Fly E125 User Guide
E125 User Manual
Important safety precautions
This section contains important information on the safe and efficient operation of your
mobile device. For your safety, please refer to the guideline prior to using the phone.
Note: Failure to comply with the following precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park the vehicle first.
Switch off the phone when refueling
Do not use the phone at a refueling point (service station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical equipment
Hospitals or health care facilities may be using equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference, which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and always switch off your phone whenever it is
forbidden to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when
the phone is switched on.
Keep your phone away from small children
Keep the phone and all its parts, including accessories, out of the reach of small children.
Accessories and batteries
Use only FLY-approved batteries and accessories, such as headsets and PC data cables. Use of any
unauthorized accessories could damage you and your phone and may be dangerous.
If jewelry, keys, beaded chains, or other conductive materials touch exposed battery terminals, this
could complete an electrical circuit (short circuit), become very hot, and could cause damage or injury.
Be careful when handling a charged battery, particularly when placing it inside a pocket, purse, or
other container with metal objects.
Never use a charger or battery that is damaged in any way.
Use the battery only for its intended purpose.
If you use the phone near the network’s base station, it uses less power. Talk and standby time are
greatly affected by the signal strength on the cellular network and the parameters set by the network
operator.
Battery charging time depends on the remaining battery charge, the type of battery, and the charger
used. The battery can be charged and discharged hundreds of times, but it will gradually wear out.
When the operation time is noticeably shorter than normal, it is time to buy a new battery.
If left unused, a fully charged battery will discharge itself over time.
Use only FLY-approved batteries, and recharge your battery only with FLY–approved chargers.
Disconnect the charger from the power source when it is not in use. Do not leave the battery
connected to a charger for more than a week, since overcharging may shorten its life.
Extreme temperatures will affect the charging capacity of your battery: it may require cooling or
warming first.
Do not leave the battery in hot or cold places because the capacity and lifetime of the battery will be
reduced. Try to keep the battery at room temperature. A phone with a hot or cold battery may not
work temporarily, even when the battery is fully charged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object like a
coin, clip or pen causes a direct connection between the + and – terminals of the battery (metal
strips on the battery). For example, do not carry a spare battery in a pocket or bag where the battery
may contact metal objects. Short-circuiting the terminals may damage the battery or the object
causing the short-circuiting.
Dispose of used batteries in accordance with local regulations. Always recycle. Do not dispose of
batteries in a fire.
The phone could explode if the battery is replaced with an incorrect type.
Dispose of used batteries according to the manufacturer’s instructions.
At very high volumes, prolonged listening to a headset can damage your hearing.
To avoid risk of personal injury, do not dispose of your battery in a fire.
Do not throw your battery or mobile device in the trash.
Charger Operation
Please, read this manual before using the charger, for the correct operation of the appliance.
Important Safety Instructions
The charger should be used for Li-Ion accumulators charging only.
Do not charge other types of accumulators with this charger.
Do not expose the charger to moisture or rain.
Do not disassemble the charger or the network adapter.
Unplug the network adapter when not in use.
Do not connect this charger with the appliances or peripheral devices, which are not indicated in this
booklet.
It is not recommended to discharge the Li-Ion accumulator before charging.
For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily
accessible. The only way to turn off the charger is to unplug it.
Mobile phone shall only be connected to a USB interface that meets the requirements of a Limited
Power Source according to EN 60950-1
Recycling of accumulators
Accumulators should be disposed in accordance with established rules. It is forbidden to throw away
accumulators along with domestic garbage. If possible, use specialized organizations services for
accumulators recycling.
Damaged Products
If your mobile device or battery has been submerged in water, punctured, or subjected to a severe fall,
do not use it until you take it to FLY-Authorized and/or Qualified Service Center. Do not attempt to dry
it with an external heat source, such as a microwave oven.
Choking Hazards
Your mobile device or its accessories may include detachable parts, which may present a choking
hazard to small children. Keep your mobile device and its accessories away from small children.
Road safety
Your wireless phone gives you the powerful ability to communicate by voice, almost anywhere,
anytime. But an important responsibility accompanies the benefits of wireless phones, one that every
user must uphold. When driving a car, driving is your first responsibility. When using your wireless
phone while driving, follow local regulations in the country or region you are in.
Use and Care
Your phone is a product of superior design and craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty obligations and allow you to enjoy this product for
many years.
Keep the phone and all its parts and accessories out of the reach of small children and pets. They
accidentally damage these things or choke on small parts.
Keep the phone dry. Precipitation, humidity, and liquids contain minerals that corrode electronic
circuits.
Do not use the phone with a wet hand. Doing so may cause an electric shock to you or damage to
the phone.
Do not use or store the phone in dusty, dirty areas, as its moving parts may be damaged.
