Force RC WARHAWK, FCES03002T1, FCES03001T1, FCES03001T2, FCES03002T2 Instruction Manual
...
INSTRUCTION MANUAL
1/10 4WD ELECTRIC
SHORT COURSE TRUCK
1/10 4WD ELECTRIC
MONSTER TRUCK
FCES03001T1/T2
WARHAWK
™
OUTBREAK
™
FCES03002T1/T2
2
EN
WARHAWK
™
OUTBREAK
™
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC.
For up-to-date product literature, visit http://www.horizonhobby.com and click on the support tab for this product.
Safety Precautions and Warnings
As the user of this product, you are solely responsible for operating in a manner that does not endanger yourself and others or
result in damage to the product or property of others.
This model is controlled by a radio signal subject to interference
from many sources outside your control. This interference can
cause momentary loss of control, so it is advisable to always
keep a safe distance in all directions around your model as this
margin will help avoid collisions or injury.
• Never operate your model with low transmitter batteries.
• Always operate your model in open spaces away from
full-size vehicles, traffic and people.
• Never operate the model in the street or in populated areas
for any reason.
• Carefully follow the directions and warnings for this and any
optional support equipment (chargers, rechargeable battery
packs, etc.) you use.
• Keep all chemicals, small parts and anything electrical
out of the reach of children.
• Never lick or place any portion of the model in your mouth
as it could cause serious injury or even death.
• Exercise caution when using tools and sharp instruments.
• Take care during maintenance as some parts may have
sharp edges.
• Immediately after using your model, do NOT touch equipment
such as the motor, electronic speed control and battery,
because they generate high temperatures. You may burn
yourself seriously touching them.
• Do not put fingers or any objects inside rotating and moving
parts, as this may cause damage or serious injury.
• Always turn on your transmitter before you turn on the
receiver in the car. Always turn off the receiver before turning
your transmitter off.
• Keep the wheels of the model off the ground when checking
the operation of the radio equipment.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating.
Failure to operate the product correctly can result in damage to the product, personal property and cause serious injury.
This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product
or other property. This product is not intended for use by children without direct adult supervision. Do not use with incompatible
components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains
instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and warnings in the manual,
prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.
Meaning of Special Language:
The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious
injury OR create a high probability of superfi cial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility
of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury.
TABLE OF CONTENTS
Age Recommendation: Not for children under 14 years. This is not a toy.
Box contents............................................................................. 4
Specifi cations .......................................................................... 4
Vehicle Preparations .............................................................. 4
Charging the vehicle Battery....................................................... 4
CHARGING WARNINGS ..............................................................4
Installing Transmitter Batteries .................................................. 5
Transmitter Battery safety precautions ...................................... 5
Removing The Vehicle Body ........................................................ 5
Installing The Battery In The Vehicle .......................................... 5
Transmitter Controls .................................................................... 6
Getting Started............................................................................ 7
Installing The Vehicle Body ......................................................... 7
Operation................................................................................... 8
After Driving .............................................................................8
Motor care ................................................................................8
Maintenance ............................................................................ 9
Electronic Speed Control (esc) .................................................... 9
Electrical Layout .......................................................................... 9
Component Specifi cations ..................................................... 10
Binding ........................................................................................ 10
Failsafe ........................................................................................ 10
Shock Cleaning............................................................................ 10
Shock Parts Diagram ................................................................... 10
Troubleshooting Guide ........................................................... 11
Recommended Upgrades ....................................................... 11
Limited Warranty ..................................................................... 12
Contact Information................................................................. 13
FCC Information........................................................................ 13
Replacement Parts ................................................................. 14
Parts Diagram (Center Chassis) ............................................ 15
Recommended tools.................................................................... 15
Parts Diagram (Front End) ...................................................... 16
Parts Diagram (Rear End) ....................................................... 17
3
EN
WARHAWK
™
OUTBREAK
™
WATER-RESISTANT VEHICLE WITH WATER-RESISTANT ELECTRONICS
CAUTION: Failure to exercise caution while using this
product and complying with the following precautions
could result in product malfunction and/or void the warranty.
General Precautions
• Read through the wet conditions maintenance procedures
and make sure that you have all the tools you will need to
properly maintain your vehicle.
