FLYABILITY SA
+41 21 311 55 00 — INFO@FLYABILITY.COM
EPFL INNOVATION PARK BLDG C | 1015 LAUSANNE | SWITZERLAND
FLYABILITY
ELIOS
ORIGINAL
INSTRUCTIONS
VERSION 1.1
05/29/2017
ORIGINAL INSTRUCTIONS Page 3 of 22
Strictly confidential
EU DECLARATION OF CONFORMITY
We,
Flyability SA
EPFL INNOVATION PARK BLDG C, 1015 Lausanne, Switzerland
Tel: +41 21 311 55 00
declare under our sole responsibility that the product:
ELIOS
Model No. 1
Serial Number 1000000-2000000
to which this declaration relates is in conformity with the following standards or other normative
documents:
Safety
Risk assessment per EN ISO 12100:2010 – Safety of machinery.
General principles for design. Risk assessment and risk reduction.
EMC
EN 301 489-1 V1.9.2
EN 301 489-3 V1.6.1
EN 301 489-17 V2.2.1
Radio
EN 300 440-1 V1.6.17
EN 300 440-2 V1.4.1
Health
EN 62471
EN 62311:2008 (RF Exposure)
following the provisions of
- Machinery Directive (MD) 2006/42/EC, and
- Radio Equipment Directive (RED) 2014/53/EU
The Technical Construction File is maintained at:
Flyability SA
Avenue de Sévelin 20, 1004 Lausanne, Switzerland
The authorized representative located within the Community is:
Dr Adrien Briod
Chief Technology Officer
Avenue de Sévelin 20, 1004 Lausanne, Switzerland
Date: March 15th, 2017
ORIGINAL INSTRUCTIONS Page 5 of 22
Strictly confidential
FCC COMPLIANCE NOTICE
This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm
from all persons and must not be co-located or operating in conjunction with any other antenna or
transmitter. End-users and installers must be provided with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure compliance.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the re-
ceiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF EXPOSURE INFORMATION
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity
to the antenna shall not be less than 20cm during normal operation.
ORIGINAL INSTRUCTIONS Page 7 of 22
Strictly confidential
DISCLAIMER
Terms with initial capital letters shall have the following meanings:
“Agreement” .......... means the conditions of use of this Original Instructions and any other agreement
between You and Flyability per which the Product has been delivered to You, including but not limited to Flyability’s General Terms and Conditions.
“Flyability” ................ means Flyability SA, a company incorporated in the Canton of Vaud in Switzer-
land under federal number CH-550.1.156.670-6 (IDE CHE-348.376.646) having its
registered offices at EPFL Innovation Park BLDG C, 1015 Lausanne, Switzerland
“Product” .................. means all goods and services described in this document.
“You” ............................ means the person or legal entity to which the Product is delivered or who is oper-
ating the aircraft
All rights related to this document and all information it contained are the property of Flyability.
REPRODUCTION, USE OR DISCLOSURE TO THIRD PARTIES WITHOUT PRIOR WRITTEN PERMISSION
FROM FLYABILITY IS STRICTLY PROHIBITED.
By using the Products, software and systems of Flyability, You fully accept and consent, without reserve, Flyability’s warranty and liability terms stated below and all other terms and conditions agreed
between You and Flyability.
1. Product limited warranty
By using the Product, You hereby signify that you have read, fully understood and agreed this disclaimer and the original instructions, and You agree that the Product:
(i) Can only be operated by Flyability Certified Elios Pilot and, if required by laws, with other
drone pilot licences or any other certification necessary to pilot Elios; and
(ii) Presents a risk of physical injuries if wrongly used; and
(iii) Presents a risk of damaging Your and Third-parties’ property if wrongly used; and
(iv) May be unfitted to Your needs and purposes; and
(v) Is intended to be used by Flyability Certified Elios Pilot for industrial and professional pur-
poses only; and
(vi) Should not be used under influence of alcohol, drugs or any substances that may impair
cognitive abilities; and
(vii) Is subject to local regulations that could prevent its use.
You shall pursue available remedies to You according to the Agreement. The warranty shall exclude
defects due to misuse, non-observation of the Original Instructions, moisture or liquids, explosive
gas, proximity or exposure to heat at temperatures exceeding the Operating temperature of 50 degrees Celsius, excessive strain, abuse, neglect, misapplication, repairs or modifications made by anyone other than Flyability or certified by Flyability. There are no express or implied warranties, representations or conditions other than those stated in this limited warranty and the Agreement. The
remedy set forth herein and in the Agreement shall be the sole, exclusive remedy with respect to
the Product.