Do not store the phone in hot areas. High temperatures can shorten the life of electronic devices,
damage batteries, and warp or melt certain plastics.
Do not store the phone in cold areas. When the phone warms up to its normal operating
temperature, moisture can form inside the phone, which may damage the phone’s electronic circuit
boards.
Do not drop, knock, or shake the phone. Rough handling can break internal circuit boards.
Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-water solution.
Do not paint the phone. Paint can clog the device’s moving parts and prevent proper operation.
Do not put the phone in or on heating devices, such as a microwave oven, stove, or radiator. The
phone may explode when overheated.
When the phone or battery gets wet, phone repairs are no longer guaranteed by the manufacturer's
warranty, even if the warranty for your phone has not expired.
If your phone has a flash or light, do not use it too close to the eyes of people or animals. This may
cause damage to their eyes.
Use only the supplied or an approved replacement antenna. Unauthorized antennas or modified
accessories may damage the phone and violate regulations governing radio devices.
Do not attempt to open the phone’s casing. Non-expert handling of the phone may cause damages
to your phone.
If the phone or any of its accessories are not working properly, take them to your nearest qualified
service center. The personnel there will assist you, and if necessary, arrange for the phone to be
repaired.
Using the earpieces or stereo headset for extended time can cause a serious damage to your
hearing. Exposing sound higher than 100db for a long time, you will get possible ear damage that
could results from extensive usage of audio playback. You are strongly advised to check the volume
level to medium before using.
Do not use the phone while charging the phone. You may be electric-shocked if you use the phone
while charging the phone with the USB data cable or the battery charger. Make sure to disconnect
the USB data cable or the charger before using the phone.
Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture.
Extreme heat or cold ;Avoid temperatures below -10°C/14°F or above 40°C/104°F
Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials.
Operating Environment
Remember to follow any special regulations in force in the area you are in, and always switch off
your phone whenever it is forbidden to use it, or when it may cause interference or danger. When
connecting the phone or any accessory to another device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
Operation of any radio-transmitting equipment, including cellular phones, may interfere with
inadequately protected medical devices. Consult a doctor or the manufacturer of the medical device
if you have any questions. Other electronic equipment may also be subject to interference.
As with other mobile radio-transmitting equipment, you are advised that for satisfactory operations
and personal safety, the equipment should only be used in the normal operating position.
Always switch off the phone when refueling (service station). You are reminded of the need to
observe restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas),
chemical plants or where blasting operations are in progress.
Do not store or carry flammable liquids, gases or explosive materials in the same compartment as
the phone, its parts or accessories.
Switch off your cellular phone when in aircraft. The use of cellular phones in aircraft is illegal and
may be dangerous to the operation of the aircraft or disrupt the cellular network. Failure to observe
these instructions may lead to the suspension or denial of cellular telephone services to the offender,
legal action or both.
As with other mobile radio transmitting equipment, users are advised that for the satisfactory
operation of the equipment and for the safety of personnel, it is recommended that the equipment
should only be used in the normal operating position (held to your ear with the antenna pointing over
your shoulder).
Electronic devices
Most modern electronic equipment is shielded from radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid potential interference with the pacemaker. These
recommendations are consistent with the independent research and recommendations of Wireless
Technology Research. If you have any reason to suspect that interference is taking place, switch
you’re your phone immediately.
Hearing aids
Some digital wireless phones may interfere with some hearing aids. In the event of such interference,
you may wish to consult your hearing aid manufacturer to discuss alternatives.
Radio frequency (RF) exposure and SAR
This phone meets the requirements concerning exposure to radio waves. Your mobile phone is a radio
transmitter and receiver. It is designed and manufactured to not exceed the limits for exposure to
radiofrequency (RF) energy, as recommended by the Council of the European Union. These limits are
part of comprehensive guidelines and establish permitted levels of RF energy for the general
population. The guidelines were developed by independent scientific organizations through the
periodic and thorough evaluation of scientific studies. The limits include a substantial safety margin
designed to ensure the safety of all persons, regardless of age and health. The exposure standard for
mobile phones employs a unit of measurement known as Specific Absorption Rate (SAR).
Specific Absorption Rate (SAR) is the unit of measurement for the amount of radio frequency energy
absorbed by the body when using a mobile phone. The SAR value is determined at the highest
certified power level in laboratory conditions, but the actual SAR level of the mobile phone while it is
operating can be well below this value. This is because the mobile phone is designed to use the
minimum power required to reach the network. Variations in SAR below the radio frequency exposure
guidelines do not mean that there are variations in safety. While there may be differences in SAR
levels among mobile phones, all FLY mobile phone models are designed to meet radio frequency
exposure guidelines. Before a phone model is available for sale to the public, compliance with the
European RTTE directive must be shown. This directive includes as one essential requirement the
protection of the health and safety for the user and any other person. The SAR limit recommended by
the Council of the European Union is 2.0W/kgA
The highest SAR value for this model phone is below 0.7 W/kg.
