Ford 2015 F-150 Quick Reference Manual

WARNING

Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution
when using any device that may take your focus o the road. Your primary responsibility is the safe operation of your vehicle. We
recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible.
Make sure you are aware of all applicable local laws that may aect the use of electronic devices while driving.

October 2014
First Printing

Quick Reference Guide

F-150

Litho in U.S.A.

FL3J 19G217 AA

LEARN MORE ABOUT
YOUR NEW VEHICLE

Scan the country-appropriate QR code with your smartphone (make
sure you have a scanner app installed) and you can access even more
information about your vehicle.

Ford.ca

FordOwner.com

This Quick Reference Guide is not intended to replace your vehicle Owner’s Manual which contains more detailed information concerning the features of your

vehicle, as well as important safety warnings designed to help reduce the risk of injury to you and your passengers. Please read your entire Owner’s Manual

carefully as you begin learning about your new vehicle and refer to the appropriate chapters when questions arise. All information contained in this Quick

Reference Guide was accurate at the time of duplication. We reserve the right to change features, operation and/or functionality of any vehicle specification at any

time. Your Ford dealer is the best source for the most current information. For detailed operating and safety information, please consult your Owner’s Manual.

2015 F-150 QUICK REFERENCE GUIDE

United States

Ford Customer
Relationship Center

1-800-392-3673 (FORD)
(TDD for the hearing
impaired: 1-800-232-5952)

fordowner.com

@FordService

Canada

Ford Customer
Relationship Centre

1-800-565-3673 (FORD)

ford.ca

@FordServiceCA

BASIC COMMANDS

• What can I say?

• List of commands

• Main menu

• Previous page

• Next page

• Go back

• Exit

• Help

ENTERTAINMENT

• Audio list of commands:

You can also get detailed lists of
commands for radio, USB, Bluetooth

®

audio, SiriusXM and SD card*

• Radio

- <On/O>

- FM <87.9-107.9>

- FM preset <#>

• CD

- Play track <1-512>

- Shue <On/O>

• USB

- Play song <name>

- Play album <name>

• SiriusXM

- <Channel name>

- Preset <#>

PHONE

• Phone list of commands

• Dial

• Call <name> on cell/at home/

at work

• Call voicemail

• Do not disturb

• Listen to text messages

(phone-dependent feature)

CLIMATE**

• Climate control list of commands

• Climate <On/O>

• Climate my temperature

• Climate automatic

NAVIGATION**

• Navigation list of commands

• Destination street address

<number, name, city>

• Destination home

• Voice guidance <On/O>

• Navigation voice volume

<increase/decrease>

• Repeat instruction

• Show <map/north-up/

heading-up/3-D>

• Destination <favorites/home/

intersection>

• Where am I?

• Zoom <In/Out>

• Detour

*if equipped
**available only with MyFord Touch

Table of Contents

Commonly Used Voice Commands

SYNC.® Say the Word. Press the voice button and then say:

4 – 9 INSTRUMENT PANEL

10 – 11 SYNC

12 – 16 SYNC WITH MYFORD TOUCH

17 CONVENIENCE

18 COMFORT

19 – 21 FUNCTION

22 – 23 ESSENTIAL INFORMATION

Some services may not be available in your area. Refer to your Owner’s Manual, visit the website
or call the toll-free number.

FOR U.S. CUSTOMERS:

Visit SyncMyRide.com or call 1-800-392-3673 (select Option 1 or 2 for language, then Option 3).

FOR CANADIAN CUSTOMERS:

Visit SyncMyRide.ca or call 1-800-565-3673 (select Option 1 or 2 for language, then Option 3).

3

1

5

6

7

8

7

5 6 6

8

423

1

4

*if equipped

POWERSCOPE®
POWER-FOLDING,
POWER-ADJUSTABLE
TELESCOPING MIRRORS*

To telescope your mirrors, make sure you
switch your vehicle on (with the ignition
in accessory mode or the engine
running) and then:

1. Press and release the
or

control.

2. Press the adjustment control to
position the mirrors.

• Press the le arrow

to extend
the mirrors out. Press the right
arrow

to retract the mirrors in.

• Press the up or down arrow
to fold the mirrors toward

the window glass. Press the up
or down arrow

to fold the

mirrors out.

Note: Once you press the control to
use the power telescoping mirrors
feature, you lock out other mirror
functions for a short time. Press the
control again to unlock other power
mirror features, or wait until the lock
out times out.

LED SIDE-MIRROR
SPOTLIGHTS CONTROL*

The spot lamps are on the forward­facing side of the exterior mirrors.
With the lighting control switch in the
parking lamps, headlamps or autolamps
position, press the buttons located
above the lighting control switch to
activate the le-hand or right-hand side
spot lamps. Once switched on, the

spot lamps light the area in front of
and to the side of your vehicle. Adjust
the aim of the spot lamps by moving
the exterior mirrors' positions.

LIGHTING CONTROL

Headlamps o.

Parking lamps on.

Headlamps on.

Autolamps on. Automatically

switches the exterior lamps on or
o based on available daylight.

Fog lamps on. Press the control

to switch the fog lamps on or o.
You can switch the fog lamps on
when the lighting control is in any
position except o and the high
beams are not on.

ELECTRIC
PARKING BRAKE*

On certain models, the electric parking
brake replaces the conventional foot
brake. The operating switch is on the
instrument panel, to the le of the
steering column.

To apply the electric parking brake,
make sure the transmission is locked
into park (P), and then pull the
switch up. The brake system lamp then
lights to confirm that the parking brake
is applied.