2. Product liability
IN NO EVENT OR UNDER ANY CIRCUMSTANCE, UNLESS EXPRESSLY STATED IN THE AGREEMENT,
SHALL FLYABILITY SA, ITS DIRECTORS, OFFICERS OR EMPLOYEES BE LIABLE TO YOU OR TO ANY
THIRD PERSON CLAIMING RIGHTS DERIVED FROM YOUR RIGHTS, IN CONTRACT, TORT OR
OTHERWISE, FOR INDIRECT, SPECIAL, INCIDENTAL, EXEMPLARY, PUNITIVE OR CONSEQUENTIAL
DAMAGES OF ANY KIND WHATSOEVER EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES
INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES CAUSED BY YOU OR A THIRD PARTY WHILE
OPERATING OR USING THE PRODUCT, ANY DAMAGES CAUSED BY FAILURE OF THE ELECTRONICS
OR SOFTWARE, ANY LOSS OF REVENUE, LOSS OF PROFIT, OR LOSS OF DATA WHETHER BASED
UPON ANY ALLEGED BREACH OF WARRANTY, REPRESENTATION OR CONDITION, CONTRACT, OR
ANY OTHER CONDUCT INCLUDING NEGLIGENCE (INTENTIONAL OR OTHERWISE), GIVING RISE TO
SUCH CLAIM. A Party who relies on a breach of the other Party’s obligations under this Agreement,
shall take any and all reasonable measures in the circumstances to mitigate the consequences, including loss of profit, resulting from the breach. If it fails to take such measures, the Party in breach
ORIGINAL INSTRUCTIONS Page 8 of 22
Strictly confidential
may claim a reduction in the damages in the amount by which the consequences should have been
mitigated.
YOU SHALL NOT OPERATE THE PRODUCT IN AREAS OR UNDER CIRCUMSTANCES WHERE A
FAILURE COULD CAUSE DAMAGES AND/OR HARM TO OBJECTS AND/OR PEOPLE. YOU SHOULD
HAVE READ AND UNDERSTOOD THE ORIGINAL INSTRUCTIONS COMPLETELY BEFORE OPERATING
THE PRODUCT. ANY DAMAGE AND/OR HARM ARISING FROM NOT ACCURATELY FOLLOWING THE
PROCESSES AND GUIDANCE FROM THE ORIGINAL INSTRUCTIONS SHALL BE THE SOLE
RESPONSIBILITY OF THE OPERATOR OF THE UAV.
ALL USE OF THE PRODUCTS IS UNDER YOUR SOLE REPONSIBILITY, INCLUDING BUT NOT LIMITED
TO, THE COMPLIANCE WITH APPLICABLE LAW AND REGULATIONS OF THE COUNTRY IN WHICH
THE PRODUCT IS OPERATED.
3. Data storage and usage
When You use the tablet application or any other software provided by Flyability, data regarding the
use and operation of the product, such as flight telemetry data (e.g. battery life, altitude, hardware
identification) and operations records may be automatically or manually uploaded to a Flyability
designed server.
The provided data does not include personal data (e.g. name, address) but identification data, such
as user name, that may become associated with, used to identify to such information we Flyability
stores it. By using the product, the tablet application or any other software distributed by Flyability,
or by manually providing data to Flyability, you consent to:
(i) Our storage of any telemetry data and other data uploaded or provided to us, including
in combination with your user name; and
(ii) Our use of any such data uploaded or provided (including your user name) in connection
with providing support and services to You and to improve our products.
Authorizations and regulations
SOME COUNTRIES MAY HAVE LAWS THAT LIMIT OR PROHIBIT THE USE OF UNMANNED AIRCRAFT.
YOU ARE SOLE RESPONSIBLE FOR SECURING ALL AUTHORIZATIONS, CERTIFICATIONS AND
LICENSES REQUIRED FOR THE USE OF THE PRODUCT. FLYABILITY SA DOES NOT PROVIDE ANY
LEGAL ADVICE OR COUNSELING AND UNDER NO EVENT SHALL BE LIABLE FOR ANY INFRIGMENT
OF ANY APPLICABLE LAW BY YOU.
