FLYABILITY
ORIGINAL INSTRUCTIONS
FLYABILITY SA
+41 21 311 55 00 —
INFO@FLYABILITY.COM
ELIOS 2
VERSION 1.0
02/15/2019
EU DECLARATION OF CONFORMITY
We,
Flyability SA
EPFL INNOVATION PARK BLDG C Lausanne CH-1014 Switzerland
Tel: +41 21 311 55 00
declare under our sole responsibility that the product:
ELIOS 2
Model No. 3
Serial Number 3000000-4000000
to which this declaration relates is in conformity with the following standards or other normative documents:
following the provisions of
The Technical Construction File is maintained at:
Flyability SA
EPFL Innovation Park Bldg C, 1015 Lausanne, Switzerland
The authorized representative located within the Community is:
Dr Adrien Briod
Chief Technology Officer
Date: February 15
Safety EN 62368-1:2014 + A11:2017
EMC EN 301 489-1 V2.2.0 (2017-03)
Radio EN 300 328 V2.1.1 (2016-11)
Health (RF Exposure) EN 62311:2008
- Radio Equipment Directive (RED) 2014/53/EU
- ROHS Directive: 2011/65/EU
- REACH Regulation: 2006/1907/EC
th
, 2019
EN 62471:2008
EN 301 489-17 V3.2.0 (2017-03)
ORIGINAL INSTRUCTIONS
Strictly confidential
FCC COMPLIANCE NOTICE
This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this
transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located
or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna
installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC RF EXPOSURE INFORMATION
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the
possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm
during normal operation.
IC RSS WARNING
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme a ux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur
de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
IC RADIATION EXPOSURE STATEMENT
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This eqipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
Ce matériel est conforme aux limites de dose d'exposition aux rayonnements, fic rss-102 énoncée dans un autre
environnement.cette eqipment devrait être installé et exploité avec distance minimale de 20 entre le radiateur et votre
corps.
ORIGINAL INSTRUCTIONS
Strictly confidential
DISCLAIMER
Terms with initial capital letters shall have the following meanings:
“Agreement” ...........means the conditions of use of this Original Instructions and any other agreement between You and
“Flyability” ..............means Flyability SA, a company incorporated in the Canton of Vaud in Switzerland under federal
“Product” ................means all goods and services described in this document.
“You” ......................means the person or legal entity to which the Product is delivered or who is operating the aircraft
All rights related to this document and all information it co ntained are the property of Flyability. REPRODUCTION, USE
OR DISCLOSURE TO THIRD PARTIES WITHOUT PRIOR WRITTEN PERMISSION FROM FLYABILITY IS STRICTLY PROHIBITED.
By using the Pro ducts, software and systems of Flyability, You fully accept and consent, without reserve, Flyability’s
warranty and liability terms stated below and all other terms and conditions agreed between You and Flyability.
1. Product limited warranty
By using the Product, You hereby signify that you have read, fully understood and agreed this disclaimer and the original
instructions, and You agree that the Product:
(i) Can only be operated by Flyability Certified Elios 2 Pilot and, if required by laws, with other drone pilot
(ii) Presents a risk of physical injuries if wrongly used; and
(iii) Presents a risk of damaging Your and Third-parties’ property if wrongly used; and
(iv) May be unfitted to Your needs and purposes; and
(v) Is intended to be used by Flyability Certified Elios 2 Pilot for industrial and professional purposes only; and
(vi) Should not be used under influence of alcohol, drugs or any substances that may impair cognitive abilities;
(vii) Is subject to local regulations that could prevent its use.
You shall pursue available remedies to You according to the Agreement. The warranty shall exclude defects due to misuse, non-observation of the Original Ins tructions, moisture or liquids, explosive gas, proximity or exposure to heat at
temperatures exceeding the Operating temperature of 50 degrees Celsius, excessive strain, abuse, neglect, misapplication, repairs or modifications made by anyone other than Flyability or certified by Flyability. There are no express or
implied warranties, representations or conditions other than those stated in this limited warranty and the A greement.
