Page 1
Electronic Vacuum Cleaner
Electronic Vacuum Cleaner
TOTAL
360360
CLEANING
USER GUIDE
Page 2
Welcome
To the world of health and happiness
Let me introduce you to the all new
Forbes Ace. It's the prescription for the
right dose of power and style. Its Deep
Cleaning+ technology fights the
toughest dust and dirt. What's more, it
removes the dreaded, invisible, allergy
causing dust mites.
Dust mites are microscopic, health
threatening creatures that hide in
places where you least expect them -
in pill ows, mattresses, furniture,
carpets and even soft toys. These dust
mites cause common cold, runny
nose, sore throat, allergic rashes and
even asthma.
You can't defeat them as you don't
even see them. In fact, a single gram
of dust contains over 19,000 dust
mites.
But the smart, new Forbes Ace, with
Deep Cleaning+ technology, assures
you a dust mite free, healthy home. I
have also packed your ACE with a
number of unique features; each
specially designed so you can clean
your home faster and better.
As you read this manual, you will
discover the many ways in which you
can use your Forbes Ace. Now, you
not only give your family a spotlessly
clean home but also keep them safe
from health threatening allergies.
360
CLEANINGTOTAL
Page 3
Forbes Ace
The new, compact Forbes Ace comes equipped with
Deep Cleaning+. Its dynamic centrifugal motion takes
care of the toughest dirt, which contains the nastiest
dust mites. Not just that, dirt hidden beneath carpets
and mattresses will also be swept off in a jiffy, with the
advantage of the Deep Cleaning+ technology.
Your machine's power leaves even the remotest corners
of your home spotlessly clean. What's more, the Vario
Power technology allows you to adjust the suction
power for delicate cleaning of electronic systems as
well as for heavy duty cleaning of curtains and carpets.
Your Ace is packed with a number of accessories, each designed to make cleaning your home faster and more efficient.
The various Suction End Accessories that accompany
your Ace include:
Carpet Brush
Floor Brush
Corner Cleaner
All Surface Cleaner (brush face / upholstery face)
Precision Cleaner
Flexi Cleaner
Vacuumised Safe Bag
Computer Cleaner
Grill Cleaner
Coat Brush
Turbo Nozzle
These accessories can be used to suck out the hard-to-remove
dirt from carpets, floors, crevices and corners.
Colour of the machine is subject to variation.
The various Blower End Accessories that
accompany your Ace include:
Spray Jar
Aromiser
Car Wash Adapter
Corner Cleaner
Precision Cleaner
Apart from blowing dirt from hard-to-reach
areas, these accessories can also be used
creatively as per your requirement.
360
CLEANINGTOTAL
1
Page 4
Forbes Ace
for a healthy home
Most of us believe that a vacuum cleaner is meant only for cleaning the home, making it spotless and sparkling. But the Forbes
Ace does much more than that. It actually maintains a safe and healthy home. The Ace not only cleans but also ensures that
allergens are kept at manageable levels by removing dirt and fine dust. Thus, allergies from these sources are reduced as
much as possible.
Conventional vacuum cleaners suck up dirt and dust, only to release it back into the air of your
home. Also, their dust storage bags act as breeding grounds for the dust mites.
The unique air filtration process of the Forbes Ace Vacuum Cleaner ensures that the air expelled
Pure
fresh air
Tips on keeping your home healthy:
from the machine has passed through a 5-stage filtration process. Thus, only pure air is expelled
out. So, your Forbes Ace not only cleans the room, but filters the air as well!
Hot wash bed sheets, pillowcases and quilts in soapy water at least once every two weeks.
Vacuum mattresses with Forbes Ace regularly to pick up dead skin cells and dust mite faeces.
Vacuum floors regularly to ensure that there is no dust between tiles, etc.
Avoid using a feather duster for cleaning as it stirs up the dust. Instead, use a damp cloth to clean the furniture.