ELIOS
Contents
ORIGINAL INSTRUCTIONS Page 9 of 22
Strictly confidential
Contents
1
!
Safety ................................................................................................................................................................................................................ 11
!
1.1! Operation Safety Rules ....................................................................................................................................................................... 11!
1.2! General Guidelines ................................................................................................................................................................................ 12!
1.3! Environmental Awareness .............................................................................................................................................................. 13!
2
!
Checklists ..................................................................................................................................................................................................... 14
!
2.1! Mission Planning Guidelines ......................................................................................................................................................... 14!
2.2! Aircraft Inspection ................................................................................................................................................................................. 15!
2.3! Take-off Checklist ................................................................................................................................................................................... 16!
2.4! After-flight Checklist ............................................................................................................................................................................ 17!
3
!
Elios Technical Specification ........................................................................................................................................................ 19
!
ELIOS
1 – Safety
ORIGINAL INSTRUCTIONS Page 11 of 22
Strictly confidential
1 Safety
Read carefully and understand these important safety instructions
before flying to prevent any risk of accident and serious injuries.
1.1 Operation Safety Rules
During operation and missions please observe the following rules. Make sure people around you have
been briefed about safety accordingly.
Warning
Read the original
instrucations
Wear eye protection
Wear head protection
Have protective gloves
in vicinity
Everyone surrounding the operation must wear eye and head protections. They must have
protective gloves in vicinity1. They should not wear jewelry, loose clothing or long hair.
Apart from the camera operator, the spotter, or the inspector, no one should talk to the pilot.
It may reduce his concentration.
When the propellers are spinning, the aircraft must not be touched. If not applicable, make
sure the aircraft is stable, touch only the aircraft’s protective cage with your hands wide open
and your fingers straight to prevent any of them from entering the cage.
Avoid any presence of people directly below the aircraft.
In case of accident, do not try to catch the falling aircraft. Your safety is more important than
the aircraft.
The area around the pilot, in addition to the takeoff and landing area should all be free from
people and obstacles.
1
A risk assessment should be made to state additional protection (e.g. respiratory protection in dusty
environments)
ELIOS
1 – Safety
ORIGINAL INSTRUCTIONS Page 12 of 22
Strictly confidential
1.2 General Guidelines
The pilot MUST have followed the mandatory training provided by Flyability or their certified
agents prior to operating the Elios system.
The pilot should always act accordingly to his or her best judgment, focusing on the safety of
the people and the environment he or she is flying in. The pilot MUST brief every personnel
attending or surrounding the flight about safety. While piloting, the pilot should not move as
it may cause him to slip, trip or fall causing personal injuries.
DO NOT fly over or near people, moving vehicles. Always give way to other aircrafts. Watch out
for low flying helicopters
Operating the Elios system can be stressing, tiring and prone to muscular fatigue. The control-
ler is equipped with a hook. Use the provided controller strap to relieve your muscles. It will
also avoid you to lose, drop, or damage the ground control station.
DO NOT use Elios under influence of alcohol, drugs or any substances that may impair cogni-
tive abilities.
A risk assessment MUST be performed before every flight
The pilot MUST always go through the checklists before, during and after each flight.
Elios, like any remotely piloted aircraft system, must be operated per the laws of the country
it is used in. It is the sole responsibility of the pilot to be informed of the applicable restrictions.
If you are flying in a public environment or around people, make sure to respect the rules of
flight in line of sight.
Use only provided Flyability parts, genuine Flyability parts, or parts certified by Flyability. Using
other devices or parts combination with Elios (e.g. batteries, propellers, etc.) or performing
unauthorized modifications may result in system malfunctioning and/or compromise safety.
It is strongly recommended to avoid any operation inside the aircraft’s cage when the battery
is plugged in, except turning off the aircraft (unplugging the battery).
DO NOT wear jewelry, loose clothing or long hair when operating Elios or being in its vicinity.
Under no circumstances, objects, fingers or any other body parts may enter inside the aircraft’s
protective cage while it is armed (when the propellers are spinning). It may result in serious
injuries for the person and damage the aircraft.
DO NOT perform the arming sequence or arm the aircraft (make propellers spin) before and
during the removal or insertion of the battery.
When the propellers are spinning, the aircraft must not be touched. If not applicable, make
sure the aircraft is stable, touch only the aircraft’s protective cage with your hands wide open
and your fingers straight to prevent any of them from entering the cage.
