UNVENTED (VENT-FREE) FIREBOX
PFS
®
US
OWNER’S OPERATION AND INSTALLATION MANUAL
MODEL FBPS, FGPN AND FGPN-LS
36" Peninsula Heat-Circulating Firebox
WARNING: If the information in these instructions
is not followed exactly, a re or explosion may result
causing property damage, personal injury or death.
FOR YOUR SAFETY
— Do not store or use gasoline or any other ammable
vapors or liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS :
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re
department.
— Installation and service must be performed by a quali-
ed installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For more information, visit www.fmiproducts.com
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Refer to this manual for correct installation and operational procedures. For assistance
or additional information consult a qualied installer,
service agency or the gas supplier.
WARNING: For use only with decorative type unvented room heaters. Do not build a wood re.
This firebox has been tested and approved by the
PFS Corporation for use with any ANS Z21.11.2
approved gas logs.
This rebox may be installed in an aftermarket*, perma-
nently located, manufactured (mobile) home, where not
prohibited by state or local codes.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.
TABLE OF CONTENTS
Safety .................................................................. 2
Local Codes......................................................... 4
Unpacking............................................................ 4
Product Features ................................................. 4
Product Specications ......................................... 5
Locating Firebox .................................................. 5
Air for combustion and Ventilation ....................... 6
Installation ........................................................... 8
Operating Guidelines and Maintenance
Instructions ..................................................... 16
Replacement Parts ............................................ 16
Technical Service............................................... 17
Accessory .......................................................... 17
Parts .................................................................. 18
Warranty ..............................................Back Cover
SAFETY
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, operate or service this rebox.
Improper use of this rebox can
cause serious injury or death
from burns, re, explosion, electrical shock or carbon monoxide
poisoning.
www.fmiproducts.com
CAUTION: Carefully review
the instructions supplied with
the decorative type unvented
room heater for the minimum
rebox size requirement. Do not
install the appliance in this rebox unless this rebox meets the
minimum dimensions required
for the installation.
WARNING: Any change to
this rebox or its controls can
be dangerous.
105163-01E2
SAFETY
Continued
WARNING: Do not use a blow-
er insert, heat exchanger insert
or other accessory not approved
for use with this rebox.
Do not allow fans to blow directly
into the rebox. Avoid any drafts
that alter burner ame patterns.
Ceiling fans can create drafts
that alter burner ame patterns.
Altered burner patterns can
cause sooting.
Firebox front and screen becomes very hot when running
rebox. Keep children and adults
away from hot surfaces to avoid
burns or clothing ignition. Firebox will remain hot for a time
after shutdown. Allow surfaces
to cool before touching.
Carefully supervise young chil-
dren when they are in the room
with rebox.
You must operate this replace
with the provided fireplace
screen, hood and brick liner in
place. Make sure these parts are
in place and screens are closed
before running heater in rebox.
The supplied hoods may not be
replaced with hoods which may
be provided with a log heater.
Keep the appliance area clear
and free from combustible ma-
terials, gasoline and other ammable vapors and liquids.
1. This rebox shall not be installed in a
bedroom or bathroom.
2. Never install the rebox
• in a recreational vehicle
• where curtains, furniture, clothing or
other ammable objects are less than
42" from front, top or sides of rebox
• in high trafc areas
• in windy or drafty areas
3. Do not use this rebox as a wood-burning
replace. Use only decorative unvented
room heaters (log sets).
4. Do not add extra logs or ornaments such as
pine cones, vermiculite or rock wool. Using
these added items can cause sooting.
5. Use only the provided hoods or appropriate polished brass hood accessories. See
Accessories on page 17.
6. Vent-free gas log heaters installed in this
rebox require fresh air ventilation to run
properly. See Air for Combustion and
Ventilation, page 6.
7. Do not run heater in rebox
• where ammable liquids or vapors are
used or stored
• under dusty conditions
8. Do not use this rebox to cook food or
burn paper or other objects.
9. Never place any objects in rebox or on
logs.
10. Turn heater off and let cool before servic-
ing. Only a qualied service person should
service and repair rebox.
11. Operating vent-free logs in a rebox above
elevations of 4,500 feet could cause pilot
outage.
12. Do not use the rebox if it has been under water due to the shock hazard that
could result with the blower accessary (if
installed) in place.
13. Provide adequate clearances around air
openings.
105163-01E 3
www.fmiproducts.com
LOCAL CODES
Install and use rebox with care. Follow all
local codes. In the absence of local codes,
use the latest edition of The National Fuel Gas
Code ANS Z223.1/NFPA 54*. Firebox must
be electrically grounded in accordance with
the National Electrical Code, ANS/NFPA70
(latest edition).
