched securely by pulling
on it.

E142533

5. When pushing down with your knee on
the child restraint, pull up on the
shoulder belt portion to tighten the lap
belt portion of the seatbelt.

6. Allow the seatbelt to retract and
remove any slack in the belt to securely
tighten the child restraint in the vehicle.

7. If the child restraint has a tether strap,
attach it.

E142534

42

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

8. Before placing the child in the seat,
forcibly move the seat forward and
back to make sure the seat is securely
held in place. To check this, grab the
seat at the belt path and attempt to
move it side to side and forward and
back. There should be no more than
1 in (2.5 cm) of movement.

9. Check from time to time to be sure that
there is no slack in the lap and shoulder
belt. The shoulder belt must be snug
to keep the lap belt tight during a crash.

We recommend checking with a NHTSA
Certified Child Passenger Safety
Technician to make certain the child
restraint is properly installed. In Canada,
check with Transport Canada for referral
to a Child Car Seat Clinic.

USING LOWER ANCHORS AND
TETHERS FOR CHILDREN

WARNING: Do not attach two child

safety restraints to the same anchor. In
a crash, one anchor may not be strong
enough to hold two child safety restraint
attachments and may break, causing
serious injury or death.

WARNING: Depending on where
you secure a child restraint, and
depending on the child restraint design,
you may block access to certain seatbelt
buckle assemblies and LATCH lower
anchors, rendering those features
potentially unusable. To avoid risk of
injury, make sure occupants only use
seating positions where they are able to
be properly restrained.

The Lower Anchors and Tethers for
CHildren (LATCH) system has three
vehicle anchor points:

• Two lower anchors where the vehicle
seat backrest and seat cushion meet,
called the seat bight.

• One top tether anchor behind that
seating position.

LATCH compatible child restraints have
two rigid or webbing mounted
attachments. These attachments connect
to the two lower anchors at the LATCH
equipped seating positions in your vehicle.
This type of attachment method
eliminates the need to use seatbelts to
attach the child restraint.

However, you can still use the seatbelt to
attach the child restraint if the lower
anchors are not used. For forward-facing
child restraints, you must also attach the
top tether strap to the proper top tether
anchor if a top tether strap has been
provided with your child restraint.

Follow the instructions later in this chapter
on attaching child restraints with tether
straps.

INSTALLING A CHILD RESTRAINT
IN A CENTER SEAT

WARNING: The standardized

spacing for LATCH lower anchors is 11 in
(280 mm) center to center. Do not use
LATCH lower anchors for the center
seating position unless the child restraint
manufacturer's instructions permit and
specify using anchors spaced at least as
far apart as those in this vehicle.

The lower anchors at the center of the
second row rear seat are spaced 25.7 in
(652 mm) apart. The standardized spacing
for LATCH lower anchors is 11 in (280 mm)
center to center.

43

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

You cannot install a child restraint with
rigid LATCH attachments at the center
seating position. You can only use LATCH
compatible child restraints with
attachments on belt webbing at this
seating position provided that the child
restraint manufacturer's instructions
permit use with the anchor spacing stated.
Do not attach a child restraint to any lower
anchor if another child restraint is attached
to that anchor.

Each time you use the child restraint, check
that the seat is properly attached to the
lower anchors and tether anchor, if
applicable. Tug the child restraint from side
to side and forward and back where it is
secured to the vehicle. The seat should
move less than 1 in (2.5 cm).

If you did not properly anchor the child
restraint, the risk of a child being injured in
a crash greatly increases.

COMBINING THE SEATBELT AND
LOWER ANCHORS FOR
ATTACHING CHILD RESTRAINTS

When used in combination, you may attach
either the seatbelt or the LATCH lower
anchors first, provided a proper installation
is achieved. Attach the tether strap
afterward, if it is included with the child
restraint.

USING TETHER STRAPS

Many forward-facing child restraints
include a tether strap which extends from
the back of the child restraint and hooks
to an anchoring point called the top tether
anchor. Tether straps are available as an
accessory for many older child restraints.

Contact the manufacturer of your child
restraint for information about ordering a
tether strap, or to obtain a longer tether
strap if the tether strap on your child
restraint does not reach the appropriate
top tether anchor in the vehicle.

Attach the tether strap only to the
appropriate tether anchor. The tether strap
may not work properly if attached
somewhere other than the correct tether
anchor.

If you install a child restraint with rigid
LATCH attachments, do not tighten the
tether strap enough to lift the child
restraint off the vehicle seat cushion when
the child is seated in it. Keep the tether
strap just snug without lifting the front of
the child restraint. Keeping the child
restraint just touching the vehicle seat
gives the best protection in a severe crash.

Once you have installed the child restraint
using either the seatbelt, the lower anchors
of the LATCH system, or both, you can
attach the top tether strap.

ATTACHING THE FRONT SEAT
TETHER STRAP

Regular Cab

E175295

1. Route the child restraint tether strap
over the back of the seat and under the
head restraint.

44

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

Note: For vehicles with adjustable head

restraints, route the tether strap under the
head restraint and between the head
restraint posts. Otherwise, route the tether
strap over the top of the seat backrest.

2. Locate the correct anchor for the
selected seating position. You may
need to pull the seat backrest forward
to access the tether anchors. Make sure
the seat is locked in the upright position
before installing the child restraint.

3. Clip the tether strap to the anchor.

4. Tighten the child restraint tether strap
according to the manufacturer's
instructions.

If you incorrectly clip the tether strap, the
child restraint may not be retained properly
in the event of a crash.

If you did not properly anchor the child
restraint, the risk of a child being injured in
a crash greatly increases.

If your child restraint system has a tether
strap, and the child restraint manufacturer
recommends its use, we also recommend
its use.

ATTACHING THE REAR SEAT
TETHER STRAP

Crew Cab and Super Cab

E309318

There are three loops of webbing above
the back of the rear seat. Use these loops
as routing loops and anchor loops for up
to three child restraint tether straps.

For example, you can use the center loop
as a routing loop for a child restraint in the
center rear seat and as an anchoring loop
for child restraints installed in the
outermost rear seats.

Many tether straps cannot be tightened if
the tether strap is hooked to the loop
directly behind the child restraint.

To provide a tight tether strap:

E309384

1. Route the vehicle tether loop between
the head restraint posts, then route the
child restraint tether strap through the
loop, forward of the head restraint.

2. Hook the strap to the vehicle tether
anchor loop in the adjacent seating
position. If using the driver side, pass
the strap behind the shoulder belt for
the center seat. Put the tether strap
through the routing loop. The head
restraint support post holds the child
restraint tightly, but the head restraint
post is not strong enough to hold the
child restraint during a crash.

3. Tighten the tether strap according to
the child restraint manufacturer's
instructions.

45

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

If you did not properly anchor the child
restraint, the risk of a child being injured in
a crash greatly increases.

If your child restraint system has a tether
strap, and the child restraint manufacturer
recommends its use, we also recommend
its use.

BOOSTER SEATS

Use a belt-positioning booster seat for
children who have outgrown or no longer
properly fit in a child restraint and meet
the following criteria.

• Generally children who are less than
57 in (1.45 m) tall.

• Are greater than age four (4) and less
than age twelve (12).

• Are between 40 lb (18 kg) and 80 lb
(36 kg) and upward to 100 lb (45 kg).

Many state and provincial laws require that
children use approved booster seats until
they reach age eight, a height of 57 in
(1.45 m) tall, or 80 lb (36 kg).

Booster seats should be used until you can
answer yes to all of these questions when
seated without a booster seat:

E142595

• Can the child sit all the way back
against their vehicle seat backrest with
knees bent comfortably at the edge of
the seat cushion?

• Can the child sit without slouching?

• Does the lap belt rest low across the

hips?

• Is the shoulder belt centered on the
shoulder and chest?

• Can the child stay seated like this for
the whole trip?

Always use booster seats in conjunction
with your vehicle lap and shoulder belt.

Types of Booster Seats

E68924

• Backless booster seats

If your backless booster seat has a
removable shield, remove the shield.

If a vehicle seating position has a low seat
backrest or no head restraint, a backless
booster seat may place your child's head,
as measured at the tops of the ears, above
the top of the seat. In this case, move the
backless booster to another seating
position with a higher seat backrest or
head restraint and lap and shoulder belts,
or consider using a high-back booster seat.

46

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

E70710

• High-back booster seats

If, with a backless booster seat, you cannot
find a seating position that adequately
supports your child's head, a high-back
booster seat would be a better choice.

Children and booster seats vary in size and
shape. Choose a booster that keeps the
lap belt low and snug across the hips,
never up across the stomach, and lets you
adjust the shoulder belt to cross the chest
and rest snugly near the center of the
shoulder.

The following drawings compare the ideal
fit to a shoulder belt uncomfortably close
to the neck and a shoulder belt that could
slip off the shoulder. The drawings also
show how the lap belt should be low and
snug across the child's hips.

E142596

E142597

47

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

If the booster seat slides on the vehicle
seat upon which it is being used, placing a
rubberized mesh sold as shelf or carpet
liner under the booster seat may improve
this condition. Do not use any item thicker
than this under the booster seat. Check
with the booster seat manufacturer's
instructions.

CHILD SAFETY LOCKS

WARNING: You cannot open the

rear doors from inside if you have put the
child safety locks on.

E112197

A child safety lock is on the rear edge of
each rear door. You must switch the child
safety lock separately on each door.

Left-Hand Side

Turn the key counterclockwise to switch
the child lock on and clockwise to switch
it off.

Right-Hand Side

Turn the key clockwise to switch the child
lock on and counterclockwise to switch it
off.

48

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Child Safety

SEATBELT PRECAUTIONS

WARNING: Always drive and ride

with your seatback upright and the lap
belt snug and low across the hips.