• Not all batteries can be used in wet conditions. Consult the
battery manufacturer before use. Caution should be taken
when using Li-Po batteries in wet conditions.
• Most transmitters are not water-resistant. Consult your
transmitter’s manual or the manufacturer before operation.
• Never operate your transmitter or vehicle where lightning may
be present.
• Do not operate your vehicle where it could come in contact
with salt water (ocean water or water on salt-covered roads),
contaminated or polluted water. Salt water is very conductive
and highly corrosive, so use caution.
• Even minimal water contact can reduce the life of your motor
if it has not been certified as water-resistant or waterproof. If
the motor becomes excessively wet, apply very light throttle
until the water is mostly removed from the motor. Running a
wet motor at high speeds may rapidly damage the motor.
• Driving in wet conditions can reduce the life of the motor. The
additional resistance of operating in water causes excess
strain. Alter the gear ratio by using a smaller pinion or larger
spur gear. This will increase torque (and motor life) when
running in mud, deeper puddles, or any wet conditions that will
increase the load on the motor for an extended period of time.
Wet Conditions Maintenance
• Drain any water that has collected in the tires by spinning
them at high speed. With the body removed, place the vehicle
upside down and pull full throttle for a few short bursts until
the water has been removed.
CAUTION: Always keep hands, fi ngers, tools and any
loose or hanging objects away from rotating parts when
performing the above drying technique.
• Remove the battery pack(s) and dry the contacts. If you have an
air compressor or a can of compressed air, blow out any water
that may be inside the recessed connector housing.
• Remove the tires/wheels from the vehicle and gently rinse the
mud and dirt off with a garden hose. Avoid rinsing the bearings
and transmission.
NOTICE: Never use a pressure washer to clean your vehicle.
• Use an air compressor or a can of compressed air to dry the
vehicle and help remove any water that may have gotten into
small crevices or corners.
• Spray the bearings, drive train, fasteners and other metal
parts with a water-displacing light oil or lubricant. Do not
spray the motor.
• Let the vehicle air dry before you store it. Water (and oil)
may continue to drip for a few hours.
• Increase the frequency of disassembly, inspection and
lubrication of the following:
• Front and rear axle hub assembly bearings.
• All transmission cases, gears and differentials.
• Motor—clean with an aerosol motor cleaner and re-oil
the bushings with lightweight motor oil.
Your new Force RC Oubreak or Warhawk has a special water-
resistant coating on the electronics to ensure reliable
performance in higher than average moisture conditions. This
conformal coating can offer mild protection from water, fuel
and motor spray.
• DO NOT
submerge this product under water for any period of
time. If it is submerged, it may result in damage or loss of function
.
• DO NOT pour water onto or allow excess water to come in
direct contact with the product.
• DO NOT use this product in wet or moist conditions such as
puddles, mud, and heavy wet or dew-covered grass.
• DO NOT operate this product in heavy rain or snow.
In case of excess exposure to water or debris, immediately
remove the component, wipe down the exterior with a soft
cloth, and allow it to fully dry before next use.
4
EN
WARHAWK
™
OUTBREAK
™
Frequency 2.4GHz
Run time 6-8 minutes
Included Battery 6 cell Ni-MH
Charge Time 10 hours
Compatible Batteries 6 -7 cell NiCad/NiMH and 2 cell LiPo
SPECIFICATIONS
VEHICLE PREPARATIONS
CHARGING THE VEHICLE BATTERY
1. Connect the battery pack to the charger.
2. Connect the charger to an AC power source.
3. Allow the battery pack to charge for 10 hours.
CAUTION: If at any time during the charge process the
battery pack(s) becomes hot to the touch, unplug the
battery immediately and discontinue the charge process.
CHARGING WARNINGS
WARNING: Failure to exercise caution while using this
product and comply with the following warnings could result in
product malfunction, electrical issues, excessive heat, FIRE, and
ultimately injury and property damage.
• NEVER LEAVE CHARGING BATTERIES UNATTENDED.
• NEVER CHARGE BATTERIES OVERNIGHT.
• Read all safety precautions and literature prior to use of this
product.
• Never leave the battery and charger unattended during use.
• Never allow children under 14 years of age to charge
battery packs.
• Never attempt to charge dead or damaged batteries.