SAR tests are conducted using standard operating positions with the phone transmitting at its highest
certified power level in all tested frequency bands.
----------------------------------------------------------------------------------------A. The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/kg) averaged
over ten grams of tissue. The limit incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in measurements. The
SAR values may vary, depending on national reporting requirements and the network band.
SIM AT Service
SIM Card provides several value-added services.
These functions will only display and work on the menu of the phone when your SIM card is supported.
The content and the terms of the function lists will depend on your network service provider.
Please contact your network service provider (a network operator or the service provider) in regards
with availability of any services related to the SIM card, application information and the costs.
Other medical devices
If you use any other personal medical devices, consult the manufacturer of your device to determine if
it is adequately shielded from external RF energy. Your physician may be able to assist you in
obtaining this information. Switch off your phone in health care facilities when regulations posted in
these areas instruct you to do so.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has been added to your vehicle.
Posted facilities
Switch off your phone in any facility where posted notices require you to do so.
Potentially explosive environments
Switch off your phone when in any area with a potentially explosive atmosphere, and obey all signs
and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or
even death.
Users are advised to switch off the phone while at a refueling point (service station). Users are
reminded of the need to observe restrictions on the use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants, or where blasting operations are in progress. Areas with a
potentially explosive atmosphere are often but not always clearly marked. They include the areas
below decks on boats, chemical transfer or storage f acilities, vehicles using liquefied petroleum gas,
such as propane or butane, areas where the air contains chemicals or particles, such as grain, dust or
metal powders, and any other area where you would normally be advised to turn off your vehicle
engine.
Emergency calls
This phone, like any wireless phone, operates using radio signals, wireless, and landline networks as
well as user-programmed functions, which cannot guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone for essential communications like medical
emergencies. To make or receive calls, the phone must be switched on and in a service area with
adequate signal strength. Emergency calls may not be possible on all wireless phone networks or
when certain network services and/or phone features are in use. Check with local service providers.
To make an emergency call:
1. Key in the emergency number for your present location. Emergency numbers may vary by location.
2. Press the Send Key.
3. Inform your location. Do not end the call until given permission to do so.
Certain features like Call Barring may need to be deactivated before you can make an emergency call.
Consult this document and your local cellular service provider.
Other important safety information
Only qualified personnel should service the phone or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate any warranty applicable to the device.
Check regularly that all wireless phone equipment in your vehicle is mounted and operating properly.
Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as
the phone, its parts, or accessories.
For vehicles equipped with an air bag, remember that an air bag inflates with great force. Do not
place objects, including installed or portable wireless equipment, in the area over the air bag or in
the air bag deployment area. Improperly installed wireless equipment could result in serious injury if
the air bag inflates.
Switch off your phone before boarding an aircraft. It is dangerous and illegal to use wireless phones
in an aircraft because they can interfere with the operation of the aircraft.
Failure to observe these instructions may lead to the suspension or denial of telephone services to
the offender, or legal action, or both.
Qualified service
Only qualified service personnel may repair your phone.
It is highly recommended to have a repair service by qualified service personnel. Use only the
approved accessories and batteries
Special features of your phone
• Touch screen
Tap any application icon with your finger to open it. Press and hold icons and drag to scroll.
• Camera and Camcorder
Use 5 Megapix Camera with AutoFocus on your phone to take a photo or record a video.
• Music player
Play music files using your phone as a music player.
• Bluetooth
Transfer media files and personal data and connect to other devices using free, wireless Bluetooth
dealer may vary,
The use of these
technology.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a combination of text, images, video, and audio.
• Flight mode
Switch your phone to use its none-wireless function in an airplane.
• E-mail
Send and receive e-mails with image, video, and audio attachments.
• Java
Enjoy Java™-based embedded game and download new games.
• Alarm
Use your phone as an alarm clock to wake you up in the morning or notify you of an impending event.
• Get personal with caller ID
See who’s calling you when their own photo ring tone plays.
Unpack
Make sure you have each item
• Phone
• Charger & USB data cable
• Battery
• User Guide
• Headset
• Stylus
• PC Sync Manager CD
• Micro SD Card
You can obtain various accessories from your local FLY dealer.
Note: • The items supplied with your phone and the accessories available at your
depending on your country or service provider.
• Use the purchased accessories with only FLY-authorized devices.
accessories with other devices could cause problems and any repair costs would not be
covered by the warranty.
Your phone
Keys, features, and locations
USB
connector
Battery
Opening
button
Left soft
key
Send key
Special Function keys
Main
display
OK key
Right soft
key
End key
Navi key
Micro SD
Volume key
Camera key
& Zoom key
Camera
Battery door
All the illustrations, simulated screen and related images used in this manual are for
en the handset and keys and content
of display used in this manual and those of your handset. Please refer to your handset for
Note:
reference only. There may be slight difference betwe
actuality
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your PIN, and available optional services.
