Page 1
EXPEDITION
2014
QUICK REFERENCE GUIDE
FORDOWNER.COM FORD.CA
This Quick Reference Guide is not intended to replace your vehicle Owner’s Manual which contains more detailed information concerning the features
of your vehicle, as well as important safety warnings designed to help reduce the risk of injury to you and your passengers. Please read your entire
Owner’s Manual carefully as you begin learning about your new vehicle and refer to the appropriate chapters when questions arise.
All information contained in this Quick Reference Guide was accurate at the time of duplication. We reserve the right to change features, operation and/
or functionality of any vehicle specification at any time. Your Ford dealer is the best source for the most current information. For detailed operating and
safety information, please consult your Owner’s Manual.
Expedition
February 2014
Second Printing
Quick Reference Guide
Litho in USA
EL1J 19G217 AA
WARNING
Driving while distracted can result in loss of vehicle control, crash and injury. We
strongly recommend that you use extreme caution when using any device that may
take your focus o the road. Your primary responsibility is the safe operation of your
vehicle. We recommend against the use of any hand-held device while driving and
encourage the use of voice-operated systems when possible. Make sure you are aware
of all applicable local laws that may aect the use of electronic devices while driving.
LEARN MORE ABOUT
YOUR NEW VEHICLE
Scan the country-appropriate
QR code with your smartphone
(make sure you have a scanner
app installed) and you can access
even more information about
your vehicle.
United States
Ford Customer Relationship Center
1-800-392-3673 (FORD)
(TDD for the hearing impaired:
1-800-232-5952)
fordowner.com
Canada
Ford Customer Relationship Centre
1-800-565-3673 (FORD)
ford.ca
Page 2
COMMONLY USED SYNC® VOICE COMMANDS
Basic Commands
• What can I say?
• List of commands
• Main menu
• Previous
• Next
• Go back
• Exit
• Help
• Vehicle health report
• Pair my phone
Phone
• Phone list of commands
- Dial
- Call <name> on cell/
at home/at work
- Call voicemail
- Do not disturb <On/O>
- Listen to text message
(phone-dependent feature)
Entertainment
• Audio list of commands:
You can also get detailed lists
of commands for radio, USB,
Bluetooth® audio, SiriusXM
and SD card
• Radio
- <On/O>
- FM <87.9-107.9>
- FM preset <#>
• CD
- Play track <1-512>
- Shue <On/O>
• USB
- Play song <name>
- Play album <name>
• SiriusXM
- <channel name>
- Preset <#>
SYNC Services*
Must say “Services” first,
and then
• What can I say?
• Trac
• Directions
• Business search
• Operator
(for direction or
business search)
• Favorites
• News, sports,
weather horoscopes,
stock quotes,
movies or travel
• Help
SYNC. SAY THE WORD.
Some services may not be available in your area. For more complete information
on SYNC, refer to your Owner’s Manual, visit the website or call the toll-free number.
For U.S. customers, visit SyncMyRide.com or call 1-800-392-3673 (select Option 1 or 2
for language, then Option 3). For Canadian customers, visit SyncMyRide.ca or call
1-800-565-3673 (select Option 1 or 2 for language, then Option 3).
TABLE OF CONTENTS
Instrument Panel
SYNC
Convenience
Comfort
Essential Information
Function
4 – 7
8 – 9
10
11 – 12
13
14 – 15
page 3
page 2
*if equipped
Page 3
page 5
page 4
INSTRUMENT PANEL
*if equipped
6
1 2
3 4
5
7 8
1
2
3
4
5
6
7
8
LIGHTING CONTROL
Switches o the
headlamps.
Switches on the
parking lamps.
Switches on the headlamps.
Autolamps: Automatically
turns the exterior lamps
on/o based on available
daylight.
Pull the control toward you
to switch on the fog lamps.
WINDSHIELD WIPERS/
WASHERS
Rotate the end of the control
away from you to increase the
wiper speed and toward you to
decrease the wiper speed.
Press the end of the stalk
• Quickly for a single swipe
without fluid
• Hold briefly for three swipes
with washer fluid
• Hold for a longer
wash cycle.
To operate your rear
window wiper
Rotate the rear wiper control
to 1 (intermittent speed), 2
(normal speed) or O (o).