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
UNPACKING
1. Remove all protective packaging from
inside rebox. Carefully lift the rebox off
the bottom corrugated tray.
2. Carton should contain 3 deective hoods
and hardware packet in addition to rebox
assembly. If items are missing, inform
dealer where you bought rebox.
3. Check heater for any shipping damage. If
heater is damaged call FMI PRODUCTS,
LLC at 1-866-328-4537 for replacement
parts before returning to dealer.
State of Massachusetts: The installation
must be made by a licensed plumber or
gas tter in the Commonwealth of Massachusetts.
Sellers of unvented propane or natural
gas-red supplemental room heaters shall
provide to each purchaser a copy of 527
CMR 30 upon sale of the unit.
Vent-free gas products are prohibited for
bedroom and bathroom installation in the
Commonwealth of Massachusetts.
NOTICE: The rebox identication label (including model
number, serial number, clear-
ances, etc.) is located directly
above the brick liner and under
the heat shield. See Figure 20,
page 16.
PRODUCT FEATURES
OPERATION
This rebox is designed for use with approved
ANS Z21.11.2 decorative type unvented room
heaters. (Physical size limitations apply. Refer
to minimum rebox requirements supplied
with log heater.) The maximum size log this
rebox will accept is: width of 32", depth of
19" and a height of 17".
This rebox requires no outside venting or
chimney making installation easy and inex-
pensive. When used without the blower, the
rebox requires no electricity making it ideal
for emergency backup heat.
www.fmiproducts.com
BLOWER ACCESSORY
The FBPS, FGPN and FGPN-LS rebox will
accept the GA3500A accessory. The variable
blower allows you to select the fan speed
you desire. The blower circulates heated air
from the rebox into the room. Use of blower
is optional.
BRICK LINER
This rebox features a concrete brick liner. As
with all concrete liners, this liner may develop
slight cracks when exposed to heat. These
cracks will not affect the performance of the
rebox or vent-free gas logs.
105163-01E4
3
5
/8"
4"
19 1/2"
1 1/2"
4 1/2"
4
3
/4"33 3/4"
3
5
/8"
4"
4"
1
1
/4"
1/2"
5/8"
19 1/2"
40"
18 1/2"
9
1
/8"
36 1/4"
1
3
/4"
4"
1 1/2"
24"
36 1/2"
3" TYP.
42 1/2"
(Edge of
Brick Liner)
PRODUCT SPECIFICATIONS
Figure 1 - Peninsula (Three-Sided) Firebox
PLANNING
Plan where you will install the rebox. This will
save time and money later when you install
the rebox. Before installation, consider the
following:
1. Where the rebox will be located. Allow for
wall and ceiling clearances (see Installa-
tion Clearances, page 9).
2.
Everything needed to complete installation.
3. This model CANNOT be installed in a
bedroom or bathroom.
4. Proper air for combustion and ventilation.
5. Consider a location where heat output
would not be affected by drafts, air condition ducts, windows or doors.
6. A location that minimizes modications
on existing framing will make installation
easier.
Projected installations can extend any
distance into the room. A projection may
be ideal as a partition between two oth-
LOCATING FIREBOX
erwise common areas when added to an
existing, nished wall (see Figure 2).
Internal wall installation provides a
discreet viewing option between two
adjacent rooms or within an added wall
to subdivide an oversize room.
Figure 2 - Projected Installation
105163-01E 5
www.fmiproducts.com
AIR FOR COMBUSTION AND VENTILATION
WARNING: This heater shall
not be installed in a room or
space unless the required volume of indoor combustion air
is provided by the method described in the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, the
International Fuel Gas Code, or
applicable local codes. Read the
following instructions to insure
proper fresh air for this and
other fuel-burning appliances
in your home.
Today’s homes are built more energy efcient
than ever. New materials, increased insulation
and new construction methods help reduce
heat loss in homes. Home owners weather
strip and caulk around windows and doors
to keep the cold air out and the warm air in.
During heating months, home owners want
their homes as airtight as possible.
While it is good to make your home energy
efcient, your home needs to breathe. Fresh
air must enter your home. All fuel-burning appliances need fresh air for proper combustion
and ventilation.
Exhaust fans, reboxes, clothes dryers and fuel
burning appliances draw air from the house to
operate. You must provide adequate fresh air
for these appliances. This will insure proper
venting of vented fuel-burning appliances.
PROVIDING ADEQUATE
VENTILATION
The following are excerpts from National
Fuel Gas Code ANS Z223.1/NFPA 54,Air for
Combustion and Ventilation.
All spaces in homes fall into one of the three
following ventilation classications:
1. Unusually Tight Construction
2. Unconned Space
3. Conned Space
The information on pages 6 through 8 will help
you classify your space and provide adequate
ventilation.