The remedy set forth herein and in the Agreement shall be the sole, exclusive remedy with respect to the Product.
2. Product liability
IN NO EVENT OR UNDER ANY CIRCUMSTANCE, UNLESS EXPRESSLY STATED IN THE A GREEMENT, SHALL FLYABILITY SA,
ITS DIRECTORS, OFFICERS OR EMPLOYEES BE LIABLE TO YOU OR TO ANY THIRD PERSON CLAIMING RIGHTS DERIVED
FROM YOUR RIGHTS, IN CONTRACT, TORT OR OTHERWISE, FOR INDIRECT, SPECIAL, INCIDENTAL, EXEMPLARY, PUNITIVE
OR CONSEQUENTIAL DAMAGES OF ANY KIND WHATSOEVER EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES
INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES CAUSED BY YOU OR A THIRD PARTY WHILE OPERATING OR USING
THE PRODUCT, ANY DAMAGES CAUSED BY FAILURE OF THE ELECTRONICS OR SOFTWARE, ANY LOSS OF REVENUE, LOSS
OF PROFIT, OR LOSS OF DATA WHETHER BASED UPON ANY ALLEGED BREACH OF WARRANTY, REPRESENTATION OR
CONDITION, CONTRACT, OR ANY OTHER CONDUCT INCLUDING NEGLIGENCE (INTENTIONAL OR OTHERWISE), GIVING
RISE TO SUCH CLAIM. A Party who relies on a breach of the other Party’s obligations under this Agreement, shall take
any and all reasonable measures in the circumstances to mitigate the consequences, including loss of profit, resulting
from the breach. If it fails to take such measures, the Party in breach may claim a reduction in the damages in the amount
by which the consequences should have been mitigated.
YOU SHALL NOT OPERATE THE PRODUCT IN AREAS OR UNDER CIRCUMSTANCES WHERE A FAILURE COULD CAUSE
DAMAGES AND/OR HARM TO OBJECTS AND/OR PEOPLE. YOU SHOULD HAVE READ AND UNDERSTOOD THE ORIGINAL
INSTRUCTIONS COMPLETELY BEFORE OPERATING THE PRODUCT. ANY DAMAGE A ND/OR HARM ARISING FROM NOT
ACCURATELY FOLLOWING THE PROCESSES AND GUIDANCE FROM THE ORIGINAL INSTRUCTIONS SHALL BE THE SOLE
RESPONSIBILITY OF THE OPERATOR OF THE UAV.
Flyability per which the Product has been delivered to You, including but not limited to Flyability’s
General Terms and Conditions.
number CH-550.1.156.670-6 (IDE CHE-348.376.646) having its registered offices at EPFL Innovation
Park BLDG C, 1015 Lausanne, Switzerland
licenses or any other certification necessary to pilot Elios 2; and
and
ORIGINAL INSTRUCTIONS
Strictly confidential
ALL USE OF THE PRODUCTS IS UNDER YOUR SOLE REPONSIBILITY, INCLUDING BUT NOT LIMITED TO, THE COMPLIANCE
WITH APPLICABLE LAW AND REGULATIONS OF THE COUNTRY IN WHICH THE PRODUCT IS OPERATED.
3. Data storage and usage
When You use the tablet application or any other software provided by Flyability, data regarding the use and operation
of the product, such as flight telemetry data (e.g. battery life, altitude, hardware identification) and o perations records
may be automatically or manually uploaded to a Flyability designed server.
The provided data does not include personal data (e.g. name, address) but identification data, such as user name, that
may become associated with, used to identify to such information we Flyability stores it. By using the product, the tablet
application or any other software distributed by Flyability, or by manually providing data to Flyability, you consent to:
(i) Our storage of any telemetry data and other data uploaded or provided to us, including in combination with
your user name; and
(ii) Our use of any such data uploaded or provided (including your user name) in connection with providing
support and services to You and to improve our products.