For a rear wash cycle, rotate
and hold the rear wiper
control to either
position.
Note: For optimal wiper
performance, clean your blades
and glass regularly.
Refer to your Owner’s Manual
for more information.
ABS WARNING LIGHT
Lights briefly when you
switch o the ignition. If it
lights when you are driving,
this indicates a malfunction.
You will continue to have
the normal braking system
(without ABS) unless the brake
warning lamp
also lights.
Have the system checked by
your authorized dealer.
SERVICE ENGINE
SOON LIGHT
Lights briefly when you
switch on the ignition. If it
remains on or blinks aer you
start the engine, the On-Board
Diagnostics (OBD-II) system
has detected a malfunction.
Drive in a moderate fashion
(avoid heavy acceleration and
deceleration) and contact your
authorized dealer as soon
as possible.
INFORMATION DISPLAY
The information display
provides important vehicle
information through a constant
monitoring of vehicle systems.
The system will notify you of
potential vehicle problems by
displaying system warnings
followed by a long indicator
chime. For more information
about your vehicle’s functions,
please see your Owner’s Manual.
ADJUSTABLE PEDALS
Let you move your brake and
accelerator pedals closer.
Located to the le of your
steering column, press
to
move the pedals closer to you,
or
to move the pedals farther
away from you. The pedals
should only be adjusted when
the vehicle is stopped and
in park (P).
CRUISE CONTROL
To set the speed
a. Press and release ON.
b. Accelerate to the
desired speed.
c. Press SET+ and take your
foot o the accelerator.
• To set a higher or lower
speed, press and hold
SET+/SET- or press
SET+/SET- repeatedly
until you reach the
desired speed.
• To cancel a set speed, tap
the brake pedal. The set
speed will not be erased.
• To return to a previously
set speed, press RES.
• To switch o, press OFF or
switch o the ignition.
STEERING WHEEL
CONTROLS
Press VOL+/VOL- to
increase/decrease your
volume level.
Press
to access
the previous/next radio station,
CD track or preset satellite
radio channel.
Press MEDIA repeatedly
to access all possible
media sources.
Press VOICE* to access
voice recognition.
Press
to access SYNC®
phone features.
Page 4
page 7
13
*if equipped
9 10
11
12
INSTRUMENT PANEL (continued)
ADVANCETRAC® WITH RSC® (ROLL STABILITY
CONTROL™)
automatically activates when you start your engine
and helps you keep control of your vehicle when on a slippery
surface. The electronic stability control portion of the system helps
avoid skids and lateral slides, while the roll stability control helps
avoid a vehicle rollover. The traction control system helps avoid drive
wheel spin and loss of traction.
Refer to your Stability Control chapter in your Owner’s Manual for
more details.
TRAILER SWAY CONTROL* applies your vehicle brakes
at individual wheels and, if necessary, reduces engine power.
If the trailer begins to sway, the stability control light flashes
and the message TRAILER SWAY REDUCE SPEED appears in the
information display. The first thing to do is slow down your vehicle,
then pull safely to the side of the road and check for proper tongue
load and trailer load distribution.
For more information, please refer to the Towing chapter in your
Owner’s Manual.
HAZARD FLASHER CONTROL
OVERDRIVE CONTROL WITH TOW/HAUL FEATURE helps
improve transmission operation when towing a trailer or a heavy
load. To switch on Tow/Haul, press the control on the end of the
gearshi lever (column-shi transmission) or on the side of the
gearshi lever (floor-shi transmission). The TOW HAUL indicator
light will display in the information display. To switch o, press the
control again. Drive with the vehicle in overdrive (D) with Tow/Haul
o for the best fuel economy.
Refer to the Transmission chapter of your Owner’s Manual for
more information.
INTEGRATED TRAILER BRAKE
CONTROLLER*
assists in smooth and eective
trailer braking by powering the trailer ’s brakes
with a proportional output based on the towing
vehicle’s brake pressure.
Use the GAIN adjustment buttons to increase or
decrease the braking feature’s power output to the
trailer. Adjust the GAIN by :
1. Pressing the GAIN + or GAIN - buttons
to increase or decrease the setting to the desired
starting point. A GAIN setting of 6.0 is a good
starting point for heavier loads.