• Never charge a battery if the cable has been pinched or
shorted.
• Never allow batteries or charger to come into contact with
moisture at any time.
• Never charge batteries in extremely hot or cold places
(recommended between 50–80°F (10–26°C)) or place in direct
sunlight.
• Always use only Ni-MH rechargeable batteries. This charger
cannot charge batteries such as “heavy duty”, “alkaline”,
“mercury” or “lithium” battery.
• Always connect to the charger correctly.
• Always disconnect the battery and charger after charging and
let them cool between charges.
• Always inspect the battery before charging.
• Always terminate all processes and contact Horizon Hobby if
the product malfunctions.
• Always make sure you know the specifications of the
battery to be charged or discharged to ensure it meets the
requirements of this charger.
• Always constantly monitor the temperature of the battery
pack while charging.
• Always end the charging process if the charger or battery
becomes hot to the touch or starts to change form during the
charge process.
• Always charge in a well ventilated area.
The vehicle battery charger produces 200 milliAmps per hour.
Divide the mAh capacity on the label of a battery by 200 to
know how long battery charging will require. For example, a
fully discharged 2000mAh battery requires 10 hours to charge.
BOX CONTENTS
1. Force RC® Outbreak™ (FCES03001T1/T2) or
Warhawk
™
(FCES03002T1/T2) Truck
2. Force RC
®
Pistol Grip Transmitter (FCE13000)
3. 200mA Battery Charger (DYNC1031)
4. Dynamite
®
Speedpack™ SPEEDPACK 2000MAH
7.2V Ni-MH battery (DYNB0020)
2
4
4 AA BATTERIES
REQUIRED, NOT
INCLUDED
3
#1
OR
5
EN
WARHAWK
™
OUTBREAK
™
• Never install damaged batteries.
• Never install batteries of mixed types or of different ages in
the transmitter.
• Always remove exhausted batteries.
• Always remove batteries before storing the transmitter.
• Low battery power can result in loss of control of the RC
vehicle.
TRANSMITTER BATTERY SAFETY PRECAUTIONS
REMOVING THE VEHICLE BODY
INSTALLING THE BATTERY IN THE VEHICLE
1. Remove the clip and swing the battery tray open.
2. Install a fully charged battery.
3. Swing the battery strap down.
4. Install the clip.
If desired, you can put foam blocks (ECX1053) in front of the battery
so the weight of the battery increases rear traction or in back of the
battery to increase steering response.
INSTALLING TRANSMITTER BATTERIES
1. Open the panel on the bottom of the transmitter.
2. Obey the battery plus (+) and minus (-) diagram in the
transmitter to install 4 AA batteries.
3. Close the panel.
We recommend using only alkaline AA batteries in the
transmitter.
CAUTION: If using rechargeable batteries, charge only
rechargeable batteries. Charging non-rechargeable
batteries may cause the batteries to burst, resulting in injury to
persons and/or damage to property.
6
EN
WARHAWK
™
OUTBREAK
™
TRANSMITTER CONTROLS
BATTERY LEVEL
INDICATOR
Solid blue: Battery
voltage is good (above
4.4V).
Flashing blue and buzzer
alarm: Battery voltage
is critically low (below
4.4V). Replace batteries.
TH TRIM
Adjusts the neutral point of
the electronic speed control.
Press the TH.TRIM button left
or right to make adjustments.
Descending tones indicate
moving away from center, a
solid loud beep indicates the
center position.
ST TRIM
Adjust to make the vehicle
drive straight when the
wheel is centered. Press
the ST.TRIM button left or
right to make adjustments.
Descending tones indicate
moving away from center,
a solid loud beep indicates
the center position.
POWER SWITCH
Turn the
transmitter
on or off.
ST RATE
Adjusts how far the front
wheels can turn when
the steering wheel is
turned to the limit.
SERVO REVERSING
Adjust to change the direction
of steering and throttle controls.
Press and hold the TH.R/N button
or ST.R/N button toward the
center of the transmitter for two
seconds until the transmitter
emits a beep.
3CH/ BIND BUTTON
This button serves as
both a bind button and a
channel 3 button.
STEERING WHEEL
Turn the wheel on the
transmitter to turn the
wheels on the vehicle..
THROTTLE TRIGGER
Controls power to motor for forward
or reverse (see TH. REV switch).