Unusually Tight Construction
The air that leaks around doors and windows
may provide enough fresh air for combustion
and ventilation. However, in buildings of unusually tight construction, you must provide
additional fresh air.
Unusually tight construction is dened as
construction where:
a. walls and ceilings exposed to the out-
side atmosphere have a continuous
water vapor retarder with a rating of one
perm (6 x 10
with openings gasketed or sealed and
b. weather stripping has been added on
openable windows and doors and
c. caulking or sealants are applied to
areas such as joints around window
and door frames, between sole plates
and oors, between wall-ceiling joints,
between wall panels, at penetrations
for plumbing, electrical and gas lines
and at other openings.
If your home meets all of the three criteria
above, you must provide additional fresh
air. See Ventilation Air From Outdoors,
page 8.
If your home does not meet all of the three
criteria above, proceed to Determining
Fresh-Air Flow for Firebox Location,
page 7.
Conned and Unconned Space
The National Fuel Gas Code ANS Z223.1/
NFPA 54 denes a conned space as a space
whose volume is less than 50 cubic feet per
1,000 Btu/hr (4.8 m3 per kw) of the aggregate
input rating of all appliances installed in that
space and an unconned space as a space
whose volume is not less than 50 cubic feet
per 1,000 Btu/hr (4.8 m3 per kw) of the ag-
gregate input rating of all appliances installed
in that space. Rooms communicating directly
with the space in which the appliances are
installed*, through openings not furnished
with doors, are considered a part of the unconned space.
This heater shall not be installed in a conned
space or unusually tight construction unless
provisions are provided for adequate combustion and ventilation air.
* Adjoining rooms are communicating only if
there are doorless passageways or ventilation
grills between them.
-11
kg per pa-sec-m2) or less
www.fmiproducts.com
105163-01E6
AIR FOR COMBUSTION AND VENTILATION
Continued
DETERMINING FRESH-AIR FLOW
FOR FIREBOX LOCATION
Determining if You Have a Conned or
Unconned Space
Use this work sheet to determine if you have
a conned or unconned space.
Space: Includes the room in which you will
install heater plus any adjoining rooms with
doorless passageways or ventilation grills
between the rooms.
1. Determine the volume of the space (length
x width x height).
Length x Width x Height =__________cu. ft.
(volume of space)
Example: Space size 22 ft. (length) x 18 ft.
(width) x 8 ft. (ceiling height) = 3168 cu. ft.
(volume of space)
If additional ventilation to adjoining room
is supplied with grills or openings, add the
volume of these rooms to the total volume
of the space.
2. Multiply the space volume by 20 to determine
the maximum Btu/Hr the space can support.
________ (volume of space) x 20 = (Maxi-
mum Btu/Hr the space can support)
Example: 3168 cu. ft. (volume of space) x 20
= 63,360 (maximum Btu/Hr the space can
support)
3. Add the Btu/Hr of all fuel burning appliances
in the space.
Gas water heater* __________ Btu/Hr
Gas furnace __________ Btu/Hr
Vented gas heater __________ Btu/Hr
Gas replace logs __________ Btu/Hr
Other gas appliances* + _________ Btu/Hr
Total = _________ Btu/Hr
* Do not include direct-vent gas appliances.
Direct-vent draws combustion air from the
outdoors and vents to the outdoors.
Example:
Gas water heater __________ Btu/Hr
Gas rebox logs + _________ Btu/Hr
Total = _________ Btu/Hr
40,000
39,000
79,000
4. Compare the maximum Btu/Hr the space
can support with the actual amount of Btu/
Hr used.
_______ Btu/Hr (maximum the space can
support)
_______ Btu/Hr (actual amount of Btu/Hr
used)
Example: 63,360 Btu/Hr (max imum t he
space can support)
79,000 Btu/Hr (actual amount of
Btu/Hr used)
The space in the above example is a conned
space because the actual Btu/Hr used is more
than the maximum Btu/Hr the space can sup-
port. You must provide additional fresh air.
Your options are as follows:
A. Rework work sheet, adding the space
of an adjoining room. If the extra space
provides an unconned space, remove
door to adjoining room or add ventilation
grills between rooms. See Ventilation Air
from Inside Building, page 8.
B. Vent room directly to the outdoors. See
Ventilation Air from Outdoors, page 8.
C. Install a lower Btu/Hr gas log heater, if
lower Btu/Hr size makes room unconned.
If the actual Btu/Hr used is less than the
maximum Btu/Hr the space can support, the
space is an unconned space. You will need
no additional fresh air ventilation.
WARNING: If the area in which
the heater may be operated does
not meet the required volume for
indoor combustion air, combustion and ventilation air shall be
provided by one of the methods
described in the National Fuel
Gas Code, ANSI Z223.1/NFPA 54,
the International Fuel Gas Code,
or applicable local codes.