2. Testing the adjusted GAIN setting.
a. In a trac-free environment, tow the
trailer on a dry, level surface at a speed of
20-25 mph (30-40 km/h) and squeeze the
manual control lever completely.
b. If the trailer wheels lock up (the tires will
squeal), reduce the GAIN setting. If the trailer
wheels turn freely, increase the GAIN setting.
c. The proper GAIN setting will be at the point
just below trailer wheel lock-up. If towing a
heavier trailer, trailer wheel lockup may not
be attainable even with the maximum GAIN
setting of 10.
Note: Even advanced technology cannot overcome
the laws of physics. It’s always possible to lose
control of a vehicle due to inappropriate driver
input for the conditions.
FOUR-WHEEL DRIVE (4WD)* operates in
four modes for a variety of road conditions:
2H (4X2) mode delivers power to the rear wheels
only, that is appropriate for normal, on-road driving
on dry pavement and provides the best
fuel economy.
4A (4X4 AUTO) mode provides
electronic control four-wheel
drive with power delivered
to all four wheels, as required,
for increased traction. This
mode is appropriate for all
on-road driving conditions,
such as dry road surfaces, wet
pavement, snow and gravel.
4H (4X4) mode provides electronically locked
four-wheel drive power to all four wheels. This
position is not recommended for use on dry
pavement and is only intended for severe winter
or o-road conditions, such as deep snow, ice or
shallow sand.
4L (4X4) mode provides electronically locked
four-wheel drive when extra power at reduced
speeds is needed. Use this mode for o-road,
low-speed operation, such as climbing steep
grades, pulling a boat out of the water
and more.
Refer to the Four-Wheel Drive (4WD) chapter
in your Owner’s Manual.
9
10
11
12
*if equipped
page 6
Page 5
USING YOUR PHONE WITH SYNC
Note: Enter your phone book contacts with
both first and last names to increase the
ability of SYNC to select the correct contact.
Remember to say the contact name exactly
as it is listed in your phone book.
Making a phone call: Use SYNC to make
a phone call to anyone in your phone book
by pressing the VOICE button and when
prompted, give a voice command. For
example, you could say “Call Jake Smith
at home”. When the system confirms the
number, say “Dial” to initiate the call.
Note: You can also make phone calls by
pressing the VOICE button. When prompted,
give the voice command “Dial”, and then
verbally say the phone number.
Answering incoming calls: Whenever you
have an incoming call, you will be able to
see the name and number of the person
calling in your display. Press the phone
button to answer an incoming call. You can
hang up at any time by pressing and holding
the phone button.
Do not disturb mode: This feature blocks
incoming calls and text messages, and
saves them for later. You still have access
to outgoing calls when this feature is active.
Say the voice command “Do not disturb on”
to enable and “Do not disturb o”
to disable.
USING SYNC TO ACCESS DIGITAL MEDIA
SYNC allows you to plug in your USBcompatible media devices such as phones
and MP3 players, and use SYNC to play all
of your favorite music.
Note: SYNC indexes all of your music. The
more music stored on your device, the longer
it takes SYNC to index.
Using voice commands to play music
1. Plug your media player into your
USB port.
2. Press the VOICE button. When
prompted, say “USB”, then follow-up
by saying one of the voice commands.
For a list of voice commands, say “What
can I say?”.
SYNC APPLINK™
*
SYNC AppLink allows your voice access to
select mobile applications that you already
have or can download to your Android™,
BlackBerry
®
or iPhone®.
Current apps available include Pandora
Internet Radio
®
, Stitcher Smart Radio™,
Open Beak (BlackBerry exclusive),
iHeartRadio, Slacker, NPR News, SYNC
Destinations and more. Some services
may not be available in your area. For
more information, visit the website or call
the toll-free number. See the inside front
cover of this guide for details.
page 9
SYNC®
GETTING STARTED WITH
YOUR SYNC SYSTEM
SYNC is a hands-free, voice recognition
system used for entertainment,
information and communication.
SYNC. Say the Word.
GENERAL TIPS
• Press the radio system seek down
arrow
to exit a current menu.
• For additional support, refer to your
Owner’s Manual, visit the website or
call the toll-free number. See the inside
front cover of this guide for details.
Before you get started
1. Set up your owner account at
SyncMyRide.com (U.S.) or
SyncMyRide.ca (Canada). Register by
following the on-screen instructions.
