Flymo COMPACT User Manual

GB

IMPORTANT INFORMATION

Read before use and retain for future reference

DE

WICHTIGE INFORMATION

Bitte vor dem Benutzen des Gerätes
durchlesen und gut aufbewahren

FR

RENSEIGNEMENTS IMPORTANTS

A lire avant usage et à conserver pour
référence ultérieure

NL

BELANGRIJKE INFORMATIE

Leest u deze informatie voor het gebruik en
bewaar ze voor toekomstige raadpleging

NO

VIKTIG INFORMASJON

Les bruksanvisningen nøye før bruk og
oppbevar den for senere bruk

SE

VIKTIG INFORMATION

Läs anvisningarna före användningen och
spara dem för framtida behov

DK

VIGTIGE OPLYSNINGER

Du bør læse brugsanvisningen før brug og
gemme til senere henvisning

ES

INFORMACIÓN IMPORTANTE

Léase antes de utilizar y consérvela como
referencia en el futuro

PT

INFORMAÇÕES IMPORTANTES

Leia antes de utilizar e guarde para consulta
futura

IT

INFORMAZIONI IMPORTANTI

Leggere prima dell’uso e conservare per
ulteriore consultazione

FI

TÄRKEÄÄ TIETOA

Lue tämä ennen käyttöä ja säilytä myöhempää
tarvetta varten

SK

Záruka na tento produkt nebude uznaná v
prípade porúch spôsobených nesprávnou
obsluhou alebo používaním výrobku na iný
účel alebo iným spôsobom, ako je uvedené.
Pred začatím práce si prosím dôkladne
prečítajte návod na obsluhu a tento si aj pre
prípad potreby uschovajte

SI

Garancija ne velja ob nepravilni uporabi
proizvoda in/ali ob uporabi za drugi namen
kot je izdelan. Prosimo, da pred uporabo,
preverite pazljivo navodila za obratovanje in
jih shranite za kasnejšo rabo.

HU

Jótállást vállalni csak rendeltetésszerűen
használatba vett gépekre tudunk. Kérjük,
hogy a gép használatba vétele elött
gondosan olvassa el a kezelési utasításokat.

PL

Gwarancja traci ważność w przypadku
używania urządzenia do celów innych niż
wymienione w instrukcji obsługi. Prosimy o
uważne przeczytanie instrukcji oraz o
stosowanie się do zaleceń i wskazówek w
niej zawartych

CZ

Záruka se nebude vztahovat na závady
způsobené nesprávným používáním, nebo
jestliže bude výrobek použit pro jiné účely
než pro jaké byl vyroben, nebo také jinak
než je uvedeno v návodu k obsluze. Tento
návod si přečtěte, prosím, velmi pozorně a
uchovejte jej pro možné budoucí odkazy