Authorizations and regulations
SOME COUNTRIES MAY HAVE LAWS THAT LIMIT OR PROHIBIT THE USE OF UNMANNED AIRCRAFT. YOU ARE SOLE
RESPONSIBLE FOR SECURING ALL AUTHORIZATIONS, CERTIFICATIONS AND LICENSES REQUIRED FOR THE USE OF THE
PRODUCT. FLYABILITY SA DOES NOT PROVIDE ANY LEGAL ADVICE OR COUNSELING AND UNDER NO EVENT SHALL BE
LIABLE FOR ANY INFRIGMENT OF ANY APPLICABLE LAW BY YOU.
ORIGINAL INSTRUCTIONS
Strictly confidential
ELIOS 2
1 – Safety
1 Safety
Read carefully and understand these important safety instructions before flying to
prevent any risk of accident and serious injuries.
1.1 Operation Safety Rules
During operation and missions please observe the following rules. Make sure people around you have been briefed about
safety accordingly.
WARNING
High speed spining
propeller
WARNING
Loud noise
WARNING
Bright light
Flashing Light
WARNING
Hot surfaces
MANDATORY
Read the original
instructions
MANDATORY
Wear hear protection
MANDATORY
Wear eye protection
Wear head protection
MANDATORY
MANDATORY
Have protective gloves
in vicinity
Everyone surrounding the operation, pilot included, must wear eye, ear, and head protections. They must have
protective gloves in vicinity1. They should not wear jewelry, loose clothing or long hair.
Apart from the camera operator, the spotter, or the inspector, no one should talk to the pilot. It may reduce his
concentration.
When the propellers are spinning, the aircraft must not be touched. If not applicable, make sure the aircraft is
stable, touch only the aircraft’s protective cage with your hands wide open and your fingers straight to prevent
any of them from entering the cage. You must wear protective gloves to touch the aircraft if the propellers are
spinning.
Avoid any presence of people directly below the aircraft and do not fly close to people.
Possibly hazardous optical radiation emitted from this product. Do not look at operating lamp. Eye injury may
result.
In case of accident, do not try to catch the falling aircraft. Your safety is more important than the aircraft.
The area around the pilot, in addition to the takeoff and landing area should all be free from people and obstacles.
1
A risk assessment should be made to state additional protection (e.g. respiratory protection in dusty environments)
ORIGINAL INSTRUCTIONS
Strictly confidential
1.2 General Guidelines
The pilot MUST be Flyability Certified Elios 2 Pilot and, if required by laws, with other drone pilot licenses or any
other certification necessary to pilot Elios 2.
A damaged propeller may break, and pieces of broken blade can become dangerous projectiles and reduce the
aircraft reliability. Replace the propeller if it is broken, cracked, bent, or damaged in any way. Operator and surrounding personnel MUST wear safety glasses.
Debris can be ejected at high velocity from the aircraft propulsion. Operator and surrounding personnel MUST
wear safety glasses.
The pilot should always act accordingly to his or her best judgment, focusing on the safety of the people and the
environment he or she is flying in. The pilot MUST brief every personnel attending or surrounding the flight about
safety. While piloting, the pilot should not move as it may cause him to slip, trip or fall causing personal injuries.
DO NOT fly over or near people, moving vehicles. Always give way to other aircrafts. Watch out for low flying
helicopters.
Operating the Elios 2 system can be stressing, tiring and prone to muscular fatigue. The controller is equipped
with a hook. Use the provided controller strap to relieve your muscles. It will also avoid you to lose, drop, or
damage the ground control station.
During a flight, parts of the aircraft can become very hot. Wait 3 minutes after disarming for it to cool down and
access the battery. If time is constraint, you may use protective gloves to change the battery during the cooling
period.
Using the LED pulsing on Elios 2 can be tiring and stressful for the pilot and surrounding personnel. It can trigger
a seizure on person with epilepsy.