105163-01E 7
www.fmiproducts.com
AIR FOR COMBUSTION AND VENTILATION
Or
Remove
Door into
Adjoining
Room,
Option
2
Ve ntilation
Grills
Into Adjoining
Room,
Option 1
4"
Outlet
Air
V e ntilated
Attic
Outlet
Air
Inlet
Air
Inlet Air
V e ntilated
Crawl Space
T o
Crawl
Space
T o Attic
Continued
VENTILATION AIR
Ventilation Air From Inside Building
This fresh air would come from an adjoining
unconned space. When ventilating to an
adjoining unconned space, you must provide
two permanent openings: one within 12" of the
ceiling and one within 12" of the oor on the
wall connecting the two spaces (see option
1, Figure 3). You can also remove door into
adjoining room (see option 2, Figure 3). Fol-
low the National Fuel Gas Code ANS Z223.1/
NFPA 54 Air for Combustion and Ventilation
for required size of ventilation grills or ducts.
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two permanent openings: one within 12" of the ceiling
and one within 12" of the oor. Connect these
items directly to the outdoors or spaces open
to the outdoors. These spaces include at-
tics and crawl spaces. Follow the National
Fuel Gas Code ANS Z223.1/NFPA 54 Air for
Combustion and Ventilation for required size
of ventilation grills or ducts.
IMPORTANT: Do not provide openings for
inlet or outlet air into attic if attic has a thermo-
stat-controlled power vent. Heated air entering
the attic will activate the power vent.
Figure 3 - Ventilation Air from Inside
Building
INSTALLATION
NOTICE: This rebox in combination with unvented log
sets are intended for use as
supplemental heat. Use along
with your primary heating
system. Do not install them as
your primary heat source. If you
have a central heating system,
you may run system’s circulating blower while using heater.
This will help circulate the heat
throughout the house. In the
event of a power outage, you
can use unvented logs as your
primary heat source.
www.fmiproducts.com
Figure 4 - Ventilation Air from Outdoors
WARNING: A qualied service person must install rebox.
Follow all local codes.
WARNING: Never install the
rebox
• in a bedroom or bathroom
• in a recreational vehicle
• where curtains, furniture,
clothing or other ammable
objects are less than 42" from
the front, top or sides of the
rebox
• in high trafc areas
• in windy or drafty areas
105163-01E8
INSTALLATION
42" Min.
0" to Wood
Floor
8" Min.
4"
Min.
0" Min. Clearance to Upper Frame/Wallboard
Ceiling
Edge of
Brick Liner
4" Min. from the Perpendicular
Side Wall to the Edge of Facia
1/2" Min. Clearance
to Combustibles
43 3/4"
24"
36" Minimum
from Edge of
Facial to
Facing Wall
on Open End
of Firebox
Continued
CAUTION: Log heaters in-
stalled in this rebox create warm
air currents. These currents move
heat to wall surfaces next to rebox. Installing rebox next to vinyl
or cloth wall coverings or operating rebox where impurities (such
as, but not limited to, tobacco
smoke, aromatic candles, cleaning uids, oil or kerosene lamps,
etc.) in the air exist, may discolor
walls or cause odors.
IMPORTANT: Vent-free gas log heaters add
moisture to the air. Although this is benecial,
installing rebox in rooms without enough
ventilation air may cause mildew to form from
too much moisture. See Air for Combustion
and Ventilation, page 6.
IMPORTANT: Make sure the rebox is level.
If rebox is not level, log set will not work
properly.
Note: Your Vanguard rebox is designed to
be used in zero clearance installations. Wall
or framing material can be placed against any
exterior surface on the rear, sides or top of
your rebox, except where standoff spacers
are integrally attached. If standoff spacers
are attached to your rebox, these spacers
can be placed directly against wall or fram-
ing materials.
Use dimensions shown for rough openings to
create the easiest installation (see Built-In or
Internal Wall Firebox Installation, page 9).
INSTALLATION CLEARANCES
C. When the rebox is installed on carpet-
ing or other combustible material, other
than wood ooring, the rebox should be
installed on a metal or wood panel extending the full width and depth of enclosure.
D. Clearances from the bottom of rebox to
the oor is 0".
E. Clearances from open end of rebox to fac-
ing wall shall should not be less than 36".
CAUTION: Do not install rebox directly on carpet or vinyl.
CAUTION: Use only the clear-
ances specied in this manual or
on the rebox rating plate.
Minimum clearances to combustibles are:
• Sides of outer casing 0" min.
• Drywall to sides and top of 0" min.
front face
• Ceiling to opening 42' min.
• Floor (see Minimum Wall 0" min.
and Ceiling Clearances, note C)
• Perpendicular walls 4' min.