B

A

D E

F G

H

1

J

C

CH

CH CH

2

1

K

1

M

1

2

3

4

2

N P

Q

R

S

L

GB - CONTENTS

1. Switchbox

2. Start/stop lever

3. Spanner/scraper tool

4. Cutting height spacers (1 fitted to
lawnmower & 2 in loose parts
pack)

5. Instruction Manual

6. Warning Label

7. Product Rating Label

DE - INHALT

1. Schalter

2. Start-/Stopphebel

3. Schraubenschlüssel/
Reinigungswerkzeug

4. Schnitthöhen-Distanzscheiben (1
befindet sich am Rasenmäher &
2 werden lose in einem Beutel
geliefert)

5. Bedienungsanweisung

6. Warnetikett

7. Produkttypenschild

FR - TABLE DES MATIÈRES

1. Boîtier de commande.

2. Levier de démarrage/arrêt

3. Raclette

4. Rondelles de réglage de la
hauteur de coupe (1 rondelle
montée à la tondeuse & 2 livrées
en pièces détachées)

5. Manuel d’Instructions

6. Etiquette d’avertissement

7. Plaquette des Caractéristiques
du Produit

NL - INHOUD

1. Schakelaar

2. Start/stop-hendel

3. Moersleutel/schraapinstrument

4. Afstandhouder voor
maaihoogte(1 op maaimachine &
2 in onderdelenzak)

5. Handleiding

6. Waarschuwingsetiket

7. Product-informatielabel

NO - INNHOLD

1. Bryterboks

2. Start/Stopp hendel

3. Skrunøkkel/skrape

4. Distanseskiver for regulering av
klippehøyden (1 stk montert på
klipperen og 2 stk løse i posen
med løse deler)

5. Bruksanvisning

6. Advarselsetikett

7. Produktmerking

FI - SISÄLTÖ

1. Kytkinrasia

2. Käynnistyskahva

3. Ruuviavain/kaavin

4. Leikkauskorkeuden välilevyt(1
kiinnitetty ruohonleikkuriin & 2
irtonaista varustepakkauksessa)

5. Käyttöopas

6. Varoitusnimike

7. Ruohonleikkurin arvokilpi

SE - INNEHÅLL

1. Kopplingsdosa

2. Start/stopp-reglage

3. Skruvnyckel/Avskrapare

4. Distansbrickor för klippningshöjd

5. Bruksanvisning

6. Varningsetikett

7. Produktmärkning

DK - INDHOLD

1. Afbryderkontakt

2. Start/stophåndtag

3. Skruenøgle/skrabeværktøj

4. Afstandsskiver til indstilling af
klippehøjde (1 monteret på
plæneklipperen og 2 løse i
posen)

5. Brugsvejledning

6. Advarselsmœrkat

7. Produktets mærkeskilt

ES - CONTENIDO

1. Caja de conmutador

2. Palanca de arranque/parada

3. Herramienta/raspador

4. Espaciadores reductores de
altura (1 montado en la cortadora
y 2 sueltas en el paquete de
piezas)

5. Manual de instrucciones

6. Etiqueta de Advertencia

7. Placa de Características del
Producto

PT - LEGENDA

1. Caixa de distribuição

2. Barra para começar/parar

3. Chave de fendas

4. Separadores para a altura do
corte( 1 instalado na máquina &
2 no pacote das peças soltas)

5. Manual de Instrucções

6. Etiqueta de Aviso

7. Rótulo de Avaliação do Produto

IT - INDICE CONTENUTI

1. Cassetta dell’interruttore

2. Leva di avviamento

3. Chiave/raschietto

4. Distanziatori per l’altezza
dell’elemento falciante (1 montato
sul tosaerba e 2 di ricambio)

5. Manuale di istruzioni

6. Etichetta di pericolo

7. Etichetta dati del prodotto

HU - TARTALOMJEGYZÉK

1. Kapcsolódoboz

2. Start/Stop kar

3. Csavarkulcs/térközbeállító
szerszám

4. Távtartók a vágómagasság
beállításához (egy a fűnyíróban,
kettő a tartalék alkatrészek
csomagjában van)

5. Kezelési útmutató

6. Figyelmeztető címke

7. Termékminősítő címke

PL - ZAWARTOSC KARTONU

1. Puszka przyłączeniowa

2. Dźwignia start/stop

3. Klucz/skrobak

4. Podkładki do regulacji wysokości
koszenia(1 na kosiarce, 2 w
opakowaniu)

5. Instrukcja Obsługi

6. Znaki bezpieczeństwa

7. Tabliczka znamionowa

CZ - POPIS STROJE

1. Spínací skříňka

2. Spouštěcí/vypínací páka

3. Klíč/nástroj pro čištění

4. Distanční tělíska k nastavení
řezné výšky (1 na sekačce a 2 v
balíčku s náhradními díly)

5. Návod k obsluze

6. Výstražný štítek

7. Typový štítek výrobku

SK - OBSAH

1. Spínacia skrinka

2. Zapínač/vypínač

3.K0úč/škrabka

4. Výškové rozpery (1 namontovaná
na kosačke a 2 v balíčku so
súčiastkami)

5. Príručka

6. Varovný štítok

7. Prístrojový štítok

SI - VSEBINA

1. Ohišje stikala

2. Start-stop ročka

3. Ključ/strgalo

4. Obročki za nastavitev višine
rezanja (1 nastavljen v kosilnici in
dva priložena v vrečki)

5. Priročnik

6. Opozorilna oznaka

7. Tipna tablica

(GB) CARTON CONTENTS
(DE) KARTONINHALT
(FR) CONTENU DU CARTON
(NL) INHOUD
(NO) KARTONGEN

INNEHOLDER

(FI) PAKETIN SISÄLTÖ

(SE) FÖRPACKNINGENS

INNEHÅLL
(DK) KARTONINDHOLD
(ES) CONTENIDO DEL

CARTON
(PT) LEGENDAS DOS

DESENHOS

(IT) CONTENUTO