Front module contains magnet that can disrupt the proper functioning of medical devices or disturbing certain
electronic devices in a near field.
DO NOT use Elios 2 under influence of alcohol, drugs or any substances that may impair cognitive abilities.
A risk assessment MUST be performed before every flight.
The pilot MUST always go through the checklists before, during and after each flight.
Elios 2, like any remotely piloted aircraft system, must be operated per the laws of the country it is used in. It is
the sole responsibility of the pilot to be informed of the applicable restrictions. If you are flying in a public environment or around people, make sure to respect the rules of flight in line of sight.
Use only provided Flyability parts, genuine Flyability parts, or parts certified by Flyability. Using other devices or
parts combination with Elios 2 (e.g. batteries, propellers, etc.) or performing unauthorized modifications may
result in system malfunctioning and/or compromise safety.
It is strongly recommended to avoid any operation inside the aircraft’s cage when the battery is plugged in, except
turning off the aircraft (unplugging the battery).
DO NOT wear jewelry, loose clothing or long hair when operating Elios 2 or being in its vicinity.
Under no circumstances, objects, fingers or any other body parts may enter inside the aircraft’s protective cage
while it is armed (when the propellers are spinning). It may result in serious injuries for the person and damage
the aircraft.
DO NOT perform the arming sequence or arm the aircraft (make propellers spin) before and during the removal
or insertion of the battery or if objects, fingers or any other body parts are inside the protective cage.
When the propellers are spinning, the aircraft must not be touched. If not applicable, make sure the aircraft is
stable, touch only the aircraft’s protective cage with your hands wide open and your fingers straight to prevent
any of them from entering the cage. You must wear protective gloves to touch the aircraft if the propellers are
spinning.
Propellers have sharp edges; protective gloves MUST be worn while changing a propeller.
If the aircraft is unresponsive due to malfunction, make the disarming sequence and DO NOT try put your hand
or fingers into the cage during 1h after the incident. Wear protective gloves to disconnect the battery.
After a strong crash (more than 1m free fall), do not touch the aircraft as it may explode or catch fire. If the
aircraft is in an enclosed place, or near to an explosive or flammable environment, you may carefully place it in a
ELIOS 2
1 – Safety
ORIGINAL INSTRUCTIONS
Strictly confidential
properly ventilated area. The aircraft must remain under supervision. A risk assessment should be performed
prior taking any actions.
It is recommended to use only transport cases approved by Flyability.
Read carefully the Battery Safety Guidelines and the Quick Start Guide before using the Elios 2 system.
After a flight, wait 3 minutes before touching the parts highlighted on the drawing above:
a. Motors
b. Lighting system heatsink
ELIOS 2
1 – Safety
ORIGINAL INSTRUCTIONS
Strictly confidential
1.3 Environmental Awareness
ELIOS 2
1 – Safety
Always fly within the listed conditions. It will reduce incident and damage on the aircraft.
Do not fly close to people.
Elios 2 is not waterproof. Do not fly under heavy rain/snow or in humid environments. Moisture can seriously
damage the electronics of Elios 2.
Store the Elios 2 system in a dry environment between 0°C and 30°C protected from sunlight.
Avoid flying in a dusty, or sandy environment or s ubject to vapor, or gas. If not applicable, avoid flying close to
people. Have yourself and surrounding personnel wear eye protection and respiratory protection as the propulsion system may blow dust, vapor or gas to you. Do not forget this topic in your risk assessment. Note that,
mechanical parts may deteriorate more rapidly in dusty or sandy environments.
Even if the cage protects the aircraft, small objects can penetrate the cage and damage the aircraft. Be sure while
flying, that protruding objects and/or any falling o bjects will not go through the cage as it might break the propellers, damage the aircraft, or create high velocity projectiles. In case of doubt performing a risk assessment is
recommended and eye protection MUST be worn.
Flying in low pressure environment such as high altitudes above the sea level might reduce flight time, and the
stability of the aircraft.