Stop
Reverse
(when TH.
REV switch
on N).
Forward
(when TH.
REV switch on N).
7
EN
WARHAWK
™
OUTBREAK
™
GETTING STARTED
1. Power on the transmitter.
3. Do a test of the transmitter’s control of the vehicle with
the vehicle’s wheels off the ground.
4. Start driving slowly, if the vehicle does not go straight,
adjust the steering trim buttons on the transmitter.
IMPORTANT: Seat the motor brushes by driving smoothly
on a fl at surface during use of the fi rst battery charge.
Properly seating the motor brushes will increase the life and
performance of the motor.
2. Power on the ESC.
INSTALLING THE VEHICLE BODY
8
EN
WARHAWK
™
OUTBREAK
™
• ALWAYS turn on your transmitter before you turn on the
receiver in the vehicle. Always power off the receiver before
turning your transmitter off.
• ALWAYS operate your vehicle in a wide open area. Operating
the vehicle in a small space or indoors can cause overheating
at low speeds. Operating at low speed increases heat in the
electronic speed control (ESC). Overheating can damage the
vehicle and failure may result.
OPERATION
WHEN YOU ARE FINISHED
• Seat the motor brushes by driving smoothly on a flat surface
during use of the first battery charge. Failing to do so can
greatly reduce motor performance and functional life.
• Prolong motor life by preventing overheating conditions.
Undue motor wear results from frequent turns, stops and
starts, pushing objects, driving in water and tall grass,
and driving continuously up hill.
• Over-temperature protection is installed on the ESC to
prevent circuit damage, but cannot protect the motor from
driving against heavy resistance.
MOTOR CARE
1. Power off the Electronic
Speed Control (ESC).
2. Disconnect the battery.
4. Remove the battery from the vehicle.
3. Power off the transmitter.
5. Recharge the battery.
9
EN
WARHAWK
™
OUTBREAK
™
MAINTENANCE
ELECTRONIC SPEED CONTROL (ESC)
Programming: The ESC comes with two jumpers pre-installed in
the REV: ON and BATT: Ni-MH confi gurations.
To disable reverse or change battery type to Li-Po, disconnect the
jumper from the default port and connect it to the desired port.
Power off the ESC, then power it back on.
If the jumpers are lost or not installed, the ESC will default to
REV: ON and BATT: Li-Po.
Operation LED Status Sound at Power UP
Stop OFF
Forward Blinks
Forward (full speed) Solid
Reverse Blinks
Brake Blinks
Brake (full brake) Solid
Ni-MH/Ni-Cd Battery 1 Short Beep
2S Li-Po Battery 2 Short Beeps
ESC Ready 1 Long Beep
Battery Low Voltage Blinks
Overheat Blinks
LED
ELECTRICAL LAYOUT
Included Part # Replacement Part # Description
A N/A DYNS1215
Motor
B DYN1062EC
DYN1060 7.2V Battery
C N/A SPMSS6170
Steering Servo
D FCES13001 FCES13001
Receiver
E DYNS2211
DYNS2210 Electronic Speed Control (ESC)
F
N/A
Channel 1
G
Channel 2
H
Bind Button
DYNC1031
DYNC0500
Battery Charger
EC3EC3
VCC
CH3
CH2
CH1
A
B
C
D
G
H
F
For correct operation, Channels 1
and 2 must be used as shown in the
wiring diagram. The motor can be
disconnected from the ESC at the
connectors in the wiring.
E
10
EN
WARHAWK
™
OUTBREAK
™
Transmitter
Frequency 2.4GHz
Channels 3
Power supply 4 AA cells
Electronic Speed Control (ESC)
Input Voltage 6.0–8.4 V
Electric Capacity (FET) Forward 40A/180A
Electric Capacity (FET) Reverse 20A/90A
PWM Frequency 1kHz
BEC Voltage 5V/2A
Size 36 x 31.7 x 18mm
Weight 65 g
Receiver
Size 31.5 x 20.5 x 13.2mm
Weight 6 Grams
Voltage 4.8V-6V
Servo
Voltage 4.8V~6V
Output Torque 41.66 oz (3 kg-cm)
Operating Speed 0.16sec/60 degrees of travel
Size 40.2 x 20.1 x 38.1mm
Battery
Type Ni-MH
Capacity 2000 mAh
Motor
Type 550 Brushed
Turns 15 turn
COMPONENT SPECIFICATIONS
BINDING
Binding is the process of programming the receiver to recognize
the GUID (Globally Unique Identifi er) code of a single specifi c
transmitter. The FCES13000 transmitter and FCES13001 receiver
are bound at the factory. If you need to rebind, follow the instructions below.