WARNING: Children must always

be properly restrained.

WARNING: Do not allow a
passenger to hold a child on their lap
when your vehicle is moving. Failure to
follow this instruction could result in
personal injury or death in the event of a
sudden stop or crash.

WARNING: All occupants of your
vehicle, including the driver, should
always properly wear their seatbelts,
even when an airbag supplemental
restraint system is provided. Failure to
properly wear your seatbelt could
seriously increase the risk of injury or
death.

WARNING: It is extremely
dangerous to ride in a cargo area, inside
or outside of a vehicle. In a crash, people
riding in these areas are more likely to be
seriously injured or killed. Do not allow
people to ride in any area of your vehicle
that is not equipped with seats and
seatbelts. Make sure everyone in your
vehicle is in a seat and properly using a
seatbelt. Failure to follow this warning
could result in serious personal injury or
death.

WARNING: In a rollover crash, an
unbelted person is significantly more
likely to die than a person wearing a
seatbelt.

WARNING: Each seating position
in your vehicle has a specific seatbelt
assembly made up of one buckle and
one tongue designed to be used as a pair.
Use the shoulder belt on the outside
shoulder only. Never wear the shoulder
belt under the arm. Never use a single
seatbelt for more than one person.

WARNING: Even with advanced
restraints systems, properly restrain
children 12 and under in a rear seating
position. Failure to follow this could
seriously increase the risk of injury or
death.

WARNING: Seatbelts and seats
may be hot in a vehicle that is in the
sunshine. The hot seatbelts or seats may
burn a small child. Check seat covers and
buckles before you place a child
anywhere near them.

WARNING: If your vehicle is
involved in a crash, have the seatbelts
and associated components inspected
as soon as possible. Failure to follow this
instruction could result in personal injury
or death.

All seating positions in this vehicle have
seatbelts. All occupants of the vehicle
should properly wear their seatbelts, even
when an airbag supplemental restraint
system is provided.

The seatbelt system consists of:

• Lap and shoulder seatbelts.

• A shoulder seatbelt with automatic

locking mode, except driver seatbelt.

• Height adjusters at the front outermost
seating positions.

• Seatbelt pretensioners at the front
outermost and rear outermost seating
positions.

49

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Seatbelts

A seatbelt warning light and
chime.

Crash sensors and monitoring
system with readiness indicator.

The seatbelt pretensioners are designed
to tighten the seatbelts when activated. In
frontal and near-frontal crashes, the
seatbelt pretensioners may be activated
alone or, if the crash is of sufficient severity,
together with the front airbags. In side
crashes and rollovers, the pretensioners
will be activated when the Safety Canopy
is activated.

FASTENING AND UNFASTENING THE SEATBELTS

This applies to all seating positions, except
for the front center position of Super Cab
and Crew Cab.

E142587

1. Insert the seatbelt tongue into the
buckle until you hear a snap and feel it
latch.

E142588

2. Press the button to release the
seatbelt.

Using the Seatbelt With Cinch
Tongue

This applies to the front center seating
position of Super Cab and Crew Cab.

The cinch tongue slides up and down the
seatbelt webbing when you stow the
seatbelt or when you put the seatbelts on.
When you buckle the seatbelt, the cinch
tongue allows you to shorten the lap
portion, but pinches the webbing to keep
the lap portion from getting longer. The
cinch tongue is designed to slip during a
crash, so wear the shoulder belt properly
and do not allow any slack in either the lap
or shoulder portions.

Fastening the Cinch Tongue

WARNING: Always drive and ride

with your seatback upright and the lap
belt snug and low across the hips.

1. Pull the seatbelt from the retractor so
that the shoulder belt portion of the
seatbelt crosses your shoulder and
chest.

2. Make sure the belt is not twisted. If the
belt is twisted, remove the twist.

50

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Seatbelts

3. Insert the belt tongue into the proper
buckle for your seating position until
you hear a snap and feel it latch.

4. Make sure you securely fasten the
tongue to the buckle by pulling on the
tongue.

While you are fastened in the seatbelt, the
seatbelt with a cinch tongue adjusts to
your movement. However, if you brake
hard, turn hard, or if your vehicle receives
an impact of 5 mph (8 km/h) or more, the
seatbelt locks and helps reduce your
forward movement.

SENSITIVE LOCKING MODE

WHAT IS SENSITIVE LOCKING
MODE

Sensitive locking mode is a seatbelt
retractor feature that allows shoulder belt
length adjustment according to your
movements and locking in response to
vehicle movement.

HOW DOES SENSITIVE LOCKING
MODE WORK

If the driver suddenly brakes, turns a corner
sharply, or the vehicle receives an impact
of about 5 mph (8 km/h) or more, the
seatbelts lock to help reduce forward
movement of the driver and passengers.

In addition, the seatbelt retractor locks if
you pull the seatbelt webbing out too
quickly. If the retractor locks, slowly lower
the height adjuster to allow the seatbelt
to retract.

If the retractor does not unlock, pull the
seatbelt out slowly then feed a small
length of webbing back toward the stowed
position.

For rear seatbelts, recline the rear seat
backrest or push the seat backrest cushion
away from the seatbelt. Feed a small
length of webbing back toward the stowed
position.

AUTOMATIC LOCKING MODE

WHAT IS AUTOMATIC LOCKING
MODE

This feature keeps the seatbelts
pre-locked. The belt still retracts to remove
any slack in the shoulder belt.

WHEN TO USE AUTOMATIC
LOCKING MODE

Use this mode any time you install a child
restraint in a front seating position in a
Regular Cab, Super Cab, Crew Cab or any
rear seating position of a Super Cab or
Crew Cab. The optional front seat center
seatbelt in the Super Cab and Crew Cab
has a cinch mechanism. Properly restrain
children 12 years old and under in a rear
seat whenever possible. See Child Safety
(page 35).

Note: Automatic locking mode is not
available on the driver seatbelt.

51

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Seatbelts

ENGAGING AUTOMATIC LOCKING
MODE

E142591

1. Fasten the combination lap and
shoulder belt.

2. Grasp the shoulder portion and pull
downward until you pull the entire belt
out.

3. Allow the belt to retract. As the belt
retracts, you will hear a clicking sound.
This indicates the seatbelt is now in the
automatic locking mode.

DISENGAGING AUTOMATIC
LOCKING MODE

Unbuckle the combination lap and
shoulder belt and allow it to retract
completely to disengage the automatic
locking mode and activate the vehicle
sensitive locking mode.

ADJUSTING THE SEATBELTS DURING PREGNANCY

WARNING: Always ride and drive

with your seatback upright and properly
fasten your seatbelt. Fit the lap portion
of the seatbelt snugly and low across
the hips. Position the shoulder portion of
the seatbelt across your chest. Pregnant
women must follow this practice. See
the following figure.

E142590

Pregnant women should always wear their
seatbelt. Position the lap belt portion of a
combination lap and shoulder belt low
across the hips below the belly and worn
as tight as comfort allows. Position the
shoulder belt to cross the middle of the
shoulder and the center of the chest.

ADJUSTING THE SEATBELT HEIGHT

WARNING: Position the seatbelt

height adjuster so that the seatbelt rests
across the middle of your shoulder.
Failure to adjust the seatbelt correctly
could reduce its effectiveness and
increase the risk of injury in a crash.

52

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Seatbelts

E145664

1. Pull the button and slide the height
adjuster up or down.

2. Release the button and pull down on
the height adjuster to make sure it is
locked in place.

ADJUSTING THE SEATBELT LENGTH

E162708

1. Pull some seatbelt webbing out of the
shoulder belt retractor.

2. While holding the webbing below the
tongue, grasp the metal tip of the
tongue so that it is parallel to the
webbing and slide the tongue up.

3. Provide enough lap belt length so that
the tongue can reach the buckle.

SEATBELT REMINDER

HOW DOES THE SEATBELT
REMINDER WORK

This feature supplements the seatbelt
warning function. It provides additional
reminders by intermittently sounding a
tone and illuminating the seatbelt warning
light when you are in the driver seat and a
seatbelt is unbuckled.

53

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Seatbelts

ThenIf

The Belt-Minder feature will not activate.

You buckle your seatbelt before you switch

the ignition on or less than 1-2 minutes

elapse after you switch the ignition on...

The Belt-Minder feature activates - the

seatbelt warning light illuminates and a

warning tone sounds for six seconds every

25 seconds, repeating for about five

minutes or until you buckle your seatbelt.

You do not buckle your seatbelt before your

vehicle reaches at least 6 mph (9.7 km/h)

and 1-2 minutes elapse after you switch the

ignition on...

The Belt-Minder feature activates - the

seatbelt warning light illuminates and the

warning tone sounds for six seconds every

25 seconds, repeating for about five

minutes or until you buckle your seatbelt.

The driver seatbelt is unbuckled for about

one minute while the vehicle is traveling at

least 6 mph (9.7 km/h) and more than 1-2

minutes elapse after you switch the ignition

on...

54

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Seatbelts

SEATBELT REMINDER
INDICATORS

A warning lamp illuminates if the ignition
is on, a front seat is occupied and the
seatbelt has not been fastened.

The warning lamp illuminates
until you fasten your seatbelt.

SEATBELT REMINDER AUDIBLE
WARNINGS

A warning tone sounds if the warning lamp
illuminates and your vehicle exceeds a
relatively low speed.

The warning tone sounds for up to five
minutes or until you fasten your seatbelt.

SWITCHING THE SEATBELT
REMINDER ON AND OFF

WARNING: While the system

allows you to deactivate it, this system
is designed to improve your chances of
being safely belted and surviving an
accident. We recommend you leave the
system activated for yourself and others
who may use the vehicle.