Aer registering, you can see what
services you may be eligible for.
2. SYNC uses a wireless connection called
Bluetooth® to communicate with your
phone. Switch on Bluetooth mode in
your phone’s menu options. This lets
your phone find SYNC.
PAIRING YOUR PHONE WITH SYNC
First-time pairing lets you use the many
features of SYNC
1. Make sure your vehicle is in park (P) and
you switch on your ignition and radio.
2. Press the phone button. When the
display indicates No Phone is Paired,
press OK.
3. When Find SYNC appears in the display,
press OK.
4. Put your phone into Bluetooth discovery
mode. Refer to your phone’s user guide,
if necessary.
5. When prompted on your phone’s display,
enter the six-digit PIN provided in the
radio display into your cellular phone.
6. The radio display indicates when the
pairing is successful.
Note: The system may prompt you to:
• Set your phone as the primary/favorite
(the primary phone will receive
messages and voicemail).
• Download your phone book
(this is required to use the full set
of voice commands).
• Switch on 911 Assist
®
.
Tips
• Make sure you accept the request
from SYNC to access your phone.
• If you are experiencing pairing
problems or would like to pair
additional phones, refer to the SYNC
chapter of your Owner’s Manual for
more complete instructions.
page 8
WHY DO YOU NEED A SYNC OWNER ACCOUNT?
A SYNC owner account is required for Vehicle Health Report activation and the
ability to view your reports online. You’ll also be able to take advantage of the
many SYNC Services and personalization features, such as saving your Favorites
and points of interest (POI). You’ll receive the latest soware updates that add
new places, directions and information; and if you have questions, you’ll get free
customer support. Visit SyncMyRide.com (U.S.) or SyncMyRide.ca (Canada)
for more information.
*if equipped
Page 6
CONVENIENCE
MYKEY
®
MyKey allows you to program certain
driving restrictions in order to promote
good driving habits. You can program
things such as speed restrictions and
limited volume levels. For complete
information, refer to the MyKey chapter
in your Owner’s Manual.
INTEGRATED KEYHEAD TRANSMITTER
Press once to lock all doors. Press
again to confirm all doors are closed.
• Press
once to unlock the driver’s
door. Press again within three
seconds to unlock all doors.
• Press
to sound the panic alarm.
Press again or switch on the ignition
to deactivate.
• Press
twice within three seconds
to unlatch the ligate window. With a
power ligate*, however, this button
will open or close the power ligate
or reverse its movement instead of
the ligate window.
• Car finder: Press
twice within three
seconds to locate your vehicle. The
horn will sound and the turn lamps
will flash.
SECURICODE™ KEYLESS
ENTRY KEYPAD
Lock or unlock the doors, or release the
ligate glass without using a key. You
can use the keypad with the factory-set,
5-digit entry code located on the owner’s
wallet card in the glove box. Additionally,
you can create up to five of your own
5-digit personal entry codes.
To lock all of the doors and ligate
Press and hold 7•8 and 9•0 at the same
time. For complete information, refer to
the SecuriCode Keyless Entry Keypad in
the Locks chapter of your Owner’s Manual.
RAIN-SENSING WIPERS
*
If switched on, your wipers will
automatically turn on when moisture
is present on the windshield. The wiper
speed will vary based on the amount of
moisture detected and the sensitivity
setting. Switch o your wipers to switch
o the rain-sensing feature.
Note: Make sure that this feature is turned
o before entering a car wash.
MEMORY FEATURE
*
The memory function will save and recall
the positions of the driver seat, power
mirrors and adjustable pedals. Use the
memory controls located on the le side
of the driver’s seat
to program
and then recall memory positions.
To program
1. Switch on the ignition.
2. Move the memory features to your
desired position.
3. Press and hold the 1 button
until
you hear a tone.
Use this same procedure to set the
second position using the 2 button
.
You can now use these controls to recall
the set memory positions.
SOS POST-CRASH ALERT SYSTEM™
The SOS Post-Crash Alert System
provides audible and visual alarms in the
event of a crash. The direction indicators
will flash and the horn will sound. To
switch o the system, press the hazard
flasher control, or press
on your
remote transmitter.
COMFORT
SEATING-TO-CARGO VERSATILITY
Note: Before folding the second- or thirdrow seats, make sure to flip down the head
restraints by pulling on the strap, and remove all
items from the floor and seats.
