IMPORTANT INFORMATION
Read before use
& retain for future reference
INSTRUCTION MANUAL
1
CONTENTS
Carton Contents
IMPORTANT !
Please check the contents of the carton are
correct BEFORE
assembling your new Flymo
product.
IF
ANY PARTS ARE MISSING CONTACT:-
Flymo/Partner Customer Service Department
direct Telephone : 01325 300303
Fax : 01325 318193
LIST OF INSTRUCTION MANUAL
CONTENTS
CONTENTS (1)
SAFETY (2-4)
ASSEMBLY
& ADJUSTMENT (5-7)
USE (8)
MAINTENANCE (9-10)
GUARANTEE (11)
CERTIFICATE
OF CONFORMITY (12)
& INSIDE BACK COVER
A
guard
wall bracket
Integrated battery
charger
scraper tool
guarantee card
instruction
manual
screws
fixing plugs
handle
knob
steady handle
handle bolt
2
SAFETY
If not used properly this trimmer can be dangerous! This trimmer can cause
serious injury to the operator and others, the warnings and safety instructions
must be followed to ensure reasonable safety and efficiency in using this trimmer.
The operator is responsible for following the warning and safety instructions in
this manual and on the trimmer.
Explanation of Symbols
on the Cordless Trimmer
Warning
Read the user instructions
carefully
Keep others, including children,
pets and bystanders outside the
10 metre hazard zone. Stop the
trimmer immediately if you are
approached.
The use of eye protection is
recommended to protect against
objects thrown by the nylon line.
Warning
The cutting line continues to rotate after the
machine has been switched off.
General
1. Never allow children or people unfamiliar
with these instructions to use the trimmer.
Local regulations may restrict the age of the
operator.
2. Only use the trimmer in the manner and for
the functions described in these
instructions.
3. Never operate the trimmer when you are
tired, ill or under the influence of alcohol,
drugs or medicine.
4. The operator or user is responsible for
accidents or hazards occurring to other
people or their property.
Battery
Cordless Battery Powered Products
require special care.
1. AVOID ACCIDENT ALSTARTING
KEEP HANDS AND FINGERS AWAY
FROM THE SWITCH LEVER WHILE
CARRYING THE TRIMMER.
2. Always charge the product indoors and
store in a cool dry place - out of the reach
of children.
3. Use only the charger provided with your
unit. Use of any other charger could
permanently damage the battery and the
trimmer.
4. Use the charger with standard domestic
household electrical outlets only.
5. Do not abuse the charger or charger cord.
6. Do not use the charger if the charger or
charger cord is damaged.
7. Use the charger indoors only.
8. Do not use the charger outdoors.
9. Store and charge this unit in a cool, dry well
ventilated location and out of the reach of
children.
10. Do not charge the battery or use the unit in
an explosive or corrosive environment.
Avoid areas where flammable liquids or
gases are present to avoid creating a fire or
explosion.
10m
360º
3
SAFETY
11. Do not attempt to repair the unit including
the battery. Nylon line replacement and
cleaning the unit are the only items suitable
for user maintenance.
12. Do not insert any object into the motor area.
Keep free of debris to avoid overheating.
13. Do not incinerate or mutilate the battery.
Batteries contain hazardous chemicals.
Dispose of properly.
Preparation
1. Do not trim barefoot or in open sandals.
Always wear suitable clothing, gloves, and
stout shoes.
2. Inspect the trimmer before each use,
especially the parts of the cutting head.
3. Inspect the area to be cut before each use.
Remove all objects such as stones, broken
glass, nails, wire, string etc, which can be
thrown or become entangled in the trimmer
head.
4. Check that the cutting head, spool and cap
are fitted correctly.
Use
1. Use the trimmer only in daylight or good
artificial light.
2. Avoid operating your trimmer in wet grass,
where feasible.
3. Take care in wet grass, you may lose your
footing.
4. On slopes, be extra careful of your footing
and wear non-slip footwear.
5. Do not walk backwards when trimming, you
could trip. Walk, never run.
6. Switch off before pushing the trimmer over
surfaces other than grass.
7. Never operate the trimmer with damaged
guards or without guards in place.
8. Never fit metal cutting elements.
9. Avoid possible injuries to feet and hands
from rotating cutting line. Always start the
trimmer carefully with feet and hands well
away from the cutting head.
10. Keep cutting head below waist level
11. Do not lean over the trimmer guard whilst
trimming or edging - objects may be thrown
by the cutting line.
12. Beware of cut-off pieces of nylon line
ejected during use.