Propellers have sharp edges; protective gloves MUST be worn while changing a propeller.
If the aircraft is unresponsive due to malfunction, make the disarming sequence and DO NOT
try put your hand or fingers into the cage during 1h after the incident. Wear protective gloves
to disconnect the battery.
After a strong crash (more than 1m free fall), do not touch the aircraft as it may explode or
catch fire. If the aircraft is in an enclosed place, or near to an explosive or flammable environment, you may carefully place it in a properly ventilated area. A risk assessment should be
performed prior taking any actions.
It is recommended to use only transport cases approved by Flyability.
Read carefully the Battery Safety Guidelines and the Quick Start Guide before using the Elios
system.
ELIOS
1 – Safety
ORIGINAL INSTRUCTIONS Page 13 of 22
Strictly confidential
1.3 Environmental Awareness
Always fly within the listed conditions. It will reduce incident and damage on the aircraft.
Elios is not waterproof. Do not fly under heavy rain/snow or in humid environments. Moisture
can seriously damage the electronics of Elios.
Store the Elios system in a dry environment between 0°C and 30°C protected from sunlight.
Avoid flying in a dusty, or sandy environment or subject to vapor, or gas. If not applicable, avoid
flying close to people and have yourself and surrounding personnel wear eye protection and
respiratory protection as the propulsion system may blow dust, vapor or gas to you. Do not
forget this topic in your risk assessment. Note that, mechanical parts may deteriorate more
rapidly in dusty or sandy environments.
Even if the cage protects the aircraft, small objects can penetrate the cage and damage the
aircraft. Be sure while flying, that protruding objects and/or any falling objects will not go
through the cage as it might break the propellers, damage the aircraft, or create high velocity
projectiles. In case of doubt performing a risk assessment is recommended and eye protection
MUST be worn.
Flying in low pressure environment such as high altitudes above the sea level might reduce
flight time, and the stability of the aircraft.
The wind has serious effects on Elios. If the wind is higher than 3m/s, it should be piloted in
Pro-mode
. In this mode and/or with the wind higher than 3m/s, Flyability cannot guaranty
Elios capability to sustain a collision. With the wind above 5m/s, Flyability cannot guarantee
the stability or flying capability of Elios.
Very cold temperatures lead to reduced flight times. Do not fly in temperatures below 0°C. If
you need to fly within a temperature below 10°C, heat the batteries prior usage using a battery
warmer bag and observe safe practices as described in the Battery Safety Guidelines.
Hot temperatures – above 40°C – will interfere with the batteries performances. The pilot
should observe the safe practices regarding the battery described in the Battery Safety Guidelines. Also, Flyability cannot guaranty the collision sustainability of the aircraft above 40°C. The
aircraft should not be left switched on without propellers spinning in temperature above 40°C,
the electronics needs to be cooled down by the airflow generated by the propulsion system.
In such temperatures use gloves for changing the battery or wait for at least 10 minutes for
the drone to cool down in a zone where the temperature is below 30°C.
Flyability cannot guaranty the aircraft flight capability and stability if not used in temperatures
from 0°C to 50°C.
It is not recommended to operate the aircraft close to power lines, power transformers or
other areas with high electromagnetic disturbances as these may cause severe effects on the
sensors, impacting the aircraft’s stability and flying capability.
The aircraft propulsion system makes loud noises. Wearing ear protection is recommended
when flying in enclosed areas or when the aircraft is operating close to the personnel.
If you are flying in a confined or enclosed place, avoid being inside this environment with the
aircraft flying. Do not forget this topic in your risk assessment.
Avoid flying in a biohazard environment. If not applicable, avoid flying close to people and
have yourself and surrounding personnel wear eye protection and respiratory protection as
the propulsion system may blow contaminated particles to you. Also, wear gloves and appropriate protection while manipulating the aircraft and its equipment until further decontamination. Do not forget this topic in your risk assessment.
Elios should not be used in or near explosive or flammable environments,
ELIOS
2 – Checklists
ORIGINAL INSTRUCTIONS Page 14 of 22
Strictly confidential
2 Checklists
The checklists are a proposed workflow to help operating the Elios system in a safe and efficient manner. They are often updated and the latest versions are available on the my.flyability.com platform.
2.1 Mission Planning Guidelines
This checklist presents the steps that must be followed whilst planning an operation.