Right and Left
• Distance to Facing Walls 36" min.
on Sides and End of Firebox
WARNING: Maintain the
minimum clearances. If you can,
provide greater clearances from
Figure 5 - Minimum Clearance Front View
oor, ceiling and adjoining wall.
Carefully follow the instructions below. This
will ensure safe installation.
Minimum Wall and Ceiling Clearances
A. Clearances from edge of liner to any
combustible wall should not be less than
8" (see Figure 5).
B. Clearances from top of rebox opening to
the ceiling should not be less than 42".
105163-01E 9
Figure 6 - Minimum Clearance - Top View
www.fmiproducts.com
INSTALLATION
Supplied
Firebox
Hoods Must
Be Used at
All Ti mes
Wire-mesh
Screen
Firebox Top
Mantel
Shelf
3"
6"
9
1
/4"
Combustible
Material 1
1
/2"
Max Thickness
Note: All vertical
measurements are
minimum distances
from top of fireplace
hood to bottom of
mantel shelf. These
minimum clearances
replace any other
recommended
clearances supplied
with your ANS Z21.11 .2
approved gas logs.
Wa ll board or facing material (above firebox)
may be of combustible material, including
decorative mantel ornaments or other similar
projections off of the facing material.
Top Frame
(Combustible Material)
12" 15" 18"
7" Min.
Note: Fireplace shown as cross-section for clarity.
Mantel material may not be less than 7" from top of
hood. Do not cover louver openings.
4" Min.
43
3
/4" Min.
36" Min. to
Facing Wall
22
3
/4"
Min.
Facing
Wa ll
Wa llboard
Gas Line
Facing Wall
(Base line)
Board
Base
40 1/4" Min.
Continued
Mantel Clearances for Built-In
Installation
If placing custom mantel above built-in rebox, you must meet the minimum allowable
clearance between mantel shelf and top of
rebox opening shown in Figure 7. These are
the minimum allowable mantel clearances
for a safe installation. Use larger clearances
wherever possible to minimize the heating of
objects and materials placed on the mantel.
CAUTION: Do not allow the
vent-free gas log heater to touch
or extend beyond the rebox
screen.
If your installation does not meet the above
minimum clearances in Figure 7, you must:
• raise the mantel to an acceptable height,
OR
• remove the mantel.
BUILT-IN OR INTERNAL WALL
FIREBOX INSTALLATION
Built-in installation of this rebox involves
installing rebox into a framed-in enclosure.
This makes the front of rebox ush with wall.
If installing a mantel above the rebox, you
must follow the clearances shown in Figure
7. Follow the instructions below to install the
rebox in this manner.
1. Frame in rough opening. The firebox
framing should be constructed of 2 x 4
lumber or heavier. Construct framing
using dimensions shown in Figure 8 and
9, page 11. It is recommended that the
framing be constructed rst and the unit
be placed in position. After sliding the unit
into place, the anges may be nailed to
the framing before applying the wallboard
to the exterior framing.
2. If the vent-free rebox is to be installed
directly on carpeting, tile (other than ce-
ramic) or any combustible material other
than wood ooring; the vent-free rebox
must be installed upon a metal or wood
panel extending the full width and depth
of the vent-free rebox.
Figure 7 - Minimum Mantel Clearances
for Built-In Installation
Figure 8 - Framing for Built-In Firebox
www.fmiproducts.com
Installation
105163-01E10
11/2" Max.
3/8" Max.
4"
8" Min. from adjacent
wall to fireplace opening
SAFE
ZONE
Combustible material must
not overlap more than 3/8"
onto black metal front face.
Nailing Flange
Drywall
INSTALLATION
Continued
3. If a raised platform is to be constructed,
ceiling clearances must be maintained.
4. Install gas piping to rebox location. See
Installing Gas Line and Connecting to Gas
Supply in log set owner’s manual.
5. Carefully set rebox in front of rough
opening.
6.
Carefully insert rebox into rough opening.
7. Attach rebox to wall studs using nails
or wood screws through holes in nailing
ange (see Figure 10). Attach rebox to
board base through holes in rebox bot-
tom (see Figure 10).
IMPORTANT: When nishing your rebox,
combustible materials such as wall board,
gypsum board, sheet rock, drywall, plywood,
etc. may be butted up next to the sides and
top of the firebox. Combustible materials
should never overlap the rebox front facing
more than 3/8".
WARNING: Do not allow any
combustible materials to over-
lap the rebox front facing (see
Figure 9).
IMPORTANT: Noncombustible materials such
as brick, tile, etc. may overlap the front facing,
but should never cover any necessary openings like louvered slots.
WARNING: Never modify or
cover the louvered slots on the
front of the rebox.