The wind has serious effects on Elios 2. If the wind is higher than 3m/s, it should be piloted in disabled Pilot assist
mode. In this mode and/or with the wind higher than 3m/s, Flyability cannot guaranty Elios 2 capability to sustain
a collision. With the wind above 5m/s, Flyability cannot guarantee the stability or flying capability of Elios 2.
Very cold temperatures lead to reduced flight times. Do not fly in temperatures below 0°C. If you need to fly
within a temperature below 10°C, heat the batteries prior usage using a battery warmer bag and observe safe
practices as described in the Battery Safety Guidelines.
Hot temperatures – above 40°C – will interfere with the battery performances. The pilot should observe the safe
practices regarding the battery described in the Battery Safety Guidelines. Also, Flyability cannot guaranty the
collision sustainability of the aircraft above 40°C. The Pilot assist performance may diminish. The maximum power
of the lighting system will reduce for the system safety. The aircraft should not be left switched on without propellers spinning in temperature above 40°C, the electronics needs to be cooled down by the airflow generated
by the propulsion system. In such temperatures use gloves for changing the battery or wait for at least 10 minutes
for the drone to cool down in a zone where the temperature is below 30°C. Pay extra attention to not to uch the
lighting system heatsinks or the motors during the cooldown period.
Flyability cannot guaranty the aircraft flight capability and stability if not used in temperatures from 0°C to 50°C.
It is not recommended to operate the aircraft close to power lines, power transformers or other areas with high
electromagnetic disturbances as these may cause severe effects on the sensors and transmission system, impacting the aircraft’s stability and flying capability.
The aircraft propulsion system makes loud noises. Wearing ear protection is mandatory when flying in enclosed
areas or when the aircraft is operating close to the personnel.
If you are flying in a confined or enclosed place, avoid being inside this environment with the aircraft flying. Do
not forget this topic in your risk assessment.
Avoid flying in a biohazard environment. If not applicable, avoid flying close to people and have yourself and
surrounding personnel wear eye protection and respiratory protection as the propulsion system may blow contaminated particles to you. Also , wear gloves and appropriate protection while manipulating the aircraft and its
equipment until further decontamination. Do not forget this topic in your risk assessment.
Elios 2 should not be used in or near explosive or flammable environments.
ORIGINAL INSTRUCTIONS
Strictly confidential
1.4 Maintenance guidelines
To ensure safe and reliable product, the user is asked to observe the following preventive actions:
1. Change pentagons anytime a damage is present.
2. A damaged propeller may break, and pieces of broken blade can become dangerous projectiles and reduce the
aircraft reliability. Replace the propeller if it is broken, cracked, bent, or damaged in any way.
3. Change the propeller after 10h of flight.
4. Change the motor after 25h of flight.
ELIOS 2
1 – Safety
ORIGINAL INSTRUCTIONS
Strictly confidential
ELIOS 2
2 – Checklists
2 Checklists
The checklists are a proposed workflow to help operating the Elios 2 system in a safe and efficient manner. They are often
updated and the latest versions are available on the my.flyability.com platform.
2.1 Mission Planning Guidelines
This checklist presents the steps that must be followed whilst planning an operation.
1. Has the Method Statement been filled?
The Method Statement (MS) is a document speci fying all the different steps that will be performed during the inspection. It will also
specify all the required equipment to fulfil the mission. The “Method Statement – Template” document offer a template to establish your
own.
2. Has the Risk Assessment been filled?
The Risk Assessment (RA) is a document specifying all the risks that can occur during the progress of the mission. It states as well the
mitigation that can be made to limit the risk to occur. The “Risk Assessment – Template” document offer a template to establish your
own.
3. Is the environment in which the Elios 2 will be operated safe?
Elios 2 is sensible to its surroundings. The mission environment must comply to the limitation presented in the “Environment Awareness”
section presented in the Original Instructions.