Maintenance and storage
1. Keep all nuts, bolts and screws tight to be
sure the trimmer is in safe working
condition.
2. Replace worn or damaged parts for safety.
3. Only use the replacement cutting line
specified for this product.
4. Only use replacement parts and
accessories recommended by
Flymo/Partner.
5. To avoid the risk of injury keep fingers and
hands clear of the line cutter on the leading
edge of the guard.
6. Clean unit with a dry cloth. Never use metal
objects to clean the unit.
7. Inspect and maintain the trimmer regularly.
Any repairs must be carried out by an
authorised repairer.
Battery Care
1. If over a period of time the battery quickly
runs down after a full 24 hour charging
period, a replacement battery is needed.
2. There will be some charge present in the
battery but to ensure maximum running
time, recharge your trimmer for 24 hours
before use.
3. Permanent connection to the charger in a
well ventilated area will automatically
keep your battery fully charged ready for
use.
4. To prevent permanent battery damage,
never store in a discharged condition.
5. Contact your local approved service
centre/dealer/distributor for a
replacement battery and for safe disposal
of your old battery .
6. Battery
12 Volt 5 Amp/Hour
"High Power"
Sealed for Life
No maintenance required
• IMPORTANT
DISPOSE OF YOUR OLD BATTERIES
SAFELY
DO NOT CUT OPEN, BURN OR
INCINERATE.
Battery Replacement
Should your battery need to be replaced
contact your local approved service centre or
dealer who will remove your old battery and
fit a genuine Flymo replacement battery.
• IMPORTANT
The red lead should always be
connected to the red terminal on the
battery. The black lead should always be
connected to the black terminal on the
battery.
Bench Top Re-charging
The wall bracket can also be used as a
"bench top" stand for re-charging your
cordless trimmer.
Winter Storage
1. Fully charge for 24 hours before winter
storage.
2. If you are unable to leave your cordless
trimmer on permanent charge, re-charge
the battery every 3 to 4 months for a full
24 hour charging period to top up the
battery charge during winter storage.
3. Avoid extended storage without recharge.
4. Store in a cool dry place.
For further information on Battery replacement contact Flymo/Partner Customer
Service direct:-
Telephone : 01325 300303
Fax : 01325 318193
BATTERY
4
5
Product Number . . . . . . . . . . . . . . . . .
Model Number. . . . . . . . . . . . . . . . . . .
Serial Number . . . . . . . . . . . . . . . . . . .
Date of Purchase . . . . . . . . . . . . . . . . .
Place of Purchase . . . . . . . . . . . . . . . .
•PLEASE KEEP PROOF OF PURCHASE•
ASSEMBLY
Your product is uniquely identified by a
silver and black product rating label.
To ensure you have full product
information when obtaining spares or
advice from one of our approved service
centres, or if you need to contact our
customer service department, you should
make a note in the space provided of the
information shown in fig.B. It will also be
useful to make a note of the date and
place of purchase before you return your
guarantee card.
Product Rating Label
B
Assembly Instructions
Safety Guard Assembly (C), (D), (E & F)
1. Locate the safety guard (C1) over the
cutting head (C2). Ensure the nylon
line is fed through the hole in the
safety guard as illustrated in fig C.
2. Align the arrow on the top of the
safety guard (C3) with the arrow on
the side of the trimmer (C4). See figs
C& D.
3. Push into location and turn safety guard
anti-clockwise, as illustrated in Fig D
until a click is heard and the safety
guard is securely locked in position.
See fig E.
• ENSURE THE SAFETY GUARD IS
SECUREL YIN PLACE BYATTEMPTING
TO TWIST GUARD.
See fig F.
C
D E
F
1
2
4
3
6
ASSEMBLY
• IMPORTANT !
Switch charger off at the wall socket
before connecting or disconnecting the
trimmer to the wall bracket.
1. It is recommended that the wall bracket
(G2) should be mounted on a smooth,
vertical and internal wall which is strong
enough to hold the weight of the product, in
a well ventilated area between 5°C and
25°C.
2. There are 3 holes on the wall bracket.
Position the wall bracket with the two holes
at the top. See Fig H.
3. Ensure that when the trimmer is attached the
bottom of the trimmer is within 4 inches (100
mm) of the ground, this will make it easier to
hang the trimmer and will also ensure that the
wall bracket is within easy reach of an electric
socket to allow the charger to be plugged in.
4. Fix wall bracket securely to the wall with the
plugs and screws provided.
5. Your cordless trimmer can now be attached
to the wall bracket for charging.