TO FOLD THE FLAT-FOLDING THIRD-ROW
SEATS TO THE LOAD FLOOR
Pull up on the Handle located behind the
seatback while pushing the seatback forward
and down into the seat cushion.
Note: You may need to exert a moderate force
to move the seat forward and down.
To return the seats to an upright
seating position
Li and pull the seat rearward until the
latch engages fully.
Pull Strap
Handle
E-Z ENTRY INTO THE
THIRD-ROW SEATS
The E-Z entry seat allows for easier
entry and exit to and from the
third-row seat.
To enter the third-row seating area
1. Fold the head restraint forward.
2. Pull up on Lever 1.
3. Fold down the second-row seat
and release the handle.
4. Pull the handle up again until the
seat releases from the floor.
5. Push the seat upward and fold it
away from the third row.
To return the seat to an upright
seating position
1. Push the seat down and latch it
to the floor.
2. Bring the seatback to an upright
position. It should lock into position.
3. Li up on the head restraint until it
locks into its original position.
Lever 1
Position 2
Position 3
page 11
page 10
*if equipped
Page 7
COMFORT (continued)
Pull Strap
Position 2
Position 3
Instrument Panel
Ligate
Rear Quarter Panel
Once you close the moonroof, you can still
open or close the sliding shade manually.
Pull the shade toward the front of the vehicle
to close it.
POWER LIFTGATE OPERATION
*
You can open your power ligate three
dierent ways:
• Push the control on the instrument panel
• Press the
control on your remote entry
transmitter twice within three seconds
• Press the ligate control located on the
inside of the ligate handle.
To close with the rear cargo area button,
press and release the control located on the
le, rear quarter panel.
Obstacle detection
If the power ligate is closing, the system
is designed to reverse to fully open when it
encounters a solid obstacle. A three-second
tone also sounds when the system detects
an obstacle. Once you remove the obstacle,
the ligate can be closed under power.
If the power ligate is opening, the system is
designed to stop when it encounters a solid
obstacle. A tone will sound for three seconds
while the obstacle is present.
ESSENTIAL INFORMATION
EASY FUEL® SYSTEM
Your vehicle’s fuel system allows you to
open the fuel filler door, insert the nozzle
and start fueling. Wait 10 seconds from the
time the refueling nozzle is shut o until you
remove the nozzle from the vehicle to allow
residual fuel in the nozzle to drain into
the tank.
The Easy Fuel system is self-sealing and
therefore protected against dust, dirt,
water, snow and ice. If you need to fill your
fuel tank with a portable fuel container,
use the fuel funnel which is attached to
the underside of the spare tire cover or
is included with the tire changing tools.
Slowly insert the funnel into the Easy Fuel
system and fill the tank with fuel from the
container. When done, clean the funnel or
properly dispose of it. Extra funnels can be
purchased from your authorized dealer.
Note: Do not use aermarket funnels as they
will not work with the Easy Fuel system and
may cause damage.
FUEL TYPE AND FUEL TANK CAPACITY
Depending on your vehicle, your fuel tank
has a capacity of either 28 gallons (106L)
or 33.5 gallons (126.8L). Flex Fuel vehicles
have a yellow ring around the top of the fuel
filler inlet (tube) and can use either Regular
unleaded fuel, E85 Ethanol fuel or any
mixture of the two.
It is best not to alternate repeatedly
between gasoline and E85. If you do switch
fuels, it is recommended that you add
as much fuel as possible—at least half
a tank. Do not add less than five gallons
(18.9L) when refueling. You should drive
the vehicle immediately aer refueling
for at least 5 miles (8 km) to allow the
vehicle to adapt to the change in ethanol
concentration. If you exclusively use E85
fuel, it is recommended to fill the fuel tank
with regular unleaded gasoline at each
scheduled oil change.
FUEL-EFFICIENT TRANSMISSION
Your vehicle has been designed to improve
fuel economy by reducing fuel usage
while coasting or decelerating. This may
be perceived as a light to medium braking
sensation when removing your foot from
the accelerator pedal.
REAR WINDOW BUFFETING
You may hear a pulsing noise when one or
both of the rear windows are open. Lower a
front window slightly to reduce this noise.