The presence of dangerous elements must have been stated in the RA and MS documents.
4. Is there any biological hazard?
If the Elios 2 is flying in environment that can present bio-hazard (sewer, pandemic area, etc.), the risk should be listed within the MS or
RA and appropriate measures must be taken (gloves, eye protection, mask, etc.).
5. Do you have the adequate Personal Protective Equipment (PPE)?
The following PPE must always be worn:
- Eye protection.
- Ear protection.
- Hard hat.
- Have protective gloves in vicinity.
You must be aware of the effects of operating Elios 2 in your working environment and dress accordingly:
- If the environment is dusty, wear respiratory protection.
- If the environment contains hazardous element, wear the corresponding PPE.
Those statements must have been defined in the MS document.
6. Do you have the proper flight authorization?
If you perform outdoor flight, depending on the area and on the country in which you will c onduct your flight, you will need a specific
authorization. Contact the aeronautical agency in place in your country for more information.
7. Use of the aircraft
Flyability’s products are NOT listed as dual-use products. Ensure the system is not used with the intent to harm.
ORIGINAL INSTRUCTIONS
Strictly confidential
ELIOS 2
2 – Checklists
2.2 Aircraft Inspection
The aircraft inspection checklist ensure the Elios 2 is suited to fly. It should be made before each flight and after having
transported the Elios 2. Remember the acronym PEACE.
P
ROPELLERS .................................... TIGHT
Propellers are tight on the motors.
LECTRICAL MOTORS ............................... MOVE FREELY
E
Make the motors rotate to make sure no dust, sand, or particles are inside
A
IRCRAFT ................................................. CLEAR OF DAMAGE
Visually inspect the aircraft to make sure it is free from damage. Pay great attention to carbon parts and pro-
pellers.
AMERA LENS AND SENSORS .................. CLEAN
C
Clean the camera lens and the sensors using the lens cleaner. It will ensure a better quality for your footage and
an increased stability of the aircraft. Make also sure that the camera lens is free of stains.
LECTRICAL SUPPLY ................................. UNDAMAGED | SECURED | PLUGGED
E
A fully charged and in visual proper condition battery is tightly connected to the aircraft and secured with the
strap.
2.3 Take-off Checklist
Do the take-off checklist before each flight. Remember the acronym SAFE.
AFETY BRIEFING ........................ PERFORMED
S
All personnel surrounding the operation has been briefed about safety using the Basic Safety Rules whilst
in operation and are aware that they should avoid perturbing the pilot.
A
IRCRAFT .................................... CHECKED
The aircraft inspection ensure the Elios 2 is ready to fly.
F
LIGHT PLAN ............................... DONE
The flight plan ensures that the Elios 2 will fly in a safe environment and will gather data in a consistent
way.
NVIRONMENT ........................... CHECKED
E
Make sure you are flying in a safe environment complying with the limitation of the system as stated in the
Environmental Awareness.