Edge
of side
rebox
opening
Min. from rebox
edge to combustible
material
Figure 9 - Framing for Built-In Firebox
105163-01E 11
Installation, Top View
www.fmiproducts.com
WARNING: Use only non-
combustible mortar or adhe-
sives when overlapping the front
facing with noncombustible
facing material.
Nails or
Wood
Screws
Figure 10 - Attaching Firebox to Wall Studs
INSTALLING GAS LINE
Nailing
Flanges
Nails or Wood
Screws
WARNING: A qualied service person must connect heater
to gas supply. Follow all local
codes.
IMPORTANT: See Connecting to Gas Supply
in your log set owner’s manual for details on
gas hookup.
Figure 11, page 12, shows the typical in-
stallation for the gas line. When you have
determined how the gas line will run, locate
one of the recessed knockouts in the rebrick oor (see Figure 12, page 12,). Firmly
tap the center of the knockout with a chisel
until it is released. Carefully chisel the rough
edges of the hole you have made to smooth
edges. This hole will line up with the hole in
the metal oor.
INSTALLATION
Continued
CAUTION: Do not use exces-
sive force to remove the knockout. Too much force may damage
the rebrick concrete insert.
A manual shutoff valve, CSA certied and
complying with the National Fuel Gas code,
ANS Z223.1/NFPA 54, must be included
within 6' of the vent-free rebox gas supply
system. It may be convenient to install the gas
shutoff outside the vent-free rebox enclosure
where it can be accessed with a key through
a wall as shown in Figure 13. Depending on
the type of installation, some local codes may
require you to install 2 manual shutoff valves
independently accessible from both rooms.
Check your local codes for applicable instal-
lation requirements.
A 36" long 1/2" NPT SCHD 40 exible gas
connector line complying with the National
Fuel Gas code ANS Z223.1/NFPA 54, may
be run from the regulator to the incoming 1/2"
NPT black iron gas line. You may also route
the incoming 1/2" NPT black iron gas line
directly to the appliance regulator.
Remove the gas line cover plate from the
vent-free rebox’s outer surround and route
Gas Line Installed Through Access
Hole on One Side of Firebox
the gas line into the rear of the rebox (see
Figure 11).
If a sediment trap is not incorporated as a part
of the gas utilization equipment, one shall be
installed as close to the inlet of the equipment
as practical at the time of installation, as per
ANS Z223.1/NFPA 54. See Figure 14.
Firebrick Floor
Remove Knockout
3/4" Thick Liner
Figure 12 - Location of Knockouts for
Key
Gas Line
Extension
Shut-Off Valve
Manual Shutoff
Valve is Located
Under Firebox Floor
on Either Side
Figure 11 - Installing Gas Line and
Manual Shutoff Valve
Figure 13 - Typical Exterior Wall Gas
Incoming
1/2" Gas Line
Permitted by
Local Codes
Sediment Trap
(Not Supplied)
Figure 14 - Sediment Trap Installation
www.fmiproducts.com
Shut-Off Installation
105163-01E12
INSTALLATION
Continued
Prepare incoming black iron gas line with
Teon tape or pipe joint compound (check with
local codes as to the use of Teon tape). Compounds used on threaded joints of gas piping
shall be resistant to the action of propane/LP
and should be applied lightly to ensure excess
sealant does not enter the gas line.
Complete your gas installation by connecting
the incoming gas line to the appliance regula-
tor. Secure all joints tightly with wrench but do
not overtighten. If a exible gas line is used,
take care not to kink the connector.
WARNING: All gas piping
and connections must be tested
for leaks after the installation is
completed. After ensuring that
the manual shutoff gas valve is
open, apply a soap and water
solution to all connections and
joints. If bubbles appear, leaks
can be detected and corrected.
DO NOT USE OPEN FLAME FOR
LEAK TESTING AND DO NOT
OPERATE ANY APPLIANCE IF
A LEAK IS DETECTED.
GAS SUPPLY TESTING
Note: This section is intended as a guide for
qualied technicians installing gas to this
vent-free rebox.
CAUTION: Do not connect
vent-free heater before pressure
testing gas piping. Damage to
gas valve may result and an un-
safe condition may be caused.
The appliance and its’ individual shutoff valve
must be disconnected from the gas supply
piping system during any pressure testing of
that system at test pressures in excess of 1/2
psig (3.5 kPa).
The appliance must be isolated from the gas
supply piping system by closing manual shutoff valve during any pressure testing of the gas
supply piping system at test pressures equal
to or less than 1/2 psig (3.5 kPa).
HARD-WIRING FIREBOX
Model FBPS and FGPN can be hard-wired
to the duplex outlet located inside the rebox
bottom if desired. This allows the blower ac-
cessory to be plugged into the duplex outlet.
