GF55 & GFI55
OWNER'S MANUAL
Freestanding and Fireplace
Insert Pellet Stove
WARNING:
Improper installation, adjustment, alteration,
service or maintenance can cause
injury, property damage, or loss of life.
Refer to this manual. For assistance or
additional information consult an authorized
installer or service agency.
Tested by:
IMPORTANT: SAVE THESE INSTRUCTIONS
GF55-079
FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4
FOR YOUR SAFETY:
Do not store or use gasoline or other fl ammable
vapours and liquids in the vicinity of this or any other
appliance.
Installation and service must be performed by an
authorized installer or service agency.
01/11/08
TO THE NEW OWNER
Congratulations! You are the owner of a state-of-the-art Pellet Stove.
Thank-you for purchasing a
FPI FIREPLACE PRODUCT.
The pride of workmanship that goes into each of our products will give you years of trouble-free
enjoyment. Should you have any questions about your product that are not covered in this manual,
please contact the GREENFIRE DEALER in your area.
Safety Note: If this stove is not properly installed, a house fi re may result. For your safety,
follow the installation instructions, contact local building, fi re offi cials, or authority having jurisdiction
about restrictions and installation inspection requirements in your area.
The authority having jurisdiction should be consulted before installation to determine the need to
obtain a permit.
2
Greenfi re Pellet Stove and Insert Owner's Manual
TABLE OF CONTENTS
SAFETY LABEL
Copy of Serial No. Decal ...............................................4
INSTALLATION
Safety Warnings & Recommendations ..........................5
Important Safety Information .........................................6
Pellet Quality .................................................................6
OPERATING INSTRUCTIONS
Control Board Functions ................................................7
Automatic Safety Features ............................................7
Operating Your Pellet Stove ..........................................8
Manual Mode ............................................................8
High / Low Mode ......................................................8
Auto / Off Mode .........................................................8
Slider / Damper Set-Up .................................................9
MAINTENANCE
Routine Cleaning & Maintenance ................................10
Opening the Door ...................................................10
Burn Pot & Liner .....................................................10
Door Glass Cleaning ..............................................10
Ash Pan & Door Gaskets ........................................10
Ash Pan .................................................................. 11
Heat Exchanger Tubes ...........................................11
Fresh Air Intake ...................................................... 11
Exhaust Vent .......................................................... 11
Blower Mechanisms ...............................................11
All Hinges ...............................................................11
Exhaust Passages ..................................................12
Post Season Clean-Up ...........................................12
Cleaning Plated Surfaces .......................................12
Firebox Panel .........................................................12
Replacing Door Glass ............................................12
WARRANTY
Warranty ......................................................................13
Exclusions and Limitations ..........................................14
Greenfi re Pellet Stove and Insert Owner's Manual 3
SAFETY LABEL
To Start Stove: Press the ON / OFF button. If the auger
needs to be primed, press the Manual Auger Feed button until fuel starts to drop into the Burn Pot.
To Operate Stove:
MANUAL MODE: When a
fire has been established the stove set
tings
are
adjustable. / HIGH/LOWMODE: (Requires a the
rmostat) When
the
the
rmostat calls for heat the stove settings are adjustable. When the thermostat contacts open, the HEA
T LEVEL and Fans will drop down to the LOW
setting until the thermostat contacts close again. / AUTO/OFF MODE: (Requires a thermostat) When the the
rmostat contacts close, the unit will light
automatically. Once
up to temperature the stove settings are adjustable. When the the
rmostat con
tacts open, the stove will drop down to the LOW settings
for
30 minutes. If
within the 30 min the thermostat contacts close, the HEA
T LEVEL will return
to previous MANUAL setting or if the thermostat contacts remain
open the stove begin its shutdown routine.
To Turn Off Stove: MANUAL an
d HI
/ LOW mode: Press the ON / OFF button
AUT
O / OFF mo
de: Turn the thermostat down or off.
The unit
canbeinstal
led on a hard,
stable non-
comb
ustible surf
ace.
L'unit
é
peut
être inst
allée sur un dur,
la
surface non-combustible stable.r.
Certified for use in Canada & USA
Cert
ifié pour inst
allation
au
Canada et aux Etats-Unis.