Initial Charging Procedure
1. Use the charger indoors only.
2. Ensure the charger is not exposed to
moisture. Keep the charger and the trimmer
dry at all times. Keep the charger well
ventilated during charging.
3. Ensure the trimmer is correctly located into
the wall bracket (G2) and the charge
connector (H1).
4. Plug the charger (G1) into a suitable
household electrical wall socket and switch
on.
5. The red indicator lamp glows continuously
during charging.
6. Full charge will be achieved in 24 hours.
During charging the charger becomes
warm. This is normal and means the
charger is operating correctly.
Re-Charging Your Cordless Trimmer
1. Re-charge the battery as soon as the cutting
power of your cordless trimmer begins to die
and slow down.
2. Avoid running the cordless trimmer into
"deep" discharge, i.e. avoid flattening the
battery completely.
3. Follow the procedure outlined in the Initial
Charging Procedure.
4. Charging the battery according to these
instructions should ensure maximum battery
life.
Fitting the wall bracket
Initial charging procedure and re-charging your cordless trimmer
G
H
1
2
1
• The battery should be charged for 24 hours
before use.
• Re-charge your cordless trimmer
immediately after every use for the full 24
hour charging period.
• The cordless trimmer can be left connected
to the charger permanently, with the charger
switched on, without fear of overcharging.
• The charger will automatically keep the
battery topped up with charge during
storage and will ensure that the cordless
trimmer is ready for use.
7
ADJUSTMENT
1. Attach steady handle to product using bolt
and handle knob as shown in Fig I.
2. Adjust the steady handle to a comfortable
operating position, see Fig J., by
unscrewing the handle knob, springing the
side lugs apart, moving the handle to the
required position, carefully re-engaging the
teeth and then tightening the handle knob.
See Fig K.
Handle Adjustment
Auto Line Feed System
I
J K
bolt
handle
knob
How the automatic line feed works (L)
1. A short length of new line is fed out every
time you switch on, this is caused by the
cutting head accelerating up to its full
speed.
2. To feed more line, it is necessary to switchoff, allow the motor to stop and then restart.
When edging do this frequently.
3. When the line feeds you will hear a change
in the motor sound as well as the noise
generated by the line being cut to its length.
4. If the line does not feed see Fault Finding
Hints for further information.
L
line cutter
8
USE
How to trim and edge
Spool Cap
To start your trimmer
1. Hold as illustrated in Fig M.
2. To start, press lock-off button (M1),
squeeze the switch lever (M2), release
lock-off button.
How to trim
1. Cut with nylon line at an angle using the tip.
See Fig N
2. Swing trimmer in and out of the cutting area
taking small cuts (O)
3. Line is fed out automatically every time the
trimmer head stops rotating and returns to
operating speed.
• Extra line can be fed out manually as
described on page 9.
4. To stop your trimmer release the switch
lever (M2).
How to edge
1. To convert to edging mode, depress locking
button and twist head anti-clockwise until
arrow lines up with "EDGE". An audible
"click" will confirm that the head is locked.
Ensure the button has returned to its
original position. See Fig P.
2. Rest edger on roller for extra stability and
line up with edge of lawn. See Fig R. Edge
in direction indicated in Fig Q. so that
debris is thrown away from you.
3. To return to trimming mode, depress
locking button and twist head clockwise
until arrow lines up with "TRIM". An audible
"click" will confirm that the head is locked.
Ensure the button has returned to its
original position. See Fig S.
To remove spool cap
1. Press and hold in the two cap release
latches. See Fig T.
2. Pull cap away from the cutting head. See
Fig U.
When refitting the spool cap
1. Keep all areas of the cap and spoolholder
clean. Failure to do so may prevent the
cap being securely located in the
spoolholder.
2. Align the two latches on the cap with the
two windows in the spoolholder, then press
down into the locked position.
3. Ensure the two cap release latches are
clearly visible and are fully engaged with
the windows in the spoolholder.
4. Check that the cap is correctly fitted by
trying to remove it without depressing the
two latches.
N
O
M
QP
SR
T
cap
release
latches
U
cap
spool
spoolholder
eyelet
manual line
feed button
1
2
Y
1
9
MAINTENANCE
To manually feed the nylon line
If required, line can be fed out manually. To
operate, gently pull on the line whilst at the
same time alternately pressing and releasing
the button, on the side of the spoolholder. See
fig V.
To replace nylon line. Replacement nylon line
is available from most Flymo/Partner stockists.
You can buy it either as spool and line
complete, or as nylon line only.
To replace spool and line (complete)
1. Take new spool and remove tape holding
line in place.