Note: The driver and front passenger
warnings switch off independently. When
you perform this procedure for one seating
position, do not buckle the other position as
this cancels the process.

Note: If you are using MyKey, you cannot
disable the seatbelt reminder. Also, if the
seatbelt reminder has been previously
disabled, it will be re-enabled during the use
of MyKey. See MyKey™ (page 77).

Read Steps 1 - 4 before proceeding with
the programming procedure.

Make sure that:

• The parking brake is set.

• The transmission is in park (P).

• The ignition is off.

• The driver and front passenger

seatbelts are unfastened.

1. Switch the ignition on. Do not start the
engine.

2. Wait about one minute until the
seatbelt warning light switches off.
After Step 2, wait an additional five
seconds before proceeding with Step

3. Once you start Step 3, you must
complete the procedure within 30
seconds.

3. For the seating position you are
switching off, buckle then unbuckle the
seatbelt three times at a moderate
speed, ending in the unbuckled state.
After Step 3, the seatbelt warning light
switches on.

4. When the seatbelt warning light is on,
buckle then unbuckle the seatbelt.
After Step 4, the seatbelt warning light
flashes for confirmation.

This switches the feature off for that
seating position if it is currently on.

This switches the feature on for that
seating position if it is currently off.

CHECKING THE SEATBELTS

Check the seatbelts and child restraints
periodically to make sure they work
properly and are not damaged. Make sure
there are no nicks, tears or cuts. Replace if
necessary.

Check the following seatbelt assemblies
after a crash.

• Retractors.

• Buckles.

• Front seatbelt buckle assemblies.

55

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Seatbelts

• Shoulder belt height adjusters.

• Shoulder belt guide on seat backrest.

• Child restraint LATCH and tether

anchors.

• Attaching hardware.
Read the child restraint manufacturer's

instructions for additional inspection and
maintenance information specific to the
child restraint.

We recommend that all seatbelt
assemblies in use in vehicles involved in a
crash be replaced. However, if the crash
was minor and an authorized dealer finds
that the belts do not show damage and
continue to operate properly, they do not
need to be replaced. Seatbelt assemblies
not in use during a crash should also be
checked and replaced if either damage or
improper operation is noted.

Properly care for seatbelts. See Cleaning

Seatbelts (page 426).

SEATBELT EXTENSIONS

WARNING: Persons who fit into

the vehicle's seatbelt should not use an
extension. Unnecessary use could result
in serious personal injury in the event of
a crash.

WARNING: Only use extensions
provided free of charge by our dealers.
The dealer will provide an extension
designed specifically for this vehicle,
model year and seating position. The use
of an extension intended for another
vehicle, model year or seating position
may not offer you the full protection of
your vehicle's seatbelt restraint system.

WARNING: Never use seatbelt
extensions to install child restraints.

WARNING: Do not use extensions
to change the way the seatbelt fits
across the torso, over the lap or to make
the seatbelt buckle easier to reach.

If, because of body size or driving position,
it is not possible to properly fasten the
seatbelt over your lap and shoulder, an
extension that is compatible with the
seatbelts is available free of charge from
our dealers. Only use our seatbelt
extensions made by the original equipment
seatbelt manufacturer with our seatbelts.
Ask your authorized dealer if your extension
is compatible with your vehicle restraint
system.

56

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Seatbelts

HOW DO THE FRONT AIRBAGS WORK

E151127

The driver and front passenger airbags
deploy during significant frontal and near
frontal crashes.

The driver and passenger front airbag
system consists of:

• Driver and passenger airbag modules.

• Crash sensors and monitoring system

with readiness indicator. See Crash
Sensors and Airbag Indicator (page

65).

The airbags are a supplemental restraint
system and are designed to work with the
seatbelts to help protect the driver and
right front passenger from certain upper
body injuries. Airbags do not inflate slowly.
There is a risk of injury from a deploying
airbag.

Note: You will hear a loud bang and see a
cloud of harmless powdery residue if an
airbag deploys. This is normal.

The airbags inflate and deflate rapidly
upon activation. After airbag deployment,
it is normal to notice a smoke-like, powdery
residue or smell the burnt propellant. This
may consist of cornstarch, talcum powder,
to lubricate the bag, or sodium compounds

(for example, baking soda) that result from
the combustion process that inflates the
airbag. Small amounts of sodium
hydroxide may be present which may
irritate the skin and eyes, but none of the
residue is toxic.

Contact with a deploying airbag may cause
abrasions or swelling. Temporary hearing
loss is also a possibility as a result of the
noise associated with a deploying airbag.

Because airbags must inflate rapidly and
with considerable force, there is the risk of
death or serious injuries such as fractures,
facial and eye injuries or internal injuries,
particularly to occupants who are not
properly restrained or are otherwise out of
position at the time of airbag deployment.
Thus, it is extremely important that
occupants be properly restrained as far
away from the airbag module as possible
while maintaining vehicle control.

Routine maintenance of the airbags is not
required.

HOW DO THE SIDE AIRBAGS WORK

WARNING: Do not place objects

or mount equipment on or near the
airbag cover, on the side of the front or
rear seatbacks, or in areas that may
come into contact with a deploying
airbag. Failure to follow these
instructions may increase the risk of
personal injury in the event of a crash.

WARNING: Accessory seat covers
not released by Ford Motor Company
could prevent the deployment of the
airbags and increase the risk of injuries
in a crash.

57

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

WARNING: Do not lean your head

on the door. The side airbag could injure
you as it deploys from the side of the
seatback.

The side airbags are on the outermost side
of the seat backrests of the front seats. In
certain sideways crashes or rollovers, the
airbags will be inflated. The airbag was
designed to inflate between the door panel
and occupant to further enhance the
protection provided to occupants in side
impact crashes.

E152533

The system consists of the following:

• A label or embossed side panel
indicating that side airbags are fitted
to your vehicle.

• Side airbags inside the driver and front
passenger seat backrests.

• Crash sensors and monitoring system
with readiness indicator. See Crash
Sensors and Airbag Indicator (page

65).

HOW DOES THE SAFETY CANOPY™ WORK

WARNING: Do not place objects

or mount equipment on or near the
headliner at the siderail that may come
into contact with a deploying curtain
airbag. Failure to follow these
instructions may increase the risk of
personal injury in the event of a crash.

WARNING: Do not lean your head
on the door. The curtain airbag could
injure you as it deploys from the
headliner.

WARNING: To reduce risk of injury,
do not obstruct or place objects in the
deployment path of the airbag.

The Safety Canopy deploys during
significant side crashes or when a certain
likelihood of a rollover event is detected
by the rollover sensor. The Safety Canopy
is mounted to the roof side-rail sheet
metal, behind the headliner, above each
row of seats. In certain sideways crashes
or rollover events, the Safety Canopy will
be activated, regardless of which seats are
occupied. The Safety Canopy inflates
between the side window area and
occupants to further enhance protection
provided in side impact crashes and
rollover events.

58

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

E75004

The system consists of the following:

• Safety Canopy curtain airbags above
the trim panels over the front and rear
side windows identified by a label or
wording on the headliner or roof-pillar
trim.

• A flexible headliner which opens above
the side doors to allow air curtain
deployment

· Crash sensors and monitoring
system with a readiness
indicator. See Crash Sensors

and Airbag Indicator (page 65).

Properly restrain children 12 years old and
under in the rear seats. The Safety Canopy
will not interfere with children restrained
using a properly installed child or booster
seat because it is designed to inflate
downward from the headliner above the
doors along the side window opening.

AIRBAG PRECAUTIONS

WARNING: Airbags do not inflate

slowly or gently, and the risk of injury
from a deploying airbag is the greatest
close to the trim covering the airbag
module.

WARNING: All occupants of your
vehicle, including the driver, should
always properly wear their seatbelts,
even when an airbag supplemental
restraint system is provided. Failure to
properly wear your seatbelt could
seriously increase the risk of injury or
death.

WARNING: Properly secure
children 12 years old and under in a rear
seating position whenever possible. If
you are unable to properly secure all
children in a rear seating position,
properly secure the largest child on the
front seat. If you must use a forward
facing child restraint on the front seat,
move the seat as far back as possible.
Failure to follow these instructions could
result in personal injury or death.

WARNING: Do not place your arms
on the airbag cover or through the
steering wheel. Failure to follow this
instruction could result in personal injury.

WARNING: Keep the areas in front
of the airbags free from obstruction. Do
not affix anything to or over the airbag
covers. Objects could become projectiles
during airbag deployment. Failure to
follow this instruction could result in
personal injury or death.

WARNING: To reduce risk of injury,
do not obstruct or place objects in the
deployment path of the airbag.

WARNING: Do not place a
rearward facing child restraint in front of
an active airbag. Failure to follow this
instruction could result in personal injury
or death.

59

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

WARNING: Do not attempt to

service, repair, or modify the
supplementary restraint system or
associated components. Failure to
follow this instruction could result in
personal injury or death.

WARNING: Several airbag system
components get hot after inflation. To
reduce the risk of injury, do not touch
them after inflation.

WARNING: If a supplementary
restraint system component has
deployed, it will not function again. Have
the system and associated components
inspected as soon as possible. Failure to
follow this instruction could result in
personal injury or death.

SWITCHING THE PASSENGER AIRBAG ON AND OFF (IF EQUIPPED)

WARNING: Even with advanced

restraints systems, properly restrain
children 12 and under in a rear seating
position. Failure to follow this could
seriously increase the risk of injury or
death.

WARNING: The front passenger
airbag is not designed to offer protection
to an occupant in the center seating
position.