To release the electric parking brake,
switch the ignition on, press the brake
pedal, and then manually press the

switch down. The brake system

lamp then turns o to confirm the
parking brake is released.

ADJUSTABLE
FOOT PEDALS*

Move the brake and accelerator pedals
by using the control located on the le
side of the steering column.

Press the le arrow

to move the

pedals away from you.

Press the right arrow to move the
pedals closer to you.

Adjust the pedals only aer stopping
your vehicle and placing it in park (P).

INFORMATION DISPLAY
PRODUCTIVITY SCREEN*

Monitor and control important vehicle
information and features through the
information display.

• Press the up or down arrows

to
scroll through and highlight the options
within a menu.

• Press the right arrow

to enter into

a sub-menu.

• Press the le arrow to exit a menu.

• Press OK to choose and confirm a

setting or message.

You can even customize your views
using MyView.

Refer to the Information Displays
chapter in your Owner’s Manual for
more details.

4 – 5

ADAPTIVE
CRUISE CONTROL*

Automatically adjust your speed to
maintain a set distance between
your vehicle and the vehicle in front
of you in the same lane. Set the
gap distance between your vehicle
and the vehicle in front of you by
pressing GAP+ or GAP– or

and

controls on the steering wheel.

Note: Driving aids do not replace
the need to watch where the
vehicle is moving and brake where
necessary. Refer to the Cruise
Control chapter in your Owner’s
Manual for more details.

POWER TILT-TELESCOPE
STEERING COLUMN*

Use the control on the side of the
steering column to adjust
the position.

To tilt: Press the top or bottom
of the control.

To telescope: Press the front or rear
of the control. The column moves to
the full up and away position when
you switch the ignition o. It returns
to your previous setting when you
switch the ignition on. You can
enable or disable this feature in the
information display.

Instrument Panel

2

9

10

11

12

109

12

11 13

13

*if equipped

AUDIO AND
MEDIA CONTROLS

• Press VOL+ or VOL– to increase or

decrease your volume level.

• Press M repeatedly to access all

possible media sources.

• Press

to access voice recognition*.

• Press to access SYNC

®

phone features*.

PUSH-BUTTON START*

Press the brake pedal and then press
the START STOP button.

An indicator light comes on when
the ignition is on and when the
engine starts.

If you leave your vehicle idling for an
extended period of time, the engine and
ignition automatically turn o.

Before the engine shuts down, a
message appears in the information
display allowing the driver time to
override the shuto feature.

Note: Your intelligent access
transmitter must be inside your
vehicle to switch the ignition on and
start the engine.

6 – 7

ELECTRONIC SHIFT
4WD SYSTEM*

The electronic shi 4WD system allows
you to choose between 2WD, 4x4
AUTO*, 4x4 HIGH or 4x4 LOW.

2H (2WD) sends power to the rear
wheels only and should be used for
street and highway driving. Provides
optimal smoothness and fuel economy
at high speeds.

4A (4x4 AUTO)* provides electronic
control four-wheel drive with power
delivered to the front and rear wheels,
as required, for increased traction.
This is appropriate for all on-road
driving conditions, including dry road
surfaces, but is especially useful on wet
pavement, snow, dirt or gravel.

4H (4x4 HIGH) helps provide extra
traction while driving in snow or
on icy roads or o road situations.
This mode is not intended for use on
dry pavement.

4L (4x4 LOW) uses extra gearing to
provide maximum power to all four
wheels at reduced speeds. Intended
only for o-road applications such
as deep sand, steep grades or pulling
heavy objects. 4L (4x4 LOW) does not
engage while the vehicle is moving
above 3 mph (5 km/h); this is normal
and should be no reason for concern.

Refer to Shiing to or from 4L (4x4
LOW) in the Four-Wheel Drive chapter
of your Owner’s Manual for details.

ELECTRONIC LOCKING
DIFFERENTIAL*

When engaged, the system temporarily
locks the rear axle, allowing both rear
wheels to turn at the same speed. This
function helps to provide additional
traction as needed.

Note: Do not use this feature on
dry surfaces.

To use:

4X4: Pull the 4WD control.

4X2: Twist the

control to ON.

The indicator light

continuously

displays in the cluster when the ELD
is active.

INTEGRATED TRAILER
BRAKE CONTROLLER*

The fully integrated trailer brake
controller assists in smooth and
eective trailer braking by powering the
trailer’s electric or electric-over
hydraulic brakes with a proportional
output based on the towing vehicle’s
brake pressure.

The Gain setting is used to set the
trailer brake controller for specific
towing conditions and should be
changed as towing conditions change.
Changes to towing conditions include
trailer load, vehicle load, road
conditions and weather.

Use the Gain + and – adjustment
buttons to increase or decrease the
braking feature’s power output to
the trailer in 0.5 increments.

Adjust the Gain by:

1. Pressing the Gain+ or Gain–

buttons to increase or decrease
the setting to the desired
starting point. For example, a
Gain setting of 6.0 is a good
starting point for heavier loads.

2. Test the adjusted Gain

setting again aer you make
adjustments. When testing:

A. In a trac-free environment,

tow the trailer on a dry, level
surface at a speed of 20-25 mph
(30-40 km/h) and squeeze the
manual control lever completely.

B. If the trailer wheels lock

up (the tires will squeal),
reduce the Gain setting. If
the trailer wheels turn freely,
increase the Gain setting.

C. The proper Gain setting will

be at the point just below
trailer wheel lock-up.

Note: If towing a heavier trailer,
trailer wheel lock-up may not be
attainable even with the maximum
Gain setting of 10.

360-DEGREE CAMERA*

See page 19 for details.

Instrument Panel
