Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Introduction

Thank you for purchasing a Flybox® product. We hope it provides many years of service to you, becoming a useful instrument for easy and immediate consultation. Developing Oblò our intent was to create a compact and lightweight attitude indicator / EFIS, easy to install and to use. Oblò is equipped with state-of-the-art highly visible display and the latest generation of solid state inertial sensors to ensure reliability and accuracy over time.

SYMBOLS USED IN THE MANUAL

NOTE: Used to highlight important informations.

CAUTION: Used to warn the user and indicate a potentially

hazardous situation or improper use of the product.

WARNING: Used to indicate a dangerous situation that can cause personal injury or death if the instruction is disregarded.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

NOTE: Keep this manual in the aircraft. This document must accompany the instrument in the event of change of ownership.

NOTE: This device is intended for installation onto non type certified aircraft only, because it has no aviation certifications. Refer to your local aviation authorities to check if this device may be installed in your aircraft.

CAUTION: Read entirely this manual before installing the instrument in your aircraft, and follow the installation and operating instructions described here.

CAUTION: The pilot must understand the operation of this instrument prior to flight, and must not allow anyone to use it without knowing the operation. Don't use this instrument in flight until you are sure of the correct operating of the same.

Important notices & warnings

CAUTION: This instrument cannot be used under any

circumstances to conduct flights in IMC conditions.

CAUTION: When the installation is finished you must do a test, prior to flight, switching on all the possible source of electric noise and checking the properly operation of this instrument.

CAUTION: Using this instrument over the maximum allowable ranges can cause malfunction or wrong indications.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Important notices & warnings

CAUTION: The software of this instrument can be subject to

change, update, addition or removal of functions, so also the operating mode of the instrument can be subject to change. Always refer to the installation and operating manual updated with the software version used in your instrument. To obtain updated software and manuals, please visit www.flyboxavionics.it.

WARNING: Responsibility for installation lies entirely with the installer. Responsibility for operations lies entirely with the operator. Responsibility for any calibration, alarms thresholds and activations, every customizable instruments thresholds or any other settings lies with the person performing these modifications.

WARNING: Do not solely rely on the Oblò to determine the primary flight informations. Always compare the informations provided with other primary flight instruments to recognize eventual malfunction.

IMPORTANT: If you do not agree with the notices above do not install the Oblò in your aircraft, but return the product for a refund.

Microel s.r.l. reserves the right to change or improve its products. Information in this document is subject to changes without notice.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Index

INDEX

SECTION 1 - Standard Oblò installation

1.1 - Mechanical installation …….…………………………….. 12

1.2 - Electrical and pneumatic installation ……..………….….. 17 General wiring hints ………………..……………….….. 20 Optional accessories available …….….…………….…... 20

1.3 - Altitude serial out for transponder …………….…………. 21

1.4 - Primary actions after installation ………………...………. 23

SECTION 2 - Oblò-A/P installation

2.1 - Mechanical installation ..…................................................. 25

Oblò-A/P installation ………...…….…............................ 25

ACU control unit installation .………............................... 25

Servo/s installation ……………….…............................... 28

2.2 - Electrical installation …...................................................... 30

SECTION 3 - Oblò-REP (repeater) installation

3.1 - Oblò-REP (repeater) installation …..................................... 37

3.1.1 - Electrical installation Oblò standard–>Oblò-REP ........... 38

3.1.2 - Electrical installation Oblò-A/P–>Oblò-REP …….......... 39

SECTION 4 - Instrument configuration

4.1 - Main menu configuration ..………...................................... 41

Zero pitch .……….…….…………................................... 42

TRK/HDG ……….…….…………................................... 42

Light ………….….…….…………................................... 42

G-meter reset ...….…….………….................................... 42

4.2 - Setup menu configuration ………....................................... 43

T.R.I. (Turn rate indicator) ………..........................….…. 43

Ball (Slip indicator) ………………................................... 44

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Index

Roll ……….….………….……….................................… 44

Pitch …….….………….……..…..................................… 45

ASI (Airspeed) ….….………...……….........................… 46

ALT/VSI (Vertical scale indicator) ...............................… 47

Autopilot …….….……..……..….................................… 48

G-meter …….………….……..….................................… 48

GPS ….….….………….……..….................................… 49

HSI ….….….………….……..…..............................….… 50

Compass ……………….……..….................................… 50

ADI ….….….………….……..….................................… 51

Config …..….………….……..….................................… 51

About ……….………….……..….................................… 52

FW Upgrade ..………….……..….................................… 52

4.3 - Magnetic calibration ….…………...................................... 53

SECTION 5 - Using the Oblò

5.1 - Using the Oblò ………………..…….…....….……........... 56

5.1.1 Attitude indicator page ……..…...…...........................… 57

5.1.2 HSI page …………………..….….............................… 64

5.1.3 Drum altimeter page ..…..…..….................................… 66

SECTION 6 - Autopilot system

6.1 - Autopilot system ..….….….……………............................ 67

Requirements …….…….……..….................................… 67

Autopilot overview ………………................................… 68

Remote disengage button …….….................................… 70

6.2 - Autopilot system configuration ………….......................... 71

6.2.1 - Servo/s calibration ……………..….………................ 72

6.2.2 - Communications check ……….……………............... 78

6.2.3 - Remote button operation check …………...…............ 79

6.2.4 - Servo torque check ……………..….….…….............. 80

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.3 - Autopilot setup menu ……………….....……..................... 81

6.3.1 - “Min Spd” and “Max Spd” parameters setting …........ 82

6.3.2 - Roll servo setup ……………...….….….…………..... 84

6.3.3 - Pitch servo setup ……………………….…………..... 87

6.3.4 - Remote button setup ……………..….….…………..... 91

6.4 - Flight based test and configuration .….……....................... 93

6.4.1 - Autopilot setup - Roll axis (Flight based) ………....... 95

6.4.2 - Autopilot setup - Pitch axis (Flight based) ….……..... 99

SECTION 7 - Autopilot operation

7.1 - Autopilot operation ………….…….………....................... 102

7.2 - How to engage and disengage the autopilot …………........ 105

7.3 - Details of operation ….………………...….…................… 108

7.4 - Autopilot related alarms ………………….......................... 114

7.5 - Important notices - safety checks ..…………...................... 117

7.6 - Autopilot activation procedure ….….………..................... 118

SECTION 8 - Use of the Oblò-REP (optional)

8.1 - Use of the Oblò-REP .….……….…………...................… 121

Index

SECTION 9 - Technical specifications

9.1 - Technical specifications ………….…………...........…..… 123

APPENDIX “A” - Altimeter calibration …..……..……………. 124 APPENDIX “B” - Detail of optional wirings …….……………. 126 APPENDIX “C” - Detail of optional GPS module..……………. 128

WARRANTY ……….………………….………………………. 130

Revision history ……….………………………..………………. 131

III

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Page intentionally left blank

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

INSTALLATION

SECTION

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Standard Oblò installation

1.1 MECHANICAL INSTALLATION

Mechanical installation

SECTION 1

Oblò fits in a standard 3 1/8” (80 mm) cutouts. On the

1) panel it's necessary to make the cutout for the knob on the lower right hole.

The installation location must be carefully chosen since

2) Oblò contains magnetic sensors for the compass indication. Given that a location without magnetic interference can be difficult or impossible to find, it’s recommended to install the instrument in the top row of the instrument panel, to limit the interference of cables, switches and breakers that are usually found at the bottom. Do not install near any magnetic sources (wires that carry large amount of current, magnets/electromagnets, electric motors, airplane parts or metal parts that may have residual magnetic field). As a general rule keep a minimum distance of 30cm, but 60cm or more are recommended. To test if the location where you intend to install it is appropriate, turn on all the electrical loads (in particular radio and strobe lights) and move a handheld compass around the area making sure that the compass needle is stable (should not cycles back and forth) and is approximately indicating the magnetic North. Small deviations from the North can be compensated with the magnetic calibration (see chap.4.3)

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

During use the instrument become warm so it's

3) necessary to have some air circulation inside the instruments room, to avoid that the temperature increase over the operating limits.

Avoid placing in hot locations (for example near heater

4) vents).

Find a location where the display will always be

5) completely visible.