(HU) A DOBOZ TARTALMA
(PL) ZAWARTOŚĆ KARTONU
(CZ) OBSAH KRABICE
(SK) OBSAH BALENIA
(SI) VSEBINA ŠKATLE

1

2

3

4

6

7

5

SAFETY PRECAUTIONS

Explanation of Symbols on the Flymo Compact

Warning

Read the user instructions carefully to
make sure you understand all the
controls and what they do.

Always keep the lawnmower on the
ground when mowing. Tilting or lifting
the lawnmower may cause stones to
be thrown out

Keep bystanders away. Do not mow
whilst people especially children or
pets are in the mowing area

Switch off! Remove plug from mains
before adjusting, cleaning or if cable is
entangled or damaged. Keep the cable
away from the blade.

Beware of severing toes or hands.
Do not put hands or feet near a
rotating blade.

Blade continues to rotate after the
machine is switched off. Wait until all
machine components have completely
stopped before touching them.

Do not mow in the rain or leave the
lawnmower outdoors while raining

General

1. Never allow children or people unfamiliar with these
instructions to use the mower. Local regulations may
restrict the age of the operator.

2. Only use the lawnmower in the manner and for the
functions described in these instructions.

3. Never operate the lawnmower when you are tired, ill
or under the influence of alcohol, drugs or medicine.

4. The operator or user is responsible for accidents or
hazards occurring to other people or their property.

Electrical

1. The use of a Residual Current Device (R.C.D.) with
a tripping current of not more than 30mA is
recommended. Even with a R.C.D. installed 100%
safety cannot be guaranteed and safe working
practice must be followed at all times. Check your
R.C.D. every time you use it.

2. Before use, examine cable for damage, replace it if
there are signs of damage or ageing.

3. Do not use the lawnmower if the electric cables are
damaged or worn

4. Immediately disconnect from the mains electricity
supply if the cable is cut, or the insulation is
damaged. Do not touch the electric cable until the
electrical supply has been disconnected. Do not
repair a cut or damaged cable. Replace it with a
new one.

5. Your extension cable must be uncoiled, coiled
cables can overheat and reduce the efficiency of
your mower.

6. Keep cable away from lawnmower, always work
away from the power point mowing up and down,
never in circles.

7. Do not pull cable around sharp objects.

8. Always switch off at the mains before disconnecting
any plug, cable connector or extension cable.

9. Switch off, remove plug from mains and examine
electric supply cable for damage or ageing befor

e

winding cable for storage. Do not repair a damaged
cable, replace it with a new one. Use only Flymo
replacement cable.

10. Always wind cable carefully, avoiding kinking.

11. Never carry the product by the cable.

12. Never pull on the cable to disconnect any of the
plugs.

13. Use only on AC mains supply voltage shown on the
product rating label.

14. Our products are double insulated to EN60335.
Under no circumstance should an earth be
connected to any part of the product.

Cables

Use only 1.00mm

2

size cable up to 30 metres length

maximum.

Maximum rating:

1.00mm

2

size cable 10 amps 250 volts AC

1. Mains cables and extensions are available from
your local Electrolux Outdoor Products Approved
Service Centre.

2. Only use extension cables specifically designed for
outdoor use.

Preparation

1. While using your product always wear substantial
footwear and long trousers.

2. Make sure the lawn is clear of sticks, stones, bones,
wire and debris; they could be thrown by the blade.

3. Before using the machine and after any impact,
check for signs of wear or damage and repair as
necessary.

4. Replace worn or damaged blades together with their
fixings in sets to preserve balance.

Use

1. Use the lawnmower only in daylight or good artificial
light.

2. Avoid operating your lawnmower in wet grass,
where feasible.

3. Take care in wet grass, you may lose your footing.

4. On slopes, be extra careful of your footing and wear
non-slip footwear.

5. Mow across the face of slopes, never up and down.

6. Exercise extreme caution when changing direction
on slopes. Walk never run.

7. Mowing on banks and slopes can be dangerous. Do
not mow on banks

or steep slopes.