WARNING: Your vehicle may have
an airbag deactivation switch. Before
driving, always look at the switch to
make sure it is in the appropriate
position. Failure to put the switch in the
proper position can increase the risk of
serious injury or death in a crash.

E181984

The front passenger airbag on and off
switch has indicators that illuminate,
indicating that the front passenger frontal
airbag is either on or off. The indicators are
near the center of the instrument panel.

Note: The indicators illuminate for a short
period of time when you switch the ignition
on to confirm it is functional.

Passenger AirbagPassenger Airbag Status

Indicator

Switch Position

DisabledOFF: IlluminatedOff

ON: Not Illuminated

EnabledOFF: Not IlluminatedOn

ON: Illuminated

60

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

Switching the Passenger Airbag
Off

WARNING: If the light does not

illuminate when the passenger airbag
switch is off and you switch the ignition
on, have the passenger airbag switch
serviced immediately by a qualified
technician.

WARNING: To avoid switching on
the airbag, always remove the ignition
key with the switch in the off position.

WARNING: If your vehicle has rear
seats, always transport children who are
12 and younger in the rear seat. Always
use seatbelts and child restraints
properly. Do not place a child in a rear
facing infant seat in the front seat unless
your vehicle is equipped with an airbag
on and off switch and the passenger
airbag is turned off. This is because the
back of the infant seat is too close to the
inflating airbag and the risk of a fatal
injury to the infant when the airbag
inflates is substantial.

The passenger airbag on and off switch is
in the glovebox.

E181522

1. Insert the ignition key, turn the switch
to OFF and hold in OFF while removing
the key.

2. When you switch the ignition on, the
passenger airbag off light illuminates
briefly, momentarily shuts off and then
switches back on. This indicates that
the passenger airbag is deactivated.

Switching the Passenger Airbag
On

WARNING: The seatbelts for the

driver and right front passenger seating
positions are specifically designed to
operate together with the airbags in
certain types of crashes. When you
switch off your airbag, you not only lose
the protection of the airbag, you also
may reduce the effectiveness of your
seatbelt system. If the passenger does
not meet the requirements stated in the
National Highway Traffic Safety
Administration or Transport Canada
deactivation criteria, switching off the
airbag can increase the risk of serious
injury or death in a crash.

WARNING: If your vehicle has rear
seats, always transport children who are
12 and younger in the rear seat. Always
use seatbelts and child restraints
properly. Do not place a child in a rear
facing infant seat in the front seat unless
your vehicle is equipped with an airbag
on and off switch and the passenger
airbag is turned off. This is because the
back of the infant seat is too close to the
inflating airbag and the risk of a fatal
injury to the infant when the airbag
inflates is substantial.

61

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

WARNING: If the passenger airbag

off light is illuminated when the
passenger airbag switch is on and the
ignition is on, have the passenger airbag
switch serviced immediately by a
qualified technician.

The passenger airbag remains off until you
switch it back on.

E181521

1. Insert the ignition key and turn the
switch to ON.

2. The passenger airbag off light briefly
illuminates when you switch the
ignition on. This indicates that the
passenger airbag is operational.

The passenger side airbag should always
be on, and the passenger airbag off light
should not be illuminated, unless the
passenger is a person who meets the
requirements stated either in Category 1, 2
or 3 of the National Highway Traffic Safety
Administration or Transport Canada
deactivation criteria which follows.

The vast majority of drivers and passengers
are much safer with an airbag than
without. To do their job and reduce the risk
of life threatening injuries, airbags must
open with great force, and this force can
pose a potentially deadly risk in some
situations, particularly when a front seat
occupant is not properly buckled up. The
most effective way to reduce the risk of
unnecessary airbag injuries without
reducing the overall safety of the vehicle
is to make sure all occupants are properly
restrained in the vehicle, especially in the
front seat. This provides the protection of
seatbelts and permits the airbags to
provide the additional protection they were
designed to provide. If you choose to
deactivate your airbag, you are losing the
very significant risk reducing benefits of
the airbag and you are also reducing the
effectiveness of the seatbelts. Seatbelts
in modern vehicles are designed to work
as a safety system with the airbags.

National Highway Traffic Safety
Administration Deactivation
Criteria-Excluding Canada

WARNING: This vehicle has special

energy management seatbelts for the
driver and right front passenger. These
particular seatbelts are specifically
designed to work with airbags to help
reduce the risk of injury in a crash. The
energy management seatbelt gives or
releases additional seatbelt webbing in
some accidents to reduce the
concentration of force on an occupant's
chest and to reduce the risk of certain
bone fractures and injuries to underlying
organs. In a crash, if the airbag is off, this
energy management seatbelt might
permit the passenger wearing the
seatbelt to move forward enough to
have a serious or fatal injury. The more

62

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

severe the crash, and the heavier the
occupant, the greater the risk. Make sure
the airbag is on for any passenger who
does not qualify under the National
Highway Traffic Safety Administration
deactivation criteria.

1. Infant. An infant, less than 1 year old,
must ride in the front seat because:

• The vehicle has no rear seat.

• The vehicle has a rear seat too small

to accommodate a rear-facing infant
seat.

• The infant has a medical condition
which, according to the infant's
physician, makes it necessary for the
infant to ride in the front so that the
driver can constantly monitor the
child's condition.

2. Children age 1 to 12. Children age 1 to

12 must ride in the front seat because:

• The vehicle has no rear seat.

• Although children ages 1 to 12 ride in

the rear seat(s) whenever possible,
children ages 1 to 12 sometimes must
ride in the front because no space is
available in the rear seat(s) of your
vehicle.

• The child has a medical condition
which, according to the child's
physician, makes it necessary for the
child to ride in the front seat so that the
driver can constantly monitor the
child's condition.

3. Medical condition. A passenger has a

medical condition which, according to his
or her physician:

• Causes the passenger airbag to pose
a special risk for the passenger.

• Makes the potential harm from the
passenger airbag in a crash greater
than the potential harm from turning
off the airbag and allowing the
passenger, even if belted, to hit the
dashboard or windshield in a crash.

Transport Canada Deactivation
Criteria-Canada Only

WARNING: This vehicle has special

energy management seatbelts for the
driver and right front passenger. These
particular seatbelts are specifically
designed to work with airbags to help
reduce the risk of injury in a crash. The
energy management seatbelt gives or
releases additional seatbelt webbing in
some accidents to reduce the
concentration of force on an occupant's
chest and to reduce the risk of certain
bone fractures and injuries to underlying
organs. In a crash, if the airbag is off, this
energy management seatbelt might
permit the passenger wearing the
seatbelt to move forward enough to
have a serious or fatal injury. The more
severe the crash, and the heavier the
occupant, the greater the risk. Make sure
the airbag is on for any passenger who
does not qualify under the Transport
Canada deactivation criteria.

1. Infant: An infant, less than 1 year old,

must ride in the front seat because:

63

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

• The vehicle has no rear seat.

• The rear seat in my vehicle cannot

accommodate a rear-facing infant
seat.

• The infant has a medical condition
which, according to the infant's
physician, makes it necessary for the
infant to ride in the front seat so that
the driver can monitor the infant's
condition.

2. Children age 12 or under: Children age

12 or under must ride in the front seat
because:

• The vehicle has no rear seat.

• Although children age 12 and under ride

in the rear seat whenever possible,
children age 12 and under have no
option but to sometimes ride in the
front seat because rear seat space is
insufficient.

• The child has a medical condition that,
according to the child's physician,
makes it necessary for the child to ride
in the front seat so that the driver can
monitor the child's condition.

3. Medical condition: A passenger has a

medical condition that, according to his or
her physician:

• Poses a special risk for the passenger
if the airbag deploys.

• Makes the potential harm from the
passenger airbag deployment greater
than the potential harm from turning
off the airbag and experiencing a crash
without the protection offered by the
airbag.

PROPERLY ADJUSTING THE DRIVER AND FRONT PASSENGER SEATS

WARNING: National Highway

Traffic Safety Administration (NHTSA)
recommends a minimum distance of at
least 10 in (25 cm) between an
occupant's chest and the driver airbag
module.

To properly position yourself away from
the airbag:

• Move your seat to the rear as far as you
can while still reaching the pedals
comfortably.

• Recline the seat slightly one or two
degrees from the upright position.

After all occupants have adjusted their
seats and put on seatbelts, it is very
important that they continue to sit
properly. Properly seated occupants sit
upright, lean against the seat backrest, and
center themselves on the seat cushion,
with their feet comfortably extended on
the floor. Sitting improperly can increase
the chance of injury in a crash event. For
example, if an occupant slouches, lies
down, turns sideways, sits forward, leans
forward or sideways, or puts one or both
feet up, the chance of injury during a crash
greatly increases.

CHILDREN AND AIRBAGS

WARNING: Do not place a

rearward facing child restraint in front of
an active airbag. Failure to follow this
instruction could result in personal injury
or death.

64

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

E142846

Children must always be properly
restrained. Accident statistics suggest that
children are safer when properly restrained
in the rear seating positions than in the
front seating position. Failure to follow
these instructions may increase the risk of
injury in a crash.

If two adults and a child occupy a vehicle
without rear seats, properly restrain the
child in the center front seat unless doing
so would interfere with driving your vehicle.
This provides lap and shoulder belt
protection for all occupants, and airbag
protection for the adults. A child or infant
properly restrained in the center front seat
should not incur risk of serious injury from
the airbags.

CRASH SENSORS AND AIRBAG INDICATOR

WARNING: Modifying or adding

equipment to the front of your vehicle
could affect the performance of the
airbag system, increasing the risk of
injury. This includes the hood, bumper
system, frame, front body structure, tow
hooks, hood pins, push bar and
snowplows.

Your vehicle has a collection of crash and
occupant sensors. These sensors provide
information to the restraints control
module which activates the following:

• Seatbelt pretensioners.