1. Hold the 3CH button, then turn on the transmitter. A blue
LED will begin flashing and the transmitter will begin
beeping. Release the 3CH button.
2. Power on the ESC. An LED on the receiver will flash slowly.
3. Press and hold the button on the receiver until the LED
flashes several times and then returns to a slow flash.
Release the button after the LED returns to a slow flash.
4. Turn off the transmitter, then turn it back on again. The
LED on the receiver should now be steadily lit, which
indicates binding is complete.
FAILSAFE
In the unlikely event that the radio link is lost during use, the
receiver will drive the servos to their pre-programmed failsafe
positions (normally full brakes and straight steering). If the
receiver is turned on prior to turning on the transmitter, the
receiver will enter failsafe mode, driving the servos to their
preset failsafe positions. When the
transmitter is turned on, normal
control is resumed.
To set failsafe, begin with the throttle
at neutral, then press and hold the
button on the receiver until the LED
begins to flash quickly. When the LED
changes to be steadily lit, the failsafe
position is set.
Failsafe must be set every time the
system is bound. Binding will reset
the failsafe setting.
SHOCK CLEANING
Oil-fi lled shocks will require regular maintenance due to the oil breaking down or getting dirty. This
maintenance should be performed after about every 3 to 5 hours of use, depending on the conditions that
the vehicle is used in.
• Remove the shock from the vehicle.
• Remove the cap from the shock body and dispose of fluid.
• Disassemble the shock. Clean thoroughly with DYN5505. Dry parts before assembly.
• Re-assemble the shock and refill the shock body with silicone fluid (30 weight recommended).
• Slowly move the shaft and piston up and down to remove air bubbles.
• Move the piston to the midway point of the body and install the cap.
• Wipe off any overflowing fluid.
• When properly filled, the piston should rebound about 3/8 in (9.5mm) after being pushed in fully.
• Re-install the shock on the vehicle.
Part # Description
23 FCESS233002 Shock Spring/Cap Set: 1:10 4wd All
24 FCESS233003 Front/Rear Shock Body & Rod End Set: 1/10 4WD All
25 FCESS233004 Front/Rear Shock Shaft & Seal Set: 1/10 4WD All
34 FCESS235000 Fastener Set, 38pcs: 1/10 4WD All
24
23
25
24
25
23
24
34
31
34
25
23
31
SHOCK PARTS
DIAGRAM
11
EN
WARHAWK
™
OUTBREAK
™
Part # Description Benefi t
KXSB2000EC 2 Cell 4000mAh LiPo Longer run times (LiPo Compatible charger required)
KXSC1002 Quick Charger Shorter charge times for the included battery, required for the LiPo upgrade battery
KXSS0500 Motor/ ESC Combo More speed, longer run times
SPMSS6180 Steering Servo Waterproof, better steering authority
SPM2335 DX2E ACTIVE Transmitter/
SR310 Receiver Combo
Spektrum compatibility, Waterproof receiver, Telemetry options:
SPM6743 DX2E ACTIVE Speedometer Bundle, SPM6744 DX2E ACTIVE Dashboard Bundle
Problem Possible Cause Solution
Short Run Time • Battery damaged/not charged
• Motor dirty or brushes worn
• Check/change battery
• Check/clean/replace
Sluggish Action • Motor dirty or brushes worn
• Bind in drivetrain
• Vehicle battery is not charged
• Check/clean/replace
• Clean/adjust
• Replace/recharge
Controls Reversed • ST. REV or TH. REV • Change switch position
Motor/ESC overheat • Running conditions putting a high strain on
the power system
• Avoid overly tall grass and muddy conditions
Doesn’t Operate • Transmitter batteries low
• Transmitter powered off
• ESC powered off
• Vehicle battery is not charged
• Replace/recharge
• Power On
• Power On
• Replace/recharge
Poor Range • Transmitter batteries low
• Receiver antenna damaged
• Replace/recharge
• Check/repair/replace
The system will not
connect
• Transmitter and receiver too near each other
• Transmitter and receiver too near large
metal objects (vehicles, etc.)