ORIGINAL INSTRUCTIONS
Strictly confidential
3 – Elios 2 Technical Specification
3 Elios 2 Technical Specification
Flight mode
Types Velocity control, angle control, manual
Availability Switch between modes at any time
Fail safes Auto-landing on low-battery or signal lost
Onboard Electronics
Avionics-board Autopilot, thermal video and system management
Power-board Motor control
Payload-board Camera, thermal camera and lighting control
Flight system
Type Quadcopter configuration
Dimension Fits in < 400 mm sphere
Motors 4 fast reversing electric brushless motors
Propellers 4 propellers, 5 inches
Take-off weight 1400g including battery, payload & protection
Flight time Up to 10 mn
Max. climb rate 1.5 m/s
Wind resistance 3 m/s (Pilot assist), 5 m/s (angle mode)
Max groundspeed 1.5 m/s (Pilot assist)
Sensors IMU, magnetometer, barometer, 7 velocity and distance sensors
Materials Carbon fiber composites, magnesium alloy, aeronautical grade aluminum, high-quality
Operating temperature 0 ºC to 50 ºC
Ruggedness Splash and dust resistant (equivalent to IP53 but not certified)
Remote controller (ground system)
Type Ergonomic joysticks and payload controls, integrated video outputs
Weight 810 g
Operating temperature 0 ºC to 40 ºC
Output ports HDMI, SDI, USB
Battery 6000 mAh, 2S
Controls Payload settings and aircraft control
Options Optional remote controller (camera operator) with video stream reception on a
Wireless communication Remote Controller to UAV
Type Digital, bidirectional, long range, video and data downlink to remote controller (RC),
Operating Frequency 2404 – 2483 MHz
Modulation Type DSSS OFDM
Range Up to 500 m in direct line of sight
EIRP RC (to UAV)
EIRP UAV (to RC) FCC: ≤ 27dBm ; CE : ≤20dBm ; SRRC : ≤20dBm ; MIC: ≤20dBm
Wireless communication Remote Controller to Camera Operator Remote Controller
Frequency 5738-5808 MHz
EIRP RC to RC 5.8GHz: FCC: ≤ 27dBm ; CE : ≤20dBm ; SRRC : ≤20dBm
System power
Type Lithium polymer battery high voltage, 5 cells, 19V, 5200 mAh, 98.8 Wh
Charging time 1 h
Battery change time < 1 mn
thermoplastics
secondary screen, and dual control of camera settings.
command and data uplink to UAV
FCC: ≤20dBm CE: ≤16dBm ; MIC: ≤16dBm
920.6-928 MHz (Japan only)
920MHz: MIC: ≤10dBm
ELIOS 2
ORIGINAL INSTRUCTIONS
Strictly confidential
3 – Elios 2 Technical Specification
Integrated payload
Payload head Damped from vibrations
Upwards tilt +80 degrees
Downwards tilt -60 degrees
Main camera
Video 4K (3840 x 2160) at 30fps, optimized for low light performance, recorded on board and
Stream FHD
Horizontal field of view 114 degrees
Vertical field of view 103 degrees
Total vertical field of view 283 degrees (considering payload up/down rotation)
Control modes Auto with EV correction
streamed
Thermal camera
Type Lepton 3.5 FLIR
Video 160x120 pixels at 9 fps, recorded on board
Horizontal field of view 56 degrees
Vertical field of view 42 degrees
Sensitivity <50 mK
Wavelength LWIR, 8 to 14 μm
Lighting system
Type High-efficiency LEDs for even lighting in front, top and bottom, optimized for low
Control From remote controller, adaptive light beam controlled by camera pitch
Power 35W continous power for front lighting, 120W total lighting
impact of dust on picture quality
IR light used imrpoved stability
Operational safety & collision worthiness
Navigation lights Green and red lights
Protection cage Carbon fiber cage with soft coating, modular subcomponents for maintenance ease,
Collision tolerance Uniform all around the drone, up to 2 m/s on sharp objects, up to 3 m/s on flat objects
thermoplastic elastomer suspensions, front opening dimensioned for hand to access
inside for swapping batteries
Accessories
Transport case IATA compliant transport case for checked-in luggage,
Chargers 5.2 A / 100 W Flyability Elios 2 battery c harger, with cha rging status indicator, RC
dimensions: 61 cm x 44 cm x 53 cm
charger: 17.4 V, 57 W, tablet USB charger: 5 V
Mobile application used during flight (Cockpit)
Features Real time video and UAV telemetry, status visualization (remaining battery, payload
Operating system Android, optimized for tablet provided with UAV system
Desktop application used after flight (Inspector)
Features Video and thermal video viewer (frame by frame), flight log analysis including point of
Operating system Windows 7, 8 and 10 (32 and 64 bits)
settings, warnings, etc. ), control payload settings and various configurations.
interests recorded during flight, screenshots and flight data export.
ELIOS 2
ORIGINAL INSTRUCTIONS
Strictly confidential