Standard Oblò installation

Mechanical installation

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Standard Oblò installation

Mechanical installation

Front view

Flybox

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Side view

Standard Oblò installation

Mechanical installation

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Standard Oblò installation

Mechanical installation

Panel cut-out

Flybox

- All dimensions are in millimeters.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Standard Oblò installation

Electrical installation

1.2 ELECTRICAL AND PNEUMATIC INSTALLATION

On the backpanel of the Oblò there is a 15 poles D-sub plug connector, supplied with the corresponding 15-pole receptacle, one static and one pitot port.

Use 1/8” NPT male fittings to connect the static pressure (STATIC) and the dynamic pressure (PITOT).

CAUTION: Don't blow air inside the fittings.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Standard Oblò installation

Electrical installation

CON1 connector pinout

PIN# Description 1 +12V Main supply 2 GND Main supply

Flybox

6 Transponder altitude serial out (see chap.1.3) 7 Autopilot remote button (see chap.2.2) 8 Not used 9 USB-VCC 10 USB-D+ 11 USB-D- 12 USB-GND 13 Low-level intercom audio out (see chap.2.2)

14 GPS input (connect to TX signal of an external GPS)

15 Not used

CAN H signal for autopilot control unit connection (see chap.2.2)

CAN L signal for autopilot control unit connection (see chap.2.2)

Open-collector alarm-out (active low) max 400mA / 5W (see chap.2.2)

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Standard Oblò installation

Electrical installation

NOTE: Connections of pin#9-10-11-12 to a USB connector

is used for software upgrades and for datalogger function (in development).

CAUTION: The connection of the external GPS is highly

recommended to increase the accuracy of the attitude indicator. It is also required for the tracking indication and for the automatic correction of magnetic declination. If you connect a GPS that is not powered by the aircraft bus (for example battery-powered), connect together the ground of the GPS and of the Oblò. If no external GPS is available use the Flybox® GPS cod. 810010.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Standard Oblò installation

Electrical installation

GENERAL WIRING HINTS:

- Take care to properly insulate any exposed wire to

avoid short circuits.

- Insert a 1-Ampere circuit breaker to the power lead (+12V).

- Use aeronautic cable for the wiring.

CAUTION: Voltage peaks on the supply line that exceeds the operating limits (20V) can damage the device.

OPTIONAL ACCESSORIES AVAILABLE:

- Ready to use wiring (ord. cod. 802000).

- GPS receiver module (ord. cod. 810010).

- USB flash drive, for eventual software upgrades.

- Backup battery system (ord.cod. 810020).

NOTE: Visit our web page http://www.flyboxavionics.it/en/oblo.html for updated prices and informations.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Standard Oblò installation

Electrical installation

1.3 ALTITUDE SERIAL OUT FOR TRANSPONDER CONNECTION

If you use a transponder with serial input for receiving the altitude data, it can be connected to the Oblò by following this steps:

- To enable the transponder output it's required to

connect a 10Kohm resistor between pin#1 and pin#14 (whether or not it's connected the external GPS on pin#14).

- Ensure there is a shared ground between the Oblò and the transponder.

- Wire a serial transmit line, using shielded cable, from the Oblò (pin#6 of the connector) to the respective receive connection on the transponder. The serial out of the Oblò is RS232 type, refer to the transponder manual for its installation and configuration.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Standard Oblò installation

Electrical installation

Connection of altitude serial out for transponder:

The Oblò does not require any configuration, the altitude data is transmitted once per second with the followig protocol:

Baud Rate Message formatting Example

9600 bps

The message contains the current pressure altitude, in feet, with a fixed reference to 1013.25mB (29.92 inches mercury). The resolution is 10 ft.

NOTE: If you use the ready-to-use wiring (ord. cod. 802000 or

802010), the 10 Kohm resistor between pin#1 and pin#14 is already fitted inside the connector housing of the wiring.

Alt,space,five altitude digits,

carriage return

Rev.3.7

ALT 05200 [CR]

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Standard Oblò installation

Pre-flight check

1.4 PRIMARY ACTIONS AFTER INSTALLATION

WARNING: Do not fly until you have performed at

least the actions indicated below:

1) Airspeed bar thresholds setting: It's essential to set the airspeed thresholds (bar colors) according to the V-speeds of the aircraft on which you installed the instrument, as explained in chapter 4.2, section “ASI”. Flying without correctly set this thresholds may be very dangerous because the airspeed bar indicate the colors relative to the various V-speeds incorrectly. The default factory settings are all preset to zero.

2) Magnetic calibration: The magnetic calibration after the installation of your Oblò is an essential procedure that you must perform before you fly. Not only the heading, but also the attitude indicator depends on a correct magnetic calibration. Without it there is no data stored for the magnetic sensors and the attitude indicator, that use this data also, may not work correctly. The magnetic calibration it's a simple procedure that is explained in chapter 4.3.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Standard Oblò installation

Pre-flight check

3) Instruments panel pitch adjust: For the proper operation of the attitude indicator it's necessary to compensate the inclination of the instruments panel regards the longitudinal axis of the aircraft, as explained in chap.4.2, “Pitch” parameter.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

OBLÒ-A/P INSTALLATION

Oblò-A/P installation

Mechanical installation

SECTION 2

2.1 MECHANICAL INSTALLATION

- Mechanical installation of Oblò A/P is identical to the

standard Oblò (see chap.1.1) with the addition of:

- Mechanical installation of ACU autopilot control unit.

- Mechanical installation of servo/s.

ACU AUTOPILOT CONTROL UNIT INSTALLATION

The ACU is available in two versions, for horizontal or vertical mounting.

- Required panel cutout: 120 x 36.1 mm.

- Outer dimensions: 139.1 x 42.1 mm.

- Screw the ACU to the instruments panel with two M3 screws.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Oblò-A/P installation

Horizontal installation (dimensions in millimeters)

Mechanical installation

Flybox

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Mechanical installation

Vertical installation (dimensions in millimeters)

Oblò-A/P installation

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Oblò-A/P installation

Mechanical installation

SERVO/S INSTALLATION :

The Flybox FX75 digital servos incorporates important safety features:

It has a reliable disengaging system: situations like severe turbolence or something other kind of anomaly will not be a problem, because the pilot can take in any case the immediate control of the plane.

When the autopilot isn't engaged, the internal gears are completely disconnected, then at difference as some servomotors the pilot will not feel no residual torque at the command stick, giving a confortable flight. In case of mechanical failure, the gear train is engineered to be reversible: the pilot can overtop the power of the brushless motor, it provides to the servomotor a further safety level.

Flybox

The output torque is electronically adjustable, and in case of forced action from the pilot on the command stick, the disengage will be without the breaking of a shear pin (unlike other servomotors on the market that use that mechanical safety system that after the break, needs a remediation action to work again).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

A software function disengage the autopilot if the pilot override the servo for more than 1 seconds.

It's recommended to install also the remote disengage button, to have an immediate way to disengage the autopilot even in presence of strong turbulence.

For installation instructions refer to the installation manual, which is included with each servo.

Oblò-A/P installation

Mechanical installation

WARNING: improper installation of servos can lead to

loss of control of the aircraft, resulting in damage to the aircraft itself and injury or death of the occupants. BE SURE TO CAREFULLY FOLLOW THE INSTALLATION INSTRUCTIONS, AND CONSULT A QUALIFIED INSTALLER.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Oblò-A/P installation

Electrical installation

Flybox

2.2 ELECTRICAL INSTALLATION

AUTOPILOT SYSTEM INSTALLATION:

• To install the autopilot system, in addition to perform the standard installation as described in chap.1.2, you must also perform the following wirings:

- Oblò ==> ACU control unit

- ACU control unit ==> servo/s

• The ACU control unit has two Molex minifit-jr connectors:

- 1 four-pole connector (here called “CON4P”).

- 1 eight-pole connector (here called “CON8P”).

Included in the kit there are the corresponding socket connectors (Molex P/N: 5556-04R for 4-poles connector and 5556-08R for 8-poles connector) and the crimp terminals (Molex P/N: 5556-TL).

Each servos is provided with a 10-poles Molex Microfit connector (Molex 43025-1000) and the corresponding crimp terminals (Molex 43030-0007).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

The electrical installation consists of the following wirings:

Oblò-A/P installation

Electrical installation

- 12 Volt power supply: the power supply input is in the

ACU control unit and power also the connected servos. Use wire with adequate sizing to minimize voltage drop and avoid that the wire become warm (recommended size: AWG18).