NOTICE: A qualied electrician
must connect electrical wiring to
duplex outlet for built-in installation. Follow all local codes. In
absence of local codes follow
The National Electric Code ANS/
NFPA 70.
ELECTRICAL INSTALLATION
A model GA3500A blower system assembly
is available for use with the FBPS and FGPN
(-LS) vent-free rebox as an optional accessory. This blower is designed to be installed
on either side of the FBPS and FGPN(-LS)
rebox, when provisions for a 120 VAC supply connection are made at either end of the
cabinet. Use of a blower system other than
those manufactured by FMI PRODUCTS, LLC
voids the warranty.
Electrical connections are made within the
receptacle with wires that are routed through
the bushing provided (see Figure 15). The re-
ceptacle may be relocated to either side, when
necessary. However, the cover plate must be
replaced over the unused access point. Be
certain to properly ground the vent-free rebox
using the green grounding wire.
Gas Connection
Access Hole
Electrical
Connection
Access Hole
Figure 15 - Locating Electrical
Connection and Gas Connection on
Either Side of Fireplace
Cover
Plates
105163-01E 13
www.fmiproducts.com
INSTALLATION
Continued
Note: A 120V supply connection to the leads
to the receptacle must be provided for use
with the optional blower kit whether installed
during or after initial rebox installation. You
may not be able to install a supply connection
after the nal installation is completed.
HEAT DEFLECTIVE HOOD
INSTALLATION
The factory supplied heat deective hoods
must be installed inside the replace opening
on both sides for the safe operation of the unit
as shown in Figure 16.
1. Remov e p r o t e c t i v e c o vering from
hoods.
2. Position deflective hood into opening
on one side of the rebox and secure
to the top of the opening using screws
provided.
3. Secure the ends of the hood to the rebox
using two screws (provided) for each
side.
4. Repeat steps 2 and 3 to install hood on the
remaining side and end of the rebox.
CAUTION: Do not clean hood
with abrasive cleanser. Use only
regular household cleaners and
a smooth cloth.
Front Hood
(Typical Each Side)
Corner
Post
2 Screws Each
End of Hood
Figure 16 - Typical Hood Installation
(Both Sides)
OPERATING GUIDELINES AND MAINTENANCE
INSTRUCTIONS
When lit for the rst time, a vent-free log
heater will emit a slight odor for about an hour
or two. This is a normal occurrence which is
due to the “curing” of the logs and the “burn-in”
of internal paints and lubricants used in the
manufacturing process.
Keep control compartments, logs, burners
and areas surrounding the logs clean by
vacuuming or brushing at least twice a year.
Temporary removal of the log set may ease
the cleaning of the burner and pilot assembly.
In cleaning, take care not to alter the settings
on the pilot assembly. See the operating
instructions supplied with your vent-free log
heater for additional cleaning instructions.
WARNING: Logs can be very
hot! Allow logs to cool before
handling.
IMPORTANT: Turn off the gas supply at the
external shutoff valve before servicing appliance. Any safety screen or guard removed for
servicing must be replaced prior to operating
the appliance.
www.fmiproducts.com
Installation and repair should be done by a
qualied person. The appliance should be
inspected before use and at least annually by
a professional service person. More frequent
cleaning may be required due to excessive lint
from carpeting, pet hair, etc. It is imperative
that the control compartments, burners and
circulating air passageways of the appliance
be kept clean.
WARNING: Children and
adults should be alerted to the
hazards of high surface temperatures and to stay away to avoid
burns or clothing ignition. Young
children should be carefully
supervised when they are in the
same room as the appliance.
For lighting and operating t his vent-free
rebox, please refer to the vent-free gas logs
manufacturer’s instruction manual.
3 Screws
(Top)
105163-01E14
REPLACEMENT PARTS
Note: Use only original replacement parts.
This will protect your warranty coverage for
parts replaced under warranty.
Contact authorized dealers of this product.
If they can’t supply original replacement
pa r t (s), ca l l FM I PRODUC T S , LLC at
1-866-328-4537.
TECHNICAL SERVICE
You may have further questions about installation, operation, or troubleshooting. If so, contact
FMI PRODUCTS, LLC at 1-866-328-4537.
When calling please have your model and serial
numbers of your heater ready.
ACCESSORY
Purchase these accessories from your
local dealer. If they can not supply these
accessories call FMI PRODUCTS, LLC at
1-866-328-4537 for information. You can
also write to the address listed on the back
page of this manual.
When calling, have ready:
• your name
• your address
• model and serial numbers of your heater
• how heater was malfunctioning
• purchase date
Usually, we will ask you to return the part to
the factory.
You can also visit FMI PRODUCTS, LLC’s
web site at www.fmiproducts.com.