Listed Room Heater, Pelletized Fuel Type (Appareil de chauffage à granules certifié)
Suitable For Mobile Home Installation (Accepté pour l'installation dans une maison mobile, test)
Tested to (Testée selon):
U
L
14
82-1998 / U
LC S
627-00 / AST M 150 9-95/ ULC S628-
M93
This pellet appliance has been tested and listed f
or use
in manufactured homes in ac
cord
ance with
Oregon
Administration Rules 814-23-900 through 814-23-909. Instal
l and use only in accordance with the Manufacture’s
installation and operating instructions. Contact lo
cal building or fire offic
ials about restrictions and insta
llation inspectio
n in
you
r area. Do not connect this u
nit to a chimney flue serving
another appliance. See local
building c
odes and
manufacturers instructions
for precautions
required for passing a chimney through a combustible wall or ceiling. Electrical
rating: 120 volts, 60 hz, 4.3 Amps. Route cord away
from the heater.
Cet appareil a été testé et certi
fié pour utilisation
dans les maisons mo
biles en
accord avec les "Règles
Administ
rat
ives de l'Oregon 814-23-900 à 814-23-909". Installez et utilis
ez
cet appareil seu
lement
selon les
instructions d'installation et d'opération du fabricant. Contactez
les autorités locales de votre quartier concernant les
restrictions et les inspections d'installation. Consultez les codes de bâtiment locaux et les instructions du fabricant
pour
les
précautions à prendre lorsque une cheminée doit être instal
lée au travers un mur ou un plafond
combustible. CLASSEMENT ÉL
ECTRIQUE : 120 Volts, 60 Hz, 4.1
Amps. Placez le câble électrique loin de l
a
chaleur
.
For
Use With Only Pelletized Wood fuels. Operate only with viewing door and ash removal door
cl
osed. Onl
y re
place
glass w
ith ceramic glass. Components required for insta
llation: a 3 inch (75 mm) or 4i
nch
(100 mm) list
ed PL vent,
complete with components. Insert and Hearth mount install
ations; a l
ist
ed single wall chimney liner may be used. Inspect
and clean Exha
ust
Ve
nting system f
req
uently.
Utilisation
avec les combustibles sous forme de bou
lets uniquement.
Utiliser seulement lorsque les portes avants et la
porte du r
écept
acle
de c
endre sont fermées. Si une ou des vitres devaient être remplac
ées,
utilisez seulement du
verre céramique. Les composantes requises pour l'installation son
t un év
ent PL certifié de 3in/75mm or 4in/100mm
avec ses composantes.
Les installatio
ns
inser
tion et de mont de foyer ; un paquebot de chemin
ée de mur de s
eul
énumér
é peut être utilisé.
Input Rating (Les données évaluant):
12
,000 to 45,000 BTU/Hr (3.5 to 13.2 kWh
)
334
DATE OF MANUFACTURE /
DATE DE FABRICATION:
GF55-081 J F M A M J J A S O N D 2008 2009 2010
CAUTION:
Hot while operating. Do not
touch, severe burns
may
result. Keep children, clothing,
furniture, gasoline or other
flammable vapors away
.
ATTENTION:
Très chaud quand allumé. Ne touche
z pas,
les brûlures sévères peuvent résulter.
Tenez loin des enfants, des vêtements, des
meubles,de l’essence ou d’autres fluides
produisant des vapeurs inflammables.
DO NOT REMOVE THIS LABEL /
NE RETIREZ PAS CETTE ÉTIQUETTE
See installation and operating instructions accompanying appliance. /
Consultez le manuel avec les instructions d’installation et d’opération
.
A Sidewall to Unit (Du mur de côté à l'appareil) 8” (203 mm)
B Top of unit to an unshielded 8” (20
3 mm) man
tle
(Le sommet de l'unité à un manteau de c
heminée non blindé) 8” (203 mm)
C
Unit
to top
facing (protruding ¾” [19 mm])
(
De l'unité au s
ommet du
pa
rement)
8” (20
3 mm)
D Unit to side
fac
ing (protruding ¾” [19 mm])
(
De l'
unité
au côté du parement)
8” (203 mm)
E From door opening of
unit to edge of floor protection
(De
la po
rte ou
vran
t au devant de protec
tion de plancher) 6” (152 mm)
F From side of un
it
to edge of floor protection
(De l'
ouverture
de
porte pour
prendre
parti de p
rotection de plancher)
6” (152 mm)
Combustible floors must be protected by a
non-combustible material.
- See Owners Manual.
Le plancher combustible doit être protégé par
un matériel incombustible.