CAUTION: Power must be supplied through a breaker connected exclusively to the ACU control unit, easily accessible to the pilot and clearly identified as “Autopilot”. If you have one servo only use a 4 Ampere breaker, if you have two servos use a 7.5 Ampere breaker.

Wirings between ACU control unit and Oblò instrument:

1) the ACU is connected to the Oblò with a two-wires CAN bus communication line. Use a two-pole twisted cable or a two-pole with shield cable (shield connected to ground in one point only). AWG24 wires should be enough.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Oblò-A/P installation

Electrical installation

Wirings of the servos: each servo need to be connected

2) to the ACU control unit with two wires for the power supply (use AWG18 wires) and need to be connected to the CAN bus communication line using a two-pole twisted cable or a two-pole with shield cable (shield connected to ground in one point only). AWG24 wires should be enough.

CAUTION: Do not route this line in parallel with transmitting antennas or other sources of known RF interference. Do not route this line in parallel with microphone cables or audio cables to avoid audible noise in headphones.

Flybox

Wiring of the remote disengage button

3) (RECOMMENDED): connect it between ground and pin#7 of the Oblò connector. The type of the button must be NORMALLY OPEN (NO).

CAUTION:

- Care should be taken to avoid that the wiring is subjected to chafing or excessive flexing.

- Avoid if possible junctions, that with excessive vibration may be subjected to fail or short-circuit.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

CONNECTIONS DETAIL FOR ACU CON4P CONNECTOR

CONNECTIONS DETAIL FOR ACU CON8P CONNECTOR

Socket view (from wire’s insertion side)

Pin# Descriprion

1 CAN bus communication line: CAN-H signal 2 +12V main supply 3 CAN bus communication line: CAN-L signal 4 GND main supply

Oblò-A/P installation

Electrical installation

Socket view (from wire’s insertion side)

Pin# Descriprion

1 GND for Pitch Servo 2 Not used 3 GND for Roll Servo 4 Not used 5 +12V for Pitch Servo 6 Not used 7 +12V for Roll Servo 8 Not used

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Oblò-A/P installation

CONNECTIONS DETAIL FOR FX75 SERVO CONNECTOR

Electrical installation

Socket view (from wire’s insertion side)

Pin# Descriprion

1 +12V power supply 2 Not used 3 Not used 4 CAN bus communication line: CAN-L signal 5 CAN bus termination 6 GND power supply 7 Not used 8 Not used 9 CAN bus communication line: CAN-H signal

10 CAN bus termination

Flybox

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Electrical connections for autopilot system

Oblò-A/P installation

Electrical installation

*NOTE: If you use the ready-to-use wiring (ord. cod. 802010), the 120 ohm resistor between pin#3 and pin#4 is already fitted inside the connector housing of the wiring.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Oblò-A/P installation

Electrical installation

NOTE: The CAN bus termination (pin#5 connected with pin#10) must be done only on the last servo of the CAN bus line. If you install only one servo, the CAN line must be terminated on that servo.

Flybox

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Oblò-REP installation

Mechanical installation

SECTION 3

3.1 OBLÒ-REP (REPEATER) INSTALLATION

Dimensions & mechanical installation of Oblò-REP are the same of standard Oblò (see chap.1.1)

Electrical installation is different and depends if the Oblò-REP is connected to a standard Oblò or if it is connected to a Oblò-A/P with autopilot control unit and servos. See next pages for the appropriate wiring diagrams.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Oblò-REP installation

Electrical installation

3.1.1 ELECTRICAL INSTALLATION OBLÒ-REP CONNECTED TO A STANDARD OBLÒ

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

3.1.2 ELECTRICAL INSTALLATION OBLÒ-REP CONNECTED TO A OBLÒ-A/P WITH AUTOPILOT

NOTE: The Oblò-REP share the same CAN bus line of

the autopilot system. It can be connected at any point of the CAN bus line but the length of the wiring that connects the Oblò-REP must be maximum 1 meter.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

USE

SECTION

Flybox

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Main menu configuration

Instrument configuration

SECTION 4

4.1 MAIN MENU CONFIGURATION

Before using your Oblò you need to configure it; read completely this chapter and follow step by step the sections to fully configure it according to your preferences.

Navigation through the menu is very simple and quick and is performed with the knob:

- Press the knob for 1 second to enter in the functions menu. The menu automatically disappears if you don't press or rotate the knob for 5 seconds.

- Rotate the knob to navigate through the menu items.

- Press the knob to enter in the selected item.

- The first item on every menu (“Exit” or “Back”) is used to exit the current menu and go back to the previous.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Instrument configuration

Main menu configuration

•

EXIT: exit the menu and returns to the main screen.

ZERO PITCH: use this function only in

•

flight because it reset the pitch to the actual attitude. Use only when the aircraft is in leveled flight and at constant speed, never use it to reset the horizon during other flight attitude.

TRK or HDG: switch between Heading/Tracking compass indications. (Tracking available only if an external GPS is connected).

LIGHT: display brightness adjustment (1=min. brightness, 19=max. brightness). Default value=19.

SETUP: enter in the setup menu.

G-METER RESET: Show/reset g-meter. Turning the knob to

highlight this item will display the maximum and minimum peaks of vertical acceleration. Press the knob if you want to reset the two peaks.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

4.2 SETUP MENU CONFIGURATION:

EXIT: exit the menu and returns to the main screen.

T.R.I.: (Turn rate indicator) Click the knob to enter the

turn rate indicator configuration.

Instrument configuration

Setup menu configuration

The available settings are:

- Scale: set the full scale, in degrees/seconds. Default

value=6°/s.

- Filter: filter setting. A low value means that the

readings will be more fast and unfiltered (but subject to fluctuations), an high value means that the readings will be more slow and stable. Default value=80.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Instrument configuration

Setup menu configuration

BALL: (Slip indicator) Click the knob to enter the slip indicator configuration.

The available settings are:

- Scale: set the full scale, in milliG. Default

value=300mG.

- Filter: filter setting. A low value means that the

readings will be more fast and unfiltered (but subject to fluctuations), an high value means that the readings will be more slow and stable. Default value=80.

ROLL: Click the knob to enter the roll scale configuration.

The available settings are:

- Arc mode: Set the roll indicator mode: set to 1 to

choose a stationary roll scale (while the arrow moves to stay perpendicular to the horizon). Set to 2 to choose to rotate the scale while the arrow stay fixed at the center. Default value=1.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

- Adjust:

adjustment of the roll to compensate misalignments due to installation. On the ground, with wings of the plane perfectly leveled, rotate slowly the knob until the number at the bottom become zero, then press it to store this value. Turn off and on the instrument after storing a new inclination value. Default value=0°

PITCH: Click the knob to enter the pitch axis configuration.

The available setting is:

- Adjust: adjustment of the pitch to compensate the

inclination of the instruments panel regards the longitudinal axis of the aircraft. This function must be executed only once after installation, on the ground, in leveled attitude. Read the number printed on the bottom of the display and copy the same value on this parameter by clicking the knob and rotating it. For example if the number printed on the bottom is -3.6° rotate the knob to the left to set exactly -3.6°. If the number printed on the bottom is +1.2° rotate the knob to the right to set exactly +1.2°. Click the knob to store the value and turn off and on again the instrument. Default value=0°.

Instrument configuration

Setup menu configuration

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Instrument configuration

Setup menu configuration

ASI: Click the knob to enter the airspeed indictor configuration.

The available settings are:

- Vne-Vno-Vfe-Vs-Vs0: Set the speed setpoint for the moving tape airspeed indicator. Default value=0 Km/h.

NOTE: Before setting these thresholds you must choose the unit of measure (see next parameter).

Vne

Vno

Vfe

Vs0

(Velocity Never Exceed)

(Velocity Normal Operation), maximum structural cruising speed.

(Velocity with Flaps Extended), maximum airspeed at which you may extend the flaps, or fly with them extended.

(Velocity of Stall), power off stalling speed with the gear and flaps retracted.

(Velocity Stall 0), power off stalling speed with gear and full flaps extended.

