RA－WN11062A
IEEE 802.11b/g/n USB Wireless Module
Datasheet
Version A2
Document Release Date Modification
Version
A1
2010/12/27
Version
A2
2010/04/14 Qiu
1．First version
1．Second version
Initials Approved
Qiu
RASIN TECHNOLOGY (H.K.) CO., LIMITED http://www.rasintech.com.cn
RASINTECHNOLOGY (H.K.) CO.LIMITED
1．Introduction
Product Description
The RT5370 is a highly integrated MAC/BBP and 2.4 GHz RF/PA/LNA single chip with 150Mbps PHY rate
supporting. It fully complies with IEEE 802.11n and IEEE 802.11 b/g feature rich wireless connectivity at high
standards, delivers reliable, cost-effective, throughput from an extended distance. Optimized RF architecture and
baseband algorithms provide superb performance and low power consumption. Intelligent MAC design
deploys a high efficient DMA engine and hardware data processing accelerators without overloading the host
processor. The RT5370 is designed to support standard based features in the areas of security, quality of
service and international regulation, giving end users the greatest performance anytime in any circumstance.
Features
*CMOS Technology with PA, LNA, RF,
Baseband, and MAC Integrated.
*1T1R Mode with 150Mbps PHY Rate for Both
Transmit and Receiving.
*Legacy and High Throughput Modes
*20MHz/40MHz Bandwidth
*Reverse Direction Grant Data Flow and Frame
Aggregation
*WEP 64/128, WPA, WPA2,TKIP, AES,
WAPI *QoS-WMM, WMM-PS
*WPS,PIN,PBC
*Multiple BSSID Support
*USB 2.0
*Cisco CCX Support
*Low Power with Advanced Power Management
*Operating Systems - Windows XP 32/64, 2000,
Windows 7,Vista 32/64 , Linux, Macintosh
RASIN TECHNOLOGY (H.K.) CO., LIMITED
http://www.rasintech.com.cn
RASINTECHNOLOGY (H.K.) CO.LIMITED
2．simplified block diagram of the RX5370A
module is depicted in the figure below.
RASIN TECHNOLOGY (H.K.) CO., LIMITED http://www.rasintech.com.cn
RASINTECHNOLOGY (H.K.) CO.LIMITED
3．General Specifications
Model Name
Product Description
WLAN Standard
Host Interface
Major Chipset
Dimension
Weight
Operating Conditions
Voltage
Operating Temperature
Humidity Non-Operating
RA-WN11062A
USB 2.0 Wireless Module
IEEE 802.11 b/g/n ,Wi-Fi compliant
USB 2.0
Ralink RT5370
11mm X 34mm X 3.3mm
5g
-10~50℃
90% RH non-condensing (12 months among 0~40℃ )
Electrical Specfications
Frequency Range
Spread Spectrum
Transmission Distance
Data Rate
Transmit power
Data security
Receiver Sensitivity
2.412~2.462GHZ
DSSS
300m(The transmission speed may vary according to the
environment)
11n:150/135/120/90/60//54/45/30/15Mbps
72/65/57.8/43.3/28.9/21.7/14.4/7.2Mbps
11b:1/2/5.5/11Mbps
11g:6/9/12/24/36/48/54Mbps
11b:1/2/5.5/11Mbps
11g:6/9/12/24/36/48/54Mbps
14.12dbm
64/128/152bitWEP,WPA/WPA2,WPA-PSK/WPA2-PSK(TKIP/AE
S)
150M:-71dbm@10%PER
135M: -71dbm@10%PER
RASIN TECHNOLOGY (H.K.) CO., LIMITED
http://www.rasintech.com.cn
RASINTECHNOLOGY (H.K.) CO.LIMITED
Environment
Modulation Type
Operating System
54M:-71dbm@10%PER
11M:-84dbm@10%PER
6M:-89dbm@10%PER
1M:-93dbm@10%PER
Storage Temperature:-40~70℃(-40℉ ~158℉ )
Relative humidity:10%-90%
Non-condensing
Storage Humidity:5%~95%
Non-condensing
OFDM/CCK/16-QAM/64-QAM
Window98,ME,SE,XP,XP-64
Windows7，32/64, 2000,Vista,linux,mac
4．Power Consumption
RASIN TECHNOLOGY (H.K.) CO., LIMITED
http://www.rasintech.com.cn
RASINTECHNOLOGY (H.K.) CO.LIMITED
5. Mechanical Information
LED G + - V+
5 pin (pin to pin=2.54mm)
RASIN TECHNOLOGY (H.K.) CO., LIMITED http://www.rasintech.com.cn
RASINTECHNOLOGY (H.K.) CO.LIMITED
6．Pin Description
J1 VCC J5 LED
J2 UDM
J3 UDP
J4 GND
7. TEST PARAMETER
Test item
Test result
TX POWER
14.12 dbm -32.17dbm -2.32 khz -70 dbm
(54M)
RASIN TECHNOLOGY (H.K.) CO., LIMITED
EVM Freq ERR RX SENS
http://www.rasintech.com.cn
8．Antenna And Interface Connection Information
Interface and the antenna have the option
9. Product ordering information
RA－WN11062A CHIPSET, only support 802.11b/g/n, 5V voltage support
RA－WN11062A CHIPSET, only support 802.11b/g/n, 3.3V voltage support
And pls mark clearly your need about usb connection information.
10. How the host system do the labeling
The Host system using this radio module , should have label indicated “contains
FCC ID: AQF-WN11062A”
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
RASIN TECHNOLOGY (H.K.) CO., LIMITED http://www.rasintech.com.cn
FCC warning:
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generate, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body; And, when the module
mix into finished product should meet the requirement: installed and operated with
minimum distance 20cm between the radiator & your body．