- Consultez le manual.
INSTALLED AS A FIREPLACE INSERT STOVE MODEL (GFI55) / A INSTALLE
COMME UN MODÈLE
SUR PIED DE POELE.
Min
imum clearances to combustib
le materials./ Les dégagements minimums aux matériels
combustibles:
A Sidewall to U
nit
(Du mur de côté à l'appareil) 6” (152 mm)
B Backw
all t
o Unit (Du mur de der
rière à l'appareil) 3”
(76 mm)
C
Corner to Unit (Du coin à l'appareil) 2” (51 mm)
D Wall to vent (Le mur pour donner vent)
3” (76 mm)
E From door opening of unit to edge of flo
or protection
(De la po
rte ou
vran
t au de
vant de protec
tio
n de plan
cher) 6” (
152 mm
)
N
OTE: A combustible
f
loor mus
tbeprotected byanon-
c
om
bustible m
ateria
l
-Wi
dth 27" (
686m
m) by depth 34"
(
864mm). (U
n plancher combustible doitetre
protege
par un
mater
i
el
i
ncombust
ible. La largeur 27" (686 mm) par la
pr
ofondeur 34" (86
4
m
m).)
Minimum Alcove Width (
La largeur minimum de l'alcove) 36” (914 mm)
Minimum Alcove Height (La hauteur minimum de l'alcove) 48” (1219 mm)
Maxi
mum Alcove
Depth (La profondeur maximum de l'alcove) 3
0” (762 mm)
INS
TAL
LED
AS A FREESTANDING STOV
E MODEL (GF55) / A INSTALLE COMME UN
MODÈLE FS, QU’IL SOIT ENCASTRÈ, SUR PIED OU DANS UNE MAISON MOBILE.
Minimum cle
arances to c
ombustible materials./ Les dégagements minimums aux matériels
combustibles:
Ser
ial No. / No. De Serié:
Greenfire GF55 (Stove) GFI55 (Insert)
Model /
Modèle:
15956
B
A
D
C
Adjacent wal
l
F
E
Floor Protection
A
B
C
E
Backwall
Sidewall
D
Pou
r démarrer le poêle: Appuyer sur le bouton "ON/OFF". Si le Auger nécessite d'être amorc
é, appuyer sur l
e bouton manuel d'alimen
tation du Auger jusqu'à ce que l
es granules se déversent dans le pot de combu
stion.
Pour faire fonctionner le poêle :
MOD
E
MANUEL : Lorsque le feu
est bien établi, les rég
lages
peuvent être ajustés. / MODE
"HIGH/LOW" : (Nécessite un thermostat)
Lorsque le thermostat requière de la cha
leur, les réglages peuvent être ajustés. Lorsque
les
contacts du
thermostat ouvrent, le réglage du niveau de chaleur et les ventilateur
s s'ajusteront au réglage " bas " jusqu'à ce que les contacts du
thermostat se ref
erment. / MODE "AUTO/OFF" : (Nécessite un thermostat)
Lorsque les contacts du thermostat ferment, le poêle
s'allumera
automatiquemen
t. Lorsque la températ
ure adéquate est atteinte, les réglages peuvent être ajustés. Lorsque les contac
ts
du the
rmostat ouvrent, le poêle s'ajustera aux réglages "LOW" pendant 30 minutes. Si les contacts du thermostat sont fermés pendant
ces 30
minutes, le réglag
e de niveau de chaleur retournera en réglages "MANUEL" ou si les contacts du thermostat restent ouver
ts, le poêle entam
era le processus d'arrêt.
Pour éteindre le poêle : MODE MANUEL ET " HIGH/LOW " : Appuyer sur le bouton "ON/OFF".
MODE "AUTO / OFF" : Régler le thermostat à la b
aisse ou ét
eignez le.
Man
ufactured in Canada for /
Fabriqué dans le Canada pour:
FPI Fireplace Products International
Ltd.
Delta, BC, Ca
nada
This is a copy of the label that accompanies each GF55 & GFI55. We have
printed a copy of the contents here for
your reference.
On the GF55 the safety label is located
on the underside of the hopper lid.
On the GFI55 the safety label is located
on the hopper cover behind the top
faceplate.
INSTALLATION
4
Greenfi re Pellet Stove and Insert Owner's Manual
SAFETY WARNINGS & RECOMMENDATIONS
CAUTION:
Do not connect to any air distribution duct or system.