If you prefer the clean transition from white to green zone set the same value on Vs and Vfe.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Instrument configuration

Setup menu configuration

- Unit: Set the unit of measure for the airspeed indicator

in kilometers per hour (Km/h), miles per hour (Mph) or knots (Kts). Default value=Km/h.

- Filter: filter setting. A low value means that the readings

will be more fast and unfiltered (but subject to fluctuations), an high value means that the readings will be more slow and stable. Default value=90.

ALT/VSI: Click the knob to enter the altimeter and vertical speed indicator configuration.

The available settings are:

- Oxygen: Set the max altitude above which the altitude

tape turns red to indicate the hazardous condition.

Default value=12000 Ft.

- Alt unit: Set the unit of measure for the altimeter in

meters (Mt) or feets (Ft). Default value=Ft.

- Baro unit: Set the unit of measure for pressure

reference in hectoPascal (hPa) or inches of mercury (inHg).

- Alt Filter: altimeter filter setting. A low value means

that the readings will be more fast and unfiltered (but subject to fluctuations), an high value means that the readings will be more slow and stable. Default value=90.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Instrument configuration

Setup menu configuration

- Vsi Filter: vertical speed indicator filter setting. A low

value means that the readings will be more fast and unfiltered (but subject to fluctuations), an high value means that the readings will be more slow and stable. Default value=95.

AUTOPILOT:(Only for autopilot enabled Oblò) see 6.2

G-METER: Click the knob to enter the g-meter indicator

configuration.

The available settings are:

- Filter: filter setting. A low value means that the

readings will be more fast and unfiltered (but subject to fluctuations), an high value means that the readings will be more slow and stable. Default value=50.

- Refresh:

with this parameter you can choose the display update rate between 1 (1 display refresh per second) and 3 0 (30 display refresh per second). Default value=2.

- Max: Show the maximum peak reached by the g-meter.

- Min: Show the minimum peak reached by the g-meter.

- Reset min/max: Click the knob after selecting this item

to reset the maximum and minimum peaks of the g-meter.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

GPS: Click the knob to enter the external GPS configuration (if connected). The available settings are:

- Baud: Set the baud rate of the external GPS.

Default value=4800 bps.

- Utc: To check if the GPS is properly connected and the

baud rate is correct verify that this indication provides the UTC time. If it shows –:-- it means that the GPS is not connected or setup correctly.

- Satellites: To check if the reception is good (and

therefore also to know if you have choosen a good location where to install the GPS) read the number of satellites indicated: the higher the number, the better the reception. For a good reception at least 4 satellites should be indicated.

Instrument configuration

Setup menu configuration

CAUTION: In case of communication problems between GPS and Oblò check the following settings on the external GPS:

- Baud rate/communication speed: must be set to the

same value as that set in the Oblò.

- Data protocol: must be set to NMEA.

- Enabled messages: must be enabled on the GPS the $GPRMC e $GPGGA messages (standard messages that every GPS should transmit). If you want to use the HSI page or if you have installed the autopilot system and you want to use the “navigation to a waypoint” function, it must be enabled also the $GPRMB message.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Instrument configuration

XTE window

Setup menu configuration

HSI: Click the knob to enter the HSI (Horizontal Situation Indicator) configuration menu.

The available settings are:

- XTE win.: Set the window amplitude of the cross track

error indicators (the XTE window is measured from the two external dots). Default=1.0 Km.

- Unit: Set the unit of measure for the indications on the

HSI page. Choose between kilometers (KM), Nautical miles (NM) or Miles (MI). Default=KM.

COMPASS: Click the knob to enter the compass configuration. The available settings are:

- Auto H/T: YES/NO. Set to “YES” to enable tha automatic

switch between heading and tracking. In this mode if the actual speed is below the speed set in the next parameter the compass is set to heading; when the actual speed is higher the compass is set to GPS tracking. This feature is useful to automatically switch from magnetic heading when you are in ground to GPS tracking, with wind correction, when you are in flight. Default value=YES.

- Speed: Set the speed for the automatic switch between

heading and tracking (see previous item). Default value=60 Km/h.

- Calibration: Magnetic calibration. See next chapter.

- Mag.Dec.: Displays the magnetic declination of the actual

place (the indication appear only with the GPS connected).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

ADI: Click the knob to enter the attitude director indicator setup. The available settings are:

- Mode: 1 / 2 / 3. There are three different display mode

of the indicator:

MODE 1 MODE 2 MODE 3

CONFIG: Click the knob to enter the configurations

menu. The available configurations are:

- Start page: Set the start page (on instrument turn-on). Choose between the attitude indicator page (HOR), the HSI page (HSI) or the drum altimeter page (ALT). Default=HOR.

- Return delay: Set the auto return to the start page after the time, in seconds, set here. Set to zero to disable the auto return. Default=0.

Instrument configuration

Setup menu configuration

- Knob: Set the operating mode of the knob. Rotate the knob to select the submenu called “Menu DN” and click to enter. The available settings are:

- CCW: select this mode to set that by turning the knob counter-clockwise you move down in the menus.

- CW: select this mode to set that by turning the knob clockwise you move down in the menus.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Instrument configuration

Setup menu configuration

ABOUT: On this screen it’s possible to read current software versions, useful to check if your Oblò is updated to the latest version. The version number to check is in the first row, indicated after the word “CORE”. Check frequently our web site www.flyboxavionics.it to see if there are any software updates.

NOTE: this manual is referred to the software version indicated on the first page.

FW UPGRADE: Menu for USB software upgrade. If you want to upgrade to a newer version, (see previous item to check the actual software version) after selecting this item keep pressed the knob for 2 seconds until the following screen appears:

- Insert the USB flash drive on which you copied the updated software and select if you want to upgrade the Oblò (by selecting ”CORE”) or if you want to upgrade the roll or pitch servo (by selecting “RSU” or “PSU”). To upgrade all select “Upgrade All”. If you have the Oblò standard without autopilot, you can only upgrade the instrument itself by selecting the “CORE” item.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Instrument configuration

4.3 MAGNETIC CALIBRATION

Oblò integrates the magnetic sensors for the heading indication. The sensors are affected by all magnetic fields present around them, which, if ignored, can lead to considerable errors in the heading indication. Magnetic fields are generated for example by ferro magnetic materials (iron, ferrites), large electric current in cables, electric motors; if possible it's recommended to avoid installation of the instrument near these source of magnetic fields.It's possible to compensate for weak static magnetic fields by performing the calibration as explained below. Please note that in particular cases (presence of strong magnetic fields) may be insufficient to perform this calibration; in this case the heading provide incorrect or approximate indications and it's necessary to install an external remote magnetometer (in development).

CAUTION: Before using Oblò in flight it's necessary to perform the magnetic calibration to obtain a correct indication of the heading.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Instrument configuration

Magnetic calibration

The calibration must be performed after the installation is complete, by following this steps:

Turn on the engine and go in a place far from

possible magnetic fields (metallic shed, concrete floors with metal armatures, etc..) and where is possible to execute more turn with the aircraft (on the ground).

Turn on all the electric load usually used in flight.

On the Oblò enter in the Setup-->Compass and

select the “Calibration” item. Keep pressed the knob for 3 seconds to enter in the calibration.

Flybox

Now the display show “PUSH TO START

CALIBRATION”: briefly press the knob to start calibration (if you want to cancel and return to the previous menu keep pressed the knob for 3 seconds).

Wait the indication “MAKE A 420 DEGREE

CLOCKWISE CIRCLE SLOWLY” on the display then start, with the aircraft on ground, a continuous slow circular movement toward right.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

In the center of the display appear a number that

Instrument configuration

Magnetic calibration

indicate the rotation degrees, that starting from zero increase during the rotation of the aircraft. Continue the slow circular movement: the calibration end automatically when the number reach a value of 420 and the indication “CALIBRATION DONE PUSH TO EXIT” appear on the display.

Now you can press the knob to terminate the calibration.

IMPORTANT: To complete the 420 degrees turn

required for the calibration you must take from 1 to 2 minutes.