Install and charge the phone
Push the side opening button and remove battery door
Insert the SIM card
Make sure that the gold-colored contacts on the card are
face down.
Install the battery
Replace and lock the battery door
Plug the charger into a standard AC wall outlet.
display the charging icon for a moment while charging. The phone will display the charging
7. When the phone is completely charged (the battery icon becomes still), unplug the charger
from the power outlet.
8. Remove the charger from the phone.
9. Switch the Phone On/Off
10. Enter Your Pin (Access Codes)
11. Dial the Phone Number Required
Low battery indicator
When the battery is low a warning tone sounds, the battery low message displays and the empty
battery icon blinks. If the battery level becomes too low, the phone automatically turns off. Recharge
your battery.
Note: When the battery is discharged completely, and not used for a while, the phone will not
icon after that transition period.
Power On or Off
Press and hold Power On/Off button to turn it on and off
Enter your SIM card PIN, if requested.
Access Codes
There are access codes for your SIM card. These codes help you to protect the phone against
unauthorized use.
When requested for any of the code explained below, key-in the appropriate code (displayed as
asterisks) and press the OK key.
PIN
The Personal Identification Number or PIN (4-8digits) protects your SIM card against unauthorized
use. The PIN comes with the SIM card; see the SIM card instruction provided with your card. If you
enter an incorrect PIN three times in succession, the code will be disabled and cannot be used until
you re-enable it by entering the PUK.
PUK
The 8-digit PUK (Personal Unblocking Key) is required to change a disabled PIN. The PUK may be
supplied with the SIM card. If not, or in case you have lost it, please contact your service provider.
To re-enable your PIN, proceed as follows.
1. Key-in the PUK and press the OK key.
2. Enter a new PIN of your choice and press the OK key.
3. When the Confirm New PIN message is displayed, key-in the same code again and press the
OK key.
If you enter an incorrect PUK ten times in succession, the SIM card becomes invalid. Please contact
your service provider for a new card.
Pin Password
The 4 ~ 8 digits of password is required when you use the Call barring function. You can obtain the
password from your service provider when you subscribe to this function.
Customize your phone
Display language
Select the language for your phone menus.
[Menu] [10.Settings] [10.2 Phone Setup] [10.2.3. Language]
Time and Date
Set time and date for your phone
[Menu] [10.Settings] [10.2 Phone Setup] [10.2.1. Time and Date]
Incoming call melody
[Menu] [4.User profile] [4.1 General] [4.1.2. Customize] [4.1.2.1 Tone set up]
[Incoming call]
Idle mode Wallpaper
Set wallpaper for the idle screen on the display.
[Menu] [10.Settings] [10.3 Display Characteristics] [10.3.1. Wallpaper]
Phone lock
Protect the phone against unauthorized use with a phone password. The phone will require the
password on power-up.
[Menu] [10.Settings] [10.5 Security Setup] [10.4.2 Phone Lock]
Set Dedicated Key
Set up a menu for your own favorite menu items.
[Menu] [10.Settings] [10.2 Phone Setup] [10.2.7 Dedicated key]
Keys and display
Key Definition
Soft Keys
Perform functions identified on the bottom line of the display.
OK Key
Send Key
Dial or answer a call.
In the Idle Mode, Recall the recently dialed, missed, or
received calls.
End Key
U
RL
D
End a call.
In Menu mode, cancel input and return the phone to the Idle
mode.
Navigation keys
To Scroll menu
Alphanumeric Keys
Enter numbers, letters and special characters.
Special Function Keys
Enter Special Characters
Perform Various Functions.
Side Key (On the right side of your phone)
In idle mode, adjust the Ringtone volume.
Adjust the earpiece volume during a call by pressing briefly.
Adjust the Audio Player volume.
Camera key (on the right side of your phone). In idle
mode, long press camera key launches camera application
Start “voice recording” during a call by pressing and holding
the camera key.. Stop “voice recording” by pressing the [Stop]
soft key.
A. The special function key performs various functions
1. Make the “International Call”
Press twice [*] key to display “+” character.
Input the country code, area code (without the leading zero), and the phone number. Then
press the Send Key. The “+” informs the network that it is an international call.
2. Enter the “Pause or Wait”
You may enter a pause (“P”) or a wait (“W”) character into a dial string by pressing and
holding the [*] key.
3. Activate or deactivate the “Silent mode”
To activate the “Silent Mode” option, press and hold [#] key in the idle mode.
4. To lock/unlock the phone
To lock/unlock the phone long press on left soft key. To unlock the phone using touchscreen,
slide the key towards the locker.
Loading...
