Flymo
MODEL
PRODUCT NO.
Maxi trim 430 Type II & Type III
9527152-79
2
KEY PART NUMBER DESCRIPTION QTY
01 5300275-95/4 GRIP 1
02 5300157-68/1 LOCKNUT 1
03 5300946-88/5 DRIVESHAFT HSG. 1
04 5300142-22/0 HANDLE ASSY 1
05 5300156-10/5 NUT 1
06 5300152-45/0 SCREW 1
07 5300109-59/1 THROTTLE LEVER ASSY 1
08 5300692-52/1 T HANDLE KIT 1
09 5300692-49/7 SHIELD KIT ASSY 1
10 5300153-37/5 SCREW 1
11 5300945-70/5 LINE LIMITER 1
12 5300156-53/5 LOCKNUT 1
13 5300936-53/0 SHIELD BRACKET 1
14 5300922-43/1 SCREW 2
KEYPART NUMBER DESCRIPTION QTY
15 5300945-43/2 DUST CAP 1
16 5300946-71/1 DRIVESHAFT 1
17 5300311-11/4 HEX WRENCH 5/32 1
18 9520301-39/2 SHAFT LUBRICATION 1
19 9527155-26/2 CUTTING HEAD ASSY 1
20 5300948-78/2 HUB ASSY 1
21 5300948-30/3 SPRING 1
22 5300948-27/9 RELEASE BUTTON 1
23 5195197-00/8 SPOOL & LINE 1
24 5300948-28/7 COVER 1
25 5300291-59/7 SHAFT WARNING LABEL 1
26 5300947-42/0 CLAMP 1
27 5300947-83/4 THROTTLE GUARD 1
28 5300158-27/5 SPACER 2
Flymo
MODEL
PRODUCT NO.
Maxi trim 430 Type II
9527152-79
1
3
Flymo
2
MODEL
PRODUCT NO.
Maxi trim 430 Type II
9527152-79
KEY PART NUMBER DESCRIPTION QTY
01 5300157-73/1 SCREW 2
02 5300275-29/3 AIR FILTER COVER 1
03 5300275-30/1 AIR FILTER 1
04 5300158-49/9 SCREW 2
05 5300158-52/3 SPACER 1
06 5300152-54/2 WAVE WASHER 1
07 5300275-26/9 CHOKE SHUTTER 1
08 5300275-27/7 AIR FILTER PLATE 1
09 5300692-47/1 FUEL LINE KIT 1
10 5300143-62/4 FUEL FILTER 1
11 5300352-59/7 CARBURETOR 1
12 5300191-56/5 CARBURETOR GASKET 1
13 5300143-47/5 FUEL CAP ASSY 1
14 5300290-15/1 SHROUD & TANK ASSY 1
15 5300191-54/0 CRANKCASE/SHROUD GASKET 1
16 5300275-93/9 REED VALVE 1
17 5300275-94/7 REED STOP 1
18 5300140-15/8 CRANKCASE/SHAFT 1
19 5300109-60/9 CONNECTING ROD ASSY 1
20 5300157-89/7 RETAINING RING 1
21 5300109-34/4 CRANKSHAFT ASSY 1
22 5300151-26/2 FLYWHEEL KEY 1
23 5300157-72/3 SCREW 1
24 5300157-80/6 SCREW 1
25 5300275-46/7 SWITCH INSULATOR 1
26 5300275-47/5 LEAD WIRE 1
27 5300157-71/5 SCREW 1
28 5300140-16/6 CRANKCASE ASSY 1
29 5300275-45/9 SWITCH RAMP 1
30 5300275-43/4 SWITCH SPRING ASSY 1
31 5300152-41/9 SCREW 1
32 5300151-62/7 PISTON PIN RETAINER 1
33 5300258-75/2 RING PISTON 1
34 5300191-78/9 GASKET CYLINDER 1
35 5300692-75/2 PISTON KIT 1
36 5300321-03/0 INNER BEARING 1
37 5300157-87/1 RETAINING RING 2
38 5300191-58/1 CRANKSHAFT SEAL 1
39 5300321-02/2 BEARING OUTER 1
40 5300692-32/3 ROPE KIT 1
42 5300275-23/6 RETAINER 1
43 5300692-57/0 MUFFLER KIT 1
44 5300364-09/7 SPRING 1
45 5300158-23/4 SCREW 1
46 5300391-34/8 IGNITION MODULE 1
47 5300151-28/8 SCREW 2
48 5300122-35/4 CYLINDER 1
49 5300300-58/8 SPARK PLUG RCJ-8 1
50 5300157-68/1 LOCKNUT 1
51 5300391-36/3 FLYWHEEL ASSY 1
52 5303479-87/6 WASHER 1
53 5300275-17/8 FAN HOUSING 1
54 5300692-91/9 STARTER PULLEY KIT 1
55 5300293-95/7 STARTER SPRING 1
56 5300275-69/9 STARTER HANDLE 1
57 5300109-61/7 PULLEY HOUSING ASSY 1
58 5300941-89/4 CLUTCH WASHER 1
59 5300692-54/7 CLUTCH ASSY KIT 1
60 5300109-64/1 CLUTCH HOUSING 1
61 5300157-67/3 SCREW 1
KEY PART NUMBER DESCRIPTION QTY
62 5300275-11/1 SPACER 1
63 5300157-70/7 SCREW 1
64 5300157-69/9 SCREW 1
65 5300154-96/9 SCREW 1
66 5300157-88/9 SPACER 1
67 5300157-96/2 WASHER 1
68 5300017-33/1 NUT 1
69 5300351-64/9 PUMP GASKET 1
70 5300351-66/4 PUMP DIAPHRAGM 1
71 5300351-78/9 INLET SCREEN 1
72 5300351-06/0 INLET NEEDLE VALVE 1
73 5300351-88/8 METERING LEVER SPRING 1
74 5300350-31/0 LEVER METERING 1
75 5300350-28/6 PIN METERING 1
76 5300350-14/6 METERING DIAPHRAGM 1
77 5300351-51/6 METERING DIAPHRAGM GASKET 1
78 5300351-47/4 CIRCUIT PLATE GASKET 2
79 5300350-36/9 HIGH SPEED NEEDLE SPRING 1
80 5300351-42/5 HIGH SPEED NEEDLE 1
81 5300351-41/7 IDLE NEEDLE 1
82 5300350-23/7 IDLE NEEDLE SPRING 1
83 5300352-08/4 IDLE SPEED SPRING 1
84 5300352-03/5 IDLE SPEED SCREW 1
85 5300352-60/5 CARB KWIK REPAIR KIT 1
86 5300351-85/4 CARB. GASKET/DIAPHRAGM KIT 1
87 5300692-76/0 ENGINE GASKET KIT 1
88 5300152-39/3 SCREW 1
89 5300157-17/8 SCREW 1
90 5300277-81/0 MUFFLER GUARD 1
91 9527016-12/6 SPARK ARRESTOR KIT 1
A Austria; AUS Australia; B Belgium; CND Canada; CH Switzerland; D Germany; DK Denmark; E Spain; EI Eire; F France;
GB Great Britain; I Italy; N Norway; NL Netherlands; NZ New Zealand; O/S Overseas; P Portugal; S Sweden; SF Finland;
WHERE NO APPLICATION DETAILS ARE SHOWN, PART APPLIES TO ALL COUNTRIES
USA America; ZA South Africa