1. Has the Method Statement been filled?
The Method Statement (MS) is a document specifying all the different steps that will be performed during the
inspection. It will also specify all the required equipment to fulfil the mission. The “Method Statement – Template”
document offer a template to establish your own.
2. Has the Risk Assessment been filled?
The Risk Assessment (RA) is a document specifying all the risks that can occur during the progress of the mission.
It states as well the mitigation that can be made to limit the risk to occur. The “Risk Assessment – Template” document offer a template to establish your own.
3. Is the environment in which the Elios will be operated safe?
Elios is sensible to its surroundings. The mission environment must comply to the limitation presented in the “Environment Awareness” section presented in the Original Instructions.
The presence of dangerous elements must have been stated in the RA and MS documents.
4. Is there any biological hazard?
If the Elios is flying in environment that can present bio-hazard (sewer, pandemic area, etc.), the risk should be
listed within the MS or RA and appropriate measures must be taken (gloves, eye protection, mask, etc.).
5. Do you have the adequate Personal Protective Equipment (PPE)?
Even if Elios is safe to fly close to human, whilst in operation some precaution might be taken. The following PPE
must always be worn:
- Eye protection
- Head protection
- Have protective gloves in vicinity.
You must be aware of the effects of operating Elios in your working environment and dress accordingly:
- If the environment is dusty, wear respiratory protection.
- If the environment contains hazardous element, wear the corresponding PPE
Those statements must have been defined in the MS document.
6. Do you have the proper flight authorization?
If you perform outdoor flight, depending on the area and on the country in which you will conduct your flight, you
will need a specific authorization. Contact the aeronautical agency in place in your country for more information.
7. Use of the aircraft
Flyability’s products are NOT listed as dual-use products. Ensure the system is not used with the intent to harm.
ELIOS
2 – Checklists
ORIGINAL INSTRUCTIONS Page 15 of 22
Strictly confidential
2.2 Aircraft Inspection
The aircraft inspection checklist ensure the Elios is suited to fly. It should be made before each flight
and after having transporting the Elios. Remember the acronym
PEACE
.
PROPELLERS ............................... TIGHT
Propellers are tight on the motors.
ELECTRICAL MOTORS ............ MOVE FREELY
Make the motors rotate to make sure no dust, sand, or particles are inside
AIRCRAFT ...................................... CLEAR OF DAMAGE
Visually inspect the aircraft to make sure it is free from damage. Pay great attention to
carbon parts, and bottom plastic hull.
CAMERA LENS ........................... CLEAN
Clean the camera lens using the lens cleaner. It will ensure a better quality for your footage. Make also sure that the camera lens is free of stains.
ELECTRICAL SUPPLY ............... UNDAMAGED | SECURED | PLUGGED
A fully charged and in visual proper condition battery is tightly connected to the aircraft
and secured with the strap.
ELIOS
2 – Checklists
ORIGINAL INSTRUCTIONS Page 16 of 22
Strictly confidential
2.3 Take-off Checklist
Do the take-off checklist before each flight. Remember the acronym
SAFE REC.
SAFETY BRIEFING ..................... PERFORMED
All personnel surrounding the operation has been briefed about safety using the Basic
Safety Rules whilst in operation and are aware that they should avoid perturbing the
pilot.
AIRCRAFT INSPECTION ......... CHECKED
The aircraft inspection ensure the Elios is ready to fly.
FLIGHT PLAN ................................ DONE
The flight plan ensures that the Elios will fly in a safe environment and will gather data
in a consistent way.
ENVIRONMENT .......................... CHECKED
Make sure you are flying in a safe environment complying with the limitation of the system as stated in the Environmental Awareness.
RECORDING ................................. STARTED
Start the tablet’s screen recording.
ELIOS ................................................ CLEARED | SECURED | ARMED
From now on, no foreign object or body parts should be inside the Elios’ cage.
Elios is being held by the pilot.
Only then the Elios can be armed.
CLAPPERBOARD ....................... RECORDED
Show the flight plan to the camera.
ELIOS
2 – Checklists
ORIGINAL INSTRUCTIONS Page 17 of 22
Strictly confidential
2.4 After-flight Checklist
Perform the After-flight checklist after each flight. Before performing it, make sure the aircraft has been
safely landed and disarmed. Remember the acronym
SET
.
SCREEN RECORDING ............. STOPPED
Stop the tablet’s screen recording
ELECTRICAL SUPPLY ............... UNPLUGGED
Make sure the propellers are not spinning. Then disconnect the battery and place it in a
battery safe bag dedicated to the empty batteries.