2. Unwind approximately 100mm of line and
feed this through eyelet, see fig W, then
drop the spool into spoolholder smooth
side uppermost.
To replace nylon line on spool.
1. Take line and insert into hole in spool.
2. Turn spool clockwise to wind on required
amount of line, (approx. half = 10m) and
cut line to length, see fig X. Care should
be taken to ensure that the line is neatly
coiled on the spool. Failure to do so will
impair the efficiency of the automatic line
feed.
3. Leave approximately 100mm of line
unwound and feed this through eyelet, see
fig W, then drop the spool into the
spoolholder smooth side uppermost.
After you have finished using your Flymo
trimmer follow the procedure below:
1. Never clean your trimmer with water,
cleaning fluids, or solvents, just remove
debris with a suitable tool, a soft brush or
dry cloth.
2. Using the scraper provided, clean around
the inside of the safety guard to remove any
grass and debris. (Fig Y1)
3. Using a soft brush, clean around the inside
of the safety guard (Fig Y2), the cutting
head (Fig Y3) and the motor housing. (Fig
Y4)
4. Inspect the trimmer carefully, especially the
parts of the cutting head.
5. If your trimmer is damaged in any way
contact your local Flymo/Partner approved
service centre.
• Never use a damaged trimmer
6. Wind cable carefully to avoid kinking.
7. Store in a cool, dry place and out of reach
of children.
Nylon Line
Caring for your Cordless Trimmer
V
X
W
eyelet
hole in
spool
line
Do not depress the button more than three times.
Excessive line will snag the line cutter and cause
the trimmer to malfunction.
• Ensure spool is fully located by gently rotating
it during fitment.
• Remember ! Your Flymo Cordless Trimmer is
designed to use only nylon line with a
maximum diameter of 1.5mm. Use only
genuine Flymo nylon line.
• Avoid accidental starting. Keep your hands
and fingers away from the switch lever while
inspecting, cleaning or carrying out any
maintenance work.
• Keep fingers and hands clear of line cutter on
leading edge of guard.
2
3 4
10
MAINTENANCE
Fault Finding Hints & Service Recommendations
Fault Finding Hints
1. Line too short
Manually feed out the line.
2. Line broken inside cutting head
Remove cap and re-thread line.
3. Line jammed on spool
Remove cap and spool and rewind line to
remove crossed loops.
4. Excess line feed
Battery needs to be charged.
5. Poor performance
Ensure inside of cutting head housing is
clean and free from debris.
6. Trimmer stops during use
Release switch lever and wait 30 seconds
before re-starting.
Service Recommendations
1. Always use genuine Flymo Spare Parts.
2. Prepacked spares are available from
most Flymo/Partner stockists.
3. If you have a problem with your machine
contact your local Approved Service
Centre ensuring you have full details of
your product as described on the product
rating label.
4. Should it be necessary for work to be
carried out by your Service Centre, it
is important to take your complete
machine with you.
5. In the event of further difficulty please
contact:-
Flymo/Partner, Customer Service
Flymo/Partner
a division of Electrolux Outdoor
Products
Preston Road
Aycliffe Industrial Estate,
NEWTON AYCLIFFE,
Co. Durham.
DL5 6UP
Telephone: (01325) 300303
Fax : (01325) 318193
A network of specialist dealers can be found
in your local Yellow Pages.
To obtain service on your Flymo product
simply telephone or visit your local Service
Centre.
Should you require service under the terms
of our guarantee the Service Centre will
require proof of purchase.
All of the centres listed stock genuine
Flymo Spare Parts.
NOTE:
Our Service Repairers act on their own
behalf and are not empowered to commit
or legally bind Flymo/Partner in any
manner whatsoever.
If any part is found to be defective due to faulty
manufacture within one year of original
purchase, Flymo/Partner, through its Authorised
Service Repairers will effect the repair or
replacement to the customer free of charge
providing:
(a) The fault is reported directly to the
Authorised Repairer.
(b) Proof of purchase is provided.
(c) The fault is not caused by misuse, neglect
or faulty adjustment by the user.
(d) The failure has not occurred through fair
wear and tear.
(e) The machine has not been serviced or
repaired, taken apart or tampered with by
any person not authorised by
Flymo/Partner.
(f) The machine has not been used for hire.
(g) The machine is owned by the original
purchaser.
(h) The machine has not been used outside of
the country for which it was specified.
(i) The machine has not been used
commercially.
* This guarantee is additional to, and in no
way diminishes the customers statutory
rights.