105163-01E 15
www.fmiproducts.com
**These items are used on both sides of fireplace.
8**
15
17**
17**
17**
7-1
7-2
7-3
2
17**
11 **
17**
17
12
6
16
13
10**
5**
17
17
15
16
4
16
16
6
16
15
17**
17**
18
Ty p.
Ty p.
Ty p.
8**
17**
17**
9**
14
16
1
3
MODELS FBPS, FGPN AND FGPN-LS
PARTS
www.fmiproducts.com
105163-01E16
PARTS
MODELS FBPS, FGPN AND FGPN-LS
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 15 of this manual.
KEY
PART
NO.
NO. DESCRIPTION QTY.
1 *** Firebox Assembly 1
2 *** Firebox Bottom 1
3 *** Firebox Top 1
4 23982 Top Spacer 4
5 26731 Deector Hood 2
6 26740 Nailing Flange 12
7-1 02013 Side Refractory Brick Liner 1
7-2 02014 Bottom Refractory Brick Liner 1
7-3 02036 Bottom Refractory Brick Liner 1
8 24007 Side Refractory Retainer 2
9 12125 Screen 4
10 26752 Extruded Louver 2
11 26733 Lower Door Panel 2
12 14200 Receptacle 1
13 21171 Access Hole Cover 3
14 12126 Screen 1
15 26771 Extruded Louver (End) 1
16 11164 Screw, #10 x 1/2, zinc PH 24
17 11165 Screw, #10 x 5/8, zinc PH 67
18 26762 Deector Hood (End) 1
*** Not a eld replaceable part.
105163-01E 17
www.fmiproducts.com
NOTES
_____________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
_____________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
_____________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
www.fmiproducts.com
105163-01E18
NOTES
_____________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
_____________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
_____________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
______________________________________________________
105163-01E 19
www.fmiproducts.com
WARRANTY
KEEP THIS WARRANTY
Model (
located on product or identication tag
Serial No. (
located on product or identication tag
Date Purchased __________________________
Keep receipt for warranty verication.
FMI PRODUCTS, LLC LIMITED WARRANTIES
Standard Warranty: FMI PRODUCTS, LLC warrants this new product and any parts thereof to be free from defects
in material and workmanship for a period of two (2) years from the date of rst purchase from an authorized dealer
provided the product has been installed, maintained and operated in accordance with FMI PRODUCTS, LLC’s
warnings and instructions.
For products purchased for commercial, industrial or rental usage, this warranty is limited to 90 days from the date
of rst purchase.
Limited Warranty: FMI PRODUCTS, LLC warrants factory reconditioned products and any parts thereof to be
free from defects in material and workmanship for 30 days from the date of rst purchase from an authorized dealer
provided the product has been installed, maintained and operated in accordance with FMI PRODUCTS, LLC’s
warnings and instructions.
The following terms apply to all of the above warranties:
Always specify model number and serial number when contacting the manufacturer. To make a claim under this
warranty the bill of sale or other proof of purchase must be presented.
This warranty is extended only to the original retail purchaser when purchased from an authorized dealer, and only
when installed by a qualied installer in accordance with all local codes and instructions furnished with this product.
This warranty covers the cost of part(s) required to restore this product to proper operating condition and an allowance for labor when provided by a FMI PRODUCTS, LLC Authorized Service Center or a provider approved by
FMI PRODUCTS, LLC. Warranty parts must be obtained through authorized dealers of this product and/or FMI
PRODUCTS, LLC who will provide original factory replacement parts. Failure to use original factory replacement
parts voids this warranty.
Travel, handling, transportation, diagnostic, material, labor and incidental costs associated with warranty repairs,
unless expressly covered by this warranty, are not reimbursable under this warranty and are the responsibility of
the owner.
Excluded from this warranty are products or parts that fail or become damaged due to misuse, accidents, improper
installation, lack of proper maintenance, tampering, or alteration(s).
This is FMI PRODUCTS, LLC’s exclusive warranty, and to the full extent allowed by law; this express warranty
excludes any and all other warranties, express or implied, written or verbal and limits the duration of any and all
implied warranties, including warranties of merchantability and tness for a particular purpose to two (2) years on
new products and 30 days on factory reconditioned products from the date of rst purchase. FMI PRODUCTS, LLC
makes no other warranties regarding this product.
FMI PRODUCTS, LLC’s liability is limited to the purchase price of the product, and FMI PRODUCTS, LLC shall not
be liable for any other damages whatsoever under any circumstances including indirect, incidental, or consequential
damages.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental
or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
For information about this warranty contact:
Factory Reconditioned Products
Terms Common to All Warranties
) _____________________________
) __________________________
New Products
2701 S. Harbor Blvd.
Santa Ana, CA 92704
1-866-328-4537
www.fmiproducts.com
105163-01
Rev. E
01/10
Loading...