After completing the calibration perform this check: with

the Oblò displaying the heading turn the aircraft exactly at North, South, West and East verifying the correct indication on display. If external GPS is connected you will automatically obtain the magnetic declination correction.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Using the Oblò

SECTION 5

5.1 USING THE OBLO’

The Oblò is organized in 3 different pages:

• Attitude indicator page

• HSI (Horizontal Situation Indicator) page

• Drum altimeter page

By default, after power-on the Oblò shows the attitude indicator page, but you can set your preferred start page

by going in the Setup menu → Config → Start page.

To switch between the pages you need to “fast rotate” the knob: fast rotate the knob clockwise to switch from attitude indicator page to HSI page and from HSI page to drum altimeter page; fast rotate the knob counterclockwise to go back in reverse order. The “fast rotate” of the knob is thought to avoid involuntary page change.

You can also set a time to automatically return to the start page after you have switched to another page (See

Setup menu → Config → Return delay).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

5.1.1 ATTITUDE INDICATOR PAGE:

SLIP INDICATOR

TURN RATE

AIRSPEED

G-METER

COMPASS

ATTITUDE

INDICATOR

ALTIMETER

PRESSURE

REFERENCE

VERTICAL SPEED

INDICATOR

COMPASS: Placed in the lower part of the screen, the

heading/tracking indication is represented with the numerical indication at the center of the graphics. The four cardinal points are shown as N , S , W , E.

- It can show the HEADING (magnetic compass, indicated with “HDG”) or the TRACKING (Track of the GPS, indicated with “TRK”, available only if an external GPS is connected).

- Note that after power-on the compass is set to heading and can automatically switch to tracking above a certain speed if you enable the “Auto H/T” function in the compass setup menu (see chap.4.2).

- It's however possible to manually switch between the two indications: keep pressed the knob for 1 second and in the menu that appear choose “HDG” or “TRK”.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Using the Oblò

Attitude indicator page

• The HEADING is valid either stationary or moving and during aircraft turns the indicator is fluid and continuous. It compensate for aircraft attitude so that the indication is valid also with pitch or roll inclination. If external GPS is connected you will automatically obtain the magnetic declination correction.

• The TRACKING is read from external GPS receiver and is usually updated once per second, so in case of fast turns it may not have a continuous and fluid indication. Provided that GPS receiver have a good satellites reception, the tracking indication is very accurate and compensated from wind.

NOTE: The GPS tracking is not valid when stationary or for speed below 20 km/h.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

TURN RATE: Graphical indications of the turn rate. To set the full scale go in the Setup menu-->T.R.I.-->Scale (see chap.4.2).

AIR SPEED: The Air speed is represented with both tape and numeric indicator. The unit of measure can be km/h, Mp/h or knots. The range of measure is from 30 to 650 km/h (16~350 knots or 18~403 mph). Below air speed of 30 km/h the indication remain fixed to zero.

To set the unit of measure and the speed thresold that define the coloured zone go in the Setup menu-->ASI (see chap.4.2).

ATTITUDE INDICATOR: With 360° continuous operation in both pitch and roll. Above and below the horizon line, major pitch marks are shown for every 10°, up to +/- 40°. Minor pitch marks are shown for every 5°.

Using the Oblò

Attitude indicator page

The roll scale show inclinations from -60 to +60°; mark lines are shown for the following inclination:

0° - 10° - 20° - 30° - 45° - 60°.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

-60°

-45°

-30°

-20°

-10°

10°

20°

30°

45°

60°

Using the Oblò

Attitude indicator page

Horizon zero

Flybox

Roll scale zero

The colors used for the attitude indicator are brown for the ground and sky blue for the sky. The zero is represented by the yellow line.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

IMPORTANT NOTES ON USING ATTITUDE INDICATOR:

The attitude indicator may loose accuracy during the flight for the following causes:

Using the Oblò

Attitude indicator page

- During uncoordinated, accentuated or acrobatics

maneuvers.

- Rapid temperature changes or temperature outside

the operating limit (-20°C~+70°C).

• Never use the attitude indicator as a reference for flight manoeuvres.

• Never use the attitude indicator as a reference in absence of visibility.

NOTE: This instrument is not certified.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Using the Oblò

Attitude indicator page

SLIP INDICATOR: It's a graphic indication of the lateral accelerations.

ALTIMETER: It include both a tape indicator and a numeric indicator. The unit of measure can be feets or meters, the range of measure is -1000~25000 feets (-300~ +7600 m). On the tape indicator the thousands digits are shown every 500 (i.e. 1500,2000, etc..) while the numeric indications is always displayed completely.

- To change the PRESSURE REFERENCE click the

knob and then rotate it to change the numerical value; click again to store the new reference.

VERTICAL SPEED INDICATOR: Displays the numerical indication (absolute value). The unit of measure is meters per second if altimeter is set in meters or feet per minute if the altimeter is set in feet. The arrow pointing up indicate an ascent (positive value), the arrow pointing down indicate a descent (negative value).

G-METER: Indicate the vertical acceleration in g; it display also an upward arrow during positive accelerations or a downward arrow during negative accelerations.

The g-meter has a memory for storing the maximum and minimum acceleration peaks: to see them entern in the function menu by pressing the knob for 1 second and then select the item “G-meter reset”.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

CAUTION: If the instrument's internal temperature exceeds the maximum allowed (70°C) it appears to display the message “SENSOR TEMPERATURE OUT OF HIGH LIMIT”. High temperatures can be reached for example if the aircraft is parked in the sun without any instruments panel protection. In this case to decrease the temperature it's sufficient to ventilate the instruments panel.

If the temperature exceeds the minimum allowed (-20°C) it appears to display the message “SENSOR TEMPERATURE OUT OF LOW LIMIT”. In both cases the data provided by the instrument may be not reliable.

It's possible to check the instrument's internal temperature on the “About” menu (“Int. Temp” item).

Using the Oblò

Attitude indicator page

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

5.1.2 HSI PAGE:

ACTUAL HEADING

OR TRACKING

Flybox

COMPASS BUG

COURSE

POINTER

DESTINATION WAYPOINT ID

GROUND SPEED

COURSE

DISTANCE TO GO

CROSS TRACK

ERROR

The HSI (Horizontal Situation Indicator) page reduces pilot workload by providing heading/tracking, course reference, course deviation and other navigation aid. In order to work, the HSI page needs that the Oblò is connected to an external GPS navigation system, in which a flight plane, route or GOTO has been set.

The available indications are the followings:

● ACTUAL HEADING OR TRACKING: It can shows the HEADING (magnetic compass, indicated with “HDG”) or the TRACKING (Track of the GPS, indicated with “TRK”). Note that after power-on the compass is set to heading and can automatically switch to tracking above a certain speed if you enable the “Auto H/T” function in the compass setup menu (see chap.4.2).

COURSE DEVIATION INDICATOR

TIME TO GO

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Using the Oblò

HSI page

During the flight is possible to manually switch between the heading or the tracking: keep pressed the knob for 1 second and in the menu that appear choose “HDG” or “TRK”.

● COMPASS BUG: The compass bug can be freely moved by the pilot by clicking the knob and rotating to select a new heading/tracking. If it’s installed the optional autopilot system and you start a navigation on it, the bug will be coupled to the autopilot.

● COURSE POINTER: This pointer indicates the currently selected course (it is automatically programmed by the GPS route).

● COURSE DEVIATION INDICATOR: The CDI indicates how far to the left or right you are from the selected course. A series of "dots" provides a linear indication of how far the aircraft is "off course". To set the full scale of the dots, go in

the setup menu → HSI → XTE win parameter.

● DESTINATION WAYPOINT ID: It shows the name of the destination waypoint, if transmitted by the GPS navigator. If no information is received this field is left blank.

● DISTANCE TO GO: It shows the distance from your aircraft’s position to the next waypoint (in kilometers (KM), Nautical miles (NM) or Miles (MI), depending on what you have set on the HSI setup menu).

● TIME TO GO: It shows the time needed to reach the next waypoint.

● GROUND SPEED: It shows the ground speed (this data is received from the GPS).

● COURSE: It shows the course to mantain to reach the waypoint.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

● CROSS TRACK ERROR: It shows the numerical indication of the deviation from the selected course (in kilometers (KM), Nautical miles (NM) or Miles (MI), depending on what you have set on the HSI setup menu).

5.1.3 DRUM ALTIMETER PAGE:

PRESSURE

REFERENCE

(hPa)

PRESSURE

REFERENCE

(InHg)

This page simulates the graphic of a traditional drum altimeter.