Do not burn garbage or fl ammable fl uids such as gasoline,
naptha or engine oil.
Unit hot while in operation. Keep children, clothing and furniture away. Contact may cause skin burns.
INSTALLATION
INSTALLATION
SMOKE DETECTOR: Smoke detectors should be installed and
maintained in the structure when installing and operating a pellet burning
appliance.
OPERATION: The ash pan and door must be closed securely for proper
and safe operation of the pellet stove. Also ensure all gaskets on the door
are checked and replaced when necessary.
FUEL: This pellet stove is designed and approved to only burn wood
pellet fuel with up to 3% ash content. Dirty fuel will adversely affect the
operation and performance of the unit and may void the warranty. Check
with your dealer for fuel recommendations.
THE USE OF CORDWOOD IS PROHIBITED BY LAW.
SOOT: Operation of the stove with insuffi cient combustion air will result in
the formation of soot which will collect on the glass, the heat exchanger,
the exhaust vent system, and may stain the outside of the house. This is
a dangerous situation and is ineffi cient. Frequently check your stove and
adjust the slider/damper as needed to ensure proper combustion. See
"Slider/Damper Setting".
CLEANING: There will be some build up of fl y ash and small amounts of
creosote in the exhaust. This will vary due to the ash content of the fuel
used and the operation of the stove. It is advisable to inspect and clean
the exhaust vent semi-annually or every two tons of pellets.
ASHES: Disposed ashes should be placed in a metal container with a tight
fitting lid. The closed container of ashes should be on a non-combustible
floor on the ground, well away from all combustible materials pending
final disposal. If the ashes are disposed of by burial in soil or otherwise
locally dispensed, they should be retained in the closed container until all
cinders have been thoroughly cooled.
ELECTRICAL: The use of a surge protected power bar is
recommended. The unit must be grounded. The grounded electrical
cord should be connected to a standard 115 volts (4.6 Amps), 60 hertz
electrical outlet. Be careful that the electrical cord is not trapped under
the appliance and that it is clear of any hot surfaces or sharp edges and
also must be accessible. If this power cord should become damaged, a
replacement power cord must be purchased from the manufacture or
a qualifi ed Greenfi re dealer. This unit's maximum power requirement is
520 watts.
KEEP ASH PAN FREE OF RAW FUEL.
DO NOT PLACE UNBURNED OR NEW PELLET FUEL IN ASH PAN. A
FIRE IN THE ASH PAN MAY OCCUR.
INSTALLATION: Be sure to maintain the structural integrity of your
home when passing a vent through walls, ceilings, or roofs. It is
recommended that the unit be secured into its position in order to avoid
any displacement.
DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST VENTING
SYSTEM OF THIS UNIT.
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING
ANOTHER APPLIANCE.
FRESH AIR: Outside Fresh Air connection is optional. Must be
connected to all units installed in Mobile and “Air Tight Homes” (R2000)
or where required by local codes. Consider all large air moving devices
when installing your unit and provide room air accordingly. Limited air
for combustion may result in poor performance, smoking and other side
effects of poor combustion.
If you have any questions with regards to your stove or the abovementioned information, please feel free to contact your local dealer for
further clarification and comments.
SINCE FPI HAS NO CONTROL OVER THE INSTALLATION OF YOUR
STOVE, FPI GRANTS NO WARRANTY IMPLIED OR STATED FOR THE
INSTALLATION OR MAINTENANCE OF YOUR STOVE. THEREFORE,
FPI ASSUMES NO RESPONSIBILITY FOR ANY CONSEQUENTIAL
DAMAGE(S).
GLASS: Do not abuse the glass by striking or slamming the door. Do not
attempt to operate the stove with broken glass. The stove uses ceramic
glass. Replacement glass must be purchased from an Greenfire dealer.
Do not attempt to open the door and clean the glass while the unit is in
operation or if glass is hot. To clean the glass, use a soft cotton cloth and
mild window cleaner, gas or wood stove glass cleaner, or take a damp
paper towel and dip into the fly ash. This is a very mild abrasive and will
not damage the glass.
FLAMMABLE LIQUIDS: Never use gasoline, gasoline-type lantern fuel,
kerosene, charcoal lighter fluid, or similar liquids to start or “freshen up”
a fire in the heater. Keep all such liquids well away from the heater while
it is in use.
Greenfi re Pellet Stove and Insert Owner's Manual 5
Loading...