Vacuum upholstered furniture like sofas, couches at least once a week.
2
360
CLEANINGTOTAL
Page 5
Forbes Ace
advantage
Why should you do this cleaning? - Dust mites, the hidden enemy.
What is a dust mite? - House dust mites are microscopic, eight-legged insects that belong to the spider and tick family
(Arachnid family). Their scientific name is Dermatophagoides, which means a skin eater. It feeds on animal material with high
protein content like dead human skin and moulds.
Where are they found? - Dust mites favour warm, humid climates. They thrive in your home, in your beds, pillows, upholstery,
curtains, carpets, etc. Basically in any fixture of your home that traps dust. In fact, a single gram of dust contains nearly 19,000
dust mites.
What do they thrive on? - They feed on human skin, fungi growing on the skin, moulds and household dust. Damp and humid
conditions provide an ideal breeding ground for dust mites. In fact, one gram of human skin can feed thousands of these dust
mites for months!
Why are dust mites dangerous? - They are carriers of allergens that cause runny noses, watery eyes, itchiness of the
skin leading to rashes. Given their small size (100-150 microns) they can be inhaled easily. They could even lead to
health threatening allergies like asthma.
Forbes Ace's Unique 5-Stage Filtration Process:
Fabric Tissue
Dust Mites
Food Particles
Spores
Animal Dander
Human Skin
Particles
Moulds
Fine Dust
Particles
Large Dust
Particles
Particle Filter
(Paper Bag) (Cloth Bag)
Spores
Fine Dust
Particles
MouldsDust Mites
Spores
Fine Dust Filter
Moulds
Triple Micron Filter
(Specially Designed
Electric Filters with Carbon)
360
CLEANINGTOTAL
3
Page 6
MITE EXTRACTOR
The Forbes Ace comes equipped with Deep
Cleani n g+. A te c h n ology s p e c iall y
designed to rid your home of dust mites.
With 1300W of Deep Cleaning power,
your Ace is all set to keep you and your
family safe.
MITE WATCH
When the dust bag gets full, the suction
pre s s u re of the vacuum cleaner
automatically drops and there is a change
When you buy the Ace
you buy the best
in the machine’s
noise.
The Forbes Ace is
provided with an
amber coloured
visua l in dica tor,
w h i c h g l o w s ,
along with the red
power-on indicator, when the dust bag
becomes full. The red indicator can be
found next to the foot operated ON/OFF
switch.
MITE GUARD
This system ensures that the dust remains
in the vacuum cleaner and the expelled
air is clean.
Here, the air goes through a 5-stage
filtration system. The air passes through
the Particle Filter, the Fine Dust Filter and
finally through the three layered Micron
Filter. Making the air dust mite free and
therefore cleaner than the air that had
earlier entered the system.
MITE BUSTER
The Forbes Ace is a modern, hi-tech
solution to the problem of allergy causing
dust mites. The Forbes Ace's powerful
motor sucks in dirt and dust mites from
every nook and corner of your home, into
the Particle Filter.
To further protect your home from these
harmful dust mites, carry out the Mite
Buster Process soon after the completion
of vacuum cleaning and before disposing
the dust.
Connect the special Mite Buster Hose
between the suction end and the blower
end of the vacuum cleaner. Switch on
the Mite Buster. The harmful dust mites
will be inactivated by hot air generated
in the vacuum cleaner. The Mite Buster
4
360
CLEANINGTOTAL
Page 7
will switch off automatically after the
process is completed, in about 3-4
minutes. After the Mite Buster goes off,
please remove the Particle Filter and
dispose the now non-harmful dust in the
usual manner.
VARIO POWER
You can adjust the motor power of the
Ace as per the nature of the cleaning
task. All you have to do is press the Ace's
Suction Regulator touch switch to the
setting you desire.
When you buy the Ace
you buy the best
ensures that the right level of suction is
maintained consistently by your Ace.