• Adaptive steering column.

• Driver airbag.

• Passenger airbag.

• Seat mounted side airbags.

• Safety Canopy.

Based on the type of crash, the restraints
control module deploys the appropriate
safety devices.

The restraints control module also
monitors the readiness of the above safety
devices plus the crash and occupant
sensors. The readiness of the safety
system is indicated by a warning indicator
light in the instrument cluster or by a
backup tone if the warning light is not
working. Routine maintenance of the
airbag is not required.

A difficulty with the system is indicated by
one or more of the following:

The readiness light will not
illuminate immediately after you
switch the ignition on.

• The readiness light either flashes or
stays on.

• You hear a series of five tones. The
tone pattern repeats periodically until
the problem, the light or both are
repaired.

If any of these things happen, even
intermittently, have the supplemental
restraint system serviced immediately.
Unless serviced, the system may not
function properly in the event of a crash.

65

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

The fact that the seatbelt pretensioners
or front airbags did not activate for both
front seat occupants in a crash does not
mean that something is wrong with the
system. Rather, it means the restraints
control module determined the accident
conditions (crash severity, seatbelt usage)
were not appropriate to activate these
safety devices.

• The front airbags activate only in
frontal and near-frontal crashes. Front
airbags may activate in rollovers, side
impacts or rear impacts if the crash
causes sufficient frontal deceleration.

• The adaptive steering column activates
only in frontal and near-frontal crashes.
It may activate in rollovers, side
impacts or rear impacts if the crash
causes sufficient frontal deceleration.

• The seatbelt pretensioners activate in
frontal, near-frontal and side crashes,
and in rollovers.

• The side airbags inflate in certain side
impact crashes or rollover events. Side
airbags may activate in other types of
crashes if the vehicle experiences
sufficient sideways motion or
deformation.

• The Safety Canopy inflates in certain
side impact crashes or rollover events.
The Safety Canopy may activate in
other types of crashes if the vehicle
experiences sufficient sideways motion
or deformation, or a certain likelihood
of rollover.

DISPOSING OF AIRBAGS

Contact your authorized dealer as soon as
possible. Airbags must be disposed of by
qualified personnel.

66

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Airbags

WHAT IS 911 ASSIST

911 Assist is a SYNC system feature that
can call for help.

For more information, visit

www.owner.ford.com .

HOW DOES 911 ASSIST WORK

If a crash deploys an airbag, excluding knee
airbags and rear inflatable seatbelts, or
activates the fuel pump shut-off, your
vehicle may be able to contact emergency
services by dialing 911 through a paired and
connected Bluetooth®-enabled phone.

Not all crashes will deploy an airbag or
activate the fuel pump shut-off. If a
connected cell phone sustains damage or
loses its connection to SYNC during a
crash, SYNC will search for and try to
connect to a previously paired cell phone.
SYNC will then attempt to call the
emergency services.

Before making the call:

• SYNC provides about 10 seconds to
cancel the call. If you fail to cancel the
call, SYNC attempts to dial 911.

• SYNC says the following, or a similar
message: "SYNC will attempt to call
911, to cancel the call, press Cancel on
your screen or press and hold the
phone button on your steering wheel."

If you do not cancel the call and SYNC
makes a successful call a pre-recorded
message plays for the 911 operator. The
occupants in your vehicle are able to talk
with the operator. Be prepared to provide
your name, phone number and location
immediately because not all 911 systems
are capable of receiving this information
electronically.

During an emergency call the system
transmits vehicle data to the emergency
service.

EMERGENCY CALL REQUIREMENTS

WARNING: Do not wait for 911

Assist to make an emergency call if you
can do it yourself. Dial emergency
services immediately to avoid delayed
response time which could increase the
risk of serious injury or death after a
crash. If you do not hear 911 Assist within
five seconds of the crash, the system or
phone may be damaged or
non-functional.

WARNING: Always place your
phone in a secure location in your vehicle
so it does not become a projectile or get
damaged in a crash. Failure to do so may
cause serious injury to someone or
damage the phone which could prevent
911 Assist from working properly.

WARNING: Unless the 911 Assist
setting is set on before a crash, the
system will not dial for help which could
delay response time, potentially
increasing the risk of serious injury or
death after a crash.

• SYNC is powered and working properly
at the time of the incident and
throughout feature activation and use.

• The 911 Assist feature must be set on
before the incident.

• You must pair and connect a
Bluetooth® enabled and compatible
cell phone to SYNC.

• A connected Bluetooth® enabled
phone must have the ability to make
and maintain an outgoing call at the
time of the incident.

67

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

911 Assist

• A connected Bluetooth® enabled
phone must have adequate network
coverage, battery power and signal
strength.

• The vehicle must have battery power
and be located in the U.S., Canada or
in a territory in which 911 is the
emergency number.

Note: If any user sets 911 Assist to on or off,
that setting applies for all paired phones. If
911 Assist is off and the phone connected
to SYNC, an icon displays on the status bar.

Note: Every phone operates differently.
While SYNC 911 Assist works with most
cellular phones, some may have trouble
using this feature.

Privacy Notice

When you switch on 911 Assist, it may
disclose to emergency services that your
vehicle has been in a crash involving the
deployment of an airbag or activation of
the fuel pump shut-off. Certain versions or
updates to 911 Assist may also be capable
of electronically or verbally disclosing to
911 operators your vehicle location or other
details about your vehicle or crash to assist
911 operators to provide the most
appropriate emergency services. If you do
not want to disclose this information, do
not switch the feature on.

EMERGENCY CALL LIMITATIONS

The SYNC 911 Assist feature only operates
in the U.S., Canada or in a territory in which
911 is the emergency number. The following
are limitations of this feature:

• Your cellular phone or 911 Assist
hardware sustains damage in a crash.

• The vehicle's battery or the SYNC
system has no power.

• The phone(s) thrown from your vehicle
are the ones paired and connected to
the system.

68

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

911 Assist

REMOTE CONTROL LIMITATIONS

WARNING: Changes or

modifications not expressively approved
by the party responsible for compliance
could void the user's authority to operate
the equipment. The term "IC:" before the
radio certification number only signifies
that Industry Canada technical
specifications were met.

This device complies with Part 15 of the
FCC Rules and with Industry Canada
license-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) This device
must accept any interference received,
including interference that may cause
undesired operation.

Make sure a valid remote control is within
5 ft (1.5 m) from the front door handles
and rear of vehicle.

The system may not function if:

• The remote control remains stationary
for about a minute.

• The vehicle battery has no charge.

• The remote control battery has no

charge.

• There is interference causing issues
with the remote control frequencies.

• The remote control is too close to
metal objects or electronic devices, for
example keys or a cell phone.

USING THE REMOTE CONTROL

Use your remote control to access various
vehicle systems.

Note: The buttons on your remote may vary
depending on the vehicle region or options.

Unlock

E138629

Press the button to unlock all
doors. See Unlocking and

Locking the Doors Using the

Remote Control (page 83).

Lock

E138623

Press the button to lock all
doors. See Unlocking and

Locking the Doors Using the

Remote Control (page 83).

Remote Start (If Equipped)

E138625

Press the button to remote start.
See Remotely Starting and
Stopping the Vehicle (page

146).

Tailgate (If Equipped)

E191530

Press the button to open the
tailgate. See Opening the

Tailgate Using the Remote

Control (page 99).

Panic Alarm (If Equipped)

E138624

Press the button to sound the
panic alarm. See Sounding the

Panic Alarm (page 70).

OPENING AND CLOSING THE FLIP KEY

Opening Your Flip Key

Press the round button on the remote
control to extend the flip key.

69

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keys and Remote Controls

E191532

Note: Inspect the key blade for debris.
Periodically clean with a brush.

Closing Your Flip Key

Press and hold the round button on the
remote control to fold the key blade when
not in use.

E191532

REMOVING THE KEY BLADE

E322866

Push the release button on your passive
key and pull the key blade out.

SOUNDING THE PANIC ALARM

E138624

Press the button to sound the
panic alarm. Press the button
again, or switch the ignition on

to turn it off.

Note: The panic alarm only operates when
the ignition is off.

LOCATING YOUR VEHICLE

E138623

Press the lock button twice
within three seconds. The turn
signal lamps flash.

Note: We recommend you use this method
to locate your vehicle.

70

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keys and Remote Controls

CHANGING THE REMOTE CONTROL BATTERY

WARNING: Keep batteries away

from children to prevent ingestion.
Failure to follow this instruction could
result in personal injury or death. If
ingested, immediately seek medical
attention.

WARNING: If the battery
compartment does not securely close,
stop using the remote control and
replace it as soon as possible. In the
meantime, keep the remote control away
from children. Failure to follow this
instruction could result in personal injury
or death.

The remote control uses one coin-type
3-volt lithium battery CR2450 or
equivalent.

E322866

1. Push the release button and pull the
key blade out.

E303824

2. Twist a thin coin under the tab hidden
behind the key blade head to remove
the battery cover.

71

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keys and Remote Controls

E218402

3. Insert a screwdriver, and carefully
remove the battery.

4. Install a new battery with the + facing
upward.

5. Reinstall the battery housing cover
onto the transmitter and install the key
blade.

E107998

Dispose of old batteries in an
environmentally friendly way.
Seek advice from your local

authority about recycling old batteries.

Note: Do not wipe off any grease on the
battery terminals or on the back surface of
the circuit board.

Note: Replacing the battery does not erase
the programmed key from your vehicle. The
remote control should operate normally.

CHANGING THE REMOTE
CONTROL BATTERY ­VEHICLES WITH: FLIP KEY

WARNING: Keep batteries away

from children to prevent ingestion.
Failure to follow this instruction could
result in personal injury or death. If
ingested, immediately seek medical
attention.