To change the PRESSURE REFERENCE click the knob and then rotate it to change the numerical value; click again to store the new reference. The settable pressure reference is the one corresponding to the unit of measure setted on the

Setup menu → ALT/VSI → Baro unit.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot system

SECTION 6

6.1 AUTOPILOT SYSTEM

REQUIREMENTS:

The following components are required for the autopilot to function:

- Flybox® Oblò-A/P instrument or Oblò with autopilot function enabled (see chap.7.6).

NOTE: Upgrade your Oblò to the latest version before

using the autopilot function (check web site

http://www.flyboxavionics.it/en/software-updates.html)

- Autopilot Control Unit (Flybox® ACU).

- 1 Flybox® FX75 digital servo for roll control.

- 1 Flybox® FX75 digital servo for pitch control.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot system

Autopilot overview

AUTOPILOT OVERVIEW:

The autopilot system can use 1 or 2 servos, that need to be connected to the control stick for roll and pitch control.

The available functions are:

Horizontal navigation (roll axis control):

- Magnetic heading hold.

- GPS tracking hold.

- Track to a waypoint (GOTO function, require an external GPS with NMEA messages $GPRMC $GPRMB $GPGGA).

- Track a flight plane (require an external GPS with NMEA messages $GPRMC $GPRMB $GPGGA).

Automatic course reversal (180°).

Vertical navigation (pitch axis control):

- Altitude hold.

- Altitude change.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

HDG/TRK knob for

heading/tracking

setting

Autopilot system

Autopilot overview

ON/OFF

switch

ON led indicator

“HDG/TRK” button with led

(led on when autopilot is

engaged in HDG/TRK mode)

“NAV” button with led

(led on when autopilot is

engaged in NAV mode)

ALT knob for

altitude setting

“ALT” button with led

(led on when autopilot is

engaged in ALT mode)

- Use the ON/OFF switch to turn on and off the autopilot control unit.

- Press the “HDG/TRK” button to engage/disengage the autopilot in heading or GPS tracking mode.

- Rotate the “HDG/TRK” knob to adjust the heading/tracking bug. Press the knob to center the bug to the actual heading or GPS tracking.

- Press the “ALT” button to engage/disengage the autopilot in altitude hold mode.

- Rotate the “ALT” knob to adjust the altimeter bug. Press the knob to center the bug to the actual altitude.

- Press the “NAV” button to engage/disengage the autopilot in flight plane or goto navigation.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot system

Autopilot overview

REMOTE DISENGAGE BUTTON:

It's recommended to install also the remote disengage button, that operate in this way:

- With autopilot engaged: push shortly to disengage.

- With autopilot disengaged: push for 2 seconds to engage it. This function must be enabled from menu:

Setup → Autopilot → Remote button → HtoE enable

(see chap.6.3.4).

- With autopilot engaged: keep pressed for more than 2 seconds to activate the Control Wheel Steering (CWS) mode: it's possible to fly the aircraft to a new heading/traking or altitude and then release the button to let the autopilot acquire and mantain the new values. This function must be enabled from menu:

Setup → Autopilot → Remote button → CWS enable

(see chap.6.3.4).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

6.2 AUTOPILOT SYSTEM CONFIGURATION

After the physical installation of the autopilot system it's required to check the connections and configure the parameters, as explained in the following two chapters.

The operations that you will perform in sequence are the following:

Ground based test and configuration:

- Servos calibration (chap.6.2.1)

- Communications check (chap.6.2.2)

- Remote button operation check (chap.6.2.3)

- Servos torque check (chap.6.2.4)

- “Min speed” and “Max speed” parameters setting (chap.6.3.1)

- Roll servo setup (chap.6.3.2)

- Pitch servo setup (chap.6.3.3)

- Remote button setup (chap.6.3.4)

Flight based test and configuration:

- Autopilot setup – roll axis (chap.6.4.1)

- Autopilot setup – pitch axis (chap.6.4.2)

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.2.1 SERVO/S CALIBRATION

Autopilot configuration

The servo/s calibrations is GROUND BASED.

The calibration procedure is mandatory: if you try to engage the autopilot without first calibrate the servo, the Oblò will show the error message “AUTOPILOT DISENGAGE! ROLL/PITCH SERVO CALIB”.

THE CALIBRATION MUST ALSO BE REPEATED IN THE EVENT OF ANY CHANGES TO MECHANICAL INSTALLATION OF THE SERVO/S.

NOTE: The “neutral position” terms used in the following explanation means the center of the servo arm travel relative to the position of the limiting bracket:

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

To begin the calibration procedure:

- Press for 1 second the knob to enter in the function menu.

- Rotate the knob to select the “Setup” menu and click to enter.

- Rotate the knob to select the “Autopilot” menu and click to enter.

- Rotate the knob to select the “Servo(s) calib”.

- Press the knob for 3 seconds until the display shows the word “IDENTIFICATION”. If instead it was already made a previous calibration, the display shows the data of the previous calibration as in example below:

Autopilot configuration

Servo/s calibration

NOTE: If appears the message “NO SERVO(S) FOUND” it means that the servos are not properly connected.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Servo/s calibration

- Press the knob to start the calibration and follow the onscreen instructions; for example if you have installed the servos on both roll and pitch axis the complete procedure will be as follows:

● Step#1: center the control stick in neutral position and then click the knob to go to the next step.

● Step#2: position the control stick to the left limit (without forcing), paying attention to not move it in the pitch axis during the motion. After doing so, the calibration automatically switch to the next step:

● Step#3: center the control stick in neutral position and then click the knob to go to the next step.

● Step#4: position the control stick to the forward limit (without forcing), paying attention to not move it in the roll axis during the motion. After doing so, the calibration automatically switch to the next step or, if you have not installed the pitch servo, click the knob to go to the next step.

● Step#5: center the control stick in neutral position and then click the knob to go to the next step.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

● Step#6: position the control stick to the left limit (without forcing). Click the knob or the remote button to store the position and go to the next step.

● Step#7: position the control stick to the right limit (without forcing). Click the knob or the remote button to store the position and go to the next step.

NOTE: If appears the message “BAD MECHANICAL INSTALLATION! NOT ENOUGH SERVO TRAVEL” it means that the servo is not correctly installed, as the travel of the servo arm is too small to function properly. In this case you should modify the mechanical installation, for example by using an outer hole of the servo arm.

Autopilot configuration

Servo/s calibration

● Step#8: position the control stick to the forward limit (without forcing). Click the knob or the remote button to store the position and go to the next step.

● Step#9: position the control stick to the backward limit (without forcing). Click the knob or the remote button to store the position and end the calibration.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Servo/s calibration

At the end of the calibration procedure the display briefly shows the confirmation message “Servo Calib Done”. To exit the calibration menu keep pressed the knob for 3 seconds.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

SERVO/S CALIBRATION CHECK

WARNING: Once finished the calibration you must execute this check (ground based):

- With the Oblò and ACU control unit turned on, insert the autopilot on roll axis by pressing the “ H D G / T R K ” button on the ACU. Rotate clockwise the HDG/TRK knob (so that the heading bug is at the right of the actual heading) and check that the flight control move as to turn the aircraft right. Rotate counter clockwise the HDG/TRK knob (so that the heading bug is at the left of the actual heading) and check that the flight control move as to turn the aircraft left. Check also that the servo pitch does not move.

Autopilot configuration

Servo/s calibration

- Engage the autopilot on pitch axis by pressing the “ALT” button on the ACU. Using the ALT knob set the altitude bug to a higher value than the actual altitude and check that the flight control move as to increase the aircraft altitude; set the altitude bug to a lower value than the actual altitude and check that the flight control move as to decrease the aircraft altitude.

If movement direction of one or both servos is reversed it means that the calibration is wrong, so NEVER ENGAGE THE AUTOPILOT IN FLIGHT but repeat the servos calibration procedure and check again.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.2.2 COMMUNICATIONS CHECK

Autopilot configuration

This check must be performed GROUND BASED.

- Turn on Oblò instrument only.

- Turn on ACU control unit and check that appear “AP:OFF” in the top left corner of the display. If no message appear means that there is a communication problem between Oblò and ACU control unit: check again the electrical wirings.