• Receiver accidentally put in bind mode so
receiver is no longer bound
• Move transmitter 8–12 feet (2.4–3.6m) from receiver
• Move away from large metal objects (vehicles, etc.)
• Rebind transmitter and receiver
The receiver goes into
failsafe mode a short
distance away from
the transmitter
• Check the receiver antenna to be sure it is
not cut or damaged
• Contact Horizon Product Support
• Make sure receiver antenna is in an antenna tube and
is above vehicle
The receiver quits
responding during
operation
• Low battery voltage
• Loose or damaged wires or connectors
between battery and receiver
• Completely recharge battery
• Do a check of the wires and connection between
battery and receiver. Repair or replace wires and/or
connectors
Receiver loses its
bind
• Transmitter accidentally put in bind mode,
ending bind to receiver
• Bind transmitter to receiver
TROUBLESHOOTING GUIDE
RECOMMENDED UPGRADES
12
EN
WARHAWK
™
OUTBREAK
™
LIMITED WARRANTY
10/15
DATE OF PURCHASE LIMITED WARRANTY
Horizon Hobby, LLC, (Horizon) warrants to the original
purchaser that the product purchased (the "Product") will be
free from defects in materials and workmanship at the date of
purchase.
What is Not Covered - This warranty is not transferable and does not
cover (i) cosmetic damage, (ii) damage due to acts of God, accident,
misuse, abuse, negligence, commercial use, or due to improper use,
installation, operation or maintenance, (iii) modifi cation of or to any part
of the Product, (iv) attempted service by anyone other than a Horizon
Hobby authorized service center, (v) Product not purchased from an
authorized Horizon dealer, (vi) Product not compliant with applicable
technical regulations, or (vii) use that violates any applicable laws,
rules, or regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON MAKES NO
OTHER WARRANTY OR REPRESENTATION, AND HEREBY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT
LIMITATION, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE
PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED
THAT THE PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF
THE PURCHASER’S INTENDED USE.
Purchaser’s Remedy - Horizon’s sole obligation and purchaser’s
sole and exclusive remedy shall be that Horizon will, at its option, either
(i) service, or (ii) replace, any Product determined by Horizon to be
defective. Horizon reserves the right to inspect any and all Product(s)
involved in a warranty claim. Service or replacement decisions are
at the sole discretion of Horizon. Proof of purchase is required for all
warranty claims. SERVICE OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE PURCHASER’S SOLE AND EXCLUSIVE
REMEDY.
Limitation of Liability - HORIZON SHALL NOT BE LIABLE FOR SPECIAL,
INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF
PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY,
REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN CONTRACT,
WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER
THEORY OF LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the liability
of Horizon exceed the individual price of the Product on which liability
is asserted. As Horizon has no control over use, setup, fi nal assembly,
modifi cation or misuse, no liability shall be assumed nor accepted for
any resulting damage or injury. By the act of use, setup or assembly,
the user accepts all resulting liability. If you as the purchaser or user
are not prepared to accept the liability associated with the use of the
Product, purchaser is advised to return the Product immediately in new
and unused condition to the place of purchase.
Law - These terms are governed by Illinois law (without regard to
confl ict of law principals). This warranty gives you specifi c legal rights,
and you may also have other rights which vary from state to state.
Horizon reserves the right to change or modify this warranty at any
time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services - Your local hobby store and/or
place of purchase cannot provide warranty support or service. Once
assembly, setup or use of the Product has been started, you must
contact your local distributor or Horizon directly. This will enable Horizon
to better answer your questions and service you in the event that you
may need any assistance. For questions or assistance, please visit our
website at horizonhobby.com, submit an inquiry to productsupport@
horizonhobby.com or call the toll-free telephone number referenced in
the Warranty and Service Contact Information section to speak with a
Product Support representative.