The Suction Regulator switch can be set
to four different levels :
Low Setting : For delicate objects like
music system, lace curtains and curios.
Medium Setting : For normal cleaning of
floors and other hard surfaces.
High Setting : For heavy duty jobs like
cleaning carpets or mattresses.
Turbo Setting : For handling tougher dirt.
AUTO CORD WINDER
It allows easy and convenient storage
of the cord and prevents tangles by
pulling the cord to the desired length.
While storing, pull the plug from the socket
and push the foot pedal to retract it.
DOUBLE SWIVEL HOSE
The swivels, located at both ends of the
hose, ensure tangle-free usage.
DOUBLE EXTENSION TUBE
This helps you to adjust the length by
providing you with a convenience of using
a single / double extension tube. It enables
you to clean hard-to-reach places like
corners and reduces work strain.
STURDY BODY
The Ace is made of mild steel that adds
to the sturdiness of the machine and
acts as a safety mechanism, as it is able
to withstand high pressure.
The Forbes Ace is reinforced with
superior g rade, heat-resistant, ABS
plastic. It is, therefore, sturdier and able to
withstand more heat.
Your Ace’s in-built system then takes over
and controls the motor power. This stently
by your Ace.
360
CLEANINGTOTAL
5
Page 8
1. To begin using your Forbes Ace:
How to use
your Forbes Ace
Stand the
Euroclean
Ace on its rear
and open the
cover by
pressing the
front latch.
Remove the
plastic ring.
Insert a
disposable
Particle
Filter into the
Fine Dust
Filter.
Squeeze the
mouth of the
Particle
Filter and
replace the
plastic ring.
Spread the
open end of
the Particle
Filter around
the rim of the
plastic ring.
Press the
front cover
shut.
NOTE: For efficient cleaning empty the
Particle Filter after every use.
Change the bag after 5-6 usages.
Using the machine without this
filter will damage the unit.
6
360
CLEANINGTOTAL
Page 9
How to use
your Forbes Ace
2. Connect the double swivel hose to the
desired end. To lock it, rotate it clockwise.
3. Attach the double extension tube to the hose. Adjust the length of the tube by
selecting single/double extension tubes to access the hard-to-reach areas.
4. Attach the accessory required to the extension tube.
Save storage space by placing
your vacuum cleaner vertically
in a corner after use. An
extension tube holder has been
provided for locking in the
extension tube.
5. Pull the cord to the desired length
and plug it in. Press the ON/OFF switch
with your foot. The power indicator will
glow red.
360
CLEANINGTOTAL
7
Page 10
Accessories for Regular cleaning
with Forbes Ace
CARPET BRUSH
It is fitted with a steel plate that glides over
carpets without damaging the fibres. Its bidirectional movements help pick dirt from
the surface of the carpet.
FLOOR BRUSH
Its nylon bristles do a thorough job of
cleaning your tiles, wooden, granite or
marble floors. And its serrations help suck
in the dust. The chemical treatment of the
bristles ensures longer life.
CORNER CLEANER
Re ach c orners , crevice s and other
hideouts of dust and dirt. Also, use it to
banish dust hidden in folds and to dryservice your car.
Application areas:
Carpets, rugs and dhurries.
Use only on suction end.
Recommended Suction Regulator Power:
High (If the brush sticks to the carpet,
reduce to ‘medium’ to enable easier
movement.)
Application areas:
All types of floors and tiled surfaces.
Use on suction end.
Recommended Suction Regulator Power:
Medium
Application areas:
Sofa corners, wall corners, behind paintings
and electrical wiring, inside book shelves, wall
cabinets, heavy cupboards, refrigerators,
corners of rooms, net and mesh on windows,
under the bed etc.
Use on suction and blower end.
8
360
CLEANINGTOTAL
Recommended Suction Regulator Power:
High / Turbo.