- Press the “HDG/TRK” button on the ACU panel and verify that the message “AP:OFF” become “AP:HDG”. If the message remains “AP:OFF” it means that there is a communication problem between ACU control unit and servo/s: check again the electrical wirings.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

6.2.3 REMOTE BUTTON OPERATION CHECK

This check must be performed GROUND BASED.

- Engage the autopilot by pressing the “HDG/TRK” button on the ACU (check the message “AP:HDG” on the Oblò display).

- Press the remote disengage button and check that the message “AP:HDG” become “AP:OFF”. If the message remains “AP:HDG” it means that there is a problem with the remote button: check the electrical wiring and the correct functionality of the button itself.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.2.4 SERVO TORQUE CHECK

Autopilot configuration

This check must be performed GROUND BASED.

- Engage the autopilot by pressing the “HDG/TRK” button on the ACU (check the message “AP:HDG” on the Oblò display).

- Force the control stick to the left or right limit, so that you override the servo force and after 1 seconds the autopilot disengages automatically (check the message “AP:OFF” on display).

- Engage the autopilot by pressing the “ALT” button on the ACU (check the message “AP:ALT” on the Oblò display).

- Force the control stick to the forward or backward limit, so that you override the servo force and after 1 seconds the autopilot disengages automatically (check the message “AP:OFF” on display).

At this stage you should check also the override force: it must be strong enough to give a fairly good control authority to the servos, but not so strong as to be difficult to override with the control stick. See chap.6.3.2 for roll servo torque setup and chap.6.3.3 for pitch servo torque setup.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.3 AUTOPILOT SETUP MENU

The parameters configuration is performed on the Oblò instrument.

During the configuration it's required to turn on also the ACU control unit but without engaging the autopilot (so on the ACU control unit turn on the ON/OFF switch and don't press any other button).

All the configurable parameters are on the Oblò menu, accessible in this way:

- Press for 1 second the knob to enter in the function menu.

Autopilot configuration

- Rotate the knob to select the “Setup” menu and click to enter.

- Rotate the knob to select the “Autopilot” menu and click to enter.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Autopilot setup menù

6.3.1 “MINSPD” AND “MAXSPD” PARAMETERS SETTING

This settings must be performed GROUND BASED.

The autopilot system measures the airspeed and allows the pilot to set the minimum and maximum operating speed to ensure that the aircraft is in safe conditions when the autopilot is engaged.

MIN SPD: Select the minimum airspeed at which the autopilot will fly the aircraft. The unit of measure is the

same set for the ASI (see Setup menu → ASI → Unit).

The autopilot cannot be engaged at airspeed below Min Spd, with the exception of 0 to allow ground testing. With autopilot engaged, if the airspeed drops below the minimum, it enters to an airspeed hold mode, to restore and maintain approximately the minimum airspeed.

Set Min Spd to be at least 20% above the Vfe of your aircraft. The Vfe speed must be set in the Oblò according to the specifications of your aircraft (to set the

Vfe, see Setup menu → ASI → Vfe).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

MAX SPD: Select the maximum airspeed at which the autopilot will fly the aircraft. The unit of measure is the

same set for the ASI (see Setup menu → ASI → Unit).

With autopilot engaged, if the airspeed rises above the maximum, it enters to an airspeed hold mode, to restore and maintain approximately the maximum airspeed.

The choice of the Max Spd value must be made according to the characteristics of your aircraft, it should be below the Vne speed of your aircraft but above the normal cruise speed. The Vne speed must be set in the Oblò according to the specifications of your aircraft (to

set the Vfe, see Setup menu → ASI → Vne).

Max Spd parameter cannot be set to a value above 95% of Vne, so you should first check the correctness of the ASI speed settings.

Autopilot configuration

Autopilot setup menù

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.3.2 ROLL SERVO SETUP

Autopilot configuration

Autopilot setup menù

This settings must be performed GROUND BASED.

This settings can be performed inside the “ROLL SERVO” menu, that can be reached in this way:

- Press for 1 second the knob to enter in the function menu.

- Rotate the knob to select the “Setup” menu and click to enter.

- Rotate the knob to select the “Autopilot” menu and click to enter.

- Rotate the knob to select the “Roll servo” menu and click to enter.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

“GAIN” PARAMETER CHECK

This check must be performed GROUND BASED.

GAIN: This parameter specify how fast or slow the autopilot responds to deviations between commanded and actual heading/tracking. For now check only that the parameter is at the default value (10), because it will be set in flight as explained later in chap.6.4.1. The min-max range is: 1~40.

“TORQUE” PARAMETER SETTING

This settings must be performed GROUND BASED.

TORQUE: Set the desired torque, that is the force of the servo when engaged.

Autopilot configuration

Autopilot setup menù

To set a correct value, keep in mind that the torque must be strong enough to give a fairly good control authority to the servos, but not so strong as to be difficult to override with the control stick.

To test the torque after setting a new value, perform the “Servo torque check” as explained in chap.6.2.4.

The min-max range is: 1~40, when the autopilot system detects for the first time that the servo is set as a roll servo, it set the default value to 10.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Autopilot setup menù

“TURN RATE” PARAMETER SETTING

This settings must be performed GROUND BASED.

TURN RATE: Select your desired target rate of turn when autopilot is engaged. The unit of measure is degrees per second and the range min-max is from

0.5°/s to 3.0°/s. When selecting your desired turn rate consider that the autopilot may slightly exceed the turn rate target during regulation.

“MAX BANK” PARAMETER SETTING

This settings must be performed GROUND BASED.

MAX BANK: This parameter specifies a maximum bank angle which the autopilot will not exceed during turns. Set an appropriate bank limit, the min-max range is: 5~30 degrees.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.3.3 PITCH SERVO SETUP

This settings must be performed GROUND BASED.

This settings can be performed inside the “PITCH SERVO” menu, that can be reached in this way:

- Press for 1 second the knob to enter in the function menu.

- Rotate the knob to select the “Setup” menu and click to enter.

- Rotate the knob to select the “Autopilot” menu and click to enter.

- Rotate the knob to select the “Pitch servo” menu and click to enter.

Autopilot configuration

Autopilot setup menù

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Autopilot setup menù

“GAIN” PARAMETER CHECK

This check must be performed GROUND BASED.

GAIN: This parameter specify how fast or slow the autopilot responds to deviations between commanded and actual altitude. For the moment check only that the parameter is at the default value (13), because it will be set in flight as explained later. The min-max range is: 1~40.

“TORQUE” PARAMETER SETTING

This settings must be performed GROUND BASED.

TORQUE: Set the desired torque, that is the force of the servo when engaged.

To test the torque after setting a new value, perform the “Servo torque check” as explained in chap.6.2.4.

The min-max range is: 1~40, when the autopilot system detects for the first time that the servo is set as a pitch servo, it set the default value to 20.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

“CLIMB” PARAMETER SETTING

This setting must be performed GROUND BASED.

CLIMB: This parameter sets the average vertical speed for autopilot-commanded climbs.The unit of measure is meters/second or feet/minute, depending on what you have choosen for the altimeter. The range min-max is: 50~2000 feet/minute (0.1~10 meters/second). When selecting your desired climb rate consider that the autopilot may slightly exceed from target value during regulation. (Default value = 500).

“DESCENT” PARAMETER SETTING

This setting must be performed GROUND BASED.

Autopilot configuration

Autopilot setup menù

DESCENT: This parameter sets the average vertical speed for autopilot-commanded descents.The unit of measure is meters/second or feet/minute, depending on what you have choosen for the altimeter. The range min-max is: 50~2000 feet/minute (0.1~10 meters/second). When selecting your desired descent rate consider that the autopilot may slightly exceed from target value during regulation. (Default value = 300)

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Autopilot setup menù

“MAX PITCH” PARAMETER SETTING

This setting must be performed GROUND BASED.

MAX PITCH: This parameter specifies a maximum pitch angle which the autopilot will not exceed during climbs or descents. Set an appropriate bank limit, the min-max range is: 5~20 degrees (Default value = 10).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.3.4 REMOTE BUTTON SETUP

The 'Remote Button' setup menu can be reached in this way:

- Press for 1 second the knob to enter in the function menu.

- Rotate the knob to select the “Setup” menu and click to enter.

- Rotate the knob to select the “Autopilot” menu and click to enter.