TIRE PRESSURE MONITORING SYSTEM
Your vehicle is equipped with a Tire Pressure
Monitoring System (TPMS) that displays a
low tire pressure warning light when one or
more of your tires are significantly under-
inflated. If this happens, stop and check your
tires as soon as possible. Inflate them to the
proper pressure. Refer to the Inflating Your
Tires section in the Wheels and Tires chapter
of your Owner’s Manual for more information.
LOCATION OF SPARE TIRE AND TOOLS
The temporary spare tire is under the
vehicle, just forward of the rear bumper.
The temporary spare is designed for
emergency use only and you should replace
it as soon as possible. The jack and tools are
in the access panel on the floor behind the
third-row seat. Make sure that you switch
o the deployable running boards* as well
as the automatic load leveling suspension
system* prior to jacking, hoisting or towing
your vehicle. For complete details on how
to change your tire, refer to the Wheels and
Tires chapter in your Owner’s Manual.
page 13
page 12
To exit the third-row seating area
1. Pull the strap located at the bottom
outboard of the seatback to release
it from the floor. Rotate it up toward
the front seat.
2. Continue pulling up on the pull strap
and the seat will flip forward.
3. To return the seat to the upright
position, push the seat down until
it is latched.
4. Then, li the seatback and the head
restraint to the upright position.
MOONROOF
*
The moonroof control is located on the
overhead console. It has a one-touch
open and close feature. To stop its motion
during the one-touch operation, press the
control a second time.
To open, press and release the SLIDE
control. It will stop short of the fully
opened position to help reduce wind
noise. Press the SLIDE control again to
fully open the moonroof. To close, pull
and release the SLIDE control.
To vent, press and release the TILT
control. Pull and hold the TILT control to
close the moonroof.
*if equipped
ROADSIDE ASSISTANCE
Your new Ford Expedition comes with
the assurance and support of 24-hour
emergency roadside assistance.
To receive roadside assistance in the
United States, call 1-800-241-3673.
In Canada, call 1-800-665-2006.
Page 8
NAVIGATION SYSTEM
*
Set your destination by using your
touchscreen or voice commands.
To program a destination using
the touchscreen
1. Press the DEST button and “Accept” when
the “Terms of Use” screen appears.
2. Select from the following:
a. Quick: allows you to cancel the route,
access emergency destinations (such as
police stations or hospitals), save your
favorite destinations to presets for quick
access, find the nearest point of interest
(POI), and recall a previous destination
or entry from your address book to set
as a current destination.
b. Standard: allows you to set a
destination using any of the following:
i. Address Book
ii. Previous Destination
iii. Phone Number
iv. Map
v. Street Address
vi. POI
vii. Freeway Exit/Entrance or
Intersection
FUNCTION
page 15
page 14
c. Edit Route: allows you to make any adjustments to the
currently selected navigation route such as:
i. Cancel
ii. Detour
iii. View Route
iv. Edit Route Preferences
v. Edit Trac Preferences
vi. Edit Destination/Way Points
vii. Edit Turn List
Note: Periodic map updates are available at an additional cost.
Call 1-800-NAVMAPS (in Mexico, call 01-800-557-5539)
or visit www.navigation.com/ford.
*if equipped
REAR VIEW CAMERA*
The rear view camera system is on the ligate and
provides a video image of the area behind the vehicle.
The display will automatically appear on the navigation
system screen* or in the interior mirror whenever the
vehicle is in reverse (R) and uses colors (green, yellow
and red) to alert you of your proximity to objects.
FORWARD AND REVERSE SENSING SYSTEMS
*
If equipped, these systems may warn you if there is
an object in front of or behind the vehicle. The system will sound a warning tone that
increases in frequency as the object gets closer and will sound continuously when the
object is less than 10 inches (25.4 centimeters) away.
Note: Visibility aids do not replace the need to watch where the vehicle is moving. Refer to
your Owner’s Manual for safety information, more details and limitations.
UNIVERSAL GARAGE DOOR OPENER
*
Your driver’s side visor has a built-in wireless transmitter that replaces the common handheld garage door opener. Additionally, you can program this system to security systems,
entry gates and home or oce lighting. Refer to the Universal Garage Door Opener chapter
in your Owner’s Manual for programming instructions.
Loading...