WARNING: If the battery
compartment does not securely close,
stop using the remote control and
replace it as soon as possible. In the
meantime, keep the remote control away
from children. Failure to follow this
instruction could result in personal injury
or death.

Battery Replacement Procedure

The remote control uses one coin-type
3-volt lithium battery CR2032 or
equivalent.

Press the button to release the key blade
before beginning the procedure.

E191533

1. Insert a screwdriver, in the position
shown and gently push the clip.

2. Press the clip down to release the
battery cover.

72

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keys and Remote Controls

E151799

3. Carefully remove the cover.

E151800

4. Insert a screwdriver as shown to
release the battery.

E151801

Note: Do not touch the battery contacts or
the printed circuit board with the
screwdriver.

5. Remove the battery.

6. Install a new battery with the + facing
up.

7. Replace the battery cover.

E107998

Dispose of old batteries in an
environmentally friendly way.
Seek advice from your local

authority about recycling old batteries.

Note: Do not wipe off any grease on the
battery terminals or on the back surface of
the circuit board.

Note: Replacing the battery does not erase
the programmed key from your vehicle. The
remote control should operate normally.

REPLACING A LOST KEY OR REMOTE CONTROL

You can purchase replacement keys or
remote controls from an authorized dealer.
Authorized dealers can program remote
controls for your vehicle.

E151795

Note: Your vehicle keys came with a
security label that provides important key
cut information. Keep the label in a safe
place for future reference.

73

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keys and Remote Controls

PROGRAMMING THE REMOTE CONTROL

General Information

You must have two previously
programmed remote controls inside your
vehicle and the new unprogrammed
remote controls readily accessible. Contact
an authorized dealer to have the spare
remote control programmed if two
previously programmed remotes are not
available. Make sure that your vehicle is
off before beginning this procedure. Make
sure that you close all the doors before
beginning and that they remain closed
throughout the procedure. Perform all
steps within 30 seconds of starting the
sequence. Stop and wait for at least one
minute before starting again if you perform
any steps out of sequence.

Read and understand the entire procedure
before you begin.

Note: You can program a maximum of four
remote controls to your vehicle.

Note: If your programmed remote controls
are lost or stolen and you do not have an
extra coded remote, you need to have your
vehicle towed to an authorized dealer. Store
an extra programmed remote away from
your vehicle in a safe place to help prevent
any inconvenience. Contact an authorized
dealer to purchase additional spare or
replacement remotes.

Steps for Programming Your Spare
Remote Control

Note: Your vehicle is equipped with one of

the following center consoles.

Programming Backup Location

E226701

E269950

74

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keys and Remote Controls

1. Place the first programmed remote in
the backup slot inside the center
console with your foot off the brake
pedal, press and release the push
button ignition switch.

2. Wait five seconds and then press and
release the push button ignition switch
again.

3. Remove the remote control.

4. Within 10 seconds, place a second
programmed remote control in the
backup slot. Press and release the
push button ignition switch.

5. Wait five seconds and then press and
release the push button ignition switch
again. Keep the ignition on for at least
three seconds, but no more than 10
seconds.

6. Remove the remote control.

7. Place the unprogrammed remote
control in the backup slot and press
and release the push button ignition
switch.

Programming is now complete. With your
foot on the brake pedal, press the push
button ignition switch to verify the remote
control functions operate and your vehicle
starts with the new remote control.

If programming was not successful, wait
10 seconds and repeat Steps 1 through 7.
If you are still unsuccessful, take your
vehicle to an authorized dealer.

PROGRAMMING THE REMOTE CONTROL - VEHICLES WITH: FLIP KEY

General Information

You can program your own remote control
to your vehicle. This procedure programs
both the engine immobilizer keycode and
the remote entry portion of the remote
control to your vehicle.

Only use remote controls with an
integrated mechanical key.

You must have two previously
programmed coded remote controls and
the new un–programmed remote readily
accessible. Contact an authorized dealer
to have the spare remote control
programmed if the two previously
programmed coded remote controls are
not available.

Read and understand the entire procedure
before you begin.

Steps for Programming Your Spare
Remote Control

1. Insert the first previously programmed
coded key into the ignition.

2. Switch the ignition from off to on. Keep
the ignition on for at least three
seconds, but no more than 10 seconds.

3. Switch the ignition off and remove the
first coded key from the ignition.

4. After three seconds but within 10
seconds of switching the ignition off,
insert the second previously coded key
into the ignition.

5. Switch the ignition from off to on. Keep
the ignition on for at least three
seconds, but no more than 10 seconds.

6. Switch the ignition off and remove the
second previously programmed coded
key from the ignition.

7. After three seconds but within 10
seconds of switching the ignition off
and removing the previously
programmed coded key, insert the new
un–programmed key into the ignition.

8. Switch the ignition from off to on. Keep
the ignition on for at least six seconds
until you hear the door locks cycle.

9. Remove the newly programmed coded
key from the ignition.

75

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keys and Remote Controls

The key starts the engine if programming
is successful. You can operate the keyless
remote entry system with the new remote
control with integrated key.

If programming was not successful, wait
20 seconds and repeat Steps 1 through 8.
If you are still unsuccessful, take your
vehicle to an authorized dealer.

Note: You can program a maximum of six
coded remote controls to your vehicle.

KEYS AND REMOTE CONTROLS – TROUBLESHOOTING

KEYS AND REMOTE CONTROLS – INFORMATION MESSAGES

ActionMessage

Replace remote control battery.Key Battery Low Replace

Soon

76

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keys and Remote Controls

WHAT IS MYKEY

MyKey allows you to program keys with
restricted driving modes to promote good
driving habits.

MYKEY SETTINGS

NON-CONFIGURABLE MYKEY
SETTINGS

Seatbelt Reminder or Belt­Minder™

MyKey mutes the audio system until the
front seat passengers buckle the front seat
belts.

Note: If your vehicle includes an AM/FM
radio or a very basic audio system, then the
radio may not mute.

Satellite Radio (If Equipped)

Some Satellite radio channels have
restricted access to adult radio content.

Early Low Fuel

The low fuel level warning lamp turns on
earlier.

Driving and Parking Aids

You cannot configure settings for parking
aids, blind spot information system, and
cross traffic alert. These systems turn on
when the vehicle turns on, and you cannot
switch them off with a MyKey.

You cannot configure settings for
pre-collision assist and lane keeping. These
systems turn on when the vehicle turns on,
but you can switch them off with a MyKey.

A new destination in the navigation system
can only be set using voice commands
when using a MyKey, and with your vehicle
moving.

Note: MyKey drivers may be able to switch
the lane departure warning feature off, but
this feature turns back on automatically
with every new key cycle.

CONFIGURABLE MYKEY
SETTINGS

You can configure the following settings
after creating a MyKey. See Creating a

MyKey (page 78).

Speed Limit

WARNING: Do not set MyKey

maximum speed limit to a limit that will
prevent the driver from maintaining a
safe speed considering posted speed
limits and prevailing road conditions. The
driver is always responsible to drive in
accordance with local laws and
prevailing conditions. Failure to do so
could result in accident or injury.

You can set a speed limit for your vehicle.
Warning messages appear in the
information display and a tone sounds if
your vehicle reaches the set speed. You
cannot override the set speed when using
a MyKey.

Speed Minder

You can set a speed reminder for your
vehicle. Warning messages appear in the
information display and a tone sounds if
your vehicle exceeds the set speed.

Audio System Volume Limit

The audio system maximum volume
reduces. A message appears in the
information display if you attempt to
exceed the volume limit. Automatic
volume control turns off.

77

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

MyKey™

Emergency Assistance

If you set emergency assistance to always
on, you cannot switch it off with a MyKey.

Do Not Disturb

If you set do not disturb to always on, you
cannot switch it off with a MyKey.

Note: If a phone is connected using Apple
CarPlay or Android Auto while driving with
a MyKey, the driver can receive phone calls
and text messages even if the do not disturb
restriction is on, and if the vehicle comes
with satellite radio, there is no restriction on
the adult content.

Traction and Stability Control

If you set traction control or stability
control to always on, you cannot switch it
off with a MyKey.

CREATING A MYKEY

Vehicles with a center console shifter:

E226701

1. Remove the mat from the center
console cup holder.

2. Remove the key blade from the
transmitter.

3. Place the remote control in the backup
slot with the buttons facing toward the
front of the vehicle.

4. Switch the ignition on using an admin
key.

5. Using the instrument cluster display
controls on the steering wheel, select
Settings.

6. Select Vehicle Settings.

7. Select MyKey.

8. Select Create MyKey.

78

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

MyKey™

9. Select Create MyKey and press the OK
button.

Note: After you confirm the creation of a
MyKey, we recommend that you label this
key.

Vehicles with a column shifter.

E269950

1. Raise the front center seat storage lid.

2. Place the remote control in the backup
slot with the buttons facing toward the
front of the vehicle.

3. Switch the ignition on using an admin
key.

4. Using the instrument cluster display
controls on the steering wheel, select
Settings.

5. Select Vehicle Settings.

6. Select MyKey.

7. Select Create MyKey.

8. Select Create MyKey and press the OK
button.

Note: After you confirm the creation of a
MyKey, we recommend that you label this
key.

CREATING A MYKEY ­VEHICLES WITH: FLIP KEY

1. Switch the ignition on using an admin
key.

2. Using the instrument cluster display
controls on the steering wheel, select
Settings.

3. Select Vehicle Settings.

4. Select MyKey.

5. Select Create MyKey.

6. Select Create MyKey and press the OK
button.

Note: After you confirm the creation of a
MyKey, we recommend that you label this
key.