If not used properly this lawnmower can be dangerous! This lawnmower can cause serious injury
to the operator and others, the warnings and safety instructions must be followed to ensure
reasonable safety and efficiency in using this lawnmower. The operator is responsible for following
the warning and safety instructions in this manual and on the lawnmower. Never use the mower
unless the grassbox or guards provided by the manufacturer are in the correct position.

ENGLISH - 1

STOP

SAFETY PRECAUTIONS

8. Do not walk backwards when mowing, you could
trip.

9. Never cut grass by pulling the mower towards you.

10. Switch off before pushing the mower over surfaces
other than grass.

11. Never operate the lawnmower with damaged guards
or without guards in place.

12. Keep hands and feet away from the cutting means
at all times and especially when switching on the
motor.

13. Do not tilt lawnmower when the motor is running,
except when starting and stopping. In this case, do
not tilt more than absolutely necessary and lift only
the part which is away from the operator. Always
ensure that both hands are in the operating position
before returning the appliance to the ground.

14. Never pick up or carry a mower when it is operating
or still connected to the mains supply.

15. Remove the plug from the mains :

- before leaving the mower unattended for any period;

- before clearing a blockage;

- before checking, cleaning or working on the
appliance;

- if you hit an object. Do not use your lawnmower
until you are sure that the entire lawnmower is in a
safe operating condition.;

- if the lawnmower starts to vibrate abnormally.
Check immediately. Excessive vibration can cause
injury.

Maintenance and storage

1. Keep all nuts, bolts and screws tight to be sure the
lawnmower is in safe working condition.

2. Check the grassbox/grassbag frequently for wear or
deterioration.

3. Replace worn or damaged parts for safety.

4. Only use the replacement blade, blade bolt, spacer
and impeller specified for this product.

5. Be careful during adjustment of the lawnmower to
prevent entrapment of the fingers between moving
blades and fixed parts of the machine.

HANDLES

Preparing your lawnmower for use

• Your lawnmower is supplied with the upper
handle folded over the machine for packing and
transportation. (See Figure A)

Handle in Operating Position

• Lift handle as illustrated in figure B.

• Do not drop the handle.

• Make sure that the cable does not become
trapped between the handles

STARTING AND STOPPING

To Start your Lawnmower

1. Connect female extension cable connector to the
back of the switchbox (C).

2. Form loop in mains cable and push the loop through
the slot as illustrated in picture (D)

3. To secure, position loop over the hook and pull the
cable back through the slot as illustrated in picture
(E).

4. Connect plug to mains and switch on.

5. To prevent a ring being cut in your lawn and to clear
any residual grass in the collection chute, tilt your
lawnmower slightly (F).

The switchbox is provided with a lock-off button
(G1) to prevent accidental starting.

6. Press and hold the lock-off button (G) on the
switchbox, then squeeze one of the Start/Stop
levers towards the upper handle (H).

7. Continue to squeeze the start/stop lever towards the
upper handle and release the lock-off button.

8. When the lawnmower has reached full speed gently
lower it onto the lawn.

• NOTE
There are two start/stop levers fitted. Either one
can be used for starting the lawnmower.

• IMPORTANT
Do not use the start/stop levers intermittently

To Stop your Lawnmower

1. To prevent a ring being cut in your lawn and to clear
any residual grass in the collection chute, tilt your
lawnmower slightly (F).

2. Release the pressure on the Start/Stop lever.

HOW TO MOW

1. For the best results mow the outside edge of the
lawn in a clockwise direction first. (H1)

2. Then start mowing the edge of the lawn nearest to
the power point so the cable is laid out on the lawn
you have already cut. (H2)

3. For best grass collection always mow in a straight
line, do not swing the lawnmower from side to side.

• Do Not Overload Your Mower

Mowing long thick grass may cause the motor speed to
drop, you will hear a change in the motor sound. If the
motor speed drops you may overload your lawnmower
which may cause damage. When mowing in long thick
grass a first cut with the cutting height set higher will
help reduce the load. See Adjusting the Cutting Height.
Mow twice a week during the growing season, your
lawn will suffer if more than a third of its length is cut at
one time and this may also result in poor collection.