Inspection or Services - If this Product needs to be inspected or
serviced and is compliant in the country you live and use the Product
in, please use the Horizon Online Service Request submission process
found on our website or call Horizon to obtain a Return Merchandise
Authorization (RMA) number. Pack the Product securely using a
shipping carton. Please note that original boxes may be included, but
are not designed to withstand the rigors of shipping without additional
protection. Ship via a carrier that provides tracking and insurance for
lost or damaged parcels, as Horizon is not responsible for merchandise
until it arrives and is accepted at our facility. An Online Service Request
is available at http://www.horizonhobby.com/content/_servicecenter_render-service-center. If you do not have internet access,
please contact Horizon Product Support to obtain a RMA number along
with instructions for submitting your product for service. When calling
Horizon, you will be asked to provide your complete name, street
address, email address and phone number where you can be reached
during business hours. When sending product into Horizon, please
include your RMA number, a list of the included items, and a brief
summary of the problem. A copy of your original sales receipt must be
included for warranty consideration. Be sure your name, address, and
RMA number are clearly written on the outside of the shipping carton.
Provided warranty conditions have been met, your Product will be
serviced or replaced free of charge. Service or replacement decisions
are at the sole discretion of Horizon.
NOTICE: Do not ship LiPo batteries to Horizon. If you have
any issue with a LiPo battery, please contact the appropriate
Horizon Product Support offi ce. Warranty Requirements- For
Warranty consideration, you must include your original sales
receipt verifying the proof-of-purchase date.
Non-Warranty Service - Should your service not be covered by
warranty, service will be completed and payment will be required
without notifi cation or estimate of the expense unless the expense
exceeds 50% of the retail purchase cost. By submitting the item for
service you are agreeing to payment of the service without notifi cation.
Service estimates are available upon request. You must include this
request with your item submitted for service. Non-warranty service
estimates will be billed a minimum of ½ hour of labor. In addition you
will be billed for return freight. Horizon accepts money orders and
cashier’s checks, as well as Visa, MasterCard, American Express, and
Discover cards. By submitting any item to Horizon for service, you
are agreeing to Horizon’s Terms and Conditions found on our website
http://www.horizonhobby.com/content/_service-center_renderservice-center.
ATTENTION: Horizon service is limited to Product compliant
in the country of use and ownership. If received, a noncompliant Product will not be serviced. Further, the sender
will be responsible for arranging return shipment of the
un-serviced Product, through a carrier of the sender’s choice
and at the sender’s expense. Horizon will hold non-compliant
Product for a period of 60 days from notifi cation, after which
it will be discarded.
13
EN
WARHAWK
™
OUTBREAK
™
FCC ID: 2ABKFBER-TRV2
FCC INFORMATION
CONTACT INFORMATION
Country of Purchase Horizon Hobby Contact Information Address
United States of America
Horizon Service Center
(Repairs and Repair Requests)
servicecenter.horizonhobby.com/
RequestForm/
4105 Fieldstone Rd
Champaign, Illinois, 61822 USA
Horizon Product Support
(Product Technical Assistance)
www.quickbase.com/db/
bghj7ey8c?a=GenNewRecord
888-959-2306
Sales
sales@horizonhobby.com
888-959-2306
20 cm
FCC Statement:
This equipment has been tested and found to comply with the limits
for Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
This device complies with part 15 of the FCC
rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.
Note: Modifi cations to this product will void
the user’s authority to operate this equipment.