PROGRAMMING A MYKEY

You can only program MyKeys to the same
settings.

1. Switch the ignition on using an admin
key.

2. Press the menu button on the steering
wheel to enter the information display
main menu.

3. Select Settings.

4. Select MyKey.

5. Select a setting and press the OK
button.

6. Configure the setting.

7. Switch the ignition off.

CLEARING ALL MYKEYS

When you clear all MyKeys, you remove all
restrictions and return all MyKeys to their
original admin key status.

1. Switch the ignition on using an admin
key.

2. Press the menu button on the steering
wheel to enter the information display
main menu.

3. Select Settings.

4. Select MyKey.

79

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

MyKey™

5. Select Clear MyKeys.

6. Press and hold the OK button until a
confirmation message appears in the
information display.

CHECKING MYKEY SYSTEM STATUS

You can find information about the
distance traveled using a MyKey and also
the number of admin keys and MyKeys
created for your vehicle.

1. Switch the ignition on.

2. Press the menu button on the steering
wheel to enter the information display
main menu.

3. Select Settings.

4. Select MyKey.

5. Select MyKey Info.

USING MYKEY WITH REMOTE START SYSTEMS

MyKey is not compatible with unapproved,
aftermarket remote start systems. If you
choose to install a remote start system,
see an authorized dealer for an approved
remote start system.

MYKEY – TROUBLESHOOTING

MYKEY – INFORMATION MESSAGES

DescriptionMessage

Displays when trying to create a MyKey and the admin key is
not placed in the backup position. See Creating a MyKey
(page 78).

Place Key in Backup
Location

Displays when trying to create a MyKey with a key already
designated as a MyKey.

Key is Already a MyKey

Displays to confirm that the key is restricted after you switch
the ignition off.

This Key restricted at
Next Key Cycle. Label
Key as MyKey

80

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

MyKey™

MYKEY – INFORMATION MESSAGES - VEHICLES WITH: FLIP KEY

DescriptionMessage

Displays when trying to create a MyKey with a key already
designated as a MyKey.

Key is Already a MyKey

Displays to confirm that the key is restricted after you switch
the ignition off.

This Key restricted at
Next Key Cycle. Label
Key as MyKey

81

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

MyKey™

MYKEY – FREQUENTLY ASKED
QUESTIONS

What is an admin key?

An admin key is a key that you have
not created as a MyKey. See Creating

a MyKey (page 78).

Why am I not able to create a MyKey?

You have not placed the admin key in
the backup position. See Creating a
MyKey (page 78). The key used to
switch the ignition on is not an admin
key. The key used to switch the ignition
on is the only admin key. There has to
be at least one admin key. You did not
switch the ignition off after creating
the last MyKey.

Why am I not able to program a MyKey?

The admin key is not inside your
vehicle. The key used to switch the
ignition on is not an admin key. You
have not created any MyKeys. See

Creating a MyKey (page 78).

Why am I not able to clear the MyKeys?

The admin key is not inside your
vehicle. The key used to switch the
ignition on is not an admin key. You
have not created any MyKeys. See

Creating a MyKey (page 78).

Why is the MyKey distance not
accumulating?

The key used to start the engine is an
admin key. An admin key and a MyKey
are inside your vehicle. You have not
created any MyKeys. See Creating a
MyKey (page 78). You have cleared
the MyKeys. See Clearing All

MyKeys (page 79).

Why am I not able to start the engine
with a MyKey?

An admin key and a MyKey are inside
your vehicle. The system recognizes
only the admin key when both are
present.

MYKEY – FREQUENTLY ASKED
QUESTIONS - VEHICLES WITH:
FLIP KEY

What is an admin key?

An admin key is a key that you have
not created as a MyKey. See Creating

a MyKey (page 79).

Why am I not able to create a MyKey?

The key used to switch the ignition on
is not an admin key. The key used to
switch the ignition on is the only admin
key. There has to be at least one admin
key.

Why am I not able to program a MyKey?

The key used to switch the ignition on
is not an admin key. You have not
created any MyKeys. See Creating a

MyKey (page 79).

Why am I not able to clear the MyKeys?

The key used to switch the ignition on
is not an admin key. You have not
created any MyKeys. See Creating a

MyKey (page 79).

Why is the MyKey distance not
accumulating?

The key used to start the engine is an
admin key. You have not created any
MyKeys. See Creating a MyKey
(page 79). You have cleared the
MyKeys. See Clearing All MyKeys
(page 79).

82

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

MyKey™

OPERATING THE DOORS FROM OUTSIDE YOUR VEHICLE

UNLOCKING AND LOCKING THE
DOORS USING THE REMOTE
CONTROL

You can only use the remote control when
your vehicle is stationary.

Unlocking the Doors

E267112

Press the button to unlock all
doors.

Locking the Doors

E267111

Press the button to lock all
doors. One short flash of the
turn signal lamps confirms that

your vehicle has locked.

Note: For more information on operating
the doors from outside your vehicle See
Keyless Entry Keypad (page 89).

UNLOCKING AND LOCKING THE
DOORS USING THE KEY BLADE

If there is a power door lock fault you can
use the key blade to lock and unlock the
doors.

E333745

Lock.A
Unlock.B

OPERATING THE DOORS FROM INSIDE YOUR VEHICLE

INDIVIDUALLY UNLOCKING AND
LOCKING THE DOORS USING THE
LOCKING BUTTON

The power door lock control is on the driver
and front passenger door panels.

E138628

Unlock.A
Lock.B

83

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Doors and Locks

OPENING THE DOORS FROM
INSIDE YOUR VEHICLE - CREW
CAB

Pull the interior door handle twice to
unlock and open a rear door. The first pull
unlocks the door and the second pull
opens the door.

AUTOUNLOCK

WHAT IS AUTOUNLOCK

Autounlock is an unlocking feature that
unlocks the vehicle doors when your
vehicle comes to a stop.

AUTOUNLOCK REQUIREMENTS

Autounlock unlocks all the doors when all
of the following occur:

• The ignition is on, all the doors are
closed and your vehicle is moving at a
speed greater than 12 mph (20 km/h).

• Your vehicle comes to a stop.

• You open the driver door within 10

minutes of switching the ignition off or
to the accessory position.

SWITCHING AUTOUNLOCK ON
AND OFF

1. Using the instrument cluster display
controls on the steering wheel, select
Settings.

2. Select Vehicle Settings.

3. Switch Autounlock on or off.

AUTOLOCK

WHAT IS AUTOLOCK

Autolock is a locking feature that locks
your vehicle doors when you start driving.

AUTOLOCK REQUIREMENTS

Autolock locks all the doors when all of the
following occur:

• All doors are closed.

• The ignition is on.

• Your vehicle reaches a speed greater

than 12 mph (20 km/h).

MISLOCK

WHAT IS MISLOCK

Mislock is a locking feature that warns you
if your vehicle has not locked.

MISLOCK LIMITATIONS

When you press the lock button once, the
direction indicators do not flash if:

• Any door or the tailgate is open.

• The hood is open.

If you switch mislock off, the horn does not
sound if you press the lock button on the
remote control when a door is open.

SWITCHING MISLOCK ON AND
OFF

1. Using the instrument cluster display
controls on the steering wheel, select
Settings.

2. Select Vehicle Settings.

3. Switch Mislock Chirp on or off.

DOORS AND LOCKS AUDIBLE WARNINGS

Door Ajar Audible Warning

Sounds when a door is not fully closed and
your vehicle is moving.

84

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Doors and Locks

DOORS AND LOCKS – TROUBLESHOOTING

DOORS AND LOCKS – WARNING
LAMPS

Door Ajar Warning Lamp

E249859

It illuminates when you switch
the ignition on and remains on if
any door or the hood is open.

DOORS AND LOCKS – INFORMATION MESSAGES

ActionMessage

Displays if a door is open. Fully close the door.Driver Door Ajar

Passenger Door Ajar

Rear Left Door Ajar

Rear Right Door Ajar

85

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Doors and Locks

DOORS AND LOCKS –
FREQUENTLY ASKED QUESTIONS

Can accessories such as steps or
handles be used with the latch
assembly?

Do not use the door latch assembly to
attach any accessory, such as handles
or steps, as this can cause damage to
your vehicle.

86

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Doors and Locks

KEYLESS ENTRY LIMITATIONS

Make sure your remote control is within 3 ft
(1 m) from the front door handles and the
tailgate.

The system could not function if:

• The remote control remains stationary
for about a minute.

• The vehicle battery has no charge.

• The remote control battery has no

charge.

• There is interference causing issues
with the remote control frequencies.

• The remote control is too close to
metal objects or electronic devices, for
example keys or a cell phone.

KEYLESS ENTRY SETTINGS

Switching Keyless Entry On and
Off

1. Switch the ignition on using an original
key that has not been created as a
MyKey.

2. Press Settings on the touchscreen.

3. Press Vehicle Settings.

4. Press Locks.

Reprogramming the Unlocking
Function

You can enable two-stage unlocking
function allowing you to unlock only the
driver door when you touch the unlock
sensor.

Press and hold both the lock and unlock
buttons on the remote control for four
seconds to disable or enable two-stage
unlocking.

If you program the unlocking function so
that only the driver door unlocks, you can
unlock all of the other doors from inside
your vehicle using the power door lock
control. You can unlock individual doors
by pulling the interior door handles on
those doors.

USING KEYLESS ENTRY

Unlocking the Doors

E333747

With your passive key within 3 ft (1 m) of
your vehicle, touch the unlock sensor on
the back of the door handle for a brief
period and then pull on the door handle to
unlock, being careful not to touch the lock
sensor at the same time or pull on the door
handle too quickly. The intelligent access
system requires a brief delay to
authenticate your passive key.