ADJUSTING THE CUTTING HEIGHT

• Always handle the blade with care - sharp edges
could cause injury.

• USE GLOVES.

• Never use more than 3 Cutting Height Spacers.

• Spacers must only be fitted between the blade and
the fan and NEVER between the blade and the bolt.

1. Remove the blade bolt, and blade as described in

Removing the Blade and Fan.

2. For a Lower Cut - Add spacers to a maximum of 3.

3. For a Higher Cut - Take spacers away.

4. Refit the blade as described in Fitting the Blade

and Fan.

ENGLISH - 2

CARING FOR YOUR LAWNMOWER

Cleaning

• IMPORTANT

It is very important that you keep your lawnmower
clean. Grass clippings left in any of the air intakes or
under the hood could become a potential fire hazard.

• USE GLOVES

1. Remove grass from under the hood with the
spanner/scraper tool. (Q)

2. Using a soft brush - remove grass clippings from all
air intakes and the grassbox. (R)

3. Remove the blade, see Figure K, to gain access to
the fan and clean with a soft brush. (R)

4. Remove grass clippings from both sides of the
grassbox full indicator (if fitted). (R)

5. Clean your lawnmower thoroughly. (R)

6. Wipe over the surface of your lawnmower with a dry
cloth. (R)

• IMPORTANT

Never use water for cleaning your lawnmower. Do
not clean with chemicals, including petrol, or
solvents - some can destroy critical plastic parts.

At the End of the Mowing Season

1. Replace blade and blade bolt, if necessary.

2. Clean your lawnmower thoroughly.

3. Ask your local Service Centre to clean the air filter
thoroughly and carry out any service or repairs
required.

4. Make sure that the electric cable is coiled properly.

Storing the lawnmower

The handles can be folded to take up the minimum of
space.

1. Hold onto the lower handle with your left hand (as
illustrated in figure S).

2. Hold the upper handle with your right hand and
push in the direction of the arrow.

3. Move the handle slowly forward to rest it on the
lawnmower. Do not drop the handle.

• Ensure the switchbox cable is not trapped.

• Store in a dry place where your lawnmower is
protected from damage.

ENGLISH - 3

REMOVING, EMPTYING AND REFITTING THE GRASSBOX

M1 - Grassbox is full, M2 - Grassbox is empty
Grassbox Full Indicator (if fitted) (M)

• Your lawnmower may be fitted with a grassbox
full indicator

• IMPORTANT
The machine must be switched on for the
grassbox full indicator to operate

1. When the ball reaches the top of the indicator
window, it is time to empty the grassbox. See figure

M.

2. When the ball is NOT

visible in the indicator

window, grass is being collected. See figure M.

Emptying the Grassbox

• Stop the lawnmower, as described in ‘To Stop
your Lawnmower’ and wait until the blade has
stopped rotating, BEFORE lifting the grassbox
lid.

1. Lift the grassbox lid and rest it against the lower
handle (N).

2. Remove the grassbox using the moulded handle
recesses at the front and rear of the grassbox. (See
Figure P).

3. Empty grassbox.

4 Replace grassbox and lid carefully.

• Failure to fit the grassbox and grassbox lid

correctly will cause poor collection of grass
clippings.

REMOVING AND FITTING THE BLADE AND FAN

L1 - Blade Bolt, L2 - Blade, L3 - Spacers, L4 - Fan
Removing the Blade and Fan

1. To remove the blade bolt, hold the fan firmly and
with the spanner provided loosen the blade bolt by
turning it anti-clockwise (K).

2. Remove the blade bolt, blade, spacers and fan.(L)

3. Inspect for damage and clean as necessary.

• Renew your metal blade after 50 hours mowing
or 2 years whichever is the sooner - regardless
of condition.

• If the blade is cracked or damaged replace it
with a new one.

• Never use a blade bolt if the insulated head is
damaged cracked or missing.