RF Radiation Exposure Statement:
1. This Transmitter must not be co located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits
set forth for an uncontrolled environment. This equipment should
be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
WARHAWK
™
OUTBREAK
™
14
Reference number Part # Description
1 FCESS231000 Front Bumper Set: 1:10 Outbreak, Warhawk
2 FCESS231001 Rear Bumper Set: 1:10 Outbreak, Warhawk
3 FCESS231002 Chassis Set: 1:10 4wd All
4 FCESS231003 Front/Rear Shock Tower Set: 1:10 4wd All
5 FCESS231004 Hinge Pin Set: 1:10 4wd All
6 FCESS231005 Servo Saver St w/Bell Crank & Posts: 1:10 4wd All
7 FCESS231006 Motor Mount, Servo and Batt Post Set: 1/10 4WD All
8 FCESS231007 Body Post Set (2): 1/10 4WD All
9 FCESS231008 Front/Rear Bumper Set: 1/10 Outbreak
10 FCESS232000 Front/Rear Differential Set (1): 1/10 4WD All
11 FCESS232001 Front/Rear Diff Ring/Pinion Set (1): 1/10 4WD All
12 FCESS232002 F/R Diff Cases and Outdrive Set (2): 1/10 4WD All
13 FCESS232003 Center Driveshaft Complete: 1/10 4WD All
14 FCESS232004 Center Driveshaft & Diff Gear Set: 1/10 4WD All
15 FCESS232005 Rear Driveshaft and Axle Set (2): 1/10 4WD All
16 FCESS232006 Front/Rear CV Set (2): 1/10 4WD All
17 FCESS232007 Spur Gear Set 68T (2): 1/10 4WD All
18 FCESS232008 Slipper Plate, Pads and Spring Set: 1/10 4WD All
19 FCESS232009 Wheel Hub & Pin Set (4):1/10th 4WD All
20 FCESS232010 Pinion Gear Set 15T, 16T, 17T: 1/10 4WD All
21 FCESS233000 Front Shock, Complete, (2): 1:10 4wd All
22 FCESS233001 Rear Shock, Complete, (2): 1:10 4wd All
23 FCESS233002 Shock Spring/Cap Set: 1:10 4wd All
24 FCESS233003 Front/Rear Shock Body & Rod End Set: 1/10 4WD All
25 FCESS233004 Front/Rear Shock Shaft & Seal Set: 1/10 4WD All
26 FCESS234000 Front/Rear Hub Set:1/10 4WD All
27 FCESS234001 Front Suspension Arm Set: 1:10 4wd All
28 FCESS234002 Rear Lower Suspension Arm Set: Warhawk
29 FCESS234003 Rear Lower Suspension Arm Set: Outbreak
30 FCESS234004 Link Set, Plastic: 1:10 4wd All
31 FCESS234005 Pivot Ball Set: 1/10 4WD All
32 ECX1015 5x10x4mm Ball Bearing (8)
33 ECX1055 10x15x4mm Ball Bearing (2)
34 FCESS235000 Fastener Set, 38pcs: 1/10 4WD All
35 DYNS1215 5-Turn 550 Brushed Motor
36 DYNS2210 Dynamite WP 60A FWD/REV Brushed ESC
37 FCES13000 2.4GHz Transmitter, 3-Channel
38 FCES13001 2.4GHz Reciever, 3-Channel
39 FCES43000 Wheel & Tire Set: 1:10 4wd Outbreak
40 LOS43006 Wheels (2) Warhawk
41 LOS43016 Tires (2) Warhawk
42 LOS43015 Wheel and Tires set, mounted (4), Warhawk
43 FCESS230000 Body, Black: 1/10 Outbreak
44 FCESS230001 Body, Red: 1/10 Outbreak
45 FCESS230002 Body, Purple/Black: 1/10 Warhawk
46 FCESS230003 Body, White/Blue: 1/10 Warhawk
REPLACEMENT PARTS
WARHAWK
™
OUTBREAK
™
15
1.5 mm
2 mm
RECOMMENDED TOOLS
14
13
3
18
7
31
6
31
30
7
38
35
7
3
7
20
18
17
33
3
36
34
34
34
34
34
34
34
34
13
34
13
34
6
PARTS DIAGRAM (CENTER CHASSIS)
WARHAWK
™
OUTBREAK
™
16
27
5
5
10
16
16
26
31
34
8
30
27
4
11
31
21
34
34
34
32
34
34
34
9
1
PARTS DIAGRAM (FRONT END)
WARHAWK
™
OUTBREAK
™
17
2
8
4
12
11
12
22
33
5
30
15
28
31
34
34
34
29
5
26
32
32 34
32
??
33
34
39
42
15
40
41
9
34
34
34
34
SCT
MT
SCT
PARTS DIAGRAM (REAR END)
WARHAWK
™
OUTBREAK
™
18
43,44
45,46
55126
Printed 09/2017
Force RC, the Force RC logo, Warhawk, Outbreak, Dynamite, Speedpack and the Horizon Hobby logo are trademarks or registered
trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. All other trademarks,
service marks and logos are property of their respective owners. All other trademarks, service marks and logos are property of their
respective owners
© 2017 Horizon Hobby, LLC.
Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC.
FCES03001T1/T2
FCES03002T1/T2
Loading...