- Rotate the knob to select the “Remote button” menu and click to enter.

Autopilot configuration

Autopilot setup menù

The settings must be performed GROUND BASED.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Autopilot setup menù

HtoE enable (Hold to engage enable):

Enable (YES) or disable (NO) the function to engage the autopilot when the button is pressed for 2 seconds. The default value is “NO” so the remote button will only serve to disengage the autopilot when already engaged.

HtoE mode (Hold to engage mode):

Select the autopilot engage mode using the remote button (if enabled, see previous parameter). Set to “HDG” to engage the autopilot in horizontal navigation (roll), set to “ALT” to engage the autopilot in vertical navigation (pitch), set to “HDG/ALT” to engage the autopilot in both axes.

CWS enable (Control wheel steering enable):

Enable (YES) or disable (NO) the following auxiliary function of the remote button:

during autopilot control, press and hold for more than 2 seconds the button (on the display will be displayed “AP:CWS”) and fly to a new heading and/or altitude, then release the button to reengage the autopilot.

By default this function is disabled.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

6.4 FLIGHT BASED TEST AND CONFIGURATION

During this phase you calibrate the servo response to match your aircraft flight dynamics. Although flight testing may be carried out in different ways, it's recommended to follow the procedures indicated in the following chapters.

CAUTION: Any test and configuration during flight must be executed in VFR conditions, with good weather and visibility conditions, at an adequate altitude and no traffic or obstacles in the flight path. It's also recommended to have another pilot on board during first flight configuration.

NOTE: In case you need to instantly disengage the autopilot you can use either one of this way:

Autopilot configuration

- Turn off the ON/OFF switch on the ACU control unit.

- Push shortly the remote button.

- Press the “HDG/TRK” button on the ACU, if autopilot is in heading/tracking mode, or press the “NAV” button if autopilot is in navigation mode.

Remember these actions so that it can be carried out instinctively in case of difficulties or emergencies.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Flight based test and configuration

Before starting the first test flight verify once more for safety that all the parameters are correctly set:

- Press for 1 second the knob to enter in the function menu.

- Rotate the knob to select the “Setup” menu and click to enter.

- Rotate the knob to select the “Autopilot” menu and click to enter.

- Rotate the knob to select the “Roll servo” menu and click to enter.

- Verify that the “Gain” parameter is set to default value, that is 10.

- Verify that the “Torque”, “Turn rate” and “Max Bank” parameters are set according to your preferences, as explained in chapter 6.3.2.

- Rotate the knob to select the “Back” item and press it to go back to the autopilot menu.

- Rotate the knob to select the “Pitch servo” menu and click to enter.

- Verify that the “Gain” parameter is set to default value, that is 13.

- Verify that the “Torque”, “Climb”, “Descent” and “Max pitch” parameters are set according to your preferences, as explained in chapter 6.3.3.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Flight based test and configuration

Autopilot configuration

6.4.1 AUTOPILOT SETUP – ROLL AXIS (FLIGHT BASED)

AUTOPILOT ENGAGE AND “GAIN” PARAMETER SET

- Start the flight and when you are in safe condition (read chap.6.4) insert the autopilot by pressing the “HDG/TRK” button on the ACU control unit (the led will turn on as confirmation). Note that the autopilot will only hold the current heading by controlling the roll axis, so the pitch axis must be controlled by the pilot; ensure that you are not affecting the roll axis, so that you can determine the autopilot performance.

If the autopilot behavior is sufficiently stable keep it engaged for some minutes and observe the way in which it mantains the heading/tracking:

- If the autopilot deviates heavily from the heading/tracking set, or make very slow adjustments, you need to increase the value of the “Gain” parameter.

- If the autopilot is too aggressive with excessively fast adjustments, you need to decrease the value of the “Gain” parameter.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Flight based test and configuration

The “Gain” parameter selects the amount of autopilot activity for a given roll angle error (that is the difference between the desired heading/tracking and the actual heading/tracking). With low “Gain” values (minimum=1) the autopilot system is very slow with few corrections, with high “Gain” values (maximum=40) the autopilot is more “aggressive” with a lot of fast corrections. Above a certain upper limit, however, the system becomes unstable and start to oscillate.

To change the “Gain” parameter:

- Press for 1 second the knob to enter in the function menu.

- Rotate the knob to select the “Setup” menu and click to enter.

- Rotate the knob to select the “Autopilot” menu and click to enter.

- Rotate the knob to select the “Roll servo” menu and click to enter.

- Rotate the knob to select the “Gain” parameter and click to enter.

- Rotate the knob to change the value and press it to store the new value.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Flight based test and configuration

HEADING/TRACKING CHANGE

During this phase you observe the autopilot behavior during a turn, further optimizing the “Gain” parameter which as said is what establishes the autopilot response.

- With the autopilot engaged in “HDG/TRK” mode, start an autopilot commanded turn by rotating the HDG/TRK knob on the ACU control unit.

- Repeat again some heading/tracking change, observing the behavior of the autopilot:

• If the autopilot will cause excessive oscillations (fast left/right bank movements) and seems too “aggressive” in the regulation, you need to decrease the “Gain” parameter.

• If the autopilot is too “smooth” and slow to reach the heading/tracking set (or cannot reach it) you need to increase the “Gain” parameter.

Autopilot configuration

- It's recommended to change the value by 1 or 2 steps

and then observe the effects on the autopilot behavior.

As you can imagine the optimal setting is highly dependent on the flight controls and the aircraft type, so you probably find the optimal setting after some flights, in which you learn also the way the autopilot control the aircraft. You should be able to find a “Gain” value that is acceptable for both heading holds and turns in smooth air; may be required, in case of turbulence, to change this value (probably needs to be increased a bit).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Flight based test and configuration

CHECK OF THE PARAMETERS “TURN RATE” AND “MAX ROLL BANK”

It's possible to check if the values set for the turn rate and for the maximum bank angle are compatible by measuring the time the autopilot takes to complete a turn: for example if in the “Turn Rate” parameter you have set a value of 2°/s, the aircraft must take nearly 45 seconds to complete a 90° turn. If it takes more time it means that the “Max Roll Bank” parameter are set too low, so the autopilot is forced not to exceed this angle and as a result also the turn rate become slower than what set in “Turn Rate” parameter.

Now you have checked and configured all the parameters so you can disengage the autopilot by pressing the HDG/TRK button on the ACU control unit (the led will turn off as confirmation).

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Flight based test and configuration

Autopilot configuration

6.4.2 AUTOPILOT SETUP – PITCH AXIS (FLIGHT BASED)

- Start the flight and when you are in safe condition (read chap.6.4), at the desired altitude and trimmed for level flight, insert the autopilot by pressing the “ALT” button on the ACU control unit (the led will turn on as confirmation). Note that the autopilot will only hold the current altitude by controlling the pitch axis, so the roll axis must be controlled by the pilot; ensure that you are not affecting the pitch axis, so that you can determine the autopilot performance.

If the autopilot behavior is sufficiently stable keep it engaged for some minutes and observe the way in which it mantains the altitude:

- If the autopilot deviates heavily from the altitude set or make very slow adjustments you need to increase the value of the “Gain” parameter.

- If the autopilot is too aggressive with excessively fast adjustments you need to decrease the value of the “Gain” parameter.

The “Gain” parameter selects the amount of autopilot activity for a given altitude error (that is the difference between the desired altitude and the actual altitude). With low “Gain” values (minimum=1) the autopilot system is very slow with few corrections, with high “Gain” values (maximum=40) the autopilot is more “aggressive” with a lot of fast corrections. Above a certain upper limit, however, the system becomes unstable and start to oscillate.

Rev.3.7

Oblò / Oblò-A/P(Autopilot) User’s manual

Flybox

Autopilot configuration

Flight based test and configuration

To change the “Gain” parameter:

- Press for 1 second the knob to enter in the function menu.

- Rotate the knob to select the “Setup” menu and click to enter.

- Rotate the knob to select the “Autopilot” menu and click to enter.

- Rotate the knob to select the “Pitch servo” menu and click to enter.

- Rotate the knob to select the “Gain” parameter and click to enter;

- Rotate the knob to change the value and press it to store the new value.

100

Rev.3.7

Flybox Oblo, Oblo-A/P User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