Fitting the Blade and Fan

1. Ensure the fan is located correctly.(L)

2. Place the spacers onto the fan ensuring the pegs
have located into the holes.(L)

3. Place the blade onto the spacers ensuring the pegs
have located into the holes on the blade and
ensuring the blades is positioned as illustrated in
Figure L.

4. Place the blade bolt through the centre hole of the
blade.

5. Tighten down clockwise by hand.

6. Hold the fan firmly and tighten the blade bolt with
the spanner provided.

FAULT FINDING HINTS

Fails to Operate

1. Is the correct Starting procedure being followed?
See ‘To Start your Lawnmower’

2. Is the Power Turned On?

3. Check the fuse in the plug, if blown replace.

4. Fuse continues to blow?

Immediately disconnect from the mains
electricity supply and consult your local
approved Service Centre.

Poor Flotation

1. Disconnect from the mains electricity supply.

2. Clean the underside of the hood and the fan blades.

3. Raise to a higher height of cut. See ‘Adjusting the
Cutting Height’.

4. If poor flotation persists?

Disconnect from the mains electricity supply
and consult your local approved Service Centre.

ENGLISH - 4

Poor Collection

1. Is the grassbox lid firmly closed?

2. Is the grassbox fitted correctly?

3. Are you mowing correctly?

4. Check all air vents and openings are not obstructed.

5. Raise to a higher height of cut. See ‘Adjusting the
Cutting Height’.

6. If poor collection persists.

Disconnect from the mains electricity supply
and consult your local approved Service Centre.

Excessive Vibration

1. Disconnect from the mains electricity supply.

2. Check that the blade is fitted correctly?

3. If the blade is damaged or worn, replace it with a
new one.

4. If vibration persists?

Immediately disconnect from the mains
electricity supply and consult your local
approved Service Centre.

GRASSBOX FULL INDICATOR (IF FITTED)
Grassbox Full Indicator Ball is visible when the
grassbox is empty
Grassbox Full Indicator Ball Fails to Operate

1. Remove grass clippings from both sides of grassbox
full indicator (U).

2. Make sure the collection chutes on the hood and
grassbox are clean and free from debris.

3. If the chute blocks persistently in longer grass ­raise the cutting height.

4. If the problem persists.

Immediately disconnect from the mains
electricity supply and consult your local
approved Service Centre.

FAULT FINDING HINTS

GUARANTEE AND GUARANTEE POLICY

If any part is found to be defective due to faulty
manufacture within the guarantee period, Electrolux
Outdoor Products, through its Authorised Service
Repairers will effect the repair or replacement to the
customer free of charge providing:
(a) The fault is reported directly to the Authorised

Repairer.
(b) Proof of purchase is provided.
(c) The fault is not caused by misuse, neglect or faulty

adjustment by the user.
(d) The failure has not occurred through fair wear and

tear.
(e) The machine has not been serviced or repaired,

taken apart or tampered with by any person not

authorised by Electrolux Outdoor Products.
(f) The machine has not been used for hire.
(g) The machine is owned by the original purchaser.
(h) The machine has not been used outside of the

country for which it was specified.
(i) The machine has not been used commercially.
* This guarantee is additional to, and in no way

diminishes the customers statutory rights.

Failures due to the following are not covered, therefore
it is important that you read the instructions contained in
this Operator's Manual and understand how to operate
and maintain your machine:

Failures not covered by guarantee

* Replacing worn or damaged blades
* Failures as a result of not reporting an initial fault.
* Failures as a result of sudden impact.
* Failures as a result of not using the product in

accordance with the instructions and
recommendations contained in this Operator's
Manual.

* Machines used for hire are not covered by this

guarantee.

* The following items listed are considered as wearing

parts and their life is dependent on regular
maintenance and are, therefore not normally subject
to a valid warranty claim: Blades, Electric Mains
cable.

* Caution!

Electrolux Outdoor Products does not accept liability
under the warranty for defects caused in whole or
part, directly or indirectly by the fitting of
replacement parts or additional parts that are not
either manufactured or approved by Electrolux
Outdoor Products, or by the machine having been
modified in any way.