Failures due to the following are not covered,
therefore it is important that you read the
instructions contained in this Operator's Manual
and understand how to operate and maintain
your machine:
Failures not covered by guarantee
* Replacing nylon line.
* Failures as a result of not reporting an
initial fault.
* Failures as a result of sudden impact.
* Failures as a result of not using the product
in accordance with the instructions and
recommendations contained in this
Operator's Manual.
* Machines used for hire are not covered by
this guarantee.
* The following items listed are considered
as wearing parts and their life is dependent
on regular maintenance and are, therefore
not normally subject to a valid warranty
claim: Spool Cap, Nylon line.
* Caution!
Flymo/Partner does not accept liability
under the warranty for defects caused in
whole or part, directly or indirectly by the
fitting of replacement parts or additional
parts that are not either manufactured or
approved by Flymo/Partner, or by the
machine having been modified in any way.
Guarantee & Guarantee Policy
11
I, the undersigned P. Howells of
Electrolux Outdoor Products,
Aycliffe Industrial Estate,
NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. Certify that
a sample of the above product
has been tested and found to
comply with directives:89/392/EEC, 89/336/EEC,
73/23/EEC
Signed at
NEWTON
AYCLIFFE..........................1999
I, the undersigned P. Howells of
Electrolux Outdoor Products,
Aycliffe Industrial Estate,
NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. Certify that
a sample of the above product
has been tested using directive
81/1051/EEC as a guide. The
maximum A-weighted sound
pressure level recorded at
operator position under free
field semi anechoic chamber
conditions was :-
Signed at
NEWTON
AYCLIFFE..........................1999
I, the undersigned P. Howells of
Electrolux Outdoor Products,
Aycliffe Industrial Estate,
NEWTON AYCLIFFE, Co.
Durham. DL5 6UP. Certify that
a sample of the above product
has been tested using ISO
5349 as a guide. The
maximum weighted root mean
square value of vibration
recorded at operator’s hand
position was:-
Signed at
NEWTON
AYCLIFFE..........................1999
Certificate of Conformity
Type
MCT-250
Identification
of Series
See Product
Rating Label
Level 77.2 dB(A)
Type
MCT-250
Identification
of Series
See Product
Rating Label
Value 1.6 m/s
2
12
Environmental Information
Electrolux Outdoor Products are manufactured under an Environmental Management
System (ISO 14001) using, where practical, components manufactured in the most
environmentally responsible manner, according to company procedures, and with the
potential for recycling at the end of the products’ life.
• Packaging is recyclable and plastic components have been labelled (where practical)
for categorised recycling.
• Awareness of the environment must be considered when disposing of ‘end-of-life’
product.
• If necessary, contact your local authority for disposal information.
Certificate of Conformity
I, THE UNDERSIGNED P. HOWELLS OF ELECTROLUXOUTDOOR PRODUCTS, AYCLIFFE
INDUSTRIAL ESTATE, NEWTONAYCLIFFE, COUNTYDURHAM DL5 6UP ENGLAND
Certify that the Trimmer
1. Category . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Electric
2. Make . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Flymo
Conforms to the specifications of Directive 84/538/EEC/
Type of Cutting Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nylon Line
Signed at
NEWTON AYCLIFFE
Date 1999. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TYPE
MCT250
Identification of Series SEE PRODUCT RATING LABEL
Motor Manufacturer Johnson HC785LG
Cutting System Width 25cm
Speed of Rotation of Cutting Device 9,400 RPM
Tested by (laboratory) Ricardo
Guaranteed sound power level 91 dB(A)
5118561-02 (01/99)
Electrolux Outdoor Products
Aycliffe Industrial Estate
NEWTON AYCLIFFE
Co.Durham DL5 6UP
ENGLAND
Telephone - (00) 44 1325 300303 Fax - (00) 44 1325 310339
UK Customer Helpline - 01325 300303 Fax - 01325 310339
Our policy of continuous improvement means that the specification of products may be altered from time to time
without prior notice. Electrolux Outdoor Products manufacture products for a number of well known brands under
various registered patents, designs and trademarks in several countries.
© Electrolux Outdoor Products Ltd. Registered Office, Electrolux Works, Oakley Road, Luton LU4 9QQ
Registered number 974979 England
The use of eye protection is recommended to
protect against objects thrown by the cutting line.
Flymo Safety Glasses are available from most
leading stockists
Contact your nearest stockist or telephone
(01325) 300303 for more details
GUIDE PRICE
ONLY
£3.49
GUIDE PRICE
ONLY
£3.49
Loading...