Page 11
Accessories for Regular cleaning
with Forbes Ace
ALL SURFACE CLEANER
(Soft brush for Multi-purpose cleaning)
Its brush end has been designed to clean
hard surfaces like walls, wall hangings,
wooden, cane and metal furniture. Delicate
electronic equipment like stereo systems,
speakers, TV sets and VCRs can be
cleaned with the brush end of the All
Surface Cleaner.
ALL SURFACE CLEANER
(For upholstery cleaning)
Its upholstery face has a rubber lining that
protects delicate upholstery and linen. It is
designed keeping soft surfaces in mind,
and its wings can be angled to take the
shape of the object being cleaned. Use it to
remove dust from difficult-to-clean areas
like mattresses and curtains. Save on
laundry bills by ‘dry cleaning’ all these
things yourself!
Application Areas:
Walls , ceili n gs, TV s, VCR s , stereo
systems, speakers, wooden, cane and
metal furniture, wall hangings and picture
frames.
Use on suction end.
Re c o m m e n d ed Suction R e g u l a tor
Power:
Low.
Application Areas:
Upholstery, sofas, mattresses, cushions,
pillows and curtains.
Use on suction end.
Re c ommend e d Sucti o n Regul a tor
Power:
High / Turbo. (Use ‘low’ setting for lace
curtains and silk material.)
360
CLEANINGTOTAL
9
Page 12
Accessories for Special cleaning
with Forbes Ace
GRILL CLEANER
Removes caked dust from blinds,
grills, frames and other hard surfaces
with the Grill Cleaner’s bristles.
PRECISION CLEANER
Clean the keyboards and delicate
circuitry by attaching the Precision
Cleaner at the suction end. You can
blow balloons or rid tiny holes of dust
by fixing the Precision Cleaner at the
blower end of your vacuum cleaner.
Caution: While using from suction end,
please do not use it for more than 30
minutes at a time.
Application areas:
Venetian blinds, car radiators, behind
refrigerators, AC grills.
Use on suction end.
Recommended Suction Regulator Power:
High.
Application areas:
Co mpute r and type write r key boards,
electronic circuitry, etc.
Use on suction end or blower end.
Recommended Suction Regulator Power:
Low.
10
360
CLEANINGTOTAL
Page 13
Special cleaning
with Forbes Ace
COMPUTER CLEANER
Attach the computer cleaner to the
precision cleaner. The soft bristles help
you clean even the minutest dust on
your computer keyboard.
FLEXI CLEANER
Now you can reach above, along and
below a host of surfaces, otherwise
inaccessible. Insert and twist the two
sections of the flexi cleaner together
and then attach either the all-surface
cleaner or the corner cleaner.
Application areas:
Computer keyboards.
Use on suction end.
Recommended Suction Regulator
Power:
Medium / Low.
Application areas:
Cup b o a r d s , shelf-tops, corners o f
cabinets, pelmets, fans, tube light tops,
underneath tables and sofa sets, walls
and paneling.
Use on suction end.
Re c ommende d Sucti o n Regul a tor
Power:
High / Turbo.
360
CLEANINGTOTAL
11
Page 14
More than just cleaning
with Forbes Ace
SPRAY JAR
Fit it at the blower end and fill it
with the liquid to be sprayed. Start
the system and place your thumb
on the hole atop the jar to
commence spraying. Use the
regulator in the front to control the
cone of the spray (Turn clockwise
for a narrower cone; anticlockwise
for a broader cone).
VACUUMISED SAFE PAC
You can store all your valuables
safely and for as long as you want.
With the Vacuumised Safe Pac,
developed using the principle of
vacuum sealing. Made from highquality, multi-layered, co-extruded
vacuum grade film with a special
two-way valve, it’s based on the
simple fact that goods packed in
vacuum are protected from the
harmful effects of atmospheric air,
dust and insects.
N.B.: Instructions for using the Vacuumised Safe
Pac are printed on it.
Application areas:
Plants (Watering), Walls (Spray painting),
Rooms ( Pest control).