TIME ................................................... LOGGED
Use the Flyability flight logbook to register your flight.
ELIOS
3 – Elios Technical Specification
3 Elios Technical Specification
Flight mode
Types
Manual thrust, altitude hold, pro mode (high speed)
Availability
Switch between modes at any time
Fail safes
Auto-landing on low-battery or signal lost
Onboard Electronics
Avionics-board
Autopilot, thermal video and system management
Power-board
Motor control
Flight system
Type
Quadcopter configuration
Dimension
Fits in < 400 mm sphere
Motors
4 electric brushless motors
Propellers
4 propellers, 5 inches
Take-off weight
700 g including battery, payload & protection
Flight time
Up to 10 mn
Max. climb rate
1.5 m/s (in normal mode) 2.5 m/s (in pro mode)
Max. airspeed
3 m/s (in normal mode) 7 m/s (in pro mode)
Wind resistance
Max. 5 m/s (in pro mode)
Sensors
IMU, magnetometer, barometer
Materials
Carbon fiber composites, magnesium alloy, aeronautical grade
aluminum, high-quality thermoplastics
Operating temperature
0 ºC to 50 ºC
Remote controller (ground system)
Type
Ergonomic joysticks and payload controls, integrated video outputs
Weight
810 g
Operating temperature
0 ºC to 40 ºC
Output ports
HDMI, SDI, USB
Battery
6000 mAh, 2S
Controls
Payload settings and aircraft control
Options
Optional remote controller (camera operator) with video stream
reception on a secondary screen, and dual control of camera settings.
Wireless communication Remote Controller to UAV
Type
Digital, bidirectional, long range, video and data downlink to remote
controller (RC), command and data uplink to UAV
Frequency
Range
Up to 500 m
Wireless communication Remote Controller to Camera Operator Remote Controller
EIRP RC to RC
4mW
Frequency
5738-5808 MHz
System power
Type
Lithium polymer battery, 3 cells, 2800 mAh, 33.08 Wh
Charging time
1 h
Battery change time
< 1 mn
2406.5 - 2476.5MHz
ORIGINAL INSTRUCTIONS Page 19 of 22
Strictly confidential
ELIOS
3 – Elios Technical Specification
ORIGINAL INSTRUCTIONS Page 20 of 22
Strictly confidential
Integrated payload
Payload head
Damped from vibrations
Upwards tilt
+80 degrees
Downwards tilt
-60 degrees
Main camera
Video
FHD (1920 x 1080) at 30 fps, good low light performance, recorded on
board and streamed to pilot and camera operator
Horizontal field of view
130 degrees
Vertical field of view
75 degrees
Total vertical field of
view
215 degrees (considering payload up/down rotation)
Control modes
Auto with EV correction, full manual mode
Thermal camera
Type
Uncooled FLIR camera core
Video
160x120 pixels at 9 fps, recorded on board
Horizontal field of view
56 degrees
Vertical field of view
42 degrees
Lighting system
Type
5 arrays of high-efficiency LEDs for even lighting in front, top, and bottom
of the robot
Control
From remote controller, adaptive light beam controlled by camera pitch
Power
11.4 W nominal power for front lighting, 28 W total installed max.
Operational safety & collision worthiness
Navigation lights
Green and red lights
Protection cage
Carbon fiber cage with soft coating, modular subcomponents for
maintenance ease, thermoplastic elastomer suspensions, size of
openings: triangles of about 11 cm sides allowing for hand to access
inside for swapping batteries
Collision tolerance
Uniform all around the drone, up to 3 m/s on sharp objects, up to 4 m/s
on flat objects
Decoupling
3-axes gimbal system, carbon fiber composite ring and transverse beam
Accessories
Transport case
IATA compliant transport case for checked-in luggage, dimensions
(approximate): 60 cm x 50 cm x 50 cm
Chargers
3 A / 35 W lithium polymer battery balance charger, with charging status
indicator, RC charger: 17.4 V, 57 W, tablet USB charger: 5 V
Mobile application used during flight (Elios Cockpit)
Features
Real time video and UAV telemetry, status visualization (remaining
battery, payload settings, warnings, etc. ), control payload settings and
various configurations.
Operating system
Android, optimized for tablet provided with UAV system
Content subject to change
To download latest version
Check on my.flyability.com
Loading...