Locking the Doors

E333746

With your passive key within 3 ft (1 m) of
your vehicle, touch the outer door handle
lock sensor for approximately one second
to lock, being careful not to touch the
unlock sensor on the back of the door
handle at the same time. After locking, you
can immediately pull on the door handle
to confirm locking occurred without
inadvertently unlocking.

87

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keyless Entry

KEYLESS ENTRY – TROUBLESHOOTING

KEYLESS ENTRY – FREQUENTLY
ASKED QUESTIONS

Why does the passive key not work?

The system deactivates passive keys
left inside your vehicle when you lock
it. You cannot switch the ignition on
using a deactivated passive key. Press
the unlock button on the remote
control to reactivate a passive key.

88

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keyless Entry

WHAT IS THE KEYLESS ENTRY KEYPAD

The keyless entry keypad allows you to
lock and unlock your vehicle using the
keypad on the window trim.

KEYLESS ENTRY KEYPAD LIMITATIONS

The system may not function if:

• The vehicle battery has no charge.

LOCATING THE KEYLESS ENTRY KEYPAD

The keypad is near the driver window and
illuminates when you touch it.

KEYLESS ENTRY KEYPAD MASTER ACCESS CODE

Unlocking the Doors

E138637

Enter the factory-set five-digit code or your
personal code. You must press each
number within five seconds of each other.

• Press 3-4 within five seconds to unlock
all doors.

89

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keyless Entry Keypad (If Equipped)

Locking the Doors

E138637

Press and hold 7·8 and 9·0 at the same
time with the driver door closed.

Note: You do not need to enter the code
first.

KEYLESS ENTRY KEYPAD PERSONAL ACCESS CODES

Programming a Personal Entry
Code

1. Enter the five-digit master code.

2. Press 1·2 on the keypad within five
seconds.

3. Enter your personal five-digit code.
You must do this within five seconds
of completing Step 2.

4. Press 1·2 on the keypad to save
personal code 1.

The doors lock then unlock to confirm that
programming was successful.

To program additional personal entry
codes, repeat Steps 1 through 3, then for
Step 4:

• Press 3·4 to save personal code 2.

• Press 5·6 to save personal code 3.

• Press 7·8 to save personal code 4.

• Press 9·0 to save personal code 5.

If your vehicle comes with SYNC, you can
also program the system with a personal
entry code.

Hints:

• Do not set a code that uses five of the
same number.

• Do not use five numbers in sequential
order.

• The five-digit master code works even
if you have set your own personal code.

Erasing a Personal Code

1. Enter the five-digit master code.

2. Press and release 1·2 on the keypad
within five seconds.

3. Press and hold 1·2 for two seconds.
You must do this within five seconds
of completing Step 2.

All personal codes erase and only the
five-digit master code works.

Anti-Scan Feature

The keypad goes into an anti-scan mode
if you enter the wrong code seven times.
This mode turns off the keypad for one
minute and the keypad lamp flashes.

The anti-scan feature turns off after:

• One minute of keypad inactivity.

• You press the unlock button on the

remote control.

• You switch the ignition on.

• You unlock your vehicle using

intelligent access.

90

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keyless Entry Keypad (If Equipped)

USING THE KEYLESS ENTRY KEYPAD

Unlocking the Doors

E138637

Enter the factory-set five-digit code or your
personal code. You must press each
number within five seconds of each other.

• Press 3-4 within five seconds to unlock
all doors.

Locking the Doors

E138637

Press and hold 7·8 and 9·0 at the same
time with the driver door closed.

Note: You do not need to enter the code
first.

To Release the Tailgate

Enter the factory-set code or your personal
code, then press 5-6 control within 5
seconds.

KEYLESS ENTRY KEYPAD – TROUBLESHOOTING

KEYLESS ENTRY KEYPAD –
FREQUENTLY ASKED QUESTIONS

Why does the keypad not accept the
access code?

If you enter the access code too fast
on the keypad, the unlock function
may not work. Slowly re-enter the
access code.

91

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keyless Entry Keypad (If Equipped)

Why does the keypad not function?

The keypad goes into an anti-scan
mode if you enter a wrong code seven
times. The anti-scan mode disables
the keypad for one minute and the red
light flashes.

92

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Keyless Entry Keypad (If Equipped)

HOW DOES EASY ENTRY AND EXIT WORK

Easy entry and exit moves the driver seat
rearward up to 2 in (5 cm) and the steering
column up when you switch the ignition
off. The driver seat and steering column
return to their previous positions when you
switch the ignition on.

Note: Depending on your vehicle, the
column may move up and in.

SWITCHING EASY ENTRY AND EXIT ON AND OFF

1. Press Settings on the touchscreen.

2. Press Vehicle.

3. Select Easy Entry/Exit.

If you press any adjustment or memory
button when in easy exit mode, the system
cancels the operation.

93

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Easy Entry and Exit

TAILGATE PRECAUTIONS

WARNING: It is extremely

dangerous to ride in a cargo area, inside
or outside of a vehicle. In a crash, people
riding in these areas are more likely to be
seriously injured or killed. Do not allow
people to ride in any area of your vehicle
that is not equipped with seats and
seatbelts. Make sure everyone in your
vehicle is in a seat and properly using a
seatbelt. Failure to follow this warning
could result in serious personal injury or
death.

OPENING THE TAILGATE

OPENING THE TAILGATE FROM
OUTSIDE YOUR VEHICLE

E333071

Pull up on the handle to release the
tailgate.

Note: You may need to unlock the tailgate
first.

LOCKING AND UNLOCKING THE TAILGATE

E332901

Lock.A
Unlock.B

1. Insert the ignition key into the tailgate
lock.

2. Turn it to the left to lock the tailgate.

3. Turn it to the right to unlock the
tailgate.

REMOVING AND INSTALLING THE TAILGATE

WARNING: Always properly secure

cargo to prevent shifting cargo or cargo
falling from the vehicle. Failure to do so
could result in compromised vehicle
stability and serious personal injury to
vehicle occupants or others.

94

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Tailgate - Vehicles With: Manual Tailgate

E248384

1. Obtain the tailgate removal kit from
the glove box.

2. Locate and disconnect the frame
connections. They are on the left-hand
side of the vehicle.

Note: Your vehicle may have up to three
frame connections.

3. Install the protective caps on the in-line
connector portion that remains under
the pickup box.

Note: If you do not install the caps on the
connectors, some features may not operate
as intended.

4. Partially lower the tailgate. Carefully
feed the tailgate harness up through
the gap between the pickup box and
the bumper and place it out of the way
under the pickup box.

5. Lower the tailgate.

E311529

6. Use a screwdriver to gently pry the
spring clip on each connector past the
head of the support screw. Disconnect
the cable.

7. Disconnect the other cable.

Note: To avoid damaging the tailgate, you
may need assistance when removing. The
tailgate weighs approximately 97 lb (44 kg).

8. Lift the tailgate to 45 degrees from the
horizontal position.

9. Lift the right-hand side off its hinge.

10. Lift the tailgate to 80 degrees from

the horizontal position.

11. Remove the tailgate from the

left-hand side hinge by sliding it to
the right.

12. Install the tailgate in reverse order.

TAILGATE STEP

ACCESSING THE TAILGATE STEP

1. Lower the tailgate.

2. Push the button in the center of the
step molding. The step pops out
slightly.

E187718

3. Pull the step out fully. Lower the step
to its lowest position.

95

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Tailgate - Vehicles With: Manual Tailgate

E189557

4. Pull the yellow handle stop backward
out of the tailgate until it fully extends.

5. To lock the handle in place, rotate the
handle up from the horizontal to the
vertical position until you hear a click.

Note: Do not tow with the step or grab
handle.

Replace the slip resistance tape or grab
handle molding if it appears as worn or
damaged.

To reduce the risk of falling:

• Only operate the step when your
vehicle is on a level surface.

• Only operate the step in areas with
sufficient lighting.

• Make sure you use the grab handle
when climbing on the step.

• Do not use the step with bare feet.

• Make sure the step is clean before use.

• Keep the step load below the total

maximum load of 350 lb (159 kg).

STOWING THE TAILGATE STEP

1. Press the yellow button on the handle
to lower and then press the yellow
lever at the bottom of the handle to
unlock. Rotate the handle down from
the vertical to the horizontal position
and push it into the tailgate.

2. Rotate the step up until it is horizontal,
then push it back into the tailgate until
the step is secure.

Note: Make sure to close and fully latch the
step before moving your vehicle. Do not
drive with the step or grab handle open.

Note: The power tailgate cannot close if
the step is opened. A warning message
appears and a chime sounds. After stowing
step the power close function is restored.

BED EXTENDER

BED EXTENDER PRECAUTIONS

Note: Do not use the bed extender when

driving off road.
Note: Make sure to engage the locking pins

and knobs fully before driving your vehicle.

Note: Make sure to secure all cargo.
Note: Do not exceed 150 lb (68 kg) on the

tailgate when your vehicle is moving.
Note: Do not keep the bed extender in the

tailgate mode when you are not using it for
restraining cargo. Always keep the bed
extender in the grocery mode or the stowed
position with the tailgate closed.

96

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Tailgate - Vehicles With: Manual Tailgate

USING THE BED EXTENDER

E311521

1. Pull the locking pin toward the center
of your vehicle.

E311522

2. Open the latches to release the panels.

A

B

A

203

A

A

E311523

3. Rotate the panels toward the tailgate.
Repeat steps 1-3 on the other side of
your vehicle.

97

2022 Super Duty (TFE) Canada/United States of America, enUSA, Edition date: 202103, First-Printing

Tailgate - Vehicles With: Manual Tailgate