Use on blower end.
Recommended Suction Regulator Power:
Medium / High.
Advantages
lUnique - First of its kind to be developed
for vacuum cleaner usage.
lHigh quality - Safely store silk and zari
saris, woollen garments, quilts, jewellery,
documents and even electronic items.
lRe-usable - Use it over and over again.
lRange of sizes - Small, medium and
large, depending on item to be stored.
lEconomy - Save through proper storage;
no more worries about shabby silks or
moth eaten documents.
lSpace saving - Reduces storage space
required by almost half.
12
360
CLEANINGTOTAL
Page 15
More than just cleaning
with Forbes Ace
CAR WASH ADAPTER
Give a pressurised jet water wash to
your car/ automobile at home. Fit the
Car Wash adapter to the extension
tube and connect the water supply
pipe. Switch on the machine to get a
high force water jet.
The non return valve ensures that no
water enters the machine.
AROMISER
Use it to fumigate or freshen your
home. Load it with naphthalene
balls and connect it at the blower
end. It will diffuse hot naphthalene
vapour to keep out mildew, stale
odours and destructive pests. Or
sprinkle a few drops of perfume on
a cotton pad, insert it into the
Aromiser and diffuse scented air
through your home, upholstery and
clothes.
Application areas:
Cars, automobiles.
Use on blower end.
Advantages:
The pressurised power jet dislodges the
thick stains and layers of mud from your
automobiles easily and gives a wash
equivalent to that done at service stations.
Caution: Never connect this accessory to
the suction end of the vacuum cleaner
which otherwise will damage the machine.
Re c ommend ed Suc t ion Re g ulator
Power:
Turbo.
Application areas:
Cupboards, wardrobes, bedroom.
Use on blower end.
Re c ommend ed Suc t ion Re g ulator
Power:
Medium.
360
CLEANINGTOTAL
13
Page 16
Your Forbes Ace
can be put to many other other uses
Since I am a patient suffering from joint
pains, I could not clean my house on my
own. I always needed other’s help to clean
my house. It was a big problem when I had
to clean the shelves and ventilators which
need to be cleaned by standing on chairs.
Now, I have Euroclean in my hand, I can
remove the dust from any corner of my
house. It is also very useful to clean nonwashable rugs and carpets.
B Manjula, Shantinagar
Sunday midnight. No doctor - My wife was
suffering from pain in the back, legs,
thighs, waist, etc. I did not know what to
do. I just opened the cupboard to search for
a balm, but Euroclean caught my eye. I
used the hot air for a massaging action
and in half an hour my wife was sound
asleep.
D N Mukunda, Bangalore
It is so easy to starch cotton sarees with the
help of the blower of the Euroclean. Put the
revive powder diluted in water, add this
mixture in the spray jar and spray on the
saree. See how nicely the cotton saree gets
starched. When I tried this method it
worked out well.
Mangala Wagh, Mumbai
It was the first day of school after Diwali
vacation. My daughter's white canvas shoes
were not cleaned and had remained dusty.
Now, there was no time to wash and dry it.
Then we thought of the Euroclean and to
my surprise the shoes had regained their
whiteness and my daughter could wear
them to school.
Geethalaksmi R. Rao, Mumbai
It was on the occasion of my son’s birthday
party that my Euroclean served me the best.
The rooms were to be decorated with
balloons and it was really tiresome and
time consuming to blow balloons manually.
Just then I realised the blower end of
Euroclean could be used for this purpose
and within no time the room appeared nice
with colourful balloons. My son was
delighted at this.
Asim Kumar Sarkar, Kolkata
We have a huge green garden outside our
house. I am very fond of maintaining it. I
used to find it difficult to pick the small
leaves which fell on the grass making it
look dull. Once I tried my newly purchased
Euroclean to clean the garden. I tied it to
my back with the help of leather belts and
using the blower end could clean the
garden. From then onwards it has become
a regular maintenance tool for my garden.