ENVIRONMENTAL INFORMATION

Electrolux Outdoor Products are manufactured under an
Environmental Management System (ISO 14001)
using, where practical, components manufactured in the
most environmentally responsible manner, according to
company procedures, and with the potential for
recycling at the end of the products’ life.

• Packaging is recyclable and plastic components
have been labelled (where practical) for categorised
recycling.

• Awareness of the environment must be considered
when disposing of ‘end-of-life’ product.

• If necessary, contact your local authority for disposal
information.

SERVICE RECOMMENDATIONS

• Your product is uniquely identified by a silver and black product rating label.

• We strongly recommend that your product is serviced at least every twelve months, more often in a
professional application.

BELGIQUE/BELGIË Flymo Belgique/België

Tel: [phone], Fax: [phone]

ČESKÁ REPUBLIKA Electrolux, spol. s.r.o., oz Electrolux Outdoor Products,

Na Křečku 365, Praha 10 - Horní Měcholupy.
Tel: [phone], Info-linka: 0800/110 220
Internet: www.partner-flymo.cz E-mail: [e-mail]

DANMARK Electrolux Outdoor Products, Flymo/Partner A/S,

Lundtoftegaardsvej 93A, DK 2800 Kgs.Lyngby
Tel: [phone], Fax: [phone], www.flymo-partner.dk

DEUTSCHLAND Flymo Deutschland

Tel: [phone], Fax:[phone]

ESTONIA Electrolux Estonia Ltd (Electrolux Eesti AS)

Tel: [phone]

FRANCE Flymo France SNC

Tel [phone], Fax [phone]

FINLAND SUOMI Electrolux Outdoor Products Finland

Tel: [phone], Fax: [phone]

ITALIA McCulloch Italiana s.r.l. - Via Como 72, 23868 Valmadrera

(LECCO) - ITALIA
Tel: [phone], Fax: [phone]

IRELAND Flymo Ireland

Tel: [phone], Fax: [phone]

MAGYARORSZÁG Electrolux Lehel Kft

Tel: [phone]

NORGE Flymo/Partner, div. av Electrolux Motor a.s.

Tel: [phone]

NEDERLAND Flymo Nederland

Tel: [phone], Fax: [phone]

ÖSTERREICH Husqvarna-Ges.m.b.H. Nfg. KG, Industriezeile 36, 4010 LINZ,

Tel: [phone], Fax: [phone],
email: [e-mail] Internet: www.husqvarna.at

POLSKA Electrolux Poland Sp. z.o.o. Husqvarna, 01-612 Warszawa

Myslowicka 10/2
Tel:- (22) 8332949

SLOVENIJA Husqvarna-Ges.m.b.H. Nfg. KG, Industriezeile 36, 4010 LINZ,

Tel: [phone], Fax: [phone],
email: [e-mail] Internet: www.husqvarna.at

SLOVENSKA Electrolux Slovakia s.r.o., Borova Sihot 211, 033 01 Lipt. Hradok

Tel: [phone], Fax: [phone], www.flymo-partner.sk

SCHWEIZ/SUISSE/SUIZZERA Flymo Schweiz/Suisse/Suizzera

Tel [phone], Fax [phone]

SVERIGE Electrolux Outdoor Products, Sverige

Tel: 036 – 14 67 00, Fax: 036 – 14 60 70

UNITED KINGDOM Electrolux Outdoor Products United Kingdom

Tel: [phone], Fax: [phone]

5119231-02

Electrolux Outdoor Products

Aycliffe Industrial Park

NEWTON AYCLIFFE

Co.Durham DL5 6UP

ENGLAND

Telephone - (00) 44 1325 300303 Fax - (00) 44 1325 310339

UK Telephone - 01325 300303 Fax - 01325 310339

Our policy of continuous improvement means that the specification of products may be altered from time to time without prior notice.

Electrolux Outdoor Products manufacture products for a number of well known brands under various registered patents, designs and

trademarks in several countries.

© Electrolux Outdoor Products Ltd. Registered Office, Electrolux Works, Oakley Road, Luton LU4 9QQ

Registered number 974979 England

The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million

Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are

sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.

The Electrolux Group. The world’s No.1 choice.