Baburao Patil, Pune
14
360
CLEANINGTOTAL
Page 17
Taking care of your
Forbes Ace
1. Please read the manual
carefully before operating
your Forbes Ace. Keep
your manual properly for
future reference.
2. Make sure the local power
supply conforms to that
on the rati ng la bel o r
instruction.
3. Do no vacuum water and
inflammable materials.
4. Do not vacuum burning
material and ashes.
5. Do not use your Forbes
A c e w i t h o u t a m o t o r
protection filter.
6. Clear the Dust Chamber
when it becomes full.
7. If a blockage is found in
any brush, hose or tubes, do
not operate your Forbes
Ace. Only operate it after the
blockage has been cleared.
8. Do not store or use your
Forbes Ace close to high
temperature places.
9. Do not let children use your
Forbes Ace.
10. Turn off your Forbes Ace if
you sense any abnormal
noise, smell, smoke or any
other breakage during the
operations. Turn off the
switch and unplug it. Then
contact a service technician
for repair. Do not repair
attempt to repair it yourself.
11. If the power cord, switch or
motor is damaged, have
them repaired or replaced
only by a qualified service
technician.
12. Do not run over the power
cord with your Forbes Ace.
13. Do not trap the cable in
between a shut door or
allow it to rub against sharp
corners. Keep it away from
hot surfaces.
14. Please do not re-use a
worn out / torn Particle Filter.
15. It is recommended to use
only genuine Forbes Ace
Particle Filter and Fine Dust
Filter, specially designed
to retain dust and let air
pa s s thro ugh. D o not,
under any circumstances,
use an ordinary paper bag.
It damages the system and
m a y e v e n b u r n o u t
the motor.
16. Do not allow water or any
other liquid to be sucked
into the system. Take care
that the Spray Jar and
Aromiser are used from the
blower end only.
17. Before using the blower
end, ensure that the flexible
hose, Particle Filter and Fine
Dust Filter are dust-free.
18. Do not run the blower end
for more than 30 minutes
wi t h o ut a b re a k . T h e
suction end can be used
for 3 hours non-stop, after
which it should be rested
for half an hour.
19. Do not open the machine
for repairs / servicing on
y o u r o w n . F o r a n y
assistance please contact
y o u r n e a re s t s e r v i c e
station.
20. For Warran ty, Ter m s &
Conditions and the list of
C u s t o m e r R e s p o n s e
Centres, please refer to the
Service booklet.
REGULAR SERVICING
The Forbes Ace is designed to
provide you with years of
trouble-free performance. It
performs best and lasts even
longer if it is serviced regularly.
360
CLEANINGTOTAL
15
Page 18
Technical Specifications
Voltage : 230 V AC, 50 Hz
Current Rating : 5.9 Amps
Input Power (IEC)* : 1300 Watts
Suction of Motor* : 23030 Pascals (2350 mm/wc)
Blower Efficiency : 40 Lt./Sec.
Power Consumption : 1.3 Units/Hour
Gross Weight : 9.4 kg.
Thermal cut-out
Cut-off Temperature : 88 Centigrade ± 3 Degrees
Cut-in Temperature : 74 Centigrade ± 5 Degrees
(All figures are of nominal value)
*At mean sea level (MSL)
The Forbes Advantage
0
0
S
E
T
D
I
W
Y
A
R
AR
O
F
E
A
C
C
16
360
S
E
I
R
O
S
S
CLEANINGTOTAL
A
L
T
V
O
10
E
R
N
E
R
A
R
E
V
O
N
1
S
E
S
U
E
V
I
T
2
S
.5
A
MI
T
I
S
F
I
E
LLIO
U
C
D
S
R
E
M
O
T
S
Page 19
Produced for Forbes Lux Group, Switzerland
Contact Address: Forbes Lux FZE
For more information visit us at www.forbeslux.com
P.O. Box 261698, Dubai, UAE.
Loading...
